Cantek CT-NC325-VBZ Specsheet

Page 1
CT-NC325-VBZ
NC325‐VBZ
5 MP WDR Vari‐focal Network Bullet Camera
Key Features
1/2.9" Progressive Scan CMOS
H.265, H.265+
120dB WDR
IP67, IK10
BLC/3D DNR/ROI
Smartencoding:Supportlowbitrate,low
latency
4 behavior analyses and face detection
Page 2
CT-NC325-VBZ
NC325‐VBZ
5 MP WDR V
ari‐focal Network Bullet Camera
Specifications
Camera
Image Sensor 1/2.9" Progressive Scan CMOS
Min. Illumination
Shutter Speed 1/3 s to 1/100,000 s
Slow Shutter Support
Day & Night IR Cut Filter
Digital Noise Reduction 3D DNR
WDR 120dB
3‐Axis Adjustment Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Lens
Focal length 2.8 to 12 mm
Aperture F1.6
FOV
Lens Mount Φ14
IR
IR Range Up to 50 m
Wavelength 850nm
Compression Standard
Video Compression
H.264 Type Main Profile/High Profile
H.264+ Support
H.265 Type Main Profile
H.265+ Support
Video Bit Rate 32 Kbps to 16 Mbps
Audio Compression G722.1/G711ulaw/G711alaw/G726/MP2L2
Audio Bit Rate 32 to 128kbps
Smart Feature‐set
Behavior Analysis
Face Detection Support
Region of Interest Support 1 fixed region for each stream
Max. Resolution 2944 × 1656
Main Stream
Sub Stream
Third Stream
Image Enhancement BLC/3D DNR
Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR Color:0.018Lux@(F1.6,AGCON),0LuxwithIR
Horizontal field of view: 88° to 29° Vertical field of view: 47.5° to 16.5° Diagonal field of view: 103° to 33°
Main stream: H.265/H.264 Sub stream: H.265/H.264/MJPEG Third stream: H.265/H.264
Line crossing detection, intrusion detection, unattended baggage detection, object removal detection
50Hz: 20 fps (2944 × 1656), 25 fps (2560 × 1440, 1920 × 1080, 1280 ×720) 60Hz: 20 fps (2944 × 1656), 30 fps (2560 × 1440, 1920 × 1080, 1280 ×720)
50Hz: 25fps (640 × 360, 352 × 288) 60Hz: 30fps (640 × 360, 352 × 240)
50Hz: 25fps (1280 ×720, 640 × 360, 352 × 288) 60Hz: 30fps (1280 ×720, 640 × 360, 352 × 240)
Page 3
CT-NC325-VBZ
NC325‐VBZ
5 MP WDR V
Image Setting
Day/Night Switch Auto/Schedule/Triggered by Alarm In
Network
Network Storage Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Alarm Trigger
Protocols
General Function
API ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI
Simultaneous Live View Up to 6 channels
User/Host
Client iVMS‐4200, iVMS‐4500, iVMS‐5200
Web Browser IE8+, Chrome 31.0‐44, Firefox 30.0‐51, Safari 8.0+
Interface
Audio 1 input (line in, 3.5 mm), 1 output(3.5 mm), single track
Communication Interface 1 RJ45 10M/100M self‐adaptive Ethernet port
Alarm 1 input, 1 output (max. 12 VDC, 30 mA)
Video Output 1Vp‐p composite output (75 Ω/BNC)
On‐board storage Built‐in Micro SD/SDHC/SDXC slot, up to 128 GB
SVC H.264 encoding supports
Reset Button Support
Audio
Environment Noise Filtering Support
Audio Sampling Rate 16 kHz
General
Operating Conditions ‐30 °C to +60 °C (‐22 °F to +140 °F), Humidity 95% or less (non‐condensing)
Power Supply
Power Consumption and Current
Protection Level IP67, IK10
Material Metal
Dimensions Φ144.13×332.73 mm (Φ5.67"× 13.10")
Weight Camera:1893g(4.17lb.)
ari‐focal Network Bullet Camera
Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser
Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error, Alarm input, Alarm output
TC P / I P, IC M P, HT T P, HT T PS , F TP, D H CP, D N S, D D N S, R T P, RT SP, RT C P, PP P oE , NT P, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
One‐key reset, anti‐flicker, three streams, heartbeat, password protection, privacy mask, watermark, IP address filter
Up to 32 users 3 levels: Administrator, Operator and User
12 VDC ± 25%, PoE (802.3at) Terminal block for DC input
12 VDC, 1.3A, max. 15.5W PoE (802.3at, 42.5V to 57V), 0.1A to 0.5A, max. 17.5W
Note: If the WDR and Rotation are both enabled, the frame rate of the main stream should not be more than 20.
Page 4
CT-NC325-VBZ
NC325‐VBZ
5 MP WDR Vari‐focal Network Bullet Camera
Dimensions
332.73mm(13.10")
83.5mm(3.29")
185.19mm(7.29")
46mm(1.81")
174.29mm(6.86")
