Cantek CT-AC334-MB 3.6mm Specsheet

CT-AC334-MB 3.6mm

1080P WDR EXIR Bullet Camera

HD

Key Features

 2 Megapixel high-performance CMOS

 Analog HD output, up to 1080P resolution

 3.6mm lens

 True Day/Night

 OSD menu, DNR, Smart IR

 True WDR, up to 120dB

 EXIR technology, up to 20m IR distance

 IP66 weatherproof

 Up the Coax(HIKVISION-C)

CT-AC334-MB 3.6mm

HD

1080P WDR EXIR Bullet Camera

Specifications

Camera

Image Sensor 2MP CMOS Image Sensor
Signal System PAL/NTSC
Effective Pixels 1928(H)*1088(V)
Min. illumination 0.01 Lux @ (F1.2,AGC ON), 0 Lux with IR
Shutter Time 1/25s to 1/50,000s
Lens

Lens Mount M12

Day & Night ICR

Angle Adjustment Pan: 0° - 360

Synchronization Internal Synchronization

WDR 120dB

Video Frame Rate 1080p@25fps/1080p@30fps

HD Video Output 1 Analog HD output

S/N Ratio ＞62dB

Menu

AGC Support

D/N Mode Color/BW/SMART

White Balance ATW/ MWB

BLC Support

Functions Wide Dynamic Range, Digital noise reduction, Mirror, SMART IR

General

Operating Conditions -40 °C – 60 °C (-40 °F – 140 °F), Humidity 90% or less (non-condensing)

3.6mm LENS@ F1.2

ilt:0° - 90°; Rotate: 0° - 360°

°; T

Power Supply 12 VDC±

Power Consumption Max. 5W

Protection Level IP66

IR Range Up to 20m

Communication Up the coax, Protocol: HIKVISION-C (TVI output)

Dimensions 58.5mm×55.5mm

Weight Approx. 370g (0.82lb)

15%

.6mm (2.30”×2.19”×6.05”)

×153
