Cantek CT-CVI-VD221R-IR-ZD Specsheet

CT-CVI-VD221R-IR-ZD
CVI-VD221R-IR-Z
2MP WDR HDCVI IR Dome Camera
Series
1080p
30
m IR
DC 12V
IP67
Vandal-proof
Pro
· 120dB true WDR, 3DNR
· HD and SD dual-output
· 2.7-12mm motorized lens
· Max. IR length 30m, Smart IR
· IP67, IK10, DC12V
System Overview
CVI-VD221R-IR-Z offers full HD 1080P video with the simplicity of using existing coaxial infrastructure. The camera features 120dB true WDR for application motorized/fixed lens models with multi-language OSD and HD&SD dual-output. The outstanding performance and true WDR feature make the camera an ideal choice for mid to large-size business and common projects where both highly reliable surveillance and construction flexibility are concerned.
s under complex dynamic range and presents high quality image with clear details and accurate color rendition. It offers various
CT-CVI-VD221R-IR-ZD
CVI-VD221R-IR-Z
2MP WDR HDCVI IR Dome Camera
Functions
4 Signa
ls over 1 Coaxial Cable
HDCVI technology supports 4 signals to be transmitted over 1 coaxial cable simultaneously, i.e. video, audio*, data and power. Dual-way data
ansmission allows the HDCVI camera to interact with the HCVR, such as sending control signal or triggering alarm. Moreover, HDCVI technology
tr supports PoC for construction flexibility.
*
Audio input is availa
Long Dis
HDCVI technology guarantees long-distance and real-time transmission without any loss. It supports up to 800m for 1080P Full
cable, and up to 300m via UTP cable.*
* Act
ual results verified
Simplicit
DCVI technology inherits the born feature of simplicity from traditional analog surveillance system, makin
H protection. HDCVI system can seamlessly upgrade the traditional analog system without replacing existing coaxial cabling. The plug and play approach enables full HD video surveillance without the hassle of configuring a network.
Wide Dynamic Range
Embedded with ind
conditions. True WDR (120dB) optimizes both the bright and dark areas of a scene at the same time to provide usable vid
A
dvanced 3DNR
3DNR is noise reduction technology that detects and eli technology allows remarkable noise reduction with little impact to sharpness, especially under limited lighting condit 3DNR effectively decreases the band width and saves the storage space.
Multi-
outputs
The camera supports HDCVI and CVBS signal outputs simultaneously with two BNC connectors. Multi-outputs facilitates construction in such situations as debugging through a tester. It also offers the possibility for cooperating with multiple devices including analog matrix or monitor.
Smart IR
The camera is designed with array LED IR illumination for best lowlight performance. Smart IR is a technology to ensure brightness uniformity in B/W image under low illumination. Dahua’s unique Smart IR adjusts to the intensity of camera's infrared LEDs to compensate for the distance of an object, and prevents IR LEDs from o
Protection
The camera's outstanding reliability is unsurpassed due to its rugged design. The camera is protected against water and dust with IP67, making it
suitable for ind
The camera complies with IK10 impact resistant rating to provide maximum durability against vandals, making it capable of withstanding the equivalent of 55kg (120lbs) of force. Supporting ±25% input voltage tolerance, this camera suits even the most unstable power supply conditions. Its 4KV lightning rating provides protection against the camera and its structure from the effects of lightning.
ble for some models of HDCVI cameras.
tance Transmission
by real-scene testi
y
ustry leading wide dynamic range (WDR) technology, vivid pictures are achieved even in the most intense contrast lighting
oor or outdoor environments.
rato
ng in Dahua's test labo
ry.
m
inates random noises by comparing two sequential frames. Dahua’s advanced 3DNR
verexposing images as the object come closer to the camera.
HD video via coaxial
g itself a best choice for investment
eo.
ion. Besides, the advanced
CVI-VD221R-IR-Z
CT-CVI-VD221R-IR-ZD
2MP WDR HDCVI IR Dome Camera
Technical Specicaon
Camera
Image Sensor
Effective Pixels
Scanning System
Electronic Shutter Speed
Minimum Illumination
S/N Ratio
IR Distance
IR On/Off Control
IR LEDs
Lens
Lens Type
Mount Type
Focal Length
Max Aperture
Angle of View
Focus Control
Close Focus Distance
1/2.7" CMOS
1928(H)×1088 (V), 2.1MP
Progressive
PAL: 1.3s~1/30000s
NTSC: 1s~1/30000s
0.03Lux/F1.4, 0Lux IR on
More than 65dB
Up to 30m (98feet)
Auto / Manual
2
Motorized lens / Fixed iris
Board-in
2.7-12mm
F1.4
H: 99°~37°
Auto / Manual
300mm
11.81''
Cercaons
Certifications
Interface
Audio Interface
Eelectrical
Power Supply
Power Consumption
Environmental
Operating Conditions
Storage Conditions
Ingress Protection &Vandal Resistance
Construcon
Casing
Dimensions
Net Weight
Gross Weight
CE (EN55032, EN55024, EN501 30- 4) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
N/A
12V DC ±25%
Max 5W (12V DC, IR on)
-30°C ~ +60 °C (-22°F ~ +140°F) / Less than 90% RH * Start up should be done at above -30°C (-22°F)
-30°C ~ +60 °C (-22°F ~ +140°F) / Less than 90% RH
IP67 & IK10
Aluminium
Φ122mm×88.9mm (Φ4.8 "×3.5")
0.45kg (0.99lb)
0.60k g (1.32lb)
Pan / Tilt / Rotaon
Pan/Tilt/Rotation
Video
Resoluon
Frame Rate
Video Output
Day/Night
OSD Menu
BLC Mode
WDR
Gain Control
Noise Reduction
White Balance
Smart IR
Pan: 0° ~ 355°
Tilt: 0° ~ 75° Rotaon: 0° ~ 355°
1080P (1920×1080)
25/30fps@1080P, 25/30/50/60fps@720P
1-channel BNC HDCV I high definition video output & 1-channel BNC CVBS video output CVBS tester out
Auto (ICR) / Manual
Multi-language
BLC / HLC / WDR
120dB
AGC
2D / 3D
Auto / Manual
Auto / Manual
CT-CVI-VD221R-IR-ZD
CVI-VD221R-IR-Z
2MP WDR HDCVI IR Dome Camera
Accessories
Oponal:
PFA137
Juncon box
PFB200C In-ceiling mount
PFB203W Wall mount
Juncon Mount Inceiling Mount
PFA136 PFB200C
Dimensions (mm/inch)
PFA152 Pole mount
Wall Mount
Pole Mount
PFB203W + PFA152PFB203W
Design and specifications are subject to change without notice.
