HARLOW
ELECTRIC FIREPLACE
MODEL NO. 064-3504-2
ASSEMBLY INSTRUCTIONS
Toll-free: 1-888-670-6684
IMPORTANT: Please read this manual carefully before beginning assembly of this product.
Keep this manual for future reference.
IMPORTED BY TRILEAF DISTRIBUTION TRIFEUIL TORONTO, CANADA M4S 2B8
MADE IN CHINA
Important Safety Information 3
Parts List 6
Assembly 7
Operating Instructions 15
Cleaning and Maintenance 16
Troubleshooting Guide 18
3
Warranty 19
Warning! To reduce the risk of serious injury, read the following safety
instructions before assembling and operating this fireplace.
This equipment has been tested and found to comply with the limits for Class B
digital devices, pursuant to part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. The equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on. The user is encouraged to try
and correct the interference by one or more of the following measures:
@S]`WS\b]``SZ]QObSbVS`SQSWdW\UO\bS\\O
7\Q`SOaSbVSaS^O`ObW]\PSbeSS\bVSS_cW^[S\bO\RbVS`SQSWdS`
1]\\SQbbVSS_cW^[S\bW\b]O\]cbZSb]\OQW`QcWbRWTTS`S\bT`][bVObb]eVWQV
the receiver is connected.
1]\acZbbVSRSOZS`]`O\Sf^S`WS\QSR`ORW]BDbSQV\WQWO\T]`VSZ^
TABLE OF CONTENTS
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that
may cause undesired operation.
Modifications not approved by the party responsible for compliance could void
user’s authority to operate the equipment.
BVWa1ZOaa0RWUWbOZO^^O`ObcaQ][^ZWSaeWbV1O\ORWO\713A!
IMPORTANT: Retain for future reference, and read carefully.
IMPORTANT SAFETY INFORMATION
4
MODEL NO. 064-3504-2
When using electrical appliances, basic precautions should always be followed to reduce
the rise of fire, electric shock and injury to persons, including the following:
Read all instructions before installing or using the replace.
DANGER: If the information in this manual is not followed exactly, an electric shock or
fire may result causing property damage, personal injury or loss of life.
WAR N ING: This appliance is hot when in use. To avoid burns, DO NOT let bare skin
touch hot surfaces. Keep combustible material, such as furniture, pillows, bedding,
papers, clothes and curtains, at least 3’ (1 m) from the front of the heater and keep them
away from the side and rear.
WAR N ING: Extreme caution is necessary when any heater is used by or near children or
individuals with disabilities and whenever the fireplace is left operating and unattended.
WAR N ING: DO NOT run cord under carpeting. DO NOT cover cord with throw rugs,
runners, or similar covering. Arrange cord away from traffic areas and where it will not
be tripped over.
WAR N ING: Do NOT insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electric shock or fire, or damage the appliance.
IMPORTANT SAFETY INFORMATION
WAR N ING: This appliance has hot and arcing or sparking parts inside. DO NOT use
it in areas where gasoline, paint or flammable vapours or liquids are used or stored.
This fireplace should not be used as a drying rack for clothing. Christmas stockings or
decorations should not be hung in the area of it.
Use this appliance only as described in the manual. Any other use is NOT recommended
by the manufacturer and may cause fire, electric shock or injury to persons.
CAUTION!
If possible, ALWAYS unplug this appliance when not in use.
DO NOT operate any heater with a damaged cord or plug or after the heater malfunctions.
DO NOT operate any heater if it has been dropped or damaged in any manner. Disconnect power at service
panel and have heater inspected by a reputable electrician before reusing.
Any repairs to this fireplace should be carried out by a qualified service person.
Under no circumstances should this fireplace be modified. Parts having to be removed for servicing must be
replaced prior to operating this fireplace again.
DO NOT use outdoors.
This heater is not intended for use in bathrooms, laundry areas and similar indoor locations. NEVER place
heater where it may fall into a bathtub or other water container.
To disconnect this appliance, turn controls to the off position, then remove plug from outlet.
ONLY connect to properly-grounded outlets.
This appliance, when installed, must be electrically grounded in accordance with local codes, with the
current CSA C22.1 Canadian Electrical Code or follow the National Electrical Code, ANSI/NFPA N0.70.
To prevent a possible fire, DO NOT block air intakes or exhaust in any manner. DO NOT use on soft surfaces,
like a bed, where opening may become blocked.
The heaters MUST NOT be located immediately below a socket-outlet.
ALWAYS plug heaters directly into a wall outlet/receptacle. NEVER use with an extension cord or
relocatable power tap (outlet/power strip).
There is a thermostat device provide inside of the unit. If the inner temperature overheats or abnormal
heating occurs, the thermostat device will cut off power supply to prevent damage or risk of fire.
DO NOT slide insert on top of wood to avoid scratching wood surface.
DO NOT place any objects on top of insert and top air intake vents as this will cause unit to overheat and
can cause a fire.
Electrical Specifications
Voltage 120 V AC, 60 Hz
Amps 11.7 A
Watts 1,400 W
Electric Connection
A 15 A, 120 V, 60 Hz circuit with a properly-grounded outlet is required. Preferably, the fireplace will be on a
5
dedicated circuit as other appliances on the same circuit may cause the circuit breaker to trip or the fuse to
blow when the heater is in operation. The unit comes standard with 6’ (1.8 m) three-wire cord, exiting from
the rear of the fireplace. DO NOT exceed the current rating of the current tap. ALWAYS plug heaters directly
into a wall outlet/receptacle. NEVER use with an extension cord or relocatable power tap (outlet/power
strip).
This heater is for use on 120 V. The cord has a plug as shown below. See illustration for grounding
instruction. An adaptor as shown in Fig. C is available for connecting three-blade grounding type plugs
to two-slot receptacles. The green grounding plug extending from the adaptor must be connected to a
permanent ground such as a properly-grounded outlet box. The adaptor should not be used if a three-slot
grounded receptacle is available.
Metal Screw
Cover of
Grounding Pin
Grounding
B
Box
IMPORTANT SAFETY INFORMATION
Grounding Means
Adaptor
CAD
Grounding Pin
6
MODEL NO. 064-3504-2
The hardware in ( ) is separated
for backup.
A
Machine Screw - 32 + (4)
PARTS LIST
1
Mantel Top Assembly - 1
2
Side Panel, Left - 1
3
Side Panel, Right - 1
4
Front Panel, Left - 1
5
Front Panel, Right - 1
6
Top Fr ont Trim - 1
B
Plastic Joints, 3 holes - 8
C
Plastic Joints, 2 holes - 4
D
Wooden Dowel - 8
E
Wood Screw - 10 + (1)
F
Wood Screw - 4 + (1)
G
Hex Key - 1
H
7
Left Front Trim - 1
8
Right Front Trim - 1
9
Mantel Base Assembly - 1
10
Fireplace Insert - 1
11
Remote Control - 1
Metal Connectors - 2
I
Wood Screw - 4 + (1)
J
Wood Screw - 2 + (1)
K
Wood Screw - 2 + (1)
L
Mounting Bracket - 2
M
White Plastic Cable Tie - 1
N
Wall Anchor - 2
12
Touch-up Pen - 1
O
Insert Mounting Bracket - 2
7
Let us help you!
DO NOT RETURN YOUR PRODUCT TO THE STORE. CALL US FIRST!
1-888-670-6684
If you have questions regarding your product, require warranty
assistance, or have damaged or missing parts, please call our customer
service toll-free helpline. Contact us for assistance; we’re here to help.
ASSEMBLY
IMPORTANT: Please read and understand this manual before any assembly. Before beginning
assembly of product, make sure all parts are present. Compare parts with packaging contents
list. If any part is missing, or if you have any questions, contact the service centre at
1-888-670-6684 (toll-free).
Place all parts from the box in a cleared area and position them on the floor in front of you.
Remove all packing materials and place them back into the box. Do not dispose of the packing
materials until assembly is complete. Read each step carefully before beginning any assembly
and make sure you understand each step. If you are missing a part, please call our toll-free
number for assistance 1-888-670-6684.
Needed for assembly:
Screwdriver 2 peopleHand Drill
8
MODEL NO. 064-3504-2
Step 1
Requires 2, 3, A, B
Install plastic joints B on left side panel 2 and right side panel 3 using sixteen
machine screws A.
ASSEMBLY
A
B
A
3
B
2
Step 2
Requires 4, 5, A, C
Install plastic joints C on left front panel 4 and right front panel 5 using four
machine screws A.
A
C
A
C
4
5
Step 3
Requires 3, 5, A
Join right side panel 3 to right front panel 5 using two machine screws A.
A
3
5
A
3
5
9
ASSEMBLY
Step 4
Requires 2, 4, A
Join left side panel 2 to left front panel 4 using two machine screws A.
A
2
A
2
4
4
10
MODEL NO. 064-3504-2
Step 5
Requires A
Insert the assemblies from step 3 and step 4 into mantel base assembly 9 with
four machine screws A.
A
5
3 35
ASSEMBLY
4
A
2
9
9
Left side (not shown)
mirrors right side.
Step 6
Requires 1, A
Install the mantel top assembly 1 on the assembly from step 5 using four
machine screws A.
A
1
5
3
2
9
1
5
A
3
Left side (not shown)
mirrors right side.
Step 7
Requires 6, 7, 8, D
Join left front trim 7, right front trim 8 and top front trim 6 using four wooden
dowels D.
D
6 6
11
ASSEMBLY
8
D
8
7
Left side (not shown)
mirrors right side.
Step 8
Requires H, I
Install the two metal connectors H on left front trim 7, right front trim 8 and top
front trim 6 with four wood screws I.
H I
6
8
7
6
H
I
8
Left side (not shown)
mirrors right side.
ASSEMBLY
12
MODEL NO. 064-3504-2
Step 9
Requires D
Install the assembly from step 8 using four wooden dowels D.
D
6
8
8
D
9
7
Step 10
Requires E
Secure the front trim assembly to the mantel using ten screws E.
E
E
Left side (not shown)
mirrors right side.
Step 11
Requires 10
Install the fireplace insert 10 into the fireplace mantel from rear.
NOTE: Do not slide insert on top of wood to avoid scratching wood surface.
10
13
ASSEMBLY
Step 12
Requires 10, F, O
Secure the fireplace insert 10 using insert mounting brackets O by aligning
mounting bracket lip with fireplace insert lip and fastening four wood screws F
into pre-drilled holes.
F O
10
4
O
F
Left side (not shown)
mirrors right side.
MODEL NO. 064-3504-2
14
14
MODEL NO. 064-3504-2
Step 13
Requires J, K, L, F, M
Drill two holes in the wall and insert the wall anchors N into the holes. Install
the mounting bracket L using screws J. Install the white plastic cable tie M
using screws K. Secure the replace to the wall by fastening the white plastic
cable tie M to mounting bracket L.
ASSEMBLY
J
WALL
K L M N
N
L
M
J
K
Power Button
Pressing the power button will turn turn the unit ON or OFF.
When the unit is in ON mode, the power icon indicator light will glow green.
15
15
OPERATING INSTRUCTIONS
When the unit is in OFF mode, the power icon indicator light will glow red. If the heater is working when the
unit is powered OFF, the fan will continue to run for another 20 seconds to ensure heat will not be trapped
inside the unit.
Note: Each time the unit is plugged in, the fan and heater will turn on for 5 seconds as a programmed internal
check.
Note: Unless the main power is interrupted, the unit will remember the last heating level and flame brightness
settings.
Mode Button
Press the mode button to cycle through the different functions. Each time the mode button is pressed, the
mode will rotate through temperature, timer, or flame brightness modes.
Temperature Setting
The temperature mode controls the heater’s thermostat setting.
Press the up arrow button or down arrow button to scroll through the pre-set temperature range from 15 to
30°C (59 to 86°F).
Hold the mode button for 3 seconds. This allows the unit to change from °C to °F or °F to °C. The unit
default is °F.
Note: This function is only available if using the control panel.
When the ambient temperature is higher than the set temperature, heater will turn off automatically.
16
MODEL NO. 064-3504-2
Timer Setting
The timer mode shoud be used to set the countdown for the unit’s main power.
Press the up arrow button or down arrow button to adjust the timer setting from 0 hour (OFF) to 9 hours
with 0.5 hour intervals.
Flame Brightness Setting
The flame brightness mode is used to set the flame brightness.
Use the up arrow button or down arrow button to scroll through the flame brightness settings: F0 (flame off,
lowest brightness of ember bed), F1, F2, F3, F4, F5 (brightest).
OPERATING INSTRUCTIONSCARE AND MAINTENANCE
Use up arrow button to increase the setting of the selected function.
Use down arrow button to decrease the setting of the selected function.
Up Arrow Button
Down Arrow Button
Child Lock
Activate Child Lock
When the unit is ON, hold the POWER button for 10 seconds to activate the child lock function. E3 will be
displayed and the unit will beep 3 times indicating that the child lock function is activated. All function keys
are locked. When any button is pressed, E3 will show on the display indicating that the child lock function is
activated.
Deactivate Child Lock
To deactivate the child lock function, hold the POWER button for 10 seconds.
Note: The child lock function is only available if using the control panel.
Care and Maintenance
Make sure the unit is turned OFF, unplugged and the heating elements of heater are cool whenever you are
cleaning the heater.
Clean the metal trim using a water-dampened soft, clean cloth. DO NOT use brass polish or household
cleaners as these products will damage the metal trim.
The motors used on the fan and the flame generator assembly are pre-lubricated for extended bearing life
and require no further lubrication. However, periodic cleaning/vacuuming of the fan/heater and air intake/
output vents is recommended.
Any other servicing should be performed by an authorized service representative.
WAR N ING: Make sure the power is turned off before proceeding. Any electrical repairs
or rewiring of this unit should be carried out by a licensed electrician in accordance with
national and local codes.
If repairing or replacing and electrical component or wiring, the original wire routing, colour
coding and securing locations must be followed.
WAR N ING: Electrical outlet wiring must comply with local building codes and other
applicable regulations to reduce the risk of fire, electric shock and injury to persons.
17
17
WAR N ING: Do not use this fireplace if any part of it has been under water. Immediately call
a qualified service technician to inspect the fireplace and replace any part of the electrical
system.
WAR N ING: Disconnect power before attempting any maintenance or cleaning to reduce
the risk of fire, electric shock or personal injury.
WAR N ING: During any service of this appliance, the power to the unit must be turned off.
First turn the main power switch to the “OFF” position. Then remove the electrical plug
from the wall outlet.
Replacing the Remote Control Battery
When the remote control stops operating or its range seems reduced, it is time to replace the battery. Note:
The battery should be removed if the product is to be left unused for a long time.
Caution: Non-rechargeable batteries must not be recharged. Exhausted battery is to be removed from the
product.
1. The battery compartment is located on the back end of the remote control.
2. Press the small tab inward as you slide the battery door open and remove the old battery.
3. Insert a new CR2025 lithium battery (not included), ensuring the polarities of the battery match the inside of
the battery compartment.
4. Re-insert the battery door.
CARE AND MAINTENANCE
Disposal of Used Battery
A battery may contain hazardous substances that could be dangerous to the
environment and human health.
This symbol marked on the battery and/or packaging indicates that used battery
shall not be treated as municipal waste. Instead it shall be left at the appropriate
collection point for recycling.
By ensuring the used battery is disposed of correctly, you will help prevent
potential negative consequences for the environment and human health. The
recycling of materials will help to conserve natural resources.
For more information about collection and recycling of used batteries, please contact your local municipality,
your waste disposal service or the point of sale where you purchased this item.
18
MODEL NO. 064-3504-2
PROBLEM POSSIBLE CAUSE SOLUTION
TROUBLESHOOTIN GUIDE
No power.
Logs do not
glow.
E1 displayed
on control
panel with
beep sound.
E2 displayed
on control
panel.
E3 displayed
on control
panel.
The unit does not
Check that unit is plugged into a
standard 120 V outlet. Then make sure
have power.
power is set at “ON” position.
Unplug unit, wait 5-10 minutes, then
The overheat
the sensor will reset itself. Plug the unit
sensor has been
back in and turn on the heater. If the
engaged.
problem persists, call customer service.
The ambient
Unplug unit, wait 5-10 minutes, then
temperature
the sensor will reset itself. Plug the unit
sensor is broken
back in and turn on the heater. If the
or not working
problem persists, call customer service.
correctly.
To inactivate the child lock function,
Child lock
holding the POWER button for 10
function is active.
seconds.
Fan motor
continues
to blow
after unit is
powered off.
Power cord
gets warm to
the touch.
This is a standard feature; the blower
runs for an additional 20 seconds to
Normal operation.
ensure heat will not be trapped inside
the unit.
This is normal for a heater appliance
as it requires more current to operate.
Check the connections of the
appliance cord and the outlet. Make
sure the plug fits tightly into the outlet.
Normal operation.
During use, check the plug and outlet
frequently to determine if it is HOT; if
so, discontinue use of the appliance
and consult with a qualified electrician
to check or change the overheating
outlet(s).
This CANVAS product carries a one (1) year warranty against defects in
workmanship and materials. Trileaf Distribution agrees to replace the defective
product free of charge within the stated warranty period, when returned by
the original purchaser with proof of purchase. This product is not guaranteed
against wear or breakage due to misuse and/or abuse.
19
WARRANT Y
Loading...
