Cantek CT-IPC-HF3500N Specsheet

IPC-HF3500

5Megapixel Full HD Network Camera

Features

 1/2.5” 5Megapixel Progressive Scan Aptina CMOS
 H.264 & MJPEG dual-stream encoding
 Max 8fps@5.0M(2536×1920)&25/30fps@1080P(1920×1080)
 DWDR, Day/Night(ICR), 2DNR, AWB, AGC, BLC
 Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
 Built-in 1/1 alarm in/out
 PoE( not for –W series); Wi-Fi(-W only)
 SD memory

IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP,

IPC-HF3500

Technical Specifications

Model IPC-HF3500P IPC-HF3500P-W IPC-HF3500N IPC-HF3500N-W

Camera

Image Sensor 1/2.5” 5Megapixel Aptina CMOS

Effective Pixels 2592(H)×1944(V)

Scanning System Progressive

Electronic Shutter Speed Auto/Manual,1/3~1/10000s Auto/Manual,1/4~1/10000s

Min. Illumination

S/N Ratio >50dB

Video Output

Camera Features

Day/Night

Backlight Compensation

White Balance Auto

Gain Control Auto/Manual

Color: 0. 6Lux/F1.2, B/W: 0.08Lux/F1.2

1 channel, BNC(1.0Vp-p, 75Ω)

Auto(ICR) / Color / B/W

BLC / HLC / DWDR

Noise Reduction 2D

Privacy Masking

Lens

Mount Type C/CS

Video

Compression H.264 / MJPEG

Resolution 5.0M(2560x1920) / 3.0M(2048×1536) /

Frame
Rate

Bit Rate H.264: 32K ~ 8192Kbps, MJPEG: 32K ~ 20480Kbps

Audio

Compression G.711a / G.711u(64kbps) / PCM(128kbps)

Interface 1/1 channel In/Out

Network

Ethernet RJ-45 (10/100Base-T)

Wi-Fi N/A 802.11b\g N/A 802.11b\g

Protocol

ONVIF ONVIF Ver. 2.0

Max. User Access 10 users

Main Stream 5M(1-8fps)/3M(1-15fps)/1080P/720P(1 ~ 25/30fps)

Sub Stream D1/CIF(1 ~ 25/30fps)

Up to 4 areas

5.0M(2560x1920) / 3.0M(2048×1536) /
1080P(1920×1080) / 720P(1280×720) /
D1(704×576) / CIF(352×288)

SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour

1080P(1920×1080) / 720P(1280×720) /
D1(704×480) / CIF(352×240)

Smart Phone iPhone, iPad, Android, Windows Phone

Auxiliary Interface

Memory Slot SD, Max 32GB

RS485 1

Alarm 1/1 channel In/Out
