Caple C621 User Manual
Page 1
C621 C721 user manual.DOC
DOMINO HOBS
C621 & C721
INSTALLATION AND OPERATING
INSTRUCTION BOOKLET
IMPORTANT: You must read this instruction Book before
installing or using this appliance and retain it for future use.
Caple Products
Telephone 0870 2411142
Facsimile 0117 982 6878
Page 2
C621 C721 user manual.DOC
The manufacturer cannot be held responsible for possible inaccuracies due to printing or transcription
errors in this booklet. The manufacturer reserves the right to make all modifications to its products
deemed necessary for manufacture or commercial reasons at any moment and without prior notice,
without jeopardising the essential functional and safety characteristics of the appliances.
Dear Customer
Thank you for purchasing our product. The safety precautions and recommendations
reported below are for your own safety and that of others. They will also provide a means
by which to make full use of the features offered by your appliance.
Please preserve this booklet carefully. It may be useful in future, either to yourself or to
others in the event that doubts should arise relating to its operation.
This appliance must be used only for the task it has explicitly been designed for,
that is for cooking foodstuffs. Any other form of usage is to be considered as
inappropriate and therefore dangerous.
The manufacturer declines all responsibility in the event of damage caused by
improper, incorrect or irrational use of the appliance.
IMPORTANT PRECAUTIONS AND RECOMMENDATIONS
• After having unpacked the appliance, check to ensure that it is not damaged. If you
have any doubts, do not use it and consult your supplier or a professionally qualified
technician.
• Packing elements (i.e., plastic bags, polystyrene foam, nails, packing straps, etc.) should
not be left around within easy reach of children, as these may cause serious injuries.
• The packaging material is recyclable and is marked with the recycling symbol
• Do not attempt to modify the technical characteristics of the appliance as this may
become dangerous to use.
• The manufacturer cannot be considered responsible for damage caused by unreasonable,
incorrect or rash use of the appliance.
• If you should decide not to use this appliance any longer (or decide to substitute with a
newer model), before disposing of it, it is recommended that it be made inoperative in an
appropriate manner in accordance to health and environmental protection regulations,
ensuring in particular that all potentially hazardous parts be made harmless, especially in
relation to children who could play with old appliances.
• The appliance should be installed and all the gas/electrical connections made by a
qualified engineer in compliance with local regulations in force and following the
manufacturer's instructions
TIPS FOR THE USER
•
During and after use of the cook top, certain parts will become very hot. Do not touch
hot parts.
•
Keep children away from the cooking hob when it is in use.
•
After use, ensure that the knobs are in position • (off), and close the main gas delivery
valve or the gas cylinder valve.
•
In case of difficulty in the gas taps operation, call Service.
•
Before any cleaning or maintenance, switch off the electricity to the cook top.
Page 3
C621 C721 user manual.DOC
•
Do not leave inflammable material on the cook top.
•
Make sure that the electrical cables of other appliances installed nearby cannot come
into contact with the cook top.
•
Never cook the food directly on the electric hotplates, but in suitable pans or containers.
IMPORTANT PRECAUTIONS AND RECOMMENDATIONS FOR USE OF ELECTRICAL
APPLIANCES
Use of any electrical appliance implies the necessity to follow a series of fundamental rules.
In particular: -
•
Never touch the appliance with wet hands or feet;
•
Do not operate the appliance barefooted;
•
Do not allow children or disabled people to use the appliance without your supervision.
The manufacturer cannot be held responsible for any damages caused by improper,
incorrect or unreasonable use of the appliance.
DECLARATION OF CE CONFORMITY
These instructions are only valid for use in the UK.
This cooking hob has been designed to be used only for cooking. Any other use (such as
heating a room) is improper and dangerous.
This cooking hob has been designed, constructed, and marketed in compliance with:
Safety requirements of the "Gas" Directive 90/396/EEC;
Safety requirements of EEC Directive "Low voltage" 73/23 (gas or gas/electric appliances);
Safety requirements of EEC Directive "EMC" 89/336 (gas or gas/electric appliances);
Requirements of EEC Directive 93/68.
FEATURES
“2 GAS" COOKING HOB (Fig. 1.1)
The appliance has class 3
1. Semi rapid burner (SR) - 1,75 kW
2. Rapid burner (R) - 3,00 kW
3. Burner 2 (R) control knob
4. Burner 1 (SR) control knob
5. Electric gas-lighting pushbutton.
CAUTION:
• If the burner is accidentally extinguished, turn the gas off at the control knob and wait
at least 1 minute before attempting to relight,
• Gas hobs produce heat and humidity in the environment in which they are installed.
Ensure that the cooking area is well ventilated by opening the natural ventilation grilles
or by installing an extractor hood connected to an outlet duct.
• If the hob is used for a prolonged time it may be necessary to provide further ventilation
by opening a window or by increasing the suction power of the extractor hood (if fitted).
Page 4
C621 C721 user manual.DOC
" 2 ELECTRIC" COOKING HOB (Fig. 1.3)
Electrical insulation Class I.
Overheating surfaces protection Type Y.
1. Electrical plate Q) 145 - (1000 W - 1500 W)
2. Electrical plate 0 180 - (1500 W - 2000 W)
3. Electrical plate 1 control knob
4. Electrical plate 2 control knob
5. Power indicator light
GAS BURNERS
Gas flow to the burners is adjusted by turning the knobs
(illustrated in fig. 2.1 b) which control the safety valves.
Turning the knob so that the indicator line points to the
symbols printed on the panel achieves the following functions:
Full circle • = closed valve
Full circle = maximum aperture or flow
Full circle = minimum aperture or flow.
To light one of the gas burners, hold a flame (e.g. a match) close to
the top part of the burner, push in and turn the relative knob in an
anti-clockwise direction, pointing the knob indicator towards the
large flame symbol (i.e. max. gas flow).
To reduce the gas flow to minimum, rotate the knob further
anti-clockwise to point the indicator towards the small flame symbol.
The maximum aperture position permits rapid boiling of liquids,
whereas the minimum aperture position allows slower warming of
food or maintaining boiling conditions of liquids.
Other intermediate operating adjustments can be achieved by positioning the indicator
between the maximum and minimum aperture positions, and never between the maximum
aperture and closed positions.
N.B. When the cooker top is not being used, set the gas knobs to their closed
positions and also close the cock valve on the gas bottle or the main gas supply
line.
PUSH BUTTON ELECTRIC SPARK-LIGHTING GAS
To light one of the burners you have to push in and turn the relative knob to the maximum
aperture position (large flame symbol) and press the electric lighter button (fig. 2.2) until
the flame has been lit.
Adjust the gas valve to the desired position.
Page 5
C621 C721 user manual.DOC
CHOICE OF BURNER (fig. 2.4)
The symbols printed on the panel beside the gas knobs indicate the correspondence
between the knob and the burner. The most suitable burner is to be chosen according to the
diameter and volume capacity of the container to be warmed. It is important that the
diameter of the pots or pans suitably match the heating potential of the burners in order not
to jeopardize the efficiency of the burners, bringing about a waste of gas fuel. A small
diameter pot or pan placed on a large burner does not necessarily mean that boiling
conditions are reached quicker.
DIAMETERS OF PANS WHICH MAY BE USED ON THE H OBS
Do not use pans with concave or convex bases
Caution!
The cooking hob becomes very hot during operation. Keep children well out of
reach.
NORMAL HOTPLATE
To turn on the electric hotplate, rotate the knob (fig. 3.1 - 3.2) to
the desired setting. The numbers from 1 to 6 or 1 to 12 indicate
the operating positions with increasing number corresponding to
higher temperature settings When the pan comes to the boil, turn
the heat down to the level desired.
Remember that the hotplate will continue to produce heat for
about five minutes after it has been turned off.
RAPID HOTPLATE (red dot)
The rapid hotplate control knob is similar to that of the normal
hotplate, with 6 or 12 selectable heating positions (fig. 3.1 - 3.2).
The characteristics of this hotplate, which is also equipped with a
thermostatic cut-off device, make it possible to:
• Achieve the cooking temperature rapidly.
• Make full use of its output power using flat-bottomed pans
• Limit the output power with unsuitable saucepans.
• Never cook food directly on the electric hotplates always use a saucepan or
suitable container.
• Caution! the cooling hob becomes very hot during operation.
• Keep children well out of reach.
BURNERS
Minimum
Maximum
Semi rapid
Rapid
12 cm
22 cm
Page 6
C621 C721 user manual.DOC
PROPER USE OF THE ELECTRIC HOTPLATE (fig. 3.3)
When the pan comes to the boil, turn the heat down to the level
desired.
• Remember that the hotplate will continue to produce heat for
about five minutes after it has been turned off.
• While using the electric hotplate, you must:
• Avoid keeping it on without something on it;
• Avoid pouring liquids on it while it is hot;
• Use flat-bottomed (electric hotplate type) pots and pans only
• Use cooking receptacles which cover as much of the surface
of the hotplate as possible.
• To save electricity, use lids whenever possible.
• Never cook food directly on the hotplate: always use a pan or suitable container.
An indicator light located close to the control panel signals that the hotplate is operating
ELECTRIC HOTPLATE USAGE
TABLE
Position
of switch
TYPE OF COOKING
0
0
Switched OFF
1/2
1/2
For melting operations (of butter or chocolate)
2
2/3/4
To keep foods warm or heat small quantities of water.
3
4/5/6
To heat greater quantities of water and to whip creams and sauces.
3/4 6/7
Slow boiling, e.g. spaghetti, soups, boiled meats, to continue steam heating
of roast meats and stews.
4
7/8
For all kinds of fried foods, meats and steaks, cutlets and cooking without a
lid.
4
8/9/10
For browning of meat, cooked potatoes, fried fish and for boiling large
quantities of water.
6
11/12
Rapid frying, grilled steaks, etc.
