SOMMERSET COLLECTION CONCRETE TABLE
PRODUCT NO. TRA54QC
MODEL N0. 088-0747-6
ASSEMBLY INSTRUCTIONS
Toll-free: 1-877-539-7436
IMPORTANT: Read this manual carefully before beginning assembly of this product.
Keep this manual for future reference.
2
Parts List 2
Assembly 3
TABLE OF CONTENTS
IMPORTANT: Retain for future reference and read carefully.
1 A
2 B
C
TABLE TOP - 1
LEG A - 1
BOLT M6*16 - 8
BOLT CAP M6 - 8
D
HEX KEY WRENCH 6 MM - 1
Use the correct bolts as indicated. Do not tighten any of the bolts until the table is completely assembled.
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed by children.
Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
!
!
!
!
PARTS LIST
WASHER d6.5*D13*1.0 - 8
3
LEG B - 1
4
CENTRE CONNECTOR - 1
3
MODEL NO. 088-0747-6
Step 1:
Requires: 2 and 3
Insert leg A (2) into the centre gap of leg B (3).
2
3
ASSEMBLY
Step 2:
Requires: 2, 3, 4, A, B, C, and D
Fasten the centre connector (4) to leg A (2) and leg B (3) by using bolts (A) and washers (B).
Fully tighten with the hex key (D).
A
A
C
C
DB
B
4
4
3
2
Step 3:
Requires: 1, 2, 3, A, B, C and D
Place the table top (1) onto a non-abrasive surface, such as a carpet, with its underside
facing upwards. Fasten leg A (2) and leg B (3) to the underside of the table top (1) rim by
using bolts (A) and washers (B). Fully tighten with the hex key (D). Make sure that all of
the bolts have been tightened
completely and cover them with bolt caps (C).
Step 4:
Turn the table to its upright position and discard of the EPE paper.
MODEL NO. 088-0747-6
4
ASSEMBLY
A C DB
A
C
B
Note:
Do not dispose of the EPE paper until the product is fully assembled.
EPE Paper
Cleaning and Maintenance
•Wash frame parts with mild soap and water, rinse thoroughly, and dry completely. Do not use
bleach, acid, or other solvents on the frame parts.
•Inspect and tighten all bolts and fasteners on a regular basis to ensure the proper performance
and safety of your table.
•When moving the table, remove the umbrella and lift. Do not drag this table.
•We recommend the use of furniture covers when not in use.
•In order to prolong the life and beauty of your table, we recommend that it be stored in a dry and
protected area during off-season periods.
•The umbrella should be lowered and/or removed in windy conditions.
3
2
1
Made in China
Imported by
Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8
