Capital MCR364GN Specifications
precision series ™
36”
Manual Clean
Crafted With You In Mind
36” MANUAL CLEAN OVEN FEATURES
Large 4.9 cu. ft oven cavity with 4.4 cu. ft usable capacity - 27”W x 15”H
x 21”D
Oven ts full size commercial cookie sheet (26” x 18”)
Convection Oven with seperate Fan On/Off switch
30,000 BTU Bake Burner for uniform cooking
18,000 BTU Infrared Broil Burner for perfect searing
5 Rack positions (2 racks provided) for all cooking needs
Dual 40 W oven lights provide excellent interior illumination
All stainess steel and glass door allow wall to wall visibility and easy
cleaning
Black porcelain with Titanium speck oven interior
Front and rear levelers allow 1-1/2” height adjustment
Broil Pan provided
WARRANTY
TWO (2) years full parts and labor covers entire product (light bulbs
covered for 60 days after installation).
FIVE (5) years limited part replacement warranty. Covers part
replacement, as noted, due to malfunction during normal operation.
Ranges*, Range Tops*, and Ovens*: All Burners, Heating Elements,
Grates*, Griddle Plates, and Oven Racks
MCR364G
36” SEALED BURNER RANGE TOP FEATURES
Four Sealed Burners rated at 19,000 BTU/hr each
All burners turn down to a true simmer
Porcelain coated cast iron grates
12” Thermo-griddle
Flush island trim is standard for non-combustible or island trim installations
Wall mount back guard provided for combustible rear wall installation
(wall mounted stainless steel High Back accessories also available)
OVEN MODES
Bake, Broil, & Convection Bake
Barbeques: Gas Valves and all burners (excluding infrared burners)
*Excludes Porcelain Enamel Coating for ovens and grates. Porcelain
enamel is prone to wear over time and use.
LIFETIME warranty (non-transferable) on stainless steel sheet metal body
parts against rust (excludes damage and normal heat discoloration). Does
not include barbeque grates.
Capital exclusive feature: Power-Flo burners
19,0000 BTU to a low delicate simmer.
Flush island trim is standard for
non-combustible or island trim installations.
Oven fits full size commercial cookie sheet
(26” X 18”)
ADD COLOR TO YOUR COOKING
All indoor ranges from Capital Cooking are available in a timeless
stainless steel or color nish.
Choose from the RAL color palette, one that really cooks for you.
MCR364G – 36”
FOUR BURNER GAS CONVECTION RANGE
W / 12” THERMO-GRIDDLE
TM
CABINET PREPARATION
AVAILABLE ACCESSORIES
P36SLB - 9” Wall Mount Stainless Steel Low Back
P36SHB - 18” Wall Mount Stainless Steel High Back
P36SHS - 18” Wall Mount Stainless Steel High Shelf
PSWK-RNG - Cast Iron Wok Ring
COMPLIMENTARY PRODUCTS
PSVH36 - 36” Performance Series vent hood with 1,200 CFM blower
PSVH36HL - 36” Performance Series vent hood with 1,200 CFM blower
and 2 heat lamps
GRT24WK - 30,000 BTU built in Power-WokTM range top
SHIPPING WEIGHT
420 LBS
ELECTRICAL RATINGS
VOLTAGE
120 VAC
CURRENT/POWER
4 AMP
FREQUENCY
60 HZ
GAS RATINGS
Manifold:
NATURAL GAS
5.0” W.C.
PROPANE
10” W.C.
OTHER
“0” Clearance base cabinet installation
Field convertible to LP or NG depending on gas type
ETL certied for USA and Canada
Capital Cooking Equipment Inc.
13211 Florence Ave.
Santa Fe Springs, CA 90670
25-1/8”
Phone: 562-903-1168
Toll Free: 866-402-4600
E-mail: sales@capital-cooking.com
Made in the U.S.A.
Visit our web site:
www.capital-cooking.com
