Page 1
IPC-HFW2300R-Z/VF
3MP Full HD Network Water-proof IR Bullet Camera
Features
1/3” 3Megapixel progressive CMOS
H.264 & MJPEG dual-stream encoding
Max 20fps@3M(2048x1536) &25/30fps@1080P(1920 x1080)
DWDR, Day/Night(ICR), 3DNR, AWB, AGC, BLC
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
2.7~12mm varifocal lens
Max IR LEDs Length 30m
IP66, PoE
Page 2
20)/D1(704× 576/704× 480)/CIF(352×288/352× 240)
Frame Rate
Main Stream
3M(1 ~ 20fps)/1080P (1 ~ 25/30fps)
Sub Stream
D1/CIF(1 ~ 25/30fps)
Bit Rate
H.264H: 40K ~ 8192Kbps; MJPEG: 40K~16384Kbps
Audio
Compression
N/A
Interface
N/A
Network
Ethernet
RJ-45 (10/100Base-T)
Wi-Fi
N/A
Protocol
IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP,
RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS,
Bonjour
Compatibility
ONVIF, CGI, PSIA
Max. User Access
20 users
IPC-HFW2300R-Z/VF
Technical Specifications
Model IPC-HFW2300R-VF IPC-HFW2300R-Z
Camera
Image Sensor 1/3” 3Megapixel progressive scan CMOS
Effective Pixels 2048(H)x1536(V)
Scanning System Progressive
Electronic Shutter Speed Auto/Manual, 1/3(4)~1/10000s
Min. Illumination
S/N Ratio More than 50dB
Video Output N/A
Camera Features
Max. IR LEDs Length 30m
Day/Night Auto(ICR)/Color/B/W
Backlight Compensation
White Balance Auto/Manual
Gain Control Auto/Manual
Noise Reduction 3D
Privacy Masking Up to 4 areas
Lens
Focal Length 2.7mm~12mm 2.7mm~12mm
Max Aperture F1.4 F1.4
Focus Control Manual Auto
Angle of View
Lens Type Manual/ Fixed Iris Motorized/ Fixed Iris
Mount Type Board-in Type Board-in Type
Video
Compression H.264/ H.264H/ MJPEG
Resolution 3M(2048x1536)/1080P(1920x1080)/1.3M(1280×960)/720P(1280× 7
0. 01Lux/F1.4 (Color), 0Lux/F1.4(IR on)
BLC / HLC / DWDR
H: 92°~ 28° H: 92°~ 28°
Page 3
Smart Phone
iPhone, iPad, Android, Windows Phone
Auxiliary Interface
Memory Slot
N/A
RS485
N/A
Alarm
N/A
PIR Sensor Range
N/A
General
Power Supply
DC12V/PoE (802.3af)
Power Consumption
< 4.5W
< 8.5W
Working Environment
-30°C~+60°C, Less than 95% RH
Ingress Protection
IP66
Vandal Resistance
N/A
Dimensions
72mm× 80mm× 212.8mm
Weight
0.65kg
IPC-HFW2300R-Z/VF
Page 4
PFA122
PFA152
PFA151
IPC-HFW2300R-Z/VF
Dimensions (mm)
Accessory (optional)
