IPC-MB132S-IR-3.6
3MP HD Network Mini IR Bullet Camera
Features
1/3” 3Megapixel progressive scan CMOS
H.264&MJPEG dual-stream encoding
Max 20fps@3M(2048×1536)&25/30fps@1080P(1920×1080)
DWDR, Day/Night(ICR), 3DNR, AWB, AGC, BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
3.6mm fixed lens (6mm optional)
Max. IR LEDs Length 30m
IP67, PoE
IPC-MB132S-IR-3.6
Model
Camera
Image Sensor
1/3” 3Megapixel progressive scan CMOS
Effective Pixels
2048(H) 1536(V)
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1s~1/100000s
Min. Illumination
0. 045Lux/F2.1(Color), 0Lux/F2.1(IR on)
S/N Ratio
More than 50dB
Video Output
N/A
Camera Features
Max. IR LEDs Length
30m
Day/Night
Auto(ICR)/Color/B/W
Backlight Compensation
BLC / HLC / DWDR
White Balance
Auto/Manual
Gain Control
Auto/Manual
Noise Reduction
3D
Privacy Masking
Up to 4 areas
Lens
Focal Length
3.6mm(6mm optional)
Max Aperture
F2.1(F1.9)
Focus Control
Manual
Angle of View
H: 81°( 55°)
Lens Type
Fixed lens
Mount Type
Board-in Type
Video
Compression
H.264/ H.264H/ H.264B/ MJPEG
Resolution
3M(2048× 1536)/1080P(1920× 1080)/720P(1280× 720)/
D1(704× 576/704×480) /CIF(352× 288/352× 240)
Frame Rate
Main Stream
3M(1 ~ 20fps)/1080P(1 ~ 25/30fps)
Sub Stream
D1(1 ~ 25/30fps)
Bit Rate
H.264: 4kbps～8192bps
Corridor Mode
Support
Audio
Compression
N/A
Interface
N/A
Network
Ethernet
RJ-45 (10/100Base-T)
Wi-Fi
N/A
Protocol
IPv4/IPv6, HTTP, HTTPS, TCP/IP, UDP, UPnP, ICMP, IGMP, RTSP, RTP,
SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS
Compatibility
ONVIF, CGI
Max. User Access
20 users
Technical Specifications
IPC-MB132S-IR-3.6
IPC-MB132S-IR-3.6
Smart Phone iPhone, iPad, Android, Windows Phone
Auxiliary Interface
Memory Slot N/A
RS485 N/A
Alarm N/A
PIR Sensor Range N/A
General
Power Supply DC12V, PoE (802.3af)
Power Consumption <4.7W(IR on)
Working Environment -30°C~+60°C, Less than 95% RH
Ingress Protection IP67
Vandal Resistance N/A
Dimensions
Weight 0.38Kg(with package 0.44 Kg)
Dimensions (mm)
Φ70mm× 165mm
Accessories (optional)
PFA121 PFA152
