Type: Digital, Multifunction Imaging System
Imaging System: Laser Dry Electrostatic Transfer
Developing System: Dry Mono Component Toner
Projection
Fixing System: RAPID Fusing System™
Image Server Memory: Standard 512MB RAM/20GB HDD
First-copyTime: 3.9 Secondsfrom Platen Glass
5.9 Seconds from Feeder
Warm-up Time: 10Secondsor Lessfrom Sleep Mode
30 Secondsfrom Main Power Off
Copy/PrintSpeed: Up to 35/45 ppm (Letter)
Max. Mail Boxes Supported: 100
Max. CopyReservation: 5 Jobs
Actual Resolution: 600 dpi x 600 dpi
Interpolated Resolution: 1200 dpi x600 dpi (Copy)
2400 dpi x600 dpi (Print)
Halftone: 256 Gradationsof Gray
Duplexing: Standard AutomaticTrayless
Duplexing
Magnification Reduction/
Enlargement: 25% to 400% — Platen
25% to 200% — Feeder
(in 1% increments)
Exposure Control: Automatic or Manual (9 levels)
Paper Sources
Standard: Dual 550-sheet Paper Cassettes
(1,100 Sheets)
StackBypass(50 Sheets)
Optional: 2,500-sheet Paper Deck (20 lb. Bond)
Dual 550-sheet Cassette Feeding Unit
(4,750 Sheets Max.)
Multiple Copies: 1 to 999
Paper Weights: 17lb. to 20 lb. Bond (Cassette)
17 lb. to 32 lb. Bond (Stack Bypass)
Network Interface
Connections: 10/100Base-T (RJ-45)
Dimensions(H x W x D): 29-7/8" x 22-1/4" x 27-5/8"
(761mm x 565mm x 700mm)
Installation Space: (WxD): 34" x 27-5/8"
Weight: 136 lb. (61.6kg)
Power Requirements: 120V AC, 60Hz, 10A
Power Consumption: 1.35kW (Max.)
Toner Yield: 24,000@ 6% Coverage
Optional Accessories
UniversalSend Kit-B1
Sending Methods: E-mail, I-fax, Super G3 Fax (Optional),
User Inbox, File Server (IPX, FTP, SMB)
AddressBook Capacity: Max. 1,800 Destinations
Max. 5 LDAP Servers
File Format: TIFF, PDF, Optional PDF (OCR)
Sending Sizes: Statementto 11" x 17"
Duplexing AutomaticDocument Feeder-N1
Acceptable Originals: Statement to 11" x 17"
Capacity: 50 Sheets (20 lb. Bond/Letter)
Max. Paper Weight: 13 lb. to 32 lb. Bond
Scanning Speed: Up to 28 Images per Minute (ipm)
(Letter @ 600 dpi), 45 ipm (Letter @
300 dpi)
Power Source: From Main Unit
Dimensions(H x W x D): 8-7/8" x 22-1/4
" x 21-1/4"
(122mm x 565mm x 538mm)
Weight: Approx. 18.7 lb. (8.5kg)
Cassette Feeding Unit-Y2
Paper Capacity: Dual 550-sheet Paper Cassettes
(1,100 Sheets/20 lb. Bond)
Acceptable Paper Sizes: Statement-R to 11" x 17"
Acceptable Paper Weights: 17 lb. to 20 lb. Bond
Power Source: From Main Unit
Dimensions(H x W x D): 9-7/8" x 22-1/4" x 27-5/8"
(251mm x 565mm x 700mm)
Weight: Approx. 50.7 lb. (23kg)
Envelope Feeder Attachment-C1
CopySpeed: 12 cpm (AllEnvelopes)
Acceptable Envelopes: COM10, DL, Monarch, ISO-B5,
ISO-C5, Yougata-4
Feeder Capacity: Approx. 50 Envelopes
or 1-1/4" (31.75mm)
Dimensions(H x W x D): 3-1/4" x 12-1/8" x 11-5/8"
(82mm x 306mm x 295mm)
Weight: Approx. 2.4 lb (1.1kg)
Paper Deck-Q1
Paper DeckCapacity: 2,500Sheets(20 lb. Bond)
Paper Size: Letter
Acceptable Paper Weights: 17lb. to 20 lb. Bond
Power Source: From the Main Unit
Dimensions(H x W x D): 18-5/8" x 14-5/8" x 23-1/4"
(473mm x 372mm x 591mm)
Weight: Approx. 65.3 lb (29.6kg)
Inner 2-Way Tray-D1
Number ofTrays: Two
TrayCapacity
Lower OutputTray: 250 Sheets (Letter)
100Sheets(Other Sizes)
Upper OutputTray: 100 Sheets (Letter)
50 Sheets (Other Sizes)
Acceptable Paper Sizes: Statement to 11" x 17"
Dimensions(H x W x D): 6" x7"x 21-1/2
"
(151mm x 176mm x 546mm)
Weight: Approx. 8.6 lb (3.9kg)
Attachable Accessories: Copy Tray-J1
Finisher-S1
Number ofTrays: One (Second TrayOptional)
TrayCapacity
Non-collate, Collate,
Group Mode: 1,000Sheets (Letter, Statement)
500 Sheets (11" x 17", Legal, Letter-R)
Staple Mode: 1,000 Sheets/30 Sets (Letter)
500 Sheets/30 Sets (11" x 17",
Legal, Letter-R)
TrayCapacity
(with Additional Finisher Tray-B1)
Non-collate, Collate,
Group Mode: 300Sheets per Tray (Letter,
Statement)
Staple Mode: 300 Sheets/30 Setsper Tray(Letter)
150 Sheets/per Tray(11" x 17",
Legal, Letter)
150 Sheets/30 Sets (11" x17", Legal)
Staple Position/Size: Corner Stapling
(11" x 17", Legal, Letter, Letter-R)
Max. Stapling Capacity: 50 Sheets (Letter-Up to 20 lb. Bond)
Power Source: From Main Unit
Dimensions(H x W x D): 11-7/8" x 18-7/8" x 20-1/2"
(300mm x 480mm x 520mm)
Weight: Approx. 26.5 lb. (12kg)
Attachable Accessories: Additional Finisher Tray-B1
Puncher Unit-R1
CopyTray-J1
AdditionalFinisher Tray-B1 (Option for Finisher-S1)
Dimensions(H x W x D): 3-1/8" x 7-7/8" x 15-5/8"
(80mm x 200mm x 395mm)
Weight: Approx. 3.7 lb. (1.7kg)
Puncher Unit-R1 (Option for Finisher-S1)
Max. Paper Weight: 17 lb. to 32 lb. Bond
Paper Sizes
2-hole: Legal, Letter-R
3-hole: 11" x17", Letter
Punch Method: Sequential Processing System
Punch DustStock
2-hole: 2,500 Sheets
3-hole: 1,500 Sheets
Power Source: From Main Unit
Dimensions(H x W x D): 6-7/8" x 19-7/8" x 5-1/8"
(175mm x 505mm x 130mm)
Weight: Approx. 8.6 lb. (3.9kg)
CopyTray-J1 (Option for Inner 2-Way Trayand Finisher-S1)
TrayCapacity: 150 Sheets (Letter)
75 Sheets (Other Sizes)
Dimensions(H x W x D): 4-3/4" x 13-5/8" x 13-7/8"
(120mm x 347mm x 351mm)
Weight: Approx. 1 lb. (471kg)
imageRUNNER 3570/4570 Specifications
EXPERIENCE A BREAKTHROUGH IN MULTIFUNCTION TECHNOLOGY
Your growing business can no longer conform to the rigid workflow processes forced upon it byyesterday’s office
technology. You need an office solution that can be shaped around your specific needs. Now you can have it with
the Canon imageRUNNER
®
3570 device and imageRUNNER 4570 device.
Take control of your office workflow with these new-generation Canon imageRUNNER devices. Delivering output at speeds of
up to 35 and 45 pages per minute (Letter), respectively, the imageRUNNER 3570 and imageRUNNER 4570 devices support
advanced digitalcopying and Mail Box features, network printing and scanning functions, Super G3 fax capabilities,* and the
ability to send electronic information across a digital landscape. Featuring Canon’s MEAP
®
(Multifunctional Embedded
Application Platform) technology and a host of Internet-enabled capabilities, these devices offer the tightest possible integration across entire corporate networks so you can streamline costs and improve efficiency.
Page 3
Finisher-Q3
Number ofTrays: Two
TrayCapacity
Non-collate, Collate,
and Group Mode: 1,000 Sheets (Letter, Statement,
Executive)
500 Sheets (11" x 17", Legal, Letter-R)
Staple Mode: 1,000 Sheets/30 Sets (Letter,
Executive)
500 Sheets/30 Sets (11" x 17", Legal,
Letter-R)
Max. Stapling Capacity: 50 Sheets (Letter, Executive)
30 Sheets (11" x 17", Legal, Letter-R)
Staple Position: Any Corner Staple
Double Staple in Rightor Left Margin
Power Source: From Main Unit
Dimensions(H x W x D): 40-3/4" x 25-3/8" x 25-7/8"
(1,036mm x 643mm x 657mm)
Weight: Approx. 91.7 lb. (41.6kg)
Attachable Accessories: Puncher Unit-M1
Saddle Finisher-Q4
Number ofTrays: Two
TrayCapacity
Non-collate, Collate,
and Group Mode: 1,000 Sheets (Letter, Statement,
Executive)
500 Sheets (11" x 17", Legal, Letter-R)
Staple Mode: 1,000 Sheets/30 Sets (Letter)
500 Sheets/30 Sets (11" x 17", Legal,
Letter-R)
Max. Stapling Capacity: 50 Sheets (Letter, Executive)
30 Sheets (11" x 17", Legal, Letter-R)
Staple Position: Any Corner Staple
Double Staple in Rightor Left Margin
Saddle-stitch (Center Staple)
Saddle-stitch
Acceptable Paper Sizes: 11" x17", Legal, Letter-R
Capacity/Tray: 1 to 5 Sheets/25 Sets
6 to 10 Sheets/15 Sets
11 to 15 Sheets/10 Sets
Max. Stapling Capacity/Set: 15 Sheets
Folding: V-fold
Power Source: From Main Unit
Dimensions(H x W x D): 40-3/4" x 29-3/4” x 25-7/8"
(1,036mm x 756mm x 657mm)
Weight: Approx. 162 lb. (73.4kg)
Attachable Accessories: Puncher Unit-M1
Puncher Unit-M1 (Option for Finisher-Q3 and Saddle Finisher-Q4)
Max. Paper Weight: 17 lb. to 32 lb. Bond
Paper Sizes
2-hole: Legal, Letter
3-hole: 11" x17", Letter, Executive
Punch Method: Sequential Processing System
Punch Types: 2-hole/3-hole (Auto Change)Punch
Dust Stock: Approx. 3,000 Sheets
Power Source: From Main Unit
Dimensions(H x W x D): 34-1/8" x 4-1/4" x 24-1/2"
(941mm x 107mm x 614.8mm)
Weight: Approx. 15.9 lb. (7.2kg)
Super G3 Fax Board-Q1/G3 Multi-Line Fax Board-D1
Applicable Line: PublicSwitched Telephone
Network(PSTN)
Connection Lines
Super G3 FaxBoard-Q1: One
Super G3 Multi-Line FaxBoard-D1: Two
Sending/OriginalSizes: Statement to 11" x17"
(from Document Feeder)
Recording/Printing Sizes: Statement to 11" x 17"
Transmission Times*
ECM-MMR: Approx. 3.2 Seconds
G3MR: Approx. 13 Seconds
G3MH: Approx. 13 Seconds
JBIG: Approx. 2.6 Seconds
Scan Line Density
Standard: 8 pels/mm x 3.85 lines/mm
Fine: 8 pels/mm x 7.7 lines/mm
Super-fine: 8 pels/mm x 15.4 lines/mm
Ultra-fine: 16 pels/mm x15.4 lines/mm
Auto Dial Function: Address Book: 1,800 Destinations
Image Memory: Approx. 8,000 Pages
Multi-PDLPrinter Kit-E1
Processor: Canon Custom Processor—Shared
RAM: 512MB—Shared
Hard Disk: 20GB—Shared
PDLSupport: PCL 5
e, PCL 6, PostScript®3™
Emulation, UFR II
Interface Connections
Standard: RJ-45 (10/100Base-T), USB 2.0
High-speed
NetworkOS: Windows
®
98/Me/2000/XP
WindowsNT
®
4.0/Server 2003
Macintosh
®
OS 8.0 or Later (PPD)
Solaris™ 1.1x, 2.5x, or Later
Novell
®
NetWare®v3.2, 4.1, 4.11, 4.2,
5, 5.1, 6, 6.5 (IPX/SPX™)
Print Drivers
UFR II: Windows2000/XP; WindowsServer
2000, CitrixMetaFrame, Macintosh
OSX (OS 10.1.5 or Later)
PCL 5e/6: Windows98/Me/2000/XP
WindowsNT 4.0/Server 2003
CitrixMetaFrame
PS 3 Emulation: Windows98/Me/2000/XP
WindowsNT 4.0/Server 2003
CitrixMetaFrame
Macintosh OSX (OS 10.2 or Later)
Internal Fonts: PS: 136 Scalable Fonts
PCL 5e/6: 80 Scalable Fonts
30 Bar code Fonts, 2 OCR Fonts
10 Bitmap Fonts
Utility Software: NetworkScanGear
Remote UI
Netspot Console
Netspot Job Monitor
Netspot Resource Downloader
Netspot Device Installer
USB Class Driver
Fax Driver
JBIG ImageViewer
Canon LPR 2
Canon NDPSGateway
Canon FontManager
BMC PATROL
®
CA Unicenter
®
Tivoli®NetView
®
HP Web Jetadmin
HP OpenView
Microsoft
®
Management Console
Canon WatermarkAdd-in
DSE(Device StatusExtension)
Address Book Conversion Utility
Other Optional Accessoriesand Utilities
Platen Cover Type H
Cabinet-P1
AccessibilityHandle-A1
Braille Label Kit-A1
Document Tray-J1
Card Reader-C1
Card Sets
UniversalSend PDF Enhancement Kit-B1
imageRUNNER Security Kit-A2
eCopySuite/ShareScan OP
Web AccessSoftware-A1**
Remote Operator’sSoftware Kit-A1**
Bar Code Printing Kit-A1**
Voice Guidance Kit-A2**
Removable HDD Kit**
* Approximate 3-second-per-page faxtransmission time based on ITU-T
No. 1 Chart (MMR, Standard Mode) at 33.6 Kbps modem speed when
transmitting to another V.34 machine. The Public Switched Telephone
Network (PSTN) currently supports 28.8 Kbps modem speeds or lower,
depending on telephone line conditions.
** Check with your localAuthorized Canon Dealer for availability.
imageRUNNER 3570/4570 Specifications (continued)
Saddle Finisher-Q4 Finisher-Q3
Puncher
Unit-M1
Main Unit
Cassette Feeding
Unit-Y2
Inner 2-way
Tray-D1
Finisher-S1
Additional
Finisher Tray-B1
Cabinet
Paper Deck-Q1
CopyTray-J1
DADF-N1
Platen Cover Type H
Page 4
As an ENERGY STAR®Partner, Canon U.S.A., Inc. hasdetermined thatthese products meet the ENERGY
STAR®guidelines for energy efficiency. ENERGYSTARand the ENERGY STAR mark are registered U.S.
marks. eCopyShareScan isa trademarkofeCopy, Inc. PostScriptisa registered trademarkofAdobe
Systems Incorporated in the United States and/or other countries. Microsoft, Windows, and
Windows NT are registered trademarks of Microsoft Corporation in the United States and/or other
countries. Macintosh isa registered trademarkofApple Computer, Inc. Solarisisa trademarkofSun
Microsystems, Inc. in the United States and other countries. Novell and NetWare are registered
trademarks of Novell, Inc. in the United States and/or other countries. IPX/SPX is a trademark of
Novell, Inc. PATROL is a registered trademark of BMC Software in the United States. Unicenter is a
registered trademark of Computer Associates International, Inc. Tivoli and Netview are registered
trademarksof IBM in the United States. CANON, IMAGERUNNER, MEAP, and NETSPOT are registered
trademarks, and UNIVERSALSEND, RAPID FUSINGSYSTEM, and the GENUINElogo are trademarksof
Canon Inc. in the United Statesand mayalso be registered trademarksor trademarksin other countries. REMOTEUI isa trademarkofCanon U.S.A., Inc. IMAGEWAREisa registered trademarkofCanon
U.S.A., Inc. in the United States and is a trademark of Canon Inc. in certain other countries.
IMAGEANYWARE is a trademark of Canon. All referenced product names and other marks are trademarks of their respective owners.
All specifications are subject to change withoutnotice.
©2006 Canon U.S.A., Inc. All rights reserved.
Some products shown with optional accessories and equipment.
1-800-OK-CANON
www.usa.canon.com
Canon U.S.A., Inc.
One Canon Plaza
Lake Success, NY11042
0106R-3570/4570-PDF-NW
Loading...
