Cantek CT-AC335-MB 3.6mm Specsheet

CT-AC335-MB 3.6mm

3MP WDR EXIR Bullet Camera

Key Features

 3 Megapixel high-performance CMOS

 Analog HD output, up to 3MP resolution

 2.8mm, 3.6mm, 6mm lens

 True Day/Night

 OSD menu, DNR, Smart IR

 True WDR, up to 120dB

 EXIR technology, up to 20m IR distance

 IP66 weatherproof

 CoC ( Control over Coax)

CT-AC335-MB 3.6mm

3MP WDR EXIR Bullet Camera

Specifications

Camera

Image Sensor 3MP CMOS Image Sensor
Effective Pixels 2052(H)*1536(V)
Min. illumination 0.01 Lux @ (F1.2,AGC ON), 0 Lux with IR
Shutter Time 1/25s to 1/50,000s
Lens 2.8mm, 3.6mm, 6mm lens @ F1.2

Lens Mount M12

Day & Night ICR

Angle Adjustment Pan: 0° - 360°; Tilt:0° - 90°; Rotate: 0° - 360°

Synchronization Internal Synchronization

WDR 120dB

Video Frame Rate 1920×1536@18fps

HD Video Output 1 Analog HD output

S/N Ratio ＞62dB

Menu

AGC Support

D/N Mode Color/BW/SMART

White Balance ATW/ MWB

BLC Support

Functions Wide Dynamic Range, Digital noise reduction, Mirror, SMART IR

General

Operating Conditions -40 °C – 60 °C (-40 °F – 140 °F), Humidity 90% or less (non-condensing)

Power Supply 12 VDC±15%

Power Consumption Max. 5W

Protection Level IP66

IR Range Up to 20m

Communication

Dimensions 58.5mm×55.5mm×153.6mm (2.30”×2.19”×6.05”)

Weight Approx. 370g (0.82lb)

CoC ( Control over Coax) : (TVI output)
