Cantek CT-NVR401CP4-4, CT-NVR402HP8-8, CT-NVR408H-32, CT-NVR5216-8P, CT-NVR6000D User Manual
...
Network Video Recorder User’s Manual
V 2.0.0
Table of Contents
1 Features and Specifications ...............................................................................................................1
1.1 Overview ........................................................................................................................................1
1.2 Features .........................................................................................................................................1
1.3 Specifications ................................................................................................................................2
1.3.1 NVR100/100-P Series ..........................................................................................................2
1.3.2 NVR11/11-P Series ...............................................................................................................4
1.3.3 NVR11H/11H-P Series .........................................................................................................7
1.3.4 NVR11HS Series ...................................................................................................................9
1.3.5 NVR41/41-P/41-8P/41-W Series....................................................................................... 11
1.3.6 NVR41H/41H-P/41H-8P Series.........................................................................................12
1.3.7 NVR42/42-P/42-8P Series .................................................................................................14
1.3.8 NVR42-4K/42-8P-4K Series ..............................................................................................16
1.3.9 NVR44/44-8P/44-16P Series .............................................................................................18
1.3.10 NVR44-4K Series ................................................................................................................20
1.3.11 NVR48-4K Series ................................................................................................................21
1.3.12 NVR48/48-16P Series ........................................................................................................23
1.3.13 NVR72/72-8P Series ...........................................................................................................24
1.3.14 NVR74/74-8P/74-16P Series .............................................................................................26
1.3.15 NVR78/78-16P/78-RH Series ............................................................................................28
1.3.16 NVR70/70-R Series .............................................................................................................30
1.3.17 NVR42V-8P Series..............................................................................................................32
2 Front Panel and Rear Panel .............................................................................................................34
2.1 Front Panel ..................................................................................................................................34
2.1.1 NVR11/11-P/41/41-P/41-W Series ...................................................................................34
2.1.2 NVR11H/11H-P/41H/41H-P/41H-8P Series ....................................................................34
2.1.3 NVR11HS Sereis .................................................................................................................35
2.1.4 NVR41-8P Series ................................................................................................................35
2.1.5 NVR42/42-P/42-8P/72/72-8P Series ................................................................................36
2.1.6 NVR42-4K/42-8P-4K/44-4K/48-4K Series .......................................................................37
2.1.7 NVR44/44-8P/44-16P/74/74-8P/74-16P Series ..............................................................38
2.1.8 NVR48/48-16P/78/78-16P Series .....................................................................................40
2.1.9 NVR78-RH Series ...............................................................................................................42
2.1.10 NVR70/70-R Series .............................................................................................................44
2.1.11 NVR42V-8P Series ..............................................................................................................46
2.2 Rear Panel ..................................................................................................................................47
2.2.1 NVR100/100-P Series ........................................................................................................47
2.2.2 NVR11/11-P Series..............................................................................................................48
2.2.3 NVR41/41-P/41-8P/41-W Series.......................................................................................49
2.2.4 NVR11H/11H-P/41H/41H-P/41H-8P Series ....................................................................51
2.2.5 NVR11HS Series .................................................................................................................53
2.2.6 NVR42/42-P/42-8P Series .................................................................................................53
2.2.7 NVR42-4K Series ................................................................................................................55
2.2.8 NVR42-8P-4K Series ..........................................................................................................57
i
2.2.9 NVR44/44-8P/44-16P Series .............................................................................................58
2.2.10 NVR44-4K/48-4K Series ....................................................................................................60
2.2.11 NVR48/48-16P Series ........................................................................................................62
2.2.12 NVR72 Series ......................................................................................................................64
2.2.13 NVR72-8P Series ................................................................................................................65
2.2.14 NVR74 Series ......................................................................................................................67
2.2.15 NVR74-8P/74-16P Series ..................................................................................................69
2.2.16 NVR78 Series ......................................................................................................................71
2.2.17 NVR78-16P Series ..............................................................................................................72
2.2.18 NVR78-RH Series ...............................................................................................................74
2.2.19 NVR70 Series ......................................................................................................................76
2.2.20 NVR70-R Series ..................................................................................................................78
2.2.21 NVR42V-8P Series ..............................................................................................................80
2.3 Alarm Connection .......................................................................................................................81
2.3.1 Alarm Port .............................................................................................................................81
2.3.2 Alarm input port ...................................................................................................................82
2.3.3 Alarm input and output port................................................................................................83
2.3.4 Alarm relay specifications ..................................................................................................83
2.4 Bidirectional talk .........................................................................................................................84
2.4.1 Device-end to PC-end ........................................................................................................84
2.4.2 PC-end to the device-end ..................................................................................................84
2.5 Mouse Operation ........................................................................................................................85
3 Device Installation ..............................................................................................................................87
3.1 Check Unpacked NVR ...............................................................................................................87
3.2 About Front Panel and Rear Panel..........................................................................................87
3.3 HDD Installation ..........................................................................................................................87
3.3.1 NVR100/100-P Series ........................................................................................................87
3.3.2 NVR11/11-P/41/41-P/41-8P/41-W Series .......................................................................88
3.3.3 NVR11H/11H-P/41H/41H-P/41H-8P/11HS Series .........................................................89
3.3.4 NVR42/42-P/42-8P/72/72-8P/42-4K/42-8P-4K Series ..................................................90
3.3.5 NVR44/44-8P/44-16P/74/74-8P/74-16P/44-4K Series ..................................................90
3.3.6 NVR48/48-16P/NVR78/78-16P/48-4K Series .................................................................91
3.3.7 NVR78-RH Series ...............................................................................................................92
3.3.8 NVR70/70-R Series .............................................................................................................93
3.3.9 NVR42V-8P Series..............................................................................................................94
3.4 CD-ROM Installation ..................................................................................................................94
3.5 Connection Sample ....................................................................................................................96
3.5.1 NVR100/NVR100-P Series ................................................................................................96
3.5.2 NVR11/11-P/41/41-P/41-8P/41-W Series .......................................................................96
3.5.3 NVR11H/11H-P/41H/41H-P/41H-8P Series ....................................................................97
3.5.4 NVR11HS Series .................................................................................................................98
3.5.5 NVR42/42-P/42-8P Series .................................................................................................99
3.5.6 NVR42-4K Series ..............................................................................................................100
3.5.7 NVR42-8P-4K Series ........................................................................................................101
3.5.8 NVR44-4K/48-4K Series ..................................................................................................101
3.5.9 NVR44/44-8P/44-16P Series ...........................................................................................102
ii
3.5.10 NVR48/48-16P Series ......................................................................................................103
3.5.11 NVR72 Series ....................................................................................................................104
3.5.12 NVR72-8P Series ..............................................................................................................104
3.5.13 NVR74 Series ....................................................................................................................105
3.5.14 NVR74-8P/74-16P Series ................................................................................................106
3.5.15 NVR78 Series ....................................................................................................................107
3.5.16 NVR78-16P Series ............................................................................................................108
3.5.17 NVR78-RH Series .............................................................................................................109
3.5.18 NVR70 Series .................................................................................................................... 110
3.5.19 NVR70-R Series ................................................................................................................ 111
3.5.20 NVR42V-8P Series............................................................................................................ 112
4 Local Basic Operation ..................................................................................................................... 114
4.1 Boot up and Shutdown ............................................................................................................ 114
4.1.1 Boot up ................................................................................................................................ 114
4.1.2 Shutdown ............................................................................................................................ 114
4.2 Startup Wizard .......................................................................................................................... 114
4.3 Navigation Bar .......................................................................................................................... 118
4.3.1 Main Menu .......................................................................................................................... 118
4.3.2 Dual-screen operation ...................................................................................................... 118
4.3.3 Output Screen .................................................................................................................... 119
4.3.4 Tour ...................................................................................................................................... 119
4.3.5 PTZ ...................................................................................................................................... 119
4.3.6 Color .................................................................................................................................... 119
4.3.7 Search ................................................................................................................................. 119
4.3.8 Alarm Status ....................................................................................................................... 119
4.3.9 Channel Info ....................................................................................................................... 119
4.3.10 Remote Device ..................................................................................................................120
4.3.11 Network ...............................................................................................................................120
4.3.12 HDD Manager ....................................................................................................................120
4.3.13 USB Manager.....................................................................................................................120
4.4 Smart Add..................................................................................................................................120
4.5 Remote Device .........................................................................................................................123
4.5.1 Remote Device Connection .............................................................................................123
4.5.2 Short-Cut Menu .................................................................................................................125
4.5.3 Image ..................................................................................................................................125
4.5.4 Channel Name ...................................................................................................................127
4.5.5 Upgrade ..............................................................................................................................128
4.5.6 UPNP ..................................................................................................................................128
4.5.7 Built-in Switch Setup .........................................................................................................129
4.6 Preview ......................................................................................................................................129
4.6.1 Preview ...............................................................................................................................129
4.6.2 Preview control interface ..................................................................................................130
4.6.3 Right Click Menu ...............................................................................................................131
4.6.4 Preview Display Effect Setup ..........................................................................................132
4.6.4.1 Video Color ................................................................................................................132
4.6.4.2 Display .......................................................................................................................134
iii
4.6.4.3 TV adjust ....................................................................................................................135
4.6.5 Preview Tour Parameters ................................................................................................135
4.7 PTZ .............................................................................................................................................136
4.7.1 PTZ Settings.......................................................................................................................136
4.7.2 PTZ Control ........................................................................................................................138
4.7.2.1 PTZ Function Setup .................................................................................................140
4.7.2.2 Call PTZ Function .....................................................................................................142
4.8 Record and Snapshot ..............................................................................................................143
4.8.1 Encode ................................................................................................................................143
4.8.1.1 Encode .......................................................................................................................143
4.8.1.2 Overlay .......................................................................................................................144
4.8.1.3 Snapshot ....................................................................................................................145
4.8.2 Schedule .............................................................................................................................146
4.8.2.1 Schedule Record ......................................................................................................146
4.8.2.2 Schedule Snapshot ..................................................................................................149
4.8.3 Motion detect record/snapshot ........................................................................................151
4.8.3.1 Motion detect record ................................................................................................151
4.8.3.2 Motion Detect Snapshot ..........................................................................................153
4.8.4 Alarm Record/Snapshot ...................................................................................................154
4.8.4.1 Alarm Record ............................................................................................................154
4.8.4.2 Alarm Snapshot ........................................................................................................155
4.8.5 Manual Record/Snapshot .................................................................................................156
4.8.5.1 Manual Record .........................................................................................................156
4.8.5.2 Manual Snapshot......................................................................................................157
4.8.6 Holiday Record/Snapshot ................................................................................................157
4.8.6.1 Holiday Record .........................................................................................................157
4.8.6.2 Holiday Snapshot .....................................................................................................159
4.8.7 Other Record/Snapshot ....................................................................................................159
4.9 Playback and Search ...............................................................................................................159
4.9.1 Real-time Playback ...........................................................................................................159
4.9.2 Search Interface ................................................................................................................160
4.9.2.1 Smart Search ............................................................................................................164
4.9.2.2 Accurate playback by time ......................................................................................164
4.9.2.3 Mark Playback ..........................................................................................................165
4.9.3 Picture Playback ................................................................................................................166
4.10 Backup .......................................................................................................................................166
4.10.1 File Backup .........................................................................................................................166
4.10.2 Import/Export ......................................................................................................................168
4.10.3 Backup Log.........................................................................................................................169
4.10.4 USB Device Auto Pop-up .................................................................................................169
4.11 Alarm ..........................................................................................................................................170
4.11.1 Detect Alarm.......................................................................................................................170
4.11.1.1 Motion Detect ............................................................................................................170
4.11.1.2 Tampering ..................................................................................................................174
4.11.1.3 Video Loss .................................................................................................................175
4.11.2 Alarm output .......................................................................................................................176
iv
4.11.3 Alarm Setup ........................................................................................................................177
4.11.4 Abnormality.........................................................................................................................182
4.12 Network ......................................................................................................................................184
4.12.1.1 TCP/IP ........................................................................................................................184
4.12.1.2 Connection ................................................................................................................186
4.12.1.3 WIFI AP ......................................................................................................................187
4.12.1.4 WIFI ............................................................................................................................188
4.12.1.5 3G ...............................................................................................................................189
4.12.1.6 PPPoE ........................................................................................................................190
4.12.1.7 DDNS Setup ..............................................................................................................191
4.12.1.8 UPnP ..........................................................................................................................193
4.12.1.9 IP Filter .......................................................................................................................194
4.12.1.10 Email ..........................................................................................................................196
4.12.1.11 FTP.............................................................................................................................197
4.12.1.12 SNMP ........................................................................................................................199
4.12.1.13 Multicast ....................................................................................................................199
4.12.1.14 Alarm Centre ............................................................................................................201
4.12.1.15 Auto register .............................................................................................................201
4.12.1.16 P2P ............................................................................................................................202
4.12.1.17 Easy Space ...............................................................................................................203
4.12.1.18 SWITCH ....................................................................................................................204
4.12.2 Network Test .......................................................................................................................205
4.12.2.1 Network Test..............................................................................................................205
4.12.2.2 Network Load ............................................................................................................206
4.13 HDD Setup ................................................................................................................................207
4.13.1 Format .................................................................................................................................207
4.13.2 HDD Information ................................................................................................................208
4.13.3 Advanced ............................................................................................................................210
4.13.4 HDD Detect ........................................................................................................................212
4.13.4.1 Manual Detect ...........................................................................................................213
4.13.4.2 Detect Report ............................................................................................................213
4.13.5 RAID Manager ...................................................................................................................215
4.13.5.1 RAID Config ..............................................................................................................215
4.13.5.2 Hotspare disks ..........................................................................................................216
4.14 Basic Setups .............................................................................................................................217
4.14.1 Device Setup ......................................................................................................................217
4.14.2 Data and Time ...................................................................................................................218
4.14.3 Holiday ................................................................................................................................219
4.15 Device Maintenance and Manager ........................................................................................219
4.15.1 System Info.........................................................................................................................219
4.15.1.1 Version .......................................................................................................................219
4.15.1.2 BPS ............................................................................................................................220
4.15.1.3 Online User ...............................................................................................................220
4.15.1.4 Remote Device Information ....................................................................................221
4.15.1.5 Remote.......................................................................................................................222
4.15.1.5.1 Device Status...........................................................................................................222
v
4.15.1.5.2 Firmware .................................................................................................................223
4.15.2 Log .......................................................................................................................................224
4.15.3 Voice ....................................................................................................................................225
4.15.3.1.1 File Manage ............................................................................................................225
4.15.3.1.2 Schedule ..................................................................................................................226
4.15.4 Account ...............................................................................................................................226
4.15.4.1 Add/Modify Group ....................................................................................................228
4.15.4.2 Add/Modify User .......................................................................................................229
4.15.5 Update .................................................................................................................................230
4.15.6 Default .................................................................................................................................231
4.15.7 RS232 .................................................................................................................................231
4.15.8 Auto Maintain .....................................................................................................................232
4.15.9 Logout /Shutdown/Restart ................................................................................................233
5 Web Operation ..................................................................................................................................234
5.1 General Introduction ................................................................................................................234
5.1.1 Preparation .........................................................................................................................234
5.1.2 Log in ...................................................................................................................................235
5.2 LAN Mode..................................................................................................................................236
5.3 Real-time Monitor .....................................................................................................................238
5.4 PTZ .............................................................................................................................................239
5.5 Image/Alarm-out .......................................................................................................................241
5.5.1 Image ..................................................................................................................................241
5.5.2 Alarm output .......................................................................................................................241
5.6 Zero-channel Encode ..............................................................................................................241
5.7 WAN Login ................................................................................................................................242
5.8 Setup ..........................................................................................................................................243
5.8.1 Camera ...............................................................................................................................243
5.8.1.1 Remote Device .........................................................................................................243
5.8.1.2 Image .........................................................................................................................245
5.8.1.3 Encode .......................................................................................................................248
5.8.1.3.1 Encode.......................................................................................................................248
5.8.1.3.2 Snapshot ....................................................................................................................249
5.8.1.3.3 Video Overlay ...........................................................................................................250
5.8.1.3.4 Path ...........................................................................................................................250
5.8.1.4 Channel Name ..........................................................................................................251
5.8.1.5 IPC Upgrade .............................................................................................................251
5.8.2 Network ...............................................................................................................................252
5.8.2.1 TCP/IP ........................................................................................................................252
5.8.2.2 P2P .............................................................................................................................253
5.8.2.3 Connection ................................................................................................................253
5.8.2.4 WIFI AP ......................................................................................................................254
5.8.2.5 WIFI ............................................................................................................................255
5.8.2.6 3G ...............................................................................................................................256
5.8.2.6.1 CDMA/GPRS ...........................................................................................................256
5.8.2.6.2 Mobile .......................................................................................................................257
5.8.2.7 PPPoE ........................................................................................................................258
vi
5.8.2.8 DDNS .........................................................................................................................258
5.8.2.9 IP filter ........................................................................................................................259
5.8.2.10 Email...........................................................................................................................260
5.8.2.11 UPnP ..........................................................................................................................261
5.8.2.12 SNMP .........................................................................................................................262
5.8.2.13 Multicast .....................................................................................................................263
5.8.2.14 Auto Register ............................................................................................................264
5.8.2.15 Alarm Centre .............................................................................................................264
5.8.2.16 HTTPS .......................................................................................................................265
5.8.2.16.1 Create Server Certificate .........................................................................................265
5.8.2.16.2 Download root certificate ........................................................................................266
5.8.2.16.3 View and set HTTPS port .......................................................................................269
5.8.2.16.4 Login .......................................................................................................................269
5.8.3 Event ...................................................................................................................................269
5.8.3.1 Video detect ..............................................................................................................269
5.8.3.1.1 Motion Detect ...........................................................................................................269
5.8.3.1.2 Video Loss ................................................................................................................273
5.8.3.1.3 Tampering .................................................................................................................274
5.8.3.2 Alarm ..........................................................................................................................274
5.8.3.2.1 Local Alarm ..............................................................................................................274
5.8.3.2.2 Net Alarm ..................................................................................................................277
5.8.3.2.3 IPC external alarm ....................................................................................................277
5.8.3.2.4 IPC Offline Alarm .....................................................................................................278
5.8.3.3 Abnormality ...............................................................................................................279
5.8.4 Storage ................................................................................................................................281
5.8.4.1 Schedule ....................................................................................................................281
5.8.4.2 HDD Manager ...........................................................................................................283
5.8.4.2.1 Local Storage ............................................................................................................283
5.8.4.2.2 HDD ..........................................................................................................................283
5.8.4.2.3 FTP ............................................................................................................................283
5.8.4.3 Record Control ..........................................................................................................284
5.8.4.4 RAID Manager ..........................................................................................................285
5.8.4.4.1 RAID Config .............................................................................................................285
5.8.4.4.2 Hotspare disks ...........................................................................................................285
5.8.4.5 Storage .......................................................................................................................286
5.8.4.5.1 Main Stream ..............................................................................................................286
5.8.4.5.2 Sub Stream ................................................................................................................286
5.8.4.5.3 Snapshot ....................................................................................................................287
5.8.5 Setting .................................................................................................................................287
5.8.5.1 General ......................................................................................................................287
5.8.5.1.1 General ......................................................................................................................287
5.8.5.1.2 Date and time ............................................................................................................288
5.8.5.1.3 Holiday Setup............................................................................................................289
5.8.5.2 Account ......................................................................................................................289
5.8.5.2.1 User name .................................................................................................................290
5.8.5.2.2 Group ........................................................................................................................291
vii
5.8.5.3 Display .......................................................................................................................293
5.8.5.3.1 Display ......................................................................................................................293
5.8.5.3.2 Tour ...........................................................................................................................293
5.8.5.4 Alarm Out...................................................................................................................294
5.8.5.5 Default ........................................................................................................................295
5.8.5.6 Import/Export.............................................................................................................295
5.8.5.7 Auto maintain ............................................................................................................296
5.8.5.8 Upgrade .....................................................................................................................296
5.8.5.9 RS232 ........................................................................................................................297
5.8.5.10 PTZ .............................................................................................................................297
5.9 Information ................................................................................................................................299
5.9.1 Version ................................................................................................................................299
5.9.2 Log .......................................................................................................................................299
5.9.3 Online User.........................................................................................................................300
5.10 Playback ....................................................................................................................................300
5.10.1 Search Record ...................................................................................................................301
5.10.2 File List ................................................................................................................................301
5.10.3 Playback .............................................................................................................................302
5.10.4 Download ............................................................................................................................303
5.10.5 Load more...........................................................................................................................303
5.10.5.1 Download By File......................................................................................................303
5.10.5.2 Download by Time ....................................................................................................304
5.10.5.3 Watermark .................................................................................................................305
5.11 Alarm ..........................................................................................................................................305
5.12 Log out .......................................................................................................................................306
5.13 Un-install Web Control .............................................................................................................307
6 Glossary.............................................................................................................................................308
7 FAQ ....................................................................................................................................................309
8 Appendix A HDD Capacity Calculation .........................................................................................314
9 Appendix B Compatible Network Camera List.............................................................................315
viii
Welcome
Thank you for purchasing our network video recorder!
This user’s manual is designed to be a reference tool for your system.
Please open the accessory bag to check the items one by one in accordance with the list below.
Contact your local retailer ASAP if something is missing or damaged in the bag.
ix
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
The product must be grounded to reduce the risk of electric shock.
We assume no liability or responsibility for all the fires or electric shock caused by improper
handling or installation.
2．Transportation security
Heavy stress, violent vibration or water splash are not allowed during transportation, storage and
installation.
3．Installation
Keep upwards. Handle with care.
Do not apply power to the NVR before completing installation.
Do not place objects on the NVR.
4．Qualified engineers needed
All the examination and repair work should be done by the qualified service engineers.
We are not liable for any problems caused by unauthorized modifications or attempted repair.
5．Environment
The NVR should be installed in a cool, dry place away from direct sunlight, inflammable, explosive
substances and etc.
This series product shall be transported, storage and used in the specified environments.
Environment which needs to comply with the following conditions:
The function of the ITE being investigated to IEC 60950-1 is considered not likely to require
connection to an Ethernet network with outside plant routing, including campus environment.
The installation instructions clearly state that the ITE is to be connected only to PoE networks
without routing to the outside plant.
6. Accessories
Be sure to use all the accessories recommended by manufacturer.
Before installation, please open the package and check all the components are included.
Contact your local retailer ASAP if something is broken in your package.
7. Lithium battery
Improper battery use may result in fire, explosion, or personal injury!
When replace the battery, please make sure you are using the same model!
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
Before your operation please read the following instructions carefully.
Installation environment
x
Keep away from extreme hot places and sources；
Avoid direct sunlight；
Keep away from extreme humid places；
Avoid violent vibration；
Do not put other devices on the top of the NVR；
Be installed in well ventilated place; do not block the vent.
Accessories
Check the following accessories after opening the box：
Please refer to the packing list in the box *
xi
Real-time
Surveillance
VGA, HDMI port. Connect to monitor to realize real-time surveillance.
Some series support TV/VGA/HDMI output at the same time.
Short-cut menu when preview.
Support popular PTZ decoder control protocols. Support preset, tour
and pattern.
Playback
Support each channel real-time record independently, and at the same
time it can support search, forward play, network monitor, record search,
download and etc.
Support various playback modes: slow play, fast play, backward play
and frame by frame play.
Support time title overlay so that you can view event accurate occurred
time
Support specified zone enlargement.
User
Management
Each group has different management powers that can be edited freely.
Every user belongs to an exclusive group.
Storage
Via corresponding setup (such as alarm setup and schedule setup), you
can backup related audio/video data in the network video recorder.
Support Web record and record local video and storage the file in the
client end.
Alarm
Respond to external alarm simultaneously (within 200MS), based on
user’s pre-defined relay setup, system can process the alarm input
correctly and prompt user by screen and voice (support pre-recorded
audio).
Support central alarm server setup, so that alarm information can
remotely notify user automatically. Alarm input can be derived from
various connected peripheral devices.
Alert you via email/sms.
1 Features and Specifications
1.1 Overview
This series NVR is a high performance network video recorder. This series product support local preview,
multiple-window display, recorded file local storage, remote control and mouse shortcut menu operation,
and remote management and control function.
This series product supports centre storage, front-end storage and client-end storage. The monitor zone
in the front-end can be set in anywhere. Working with other front-end devices such as IPC, NVS, this
series product can establish a strong surveillance network via the CMS. In the network system, there is
only one network cable from the monitor centre to the monitor zone in the whole network. There is no
audio/video cable from the monitor centre to the monitor zone. The whole project is featuring of simple
connection, low-cost, low maintenance work.
This series NVR can be widely used in many areas such as public security, water conservancy,
transportation and education.
1.2 Features
1
Network
Monitor
Through network, sending audio/video data compressed by IPC or NVS
to client-ends, then the data will be decompressed and display.
Support max 128 connections at the same time.
Transmit audio/video data by HTTP, TCP, UDP, MULTICAST,
RTP/RTCP and etc.
Transmit some alarm data or alarm info by SNMP.
Support WEB access in WAN/LAN.
Window Split
Adopt the video compression and digital process to show several
windows in one monitor. Support 1/4/8/9/16/ 25/36-window display when
preview and 1/4/9/16-window display when playback.
Record
Support normal/motion detect/alarm record function. Save the recorded
files in the HDD, USB device, client-end PC, or network storage server.
You can search or playback the saved files at the local-end or via the
Web/USB device.
Backup
Support network backup, USB2.0 record backup function, the recorded
files can be saved in network storage server, peripheral USB2.0
device, burner and etc.
Network
Management
Supervise NVR configuration and control power via Ethernet.
Support management via WEB.
Peripheral
Equipment
Management
Support peripheral equipment management such as protocol setup and
port connection.
Support transparent data transmission such as RS232 (RS-422), RS485
(RS-485).
Auxiliary
Support switch between NTSC and PAL.
Support real-time system resources information and running statistics
display.
Support log file.
Local GUI output. Shortcut menu operation via mouse.
IR control function (For some series product only.). Shortcut menu
operation via remote control.
Support IPC or NVS remote video preview and control.
Model
100 Series
100-P Series
System
System
Resources
4/8-ch series product support 4/8 HD connection respectively. Total
bandwidth supports 28/56Mbps respectively.
OS
Embedded Linux real-time operation system
Operation
Interface
WEB/Local GUI
Decode
Video Decode
H.264/MJPEG
1.3 Specifications
1.3.1 NVR100/100-P Series
2
Model
100 Series
100-P Series
Type
Decode
Capability
Max 2-ch 1080P 30fps or 4-ch 720P 30fps or 8-ch D1 30fps
Video
Video Input
4/8-ch network compression video input
Video Output
1-channel VGA analog video output
HDMI
1-ch HDMI output. Version number is 1.4
Window Split
1/4/8-window
Audio
Audio Input
N/A
Audio Output
N/A
Audio
Compression
Standard
G.711a
Alarm
Alarm Input
N/A
Alarm Output
N/A
Funciton
Storage
1 built-in 2.5-inch SATA port
Multiple-Chann
el Playback
Max 8-channel D1 or 4-channel 720P or 2-channel 1080P playback
Port and
Indicator
RS232 Port
N/A
RS485 Port
N/A
USB Port
2 peripheral USB2.0 ports.
3
Model
100 Series
100-P Series
Network
Connection
1 RJ45 10/100Mbps self-adaptive Ethernet port.
PoE
N/A
4
Power Port
1 power socket. Power adapter
power supplying mode. DC 5V
2A power.
1 power socket. Power adapter
power supplying mode. DC 48V
1.25A power.
Power Button
N/A
Power On-off
Button
N/A
IR Receiver
Window
N/A
Clock
Built-in clock.
Indicator Light
N/A
General
Power
Consumption
＜10W (Exclude HDD)
Working
Temperature
﹣10℃～﹢55℃
Working
Humidity
10℅～90℅
Air pressure
86kPa～106kPa
Dimension
191.8mm×128.2mm×35.8mm
Weight
0.32kg～0.36kg (Exclude HDD)
Installation
Mode
Desk installation
Model
11 Series
11-P Series
1.3.2 NVR11/11-P Series
4
Model
11 Series
11-P Series
System
System
Resources
4/8-ch series product support 4/8 HD connection respectively. Total
bandwidth supports 28/56Mbps respectively.
OS
Embedded Linux real-time operation system
Operation
Interface
WEB/Local GUI
Decode
Video Decode
Type
H.264/MJPEG
Decode
Capability
Max 2-ch 1080P 30fps or 4-ch 720P 30fps or 8-ch D1 30fps
Video
Video Input
4/8-ch network compression video input
Video Output
1-channel VGA analog video output
HDMI
1-ch HDMI output. Version number is 1.4
Window Split
1/4/8-window
Audio
Audio Input
1-ch bidirectional talk input
Audio Output
1-ch bidirectional talk output
Audio
Compression
Standard
G.711a
Alarm
Alarm Input
N/A
Alarm Output
N/A
Funciton
Storage
1 built-in SATA port
5
Model
11 Series
11-P Series
Multiple-Chann
el Playback
Max 8-channel D1 or 4-channel 720P or 2-channel 1080P playback
Port and
Indicator
RS232 Port
N/A
RS485 Port
N/A
USB Port
2 peripheral USB2.0 ports.
Network
Connection
1 RJ45 10/100Mbps self-adaptive Ethernet port.
PoE
N/A
4
Power Port
1 power socket. Power adapter
power supplying mode. DC 12V
power.
1 power socket. Power adapter
power supplying mode. DC 48V
power.
Power Button
N/A
Power On-off
Button
N/A
IR Receiver
Window
N/A
Clock
Built-in clock.
Indicator Light
One power status indicator light.
One network status indicator light.
One HDD status indicator light.
General
Power
Consumption
＜10W (Exclude HDD)
Working
Temperature
﹣10℃～﹢55℃
Working
Humidity
10℅～90℅
Air pressure
86kPa～106kPa
6
Model
11 Series
11-P Series
Dimension
205mm×206.75mm×45.2mm
Weight
0.5kg～1kg (Exclude HDD)
Installation
Mode
Desk installation
Model
11H Series
11H-P Series
System
System
Resources
4/8-ch series product support 4/8 HD connection respectively. Total
bandwidth supports 28/56Mbps respectively.
OS
Embedded Linux real-time operation system
Operation
Interface
WEB/Local GUI
Decode
Video Decode
Type
H.264/MJPEG
Decode
Capability
Max 2-ch 1080P 30fps or 4-ch 720P 30fps or 8-ch D1 30fps
Video
Video Input
4/8-ch network compression video input
Video Output
1-channel VGA analog video output
HDMI
1-ch HDMI output. Version number is 1.4
Window Split
1/4/8-window
Audio
Audio Input
1-ch bidirectional talk input
Audio Output
1-ch bidirectional talk output
1.3.3 NVR11H/11H-P Series
7
Model
11H Series
11H-P Series
Audio
Compression
Standard
G.711a
Alarm
Alarm Input
N/A
Alarm Output
N/A
Funciton
Storage
1 built-in SATA port
Multiple-Chann
el Playback
Max 8-channel D1 or 4-channel 720P or 2-channel 1080P playback
Port and
Indicator
RS232 Port
N/A
RS485 Port
N/A
USB Port
2 peripheral USB2.0 ports.
Network
Connection
1 RJ45 10/100Mbps self-adaptive Ethernet port.
PoE
N/A
4
Power Port
1 power socket. Power adapter
power supplying mode. DC 12V
power.
1 power socket. Power adapter
power supplying mode. DC 48V
power.
Power Button
N/A
Power On-off
Button
N/A
IR Receiver
Window
N/A
Clock
Built-in clock.
8
Model
11H Series
11H-P Series
Indicator Light
One power status indicator light.
One network status indicator light.
One HDD status indicator light.
General
Power
Consumption
＜10W (Exclude HDD)
Working
Temperature
﹣10℃～﹢55℃
Working
Humidity
10℅～90℅
Air pressure
86kPa～106kPa
Dimension
325mm×250.58mm×51mm
Weight
0.5kg～1kg (Exclude HDD)
Installation
Mode
Desk installation
Model
11HS Series
System
System
Resources
4/8-ch series product support 4/8 HD connection respectively. Total
bandwidth supports 25/56Mbps respectively.
OS
Embedded Linux real-time operation system
Operation
Interface
WEB/Local GUI
Decode
Video Decode
Type
H.264
Decode
Capability
For 8-channel series product: Max 2-ch 1080P 30fps or 4-ch
720P 30fs or 8-ch D1 30fps.
For 4-channel series product: Max 1-ch 1080P 30fps or 4-ch
720P 30fs or 4-ch D1 30fps.
Video
Video Input
4/8-ch network compression video input
Video Output
1-channel VGA analog video output
HDMI
1-ch HDMI output. Version number is 1.4
1.3.4 NVR11HS Series
9
Model
11HS Series
Window Split
1/4/8-window
Audio
Audio Input
N/A
Audio Output
N/A
Audio
Compression
Standard
G.711a
Alarm
Alarm Input
N/A
Alarm Output
N/A
Funciton
Storage
1 built-in SATA port
Multiple-Chann
el Playback
For 8-channel series product: Max 2-ch 1080P 30fps or 4-ch
720P 30fs or 8-channel D1 30fs playback.
For 4-channel series product: Max 1-ch 1080P 30fps or 4-ch
720P 30fs or 4-ch D1 30fs playback.
Port and
Indicator
RS232 Port
N/A
RS485 Port
N/A
USB Port
2 peripheral USB2.0 ports. One at the front panel and one at the rear
panel.
Network
Connection
1 RJ45 10/100Mbps self-adaptive Ethernet port.
PoE Port
N/A
Power Port
1 power socket. Power adapter power supplying mode. DC 12V/1.5A
power.
Power Button
N/A
Power On-off
Button
N/A
IR Receiver
Window
N/A
Clock
Built-in clock.
Indicator Light
One power status indicator light.
One network status indicator light.
One HDD status indicator light.
General
Power
Consumption
＜10W (Exclude HDD)
Working
Temperature
﹣10℃～﹢55℃
Working
10℅～90℅
10
Model
11HS Series
Humidity
Air pressure
86kPa～106kPa
Dimension(W*
D*H)
260mm×220mm×44mm
Weight
0.7kg～0.8kg (Exclude HDD)
Installation
Mode
Desk installation
Model
41 Series
41-P Series
41-8P Series
41-W Series
System
System
Resources
4/8/16-ch series product support 4/8/16 HD connection respectively.
Total bandwidth supports 28/56/80Mbps respectively.
OS
Embedded Linux real-time operation system
Operation
Interface
WEB/Local GUI
Decode
Video Decode
Type
H.264/MJPEG/MJPEG4
Decode
Capability
Max 2-ch 5M 25fps or 4-ch 3M 25fps or 4-ch 1080P 30fps
or 8-ch 720P 30fs
Video
Video Input
4/8/16-ch network compression video input
Video Output
1-channel VGA analog video output
HDMI
1-ch HDMI output. Version number is 1.4
Window Split
1/4/8/9/16-window
1/4-window
Audio
Audio Input
1-ch bidirectional talk input
Audio Output
1-ch bidirectional talk output
Audio
Compression
Standard
G.711a
Alarm
Alarm Input
N/A
Alarm Output
N/A
Funciton
Storage
1 built-in SATA port
Multiple-Chann
el Playback
Max 4-channel 1080P playback
1.3.5 NVR41/41-P/41-8P/41-W Series
11
Model
41 Series
41-P Series
41-8P Series
41-W Series
WIFI AP
N/A
Yes
Port and
Indicator
RS232 Port
N/A
RS485 Port
N/A
USB Port
2 peripheral USB2.0 ports.
Network
Connection
1 RJ45 10/100Mbps self-adaptive Ethernet port.
PoE Port
N/A
4 8 N/A
Power Port
1 power
socket. Power
adapter power
supplying
mode. DC 12V
power.
1 power socket. Power adapter
power supplying mode. DC 48V
power.
1 power
socket. Power
adapter power
supplying
mode. DC 12V
power.
Power Button
1 button
Power On-off
Button
N/A
IR Receiver
Window
N/A
Clock
Built-in clock.
Indicator Light
One power status indicator light.
One network status indicator light.
One HDD status indicator light.
General
Power
Consumption
＜10W (Exclude HDD)
Working
Temperature
﹣10℃～﹢55℃
Working
Humidity
10℅～90℅
Air pressure
86kPa～106kPa
Dimension
205mm×206.75mm×45.2mm
270mm×204m
m×42mm
205mm×206.7
5mm×45.2mm
Weight
0.5kg～1kg (Exclude HDD)
Installation
Mode
Desk installation
Model
41H Series
41H-P Series
41H-8P Series
1.3.6 NVR41H/41H-P/41H-8P Series
12
Model
41H Series
41H-P Series
41H-8P Series
System
System
Resources
4/8/16-ch series product support 4/8/16 HD connection respectively.
Total bandwidth supports 28/56/80Mbps respectively.
OS
Embedded Linux real-time operation system
Operation
Interface
WEB/Local GUI
Decode
Video Decode
Type
H.264/MJPEG/MJPEG4
Decode
Capability
Max 2-ch 5M 25fps or 4-ch 3M 25fps or 4-ch 1080P 30fps
or 8-ch 720P 30fs
Video
Video Input
4/8/16-ch network compression video input
Video Output
1-channel VGA analog video output
HDMI
1-ch HDMI output. Version number is 1.4
Window Split
1/4/8/9/16-window
Audio
Audio Input
1-ch bidirectional talk input
Audio Output
1-ch bidirectional talk output
Audio
Compression
Standard
G.711a
Alarm
Alarm Input
N/A
2-channel
Alarm Output
N/A
2-channel
Funciton
Storage
1 built-in SATA port
Multiple-Chann
el Playback
Max 4-channel 1080P playback
Port and
Indicator
RS232 Port
N/A
RS485 Port
N/A
USB Port
2 peripheral USB2.0 ports.
Network
Connection
1 RJ45 10/100Mbps self-adaptive Ethernet port.
PoE Port
N/A
4
8
Power Port
1 power socket.
Power adapter
power supplying
mode. DC 12V
1 power socket. Power adapter power
supplying mode. DC 48V power.
13
Model
41H Series
41H-P Series
41H-8P Series
power.
Power Button
1 button
Power On-off
Button
N/A
IR Receiver
Window
N/A
Clock
Built-in clock.
Indicator Light
One power status indicator light.
One network status indicator light.
One HDD status indicator light.
General
Power
Consumption
＜10W (Exclude HDD)
Working
Temperature
﹣10℃～﹢55℃
Working
Humidity
10℅～90℅
Air pressure
86kPa～106kPa
Dimension
325mm×250.58mm×51mm
Weight
0.5kg～1kg (Exclude HDD)
Installation
Mode
Desk installation
Model
42 Series
42-P Series
42-8P Series
System
System
Resource
s
4/8/16/32-channel series product support 4/8/16/32-channel HD connection
respectively. Main stream bandwidth supports 40/80/160/160Mbps
respectively.
Operation
System
Embedded Linux real-time operation system
Operation
Interface
WEB/Local GUI
Decode
Video
Compres
sion
H.264/MJPEG/MPEG4
Decode
Capacity
Max supports 16-channel D1, or 8-channel 720P, or 4-channel 1080P, or
4*3M or 2*5M decode.
Video
Video
Input
4/8/16/32-ch network compression video input
1.3.7 NVR42/42-P/42-8P Series
14
Video
Output
1-channel VGA analog video output.
HDMI
1-ch HDMI output. Version number is 1.4
Window
Split
1/4/8/9/16-window
Audio
Audio
Input
1-ch bidirectional talk input
Audio
Output
1-ch bidirectional talk output
Audio
Compres
sion
G.711a
Alarm
Alarm
Input
4-ch alarm input
Alarm
Output
2-ch alarm output
Function
Storage
2 built-in SATA ports.
Multiple-c
hannel
Playback
Max 8-channel 720P/4-channel 1080P playback at the same time.
Port and
Indicator
RS232
Port
One RS232 port to debug transparent COM data.
RS485
port
One RS485 port to control PTZ. Support various protocols.
USB2.0
Port
Three peripheral USB2.0 ports.
Network
Connecti
on
1 RJ45 10/100/1000Mbps self-adaptive Ethernet port.
Power
Port
One power port,
power adapter. Input
DC 12V.
Two power ports. Input
DC 12V/DC 48V.
One power ports.
Input 100-240V ，
47~63Hz.
Power
Button
One button. At the rear panel.
Power
On-off
Button
One button. At the front-panel.
IR
Receiver
Window
Support IR remote control
Clock
Built-in clock.
Indicator
Light
One power status indicator light.
One network status indicator light.
One HDD status indicator light.
15
General
Power
Consump
tion
＜30W(Exclude HDD)
Working
Temperat
ure
-10℃～+55℃
Working
Humidity
10℅－90℅
Air
pressure
86kpa－106kpa
Dimensio
n
375mm×287mm×52m
m
375mm×287mm×52mm
295mm×275mm×47m
m
Weight
1.5kg～2.5kg（Exclude HDD）
Installatio
n
Desk installation
Model
NVR42-4K Series
NVR42-8P-4K Series
System
System
Resource
s
8/16/32-channel series product support 8/16/32-channel HD connection
respectively. The main stream bandwidth supports 48/96/192Mbps.
Operation
System
Embedded Linux real-time operation system
Operation
Interface
WEB/Local GUI
Decode
Video
Compres
sion
H.264/MJPEG/MPEG4
Decode
Capacity
H.264: Max supports 16-channel D1, or 8-channel 720P, 4-channel 1080P
or 1-channel 4K decode.
H.265: Max supports 16-channel D1, or 8-channel 720P, 4-channel 1080P
or 1-channel 4K decode.
Video
Video
Input
8/16/32-ch network compression video input
Video
Output
1-channel VGA analog video output.
HDMI
1-ch HDMI output. Version number is 1.4
Window
Split
1/4/8/9/16-window
Audio
Audio
Input
1-ch bidirectional talk input
Audio
Output
1-ch bidirectional talk output
1.3.8 NVR42-4K/42-8P-4K Series
16
Audio
Compres
sion
G.711a, G.711u, PCM, G726
Alarm
Alarm
Input
8-ch alarm input
Alarm
Output
3-ch alarm output
Relay output. Relay （DC 30V /1A，AC 125V/0.5A（Activation output））
Including one controllable DC +12V output.
Function
Storage
2 built-in SATA ports.
Multiple-c
hannel
Playback
Max 8-channel 720P/4-channel 1080P/1-channel 4K playback at the same
time.
Port and
Indicator
RS232
Port
One RS232 port to debug transparent COM data.
RS485
port
One RS485 port to control PTZ. Support various protocols.
USB Port
2 peripheral USB ports: One USB2.0 at the front panel and one USB3.0 at
the rear panel.
Network
Connecti
on
One RJ45 10/100/1000Mbps self-adaptive Ethernet port.
Power
Port
One power socket. Power adapter
power supplying. Input DC 12V
power.
One power port. Input 100-240V，
47~63Hz.
Power
Button
One button. At the rear panel.
Power
On-off
Button
N/A
IR
Receiver
Window
N/A
Clock
Built-in clock.
General
Indicator
Light
One power status indicator light.
One network status indicator light.
One HDD status indicator light.
One device running status indicator light.
Power
Consump
tion
＜20W(Exclude HDD)
Working
Temperat
ure
-10℃～+55℃
Working
10℅－90℅
17
Humidity
Air
pressure
86kpa－106kpa
Dimensio
n
1U, 375mm(W) × 49.8mm(H) × 250mm(D)
Weight
1.65kg（Exclude HDD）
Installatio
n
Desk/rack installation
Model
NVR44 Series
NVR44-8P Series
NVR44-16P Series
System
System
Resource
s
8/16/32-channel series product support 8/16/32-channel HD connection
respectively. The main stream bandwidth supports 200Mbps.
Operation
System
Embedded Linux real-time operation system
Operation
Interface
WEB/Local GUI
Decode
Video
Compres
sion
H.264/MJPEG/MPEG4
Decode
Capacity
Max supports 16-channel D1, or 8-channel 720P, or 4-channel 3M or 2*5M
decode.
Video
Video
Input
8/16/32-ch network compression video input
Video
Output
1-channel VGA analog video output.
HDMI
1-ch HDMI output. Version number is 1.4
Window
Split
1/4/8/9/16-window
Audio
Audio
Input
1-ch bidirectional talk input
Audio
Output
1-ch bidirectional talk output
Audio
Compres
sion
G.711a
Alarm
Alarm
Input
16-ch alarm input
Alarm
Output
4-ch alarm output
Relay output. Relay （DC 30V /1A，AC 125V/0.5A（Activation output））
Including one controllable DC +12V output.
1.3.9 NVR44/44-8P/44-16P Series
18
