Cantek CT-AC334-FD4 3.6mm Specsheet

CT-AC334-FD4 3.6mm

HD1080P WDR EXIR Turret Camera

Key Features

 2 Megapixel high-performance CMOS

 Analog HD output, up to 1080P resolution

 True Day/Night

 OSD menu, DNR, Smart IR

 True WDR, up to 120dB

 EXIR technology, up to 40m IR distance

 IP66 weatherproof

 Up the Coax(HIKVISION-C)

CT-AC334-FD4 3.6mm

HD1080P WDR EXIR Turret Camera

Camera

Image Sensor 2MP CMOS Image Sensor
Signal System PAL/NTSC
Effective Pixels 1928(H)*1088(V)
Min. illumination 0.01 Lux @ (F1.2,AGC ON),0 Lux with IR
Shutter Time 1/25(1/30)s to 1/50,000s

Specifications

Lens

Lens Mount M12

Day & Night ICR

Angle Adjustment Pan: 0° - 360°; Tilt: 0° - 75°; Rotate: 0° - 360°

Synchronization Internal Synchronization

WDR 120dB

Video Frame Rate 1080p@25fps/1080p@30fps

HD Video Output 1 Analog HD output

S/N Ratio ＞62dB

Menu

AGC Support

D/N Mode Color/BW/SMART

White Balance ATW/ MWB

BLC Support

Functions Wide Dynamic Range, Digital noise reduction, Mirror, SMART IR

General

3.6mm

Angle of View: 103°(2.8mm), 82.2°(3.6mm), 54°(6mm), 37.7°(8mm), 24.3°(12mm), 18.8°(16mm)

Operating Conditions -40 °C – 60 °C (-40 °F – 140 °F), Humidity 90% or less (non-condensing)

Power Supply 12 VDC±15%

Power Consumption Max. 5W

Protection Level IP66

IR Range Up to 40m

Communication Up the coax, Protocol: HIKVISION-C (TVI output)

Dimensions φ110mm×93.2mm (φ4.33”×3.67”)

Weight Approx. 350g (0.77lb)
