Caple C165R Instruction Manual

Page 1 of 9

C155L C165R user manual.DOC

C155L Larder

Fridge

& C165R 3* Star

Fridge

INSTRUCTIONS FOR USE

Caple Quality Products

Consumer Help Line 0870 2411142

Page 2 of 9

C155L C165R user manual.DOC

Thank you for purchasing this Caple appliance which, if these instructions are
followed, will give you many years trouble free service.

Please keep these instructions for use close at hand and available to anyone
other than yourself who may use the appliance. By following all the
recommendations made in the instructions you will be able to make the best
possible use of your new appliance's facilities.

Should you have any queries on this product, please call our Customer Service
desk on: 0870 2411142

Please be ready to supply details of your appliance. We will need to know the
Model Number. Serial number and colour. You will find these details on the data
badge which is attached to the inside cabinet.

GUARANTEE

This appliance is guaranteed for a period of 12 months against faulty materials. In the
unlikely even of a service engineer being required please call our help desk on 0870

2411142. You will need to provide the engineer with a copy of the invoice to

confirm date of purchase. Without this information work will be on a chargeable basis.

This appliance is designed for domestic use only. Use for any other purpose will
invalidate any warranty claim.

The manufacturer declines all liability for any direct or indirect damage if these regulations
are not complied with.

• Always keep the instruction manual and, if you sell the equipment, hand it over to the
new owner.

• This equipment must not be installed outdoors, not even under the cover of roofing; it is
extremely dangerous to expose it to rain, storms and bad weather in general.

• We recommend waiting at least an hour before connecting the equipment so that the oil
in the cooling circuit is perfectly efficient.

• The equipment must be used exclusively for domestic preservation and/or freezing of
food.

• Packaging materials such as plastic bags, polystyrene, plastic tape must be kept out of
reach of children, as they are potential sources of danger.

• Do not allow children to play with the equipment, e.g. sitting in the drawers or swinging
on the door. The refrigerator could tip over or objects on top might fall off.

• Do not use the mouldings, drawers, doors or grids to stand on.

• Be careful not to damage the cooling fluid circuit during positioning, installation or

cleaning.

• Having installed the equipment make sure it's not resting on the power cable.

• It is not advisable to use extensions or multiple plugs for connecting to the power

supply. Never touch or operate with bare feet or wet hands or feet.

• Before carrying out any cleaning or maintenance operations, disconnect the equipment
at the power outlet or switch off your entire power system.

• Each grid or basket can take a maximum distributed load of 18 kg.

• To disconnect the equipment from the mains supply, remove the plug but don't do this

by pulling the cable.

Page 3 of 9

C155L C165R user manual.DOC

• Don't put glass bottles or other containers in the freezer compartment as they might
crack or break when the contents are frozen.

• Avoid flames or sparks inside the equipment.

• Do not consume food of which the storage deadline has expired, as this may cause food

poisoning.

• Do not obstruct the equipment's ventilation openings/grills.

• During defrosting, never use metallic objects to accelerate the process. Failure to

observe this rule could cause irreparable damage to the cooling fluid circuit.

• Do not use electrical appliances (ice-cream makers, deodorizers, etc.) inside the
equipment.

• Any maintenance, including replacement of the power cable, must be done by
the technical assistance service or other qualified personnel. To ignore this
rule is to run a very dangerous risk.

• This equipment is made for use in contact with foods and complies with
D.L.108, 25.01.92 (EEC Directive 89/109).

• This equipment is designed, built and sold in accordance with:

EC Directive 73/23 - LOW VOLTAGE

EC Directive 89/336 - EMC

EC Directive 93/68 - EC markings

EC Directive 96/57 - energy efficiency

ENVIRONMENTAL INFORMATION

This equipment was designed and built with the maximum respect for the environment. To
guarantee the same scrupulosity when it's disposed of (given the presence of pollutant or
inflammable materials, e.g. lubricant in the compressor), never abandon the equipment
outside. Contact the local authority responsible for collection and disposal. Don't throw the
packaging material from your equipment in the rubbish but sort the various materials (e.g.
polystyrene, cardboard, plastic bags) as required by local waste disposal authorities in
pursuance of current legislation.

This equipment does not contain CFCs (the cooling circuit contains R134a) or
HFCs (the cooling circuit contains R600a - ISOBUTANE).

To check what gas is used, see the technical data plate on the equipment.

For equipment with ISOBUTANE (R600a)

• Isobutane is a natural gas that doesn't affect the environment, but it is inflammable. It is
therefore essential to check that the cooling circuit tubing is not damaged before
connecting the equipment to the mains.

• For every 8 g of cooling fluid, the installation location must have a minimum volume of 1
cubic metre. The amount of cooling fluid in the appliance is indicated on the technical
data plate inside the refrigerator.

• Leakage of cooling fluid: avoid naked flames or other sources of ignition at the seat of
the leakage.
