W-SD23-E
23x Cost-effective PTZ Dome Camera
Features
Powerful 23x optical zoom
High resolution@700TVL/600TVL/540TVL
DWDR, Day/Night (ICR), DNR (2D&3D), Auto iris, Auto focus, AWB, AGC, BLC
Max 300 °/s pan speed, 360° continuous pan rotation
Up to 255 presets, 5 auto scan, 8 tour, 5 pattern
Support intelligent 3D positioning with DH-SD protocol
IP66
Model
Camera
Image Sensor
Effective Pixels
Horizontal Resolution
Scanning System
Electronic
Shutter Speed
Min. Illumination
S/N Ratio
More than 50dB
Video Output
BNC(1.0Vp-p/75Ω), PAL / NTSC
Camera Features
Day/Night
Auto(ICR) / Color / B/W
Backlight
Compensation
White Balance
Auto, ATW, Indoor, Outdoor, Manual
Gain Control
Auto / Manual
Noise Reduction
Privacy Masking
Digital Zoom
Lens
Focal Length
Max Aperture
Focus Control
Auto / Manual
Angle of View
Close Focus Distance
PTZ
Pan/Tilt Range
Pan: 0° ~ 360° endless; Tilt: -2° ~ 90°, auto flip 180°
Manual Control Speed
Pan: 0.1° ~ 250°/s; Tilt: 0.1° ~150°/s
Preset Speed
Pan: 300°/s; Tilt: 200°/s
Preset
80(DH-SD) , 255(Pelco-P/D)
PTZ Mode
5 Pattern, 8 Tour, Auto Pan, Auto Scan
W-SD23-E
Technical Specifications:
W-SD23-E
1/4" EXview HAD CCD II
976(H) ×582(V) /976(H) ×494(V)
Color: 650TVL; B/W: 700TVL
Interlacing
1/1s ~1/100,000s
Color: 0.01 Lux/F1.6
B/W: 0.001Lux/F1.6
BLC / HLC / DWDR (Digital WDR)
2D / 3D
Up to 24 areas
16x
3.9mm~89.7mm
(23x Optical
zoom)
F1.6~ F3.7
H: 61.68° ~ 3.06°
100mm~1000mm
Speed Setup
Human-oriented focal length/ speed adaptation
Power up Action
Auto restore to previous PTZ and lens status after power failure
Idle Motion
Activate Preset/Pan/Scan/Tour/Pattern if there is no command in the
specified period
Time Task
Auto activation of Preset/Pan/Scan/Tour/Pattern by preset-time
Protocol
DH-SD, Pelco-P/D (Auto recognition)
Auxiliary Interface
RS485
1 port
General
Power Supply
AC24V/3A (±10%), DC12V optional
Power Consumption
12W, 24W(Heater on)
Working Environment
-40ºC ~ 60ºC / Less than 90% RH
Ingress Protection
IP66
Vandal Resistance
IK10(optional)
Dimensions
Φ222(mm) x 324 (mm)
Weight
5.0kg
W-SD23-E
Dimensions (mm)
Power Supply
W-SD23-E
Accessories
63FB
Accessories (Optional)
PFA111 PFB300C PFB301C PFA112 PFA113
PFB301S PFA120 PFA150 PFA151
Winic Technologies USA Inc.
42 Central avenue, Farmingdale, New York 11735
Tel: +631-396-0800
Fax: +631-396-0805
Email:sales@winictech.com
www.winictech.com
*Design and specifications are subject to change without notice.
