Thank you for purchasing this Canon product

The EOS D60 digital camera is a high-performance, single-lens reflex AF camera with an ultra­fine CMOS sensor having approx. 6.3 million effective pixels. The camera is compatible with all
Canon EF lenses and designed for quick and easy shooting. It is full-featured for all types of
photography, from fully automatic snapshooting to professional-level, creative work.
CompactFlash cards (CF Type I and II) serve as the recording medium.

Before using the camera, be sure to read these Instructions to familiarize yourself with the
camera’s features and proper operation.

∗ Using CF cards made by Canon is recommended.

Radio and Television Interference (VCCI Statement)

This camera is an information technology device that does not exceed Class B limits for
electromagnetic interference (EMI) in compliance with standards set by Japan’s Voluntary
Control Council for Interference by Information Technology Equipment (VCCI). This device may
still cause interference with radio or television reception when placed near such an appliance.
Read these Instructions to learn how to avoid reception interference of other appliances.

Test the Camera Before Shooting

Before using the camera, be sure to test it first. Check that the images are properly recorded
on the CF card. If the camera or CF card is faulty and the images cannot be recorded or read
by a personal computer, Canon cannot be held liable for any loss or inconvenience caused.

About Copyrights

Copyright laws in your country may prohibit the use of images of people and certain subjects
for anything but private enjoyment. Photographing public performances or exhibitions may
also be prohibited.

● Canon and EOS are trademarks of Canon Inc.

● Adobe and Photoshop are trademarks of Adobe Systems Incorporated.

● CompactFlash is a trademark of SanDisk Corporation.

● IBM PC/AT and Microdrive are trademarks or registered trademarks of International

Business Machines.

● Macintosh is a registered trademark of Apple Corporation in the United States and other

countries.

● All other trademarks are the property of their respective owners.

This digital camera supports Exif 2.2 (also called “Exif Print”). Exif Print is a standard for
enhancing the communication between digital cameras and printers. By connecting to an Exif
Print-compliant printer, the camera’s image data at the time of shooting is used and optimized,
yielding extremely high quality prints.

Equipment Check List

Be sure all the following equipment and accessories have been included with your camera. If
anything is missing, contact your dealer.

¢ EOS D60 camera body (with body cap and lithium backup battery for the date and time)
¢ Eyecup Eb
¢ Battery Pack BP-511
¢ Compact Power Adapter CA-PS400
¢ DC Coupler DR-400
¢ Interface Cable IFC-200PCU
¢ Video Cable VC-100
¢ Neck Strap EW-100DB (with eyepiece cover)

¢ EOS Digital Solution Disk
¢ Adobe Photoshop LE Disk

¢ EOS D60 Instructions (which you are reading now)
¢ EOS D60 Software Instructions

Explains how to install the software for transferring images from the camera to a personal
computer, editing RAW images, and setting processing parameters.

¢ Battery Pack BP-511 Instructions

¢ Warranty card
¢ Quick Operation Guide
¢ EOS D60 Accessories

Introduces major accessories for the EOS D60.

Introduction

∗ No CF card is included. Please purchase it separately. CF cards made by Canon are

recommended.

∗ A microdrive is a recording medium using a hard disk. It has a large capacity and the price

per megabyte is low. However, compared to a CF card equipped with a flash memory, it is
vulnerable to vibration and physical shock. If you use a microdrive, be careful not to subject
the camera to vibration, shake, or physical shock while it is recording or displaying images.

3

Contents

Introduction

Equipment Check List .......................... 3

Handling Precautions ......................... 10

Quick Guide ....................................... 12

Nomenclature..................................... 14

Conventions Used in This Manual...... 20

Before Y ou Start

1

Charging the Battery Pack ................. 22

Inserting and Removing the Battery Pack

Inserting the Battery Pack............... 24

Battery Level Icons ......................... 24

Removing the Battery Pack ............ 25

Using a Household Power Supply.... 26

Mounting and Detaching a Lens ........ 27

Mounting a Lens ............................. 27

Detaching a Lens ............................ 27

Installing a CF Card ........................... 28

Removing a CF Card ...................... 28

Basic Operation ................................. 29

Main Switch .................................... 29

Shutter Button ................................. 29

Using the Electronic Dials ............... 30

LCD Monitor.................................... 31

Menu Functions and Settings ......... 32

Setting the Date and Time .......... 34

Dioptric Adjustment in the Viewfinder.. 36

Holding the Camera ........................... 36

Simple Picture Taking

2

Fully Automatic Picture Taking ...... 38

Automatic Built-in Flash .................. 39

AF-Assist Beam .............................. 39

Check the Image Immediately............ 40

Check the Image in PLAY Mode .. 40

Checking the Image

After it is Taken.............................. 41

Time for Image Review ............ 42

Erasing a Recorded Image

(Single Image Erase) ...................... 43

Portrait Mode .................................. 44

Landscape Mode ........................... 45

..........................

... 24

.................

21

37

Close-Up Mode............................... 46

Sports Mode .................................. 47

Night Portrait Mode ........................ 48

Advanced Operations

3

Quality Selection ......................... 50

ISO Speed .................................. 51

Setting Processing Parameters... 52

AF Mode Selection ....................... 54

One-Shot AF for Still Subjects ........ 55

AI Servo AF for Moving Subjects .... 56

AI Focus AF .................................... 56

AF Point Selection......................... 57

Focusing On an Off-Center Subject ... 58

Problem Subjects for Autofocusing .... 59

Manual Focus............................ 59

INFO.

Checking Camera Settings ........ 60

Selecting a Metering Mode............ 61

Metering Modes ................................. 62

Selecting a Drive Mode ...................... 63

Setting the White Balance ............ 64

White Balance Settings ...................... 65

Custom White Balance Setting ... 66

LCD Panel Illumination....................... 67

Program AE .................................... 68

Shutter-Priority AE ......................... 70

Aperture-Priority AE ...................... 72

Checking the Depth of Field............... 73

Manual Exposure............................ 74

Automatic Depth-of-Field AE....... 76

Setting Exposure Compensation ....... 77

Autoexposure Bracketing ............ 78

AE Lock .......................................... 80

Self-timer Operation ....................... 81

Using the Eyepiece Cover .............. 82

Bulb Exposures .................................. 83

Mirror Lockup ..................................... 84

Flash Photography

4

Using the Built-in Flash ...................... 86

in the Basic Zone .......................... 86

in the Creative Zone...................... 86

Built-in Flash Range ....................... 87

.................

......................

49

85

4

Contents

Flash Sync Shutter Speed and

Aperture Settings .......................... 87

Red-eye Reduction .................. 89

FE Lock ....................................... 90

Flash Exposure Compensation .. 91

Flash Photography with the

EOS-Dedicated 550EX Speedlite ... 92

Full Auto Flash ................................ 93

Taking Flash Pictures in Each

Shooting Mode................................ 93

High-Speed Sync (FP Flash) ...... 94

FEB (Flash Exposure Bracketing)... 94

FE Lock ....................................... 95

Flash Exposure Compensation .. 95

Modeling Flash ............................... 95

Wireless Multi-Flash/E-TTL

Autoflash Shooting.......................... 95

Using Non-Canon Flash Units ........... 96

TTL and A-TTL Speedlites ................. 96

Playing and Erasing Recorded Images

5

Viewing Recorded Images ................. 98

Viewing a Single Image .............. 98

Viewing the Index ..................... 98

Viewing Enlarged Images......... 99

JUMP

Jumping to Another Image..... 99

INFO.

Turning the Information Display

On and Off .................................. 100

Automated Playback of Recorded

Images (Auto playback) .............. 101

Rotating an Image ................. 102

Protecting an Image.................. 103

Erasing Images (All Image Erase) ..

Formatting the CF Card ............ 105

Print Order ................................ 106

Selecting Images for Printing ........ 107

Print T ype...................................... 109

Specifying Date Printing ............... 110

Specifying File Number Printing ... 111

Connecting to a TV .......................... 112

Replacing the Date/Time Battery ..... 113

File Numbering System............. 114

Cleaning the CMOS Imaging

Element......................................... 115

...

104

97

Menu Function Settings

6

List of Menu Functions.............. 118

Custom Function Settings............. 122

Reference

7

Basic T erminology ............................ 128

Function Availability Table ................ 131

AF Modes and Drive Modes ............ 131

Exposure Warnings .......................... 132

AE Lock Effects for Combinations of

AF Point Selection and

Metering Method ........................... 133

Program Line.................................... 133

Shutter Speed and

Aperture Value Readouts .............. 134

Message List .................................... 135

Error Code ....................................... 135

Troubleshooting................................ 136

Major Accessories (Optional) .............. 138

System Map ..................................... 140

Major Specifications ......................... 142

Index ................................................ 146

...................................

...........

117

128

Introduction

1

2

3

4

5

6

7

5

EOS D60

This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.

Note:This equipment has been tested and found to comply with the limits for class B

digital devices, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa­tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interfer­ence will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

— Consult the dealer or an experienced radio/TV technician for help.

The cable with the ferrite core provided with the digital camera must be used with this
equipment in order to comply with Class B limits in Subject B of Part 15 on the FCC rules.

Do not make any changes or modifications to the equipment unless otherwise specified in
the manual. If such changes or modifications should be made, you could be required to
stop operation of the equipment.

Canon U.S.A. Inc.
One Canon Plaza, Lake Success, NY 11042, U.S.A.
Tel No. [phone]

The Mark is a directive conformity mark of the European Community (EC).

This mark indicates that the product complies with Australia’s EMC regulations.

6

SAFETY PRECAUTIONS

• Before using the camera, please ensure that you have read and understood the safety
precautions described below. Always ensure that the camera is operated correctly.

• The safety precautions noted as follows are intended to instruct you in the safe and
correct operation of the camera and its accessories to prevent injuries or damage to
yourself, other persons and equipment.

• The term “equipment” refers primarily to the camera and its power supply accessories.

WARNINGS

• Do not aim the camera or detached lens only directly into the sun or at other intense light
sources that could injure your eyesight.

• Store this equipment out of the reach of children and infants. Accidental damage to the
camera or batteries by a child could result in serious injury. In addition, placement of the
neck strap around a child’s neck could result in asphyxiation.

• Be particularly careful to keep the lithium battery CR2025 used in the camera out of the
reach of children. Seek medical assistance immediately if a child swallows the battery.

• Do not attempt to disassemble or alter any part of the equipment. Disassembly or
alteration may result in high-voltage electrical shock. Internal inspections, alterations and
repairs should be conducted by qualified service personnel authorized by your camera
distributor or Canon Customer Support.

•To avoid the risk of high-voltage electrical shock, do not touch internal portions of the
equipment that become exposed as a result of damage. Please take the first opportunity
to consult your camera distributor or Canon Customer Support immediately.

• Stop operating the equipment immediately if it should emit smoke or noxious fumes.
Failure to do so may result in fire or electrical shock. Set the camera’s main switch to the
OFF position and remove the camera battery or unplug the power cord from the electrical
outlet immediately. Please consult your camera distributor or the closest Canon Customer
Support.

• Stop operating the equipment if it is dropped or the casing is damaged. Failure to do so
may result in fire or electrical shock. Set the camera’s main switch to the OFF position
and remove the camera battery or unplug the power cord immediately. Please consult
your camera distributor or the closest Canon Customer Support.

• Prevent the equipment from immersion in, water or other liquids. Do not allow liquids to
enter the interior. The camera is not waterproof. If the exterior contacts with liquids or salt
air, wipe it dry with a soft, absorbent cloth. If water or other foreign substances enter the
interior, immediately set the camera’s main switch to the OFF position and remove the
camera battery or unplug the power cord immediately. Continued use of the equipment
may result in fire or electrical shock. Please consult your camera distributor or the closest
Canon Customer Support.

• Do not use substances containing alcohol, benzene, thinners or other organic solvent
substances to clean or maintain the equipment.

• Do not cut, damage, alter or place heavy items on the power cord. Any of these actions
may cause an electrical short circuit, which may lead to fire or electrical shock. Replace a
broken or damaged power cord.

Introduction

7

• Do not use substances containing alcohol, benzene, thinners or other flammable
substances to clean or maintain the equipment. The use of these substances may lead to
fire.

• Do not cut, damage, alter or place heavy items on the power adapter cord. Any of these
actions may cause an electrical short circuit, which may lead to fire or electrical shock.
Replace a broken or damaged power adapter cord.

• Do not handle the power cord if your hands are wet. Handling it with wet hands may lead
to electrical shock. When unplugging the cord, ensure that you hold the rigid portion of
the plug. Pulling the flexible portion of the cord may damage or expose the wire and
insulation, creating the potential for fires or electrical shocks.

• Use of power sources not expressly recommended for this equipment may lead to
overheating, distortion of the equipment, fire, electrical shock or other hazards. Use only
the recommended power accessories.

• Power down the computer and unplug the power cord before attempting to connect the
interface cable, to avoid the risk of electrical shock.

• Do not place the batteries near a heat source or expose them to direct flame or heat.
Neither should you immerse them in water. Such exposure may damage the batteries and
lead to the leakage of corrosive liquids, fire, electrical shock, explosion or serious injury.

• Do not attempt to disassemble, alter, or apply heat to the batteries. There is serious risk
of injury due to an explosion. Immediately flush with water any area of the body, including
the eyes and mouth, or clothing, that comes into contact with the inner contents of a
battery. If the eyes or mouth contact these substances, immediately flush with water and
seek medical assistance.

•Avoid dropping or subjecting the batteries to severe impacts that could damage the
casings. This could lead to leakage and injury.

• Do not short-circuit the battery ter minals with metallic objects, such as key holders. This
could lead to overheating, burns and other injuries. Use the supplied battery case to
transport or store the battery pack.

• Before you discard a battery, cover the terminals with tape or other insulators to prevent
direct contact with other objects. Contact with the metallic components of other materials
in waste containers may lead to fire or explosions. Discard batteries in specialized waste
facilities if available in your area.

• Use of batteries not expressly recommended for this equipment may cause explosions or
leaks, resulting in fire, injury and damage to the surroundings. Use only recommended
batteries and accessories.

• Use only the recommended compact power adapter to charge the Battery Pack BP-511
rechargeable batteries. Use of chargers not expressly recommended may result in
overheating, distortion, fire or electrical shock.

• Disconnect the compact power adapter from both the camera and electrical outlet after
recharging and when the camera is not in use to avoid fires and other hazards.

• The camera terminal of the compact power cord is designed for exclusive use with the
EOS D60. Do not use it with other products or batteries. There is a risk of fire and other
hazards.

8

CAUTIONS

•Avoid using, placing or storing the equipment in places subject to strong sunlight or high
temperatures, such as the dashboard or trunk (boot) of a car. Exposure to intense
sunlight and heat may cause the batteries to leak, overheat or explode, resulting in fire,
burns or other injuries. High temperatures may also cause deformation of the casing.
Ensure that there is good ventilation when using the compact power adapter to charge
the battery pack or power the camera.

• Do not store the equipment in humid or dusty areas. Storage in these areas could lead to
fire, electrical shock or other damage.

• Be careful not to bang the camera or subject it to strong impacts or shocks that could lead
to injury or damage the equipment when wearing or holding it by the wrist strap.

• Be careful not to cover the flash with your fingers when shooting. In addition, do not touch
the surface of the flash after taking several pictures in rapid succession. Either action
could result in burns.

Preventing Malfunctions

Avoid Strong Magnetic Fields

Never place the camera in close proximity to electric motors or other equipment generating
strong electromagnetic fields. Exposure to strong magnetic fields may cause malfunctions
or corrupt image data.

Avoid Condensation Related Problems

Moving the equipment rapidly between hot and cold temperatures may cause condensation
(water droplets) to form on its external and internal surfaces. You can avoid this by placing
the equipment in an airtight, resealable plastic bag and letting it adjust to temperature
changes slowly before removing it from the bag.

If Condensation Forms Inside the Camera

Stop using the camera immediately if you detect condensation. Continued use may damage
the equipment. Remove the CF card and battery or power cord (if connected) from the
camera and wait until the moisture evaporates completely before resuming use.

Extended Storage

When not using the camera for extended periods of time, remove the battery (except the
CR2025 lithium button battery) and store the equipment in a safe place. Storing the camera
for extended periods with a battery installed will run down the battery and may damage the
camera.

Important Safety Functions and Preventive Measures

• When the CF Card Access Lamp is blinking, do not remove the CF card from the camera.
Since the card is reading and writing data when the lamp is blinking, removal of the CF
card at this time will damage the card.

• Do not use any cable other than that supplied with the camera. Use the supplied interface
cable to connect the camera to a computer. Use of any other cable may lead to a
malfunction.

Introduction

9

Handling Precautions

The Camera

(1) This camera is a precision instrument. Do not drop it or expose it to physical shock.
(2) The camera is not waterproof and should not be used in wet conditions or underwater. If

the camera gets wet, take it to your nearest Canon dealer as soon as possible. If small
amounts of water splash onto the camera, wipe it with a clean dry cloth. If the camera is
exposed to salty air, wipe it thoroughly with a slightly damp cloth.

(3) Never leave the camera close to devices that generate strong magnetic fields, such as

magnets or electric motors. Do not operate or leave the camera in areas where strong
electromagnetic signals are generated, such as near electronic transmission towers.
Exposing the camera to strong electromagnetic signals can cause it to malfunction and
destroy recorded image data.

(4) Do not leave the camera in hot locations, such as in a car sitting in direct sunlight. High

temperatures can damage the camera.

(5) The camera contains precision circuits. Never attempt to disassemble the camera or

service it yourself.

(6) Use a commercially available blower brush to remove any dust that accumulates on the

camera lens, viewfinder, mirror, or focusing screen. Do not use cleaners that contain
organic solvents to wipe off the camera body or lens. If the camera is very soiled, consult
your nearest Canon dealer.

(7) Do not touch the camera’s electrical contacts with your hands. Doing so could corrode the

contacts and interfere with the camera’s normal operation.

(8) If you take the camera quickly from a cold location into a warm one, condensation can

form on the outside and inside of the camera. To prevent this, place the camera in an
airtight, resealable plastic bag until it warms up to the ambient temperature.

(9) Do not use the camera if condensation forms on it, or you could damage it. If this occurs,

remove the CF card and battery from the camera, and wait until the condensation has
evaporated before using the camera.

(10) If the camera will not be used for an extended period, remove its battery and store the

camera in a cool, dry, well-ventilated location. While the camera is in storage, operate its
shutter periodically to make sure that it is working.

(11) Avoid storing the camera in locations where potentially corrosive chemicals are used,

such as in a laboratory.

(12) If the camera has been in storage for an extended period, check its components before

using it. If you have not used the camera for some time or are planning to take shots you
will not want to lose (overseas vacation, etc.), have the camera checked by your Canon
dealer beforehand, or check for yourself that the camera components are working
properly.

LCD Panel and LCD Monitor

(1) LCD displays are manufactured using high-precision technology. Even so, very small

black, red, or green dots can occasionally appear on a display. This is within the normal

99.98% range for valid picture elements (pixels), and does not indicate a fault. Such
aberrations on the display also do not affect recorded images.

(2) Do not press hard on an LCD display or subject it to impacts, as this can cause display

flaws and damage.

10

Handling Precautions

(3) If an LCD display becomes soiled, clean it with a commercially available blower brush, or

wipe it with a soft cloth, taking care not to scratch the screen. If an LCD display becomes
extremely soiled, consult your nearest Canon dealer.

(4) By their nature, LCD displays react more slowly at low temperatures, and may appear

dark at high temperatures. The display will return to normal at room temperature.

Lithium Battery for the Date and Time

(1) Store lithium batteries out of reach of small children. The chemicals in these batteries are

very dangerous if the battery is accidentally swallowed. If this happens, seek medical
attention at once.

(2) Do not use metal instruments such as pliers to hold the battery, or you could cause a short

circuit.

(3) Do not disassemble or heat the battery, or you could rupture it.

CF Card

(1) The CF card is a precision device. Do not drop CF cards or expose them to vibrations.

Doing so could lose the images recorded on them.

(2) Do not store or use CF cards near objects that generate magnetic fields, such as TVs,

speakers, or magnets, or in locations affected by static electricity. Doing so could lose the
images recorded on the CF card.

(3) Do not place CF cards in direct sunlight or close to heating appliances. Doing so can

distort the cards and make them unusable.
(4) Do not spill liquids onto CF cards.
(5) Always store your CF cards in a case or cabinet to protect the data stored on them.
(6) Use only CF cards specified by Canon. Otherwise, you may be unable to record or play

back images.
(7) Do not bend CF cards, or subject them to strong impacts.
(8) Do not store CF cards in hot, dusty, or humid locations, or in locations exposed to static

electricity or magnetic fields.

Introduction

Lens Electrical Contacts

After detaching the lens from the camera, attach the lens caps or put
down the lens with the rear end up to avoid scratching the lens
surface and electrical contacts.

Contacts

11

Quick Guide

Reference page numbers are indicated by (→✽✽) .

Charge the battery pack.

Connect the power cord to the adapter,

1

then attach the battery. When the charge
lamp stops blinking and stays lit, the battery
is completely charged. A full battery charge
takes approximately 90 minutes. (→22)

Open the CF card slot
cover.

5

Slide the cover in the direction
shown by the arrow, then open it.
(→28)

Insert the battery pack.

Open the battery chamber cover

2

and slide the battery pack into
position until it locks into place.
Press the cover closed until it
clicks shut. ( →24)

Insert a CF card
(optional).

6

After inserting the CF card, close
the cover. (→28)

● Using CF cards made by Canon

is recommended.

Focus on the subject.

Look through the viewfinder and place the

9

AF point over the subject. Then press the
shutter button down halfway to focus. (→29)

● The AF point which achieves focus will flash in red.

●

In low-light conditions or backlit daylight
conditions, the built-in flash fires
automatically. (→86)

12

10

Take the shot.

Press the shutter button down
fully. (→29)

Quick Guide

Introduction

Mount the lens.

Align the red dots on the lens and

3

camera and turn the lens in the
direction shown by the arrow in the
diagram until it clicks into place. (→27)

Turn on the camera.

Turn the main switch to <ON>.

7

(→29)

Set the focus mode
switch on the lens to AF.

4

(→27)

Set the Mode Dial to < >
(Full Auto).

8

(→38)

11

Check the image.

The image is displayed for
approximately 2 seconds after
the shot. (→40)

● To check other images you have

taken, see “Check the Image
Immediately” (→40) and “Viewing
Recorded Images” (→98).

● To erase images you have taken,

see “Erasing a Recorded Image
(Single Image Erase)” (→43).

13

Nomenclature

〈DRIVE〉

Drive mode selection button

〈 〉 Metering mode selection/
Flash exposure compensation
button (→61, 91)

LCD panel (→16)

〈 〉 Main dial
(→30)

Shutter button
(→29)

Grip (Battery
chamber)

DC coupler cord
hole (→26)

Red-eye reduction/
Self-timer lamp (→89, 81)
AF-assist lamp (→39)

Mirror (→84, 115)

(→63)

AF

〈〉

AF mode selection/White balance

WB

selection button

Lens mount index (→27)

Built-in flash (→86)

Hot shoe (→92)

〈〉 Flash button (→86)

Mode dial (→18)

Lens release
button (→27)

Depth-of-field preview button

Lens lock pin

Electrical contacts (→11)

(→54, 66)

Strap mount

(→21)

(→73, 95)

Lens mount

DIGITAL terminal
(See software instructions.)

VIDEO OUT terminal (→112)

PC terminal (→96)

Remote control terminal

Reference page numbers are indicated by (→✽✽) .

14

Cover

Nomenclature

Eyecup (→82)
Viewfinder eyepiece

Main switch (→29)

〈MENU〉 Menu button
(→32)

〈INFO.〉 Info button
(→60, 100)

〈JUMP〉 Jump button
(→99)

〈 〉 Index/
Enlarge button
(→98, 99)

〈 〉 Playback
button (→40, 98)

LCD monitor (→32)
〈 〉 Erase button (→43, 104)
Tripod socket

Date/time battery compartment cover (→113)

〈 〉 Set button (→32)

〈 〉 Quick control dial (→31)

Dioptric adjustment knob (→36)

Quick control dial switch (→31)

〈 〉 AE lock /FE lock button

(→80, 90)

〈 〉 AF point

selection button (→57)

Access lamp

(→28)

Strap mount

(→21)

CF card slot

cover (→28)

Battery chamber cover

release lever (→24)

Battery chamber cover

(→24)

Introduction

CF Card Slot Cover

CF card slot
(accepts card type1and 2)
(→28)

CF card eject button (→28)

15

Nomenclature

LCD Panel

Shutter speed ( - , )
Data processing ( )
Date/time battery level warning ( )
Cleaning warning ( )
Parameters ( - )
ISO Speed ( - )

No CF card warning ( )
CF full warning ( )
CF error warning ( )
AF point ( )
Error cod ( - )
Cleaning ( )

Quality

Large/Fine
Large/Normal
Medium/Fine
Medium/Normal
Small/Fine
Small/Normal
RAW

White balance
mode

Auto
Daylight
Cloudy
Tungsten
Fluorescent
Flash
Custom

Aperture value ( - )

Drive mode

Single-frame
Continuous
Self-timer

Shots remaining ( - )
Self-timer countdown ( - )
Bulb exposure time ( - )
ISO speed ( )

AF mode
ONE SHOT AF
AI FOCUS AF
AI SERVO AF

Exposure level scale

Custom function

Beeper

Battery check

Red-eye reduction

Flash exposure compensation

Exposure level

Exposure compensation amount
AEB level
Flash exposure compensation amount

CF card writing status

Metering mode

Evaluative metering
Partial metering
Center-weighted average
metering

AEB

Manual focus

The above diagram shows the LCD panel with all icons and indicators displayed. In actual
use, the items displayed differ according to the camera settings.

16

Viewfinder Information

New laser matte screen

Nomenclature

AF points

(Superimposed display)

AE lock/FE lock
AEB in progress

Flash-ready indicator
FE lock underexposure warning

High-speed sync
(FP flash)

Flash exposure compensation

Partial metering circle

Focus confirmation light

Maximum burst count during
continuous
Shots remaining in CF card

( - )

Exposure level
Exposure compensation amount
AEB level
Flash exposure compensation amount
Red-eye reduction lamp-on indicator

shooting ( - )

Introduction

Shutter speed ( - , )
FE lock ( )
Data processing ( )

Aperture value ( - )

CF full warning ( )
CF error warning ( )
No CF card warning ( )

The above diagram shows the LCD panel with all icons and indicators displayed. In actual
use, the items displayed differ according to the camera settings.

17

Nomenclature

Mode Dial

The Mode Dial is divided into two functional zones.

C

r

e

a

t

i

v

e

z

o

o

z

e

g

a

m

I

a

B

n

e

Full Auto

e

n

e

n

o

z

c

i

s

11

1 Basic zone

11

● All you do is press the shutter button.

: Full Auto (→38)
Lets you take fully automatic
pictures—the camera makes all the
settings.

Image zone

Lets you take fully automatic pictures
in specific situations.

: Portrait (→44)

: Landscape (→45)

: Close-up (→46)

: Sports (→47)

: Night Portrait (→48)

Reference page numbers are indicated by (→✽✽) .

18

22

2 Creative zone

22

Lets you make a variety of settings.

: Program AE (→68)
: Shutter-priority AE
: Aperture-priority AE (→72)
: Manual exposure (→74)
: Automatic Depth-of-field AE

(→76)

(→70)

Compact Power Adapter
CA-PS400

Nomenclature

Power cord (→22, 26)

Power cord socket (→22, 26)

Plug in power cord here.

Back

Battery pack
connectors (→22)

Attach battery packs
for charging.

Charge lamp (→22)

DC coupler socket (→26)

Plug in cord for DC
coupler here.

Introduction

DC Coupler
DR-400

DC coupler plug (→26)

Plug into DC coupler socket of compact power adapter.

DC coupler cord (→26)

19

Conventions Used in This Manual

● The procedures in this booklet assume that the camera has been turned on. Before

proceeding, be sure that the main switch is set to <ON> .

● In this manual, the < > icon indicates the Main Dial.

● In this manual the < > icon indicates the Quick Control Dial.

● In this manual the < > icon indicates the SET button, used

to set menu functions and custom functions.

● The camera control icons and markings in this booklet correspond to the icons and

markings on the camera. See “Nomenclature” on page 14.

● Reference page numbers are indicated by (→✽✽) .

● The procedures in this instraction use a Canon EF 24-85mm f/3.5-4.5 USM lens for

reference.

● The descriptions also assume that the menu functions and custom functions are set to the

default settings.

● The icons (4), (6), and (16) indicate that the function operates on a timer, and remains

in effect after the button is released. The icons represent 4, 6, or 16 seconds respectively.

● In general, the pictures used for explaining procedures are taken with a single-lens reflex

camera using 35 mm film.

■ These Instructions use the following alert symbols:

: The Caution symbol indicates a warning to prevent shooting problems.
: The Note symbol gives supplemental information.
: The Light bulb symbol gives a helpful tip for operating your camera or taking

pictures.

: The Custom Function symbol indicates that there is a relevant Custom Function.

For details, see “Custom Functions” on page 122.

20

1

Before You Start

Before Y ou Start

This chapter describes preparations and settings you need to make
before you start shooting, as well as how the shutter button
operates.

Attaching the Strap

Pass the end of the strap through the
strap mount from beneath, then back in
and out of the strap clasp as shown. Pull
the strap to make sure it does not slip out
of the clasp.

● The eyepiece cover is attached to the

strap. (→82)

1

Eyepiece cover

21

Charging the Battery Pack

Connect the power cord.

● Connect the power cord to the compact

1

2

power adapter.

● Insert the plug into a power outlet.

Remove the cover.

● Store the cover in a place where it will not

be lost.

● If you remove the battery from the camera,

be sure to reattach the cover to protect
against short circuit.

Battery charge

0–50%

50–75%

Over 75%

Almost full

<–> mark

Charge lamp

Blinks once per
second

Blinks twice per
second

Blinks three times
per second

Stays on

Place the battery in the adapter.

● Align the end of the battery with the <–>

3

mark on the adapter, press down on the
battery, and slide it into place.

● To remove the battery, use the reverse of

the above.

● Batteries can be charged in either the left or

right side of the adapter.

Charge the battery pack.

➡ As soon as you place the battery pack in

4

the compact power adapter, the charge
lamp starts blinking and charging begins.

➡ When charging is complete, the lamp stops

blinking and stays on.

➡ It can take up to 90 minutes to fully

charge a battery pack.

● You can check whether a battery is charged

by seeing whether the charge lamp blinks
or stays on.

➡ When charging is complete, the charge

lamp stops blinking and stays on. You can
continue charging the battery for approxi­mately an hour to reach full charge
capacity.

● When charging is complete, remove the

battery and unplug the power cord from the
outlet.

22

Charging the Battery Pack

● When the DC coupler is connected to the compact power adapter, the

adapter cannot be used to charge battery packs.

● Do not charge any battery packs other than model BP-511.

● When the battery pack is in the camera, it discharges slightly all the time even

when the camera is not used. This reduces the battery pack’s life due to over
discharge. When not using the camera, remove the battery pack and store it
with its protective cover attached. Always be sure to charge the battery pack
before using it again.

● If the battery is completely exhausted, it may take 20 or 30 minutes for the

CHARGE lamp to blink when you recharge the battery.

● To protect battery packs and prevent loss of capacity, do not charge them

continuously for more than 24 hours.

● If operating time is sharply reduced even after charging normally, the battery

pack may have exceeded its useful life. Replace it with a new battery pack.

● The adapter can hold and charge two battery packs. Charging starts with the

first battery pack attached. After that battery pack is charged, the charge lamp
goes on and the adapter starts charging the second battery pack.
After charging of both battery packs is completed (both charge lamps are on),
leave both battery packs in the charger for two more hours (one hour per
battery pack) to reach a full charge.

● Charging time depends on the ambient temperature, and the level to which the

battery pack is already charged.

● When battery power is low, the < > icon on the LCD panel blinks. Remove

the battery pack from the camera and charge it.

● The battery pack can operate in temperatures from 0°C to 40°C (32°F to

104°F), however for full operating performance, use between 10°C (50°F) and
30°C (86°F) is recommended. In cold locations such as ski areas, battery
performance is temporarily decreased and operating time may be reduced.

1

Before You Start

23

Inserting and Removing the Battery Pack

Inserting the Battery Pack

Load a fully charged BP-511 battery pack into the camera.

Open the battery chamber cover.

● Slide the lever in the direction shown by the

1

2

3

arrow in the diagram, and open the cover
as shown.

Insert the battery into the camera.

● Make sure the battery pack is facing the

right way, and insert it into the battery
chamber.

● Insert the battery pack until it locks into

place.

Close the cover.

● Press the cover closed until it clicks shut.

Battery Pack BP-512 cannot be used with this camera.

Battery Level Icons

The level of charge remaining is shown in three stages when the Main Switch is set to <ON>.
(→29)

: Charge is sufficient.
: Charge is low.
: Battery pack must be charged.

If the level of charge remaining runs out when you are using the menu screen or
playing back an image, a no battery warning appears on the LCD monitor. When
this occurs, remove the battery and charge it.

24

Inserting and Removing the Battery Pack

Battery Life

Temperature

Normal (20°C/68°F) Approx. 620 Approx. 490
Low (0°C/32°F) Approx. 480 Approx. 400

● The above figures were obtained under Canon test conditions (fully charged battery, EF

50mm f/1.4 USM lens, Review function [On], Review Time [2 sec.], Quality [Large ]).

● The number of shots may be less than indicated in some cases, due to

differences in operating conditions.

● The number of shots is reduced by frequent use of the LCD monitor.

● Holding the shutter button halfway down for long periods to use the AF function

without taking a shot can reduce the number of shots.

● In low temperature conditions (0°C/32°F), the number of shots may be less than

indicated.

● Regarding the battery life (number of shots) with Battery Grip BG-ED3

(optional), refer to the BG-ED3’s instructions.

Shooting conditions

No flash use 50% flash use

Removing the Battery Pack

Open the battery cover.

● Slide the lever in the direction shown by the

1

arrow in the diagram, and open the cover
as shown.

1

Before You Start

Remove the battery pack.

● Slide the battery lock lever in the direction

2

3

shown by the arrow, and remove the
battery.

Close the battery cover.

● Press the cover closed until it clicks shut.

25

Inserting and Removing the Battery Pack

Using a Household Power Supply

You can operate the EOS D60 from a household power outlet by using the DC coupler. This
enables you to use the camera as long as you like without a battery.

Connect the DC coupler.

● Plug the DC coupler into the compact

1

2

3

power adapter.

Place the cord in the groove.

● Carefully insert the cord into the groove.

Insert the DC coupler into the
camera.

● Open the cover (→24) and lower the

covering on the cord hole.

● Insert the DC coupler and fit the cord into

the cord hole.

● Check that the cord is placed tightly in the

cord hole, and slide the DC coupler into the
chamber until it locks into place.

● Close the cover so that it clicks into place.

26

Connect the power cord.

● Connect the power cord to the compact

4

● Do not use any DC coupler other than the one provided with your EOS D30 or

D60 camera.

● The DC Coupler cannot be used with cameras other than the EOS D30 and

D60.

power adapter.

● Plug the cord into a power outlet.

● When you are finished, remove the plug

from the power outlet.

Mounting and Detaching a Lens

Mounting a Lens

Remove the caps.

● Remove the rear lens cap and the body cap

1

2

Lens mount index

3

by turning them as shown by the arrows in
the diagram.

Attach the lens.

● Align the red dots on the lens and camera

and turn the lens as shown by the arrow
until it clicks in place.

Set the focus mode switch on the
lens to <AF>.

● If the focus mode switch is set to <MF> (or

<M> on older lenses), the autofocus will not
operate and < > will be displayed on the
LCD panel.

Remove the front lens cap.

4

1

Before You Start

Detaching a Lens

● Since the EOS D60’s picture coverage is smaller

than the normal 35mm film format (see illustration),
the EF lens attached to the camera will have a
telephoto effect equivalent to 1.6 times the lens
focal length.

● AF stands for autofocus.

● MF or M stands for manual focus.

● Be careful not to lose the lens caps or body cap.

Press and hold the lens release
button, and turn the lens as
shown by the arrow.

● Turn the lens until the index mark is at the

top, then remove it.

EOS D60 image field
(22.7 x 15.1 mm / 0.89 x 0.59 in)

35 mm image field
(36 x 24 mm / 1.42 x 0.94 in)

27

Installing a CF Card

The captured images are saved on a CF card (optional).
The camera is compatible with Type I and Type II CompactFlash (CF) cards.

Open the cover.

● Slide the cover in the direction shown by

1

2

mark

Eject button Label side

3

the arrow, and open it as shown in the
diagram.

Insert the CF card.

● Using CF cards made by Canon is recom-

mended.

● With the CF card label side (the side with

the printed mark) facing toward the rear of
the camera, slide the card in the direction of
the mark, into the slot.

➡ The Eject button pops out.

Close the cover.

● Close the cover and slide it in the direction

shown by the arrow until it clicks shut.

Removing a CF Card

● While the access lamp is blinking, never do the following:

• Shake or hit the camera. • Open the CF card slot cover.

• Open the battery compartment cover.
Doing so may destroy the image data or even damage the camera.

●

While the image data is being written to the CF card (access lamp blinks, →15), the on-screen
menu will not be displayed and recorded images cannot be played back. Pressing the <MENU>
button or < > button will only display the “Busy” message (→135) on the LCD monitor.

● If a CF card is being used for the first time and “ ” is displayed on the

LCD panel, see “Formatting the CF Card” (→105) to initialize the card.

28

Open the cover.

● Set the Main Switch to <OFF>.

1

● Check that the “ ” message is not

shown on the LCD panel.

● Make sure the access lamp is off (→15),

and open the cover.

Remove the CF card.

● Press the Eject button.

2

➡ The CF card is ejected.

● Close the cover.

Basic Operation

Main Switch

The camera operates only after the Main Switch is set to <ON>.

<ON>:Set to this position when the camera is in use.
<OFF>: The camera does not operate.

Set to this position when not using the camera.

● To save battery power, the camera automatically turns off if you do not operate it

for approximately one minute (Auto power off function). To use the camera
again, press the shutter button down halfway, or set the Main Switch to <OFF>
and then set it to <ON> again. You can use the Menu functions to set the Auto
power off function to [1], [2], [4], [8], [15], or [30] minutes, or [Off]. (→120)

● If you set the Main Switch to <OFF> immediately after you take a picture, the

access lamp may blink for a few seconds so that the image is recorded onto the
CF card.
The access lamp will go off when the image has been recorded onto the CF
card and the camera will turn off automatically.

Shutter Button

The shutter button has two stages. You can press it down halfway or fully. The two levels of
shutter button operation are as follows:

1

Before You Start

(1) Halfway pressing (4)

Pressing the shutter button down halfway activates
autofocusing (AF), and also activates the automatic exposure
mechanism and sets the shutter speed and aperture value.
The exposure (the combination of shutter speed and aperture
value) appears on the LCD panel and in the viewfinder.

(2) Full pressing

This releases the shutter and takes the picture.

● This camera has been designed so that taking pictures is given priority over

other operations. Unless the internal memory is full, you will always be able to
take pictures immediately by pressing the shutter button down.

● Regardless of the camera status (playback, menu selection or image recording

in progress, etc.), you can return to shooting mode immediately by pressing the
shutter button down halfway.

29

Basic Operation

Using the Electronic Dials

Basic Operations with the < > Dial

The < > dial is used to make settings only when taking
pictures. It can be used in two ways.

(1) Press a button and turn the < > dial.

When you press a button, its function remains active while a timer (6) runs. During this
time you can turn the < > dial and view the settings on the LCD panel. When the timer
runs out or you press the shutter button down halfway, the camera is ready to take a
picture.

2 Turn the < > dial

Use the dial this way to set the AF mode, AF point, metering mode or drive mode.

(2) Just turn the < > dial.

Use the dial this way to set the shutter speed and aperture value.

30

1 After a button is pressed

Turn the < > dial while watching the LCD panel.

Basic Operation

Basic Operations with the < > dial

You can only use the < > dial when the Quick Control Dial
switch is set to <ON>. Use the dial for shooting preparation
and selection of functions from the LCD monitor.
When using the < > dial to carry out basic operations, you
can use it in two ways.

(1) Press a button and turn the < > dial.

When you press a button, its function remains active
while a timer (6) runs. During this time you can
turn the < > dial and view settings on the LCD
panel.
The timer function and return to shooting mode are
the same as for the < > dial.

Use the dial this way to select and set the white balance, drive mode and flash
exposure compensation.

(2) Just turn the < > dial.

When you are taking pictures, turn the < > dial
while watching the viewfinder display or LCD panel.
When you are making selections and settings from
the LCD monitor, turn the dial while watching the
LCD monitor.

● When you are taking pictures, use the dial to set the exposure compensation

and manual aperture value.

● When using the LCD monitor, use the dial to review and select the recorded

image and select menu functions.

LCD Monitor

You can use the LCD monitor on the back of the
camera to review and select images, as well as
select and set menu functions.

1

Before You Start

You cannot use the LCD monitor as a viewfinder while taking pictures.

You can use the < > dial when you are using the LCD monitor, regardless of
whether the Quick Control Dial Switch is set to <OFF>.

31

Basic Operation

Menu Functions and Settings

The Canon EOS D60 uses menu functions to set functions such as the quality, the date and
time, and Custom Function settings. To use the menu functions, look at the LCD monitor and
use the <

MENU

> button, < > dial and < > button as shown below.

<

MENU

> button

LCD monitor

1. Display the menu.

Press the <
again to clear the screen.

2. Select the menu item.

Turn the < > dial to select the desired item.

MENU

> button to display the menu. Press the button

move the frame up

move the frame down

< > dial

< > button

32

3. Display the options for the item and make your selection.

Press the < > button to display the options list, then turn the
< > dial to select the desired option.

4. Make the setting.

Press the < > button.

5. Exit the menu.

Press the <

● When the menu is displayed, you can take pictures immediately by pressing the

shutter button down.

● You can finish making a setting by pressing the shutter button down halfway.

● You can cycle through menu items and options lists.

● You can select the display language from three other languages besides

English. (→121)

● If you press the <

move to the top item in the shooting, playback and setup sub-menus in that
order, each time you press this button.

JUMP

MENU

> button to exit the menu.

> button while the menu screen is displayed, you can

Basic Operation

Menu Selections and Default Settings

On the Menu screen, items and settings are shown in different colors according to the
functions they control. Selected items are enclosed in a color frame.

Menu item Setting indicated by color frame

Color

Setting type

Red
Blue

Yellow

Shooting
Playback

Setup

Menu items related to taking pictures.
Menu items related to playing back

recorded images.
Menu items related to basic camera

functions.

Options list

Menu item Settings and Description

Quality Large Large Medium Medium 50

Small Small RAW

Red-eye on/off

Shooting (Red)

AEB

∗1

∗2

Off On 89

ISO speed 100 200 400 51

800 1000
LCD illumination Off On 67
Beep On Off 118
Custom WB
Parameters

Playback (Blue)

Protect Protects the image from erasure. 103

∗1

∗1

Set custom white balance 66

Standard Set 1 Set 2 52

Set 3 Set up

Rotate Rotate recorded image 102
Print Order Order print of recorded image 106
Auto playback Plays the images automatically. 101
Auto power off 1 min. 2 min. 4 min. 120

8 min. 15 min. 30 min.

Off
Review Off On On (Info) 41
Review time 2 sec. 4 sec. 42

Setup (Yellow)

8 sec. Hold
LCD Brightness Normal Bright 120
Date/Time mm/dd/yy dd/mm/yy yy/mm/dd 34
File numbering Continuous Auto reset 114
Language English Deutsch 121

Français Japanese
Video system NTSC PAL 121
Format Format CF card 105

∗1

C. Fn
C. Fn default setting

Custom Function settings 122

∗1

Resets all Custom Functions to the default settings. 121
Firmware Ver. Camera’s firmware version. 121

∗1: Does not appear in the menu when the Basic zone (→18) is selected.
∗2: Does not appear in the menu in < > and < > modes.

Description

: Default setting

1

Before You Start

Ref. page

78

33

Setting the Date and Time

Set the date and time as shown below. The date and time are recorded with the image data for
each photographed image.

From the Menu, select [Date/
Time].

1

● Press the <

● Turn the < > dial to select [Date/Time].

Press the < > button.

➡ The Date/Time setting screen appears.

2

Set the date and time.

● Turn the < > dial to adjust the date or

3

time values, then press the < > button.

● After entering the setting, go to the next

item.

MENU

> button.

34

Select the order for the display.

● Use the < > dial to select the order, then

4

press the < > button.

● Turn the < > dial to cycle through the

selections in the order shown.

yy/mm/dd

mm/dd/yy

dd/mm/yy

Setting the Date and Time

Press the < > button.

➡ The date and time are set, and the display

5

returns to the menu.

● Press the <

screen and exit the menu.

MENU

> button to clear the

1

Before You Start

● Each photographed image is recorded with the date and time it was taken. If the

date and time are not set, they cannot be recorded correctly. Make sure you set
the date and time correctly.

● The date and time setting is maintained by the date/time battery.

35

Dioptric Adjustment in the Viewfinder

Use the dioptric adjustment in the viewfinder to best suit your eyesight. This adjustment can
enable eyeglass wearers to see through the viewfinder clearly, even without their eyeglasses.
The camera’s adjustable dioptric range is –3 to +1 dpt.

Turn the Dioptric Adjustment
Knob

● Turn the knob right or left until the AF point

or the center spot metering circle appears
sharply defined in the viewfinder.

● The diagram shows the knob set at the

standard diopter (–1 dpt).

If the viewfinder image still does not look sharp after adjusting the diopter
adjustment knob, try one of the E-series dioptric adjustment lenses (optional).
(→138)

Holding the Camera

To get sharp pictures, hold the camera as still as possible.

Horizontal shooting Vertical shooting

● Grasp the camera grip firmly with your right hand, and hold your elbows lightly against your

body.

● Hold the lens at the bottom with your left hand.

● Hold the camera to your face and look through the viewfinder.

● To maintain a stable stance, place one foot slightly in front of the other.

36

Basic zone

Simple Picture

Taking

This chapter describes how to use the camera’s
Basic Zone modes<

> for quick and easy shooting. In these modes,

<
all you do is point and shoot.
In addition, to help prevent mistakes caused by
operating the camera improperly, the <
the <
operate so there is no need to worry about acciden­tal errors.

AF

>, <

>, < >, and < > buttons do not

WB

Shutter button

>, < >, < >, < >, < >,

2

Simple Picture Taking

2

> dial, and

37

Fully Automatic Picture Taking

You can easily and confidently take pictures of any subject, with no need to do anything but
press the shutter button. The Canon EOS D60 can capture subjects at any of three AF points,
so that anybody can take great pictures easily.

Set the Mode Dial to < >.

➡ The AF mode is automatically set to <AI

1

2

AF point

3

FOCUS> (→56), the metering mode is set
to < > and the drive mode to < >
(Single-frame).

Place one of the AF points on the
subject.

●

The camera determines the subject position
and uses the most appropriate AF point.

● To focus on a subject that is not at any of

the three AF points, see “Focusing On an
Off-Center Subject” (→58).

Set the focus.

● Press the shutter button down halfway to

set the focus.

➡ The AF point achieving focus will flash in

red and the beeper will sound. The focus
confirmation light <●> at the lower right will
also light.

38

Check the display.

➡

4

5

The camera determines the shutter speed and
aperture value automatically, and displays
them in the viewfinder and on the LCD panel.

●

A number to displayed on the left of the
focus confirmation light <●> indicates the
maximum number of shots that can be taken
in a single burst of continuous shooting.

If a number
the number of remaining shots that can be
stored in the almost-full CF card.

Take the picture.

● Compose the shot and press the shutter

button down fully.

➡ The image is shown for approximately 2

seconds on the LCD monitor.

to

is displayed, it indicates

Fully Automatic Picture Taking

● If the CF card becomes full, the CF Full message “ ” appears on the

LCD panel and in the viewfinder, and the camera will not take any more
pictures. Replace the CF card with another CF card that has capacity available.

● When the in-focus indicator <●> is blinking, the camera will not take pictures.

(→59, 137)

● The focus and exposure are locked when AF focusing is complete.

● The camera automatically focuses on the AF point that is on the subject closest

to the camera.

● The image quality can also be set. (→50, 118)

● You can set the beep that indicates the subject is in focus or the beep that

indicates the self-timer is operating to [On] or [Off]. (→33, 118)

● If the number of remaining shots to in the CF card is displayed, changing

the image quality will also change this remaining number of shots.

● The LCD panel can be illuminated. (→67, 118)

Automatic Built-in Flash

In the Basic Zone (other than < > and < >), the flash pops up automatically and fires in
low-light conditions or backlit daylight conditions. Press the flash back down when you are
finished using it.

If anything blocks the flash so that it cannot pop up automatically, the error code
“ ” (→135) appears on the LCD panel. When this occurs, set the Main
Switch to <OFF> and then set it to <ON> again.

2

Simple Picture Taking

● To take pictures in an area where flash photography is prohibited or using indoor

lighting, the < > (Program) (→68) mode setting is recommended.

● When taking flash pictures of people at night or in dark interiors, we recommend

using “Red-eye Reduction” (→89).

AF-Assist Beam

● The built-in AF-assist beam’s maximum range is 3.8 meters /12.5 ft.

● When an EX-series external Canon Speedlite (optional) is used, the AF-assist

beam will be emitted either by the camera or external Speedlite depending on the
shooting conditions.

● In the < > and < > modes, the AF-assist lamp will not light.

● In dark locations, pressing the shutter button

down halfway causes the AF-assist beam
emitter to light. The AF-assist beam helps the
AF function.

39

Check the Image Immediately

You can view the images you take immediately, on the LCD monitor on the back of the camera.

Take the picture.

➡ After the picture is taken, the image as it

1

● You can turn the Review function on or off, as well as display the image

information display. (→41)

● You can change the length of time the image is displayed. (→42)

● You can change the brightness of the LCD monitor. (→120)

● While a picture is being displayed, you can press the < > button to delete that

image. (→43) This will erase the image shown on the LCD monitor before it is
written to the CF card.

Check the Image in PLAY Mode

1

was shot appears on the LCD monitor.
During continuous shooting, the last
captured image will be displayed.

● The image is shown for approximately 2

seconds.

View the image.

● Press the < > button.
➡ The most recently recorded image appears.

● Press the < > button again to remove the

image from the LCD monitor and exit PLAY
mode.

40

Change the displayed image.

● Turn the < > dial counterclockwise to

2

While the image data is being written to the CF card (access lamp blinks, →15),
the on-screen menu will not be displayed and recorded images cannot be played
back. Pressing the <MENU> button or < > button will only display the “Busy”
message (→135) on the LCD monitor.

You can also view the images you have taken in index form (→98) or enlarged form
(→99).

move back through the images you have
taken, from newest to oldest.

● Turn the < > dial clockwise to move

through the images from oldest to newest.

Check the Image Immediately

Checking the Image After it is Taken

You can set the camera to display each image on the LCD monitor as soon as it is taken. You
can do this two ways: Select [On] to display the image by itself, or select [On (Info)] (→100) to
display the image with its recording information. Select [Off] if you do not want to display the
image. The default setting is [On].

From the Menu, select [Review].

● Press the <

1

● Turn the < > dial to select [Review], then

press the < > button.

Select the Review setting.

● Turn the < > dial to select the desired

2

option, then press the < > button.

➡ The setting is entered, and the display

returns to the menu.

● Press the <

screen and exit the menu.

Take the picture.

➡ After the picture is taken, the image as it

3

was shot appears on the LCD monitor.

● The time that image is displayed depends

on the review time setting. (→42)

● The display differs depending on whether

you selected [On] or [On (Info)].

MENU

> button.

MENU

> button to clear the

2

Simple Picture Taking

[On] selected [On (Info)] selected (→100)

You can change the review time setting. (→42)

Histogram
(→100)

information
(→100)

Date/time
(→34)

41

Check the Image Immediately

Time for Image Review

You can control how long images are displayed by setting the review time to [2 sec.], [4 sec.],
[8 sec.], or [Hold] which keeps the image on the monitor screen. The default setting is [2 sec.].

From the Menu, select [Review
time].

1

● Press the <

● Turn the < > dial to select [Review time],

then press the < > button.

Set the review time.

● Turn the < > dial to select the review time

2

you want, then press the < > button.

➡ The setting is entered, and the display

returns to the menu.

● Press the <

screen and exit the menu.

MENU

> button.

MENU

> button to clear the

42

● When this function is set to [Hold], the image is displayed until you press the

shutter button down halfway. Note however that the camera power will turn off
automatically when the Auto power off time setting is reached (→29, 120).

● The [Review time] setting is valid when the [Review] feature is set to [On] or [On

(Info)].

Erasing a Recorded Image (Single Image Erase)

Set the camera to Play mode.

● Press the < > button to enter Play mode.

1

➡ The most recent image appears.

Select the image you want to
erase.

2

● Turn the < > dial to select the image you

want to erase.

Open the Erase menu.

● Press the < > button.

3

➡ The Erase menu appears at the bottom of

the LCD monitor.

Erase the image.

● Turn the < > dial to select [Erase], then

4

press the < > button.

➡ The access lamp blinks and the image is

erased.

2

Simple Picture Taking

You cannot recover an image once you have erased it. Make sure you no longer
want an image before erasing it.

● You can protect images (→103) to prevent them from being erased accidentally.

● To erase all images recorded on the CF card, see “Erasing Images (All Image

Erase) ” (→104).

43

Portrait Mode

This mode blurs the background to make the
subject stand out.

Set the Mode Dial to < >.

● The way you take pictures is the same as in

➡ The AF mode is automatically set to <ONE

< > (Full Auto) mode. (→38)

SHOT>, the drive mode to < >, and the
metering mode to < >.

44

The image quality can also be set. (→50, 118)

● Head-and-shoulder shots give the best background blur effect. Also, the farther

the subject is from the background, the more blurred the background will
appear.

● Use a telephoto lens to blur the background even more. If you use a zoom lens,

its longest focal length is the most effective (for example, a 24-85mm lens set to
85 mm).

Landscape Mode

This mode is for sweeping scenery, sunsets, etc.

Set the Mode Dial to < >.

● The way you take pictures is the same as in

< > (Full Auto) mode. (→38)

➡ The AF mode is automatically set to <ONE

SHOT>, the drive mode to < > (Single-frame),
and the metering mode to < >.

2

Simple Picture Taking

If the shutter speed indicator blinks, the shutter speed may be too slow to keep the
picture from being blurred by camera shake. We recommend you use a tripod
when taking landscape pictures. (The shutter speed indicator still blinks if you use
a tripod, but camera shake will not be a problem.)

● The built-in flash does not fire in Landscape mode, even if it is raised.

● The image quality can also be set. (→50, 118)

A wide-angle lens provides the greatest depth from foreground to background, as
well as a wider image. If you use a zoom lens, its shortest focal length is the most
effective (for example, a 24-85mm lens set to 24 mm).

45

Close-Up Mode

This mode is for taking close-up shots of flowers,
insects, or other small subjects.

Set the Mode Dial to < >.

● The way you take pictures is the same as in

< > (Full Auto) mode. (→38)

➡ The AF mode is automatically set to <ONE

SHOT>, the drive mode to < > (Single-frame),
and the metering mode to < >.

46

The image quality can also be set. (→50, 118)

● Close-up mode is most effective when the subject is at the minimum focusing

distance of the lens.

● If you use a zoom lens, use its longest focal length to get a higher magnifica-

tion.

● For serious macro photography, using EOS-dedicated macro lenses and Macro

Ring Lite MR-14EX or Macro Twin Lite MT-24EX is recommended.

Sports Mode

This mode is used for sports photography and
capturing fast-moving subjects.

Set the Mode Dial to < >.

● The way you take pictures is the same as in

➡ The AF mode is automatically set to <AI

< > (Full Auto) mode. (→38)

SERVO>, the drive mode to < >, and the
metering mode to < >.

2

Simple Picture Taking

If the shutter speed indicator blinks, the shutter speed may be too slow to keep the
picture from being blurred by camera shake. Be careful to hold the camera steady
and press the shutter button smoothly, or use a tripod. (The shutter speed
indicator still blinks if you use a tripod, but camera shake will not be a problem.)

● The built-in flash does not fire in Sports mode, even if it is raised.

● The image quality can also be set. (→50, 118)

● For best results in Sports mode, use an ISO speed setting of ISO 400 or faster.

(→51, 118)

● For sports photography we recommend using a telephoto lens of 200-300 mm.

47

Night Portrait Mode

This mode is for taking pictures of people at sunset
or at night. It uses flash to illuminate the subject and
a slow shutter speed to expose the background,
resulting in a natural-looking exposure.

Set the Mode Dial to < >.

● The way you take pictures is the same as in

< > (Full Auto) mode. (→38)

➡ The AF mode is automatically set to <ONE

SHOT>, the drive mode to < > (Single-frame),
and the metering mode to < >.

48

To prevent camera shake, always use a tripod.

● If you are taking images of scenery only (and not people), use Landscape < >

mode.

● Tell your subjects not to move for a few seconds after the flash fires.

● You can also use Night Portrait < > mode with an EX-series Speedlite.

● In daylight, Night Portrait < > mode operates the same as < > (Full Auto)

mode.

● The image quality can also be set. (→50, 118)

For best results in Night Portrait mode, use an ISO speed setting of ISO 400 or
faster. (→51, 118)

Advanced

Creative zone

Operations

The Creative zone features shooting modes that let
you select the shutter speed or aperture value and
change the exposure yourself, providing you with
more flexibility to set up the camera for a variety of
shooting styles. This chapter describes how to make
effective use of each of these functions.

● The < > icon represents the Main Dial, and the < > icon

represents the Quick Control Dial.

● Press the shutter button down halfway and release, and a

timer will show the exposure setting for approximately 4
seconds on the LCD panel and viewfinder.

● You can set the AF mode, AF point, metering mode, drive

mode, and white balance only in the Creative Zone modes.

● You can use AE lock, exposure compensation, AEB, bulb

exposures, and depth-of-field preview only in the Creative
Zone modes.

● The AEB setting, M-WB image selection, processing

parameters, C.Fn settings and C.Fn cancel settings will be
displayed only in the Creative Zone modes.

3

3

Advanced Operations

49

Quality Selection

Use the Menu function to choose from seven Quality settings:

Quality

Large/Fine
Large/Normal
Medium/Fine
Medium/Normal
Small/Fine
Small/Normal
RAW

● You can set the image quality also for the Basic Zone modes.

● The CF card's maximum capacity is based on Canon's testing standards (at ISO 100).

● The maximum capacity applies to a 128 MB CF card.

●

The image file size and the CF card's maximum capacity depend on the subject and ISO speed.

● The CF card's number of remaining shots is displayed on the LCD panel.

Icon

Recording

size

3072 × 2048

2048 × 1360

1536 × 1024
3072 × 2048

Recording

method

JPEG

RAW

1

2

Compression

ratio

Low

High

Low

High

Low

High

–

Size of one


2.5 Mbyte

1.3 Mbyte

1.4 Mbyte

0.7 Mbyte

0.9 Mbyte

0.5 Mbyte

7.4 Mbyte

Recording

capacity

Approx. 48 shots
Approx. 92 shots

Approx. 89 shots
Approx. 172 shots
Approx. 138 shots
Approx. 255 shots

Approx. 15 shots

From the menu, select [Quality].

● Press the <

● Turn the < > dial to select [Quality], then

press the < > button.

MENU

> button.

Set the quality.

● Turn the < > dial to select the Quality you

want, then press the < > button.

➡ The selected Quality setting is entered, and

the screen returns to the menu.

● Press the <

screen and exit the menu.

MENU

> button to clear the

50

To open RAW images with a personal computer, you must use the dedicated
driver software. For details, see the bundled software's instructions.

You can also use the bundled software to create a Medium/Fine JPEG file from the
RAW image. For details, see the software's instructions.

You can set the Quality by pressing the < > button and turning the < > or
< > dial as you look at the LCD panel. (C.Fn-12-1→126)

ISO Speed

ISO speed is an index number representing the photosensitivity of silver-halide film. Digital
cameras do not use film, but their photosensitivity is commonly described in terms of “ISO
equivalent” speed settings. (→130)
The higher the number, the greater the sensitivity. Higher speeds are better for taking pictures
of moving subjects or in dim light, but the pictures will also contain more noise and so will be
less sharp. Conversely, lower speeds are less suited to moving subjects or dim conditions, but
produce sharper, more detailed images.
The Canon EOS D60 provides ISO-equivalent speed settings from ISO 100 to ISO 1000, in
full-stop increments. The default setting is ISO 100.

Select [ISO speed].

● Press the <

1

● Turn the < > dial to select [ISO Speed],

then press the < > button.

Set the ISO speed.

● Turn the < > dial to select the desired

2

ISO speed, then press the < > button.

➡ The selected ISO speed is entered, and the

screen returns to the Menu.

● Press the <

screen and exit the Menu.

MENU

> button.

MENU

> button to clear the

3

Advanced Operations

● The higher the ISO speed, the more noise the image will contain and the larger

the image file size will be. Therefore, setting a higher ISO speed will reduce the
number of images that the CF card can store. On the LCD panel, you can check
the number of images the CF card can hold. (→16)

● Taking pictures under a high temperature, at a high ISO speed, or with a long

exposure may cause irregular colors in the image.

You can set the ISO speed by pressing the < > button and turning the < > or
< > dial as you look at the LCD panel. (C.Fn-12-2 →126)

51

Setting Processing Parameters

Contents of processing for the captured image (parameters: [contrast], [sharpness],[saturation]
and [color tone]) can be set with the camera, and you can set and register up to three sets of
parameters. Defaut setting is “standard” (0 for all parameters).

Parameter

Contrast

Sharpness

Saturation

Color tone

Setting

Adjusts the
contrast

Adjusts the
sharpness

Adjusts the
color saturation

Adjusts the color
balance

Level

– (Low)
0 (Standard)
+ (High)
– (Low)
0 (Standard)
+ (High)
– (Low)
0 (Standard)
+ (High)
– (Red)
0 (Standard)
+ (Yellow)

1

2

Effect

Takes pictures with lower contrast.
Takes pictures with normal contrast.
Takes pictures with higher contrast.
Takes pictures with lower sharpness.
Takes pictures with normal sharpness.
Takes pictures with higher sharpness.
Takes pictures with muted colors.
Takes pictures with normal color saturation.
Takes pictures with intense colors.
Makes skin tones look more reddish.
A standard color balance is applied.
Makes skin tones look more yellowish.

From the menu, select [Param­eters].

● Press the <

● Turn the < > dial to select [Parameters],

then press the < > button.

MENU

> button.

Select [Set].

● Turn the < > dial to select [Set up], then

press < >.

● By default, Sets 1 to 3 have all the param-

eters set to 0 (Standard).

52

Select the desired set number.

● Turn the < > dial and select Set [1], Set

3

[2], or Set [3]. Then press < >.

Setting Processing Parameters

Select the parameter to be set.

● Turn the < > dial to select the parameter,

4

5

then press < >.

● The parameter selection will change in the

following loop:

[Contrast]

[Sharpness]

[Saturation]

[Color tone]

Set the desired parameter setting.

● Turn the < > dial and select [–], [0], or [+].

Then press < > .

3

Advanced Operations

Go back to step 1.

● Press the <MENU> button twice to return to

6

7

You can set the processing parameter by pressing < > and turning the < > or
< > dial while looking at the LCD panel. (C.Fn-12-3→126)

step 1, then press < >.

Select the desired set number.

● Turn the < > dial and select [Set 1], [Set

2], or [Set 3]. Then press < >.

53

AF Mode Selection

The AF mode setting controls how the autofocus functions operate. The camera has two AF
modes: One-shot AF for still subjects, and AI Servo AF for moving subjects.
AF mode selection is available in all Creative zone settings except for < >.

Set the lens focus mode switch to
<AF>.

1

Set the Mode Dial to a Creative
zone setting other than < >.

2

Press the <

AF

> button. (6)

WB

3

Select the AF mode.

● Turn the < > dial to make the selection.

4

● Press the shutter button down halfway to

return to ready-to-shoot status.

● In addition to the above two AF modes, the EOS D60 provides AI Focus AF,

which automatically switches between One-shot and AI Servo AF modes
according to the state of the subject. AI Focus AF is automatically selected
when operating in < > (Full Auto) mode.

● Turn the < > dial to select the white balance (→64).

54

One-Shot AF for Still Subjects

Press the shutter button down
halfway to activate AF operation
and focus once.

➡ The AF point achieving focus will flash in

red and the beeper will sound. The focus
confirmation light <●> at the lower right will
also light.

● When using evaluative metering, the

exposure setting is determined when focus
is achieved. The exposure setting and focus
remain locked as long as the shutter button
is pressed down halfway. You can then
recompose the shot while retaining the
exposure setting and focus (→58).

AF Mode Selection

Superimposed display

3

Advanced Operations

Focus confirmation light

If the camera cannot focus, the focus confirmation light (●) in the viewfinder
blinks. If this happens, you will not be able to take a picture even if you press the
shutter button down fully. Instead, reframe the shot and focus again. See also,
“Manual Focus” (→59).

You can disable the AF point’s red flashing (superimposed display).
(C.Fn-14-1→126)

55

AF Mode Selection

AI Servo AF for Moving Subjects

Press and hold the shutter button
down halfway, and the camera
focuses continuously.

● This mode is suited for moving subjects

when the focusing distance keeps chang­ing.

● With its predictive AF function, the camera

can also track a subject that is steadily
approaching or retreating from the camera.

● The exposure settings are determined

immediately before the picture is taken.

● The focus confirmation light <●> will not light and the beeper will not sound

when focus is achieved.

● When focus is not achieved, the focus confirmation light <●> will blink.

● Focus lock (→58) cannot be used.

You can set the camera so that during AI Servo AF operation, you can press the
< > button and the focus will momentarily lock as long as the button is held
down. (C.Fn-2-2→122)

Predictive AF

When a subject is approaching or retreating from the camera at a constant rate, the focusing
function can track the subject and predict the focusing distance immediately before the picture
is taken so that the shot will be in focus at the moment of exposure.

● When the AF point is selected automatically, the camera uses one of three AF points to

focus on the subject. Tracking and predictive focusing is carried out using the camera
selected AF point.

● When the AF point is selected manually (→57), the selected AF point tracks the subject.

AI Focus AF

AI Focus AF is set automatically in < > (Full Auto) mode. At the time of the shot, the camera
automatically selects One-shot AF or AI Servo AF according to the state of the subject.
If the subject is focused in One-shot AF and the subject then begins to move continuously, the
camera detects the movement, automatically switches to AI Servo AF, and focuses continu­ously as it tracks the subject.

56

AF Point Selection

The AF point can be selected automatically or manually. In the Basic Zone modes and < >
mode, AF point selection will be automatic. In the < >, < >, < >, and < > modes, AF
point selection can be set to either automatic or manual.

Automatic selection : The camera selects the AF point automatically according to conditions.
Manual selection : You can select any of the three AF points manually. This is best when

you want to be sure to focus on a particular subject, or to use the speed
of the AF focusing function to help you compose a particular shot
quickly.

Press the < > button. (6)

1

Select the AF point.

➡ Look at the LCD panel or the viewfinder

2

display as you turn the < > or < > dial.

● Press the shutter button halfway to ready

the camera for shooting.

LCD panel

3

Advanced Operations

Viewfinder

Automatic AF point

selection

Automatic

AF point selection

Manual AF point

selection

●

Automatic selection

●

Manual selection: The desired AF point

Manual

AF point selection

: All the AF points will light

in red.

lights in red.

57

Focusing On an Off-Center Subject

To focus on a subject not covered by one of the three AF points, follow the procedure below.
This technique is called Focus Lock.
Focus lock is valid when the AF mode is set to One-shot AF.

Select an AF point.

(→57)

1

Focus on the subject.

● Place the AF point over the subject and

2

3

press the shutter button down halfway.

Hold the shutter button down
halfway and recompose the
picture.

Take the picture.

4

58

You can also use the Focus lock function in the Basic Zone (except for
< >mode), starting from step 2.

For best results, use the combination of One-shot AF with AE lock applied on the
AF point where focus is achieved, and evaluative metering.

Problem Subjects for Autof ocusing

The EOS D60 has a precision AF system that can focus on most subjects. However, it may not
be able to focus on subjects (focus confirmation light <●> blinks) in particular conditions such
as the following:

Difficult-to-Focus Subjects

● Very low-contrast subjects, such as a blue sky or single-color wall

● Subjects in very dark locations

● Extremely backlit or reflective subjects, such as a shiny new car

● Overlapping nearby and distant objects, such as cage bars and the animal inside the cage

In such cases, use one of the following procedures:
(1) Focus on an object that is at the same distance as the desired subject, apply Focus Lock,

then recompose the picture.

(2) Set the lens focus mode switch to <MF> (or <M>), and focus manually.

Manual Focus

Set the lens focus mode switch to
<MF> (or <M> on older lenses).

1

➡ The < > icon appears on the LCD panel.

3

Advanced Operations

Focus on the subject.

● Turn the manual focusing ring on the lens

2

● If you press and hold the shutter button down halfway as you focus manually,

you will see the AF point where the subject is focused, and the focus confirma­tion light <●> will light.

● During manual focus, the beeper will not sound even when focus is achieved.

until the subject appears sharp in the
viewfinder.

59

INFO.

Checking Camera Settings

When the camera is ready to shoot, press the <
settings on the LCD monitor.

Camera Setting Information

Auto power off time
(→29, 120)

Review (→41),
Review time (→42)

Parameters (→52)

C.Fn (Custom Function)
number(s) (→122)

Flash exposure
compensation (→91)

Shots remaining

CF card capacity remaining (→50)

1

INFO.

> button to view the current camera

AEB (→78)
ISO speed

(→51)

Display the camera settings.

● Press the <
➡ The current camera settings appear on the

LCD monitor.

● Press the <

LCD monitor.

INFO.

> button.

INFO.

> button again to clear the

60

For viewing image information during playback, see “Turning the Information
Display On and Off” (→100).

Selecting a Metering Mode

The EOS D60 uses three modes for metering: Evaluative, Partial, and Center-weighted
average.
The Basic Zone uses evaluative metering. In the Creative zone, any of the three modes can be
selected.

Press the < > button. (6)

1

Select a metering mode.

➡ Look at the LCD panel as you turn the

2

< > dial.

: Evaluative

: Partial

: Center-weighted average

3

Advanced Operations

● Press the shutter button down halfway to

return to ready-to-shoot mode.

Turn the < > dial to set the flash exposure compensation for the built-in/optional
flash (→91).

61

Metering Modes

This is an all-around metering mode suited even for
backlit subjects. The viewfinder field is divided into
35 metering zones to which the three AF points are
linked for evaluative metering. The camera deter­mines the main subject’s size, position, brightness,
background, front and back lighting, etc., so that it
can select the proper exposure for the subject at all
times.

● When using manual focusing, evaluative

metering is based on the center AF point.

This is particularly effective when the background is
much brighter than the subject due to backlighting,
etc. This method uses a center area of approxi­mately 9.5% of the screen.

● The area covered by partial metering is shown on

the left.

This method meters the average exposure of the
entire viewfinder screen, and gives extra weight to
the center.

: Evaluative Metering

: Partial Metering

: Center-weighted Average Metering

62

Selecting a Drive Mode

You can set the EOS D60’s drive mode to single-frame shooting, continuous shooting or self­timer operation.

Single-frame shooting < >: Press the shutter button to take one image.
Continuous shooting < >: You can use the continuous shooting mode by pressing and

Self-timer operation: When you press the shutter button, the picture will be taken

Size/Quality

Large/Fine
Large/Normal
Medium/Fine
Medium/Normal
Small/Fine
Small/Normal
RAW

● The figures above are based on Canon’s testing standards (at 1/250 sec. or faster and ISO

100).

holding the shutter button.

about 10 sec. later. (→81)

Maximum number of images

(Approx. images/sec.)

ONE SHOT

3

AI SERVO

2.5

Max. Burst During Continuous Shooting

(Approx. images)

ONE SHOT AI SERVO

8

3

Advanced Operations

Press the <

DRIVE

> button. (6)

1

Select the drive mode.

● Look at the LCD panel as you turn the

2

If the CF card’s remaining capacity is enough for less than 8 images, continuous
shooting might not be possible.

< > or < > dial.

: Single-frame shooting

: Continuous shooting

: Self-Timer Operation

● Press the shutter button down halfway to

return to ready-to-shoot mode.

63

Selecting a Drive Mode

● During continuous shooting, the captured images are first stored in the camera's

internal memory and then successively transferred to the CF card. When the
internal memory becomes full during continuous shooting, “ ” will be
displayed on the LCD panel and in the viewfinder and the camera cannot take
any more pictures. As the captured images are transferred to the CF card, you
will be able to take more pictures. Press the shutter button halfway to check in
the viewfinder the current remaining number of maximum shots ( to ) for
continuous shooting. Note that this number will be displayed even when there is
no CF card in the camera, so make sure a CF card is in the camera.

● If you press the shutter button halfway before all the images in the internal

memory are transferred to the CF card (access lamp blinking), the image
transfer to the CF card will stop temporarily.

● When “ ” is displayed in the viewfinder and on the LCD panel, replace

the CF card after the access lamp stops blinking.

Setting the White Balance

The EOS D60 has seven white balance settings, Auto, Daylight, Cloudy, Tungsten, Fluores­cent, Flash, and Custom. In the Basic Zone the Auto setting is selected automatically, while in
the Creative zone you can select any of the seven white balance settings.

Press the <

1

Select the white balance setting.

● Set the Quick Control Dial switch to <ON >.

2

● Turn the < > dial.

● Press the shutter button down halfway to

return to ready-to-shoot mode.

Auto Daylight Cloudy Tungsten

Turn the < > dial to select the AF mode (→54).

64

Fluorescent

AF

> button. (6)

WB

Flash Custom

White Balance Settings

In light from any source, the proportion of the primary colors (red, green, blue) in the light
varies according to the color temperature. Higher color temperatures contain a greater
proportion of blue, and lower color temperatures contain a greater proportion of red. Moving
from low to high, the progression is red → orange → yellow → white → blue-white. For ex­ample, a given subject will appear reddish if taken under tungsten (incandescent) lighting, or
greenish if taken under fluorescent lighting.
The human eye automatically adapts to changes in light so that white subjects appear white
even under different lighting conditions. Cameras that use film have to adjust for these
differences by using color-correcting filters or switching to different film types. Digital cameras
rely on software to correct the color temperature by determining white as the basis for the
colors in the subject, then correcting the other colors to achieve a natural color range.
< > mode automatically selects the white balance according to the light source where you
are shooting. If this does not produce pictures with satisfactory coloring, you can select a
mode other than < >.

Icon

Conditions

Camera selects the setting automatically.

For bright outdoor daylight.

For cloudy conditions, twilight or evening.

For indoor incandescent lighting.

For indoor white fluorescent lighting.

For flash pictures.
To photograph a white subject to use as a

base color, then load that white balancedata
to set the ideal white balance for that
shooting location (→66).

Color temperature K (Kelvin)

approx. 3000 -7000

approx. 5500

approx. 6000

approx. 3200

approx. 4000

approx. 6000

approx. 2000-10000

3

Advanced Operations

65

Custom White Balance Setting

Custom white balance lets you set the white balance yourself by photographing a white subject
to use as the basis for the camera’s white balance, and then selecting that picture for use as
white balance data.

Photograph a white subject.

● Take a picture of a white subject, just as

1

Partial metering zone

2

3

you would take a normal picture.

●

Frame the shot so that the white subject fills the
entire partial metering zone in the viewfinder.

●

This picture can be taken using any mode (→16).

●

Photograph a white subject so that a standard
exposure is obtained. If the picture is underex­posed or overexposed, the correct white balance
might not be obtained.

From the menu, select [Custom
WB].

● Press the <

● Turn the < > dial to select [Custom WB],

then press the < > button.

Select the image.

● Turn the < > dial to select the picture you

took in step 1, then press the < > button.

● When the setting is entered, the screen

returns to the menu.

● Press the <

screen and exit the menu.

MENU

> button.

MENU

> button to clear the

66

Press the <

AF

> button. (6)

WB

4

Select the white balance.

● Turn the < > dial to select < >.

5

➡ The custom white balance is entered.

Custom White Balance Setting/

● For best results, use subjects such as plain white paper for white balance basis.

● White balance data is loaded from the partial metering zone (→17).

● You can store white subjects photographed under various conditions on the CF

card, then select these images as needed for the [Custom WB] function as an
easy way of setting the ideal white balance for any lighting conditions.

● The default setting for < > is the same as the default setting for < >.

LCD Panel Illumination

LCD Panel Illumination

The LCD panel can be illuminated for about 4 sec. by pressing the < > button. Pressing the
button again turns off the illumination.
After a picture is taken, the LCD panel illumination turns off automatically after 2 sec.

On the menu, select [LCD illumi.]
and set the LCD panel illumina­tion.

● Press the <

● Turn the < > dial to select [LCD illumi.],

then press < >.

● Turn the < > dial to select [On], then

press < >.

➡ The LCD panel illumination will be enabled,

and the menu will reappear.

● Press the <

turn off the display.

MENU

> button.

MENU

> to quit the menu and

3

Advanced Operations

Illuminating the LCD panel

● Press < >.

● To turn off the illumination, press < >

again.

● If you operate a button or dial for picture-

taking while the LCD panel is illuminated,
the illumination will continue. If you press a
menu or image playback button, the
illumination will turn off.

● If C.Fn-12-1/2/3 has been set, pressing < > will not turn off the LCD panel

illumination (it will turn off automatically).

● If you take a picture while the LCD panel is illuminated, the illumination will

continue as you shoot.

● LCD panel illumination works in all shooting modes.

67

Program AE

Like < > (Full Auto) mode, this is a general­purpose picture-taking mode. The camera automati­cally sets the shutter speed and aperture value to
suit the scene’s brightness. This is called Program
AE.

∗ stands for Program
∗ AE stands for Auto Exposure

Set the Mode Dial to < >.

1

Focus on the subject.

● Press the shutter button down halfway.

2

➡ The AF point achieving focus will flash in

red and the beeper will sound. The focus
confirmation light <●> at the lower right will
also light.

68

Check the display.

➡ The shutter speed and aperture value are

3

4

determined automatically, and displayed in
the viewfinder and on the LCD panel.

● If the shutter speed and aperture values are

not blinking, the exposure is correct.

● If either is blinking, see “Exposure Warn-

ings” (→132).

Take the picture.

● Compose the picture, then press the shutter

button down fully.

Program AE

Differences Between Program AE Mode < > and Full Auto Mode < >

● < > (Program AE) and < > (Full Auto) mode are alike in that both automatically deter-

mine the shutter speed and aperture values.

● The following functions can be used in < > mode but not in < > mode.

• AF mode selection • Built-in flash firing manually/firing prohibited

• Manual AF point selection • Flash exposure compensation

• Metering mode selection • Special features with EX-series Speedlites

•Drive mode selection - High-speed sync (FP Flash)

• Program shift - FE lock

• AE lock with < > button - Flash output ratio control

• Exposure compensation - FEB

•Autoexposure bracketing (AEB) - 2nd-curtain sync

• Depth-of-field preview - Modeling flash

• Custom Functions

Shifting the Program

In Program AE mode, you can freely change the shutter speed and aperture value combina­tion (program) set by the camera while maintaining the same exposure value. This is called
shifting the program.
To do this, press the shutter button down halfway, then turn the < > dial until the shutter
speed or aperture value you want is displayed.

● Once you take a picture with the shifted program, the shifted program is canceled automati-

cally and the original program is restored.

● If you are using a flash, you cannot shift the program.

3

Advanced Operations

69

Shutter-Priority AE

In this mode, you set the shutter speed, and the camera automatically sets the aperture value
to suit the brightness of the subject. This is called Shutter-Priority AE.
A fast shutter speed can freeze the motion of a fast-moving subject, and a slow shutter speed
can blur the subject to give the impression of motion.
∗ stands for “time value.”

Fast shutter speed Slow shutter speed

Set the Mode Dial to < >.

1

Set the shutter speed.

● Turn the < > dial.

2

70

Focus on the subject.

● Press the shutter button down halfway.

3

➡ The aperture value is determined automati-

cally.

Check the display, then take the
picture.

4

● If the aperture value is not blinking, the

exposure is correct.

● Compose the picture, then press the shutter

button down fully.

Shutter-Priority AE

● If the smallest aperture value (the

maximum open aperture) for the lens you
are using blinks, the scene is too dark.
Turn the < > dial to a slower shutter
speed until the aperture value stops
blinking.

● If the largest aperture value (the

minimum aperture) for the lens you are
using blinks, the scene is too bright. Turn
the < > dial to a faster shutter speed
until the aperture value stops blinking.

Shutter Speed Display

You can set the shutter speed in half-stop increments as shown below. The shutter
speeds from 4000 to 4 indicate the denominator of the fractional shutter speed, so
that—for example—125 is 1/125 second. For slow speeds, 0”7 is 0.7 seconds,
and 15” is 15 seconds.
4000 3000 2000 1500 1000 750 500 350 250 180 125 90 60 45 30 20
15 10 8 6 4 0”3 0”5 0”7 1” 1”5 2” 3” 4” 6” 8” 10” 15” 20” 30”

The ideal shutter speed for capturing a clear image from a TV screen is 1/15
second. We recommend using a tripod.

3

Advanced Operations

You can also set the camera so that you can set the shutter speed in 1/3-stop
increments. (C.Fn-4-1→122)

71

Aperture-Priority AE

In this mode, you set the aperture value, and the camera automatically sets the shutter speed
to suit the brightness of the scene. This is called Aperture-Priority AE.
By setting a smaller aperture value (larger aperture), you can blur the background to make the
subject stand out as in a portrait. Or, by setting a larger aperture value (smaller aperture), you
can increase the depth of field to make both the foreground and background look sharp.
∗ Av stands for “aperture value.”

Small aperture value Large aperture value

Set the Mode Dial to < >.

1

Select the aperture value.

● Turn the < > dial.

2

72

Focus on the subject.

● Press the shutter button down halfway.

3

➡ The shutter speed is determined automati-

cally.

Check the display, then take the
picture.

4

● If the shutter speed is not blinking, the

exposure is correct.

● Compose the picture, then press the shutter

button down fully.

Aperture-Priority AE/Checking the Depth of Field

● If the 30” shutter speed blinks, the scene

is too dark. Turn the < > dial to reduce
the aperture value (larger aperture).

● If the 4000 shutter speed blinks, the

scene is too bright. Turn the < > dial to
increase the aperture value (smaller
aperture).

Aperture Value Display

You can set the aperture in half stops as shown below. The higher the aperture
value, the smaller the aperture opening. The range of aperture settings displayed
depends on the lens mounted on the camera.

1.0 1.2 1.4 1.8 2.0 2.5 2.8 3.5 4.0 4.5 5.6 6.7 8.0 9.5 11 13 16 19 22
27 32 38 45 54 64 76 91
If no lens is mounted on the camera, the aperture setting is displayed as 00.

● You can also set the camera so that you can set the aperture value in 1/3-stop

increments. (C.Fn-4-1→122)

● You can fix the shutter speed at 1/200 second for shooting with a flash.

(C.Fn-6-1→124)

3

Advanced Operations

Checking the Depth of Field

You can press the Depth-of-Field Preview button to
close the aperture to the current aperture setting,
and then verify the range of focus in the viewfinder.

● This feature can be used in the Creative zone.

● In < > mode, this feature operates when the shutter button is pressed down

halfway.

● The exposure is locked (AE lock) while the Depth-of-Field Preview button is

pressed.

73

Manual Exposure

In this mode you set the shutter speed and aperture
value yourself. The camera makes no settings
automatically. You can determine the correct
combination of shutter speed and aperture value by
checking the exposure level displayed in the
camera.
∗ stands for manual.

Set the Mode Dial to < >.

1

Set the shutter speed.

● Turn the < > dial.

2

74

Set the aperture value.

● Set the Quick Control Dial switch to <ON >,

3

4

then turn the < > dial.

Focus on the subject.

● Press the shutter button down halfway.

(4)

➡ The exposure level indicator appears in the

viewfinder and on the LCD panel.

● The exposure level icon < > lets you see

how far you are from the standard exposure
level.

Determine the exposure.

● Set the shutter speed or aperture value

5

manually.

Manual Exposure

Standard exposure : This is the standard reference point for a correct

Underexposure : Decrease the shutter speed or reduce the

Overexposure : Increase the shutter speed or increase the

exposure.

aperture value.

aperture value.

● If the exposure level indicator < > is

flashing at the < > or < > position, the
exposure is over- or under-exposed by
more than two stops.

Take the picture.

● Compose the picture, then press the shutter

6

button down fully.

3

Advanced Operations

You can set the camera so that you can set the shutter speed or aperture value in
1/3-stop increments. (C.Fn-4-1→122)

75

A utomatic Depth-of-Field AE

When taking pictures of large groups or landscapes, the EOS D60 can automatically achieve a
sharp focus over a wide depth of field. All the subjects covered by the AF points, from those
close to the camera to those far away from the camera, can be taken clearly.

● In < > mode, the shutter speed and aperture value cannot be changed freely. If the

camera selects a slow shutter speed, the use of a tripod is recommended.

● Automatic depth-of-field AE cannot be used if the lens’ focus mode switch is set to <MF>

(or <M> on older lenses). Set the switch to <AF>.

∗ stands for Auto-Depth of field.

Set the Mode Dial to < >.

1

Focus the picture.

● Place an AF point over the subject and

2

press the shutter button down halfway. (4)

● The focus will be sharp between the

subjects where the AF points flashes in red.

● You can check the depth of field beforehand

while the exposure is displayed. (→73)

● In the example shown on the left, sharp

focus will be attained between the left-most
person and right-most person.

76

Check the display, then take the
picture.

3

● If the aperture value is not blinking, the

exposure is correct.

● Press the shutter button down fully.

If the aperture value is blinking, the exposure level is correct but the desired depth
of field cannot be achieved. Either use a wide-angle lens or move farther from the
subject.

● Regardless of the AF mode setting, ONE-SHOT AF will take effect.

● If you use a flash, the result will be the same as using < > (Program AE) mode

with flash.

Setting Exposure Compensation

Exposure compensation is used to alter the camera’s standard exposure setting to make the
picture brighter (increased exposure) or darker (decreased exposure). Exposure compensation
can be set up to +/–2 stops, in 1/2-stop increments.

Set the Quick Control Dial switch
to <ON>.

1

Focus on the subject, then check
the exposure level.

2

● Press the shutter button down halfway and

check the display. (4)

Set the exposure.

● While looking at the LCD panel or

3

viewfinder, turn the < > dial.

● Turn the < > dial while pressing the

shutter button down halfway, or within (4)
seconds of pressing the shutter button
down halfway.

● Positions on the [+] side indicate increased

exposure, and positions on the [–] side
indicate decreased exposure.

Decreased Increased
exposure

● Once set, the exposure compensation

remains in memory after the Main Switch is
set to <OFF>.

● To cancel exposure compensation, return

the compensation setting to the standard
exposure position < >.

exposure

3

Advanced Operations

Take the picture.

4

● To prevent the < > dial from turning inadvertently and changing the exposure

compensation, enter the setting and then set the Quick Control Dial switch to
<OFF>.

● In < > (Manual) mode, because you determine the exposure (the combination

of shutter speed and aperture) yourself, the exposure compensation function
does not operate.

You can set the camera so that you can set the exposure compensation amount in
1/3-stop increments. (C.Fn-4-1→122)

77

Autoexposure Bracketing

When using autoexposure bracketing, the camera automatically changes the exposure level within
the set range (up to +/–2 stops in 1/2-stop increments) for three successive frames. This is called
AEB (Auto Exposure Bracketing). The three bracketed shots are exposed in the selected drive mode
(→63) in the following order: correct exposure, decreased exposure, and increased exposure.

Standard exposure (0) Decreased exposure (–1.0) Increased exposure (+1.0)

From the menu, select [AEB].

● Press the <

1

● Turn the < > dial to select [AEB], then

press the < > button.

Set the AEB level.

● Turn the < > dial to set the AEB level you

2

want, then press the < > button.

● The AEB setting is entered, and the display

returns to the Menu.

● Press the <

screen and exit the menu.

MENU

> button.

MENU

> button to clear the

: Correct exposure

: Decreased

exposure

: Increased

exposure

Canceling AEB

78

Take the picture.

➡

3

The bracketing sequence will be standard exposure,
decreased exposure, and increased exposure.

➡

The pictures will be taken in the drive mode currently
set. (→63)

●

When using continuous shooting, press and hold the
shutter button down fully to take all three bracketed
shots continuously, and then stop automatically.

●

When using AEB with the self-timer, the camera
takes the three bracketed shots in succession after
the 10-second timer delay.

● Follow steps 1 and 2 to set the AEB level to

< >.

● AEB will be automatically cancelled when

the Main Switch is set to <OFF>, the lens is
changed, the flash is charged, the battery
pack or the CF card is replaced.

Autoexposure Bracketing

● Neither flash nor bulb exposures can be used in AEB mode.

● If you set mirror lockup with C.Fn-3-1 and then use AEB, single-frame shooting

takes effect even if the drive mode is set to continuous shooting.

● To indicate that AEB is in progress, the < > AEB icon on the LCD panel and

the < > indicator in the viewfinder blink until all three bracketed shots have
been taken.

● If the drive mode is set to single-frame shooting, you must press the shutter

button three times to complete the bracketing sequence.

● During continuous shooting, no viewfinder information is displayed.

● In manual exposure mode, AEB is applied by changing the shutter speed.

●

You can use AEB in combination with exposure compensation. In this case, if
exposure compensation causes the exposure to fall outside the indicated exposure
level, the viewfinder display looks as follows. In all cases, the exposures are taken
according to both the AEB and exposure compensation settings.

In < >, < >, < > and < > modes

: AEB set to +/–1 stop.
: With exposure compensation of –1 stop

: With exposure compensation of –1.5 stops
: With exposure compensation of –2 stops

3

Advanced Operations

In < > mode

: Center exposure –2 stops from standard exposure

: Center exposure more than –2 stops from satandard exposure

● You can change the AEB settings in 1/3-stop increments. (C.Fn-4→122)

In this case, the AEB indicator on the LCD panel looks like this.

AEB settings in 1/3-stop increments

: –1/3 : +1/3

AEB settings in 2/3-stop increments

: –2/3 : +2/3

● You can change the sequence to decreased exposure, standard exposure, or

increased exposure. (C.Fn-7→124)

79

AE Lock

AE lock enables you to lock the exposure at a place other than the point of focus. After locking
the exposure, you can recompose the shot while maintaining the exposure level. This feature
is useful for backlit and spotlighted subjects.

● The effects of the AE lock depend on the AF point and metering method selected. (→133)

Focus on the point on which you
want to lock the exposure read-

1

ing.

➡ The exposure value is displayed in the

viewfinder.

Press the < > button.

● The < > icon lights in the viewfinder to

2

indicate that the exposure setting is locked.
(4)

● Each time you press the < > button, the

current exposure setting is locked.

80

Compose the shot and take the
picture.

3

You can apply AE lock by pressing the shutter button (instead of the < > button)
down halfway, and focus with the < > button. (C.Fn-2-1→122)

Self-timer Operation

The self-timer is convenient for group photographs. You can use it in any Basic mode or
Creative mode. We recommend using a tripod when you use the self-timer.

Select the self-timer.

1

● Press the <

the < > dial to select < >.

DRIVE

> button (6), and turn

Focus on the subject.

● Make sure the focus confirmation light <●>

2

3

Do not stand in front of the camera when you press the shutter button to start the
self-timer. Doing so prevents the camera from focusing on the subject.

● You can set the beep that indicates the subject is in focus and the beep that

indicates the self-timer is operating to [On] or [Off]. (→118)

● When using the self-timer to shoot only yourself, lock the focus (→58) on an

object at about the same distance as where you will be.

● You can use the Remote Switch RS-80N3 (optional) or Timer Remote Controller

TC-80N3 (optional) to take a picture when you are away from the camera.

and the exposure setting are displayed.

Take the picture.

● Press the shutter button down fully.
➡ The beeper sounds as the red-eye

reduction lamp operates, and the picture is
taken after 10 seconds.
First 8 seconds:
Slow beeps and the lamp blinks slowly.
Last 2 seconds:
Faster beeps and the lamp stays on.

➡ While the self-timer is operating, the LCD

panel shows count down.

● To cancel the self-timer, press the <

button.

DRIVE

3

Advanced Operations

>

81

Self-timer Operation

Using the Eyepiece Cover

If you take a picture using the self-timer or remote switch (optional) without looking through the
viewfinder, stray light can enter the eyepiece and affect the exposure. To prevent this, attach
the eyepiece cover to the viewfinder eyepiece before taking the picture.

Remove the eyecup.

● Grasp both sides of the eyecup and lift it up

1

2

and away from the camera.

Slip the eyepiece cover over the
eyepiece.

● The eyepiece cover is attached to the strap.

82

Bulb Exposures

In a bulb exposure, the shutter remains open as long as you hold the shutter button down, and
closes when you release it. Bulb exposures are useful for the long exposures required for
night scenes, fireworks, etc.

Set the Mode Dial to < >.

1

Set the shutter speed to “ ”.

● Look at the LCD panel and turn the < >

2

3

4

dial to select “ ”.

● The next setting after “ ” is “ ”.

Set the aperture value.

● Turn the < > dial.

Take the picture.

● Press and hold the shutter button down

fully.

➡ During the bulb exposure, the elapsed

exposure time is displayed on the LCD
panel (1 to 999 seconds).

● Exposure continues as long as you hold

down the shutter button.

3

Advanced Operations

The elapsed exposure time displayed on the LCD panel is only counted up to 999
seconds. For accurate exposure time, check the information display for the
exposed image. (→100)

The Remote Switch RS-80N3 (optional), or Timer Remote Controller TC-80N3
(optional) can be used to eliminate the need to hold down the shutter button.

83

Mirror Lockup

Mirror lock is enabled with C.Fn-3-1 (→122). This function raises the mirror and exposes the
picture, in separate operations. It is useful for close-up shots or when using a super telephoto
lens, where the mirror shock could affect the picture.

● When using mirror lockup, we recommend you use the Remote Switch RS-80N3 (optional).

Press the shutter button down
fully.

1

➡ The mirror is raised.

● The mirror automatically returns to the

down position approximately 30 seconds
after it is raised. Be sure to take the picture
within 30 seconds.

Press the shutter button down
fully again.

2

● The picture is taken, and the mirror goes

back down.

● To take the picture again, repeat the

procedure from step 1.

84

● During mirror lockup, do not point the camera at the sun. The sun’s heat can

scorch and damage the shutter curtains.

● If you use mirror lockup with the self-timer for a bulb exposure, there will be a

shutter release sound when you release the shutter button during self-timer
operation. This is not the sound of the shutter release.

● During mirror lockup, the drive mode (→63) is single-frame shooting regardless

of the current setting.

● If you use mirror lockup with the self-timer, pressing the shutter button down

fully the first time raises and locks the mirror, then releases the shutter 2
seconds later.

Flash

Photography

The EOS D60 can take easy, natural-looking flash pictures with
correct subject illumination using E-TTL autoflash (preflash evalua­tive metering in memory) and either the camera’s built-in flash or any
EOS-dedicated EX-series Speedlite. The procedure is as easy as a
normal AE shot.
This chapter describes how to take flash pictures with the built-in
flash, with the EOS-dedicated 550EX Speedlite, or other types of
external flash.

4

4

Flash Photography

85

Using the Built-in Flash

The built-in flash lets you take the following kinds of flash pictures with the ease of a normal
AE shot.

● E-TTL autoflash

E-TTL autoflash (preflash evaluative metering in memory) supplies the correct level of flash for
the subject in the AF point selected by AF.

●

FE (Flash Exposure) lock (→90)

FE (flash exposure) lock sets the correct flash exposure for a selected part of the subject. The
FE lock functions as an AE lock with flash.

●

Flash exposure compensation (→91)

This function corrects the flash level in much the same way as the Exposure compensation
function. The level of compensation can be up to +/–2 stops in 1/2-stop increments.

Using the Built-in Flash in the Basic Zone

In the Basic Zone (except in < > and < > modes), the built-in flash pops up and fires
automatically in low-light or backlit conditions.

Using the Built-in Flash in the Creative Zone

In the Creative zone, you can take flash pictures by simply pressing the < > button to pop up
the built-in flash at any time, regardless of lighting conditions.

: Select < > mode for full autoflash.

The shutter speed and aperture value are determined automatically, just as in < >
(Full Auto) mode.

: Select < > mode to manually set a shutter speed slower than 1/200 second.

The camera then automatically sets the flash aperture value to provide the proper
exposure for your shutter speed.

: Select < > mode to manually set the aperture value.

In low-light conditions against a background such as a night sky, you can use automatic
slow-sync settings to properly expose the main subject and the background. The main
subject is captured by the flash, and the background is captured by time exposure using
a slow shutter speed.

● Because automatic slow-sync photography uses a slow shutter speed, always use a
tripod.

: Select < > mode to set the shutter speed and the aperture value manually.

The main subject is exposed properly by the flash. The background exposure varies
according to the shutter speed and aperture settings.

: The effect is the same as using flash in < > mode.

86

Using the Built-in Flash

Built-in Flash Range

(using EF24-85mm f/3.5-4.5 USM lens)

ISO Speed Wide-angle: 24 mm Telephoto: 85 mm

100 Approx. 1-3.4 m (3.3-11.2 ft) Approx. 1-2.6 m (3.3-8.5 ft)
200 Approx. 1-4.8 m (3.3-15.7 ft) Approx. 1-3.7 m (3.3-12.1 ft)
400 Approx. 1-6.8 m (3.3-22.3 ft) Approx. 1-5.3 m (3.3-17.4 ft)
800 Approx. 1-9.6 m (3.3-31.5 ft) Approx. 1-7.5 m (3.3-24.6 ft)

1000 Approx. 1-10.8 m (3.3-35.4 ft) Approx. 1-8.4 m (3.3-27.6 ft)

Flash Sync Shutter Speed and Aperture Settings

Mode

Sync shutter speed

Automatically set from 1/200 to 1/60
second.

Manually set to speeds slower than
1/200 second.

Automatically set (1/200 to 30 sec.)
for the metered brightness, according
to the aperture value.

Manually set to speeds slower than
1/200 second.

Aperture Value

Automatically set by the E-TTL
program.

Automatically set for the metered
brightness, according to the shutter
speed setting.

Manually set as desired.

4

Flash Photography

87

Using the Built-in Flash

● When using an EX-series Speedlite (→92), press the built-in flash back into the

camera before mounting the external flash.

● When using the built-in flash, keep at least 1 m/3.3 ft away from the subject.

Otherwise the lens barrel may partially obstruct the flash and cause part of the
photo to look dark.

● When using the built-in flash, detach any hood from the lens to keep it from

obstructing flash coverage.

● Using the built-in flash with any of the following lenses can partially obstruct the

flash coverage. Instead, use an EOS-dedicated external flash.
Large-aperture lenses, including the EF16-35mm f/2.8L USM, EF28-70mm
f/2.8L USM.
Super-telephoto lenses, including the EF300mm f/2.8L IS USM and EF600mm
f/4L IS USM.

● The built-in flash can cover the picture area for lenses with focal lengths as

short as 18 mm. If you use a lens shorter than 18 mm, the photo will be dark
around the edges.

● The ‘E’ in E-TTL stands for ‘Evaluative.’

● To retract the built-in flash, press it back down into the camera.

● You cannot use the built-in flash to set high-speed sync (FP flash).

● In < > or < > mode, if you set the shutter speed faster than 1/200 second,

the camera will automatically reset it to 1/200 unless the EX-series Speedlite
has been set for high-speed sync.

● AF flash exposure is always based on the aperture value at the time the shot is

taken, and controlled by E-TTL automatic flash compensation linked to the
active AF point and weighted for the main subject.

● The built-in flash and external flash cannot be used at the same time.

● If the camera finds it difficult to focus, the AF-assist lamp (→39) will light

automatically (except in the < > and < > modes).

88

● You can disable the AF-assist beam and built-in flash. (C.Fn-5→122)

● You can set the Shutter curtain sync to 2nd-curtain sync. (C.Fn-8-1→124)

● In the aperture-priority AE mode with flash, you can set the sync speed to 1/200

sec fixed. (C.Fn-6-1→124)

Using the Built-in Flash

Red-eye Reduction

When you use flash in low-light conditions, it can reflect off your subject’s pupils and make
their eyes look red in the recorded imge. This effect is called “red-eye,” and is caused by the
light of the flash reflecting off the retina of the eye. The Red-eye reduction function uses the
camera’s red-eye reduction lamp, which gently shines into the subject’s eyes to constrict the
pupils and thereby reduces the likelihood that red-eye will occur. You can use red-eye reduc­tion in any picture-taking mode except < > and < > modes.

From the menu, select [Red-eye
on/off].

1

● Press the <

● Turn the < > dial to select [Red-eye on/

off], then press the < > button.

Set the Red-eye reduction func­tion.

2

● Turn the < > dial to select [On], then

press the < > button.

➡ The red-eye reduction function is turned

On, and the display returns to the Menu.

● Press the <

screen and exit the menu.

MENU

> button.

MENU

> button to clear the

4

Flash Photography

● When you press the shutter button down halfway, the red-

eye reduction lamp indicator appears in the viewfinder.

● Red-eye reduction is effective only when the subject is

looking at the red-eye reduction lamp. Be sure to tell your
subjects to look at the lamp.

● To increase the effectiveness of red-eye reduction, press the

shutter button down fully after the red-eye reduction lamp
(which lights for approximately 1.5 seconds) indicator goes
off.

● You can take a picture anytime by pressing the shutter

button down fully, even if the red-eye reduction lamp is on.

● Red-eye reduction also operates when you use an EOS-

dedicated Speedlite.

● The effectiveness of red-eye reduction varies from subject to

subject.

Red-eye reduction is more effective in bright interior locations, with the camera
closer to the subject.

Red-eye reduction

lamp indicator

89

Using the Built-in Flash

FE Lock

FE (flash exposure) Lock obtains and locks the correct flash exposure reading for any part of a
subject. FE Lock is a function in the Creative zone.

Make sure the < > icon in the
viewfinder is on.

1

● In the Creative zone, press the < > button

to pop up the built-in flash.

Focus on the subject.

● Focus on the subject you want to lock the

2

3

1

2

flash exposure on.

Place the center AF point over the
subject, and press the < >

button. (

➡ The Speedlite fires a preflash and records

the required flash output for this subject in
memory.

➡ The < > icon lights in the viewfinder.
➡ The center AF point will flash in red.
➡ In the viewfinder, the display appears as

shown in 1 for 0.5 seconds, then changes
to 2.

● Each time you press the < > button the

preflash fires, and the FE lock is applied at
the required exposure level.

16

)

90

Take the picture.

● Compose the shot and take the picture.

4

If the subject is far enough away to cause underexposure, the < > icon will blink
in the viewfinder. Move closer to the subject and repeat steps 2 – 4.

Using the Built-in Flash

Flash Exposure Compensation

The EOS D60 camera can adjust the level of the built-in flash or any EX-series Speedlite. The
compensation amount can be up to +/–2 stops in 1/2-stop increments. You cannot use flash
exposure compensation in the Basic Zone.

Press the < > button. (

1

Set the exposure compensation
amount.

2

● Set the Quick Control Dial Switch to <ON>.

● While looking at the LCD panel or

viewfinder display, turn the < > dial.

● The [+] side indicates increased compensa-

tion, and the [–] side indicates decreased
compensation.

Decreased Increased
exposure

● Once set, the exposure compensation

amount remains in memory after the Main
Switch is set to <OFF>.

● To cancel, set the compensation amount to

the < > position.

)

6

exposure

4

Flash Photography

Flash exposure compensation can also be set with EX-series Speedlites. If flash
exposure compensation is set with both the camera and EX-series Speedlite, the
Speedlite's setting will override the camera’s.

● You can set the camera to adjust exposure compensation in 1/3-stop incre-

ments. (C.Fn-4-1→122)

● You can also disable the Auto reduction of fill flash function. (C.Fn-10-1→124)

91

Flash Photography with the EOS-Dedicated 550EX Speedlite

The Canon 550EX Speedlite allows you to take high-quality flash pictures easily, in the same
way as you would with a built-in flash.

● E-TTL Autoflash

E-TTL autoflash (preflash evaluative metering in
memory) supplies the correct level of flash for the
subject in the AF point selected by AF. In dark locations,
you can set the camera to aperture-priority AE for
automatic slow-sync operation, for a natural-looking
exposure balanced between the subject and back­ground.

●

High-Speed Sync (FP Flash) (→94)

High-speed sync (FP or focal-plane flash) enables flash synchronization at all shutter speeds
from 30 sec. to 1/4000 sec.

●

FE (Flash Exposure) Lock (→95)

FE lock obtains and locks the correct flash exposure for any part of the subject. This is the
flash equivalent of AE lock.

●

Flash Exposure Compensation (→95)

As with normal exposure compensation, you can use flash exposure compensation to adjust
the flash output within a range of +/–2 stops, in 1/2-stop increments.

●

FEB (Flash Exposure Bracketing) (→94)

The FEB function is like AEB (autoexposure bracketing) with flash. You can bracket flash
exposures by up to +/–3 stops, in 1/2-stop increments.

●

Modeling Flash (→95)

Modeling flash allows you to check shadows and the light balance produced by multi-light
settings.

●

Wireless Multi-Flash/E-TTL Autoflash (→95)

You can implement wireless multi-light E-TTL autoflash, using any or all of the features listed
above. This provides the freedom to set up sophisticated lighting effects with no connection
cords required.

92

Autoflash functions are not available with EZ, E, EG, ML, or TL-series Speedlites.

● In difficult focusing conditions, the AF-assist beam is emitted from the 550EX

Speedlite, and automatically linked to the active AF point.

● Besides the 550EX, other EX-series Speedlites can be used with the camera.

Regarding the available features, refer to the Speedlite's instructions.

Flash Photography with the EOS-Dedicated 550EX Speedlite

MODE SELEC

PILOT

H

Full Auto Flash

Using the < > (Program AE) mode with E-TTL autoflash is described below. Regarding the
operation of the 550EX, refer to the Speedlite's instructions.

Set the Mode Dial to < >.

1

Make sure the 550EX Speedlite’s
pilot lamp is on.

2

Focus the subject, and take the
picture.

3

● Make sure the flash-ready indicator < > is

on, and check the shutter speed and
aperture value before taking the picture.

Taking Flash Pictures in Each Shooting Mode

Even in < >, < >, and < > modes, E-TTL autoflash is as easy as normal picture-taking
without flash.

4

Flash Photography

(1) Press the shutter button down halfway to have the camera automatically set the shutter

speed or aperture value, just as in normal picture-taking without flash.

Mode Shutter speed setting

(Shutter-priority AE) Manual (30 to 1/200 sec.) Auto
(Aperture-priority AE) Auto (30 to 1/200 sec.) Manual
(Manual exposure) Manual (30 to 1/200 sec.) Manual

∗ If < > is set in low-light conditions, a slow shutter speed will be set. Therefore, use a

tripod to prevent camera shake.

(2) When you press the shutter button completely, a preflash will be fired based on the

aperture set in (1) and the picture will be taken with E-TTL autoflash.

(3) The background exposure is determined by the shutter speed and aperture value.

● Flash photography in < >mode operates the same as in < > mode.

● In the Basic Zone modes (→18), it will be automatic and as easy as flash

photography with the built-in flash.

● You can disable the EX-series Speedlite from firing. (C.Fn-5-3→122)

● You can set the camera to apply a fixed shutter speed of 1/200 for flash

photography in aperture-priority AE mode. (C.Fn-6→124)

Aperture (flash aperture) setting

93

Flash Photography with the EOS-Dedicated 550EX Speedlite

High-Speed Sync (FP Flash)

When the 550EX Speedlite is set to high-speed sync < > mode, it can automatically
synchronize at any shutter speed of 1/200 second or faster, thus providing high-speed sync
(FP) flash operation. When high-speed sync is On, the < > icon appears in the viewfinder.
High-speed sync is effective for portrait photography in the following situations:
(1) When you want to use daylight sync flash for a portrait, and widen the aperture (reduce

the aperture value) to blur the background.
(2) When you want to produce a catchlight in the subject’s eyes.
(3) When you want to use fill flash to eliminate shadows.

Normal flash FP flash

FEB (Flash Exposure Bracketing)

By setting FEB (flash exposure bracketing) < > with the 550EX, you can bracket the flash
exposure up to +/-3 stops in 1/2-stop increments. The flash output is changed automatically for
each bracketed shot so that the background exposure level remains the same.

Standard exposure (0) Decreased exposure (–1.0) Increased exposure (+1.0)

● FEB is applied from the 550EX Speedlite. For details, see the Instractions for your

Speedlite.

● For best results use < > (single-frame shooting) drive mode. (→63)

You can set the camera to change FEB settings in 1/3-stop increments.
(C.Fn-4-1→122)

94

Flash Photography with the EOS-Dedicated 550EX Speedlite

FE Lock

The procedure for setting FE lock is the same as with the built-in flash (→90). FE lock works in
both the normal flash and high-speed sync (FP flash) modes.

Flash Exposure Compensation

For flash pictures with flash exposure compensation, see “Flash Exposure Compensation” for
the built-in flash. (→91)

Modeling Flash

Modeling flash allows you to see shadows, light balance, and other effects produced by multi­light settings.

Check that the camera and
Speedlite are properly set for flash

1

photography.

Press the camera’s depth-of-field
preview button.

2

● The Speedlite fires at 70Hz for approxi-

mately one second.

Wireless Multi-Flash/E-TTL Autoflash Shooting

The 550EX Speedlite can be operated as a slave light from a master (550EX or ST-E2) for
easy wireless multi-flash/E-TTL autoflash photography. The slave 550EX is placed to supple­ment the master flash, which provides the primary flash for the subject.

● This is a Type-A camera. For details, refer to the instractions for your master Speedlite.

Macro Ring Lite MR-14EX and Macro Twin Lite MT-24EX can also be used as the
master unit, and Speedlite 420EX can also be used as a slave unit.

4

Flash Photography

95

Using Non-Canon Flash Units

Sync Speed

The EOS D60 can synchronize with compact, non-Canon flash units at shutter speeds of 1/
200 second or slower. With larger studio flash units, the flash speed is 1/60 second or slower.
Be sure to test the flash you are using beforehand, to make sure it synchronizes properly with
the camera.

PC Terminal

We recommend you use a flash with sync cable connected to the PC contacts. The PC
terminal has a locking thread to prevent accidental disconnection. Only the X-sync terminal is
used for synchronization at 1/200 second or slower.

● If you use the EOS D60 with a flash unit or flash accessory built for another

brand of camera, the EOS D60 may not operate properly.

● Some large studio flash units have a sync

cord polarity that is the opposite of the EOS
D60’s PC terminal. Such flash units will not
work with the EOS D60 unless you change
the polarity of the sync cord. Consult the
manufacturer of the flash unit, or purchase a
commercially-available polarity conversion
cord. The camera’s PC terminal polarity is
shown in the figure on the right.

● Do not use a high voltage flash on the hot shoe. It might not fire.

● You can use a flash unit attached to the camera's hot shoe and another flash

unit connected to the PC terminal at the same time.

● We recommend Canon EX-series Speedlites for use with this camera.

+ (plus)

– (minus)

TTL and A-TTL Speedlites

● With an EZ-, E-, EG-, ML-, or TL-series Speedlite set in the TTL or A-TTL autoflash mode,

the flash will not fire. The manual flash mode must be used (with Speedlites having a
manual flash mode).

● When the 550EX is set to C.Fn-3-1, the flash will not fire in the TTL autoflash mode.

96

Playing and

Erasing

Recorded Images

This section explains how to view the images you have recorded
with the EOS D60, how to erase images, and how to make settings
for Digital Print Order Format (DPOF) printers or photo lab printing
services.
This section also describes how to connect the EOS D60 to a televi­sion and how to set the date and time.

About Image Data Taken or Recorded by Other Devices

The EOS D60 may in some cases be unable to accurately display images taken
with other cameras, or taken with the EOS D60 but subsequently had image data or
file names modified by computer or other means.

About DPOF

DPOF (Digital Print Order Format) is a standard used to record (on the CF card or
other recording media) the image number, number of pr ints, etc. of images taken by
digital camera.

●You can simply insert the CF card into a DPOF-compatible printer to make prints

as specified.

●You will not need to fill out the desired numbers and quantities of prints when

ordering prints from a photo printing lab.

∗ This camera is compatible with DPOF Version 1.1.

5

5

Playing and Erasing Recorded Images

97

Viewing Recorded Images

The EOS D60 can display recorded images on its LCD monitor. You can view these images in
single-image format, index format, or enlarged format. Press the < > button to switch
formats.

Viewing a Single Image

Check the image.

● Press the < > button.

1

➡ The most recent single image taken by the

camera appears.

● Press the < > button again to clear the

LCD monitor and exit PLAY.

Change the displayed image.

● Turn the < > dial counterclockwise to

2

Viewing the Index

This mode displays 9 images simultaneously on a single screen.

view images in order from newest to oldest.

● Turn the < > dial clockwise to view

images in order from oldest to newest.

98

Press the < > button.

➡ The most recent single image taken by the

1

2

3

camera appears.

Display the index.

● Press the < > button.
➡ The images are displayed in index format.

Change the image selection.

➡ The selected image is surrounded by a

green frame.

● Turn the < > dial counterclockwise to

select images in order from newest to
oldest.

● Turn the < > dial clockwise to select

images in order from oldest to newest.

● Press the < > button to enlarge the

selected image. To retur n to single-image
display, press the < > button again.

● When you finish viewing, press the < >

button.

Viewing Enlarged Images

Recorded images can be enlarged approximately 3×.

Select the image you want to
enlarge from a single-image or

1

index display. (→98)
Enlarge the image.

● Press the < > button twice from a

2

Part to be enlarged

3

single-image display, or once from an index
display.

➡ The selected image is enlarged approxi-

mately 3×.

➡ The central part of the image is displayed

first.

➡ An icon in the lower right part of the image

indicates which part of the picture is
currently displayed.

Change the display area.

● Turn the < > dial

clockwise to change the
displayed area of the
picture from center to
center right to lower left.
Turn the < > dial counterclockwise to
change the displayed area of the picture
from center to center left to top right.

● When you finish viewing, press the < >

button.

Viewing Recorded Images

5

Playing and Erasing Recorded Images

JUMP

The display can jump directly to another image.

Jumping to Another Image

1
2

Jump bar

3

Image 10

frames back

Current


Image 10

frames forward

Display a single image or index.

(→98)

Change to jump display.

● Press the <
➡ The Jump bar appears.

Jump to another image.

● Turn the < > dial.
➡ From a single-image display, turn the dial

counterclockwise to go back 10 images, or
clockwise to go forward 10 images.

➡ From an index display, turn the dial

counterclockwise to go back 9 images, or
clockwise to go forward 9 images.

● Press the <

bar and exit JUMP.

● When you finish viewing, press the < >

button.

JUMP

> button.

JUMP

> button to clear the Jump

99

Viewing Recorded Images

INFO.

Turning the Information Display On and Off

When an image is displayed on the LCD monitor, you can press the <
information about that image. Image information is available only for single-image displays.

INFO.

> button to view

Image Information Displayed During PLAY

The following information is displayed:

File number (→114)
Histogram
Exposure compensation

Image (→40)
Aperture value (→128, 134)

Shutter speed (→130, 134)
Shooting mode (→18)

Image number/total images
recorded

Image protect (→103)

Quality (→50)

Date (→34) Time (→34)

Press the <

➡ Pressing the button repeatedly switches the

LCD monitor information display On and Off.

(→77)
Flash exposure
compensation (→91) (not

displayed when flash not in use)

ISO speed (→51)
Metering mode (→61)
White balance (→64)

INFO.

> button

● You can change the displayed image using

the < > dial, just as for a single-image
display.

● For settings displayed while preparing to shoot, see “Checking Camera

Settings” (→60).

● You can switch the information display On and Off by pressing the <

button, even during automated playback (Auto playback) (→101), or while
rotating (→102), or protecting images (→103).

INFO.

>

Histograms

The histogram is a graph showing brightness levels on the horizontal axis, and the number of
pixels at each level of brightness on the vertical axis. Darker pixels are towards the left side of
the graph, and brighter pixels towards the right. By looking at a histogram you can judge the
brightness of a picture after it is recorded.
If the histogram is higher towards the dark end,
set the exposure compensation (→77) towards the
plus end. If the histogram is higher towards the
light end, set the exposure compensation towards
the minus end, then take the picture again.

Sample Histograms

Normal brightnessDarker image Lighter image

Highlight Alert

When exposure information is displayed for a picture that will be overexposed, the related
settings will blink. For better results check the histogram and adjust the exposure compensa­tion towards the decreased exposure end (→77), then take the picture again.

100
