Caple C813C User Manual
Instruction manual for ceramic hob
Model code:
C813C
Contact Caple on 0844 800 3830 or for spare parts www.4caple.co.uk
Congratulations
We recommend that you spend some time reading this Instruction / Installation
Manual in order to fully understand how to install and operate it correctly
For installation, please read the installation section.
Read all the safety instructions carefully before use and keep this Instruction /
Installation Manual for future reference.
on the purchase of your new Ceramic Hob.
Product Overview
Top View
1. max. 1200 W zone
2. max. 1800 W zone
1
4
Control Panel
1
2
3
3. max. 1200 W zone
5
4. max. 1000/2200 W zone
5. Glass plate
6. ON / OFF
7. Control panel
6
1. ON/OFF control
2. Dual zone control
3. keylock control
4
4. Power regulating controls
2
3
2
Product Information
The microcomputer ceramic cooker hob can meet different kinds of cuisine
demands because of resistance wire heating, micro-computerized control and
multi-power selection, really the optimal choice for modern families.
The ceramic cooker hob centers on customers and adopts personalized design.
The hob has safe and reliable performances, making your life comfortable and
enabling to fully enjoy the pleasure from life.
Before using your New Ceramic Hob
• Read this guide, taking special note of the ‘Safety Warnings’ section.
• Remove any protective film that may still be on your ceramic hob.
Using the Touch Controls
• The controls respond to touch, so you don’t need to apply any pressure.
• Use the ball of your finger, not its tip.
• You will hear a beep each time a touch is registered.
• Make sure the controls are always clean, dry, and that there is no object (e.g. a
utensil or a cloth) covering them. Even a thin film of water may make the
controls difficult to operate.
3
Choosing the right Cookware
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits flat against the glass, and is
the same size as the cooking zone. Always centre your pan on the cooking zone.
Always lift pans off the ceramic hob – do not slide, or they may scratch the glass.
4
Using your Ceramic Hob
To start cooking
1. Touch the ON/OFF control.
• After power on, the buzzer beeps once, all
the indicators light up for 1 second then go
out, indicating that the ceramic hob has
entered the state of standby mode.
2. Place a suitable pan on the cooking zone that
you wish to use.
• Make sure the bottom of the pan and the surface
Of the cooking zone are clean and dry.
3. Select a heat setting by touching the or
control.
"+"
• If you don’t choose a heat setting within 1
minute, the ceramic hob will automatically
switch off. You will need to start again at
step 1.
• You can modify the heat setting at any time
during cooking.
• By holding down either of these buttons, the
value will adjust up or down.
"-"
5
When you have finished cooking
1a. Turn the cooking zone off by scrolling down to “-“ or touching and
control together.
"-"
control.1b. Turn the whole hob off by touching the ON/OFF
"+"
2. Beware of hot surfaces
will show which cooking zone is hot to touch. It will disappear
when the surface has cooled down to a safe temperature. It can also be
used as an energy saving function if you want to heat further pans, use
the hotplate that is still hot.
6
