High-performance
cheque scanning
that is fast, accurate
and reliable

CR-190i / CR-190i UV

Compact Cheque Scanner /
With UV Reader

you can

Scan your cheques, coupons and vouchers
quickly and precisely with the imageFORMULA

CR-190i / CR-190i UV and boost your productivity

Specifically created for demanding commercial back-office environments like banking and retail,
these advanced scanners are rich in features designed to drive up productivity in your payment
processing or other critical workflows.

Fast, precise scanning

Rapid scanning speeds of up to 190 cheques per minute make
both the CR-190i / CR-190i UV ideal for batch scanning; while
Ultrasonic Double Feed Detection prevents misreading and
omissions. With a compact design that fits easily on any desktop,
the CR-190i / CR-190i UV are exceptionally productive devices that
deliver outstanding levels of accuracy.

Information you can trust

Both scanners are equipped with a built-in jogger that aligns
cheques in the feeder before they are scanned. For precise
simultaneous reading, Magnetic Ink Character Recognition (MICR)
is supported by Optical Character Recognition (OCR) technology,
ensuring that image data is recorded and transferred
accurately – before originals are removed from circulation.

Optimum quality outputs

The CR-190i / CR-190i UV’s new Fine Text Filtering feature ensures
that vital information is captured and unnecessary ‘noise’
eliminated: ideal when you need to capture high-quality scans
of documents with patterned backgrounds. With the auto deskew
and auto size functions, there is less need for manual quality
control, saving valuable time and cost.

Three Pocket Sorting

To give you added confidence and flexibility, the CR-190i
and CR-190i UV have a three pocket sorting system.
Two motor drive units work independently of each other,
allowing you to separate mission-specific documents into
designated output pockets.

Eject pocket three:
50 items

Eject pocket two:
200 items

Eject pocket one:
200 items

AUTOMATIC
DOCUMENT

FEEDER

250 sheets

CR-190i /

CR-190i UV

B&W

SPEED

190cpm

DAILY DUTY

CYCLE

24,000

scans/day

Flexible imprinting

A 4-line built-in imprinter for high-quality bitmap images and text
gives you a flexible choice of imprinting capabilities. Using the
Software Development Kit (SDK), the CR-190i / CR-190i UV can
improve productivity by dynamically printing on-the-fly using MICR
information before exiting to the sorting pockets.

Easy maintenance

Built for simple maintenance, the CR-190i / CR-190i UV are
designed with convenient side opening covers, to help minimise
costly downtime. This design makes tasks such as changing the
imprinter’s ink cartridge and cleaning easy to accomplish.

Straightforward integration

Both CR-190i / CR-190i UV include Scanning Utility software,
a Ranger driver and also ISIS and TWAIN drivers, allowing
organisations to use the devices across a broad range of scanning
applications. In addition, various Software Development Kits (SDK)
are available for partners to create customised scanning applications
for their customers.

CR-190i UV: increasing payment
processing security

The imageFORMULA CR-190i UV model is equipped with
UV sensors that can scan anti-fraud patterns printed on
cheques with UV ink. It allows two images to be captured
simultaneously – a black and white or greyscale image and
a UV image – at a high-speed rate of up to 160cpm.

The CR-190i UV is ideal for cheque-fraud detection while
offering the same efficient cheque processing capabilities
of the CR-190i.

Specification: imageFORMULA CR-190i & CR-190i UV

Type

Document Reading

Sensor

Optical Resolution

Light Source

Reading Side

Interface

Dimensions

Weight

Power Requirements

Power Consumption

Operating Environment

Environmental Compliance

READING SPEED*

(American Cheque, 200dpi)

B & W

Greyscale

DOCUMENT

SPECIFICATIONS

Width

Length

Thickness

Paper separation

Sorting Pockets

Feeder Capacity

Desktop Type Sheet Fed Scanner
CMOS CIS Sensor
1200dpi
CR-190i: RGB LED
CR-190i UV: UV LED
CR-190i: Simplex / Duplex
CR-190i UV mode: Front only
High speed USB 2.0
Tray closed: 476 (W) × 272 (D) × 214 (H) mm
Approx. 8.4Kg
AC220 – 240V (50 / 60Hz)

CR-190i:

Scanning: 52.8W
Sleep Mode: less than 4.7W

CR-190i UV:

Scanning: 47.1W
Sleep Mode: less than 3.8W
10 – 32.5°C (50 – 90.5°F), Humidity: 20 – 80% RH
RoHS and ENERGY STAR

CR-190i / CR-190i UV CR-190i UV Mode

190 cpm (simplex) / 190 cpm (duplex)

190 cpm (simplex) / 190 cpm (duplex) 160 cpm

68 – 108 mm
120 – 245 mm
Automatic feeding: 64 – 157g/m² (0.08 – 0.2 mm)
Corrugation Retard Roller Method
3 Output Pockets (200 sheets x 2, 50 sheets x 1)
250 sheets

®

160 cpm

PRODUCT FEATURES

BUNDLED SOFTWARE

Suggested Daily Duty Cycle

* Actual scanning speed may vary depending on your system configuration and PC specification.

Some images are simulated for clarity of reproduction. All data is based on Canon’s standard
testing methods. This leaflet and the specifications of the product have been developed
prior to the date of product launch. Final specifications are subject to change without notice.
™ & ®: All company and/or product names are trademarks and/or registered trademarks
of their respective manufacturers in their markets and/or countries.

OUTPUT

Mode

Optical Resolution

Imprinter

MICR/OCR

Options

Consumables

Black and White, Error Diffusion, Fine Text Filtering,
Greyscale: 4 Bit / 8 Bit
CR-190i: 100 x 100dpi, 120 x 120 dpi, 150 x 150dpi,
200 x 200dpi, 240 x 240 dpi, 300 x 300dpi
CR-190i UV: 100 x 100dpi, 120 x 120dpi, 150 x 150dpi,
200 x 200dpi

Deskew, Auto Page Size Detection, Ultrasonic Double
Feed Detection, Colour Dropout (RGB), CR-190i UV (R) /
Enhancement CR-190i (R), Background Colour: CR-190i
(White), CR-190i UV (Black), Edge Emphasis, Preset Gamma
Curve, Scan Area Setting, Batch Seperation, Continuous Scanning,
Image Quality Assurance function, Jogger Function
Dynamic Imprinting, 4-line, Can print bitmap, Ink level
detection & warning

ISIS/TWAIN Driver
Canon Scanning Utility for CR-190i (Incl. Canon Scanner Driver)
Ranger Driver
MICR: E13B / CMC7, OCR: E13B / OCR-A / OCR-B
SDK: CR-SDK / CR-SDK.NET / Ranger (Ranger API)

Exchange Roller Kit
Ink Disposal Tank
Approx. 24,000 sheets / day
