Page 1
•
High-performance cheque scanners
perfect for centralised batch
scanning
Processing eciency
Improve cheque, vouchers and coupons processing
eciency with one device combining stack
alignment (CR-190i II series only), scanning,
MICR reading, endorsement printing and sorting
operations.
Smart UV scanning
For added flexibility, choose the dedicated
UV model that includes built-in UV sensors for
scanning anti-fraud patterns printed on cheques.
UV scanning enables you to easily capture two
images simultaneously: a black-and-white (or
greyscale) image and a UV image.
CR-135i II series
B&W
SPEED
135 cpm
BUILT-IN
endorsement
IMPRINTER
DA I LY D U T Y
CYCLE
24,000 SCANS/DAY
AU TO M AT I C
DOCUMENT FEEDER
250 sheets
CR-190i II series
B&W
SPEED
190 cpm
BUILT-IN
endorsement
IMPRINTER
DA I LY D U T Y
CYCLE
24,000 SCANS/DAY
AU TO M AT I C
DOCUMENT FEEDER
250 sheets
AU TO M AT I C
CHEQUE
ALIGNMENT
Page 2
imageFORMULA CR-135i II and CR-190i II series
Versatile, high-speed scanning
Enjoy fast, ecient and reliable batch scanning of cheques,
vouchers and coupons with the Canon imageFORMULA
CR-135i II and CR-190i II scanners. Banks and retailers will
find its accurate scanning, at speeds of up to 135 and 190
cheques per minute respectively, oers a great way to increase
productivity in back oce workflows.
Precise MICR reading
You’re assured that cheque data will be read correctly first
time, with 99.999%* read accuracy, thanks to the scanner’s
Magnetic Ink Character Recognition (MICR) supported by
simultaneous Optical Character Recognition (OCR).
Reliable feeder
Reduce misreading and omissions with the high capacity
250-sheet document feeder that oers ultrasonic double
feed detection. To keep your workflows even more ecient,
scanned cheques can be sorted into three output pockets,
based on MICR and OCR data.**
Eortless imprinting
Quickly and easily print endorsement on the back of cheques
while scanning using the built-in imprinter. Up to four
48-character lines of text, as well as bitmap images, can be
printed in high quality in just a single motion, helping you
sustain a high standard of productivity.
Convenient one-button cheque alignment (CR-190i II series)
Save the time of manually aligning batches of cheques prior to
scanning, or the cost of a separate unit, with the built-in cheque
jogger. It aligns cheques in the CR-190i II’s feeder before
scanning, ensuring that all your MICR data is read accurately.
Easy maintenance
* Based on Canon testing
** Depe nding on the capabilities of the application used
Page 3
Advanced image processing
Capture both printed and handwritten text accurately
every time. Fine Text Filtering technology significantly
reduces unwanted noise from patterned document
background colours or images.
RAPID,
RELIABLE
SCANNING
AND COMPACT
DESIGN
Three Pocket Sorting
Scanned cheques can be automatically
sorted based on MICR and OCR data
(application support required) between
three available pockets. Two of them can
hold 200 and third one 50 cheques.
Simple integration
Easily integrate with a range of scanning applications
using the bundled software drivers: Canon Scanning
Utility, Canon ISIS / TWAIN driver and a driver based
on Silver Bullet Technology’s Ranger Transport API
software. Application developers can take advantage of
the SDK to create custom capabilities.
Page 4
•
Technical Specifications
CR-135i II / CR-135i II U V CR-19 0i II / CR -190 i II UV
Scanner Type Cheque Scanner with automatic sheet feeding Cheque Scanner with automatic sheet feeding and alignment
Interface Hi-Speed USB 2.0 Hi-Speed USB 2.0
Daily duty cycle Approx . 24,000 sca ns/day Approx . 24,000 sca ns/day
Dimensions (WxDxH) 476 x 272 x 214 m m 476 x 272 x 214 m m
Weight (Kg) Approx. 8.0 Kg Approx . 8.4 Kg
Scanning sensor unit CMOS CIS CMOS CIS
Optical resolution 1200 dpi 1200 dpi
Light source CR-135 i II - RGB L ED
Black and white spe ed CR-135 i II - 135cpm (cheques/min)
Output resolution 100 dpi, 120 d pi, 15 0 dpi, 200 dpi , 240 dpi , 300 dpi
Output mode Blac k and White
Special features Deskew
Width 68 - 108 mm 68 - 108 mm
Length 120 - 245 mm 120 - 245 mm
Thickness and weight 0.08 - 0.2 mm
Scanning side CR-135 i II - Simplex / Duplex
Paper separation Corru gation Retard Roller M ethod Corru gation Retard Roller M ethod
Feeder capacity 250 sheets or 25 mm stack 250 sheets or 25 m m stack
Windows ISIS / TWAIN Driver for Wind ows XP / Vis ta / 7 / 8 / 8.1 / 1 0
MICR E13B / C MC-7 E13B / CMC-7
OCR E13B / O CR-A / OC R-B / Cheque Writer / Universal Chara cter E13B / OC R-A / OCR-B / Cheque Write r / Universal Ch arac ter
SDK CR-SD K / CR-SD K.NET / Ra nger (Range r API) CR-SD K / CR-SD K.NET / Ra nger (Range r API)
Power requirements AC220 - 240V (50 / 60 Hz) AC220 - 240V (50 / 60 Hz)
Power consumption Scanning: 4 3W or less
Operating environment Temperature: 10 - 32.5°C
Environmental
compliance
Consumables Exchange Roller Kit
CR-135 i II UV - RG B LED an d UV LED
CR-135 i II UV - 13 5cpm ( 120cpm in UV m ode)
Up to 200 d pi in UV mode (CR-13 5i II UV)
Error Diusion
Fine Text Filtering
Greyscale (1 6 and 256-level)
UV scan (CR-135i I I UV)
Auto Page Size Detection
Ultrasonic Double Feed Detection
Colou r Dropout (R/G/B)
64 - 157 g /m²
CR-135 i II UV - Simplex / D uplex / Fro nt only in UV mode
Canon Scanning Utility
Ranger Driver
Sleep Mode: 2 .7W or less
Humidity: 2 0 - 80% RH
RoHS and ENERGY STAR RoHS and E NERGY STAR
Ink Disposal Tank
Black Ink Cartrid ge for im printe r:
PG-5 45 / PG -545XL / PG -445 / PG- 445X L
CR-19 0i II - RG B LED
CR-19 0i II UV - RGB LED and UV LED
CR-19 0i II - 190cp m (cheque s/min)
CR-19 0i II UV - 190cpm (1 60cpm in UV mo de)
100 dpi, 120 d pi, 15 0 dpi, 200 dpi , 240 dpi , 300 dpi
Up to 200 d pi in UV mode (CR-190i II UV)
Black and White
Error Diusion
Fine Text Filtering
Greyscale (1 6 and 256-level)
UV scan (CR-190 i II UV )
Deskew
Auto Page Size Detection
Ultrasonic Double Feed Detection
Colou r Dropout (R/G/B)
0.08 - 0.2 mm
64 - 157 g /m²
CR-19 0i II - Simplex / D uplex
CR-19 0i II UV - Simplex / Duplex / Front only in UV mo de
ISIS / T WAIN Driver for Windows XP / Vista / 7 / 8 / 8 .1 / 10
Canon Scanning Utility
Ranger Driver
Scanning: 49W or less
Sleep Mode: 2 .7W or less
Temperature: 10 - 32.5°C
Humidity: 2 0 - 80% RH
Exchange Roller Kit
Ink Disposal Tank
Black Ink Cartrid ge for im printe r:
PG-5 45 / PG -545XL / PG -445 / PG- 445X L
All data i s based on C anon standa rd testing m ethods exc ept wher e indica ted and su bject to c hange wi thout no tice.
