INSTALLATION AND OPERATING

INSTRUCTION BOOKLET

LIBERTY SINGLE ELECTRIC FAN OVEN

MODELS C210 F/A & C210 F/W

IMPORTANT: You must read this instruction Book before

installing or using this appliance and retain it for future use.

Caple Products

Telephone [phone]

Facsimile 0117 982 6878

Page 2

C210 user manual.doc

Thank you for buying your new CAPLE Built-under oven. To ensure that you get

the best results from your new Built-under oven, we strongly suggest that you

read this instruction manual thoroughly before use. This manual contains instal-

lation advice, usage instructions and a cleaning guide, as well as other important

facts about your CAPLE Built-under oven. If treated with care, your CAPLE Built-

under oven should give you years of trouble-free cooking.

IMPORTANT WARNINGS AND ADVICE

After unpacking, make sure that the appliance is in perfect order. If you have any doubt, do
not use it and contact the retailer or call a qualified engineer.

Pieces of packing (plastic bags, polystyrene, nails, metal, etc.) must not be left within the
reach of children because they are potential sources of danger.

• do not try to modify the appliance's technical characteristics because this could be
dangerous

• do not clean or maintain the appliance without previously disconnecting it

• when you decide not to use this appliance any more or if you want to throw away your

old appliance, before dumping it, make it unusable following the procedure laid down by
the standards in force concerning protection of health and the environment. The parts
which could be dangerous to children, must be made harmless.

WARNING AND USEFUL ADVICE FOR USING ELECTRICAL APPLIANCES

The use of an electrical appliance involves the observance of certain fundamental
precautions. In particular:

• do not touch the appliance with wet hands or feet

• do not use the appliance without footwear

• do not let children or people who are not capable, use the appliance without supervision.

The manufacturer declines any responsibility for damage caused by incorrect, mistaken or
irrational use.

For Spare Parts, Technical Advice

or Product Service call the

CAPLE HELPLINE on 0870 2411142

(Answer phone outside office hours)

Page 3

C210 user manual.doc

SAFETY REMINDERS

Instruction Book

This appliance should only be used for its intended purpose as described in these
instructions.

Ensure that you fully understand these instructions before operating this appliance.

Space Requirements

Ensure that the specified ventilation space around the appliance is not obstructed.

Food Splashes

Always wipe clean the oven after use. Food splashes can carry on cooking next time and
may become a fire hazard.

Hot Surfaces

It is important to remember that the surfaces of cooking appliances get hot during use and
retain the heat for some time after switching off.

It is therefore advisable to keep small children away from the appliance.

The Grill and Top oven element

Are exposed, so take great care when placing food in the oven or removing it. Use the grill
panhandles or gloves.

DO NOT line the oven, grids, trays etc. with aluminum foil as this could adversely affect the
heating elements and it could also damage the interior surfaces.

DO NOT place flammable materials in the oven.

Faults

Do not continue to use this appliance if it appears to be faulty.

After Use

Switch the oven controls off.

Always switch off at the isolating switch before cleaning the appliance, or attempting any
maintenance task, or when not in use for long periods (when on holiday).

CAPLE Service

To ensure the continued safe and efficient operation of this appliance, we recommend that
any servicing or repairs are carried out only by an authorised CAPLE SERVICE ENGINEER.

Page 4

C210 user manual.doc

ELECTRICAL REQUIREMENTS

This Installation should be carried out by a competent
electrician in accordance with current I.E.E. Regulations.

This CAPLE product must be connected to an electricity
supply at the voltage shown on the rating plate. Connection
must be made via a double pole-isolating switch with a
contact separation of at least 3mm.

Use supply cable, having a minimum conductor
cross-sectional area of 1.25 mm2.

Where both hob unit and an oven are to be installed

adjacent to each other, both appliances may be
supplied via the same double pole-isolating switch using

separate supply cables. Check that the total loading of the installation is within the capacity
of the double pole isolating switch and the supply circuit.

Allow sufficient length in the supply cable(s) for removal of the appliance(s) for any
subsequent servicing. Ensure that this extra cable is not trapped and is not in contact with
the underside of any hob when fitting the appliance(s) in position.

As with all electrical appliances always switch off the electricity supply when not in use for
long periods (when on holiday) and before attempting any maintenance task.

Fitting Into position

Your new CAPLE oven is designed to fit into a kitchen unit, which is at least 550 mm deep.

Before proceeding with the installation, check that the oven will fit into the space intended
for it, appropriate ventilation slots are provided as per installation instructions on page 5 and
that all packing material has been removed.

IMPORTANT

Materials used to build the oven housing must be capable of withstanding temperatures of
up to 100°C and the housing must be firmly fixed in position.

WARNING!

ELECTRICITY CAN BE

EXTREMELY

DANGEROUS.

THIS APPLIANCE

MUST BE

EARTHED.

Before Use

• Check that all accessories have been removed from the oven interior.

• Set the temperature to 225°C using the temperature control knob.

• Leave on for approximately 30 minutes. This will burn off any protective coating applied

to the oven during manufacture.

• The kitchen should be well ventilated during this time as there may be an odor given off.

• When cool, wash the accessories and the oven with warm water and mild detergent.

Page 5

C210 user manual.doc

ELECTRICAL INSTALLATION

1. This appliance must be connected to a double pole isolating switch (fig. 1) and to the

terminal block in the oven (figs. 2 & 3) using the following guide:

2. The wire which is coloured brown must be connected to the terminal marked L

(Live), or coloured Red.

3. The wire which is coloured blue must be connected to the terminal marked N

(Neutral), or coloured Black.

4. The wire which is coloured green and yellow must be connected to the terminal

marked E (Earth), or coloured Green.

IMPORTANT: These connections must be carried out by a qualified electrical
engineer.
