BLAIRE OFFICE CHAIR
Product No. 068-7859-2
ASSEMBLY INSTRUCTIONS
IMPORTANT: Please read this manual carefully before beginning assembly of this product.
Keep this manual for future reference.
2
Table of Contents
Important Safety Instructions
Parts List
Assembly
Technical Specications
Warranty
Warning!
Use this product only one person at a time.
Do not use this chair unless all bolts, screws and knobs are securely tightened.
Check that all bolts, screws and knobs are tightened every three months or as needed.
Do not overturn back tilt knob when decreasing tension.
Dispose of packing material properly. Do not use plastic cover as head covering,
as it may cause suocation.
Do not use chair as a stepladder.
Use this chair for its intended purpose only.
To reduce the risk of injury, read the following safety instructions
before assembling.
2
2
3
4
6
6
TABLE OF CONTENTS
Table of Contents
IMPORTANT SAFETY INSTRUCTIONS
Product No. 068-7859-2
3
1
Casters (5)
2
PARTS LIST
Base
3
Cylinder
Parts List
4
Seat plate
5
Seat cushion
6
Back cushion
7
Arms
8
9
Screws (5/16’’ x 20 mm) (4)
10
Screws (M8 x 50 mm) (4)
12
Hex wrench
Screws (M6 x 25 mm) (4)
11
Plastic caps (4)
Model No. 068-7568-8
Step 1
Requires 1, 2, 3,
Insert ve casters 1 into base 2.
4
(3)
Push hard until you feel or hear the
caster 1 snap into place.
Insert cylinder 3 into base 2.
Step 2
Requires 4, 5, 8, 12,
Assembly
Attach seat plate 4 to seat cushion 5 with
the arrow towards the front of the chair.
Insert four screws 8 into the seat plate 4.
Fully tighten all screws using hex wrench 12.
Step 3
Requires 1, 2, 3, 4, 5, 8,
Place the seat plate 4 on top of cylinder 3
and apply downward pressure.
Step 4
⑻
FRONT
(2)
(1)
ASSEMBLY
⑷
⑸
( 4 )
( 3 )
Requires 1, 2, 3, 4, 5, 6, 8, 9, 12,
Open the velcro on both sides of seat rst,
then place the back cushion 6 on the seat
cushion 5 and use two screws 9 to attach
the lower screw holes on seat cushion 5.
Step 5
Requires 1, 2, 3, 4, 5, 6, 8, 9, 12,
Push the back cushion 6 up to a vertical
position and attach the seat cushion 5
by using two screws 9 then cover the
velcro back.
Step 6
Requires 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12,
Attach arms 7 to seat cushion 5 and back
cushion 6 using four screws 10.
Tighten screws using hex wrench 12,
⑽
⑼
⑺
⑼
⑼
⑹
⑹
⑸
⑼
⑸
⑽
then cover the caps 11.
5
ASSEMBLY
ASSEMBLY
Now your chair is ready for use. Enjoy!
6
Dimensions (H x W x D)
37 13/32-41 5/16 x 24 13/32 x 25 13/64’’
(95-105 x 62 x 64 cm)
Technical Specications
This CANVAS™ product carries a one (1) year warranty against defects in workmanship
and materials.Trileaf Distribution agrees to replace the defective product free of charge
within the stated warranty period,when returned by the original purchaser with proof of
purchase. This product is not guaranteed against wear nor breakage due to misuse and/
or abuse.
Made in China.
Imported by Trileaf Distribution Trifeuil, Toronto, Canada M4S 2B8
TECHNICAL SPECIFICATION
WARRANTY
