Canmax CM-520 User Manual

CM-520 Multi

Function Bluetooth

Barcode Scanner User

manual.

Copy Right 2015.08.24©

2

1. Important Notice

Chapter 1: Import Notice ............................................................................. 20

1-1 Regulations ..................................................................................... 17

1-2 TECHNICAL REGULATIONS CONFORMITY FOR SPECIFIED

RADIO EQUIPMENT IN JAPAN ..................................................... 17

1-3 NATIONAL COMMUNICATION COMMISSION ............................... 18

1-4 RoHS DIRECTIVE ............................................................................ 18

1-5 SAFTY PRECAUTION ..................................................................... 19

Chapter 2: Introduction ............................................................................... 20

2-1 PRODUCT FEATURES .................................................................... 21

2-2 PRODUCT SPECIFICATION ........................................................... 22

2-3 PACKAGE INFORMATION .............................................................. 23

2-4 DEFAULT SYMBOLOGIES .............................................................. 24

2-5 FUNCTION KEYS AND LED INDICATOR ....................................... 25

2-6 QUICK START GUIDE ..................................................................... 27

Chapter 3: Scanner Configuration .............................................................. 28

3-1 Configuration by USER MANUAL.................................................. 29

3-2 Configuration by SOFTWARE ........................................................ 30

Chapter 4: Memory / Bluetooth Mode ........................................................ 31

4-1 Memory Mode ................................................................................. 32

4-1-1 Function switch (Bluetooth mode to Memory mode) ........... 32

4-1-2 Transmitting barcode data in memory mode ....................... 32

4-1-3 Erase barcode data (single data/ all data) .......................... 33

4-2 Bluetooth Mode .............................................................................. 34

4-2-1 Function switch (Memory Mode to Bluetooth mode) ........... 34

4-2-2 LED indication under Bluetooth Mode ................................ 35

4-2-3 Bluetooth mode selection Code Table ................................ 36

4-2-4 Bluetooth mode configuration by user manual .................... 37

4-2-4-1 Slave Mode : Third party Bluetooth devices ( Mode

selection code: 1) .................................................. 37

4-2-4-2 Master Mode - Third party Bluetooth devices (Mode

selection code: 2) .................................................. 37

4-2-4-3 HID Mode - For third party Bluetooth devices (Mode

selection code: 3) .................................................. 38

4-2-4-4 Hid-iOS MODE (Mode selection code : 4) ............ 38

4-2-4-5 A-302 dongle Mode (Mode selection code: 5) ....... 39

4-2-4-6 A-302 dongle Mode (Mode selection code: 6) ....... 39

4-2-4-7Spp-A303PT Mode (Mode selection code: 7)........40

4-2-5 Bluetooth parameter configuration by manual .................... 41

4-2-5-1 BT Local name ................................................... 41

4-2-5-2 Remote Mac Address ......................................... 43

3

1. Important Notice

4-2-5-3 Pin Code ............................................................ 45

Chapter 5: Bluetooth Connection Mode Instruction ................................. 46

5-1 Slave mode Connection (For Third party Bluetooth devices) ..... 47

5-2 Master mode Connection (For third party Bluetooth Devices) ... 52

5-3 HID mode Connection (For Third party Bluetooth devices) ........ 57

5-4 HID iOS mode Connection ............................................................. 61

5-5 A-303 Dongle mode Connection(USB-HID / USB COM) ............... 65

5-5-1 HID mode............................................................................ 65

5-5-2 USB-COM mode ................................................................. 66

5-6 A-302 Dongle mode connection (USB-HID only) .......................... 68

5-7 Spp-A303PT mode connection (USB-COM only) ......................... 69

Chapter 6: Memory / Bluetooth General Setting ....................................... 70

6-1 General Memory Mode Setting ...................................................... 74

6-1-1 Mode ................................................................................... 74

6-1-2 Output Interface .................................................................. 75

6-1-3 Scan Activation Time .......................................................... 76

6-1-4 Composite Triggers Functionality ........................................ 76

6-1-5 Small Trigger Functionality .................................................. 77

6-1-6 Battery Charge .................................................................... 77

6-1-7 Power Saving Time ............................................................. 78

6-1-8 Stand by Time ..................................................................... 79

6-1-9 Headr/Footer ....................................................................... 80

6-1-10 Date &Time Transmission ................................................. 81

6-1-11 Date &Time Delimiter ........................................................ 81

6-1-12 Delimiter Content .............................................................. 82

6-1-13 Transmission Length ......................................................... 82

6-1-14 Reject Same ..................................................................... 83

6-1-15 Good Read Beep .............................................................. 83

6-1-16 Warning Beep ................................................................... 84

6-1-17 Normal Beep ..................................................................... 84

6-1-18 Good Read Vibrator .......................................................... 85

6-1-19 Warning Vibrator ............................................................... 85

6-1-20 Normal Vibrator ................................................................. 86

6-1-21 Viberator Time .................................................................. 86

6-1-22 Force Case ....................................................................... 87

6-1-23 Transmission Code ID ....................................................... 87

6-1-24 Code ID Position ............................................................... 88

6-1-25 Transmission Code Name ................................................. 88

6-1-26 Good Read Volume .......................................................... 89

6-1-27 Warning Beep Volume ...................................................... 89

4

1. Important Notice

6-1-28 Normal Volume ................................................................. 90

6-1-29 Double Confirm ................................................................. 90

6-1-30 Date/Time Position ........................................................... 91

6-1-31 Preamble Code ................................................................. 91

6-1-32 Preamble Content ............................................................. 92

6-1-33 Postamble Code ............................................................... 92

6-1-34 Postamble Content ........................................................... 93

6-1-35 Prefix Code ....................................................................... 93

6-1-36 Prefix Content ................................................................... 94

6-1-37 Suffix Code ....................................................................... 94

6-1-38 Suffix Content ................................................................... 95

6-1-39 Control Characters ............................................................ 95

6-1-40 Delimiter Code .................................................................. 96

6-1-41 Transmission Unit ............................................................. 96

6-1-42 Transmission Data All Delete ............................................ 97

6-2 General Bluetooth Mode Setting ................................................... 98

6-2-1 Mode ................................................................................... 98

6-2-2 Output Interface .................................................................. 99

6-2-3 Scan Activation Time ........................................................ 100

6-2-4 Composite Triggers Functionality ...................................... 100

6-2-5 Small Trigger Functionality ................................................ 101

6-2-6 Battery Charge .................................................................. 101

6-2-7 Power Saving Time ........................................................... 102

6-2-8 Stand by Time ................................................................... 103

6-2-9 BT Pairing ......................................................................... 103

6-2-10 BT Pairing Time .............................................................. 104

6-2-11 Good Read Beep ............................................................ 104

6-2-12 Warning Beep ................................................................. 105

6-2-13 Normal Beep ................................................................... 105

6-2-14 Good Read Vibrator ........................................................ 106

6-2-15 Warning Vibrator ............................................................. 106

6-2-16 Normal Vibrator ............................................................... 107

6-2-17 Viberator Time ................................................................ 107

6-2-18 Transmission Length ....................................................... 108

6-2-19 Force Case ..................................................................... 108

6-2-20Transmission Code ID...................................................... 109

6-2-21 Code ID Postition ............................................................ 109

6-2-22 Transmission Code Name ............................................... 110

6-2-23 Good Read Volume ........................................................ 110

6-2-24 Warning Volume ............................................................. 111

5

1. Important Notice

6-2-25 Normal Volume ............................................................... 112

6-2-26 Beep Tone....................................................................... 113

6-2-27 Beep Time ...................................................................... 113

6-2-28 Double Confirm ............................................................... 114

6-2-29 Date/Time Position ......................................................... 114

6-2-30 Preamble Code ............................................................... 115

6-2-31 Preamble Content ........................................................... 115

6-2-32 Postamble Code ............................................................. 116

6-2-33 Postamble Content ......................................................... 116

6-2-34 Prefix Code ..................................................................... 117

6-2-35 Prefix Content ................................................................. 117

6-2-36 Suffix Code ..................................................................... 118

6-2-37 Suffix Content ................................................................. 118

6-2-38 Control Characters .......................................................... 119

6-2-39 Delimiter Code ................................................................ 119

6-2-40 Delimiter Content ............................................................ 120

6-2-41 Reject Same ................................................................... 120

6-2-42 Date &Time Transmission ............................................... 121

6-2-43 Date &Time Delimiter ...................................................... 121

6-3 General Cable Mode Setting ........................................................ 122

6-3-1 Mode ................................................................................. 122

6-3-2 Output Interface ................................................................ 123

6-3-3 Scan Activation Time ........................................................ 123

6-3-4 Composite Triggers Functionality ...................................... 124

6-3-5 Small Trigger Functionality ................................................ 124

6-3-6 Battery Charge .................................................................. 125

6-3-7 Power Saving Time ........................................................... 125

6-3-8 Stand by Time ................................................................... 126

6-3-9 Date &Time Transmission ................................................. 127

6-3-10 Date &Time Delimiter ...................................................... 127

6-3-11 Reject Same ................................................................... 128

6-3-12 Good Read Beep ............................................................ 128

6-3-13 Warning Beep ................................................................. 129

6-3-14 Normal Beep ................................................................... 129

6-3-15 Good Read Vibrator ........................................................ 130

6-3-16 Warning Vibrator ............................................................. 130

6-3-17 Normal Vibrator ............................................................... 131

6-3-18 Viberator Time ................................................................ 131

6-3-19 Transmission Length ....................................................... 132

6-3-20 Force Case ..................................................................... 132

6

1. Important Notice

6-3-21Transmission Code ID...................................................... 133

6-3-22 Code ID Postition ............................................................ 133

6-3-23 Transmission Code Name ............................................... 134

6-3-24 Good Read Volume ........................................................ 134

6-3-25 Warning Volume ............................................................. 135

6-3-26 Normal Volume ............................................................... 136

6-3-27 Beep Tone....................................................................... 137

6-3-28 Beep Time ...................................................................... 137

6-3-29 Double Confirm ............................................................... 138

6-3-30 Date/Time Position ......................................................... 138

6-3-31 Preamble Code ............................................................... 139

6-3-32 Preamble Content ........................................................... 139

6-3-33 Postamble Code ............................................................. 140

6-3-34 Postamble Content ......................................................... 140

6-3-35 Prefix Code ..................................................................... 141

6-3-36 Prefix Content ................................................................. 141

6-3-37 Suffix Code ..................................................................... 142

6-3-38 Suffix Content ................................................................. 142

6-3-39 Control Characters .......................................................... 143

6-3-40 Delimiter Code ................................................................ 143

6-3-41 Delimiter Content ............................................................ 144

6-4 Scanner Confuguration by Software ........................................... 145

6-4-1 Firmware Update .............................................................. 145

6-4-2 Scanner Configuration ...................................................... 150

Chapter 7: General configuration setting ................................................ 154

7-1 Host Interface ................................................................................ 157

7-1-1 Version .............................................................................. 157

7-1-2 Abort Setting ..................................................................... 157

7-1-3 ISP Mode .......................................................................... 158

7-1-4 Barcode Default ................................................................ 158

7-1-5 All Default ......................................................................... 158

7-1-6 Mode Switch ..................................................................... 159

7-2 Output Interface ............................................................................ 160

Cable Mode ........................................................................... 160

7-2-1 USB-HID Keyboard Type ................................................ 161

7-2-1-1 Caps Lock .................................................................. 161

7-2-1-2 Num Lock ................................................................... 162

7-2-1-3 Shift Release Caps Lock ............................................ 162

7-2-1-4 Set OS ....................................................................... 162

7-2-1-5 Transmission specific symbols Delay Time ................ 163

7

1. Important Notice

7-2-1-6 Transmission Timeout ................................................ 163

7-2-1-7 Transmission Char Delay ........................................... 164

7-2-1-8 Transmission Char Gap Time ..................................... 164

7-2-1-9 Transmission Record Gap Time ................................. 165

7-2-1-10 USB HID Layout Setting ........................................... 165

7-2-2 USB-SPP(Virtual COM) Type .......................................... 167

7-2-2-1 Length of Data Transfer Bit ........................................ 167

7-2-2-2 Length of Data Stop Bit .............................................. 167

7-2-2-3 Parity Check ............................................................... 168

7-2-2-4 Communication Protocol ............................................ 168

7-2-2-5 <STX> & <ETX> Characters ...................................... 169

7-2-2-6 <CMD> & <BAR> Characters .................................... 169

7-2-2-7 Command Mode ........................................................ 169

7-2-2-8 Baud Rate .................................................................. 170

7-2-2-9 Retransmission Count ................................................ 171

7-2-2-10 ACK Timeout ............................................................ 172

7-2-2-11 Transmission specific symbols Delay Time .............. 173

7-2-2-12 Transmission Timeout .............................................. 173

7-2-2-13 Transmission Char Delay ......................................... 174

7-2-2-14 Transmission Char Gap Time ................................... 174

7-2-2-15 Transmission Record Delay ..................................... 175

Bluetooth Mode .................................................................... 176

7-2-3 Bluetooth HID Type ......................................................... 176

7-2-3-1 Caps lock ................................................................... 176

7-2-3-2 Num Lock ................................................................... 176

7-2-3-3 Bluetooth HID Layout Settiing .................................... 177

7-2-3-4 Transmission specific symbols Delay Time ................ 178

7-2-3-5 Transmission Timeout ................................................ 178

7-2-3-6 Transmission Char Delay ........................................... 179

7-2-3-7 Transmission Char Gap Time ..................................... 179

7-2-3-8 Transmission Record Gap Time ................................. 180

7-2-4 Bluetooth-SPP Type........................................................ 181

7-2-4-1 Communication Protocol ............................................ 181

7-2-4-2 <STX> & <ETX> Characters ...................................... 181

7-2-4-3 <CMD> & <BAR> Characters .................................... 182

7-2-4-4 Command Mode ........................................................ 182

7-2-4-5 Retransmission Count ................................................ 183

7-2-4-6 ACK Timeout .............................................................. 183

7-2-4-7 Transmission specific symbols Delay Time ................ 184

7-2-4-8 Transmission Timeout ................................................ 184

8

1. Important Notice

7-2-4-9 Transmission Char Delay ........................................... 185

7-2-4-10 Transmission Char Gap Time ................................... 185

7-2-4-11 Transmission Record Gap Time ............................... 186

7-3 System Control ............................................................................. 187

7-3-1 Mode ................................................................................. 187

7-3-2 System Beep Sw .............................................................. 187

7-3-3 Date Format ...................................................................... 188

7-3-4 Time Format ..................................................................... 188

7-3-5 Battery Chagre Speed ...................................................... 189

7-3-6 USB Plug to Cable Mode .................................................. 189

7-3-7 System Beep Volume ....................................................... 190

7-3-8 System Virbator ................................................................ 190

7-3-9 Setup Virbator ................................................................... 191

7-3-10 Header Str Sw ................................................................ 191

7-3-11 Header Serial Number .................................................... 191

7-3-12 Header Date & Time ..................................................... 192

7-3-13 Header Record Count ..................................................... 192

7-3-14 Footer Str Sw .................................................................. 192

7-3-15 Footer Serial Number ..................................................... 193

7-3-16 Footer Date & Time ......................................................... 193

7-3-17 Footer Record Count ...................................................... 194

7-3-18 Lamp Light Brightness .................................................... 194

7-3-19 DLE Escape Characters ................................................. 195

7-3-20 CMD Escape Characters ................................................ 195

7-3-21 BAR Escape Characters ................................................. 196

7-3-22 ETX Escape Characters ................................................. 196

7-3-23 STX Escape Characters ................................................. 197

7-3-24 Date Separator ............................................................... 197

7-3-25 Time Separator ............................................................... 198

7-3-26 Wait Addon Count ........................................................... 198

7-3-27 Double Confirm Count .................................................... 199

7-3-28 Continue Mode Clear Time ............................................. 199

7-3-29 Setup Time ..................................................................... 200

7-3-30 Set Date & Time Format ................................................. 200

7-3-31 All Memory Data Clear .................................................... 201

7-3-32 All Data Transmission ..................................................... 201

7-3-33 Footer Chatacters ........................................................... 201

7-3-34 Header Chatacters .......................................................... 202

Chapter 8: Symbology Settings ................................................................ 203

8-1 Barcode Symbologies Default Setting Chart ............................. 204

9

1. Important Notice

8-2 UPC-A ............................................................................................ 205

8-2-1 Read ................................................................................. 205

8-2-2 Add-on Type ...................................................................... 205

8-2-3 Wait Add-on ...................................................................... 206

8-2-4 Truncate Leading Zeros .................................................... 206

8-2-5 Expansion ......................................................................... 206

8-2-6 Transmission Checksum ................................................... 207

8-2-7 Truncate Leading Characters ............................................ 207

8-2-8 Truncate Trailing Characters ............................................. 208

8-2-9 Position for Inserting ......................................................... 208

8-2-10 Position for Inserting Characters ..................................... 209

8-2-11 Code ID for UPC-A ......................................................... 209

8-3 UPC-E ............................................................................................ 210

8-3-1 Read ................................................................................. 210

8-3-2 Wait Add-on ...................................................................... 210

8-3-3 Expansion ......................................................................... 211

8-3-4 Add-On Type ..................................................................... 211

8-3-5 Transmission Checksum ................................................... 212

8-3-6 Truncate Leading Zeros .................................................... 212

8-3-7 Truncate Leading Characters ............................................ 213

8-3-8 Truncate Trailing Characters ............................................. 213

8-3-9 Position for Inserting ......................................................... 214

8-3-10 Position for Inserting Characters ..................................... 214

8-3-11 Code ID for UPC-E ......................................................... 215

8-3-12 Sub Code ID for UPC-E .................................................. 215

8-4 EAN-13 ........................................................................................... 216

8-4-1 Read ................................................................................. 216

8-4-2 Wait Add-on ...................................................................... 216

8-4-3 Add-on Type ...................................................................... 217

8-4-4 ISBN/ISSN Conversion ..................................................... 217

8-4-5 Truncate Leading Zeros .................................................... 218

8-4-6 Transmission Checksum ................................................... 218

8-4-7 Truncate Leading Characters ............................................ 219

8-4-8 Truncate Trailing Characters ............................................. 219

8-4-9 Position for Inserting ......................................................... 220

8-4-10 Position for Inserting Characters ..................................... 220

8-4-11 Code ID for EAN-13 ........................................................ 221

8-4-12 Sub Code ID for EAN-13 ................................................ 221

8-5 EAN-8 ............................................................................................. 222

8-5-1 Read ................................................................................. 222

10

1. Important Notice

8-5-2 Wait Add-on ...................................................................... 222

8-5-3 Add-on Type ...................................................................... 223

8-5-4 Expansion ......................................................................... 223

8-5-5 Transmission Checksum ................................................... 224

8-5-6 Truncate Leading Zeros .................................................... 224

8-5-7 Truncate Leading Characters ............................................ 225

8-5-8 Truncate Trailing Characters ............................................. 225

8-5-9 Position for Inserting ......................................................... 226

8-5-10 Position for Inserting Characters ..................................... 226

8-5-11 Code ID for EAN-8 .......................................................... 227

8-5-12 Sub Code ID for EAN-8 .................................................. 227

8-6 Code-39 ......................................................................................... 228

8-6-1 Read ................................................................................. 228

8-6-2 Type .................................................................................. 228

8-6-3 Code 32 translation ........................................................... 229

8-6-4 Transmission Start/End ..................................................... 229

8-6-5 Checksum Verification ...................................................... 230

8-6-6 Transmission Checksum ................................................... 230

8-6-7 Truncate Leading Zeros .................................................... 230

8-6-8 Min/Max Code Length ....................................................... 231

8-6-9 Truncate Leading Characters ............................................ 231

8-6-10 Truncate Trailing Characters ........................................... 232

8-6-11 Position for Inserting ....................................................... 232

8-6-12 Position for Inserting Characters ..................................... 233

8-6-13 Code ID for Code-39 ....................................................... 233

8-6-14 Sub Code ID for Code-39 ............................................... 234

8-7 Codabar/NW7 ................................................................................ 235

8-7-1 Read ................................................................................. 235

8-7-2 Start/ End Symbol Types ................................................... 235

8-7-3 Same Start/End Pair ......................................................... 236

8-7-4 Transmission Start/End ..................................................... 236

8-7-5 Checksum Verfification ..................................................... 237

8-7-6 Transmission Checksum ................................................... 237

8-7-7 Truncate Leading Zeros .................................................... 238

8-7-8 Min/Max Code Length ....................................................... 238

8-7-9 Truncate Leading Characters ............................................ 239

8-7-10 Truncate Trailing Characters ........................................... 239

8-7-11 Position for Inserting ....................................................... 240

8-7-12 Position for Inserting Characters ..................................... 240

8-7-13 Code ID for Codabar/NW7 .............................................. 241

11

1. Important Notice

8-8 Code-128 ....................................................................................... 242

8-8-1 Read ................................................................................. 242

8-8-2 Type .................................................................................. 242

8-8-3 Checksum Verificaiton ...................................................... 243

8-8-4 Transmission Checksum ................................................... 243

8-8-5 Truncate Leading Zeros .................................................... 243

8-8-6 ID Separtor UCC-128/GS1-128 ........................................ 244

8-8-7 Min/Max Code Length ....................................................... 244

8-8-8 Truncate Leading Characters ............................................ 245

8-8-9 Truncate Trailing Characters ............................................. 245

8-8-10 Position for Inserting ....................................................... 246

8-8-11 Position for Inserting Characters ..................................... 246

8-8-12 Code ID for Code-128 ..................................................... 247

8-8-13 Code ID for Code-128 ..................................................... 247

8-9 Interleaved 2 of 5 .......................................................................... 248

8-9-1 Read ................................................................................. 248

8-9-2 Checksum Verification ...................................................... 248

8-9-3 Transmission Checksum ................................................... 249

8-9-4 Truncate Leading Zeros .................................................... 249

8-9-5 Min/Max Code Length ....................................................... 250

8-9-6 Truncate Leading Characters ............................................ 250

8-9-7 Truncate Trailing Characters ............................................. 251

8-9-8 Position for Inserting ......................................................... 251

8-9-9 Position for Inserting Characters ....................................... 252

8-9-10 Code ID for Interleaved 2 of 5 ......................................... 252

8-10 Industrial 2 of 5 ........................................................................... 253

8-10-1 Read ............................................................................... 253

8-10-2 Checksum Verification .................................................... 253

8-10-3 Transmission Checksum ................................................. 254

8-10-4 Truncate Leading Zeros .................................................. 254

8-10-5 Min/Max Code Length ..................................................... 255

8-10-6 Truncate Leading Characters .......................................... 255

8-10-7 Truncate Trailing Characters ........................................... 256

8-10-8 Position for Inserting ....................................................... 256

8-10-9 Position for Inserting Characters ..................................... 257

8-10-10 Code ID for Industrial 2 of 5 .......................................... 257

8-11 Matrix 2 of 5 ................................................................................. 258

8-11-1 Read ............................................................................... 258

8-11-2 Checksum Verification .................................................... 258

8-11-3 Transmission Checksum ................................................. 259

12

1. Important Notice

8-11-4 Truncate Leading Zeros .................................................. 259

8-11-5 Min/Max Code Length ..................................................... 260

8-11-6 Truncate Leading Characters .......................................... 260

8-11-7 Truncate Trailing Characters ........................................... 261

8-11-8 Position for Inserting ....................................................... 261

8-11-9 Position for Inserting Characters ..................................... 262

8-11-10 Code ID for Matrix 2 of 5 ............................................... 262

8-12 Code-93 ....................................................................................... 263

8-12-1 Read ............................................................................... 263

8-12-2 Transmission Checksum ................................................. 263

8-12-3 Checksum Verification .................................................... 264

8-12-4 Truncate Leading Zeros .................................................. 264

8-12-5 Min/Max Code Length ..................................................... 265

8-12-6 Truncate Leading Characters .......................................... 265

8-12-7 Truncate Trailing Characters ........................................... 266

8-12-8 Position for Inserting ....................................................... 266

8-12-9 Position for Inserting Characters ..................................... 267

8-12-10 Code ID for Code-93 ..................................................... 267

8-13 Code-11 ........................................................................................ 268

8-13-1 Read ............................................................................... 268

8-13-2 Checksum Transmission ................................................. 268

8-13-3 Verify Checksum ............................................................. 269

8-13-4 Truncate Leading Zeros .................................................. 269

8-13-5 Min/Max Code Length ..................................................... 270

8-13-6 Truncate Leading Characters .......................................... 270

8-13-7 Truncate Trailing Characters ........................................... 271

8-13-8 Position for Inserting ....................................................... 271

8-13-9 Position for Inserting Characters ..................................... 272

8-13-10 Code ID for Code-11 ..................................................... 272

8-14 MSI/Plessey ................................................................................. 273

8-14-1 Read ............................................................................... 273

8-14-2 Transmission Checksum ................................................. 273

8-14-3 Checksum Verification .................................................... 274

8-14-4 Truncate Leading Zeros .................................................. 275

8-14-5 Min/Max Code Length ..................................................... 275

8-14-6 Truncate Leading Characters .......................................... 276

8-14-7 Truncate Trailing Characters ........................................... 276

8-14-8 Position for Inserting ....................................................... 277

8-14-9 Position for Inserting Characters ..................................... 277

8-14-10 Code ID for MSI/Plessey............................................... 278

13

1. Important Notice

8-15 UK/Plessey .................................................................................. 279

8-15-1 Read ............................................................................... 279

8-15-2 Verify Checksum ............................................................. 279

8-15-3 Transmission Checksum ................................................. 280

8-15-4 Truncate Leading Zeros .................................................. 280

8-15-5 Min/Max Code Length ..................................................... 281

8-15-6 Truncate Leading Characters .......................................... 281

8-15-7 Truncate Trailing Characters ........................................... 282

8-15-8 Position for Inserting ....................................................... 282

8-15-9 Position for Inserting Characters ..................................... 283

8-15-10 Code ID for UK/Plessey ................................................ 283

8-16 Telepen ........................................................................................ 284

8-16-1 Read ............................................................................... 284

8-16-2 Checksum Verification .................................................... 284

8-16-3 Type ................................................................................ 285

8-16-4 Transmission Checksum ................................................. 285

8-16-5 Truncate Leading Zeros .................................................. 286

8-16-6 Min/Max Code Length ..................................................... 286

8-16-7 Truncate Leading Characters .......................................... 287

8-16-8 Truncate Trailing Characters ........................................... 287

8-16-9 Position for Inserting ....................................................... 288

8-16-10 Position for Inserting Characters ................................... 288

8-16-11 Code ID for Telepen ...................................................... 289

8-17 RSS(GS1 DataBar)14 .................................................................. 290

8-17-1 Read ............................................................................... 290

8-17-2 Code Mark ...................................................................... 290

8-17-3 Application ID .................................................................. 291

8-17-4 Transmission Checksum ................................................. 291

8-17-5 Truncate Leading Zeros .................................................. 292

8-17-6 Truncate Leading Characters .......................................... 292

8-17-7 Truncate Trailing Characters ........................................... 293

8-17-8 Position for Inserting ....................................................... 293

8-17-9 Position for Inserting Characters ..................................... 294

8-17-10 Code ID for RSS(GS1 DataBar)14 ............................... 294

8-18 RSS(GS1 DataBar) Limited ........................................................ 295

8-18-1 Read ............................................................................... 295

8-18-2 Code mark ...................................................................... 295

8-18-3 Application ID .................................................................. 296

8-18-4 Transmission Checksum ................................................. 296

8-18-5 Truncate Leading Zeros .................................................. 297

14

1. Important Notice

8-18-6 Truncate Leading Characters .......................................... 297

8-18-7 Truncate Trailing Characters ........................................... 298

8-18-8 Position for Inserting ....................................................... 298

8-18-9 Position for Inserting Characters ..................................... 299

8-18-10 Code ID for RSS(GS1 DataBar) Limited ....................... 299

8-19 RSS(GS1 DataBar)14 Stack ........................................................ 300

8-19-1 Read ............................................................................... 300

8-19-2 Code Mark ...................................................................... 300

8-19-3 Application ID .................................................................. 301

8-19-4 Transmission Checksum ................................................. 301

8-19-5 Truncate Leading Zeros .................................................. 302

8-19-6 Truncate Leading Characters .......................................... 302

8-19-7 Truncate Trailing Characters ........................................... 303

8-19-8 Position for Inserting ....................................................... 303

8-19-9 Position for Inserting Characters ..................................... 304

8-19-10 Code ID for RSS(GS1 DataBar)14 Stack ...................... 304

8-20 RSS(GS1 DataBar) Expansion ................................................... 305

8-20-1 Read ............................................................................... 305

8-20-2 Code Mark ...................................................................... 305

8-20-3 Application ID .................................................................. 306

8-20-4 Transmission Checksum ................................................. 306

8-20-5 Truncate Leading Zeros .................................................. 307

8-20-6 Truncate Leading Characters .......................................... 307

8-20-7 Truncate Trailing Characters ........................................... 308

8-20-8 Position for Inserting ....................................................... 308

8-20-9 Position for Inserting Characters ..................................... 309

8-20-10 Code ID for RSS(GS1 DataBar) Expansion .................. 309

8-21 RSS(GS1 DataBar) Expansion Stack ......................................... 310

8-21-1 Read ............................................................................... 310

8-21-2 Code Mark ...................................................................... 310

8-21-3 Application ID .................................................................. 311

8-21-4 Transmission Checksum ................................................. 311

8-21-5 Truncate Leading Zeros .................................................. 312

8-21-6 Truncate Leading Characters .......................................... 312

8-21-7 Truncate Trailing Characters ........................................... 313

8-21-8 Position for Inserting ....................................................... 313

8-21-9 Position for Inserting Characters ..................................... 314

8-21-10 Code ID for RSS(GS1 DataBar) Expansion .................. 314

Hexadecimal / Decimal TABLE .................................................................. 315

ASCII Code Table ....................................................................................... 316

15

1. Important Notice

16

1. Important Notice

Chapter 1: important Notice

Important Notice:

1-1 Regulations
1-2 TECHNICAL REGULATIONS CONFORMITY FOR SPECIFIED RADIO

EQUIPMENT IN JAPAN
1-3 NATIONAL COMMUNICATION COMMISSION
1-4 RoHS DIRECTIVES
1-5 SAFETY PRECAUTION

17

1. Important Notice

1-1 Regulations

This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.

This device has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiated radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:

 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and receiver.
 Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

1-2 TECHNICAL REGULATIONS CONFORMITY FOR SPECIFIED RADIO EQUIPMENT IN
JAPAN

Certificate Number: 204WW81000100

1. Important Notice:

1-1 REGULATIONS

1-2 TECHNICAL REGULATIONS CONFORMITY FOR

SPECIFIED RADIO EQUIPMENT IN JAPAN

18

1. Important Notice

1-3 NATIONAL COMMUNICATION COMMISSION

NCC Registration Number: NCC-RCB-05

Qualified serials number on device:

1-4 RoHS DIRECTIVE

The RoHS directive (European Parliament Directive 2002/95/EC) mandates
that producers of electrical or electronic equipment sold into Europe must
minimize or eliminate the following materials from their design, as they are
considered health risks:

These Materials must be reduced to their appropriate level (as announced by
the directive) by July 1, 2006.

Technology committed to the environment, which makes the necessary
changes to our products in order to comply with the directive. This involves
converting most of the non-compliant components (electronics, PC boards,
etc.) of our products to the compliant equivalent. We also changed the
assembly processes (solder, glue, etc) to fully compliant with the directive.
These changes will not affect the form, size or function of our products and the
important thing is the reliability and performance remains the same.

1-3 NATIONAL COMMUNICATION COMMISSION

1-4 RoHS DIRECTIVE

1. Lead

2. Mercury

3. Cadmium

4. Hexavalent Chromium

5. Polybrominated biphenyls (PBB)

6. Polybrominated diphenyl ethers (PBDE)

19

1. Important Notice

1-5 SAFETY PRECAUTION

 Do not stare the scanning light source beam.
 Do not touch the device transparent window, reading performance

might decrease if transparent window is dirty or scratch.
 Do not disassemble or modify the internal components from the

scanner.

 Do not expose the scanner to any flammable source.
 Do not over charge the battery.

Lithium-Ion polymer Battery

 The Lithium-Ion polymer battery energy density is less than 400

Wh/L. Therefore, PSE certification does not required in this product.

 First time battery charge will take 4 hours for fully charge.
 Battery Life time:

Memory Mode: Approx. 18000 scans (5 sec/per scan).

Bluetooth Mode: Approx. 15000 scans (5 sec/ per scan).

 Do not assemble / disassemble the battery without technical

support.

 Do not use unspecified power adaptor to charge the battery.
 During the charging process, if red color LED indicator flashing

rapidly, discontinued the charging process, and return the scanner

to the authorized dealer.
 Any leakage of fluid or abnormal odor occurred, discontinued the

operation of the scanner, and returns to authorized dealer.
 Any leakage of fluid from the battery, avoid any contact with skins or

eyes, if situation occurred, rinse with fresh water and consult the

doctor immediately.

1-5 SAFETY PRECAUTION

20

2. Introduction

Chapter 2: Introduction

Introduction:

2-1 PRODUCT FEATURES

2-2 PRODUCT SPECIFICATION

2-3 PACKAGE INFORMATION

2-4 DEFAULT SYMBOLOGIES

2-5 FUNCTION KEYS AND LED INDICATOR

2-6 QUICK START GUIDE

21

2. Introduction

2-1 PRODUCT FEATURES

 Ergonomic and lightweight
 Three in one functions (Bluetooth/ Memory/ Cabled)
 USB cable can be used as cabled scanner, data transferring from flash

memory, and battery charging cable.
 Six different Bluetooth mode (Master, Slave, USB HID, iPad mode, A-303

Dongle and A-302 Dongle) to communicate between PC, mobile phone ,

PDA ,A-303 Dongle and A-302 Dongle.

 Programmable time stamp and output data format
 Programmable Beep tone, volume.
 Flash memory can stored up to 130000 barcode data with time stamp

( bas-on EAN-13 barcode symbology)

2-1 PRODUCT FEATURES

2.

Introduction

22

2. Introduction

2-2 PRODUCT SPECIFICATION

Model No. CM-520W wireless series

Microprocessor

32 bits CPU

Main battery operation

times

8000 scans in Bluetooth Mode

( 5 sec /per scan)

Supported barcodes

Code 39, INT 25, Industrial 2 of 5, Matrix 2 of 5,

Codabar(NW7), Code 93, Code 128,EAN 128,

JAN/EAN/ UPC and fully RSS code (GS1

Databar )

Min. PCS value

0.45

Scan

Engine

CCD

Type

630nm Red LED LAMP, Linear CCD Image

Sensor

Scan rate : 100 scan/sec,

Scan distance : 50mm~250mm

Laser

Type

Visible Laser Diode 650nm ±10 ( 25°C)

Scan rate : 100 scan/sec

Scan distance : 50mm~350mm

Main battery

Built in Rechargeable Li-polymer battery

pack.,(3.7V, 420mAH) charging via USB port

Wireless

Communication

2.4Ghz Bluetooth Class I

Keys

2 keys, 1 for scan 1 for clear data.

LED indicator

1 LED 2 colors (green and orange) for Memory mode

1 LED (red) for low battery

1 LED(blue) for wireless communication on-line

status

Beep indicator

Buzzer can be disable or enable by

configuration

Temperature in

operation

-10 ~ +40

℃

Environment Humidity

10%-90%RH

Certification

FCC / CE / RoHS approved, VCCI, Telec

Operation system

Windows XP/2000/Vista/Win 7, Win8

Dimension

(L x W x H) 89 x 40 x 17.5 mm

Weight

CCD : 75g / Laser : 85g

Power consumption

CCD : 90mA / Laser : 60mA

2-2 PRODUCT SPECIFICATION

23

2. Introduction

2-3 PACKAGE INFORMATION

The package included: Scanner, Bluetooth Dongle (optional), power

adaptor (optional), Lanyard, USB cable, Quick start guide, product CD.

Note: The product CD includes: Quick start guide, user manual,

Bluetooth setting software, barcode scanner setting software.

(Optional)

(Optional)

2-3 PACKAGE INFORMATION

24

2. Introduction

2-4 DEFAULT SYMBOLOGIES

Symbologies Default setting

EAN/ UPC

UPC-A

Enabled

UPC-E

Enabled

EAN-8

Enabled

EAN-13

Enabled

EAN-13(ISBN) Disabled

Code 39

Enabled

Interleaved 2/5

Disabled

Industrial 2/5

Disabled

Matrix 2/5

Disabled

Codabar/ NW7

Enabled

Code 128

Enabled

Code 93

Disabled

Code 11

Disabled

MSI/ Plessey

Disabled

UK/ Plessey

Disabled

Telepen

Disabled

GS1 Databar
(RSS)

RSS14 Disabled

RSS14 Limited Disabled

RSS 14 Stacked Disabled

RSS Expansion Disabled

RSS Expansion Stacked Disabled

2-4 DEFAULT SYMBOLOGIES

25

2. Introduction

2-5 FUNCTION KEYS AND LED INDICATOR

○1 Press down Scan Button to decode or store the barcode.

○2 Press down Small Trigger to perform versatile supplementary functions.

For instance, pressing the key will lead to erasing barcode data which have

been previously decoded in Memory Mode; it also works to pair the

scanner with the Bluetooth devices in Bluetooth Mode.

○3 Power Indicator indicates the charge status. When the battery is running

low, red LED light will be on to show a poor charge level. Once the

charging process is completed, red LED will flash slowly to show a full

battery charge.

○4 Good Read Indicator indicates whether the barcode is successfully

decoded. Green LED shows a successful decoding attempt.

○5 Mode Indicator indicates the current operation mode. Blue LED stands

for Bluetooth mode, green LED for Cable mode, and orange LED for

Memory mode.

○6 Strap Hole

○7 Secure the interface cable into USB Host in an attempt to transmit data or

to charge the battery.

○8 Replace the battery in the Battery Compartment.

2-5 FUNCTION KEYS AND LED INDICATOR

26

2. Introduction

Step 1 >

Insert Bluetooth Dongle to

USB port.

Step 2 >

Make sure the scanner is in Bluetooth mode. If scanner is in memory mode,
press and hold the scan key for few seconds until beep sound and orange LED
light indication OR scan the mode switching barcode.

Step 3>

When the scanner is in Bluetooth mode, press the scan key again and wait for
few seconds, the Bluetooth connection will automatically establish. If
connection successful, the Blue LED indicator will be on.

Step 4>

When Bluetooth Connection established, execute any word processing
software, for example: Word, notepad, Excel and etc. to receive to barcode
data.

Note: Bluetooth connection will switch to sleep mode if not in use; Press

Scan OR erase key once will reestablish the Bluetooth connection.

2-6 QUICK START GUIDE

The Quick Start guide demonstrates how to connect the scanner with
Bluetooth Dongle, and some of the quick references. For detail configuration
with Bluetooth, please refer to related chapter.

2-6 QUICK START GUIDE

How to

connect

the

s

canner

with Bluetooth Dongle

Procedure

27

2. Introduction

When plug in the USB cable

with scanner.

a) It will start with short melody and the red

LED will be indicated.

b) Execute Word, Excel or any word

processing software; scan the barcode will
transmit the barcode data to the word
processing software in real time.

c) When the barcode is successfully read,

beep sound and green LED will be
indicated.

Note: after uploading the
barcode data to PC, the barcode
data in the memory will not be
erase. User needs to erase the
barcode data manually.

When Unplug the USB cable

with scanner.

a) It will automatically switch to Memory

mode / Bluetooth mode.

b) Press the erase key and point to the

scanned barcode label, this action will
erase the previously saved barcode
data in the memory scanner.

.

Transmitting barcode data

Clear all saved barcode data

Warning: Scan the “Clear” barcode will

lose all the barcode data.

I

mportant Note: For better Bluetooth

transmission quality, when holding the

scanner, please avoid covering the

reverse top cover.

Scanner Operation Guide

Operation Mode

*/$%

MTX

*

(Send)

Send barcode data by Bluetooth OR

connected by USB cable.

*/$%MCR*

(Clear)

Clear all barcode data in the memory

28

3. Scanner Configuration Quick Start

Chapter 3: Scanner Configuration

Scanner Configuration Quick Start

3-1 CONFIGURATION BY USER MANUAL

3-2 CONFIGURATION BY SOFTWARE

29

3. Scanner Configuration Quick Start

3-1 Configuration by USER MANUAL

In the user manual, print out the related topics of setting page, simply use the
scanner to scan the barcode for configuration.

For example:

Factory Default setting: user may configure the scanner back to all default

settings, if configuration goes wrong.

3. Scanner Configuration Quick Start

ENTER

*/$%ENTR*

(Enter configuration)

Good read Beep

Disable

*B8500*

Enable

*B8501*

End

*ZEND*

(Exit Configuration)

ABORT

*ZEXT*

Abort current setting before

exit configuration

ENTER

*/$%ENTR*

(Enter configuration)

ALL DEFAULT

*ZADE*

Restore to factory default

setting.

3-1 CONFIGURATION BY USER MANUAL

30

3. Scanner Configuration Quick Start

3-2 Configuration by SOFTWARE

In the product CD, you can find configuration software “Normal command
setting” to configure the parameters.

Scanner general settings: (CM-520\Software\Normal command

setting\Scanner Setting.exe)

Note: Please refer to the related configuration chapters or additional manual

for how to use the software.

3-2 CONFIGURATION BY SOFTWARE

31

4. Memory / Bluetooth Mode

Chapter 4: Memory / Bluetooth Mode

Memory / Bluetooth Mode:

4-1 Memory Mode

4-1-1 Function Switch (Bluetooth mode to Memory mode)

4-1-2 Transmitting barcode data in memory mode

4-1-3 Erase barcode data (single data/ all data) in memory mode

4-2 Bluetooth Mode

4-2-1 Function switch (Memory Mode to Bluetooth mode)

4-2-2 Bluetooth Mode LED indication

4-2-3 Bluetooth mode selection Code Table

4-2-4 Bluetooth mode configuration by user manual

4-2-4-1 Slave Mode-Third party Bluetooth devices (Mode selection

code:1)

4-2-4-2 Master Mode -Third party Bluetooth devices (Mode

selection code: 2)

4-2-4-3 HID Mode - For third party Bluetooth devices (Mode

selection code: 3)

4-2-4-4 iOS MODE (Mode selection code : 4)

4-2-4-5 A-303 dongle MODE (Mode selection code : 5)

4-2-4-6 A-302 dongle Mode (Mode selection code:6)

4-2-4-7 Spp-A303 PT Mode(Mode selection code:7)

4-2-5 Bluetooth parameter configuration by user manual

4-2-5-1 BT Local name

4-2-5-2 Remote Mac Address

4-2-5-3 Pin Code

32

4. Memory / Bluetooth Mode

This chapter explains the different functions between Memory function and
Bluetooth function.

Note: If user only purchase Memory scanner model, switching to

Bluetooth mode is not applicable.

4-1 Memory Mode

4-1-1 Function switch (Bluetooth mode to Memory mode)

There are two methods of switching from Bluetooth mode to Memory mode:

1) Long keep holding Scan key, till the LED as solid color,

then release Scan key, will into the mode switching,
if the LED turn to orange color, it is in Memory mode.

OR

2) Scan the following barcode to switch from

Bluetooth Mode to Memory Mode.

(1) Enter: (Enter setting)

*/$%ENTR*

(2) To Memory mode

*ZTOM*

4-1-2 Transmitting barcode data in memory mode

There are two methods of sending the barcode data from barcode scanner.

1) Connect the USB cable between scanner and PC,

keep holding Small Trigger till the LED as solid color,
then release Small Trigger to into Transmit mode;
at this moment, push Scan key will transmit the stored data.

barcode data to your word processing software,

e.g. Word, excel, or notepad.

OR

2) Connect the USB cable between scanner and PC, and scan the below

“Send” barcode.

4. Memory / Bluetooth Mode Explanation

4-1 Memory Mode

4-1-1 Function switch (Bluetooth mode to Memory mode)

4-1-2 Transmitting barcode data in memory mode

33

4. Memory / Bluetooth Mode

*/$%MTX*

(Send)

4-1-3 Erase barcode data (single data/ all data)

Erase single data:

While holding Small Trigger and point to the scanned barcode, this action
will erase the last previous saved barcode data
in the memory.

Erase all data:

1. While holding Small Trigger till Orange LED turns rapidly blinking,

2. Press down Scan Button

3. Release Scan Button and Small Trigger together,
alll barcode data saved in the memory will be erased.

OR

By scanning the send barcode as below:

*/$%MCR*

(Clear)

Clear all barcode data in the memory

Caution: Scan the “Clear” Barcode will erase all the barcode

data saved in the memory; make sure you have back up all

the barcode data before performing this action.

4-1-3 Erase barcode data (Single data / ALL data)

34

4. Memory / Bluetooth Mode

4-2 Bluetooth Mode

User can configure different Bluetooth connection mode in different

Bluetooth environment.

1. Slave Mode (For third party Bluetooth devices)

2. Master Mode (For third party Bluetooth devices)

3. HID Mode (Third party Bluetooth devices with USB HID mode only)

4. iPAD/ iPhone OS Mode (iPad, iPhone)

5. A-303 Dongle Mode ( Original factory dongle, USB-HID / USB-COM
configurable)

6. A-302 Dongle Mode (Original factory dongle , USB-HID only)

7. Spp-A303PT Mode( Original factory dongle, USB-COM Only)

4-2-1 Function switch (Memory Mode to Bluetooth mode)

There are two methods of switching from Memory mode to Bluetooth Mode:

1) Long keep holding Scan key, till the LED as solid color,
then release Scan key, it will into the mode switching,
if the LED turn to blue color, it is in BT mode.

OR

1. Scan the following barcode to Bluetooth Mode.

(1) Enter: (Enter setting)

*/$%ENTR*

(2) To Bluetooth mode

*ZTOB*

4-2 Bluetooth Mode

4-2-1 Function switch (Memory Mode to Bluetooth mode)

35

4. Memory / Bluetooth Mode

4-2-2 LED indication under Bluetooth Mode

Description

Red

indicates the charge status. When the battery is running low,
red LED light will be on to show a poor charge level. Once the
charging process is completed, red LED will flash slowly to
show a full battery charge.

Green Green

:Good Read Indicator indicates whether the barcode is

successfully decoded. Green LED shows a successful decoding attempt.

Blue

Under Bluetooth mode, and Bluetooth connection is not yet
connected, the blue LED indicator will be flash per 3 seconds.
Under Bluetooth Mode and if Bluetooth connection is not
connected, Press and Hold the delete key until BLUE LED
indicator flashing rapidly, at this time, release the delete key
after Press Scan key for Bluetooth pairing with your device.
When power on and if Bluetooth is connected, the blue LED
will be on.

4-2-2 LED indication under Bluetooth Mode

36

4. Memory / Bluetooth Mode

4-2-3 Bluetooth mode selection Code Table

Bluetooth mode selection code Table

Mode Description Mode selection Code

Slave Mode

Applied to third party

Bluetooth dongle, or

build-in Bluetooth

devices

1

Master Mode

Applied to third party

Bluetooth dongle, or

build-in Bluetooth

devices

2

HID Mode

Third party Bluetooth

dongle, or build in

Bluetooth device with

USB HID mode only

3

iOS Mode

iPad, iPhone devices

4

A-303 Dongle Mode

Applied to original

factory dongle,

USB-HID / USB-COM

configurable

5

A-302 Dongle Mode

Original factory dongle ,

USB-HID only

6

Spp-A303PT Mode

Original factory dongle,

USB-COM Only

7

4-2-3 Bluetooth mode selection Code Table

37

4. Memory / Bluetooth Mode

4-2-4 Bluetooth mode configuration by user manual

4-2-4-1 Slave Mode : Third party Bluetooth devices ( Mode selection code:

1)

This mode is for user to configure with third party Bluetooth dongle, or
build-in Bluetooth device.

For slave mode configuration; please scan below barcodes step by step.

Procedure:

(1) Enter: (Enter setting)

*/$%ENTR*

(2) Mode: (selection Spp-Slave)

*C41D1*

(3) End (Exit setting)

*ZEND*

4-2-4-2 Master Mode - Third party Bluetooth devices (Mode selection

code: 2)

This mode is for user to configure with third party Bluetooth dongle, or
build-in Bluetooth device.

For master mode configuration, please scan below barcodes step by step.

Procedure:

(1)Enter: (Enter setting)

*/$%ENTR*

(2)Mode: ( selection Spp-Master)

*C41D2*

(3)End: (Exit setting)

*ZEND*

4-2-4 Bluetooth mode configuration by user manual

38

4. Memory / Bluetooth Mode

4-2-4-3 HID Mode - For third party Bluetooth devices (Mode selection

code: 3)

This mode is for user to configure with third party Bluetooth dongle, or
build-in Bluetooth device with USB HID only.

For HID mode Configuration, please scan below barcodes step by step.

Procedure:

(1)Enter: (Enter setting)

*/$%ENTR*

(2)Mode: ( selection Hid)

*C41D3*

(3)End: (Exit setting)

*ZEND*

4-2-4-4 Hid-iOS Mode (Mode selection code : 4)

This mode is for user to configure with iPad or iPhone devices

For Hid-iOS mode configuration, please scan below barcodes step by step.

Procedure:

(1)Enter: (Enter setting)

*/$%ENTR*

(2)Mode: ( selection Hid-iOS)

*C41D4*

(3)End: (Exit setting)

*ZEND*

39

4. Memory / Bluetooth Mode

4-2-4-5 A-303 dongle Mode (Mode selection code: 5)

This mode is for user to configure with purchased original factory dongle,
and it is USB-HID / USB-COM configurable.

For A-303 Dongle mode configuration, please scan below barcodes step by
step.

Procedure:

(1)Enter: (Enter setting)

*/$%ENTR*

(2)Mode: ( selection Hid-A303)

*C41D5*

(3)End: (Exit setting)

*ZEND*

4-2-4-6 A302 dongle Mode (Mode selection code:6)

This mode is for user to configure with purchased original factory dongle,
but it only support USB-HID.

A-302 Dongle mode, please scan below barcodes step by step.

Procedure:

(1)Enter: (Enter setting)

*/$%ENTR*

(2)Mode: ( selection Hid-A302)

*C41D6*

(3)End: (Exit setting)

*ZEND*

40

4. Memory / Bluetooth Mode

4-2-4-7 Spp-A303PT Mode (Mode selection code:7)

This mode is for user to configure with purchased original factory dongle,
but it only support USB-COM.

Spp-A303PT mode, please scan below barcodes step by step.

Procedure:

(1)Enter: (Enter setting)

*/$%ENTR*

(2)Mode: ( selection Spp-A303PT)

*C41D7*

(3)End: (Exit setting)

*ZEND*

41

4. Memory / Bluetooth Mode

4-2-5 Bluetooth parameter configuration by manual

4-2-5-1 BT Local name

1. Slave, Master, HID Dongle, Hid-iOS Device

This option enables to assign Bluetooth the scanner name. Please refer to the
HEX ASCII table (Form 0~9, A~F). The first digit and last digit cannot be space
or “-“. If scanner name setting is incorrect, connection failure will occur.

Configuration Max. Configurable Length Default Setting

Please refer to

ASCII table

16 digits ‘Serial Adaptor’

Procedure:

(1) Enter: (Enter setting)

*/$%ENTR*

(2) “BtDevName”

*B14E6*

(3) Scan Hexadecimal/Decimal Barcode table for input parameters.

(4) OK : (Selection confirmed)

*%OK*

(5) End: (Exit setting)

*ZEND*

Example:

Set Local name as ‘BT Scanner’

(A) Scan “Enter” barcode
(B) Scan “BtDevName” barcode
(C) Scan parameters from Hexadecimal / Decimal barcode table =>“4”,”2”,

“5”,”4”, “2”,”0”, “5”,”3”, “6”,”3”, “6”,”1”, “6”,”E”, “6”,”E”, “6”,”5”, “7”,”2”,”OK”
(configured as ‘BT Scanner’, Please refer to ASCII TABLE)
(D) Scan “End” Barcode

4-2-5 Bluetooth parameter configuration by manual

42

4. Memory / Bluetooth Mode

2. A-303,A-302 Dongle,Spp-A303 PT
This option enables to assign Bluetooth the scanner name. Please refer to the
HEX ASCII table (Form 0~9, A~F). The first digit and last digit cannot be space
or “-“. If scanner name setting is incorrect, connection failure will occur.

Configuration Max. Configurable Length Default Setting

Please refer to

ASCII table

16 digits ‘Serial Adaptor’

Procedure:

(1) Enter: (Enter setting)

*/$%ENTR*

(2) “DongleBtDevName”

*B34E6*

(3) Scan Hexadecimal/Decimal Barcode table for input parameters.

(4) OK : (Selection confirmed)

*%OK*

(5) End: (Exit setting)

*ZEND*

Example:

Set Local name as ‘BT Scanner’

(A) Scan “Enter” barcode
(B) Scan “DongleBtDevName” barcode
(C) Scan parameters from Hexadecimal / Decimal barcode table =>“4”,”2”,

“5”,”4”, “2”,”0”, “5”,”3”, “6”,”3”, “6”,”1”, “6”,”E”, “6”,”E”, “6”,”5”, “7”,”2”,”OK”
(configured as ‘BT Scanner’, Please refer to ASCII TABLE)
(D) Scan “End” Barcode

43

4. Memory / Bluetooth Mode

4-2-5-2 Remote Mac Address.

1. Slave, Master, HID Dongle, His-iOS Device

Mac address configuration, total of 12 digits, Please refer to the HEX ASCII
table (From 0~9, A~F).

Configuration Max. Configurable Length Default Setting

Hexadecimal /

decimal

barcode table

12 digits 000000000000

Procedure:

(1) Enter: (Enter setting)

*/$%ENTR*

(2) “BtMacAddr”

*B08FE*

(3) Scan Hexadecimal/Decimal Barcode table for input parameters.

(4) OK : (Selection confirmed)

*%OK*

(5) End: (Exit setting)

*ZEND*

Example:

Set Remote Mac Address to 00126F006EAA

A. Scan “Enter” barcode
B. Scan “BtMacAddr” barcode
C. Scan parameters from Hexadecimal /decimal barcode table =>“0”, “0”,

“1”,”2”, “6”,”F”, “0”,”0”, “6”,”E”, “A”,”A” ”OK” (Set “Remote Mac Address
“ value to 00126F006EAA)

D. Scan “End” barcode

Note:

If scanner connection mode is”Slave” or “HID” or “Hid-iOS” Mode, Mac

Address configuration does not required.

44

4. Memory / Bluetooth Mode

2. A-303 , A302 Dongle ,Spp-A303PT

Mac address configuration, total of 12 digits, Please refer to the HEX ASCII
table (From 0~9, A~F).

Configuration Max. Configurable Length Default Setting

Hexadecimal /

decimal

barcode table

12 digits 000000000000

Procedure:

(1) Enter: (Enter setting)

*/$%ENTR*

(2) “DongleBtMacAddr”

*B28FE*

(3) Scan Hexadecimal/Decimal Barcode table for input parameters.

(4) OK : (Selection confirmed)

*%OK*

(5) End: (Exit setting)

*ZEND*

Example:

Set Remote Mac Address to 00126F006EAA

A. Scan “Enter” barcode
B. Scan “DongleBtMacAddr” barcode
C. Scan parameters from Hexadecimal /decimal barcode table =>“0”, “0”,

“1”,”2”, “6”,”F”, “0”,”0”, “6”,”E”, “A”,”A” ”OK” (Set “Remote Mac Address
“ value to 00126F006EAA)

D. Scan “End” barcode

Note:

If scanner connection mode is “A-303 Dongle” or “A-302 Dongle” or
“Spp-A303PT” mode, configuration of Mac address does required, and the
configuration cannot be “000000000000”

45

4. Memory / Bluetooth Mode

4-2-5-3 Pin Code

When the scanner and Bluetooth device is in the pairing process, user will
need to enter the pin code for pairing confirmation. This pin code might be
generate by Bluetooth devices or preconfigured by user depends on different
mode setting.

(1) Under “Slave” or “Master” mode, pin code configuration is needed when the
pairing action is performed.

(2) Under “A-303 Dongle” or “A-302 Dongle” mode or “Spp-A303PT” mode, Pin

code does not required.

(3) Under “HID” or “HID-iOS” Mode, during pairing process, the PC or other
devices will generate the pin code, user will need to referred to that pin code,
and scan the pin code digits from Hexadecimal / Decimal table.

Configuration Range Max. Configurable Length Default Setting

0000 ~ 9999 4 digits 1234

Procedure:

(1) BT Module Enter: (Enter Bluetooth setting)

*/$%ENTR*

(2) “ BtPinCode”

*B00E9*

(3) Scan Hexadecimal/Decimal Barcode table for input digits.

(4) OK : (Selection confirmed)

*%OK*

(5) End: (Exit setting)

*ZEND*

Example:

Set Pin Code to 5678

(A) Scan “Enter” Barcode
(B) Scan “BtPinCode” Barcode
(C) Scan parameters from Hexadecimal/Decimal table =>“5”,”6”, “7”,”8”

”OK”
(Set “Pin Code “ value to 5678)

(D) Scan “End” Barcode

46

5. Bluetooth Connection Mode Instruction

Bluetooth Mode – Bluetooth
Connection Mode Instruction

5-1 Slave mode Connection (For Third party Bluetooth devices)

5-2 Master mode Connection (For third party Bluetooth Devices)

5-3 HID Mode Connection (For Third party Bluetooth devices)

5-4 HID iOS MODE Connection

5-5 A-303 Dongle Mode Connection (USB-HID / USB COM)

5-3-1 HID MODE:

5-3-2 USB-COM mode

5-6 A-302 Dongle Mode Connection (USB-HID only)

5-7 Spp-A303 PT Mode Connection(USB-COM only)

47

5. Bluetooth Connection Mode Instruction

5-1 Slave mode Connection (For Third party Bluetooth devices)



Make sure the scanner is in Bluetooth mode; please refer to chapter

4-2-1 for how to configure in Bluetooth mode.



Make sure the Mode selection code is configured as “1”. Please refer

to chapter 4-2-4-1.

1. After connect with Dongle and PC, you will see Bluetooth sign in system display.

Click right button of the mouse on this sign, and choose ”Add a Device”. See the

screen below:

After choose this function, it will start to search a nearby Bluetooth device.

2. Make the scanner into pairing mode, if it can search available connecting

Bluetooth device, it will show the screen below:

5. Bluetooth Connection Mode Instruction

5-1 Slave mode Connection (For Third party

Bluetooth devices)

48

5. Bluetooth Connection Mode Instruction

From all the finding devices, search the pairing Bluetooth device and click the left

button of the mouse on finding devices. The popping out screen let users set Pin code

by which way. See the screen below:

In this screen, choose ”Enter the device’s pairing code” will show up the screen

below:

49

5. Bluetooth Connection Mode Instruction

Please key in Pin Code with 1234 in this screen. After key in Pin code,

press ”Next” then it will start to do verification of Pin code. After pass the

verification, it will go to pairing mode. After it pairs successfully, the screen will

show like down below:

2. After it pairs successfully, click the right button of the mouse on Bluetooth sign

in the system display. It will show screen below:

50

5. Bluetooth Connection Mode Instruction

Choose ”Open Settings” function and switch to the page of ”COM Ports.” It will

show screen below:

From this screen can know the current using COM Port of Bluetooth device. Due

to the Bluetooth connection mode, it should choose ”COM15” as using COM

Port.

3. Turn on terminal software, and set COM Port as ”COM15”. It will show screen

below:

51

5. Bluetooth Connection Mode Instruction

After select COM port, click ”Connect” button to connect. After connect

successfully, it can start to scan barcode, and scan result will show in terminal

screen. It will show screen below:

52

5. Bluetooth Connection Mode Instruction

5-2 Master mode Connection (For third party Bluetooth Devices)



Make sure the scanner is in Bluetooth mode; please refer to chapter

4-2-1 for how to configure in Bluetooth mode.



Make sure the Mode selection code is configured as “2”. Please refer

to chapter 4-2-4-2.

4. After connect Dongle and PC, it will see Bluetooth sign in system display, and

click right button of mouse on it. It will show screen below:

Choose ”Open Settings” function, switch ”Open Settings” function and switch

to ”Options” page.

In this page, click ”Allow Bluetooth devices to find this computer” to let this

Bluetooth device can be searched.

5-2 Master mode Connection (For third party

Bluetooth Devices)

53

5. Bluetooth Connection Mode Instruction

5. Switch to ”COM ports” page. It will show screen below:

6. In this page, click ”Add” button to create new COM port. It will show screen

below:

7. In this screen, click ”Incoming(device initiates the connection)”, and click”OK”.In

此 the meantime, it will create Incoming port(COM14). It will show screen below:

54

5. Bluetooth Connection Mode Instruction

Click ”OK” to finish setting.

8. Turn on terminal software, set COM Port as ”COM14”, and click ”Connect” to

start connect with this COM Port. It will show screen below:

Make the scanner into pairing mode. When the scanner find the PC, it will show the

information in system display to let user key Pin Code. It will show screen below:

55

5. Bluetooth Connection Mode Instruction

Click this information and it will show screen below to let user to key Pin Code.

9. In this time, it can start to scan barcode, scanned result will show up in the

terminal screen. It will show screen below:

10. In this time, it can start to scan barcode, scanned result will show up in the

terminal screen. It will show screen below:

56

5. Bluetooth Connection Mode Instruction

57

5. Bluetooth Connection Mode Instruction

5-3HID Mode Connection (For Third party Bluetooth devices)



Make sure the scanner is in Bluetooth mode; please refer to chapter

4-2-1 for how to configure in Bluetooth mode.



Make sure the Mode selection code is configured as “3”. Please refer

to chapter 4-2-4-3

1. After connect Dongle and PC, it will show Bluetooth sign in system display.

Click right button of the mouse and select ”Add a Device”. It will show screen

below:

After select this function, it starts to search nearby available Bluetooth device. Make

the scanner into pairing mode. In the meantime, if it can find available connecting

Bluetooth device, then it will show screen below:

From all the finding Bluetooth device, search pairing device and click left button

of the mouse. From show up window, let the user to use which way to generate

5-3 HID Mode Connection (For Third party

Bluetooth devices)

58

5. Bluetooth Connection Mode Instruction

Pin Code. It will show screen below:

In the meantime, there are 2 ways to let user to choose the way to generate Pin

Code:

2. (1).Choose ”Create a pairing code for me”: it will randomly generate a set of Pin

Code. It will show screen below:

In the meantime, user can use the scanner to scan corresponding barcode in order.

After finished scanning, scan “OK” barcode to finish Pin Code input. In this time,

it will start to verify the Pin Code. After verified the Pin Code, it will start to

connect Bluetooth connection. When it connect successfully, it will show up the

following screen:

59

5. Bluetooth Connection Mode Instruction

(2) Choose”Enter the device’s pairing code”: it will show up the following

window to let the user key Pin Code. It will show screen below:

In the meantime, after clicked “Next” button, user can use the scanner to scan

corresponding barcode in order. After finished scanning, scan “OK” barcode to

finish Pin Code input. In this time, it will start to verify the Pin Code. After

verified the Pin Code, it will start to connect Bluetooth connection. When it

connect successfully, it will show up the following screen:

60

5. Bluetooth Connection Mode Instruction

In the meantime, turn on the software to receive scanned result and scan barcode.

It will show screen below:

61

5. Bluetooth Connection Mode Instruction

5-4 HID iOS MODE CONNECTION



Make sure the scanner is in Bluetooth mode; please refer to chapter

4-2-1 for how to configure in Bluetooth mode.



Make sure the Mode selection code is configured as “4”. Please refer

to chapter 4-2-4-4

Please turn on iPad and select “settings” as below

Please access to General  Bluetooth Bluetooth ON. At this stage, iPad will
start searching for Bluetooth devices

5-4 HID iOS MODE CONNECTION

62

5. Bluetooth Connection Mode Instruction

From the scanner, press and hold the pairing key

(small button) until the blue LED blinking, then push

Scan key into pairing mode.

From iPad, the Bluetooth will search for the Bluetooth

device (“Serial Adaptor” as scanner name)

When iPad searched “Serial Adaptor”, select the

device for Bluetooth pairing

63

5. Bluetooth Connection Mode Instruction

When the pairing processes succeed, on the iPad Bluetooth devices, it will
appear as Connected. And the scanner will launch 2 beep sounds with BLUE
LED indicator ON.

Now, user can access to “Notes” from iPad application to receive barcode
data.

From the scanner, scan the digits appear on iPad to complete the pairing

process. (Note: please print out the “Hexadecimal / Decimal table

(page315)” and scan the digits, for example: “scan 5,3,2,4 –> OK.)

64

5. Bluetooth Connection Mode Instruction

Additional Function: press the small button from

the scanner once, iPad will wake up the virtual

keyboard for information editing.

65

5. Bluetooth Connection Mode Instruction

5-5 A-303 Dongle Mode Connection(USB-HID / USB COM)

5-5-1 HID mode



Make sure the scanner is in Bluetooth mode; please refer to chapter

4-2-1 for how to configure in Bluetooth mode.



Make sure the Mode selection code is configured as “5”. Please refer

to chapter 4-2-4-5.

When Bluetooth Connection established, execute any word processing

software, for example: Word, notepad, Excel and etc. to receive to

barcode data.

When connecting scanner and Bluetooth Dongle,

Press and hold the Pairing/delete (small) key until the

blue LED blinking, then push Scan Key into pairing

mode. The scanner will establish the Bluetooth

connection. If connection successful, the Blue LED

indicator will be on. If not, please repeat the above

mention action or check the Bluetooth parameters

setting.

Insert Bluetooth SPP Dongle to PC.

5- 5 A-303 Dongle Mode Connection

(USB-HID / USB COM)

5-5-1 HID MODE:

66

5. Bluetooth Connection Mode Instruction

5-5-2 USB-COM mode



Make sure the scanner is in Bluetooth mode. Please refer to above

sections of how to configure in Bluetooth mode.



Make sure the Mode selection code is configured as “5”. Please refer

to chapter 4-2-4-5.

If the user wants to switch between USB-HID/ USB- COM mode, please

scan the following barcode.

Note: Before scan the barcode, make sure the scanner and the Bluetooth

Dongle is in paired status.

When connecting scanner and Bluetooth Dongle,

Press and hold the Pairing/delete (small) key until the

blue LED blinking, then push Scan Key into pairing

mode. The scanner will establish the Bluetooth

connection. If connection successful, the Blue LED

indicator will be on. If not, please repeat the above

mention action or check the Bluetooth parameters

setting.

Insert Bluetooth SPP Dongle to PC.

ENTER

(Enter configuration)

USB

-

HID

USB

-

COM

5-5-2 USB COM MODE

67

5. Bluetooth Connection Mode Instruction

When under “USB COM” mode, please check device manager. You will know which

COM port is available, then use Terminal program to receive scan data.

68

5. Bluetooth Connection Mode Instruction

5-6 Bluetooth HID Dongle Mode CONNECTION (USB-HID only)



Make sure the scanner is in Bluetooth mode. Please refer to chapter

4-2-1 for how to configure in Bluetooth mode.



Make sure the Mode selection code is configured as “6”. Please refer

to chapter 4-2-4-6

When Bluetooth Connection established, execute any word

processing software, for example: Word, notepad, Excel and etc. to

receive to barcode data.

When connecting scanner and Bluetooth Dongle,

Press and hold the Pairing/delete (small) key until the

blue LED blinking, then push Scan Key into pairing

mode. The scanner will establish the Bluetooth

connection. If connection successful, the Blue LED

indicator will be on. If not, please repeat the above

mention action or check the Bluetooth parameters

setting.

Insert Bluetooth HID Dongle to PC.

5- 6 A302 Dongle Mode Connection

(USB-HID only)

69

5. Bluetooth Connection Mode Instruction

5-7 Spp-A303PT Mode CONNECTION (USB-COM only)



Make sure the scanner is in Bluetooth mode. Please refer to chapter

4-2-1 for how to configure in Bluetooth mode.



Make sure the Mode selection code is configured as “7”. Please refer

to chapter 4-2-4-7

When Bluetooth Connection established, please check device manager. You
will know which COM port is available, then use Terminal program to receive
scan data.

When connecting scanner and Bluetooth Dongle,

Press and hold the Pairing/delete (small) key until the

blue LED blinking, then push Scan Key into pairing

mode. The scanne will establish the Bluetooth

connection. If connection successful, the Blue LED

indicator will be on. If not, please repeat the above

mention action or check the Bluetooth parameters

setting.

Insert Bluetooth SPP Dongle to PC.

5- 7 Spp-A303PT Mode Connection (USB-COM only)

70

6. Memory / Bluetooth General Setting

Chapter 6: Memory / Bluetooth General Setting

Memory / Bluetooth/Cable General

Setting

6-1 General Memory Mode Setting

6-1-1 Mode

6-1-2 Output Interface

6-1-3 Scan Activation Time

6-1-4 Composite Triggers Functionality

6-1-5 Small Trigger Functionality

6-1-6 Battery Charge

6-1-7 Power Saving Time

6-1-8 Stand by Time

6-1-9 Header/Footer

6-1-10 Date &Time Transmission

6-1-11 Date &Time Delimiter

6-1-12 Delimiter Content

6-1-13 Transmission Length

6-1-14 Reject Same

6-1-15 Good Read Beep

6-1-16 Warning Beep

6-1-17 Normal Beep

6-1-18 Good Read Vibrator

6-1-19 Warning Vibrator

6-1-20 Normal Vibrator

6-1-21 Vibrator Time

6-1-22 Force Case

6-1-23 Transmission Code ID

6-1-24 Code ID Position

6-1-25 Transmission Code Name

6-1-26 Good Read Volume

6-1-27 Warning Beep Volume

6-1-28 Normal Volume

6-1-29 Double Confirm

6-1-30Date/Time Position

6-1-31 Preamble Code

6-1-32 Preamble Content

71

6. Memory / Bluetooth General Setting

6-1-33 Postamble Code

6-1-34 Postamble Content

6-1-35 Prefix Code

6-1-36 Prefix Content

6-1-37 Suffix Code

6-1-38 Suffix Content

6-1-39 Control Characters

6-1-40 Delimiter Code

6-1-41 Transmission Unit

6-1-42 Transmission Data All Delete

6-2 General Bluetooth Mode Setting

6-2-1 Mode

6-2-2 Output Interface

6-2-3 Scan Activation Time

6-2-4 Composite Triggers Functionality

6-2-5 Small Trigger Functionality

6-2-6 Battery Charge

6-2-7 Power Saving Time

6-2-8 Standby Time

6-2-9 BT Pairing

6-2-10 BT Pairing Time

6-2-11 Good Read Beep

6-2-12 Warning Beep

6-2-13 Normal Beep

6-2-14 Good Read Vibrator

6-2-15 Warning Vibrator

6-2-16 Normal Vibrator

6-2-17 Vibtator Time

6-2-18 Transmission Length

6-2-19 Force Case

6-2-20 Transmission Code ID

6-2-21 Code ID Postition

6-2-22 Transmission Code Name

6-2-23 Good Read Volume

6-2-24 Warning Volume

6-2-25 Normal Volume

6-2-26 Beep Tone

6-2-27 Beep Time

6-2-28 Double Confirm

72

6. Memory / Bluetooth General Setting

6-2-29 Date/Time Position

6-2-30 Preamble Code

6-2-31 Preamble Content

6-2-32 Postamble Code

6-2-33 Postamble Content

6-2-34 Prefix Code

6-2-35 Prefix Content

6-2-36 Suffix Code

6-2-37 Suffix Content

6-2-38 Control Characters

6-2-39 Delimiter Code

6-2-40 Delimiter Content

6-2-41 Reject Same

6-2-42 Date &Time Transmission

6-2-43 Date &Time Delimiter

6-3 General Cable Mode Setting – By User Manual

6-3-1 Mode

6-3-2 Output Interface

6-3-3 Scan Activation Time

6-3-4 Composite Triggers Functionality

6-3-5 Small Trigger Functionality

6-3-6 Battery Charge

6-3-7 Power Saving Time

6-3-8 Standby Time

6-3-9 Date &Time Transmission

6-3-10 Date &Time Delimiter

6-3-11 Reject Same

6-3-12 Good Read Beep

6-3-13 Warning Beep

6-3-14 Normal Beep

6-3-15 Good Read Vibrator

6-3-16 Warning Vibrator

6-3-17 Normal Vibrator

6-3-18 Vibtator Time

6-3-19 Transmission Length

6-3-20 Force Case

6-3-21 Transmission Code ID

6-3-22 Code ID Postition

6-3-23 Transmission Code Name

73

6. Memory / Bluetooth General Setting

6-3-24 Good Read Volume

6-3-25 Warning Volume

6-3-26 Normal Volume

6-3-27 Beep Tone

6-3-28 Beep Time

6-3-29 Double Confirm

6-3-30 Date/Time Position

6-3-31 Preamble Code

6-3-32 Preamble Content

6-3-33 Postamble Code

6-3-34 Postamble Content

6-3-35 Prefix Code

6-3-36 Prefix Content

6-3-37 Suffix Code

6-3-38 Suffix Content

6-3-39 Control Characters

6-3-40 Delimiter Code

6-3-41 Delimiter Content

6-4 Scanner Configuration by Software

6-4-1 Firmware update

6-4-2 Scanner Configuration

Enter 74 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1 General Memory Mode Setting – By User Manual

6-1-1 Mode

This function to set operation Mode:
(1) Good Read Off: When pressing “Scan” key, turning on scanning light,

scanning barcode correctly or over loading time to make barcode scanning
incorrectly, the light will be turned off.

(2) Momentary: When pressing “Scan” key, turning on scanning light,

scanning barcode correctly or release “Scan” key, the light will be turned
off.

(3) Continue: When pressing “Scan” key, turning on scanning light, No need to

press the trigger then the scanner can read barcode when the LED light
source is on.

(4) Toggle: Scan Toggle label if you intend to gain more flexibility in when to

read a barcode. A press on Scan Button will lead in switching on the light
whereas either a successful decoding of a barcode or giving it another
press correspondingly switches off the light. Please scan the appropriate
label to determine your preferred scan mode.

*BE080*

Good Read Off

*BE081*

Momentary

*BE082*

Continue

*BE083*

Toggle

6. Memory / Bluetooth/ Cable General

6-1 General Memory Mode Setting

6-1-1 Mode

Enter 75 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-2 OutputInterface

Please scan the appropriate barcode to specify the output interface

*BE1D0*

AppStd

*BE1D1*

Usb-Hid

*BE1D2*

Usb-Spp

*BE1D3*

Spp

*BE1D4*

Usb-Mass

6-1-2 Output Interface

Enter 76 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-3 Scan Activation Time

In general, after Scan Button is pressed down, LED light will emit a stream of
light for a scan attempt. This parameter is thus used to specify activation
duration which indicates the amount of time LED light will stays on after Scan
button is held.

*BFDE0*

Configuration Range Unit Default Setting

5 Secs ~ 4 Min 15 Secs 1 Secs 10 Secs

6-1-4 Composite Triggers Functionality

ctionality

Some supplementary functions are necessarily executed by using composite
triggers though Scan Button primarily serves to scan barcodes, and Small
Trigger to initiate data transmission. In Memory mode, all the scanned barcode
data will be deleted by pressing small trigger and Scan button in a specified
sequence described below: while holding the smaller till the orange LED light
starts flashing rapidly, press down Scan button at the same time and then
release both buttons. Scan the appropriate label to DelAll or disable
functionality of file deletion.

*BE280*

Disable

*BE281*

DelAll

(A) Scan “Enter” barcode
(B) Scan “Scan Activation Time” barcode
(C) Scan parameters from Hexadecimal / Decimal table
(D) Scan “OK“ barcode
(E) Scan “End” barcode

6-1-4 Composite Triggers Functionality

6-1-3 Scan Activation Time

Enter 77 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-5 Small Trigger Functionality tionality

Small Trigger is designed to perform various supplementary operations, from
deleting single scanned , data charge to switching to data transmission mode,
according to the length of time the button has been pressed. To facilitate the
associated operations with Small Trigger, this parameter is available to specify
the degree of Small Trigger’s functionality. Scan Disable label to specify Small
Trigger will not provide any additional function. On the other hand, when Mem
Tx is enabled, the device able to switch to data transmission mode. By default,
Small Trigger is set for maximum functionality without limit.

*BE290*

Disable

*BE291*

Del

*BE292*

MemTx

*BE293*

Normal

6-1-6 Battery Charge

Scan the appropriate barcode to determine whether to initiate battery charge
whenever the device is well connected to host PC using an interface cable.

*BE300*

Disable

*BE301*

Enable

6-1-5 Small Trigger Functionality

6-1-6 Battery Charge

Enter 78 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-7 Power Saving Time

The device will switch to power-saving mode after remaining idle for a while.
This parameter is thus used to specify the length of time allocated for the
scanner to elapse before power-saving mode is initiated

.

*BFEE0*

Configuration Range Unit Default Setting

0 Secs ~ 4 Min 15 Secs 1 Secs 0 Secs

(A) Scan “Enter” barcode
(B) Scan “Power Saving Time” barcode
(C) Scan parameters from Hexadecimal / Decimal table
(D) Scan “OK“ barcode
(E) Scan “End” barcode

6-1-7 Power Saving Time

Enter 79 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-8 Stand by Time

After lengthy idleness, the device will first be put into standby state in which the
machine is still able to react to the emergent request yet running in lower
power consumption. This parameter refers to the amount of time allocated for
the device to stay in standby before being totally shut down.

*BFFE0*

Configuration Range Unit Default Setting

1 0Secs ~ 4 Min 15 Secs 1 Sec 10 Secs

Procedure Example

(A) Scan “Enter” barcode
(B) Scan “Stand by time” barcode
(C) Scan parameters from

Hexadecimal / Decimal table
(D) Scan “OK“ barcode
(E) Scan “End” barcode

If configuration is 1 minutes, the
parameter value is 1 min / 1 sec = 60

6-1-8 Stand by Time

Enter 80 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-9 Header/Footer

The user push small key to transmit data from memory. The user will be able to
verify the barcode data saved in the memory by the header <Header><Footer>.
User can enable / Disable the function by scanning the following barcode.

Header:

*BE760*

Disable

*BE761*

Enable

Footer:

*BE770*

Disable

*BE771*

Enable

6-1-9 Header/Footer

Enter 81 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-10 Date & Time Transmission

The user scans following barcode to Enable/Disable date and time for every

data in memory.

Date:

*C0130*

Disable

*C0131*

Enable

Time:

*C0140*

Disable

*C0141*

Enable

6-1-11 Date &Time Delimiter

When the display is used to set the date and time, date delimiter between date
parameters and time parameters

*C0AE2*

Procedure

(A) Scan “Enter” barcode
(B) Scan “Date & Time Delimiter” barcode
(C) Scan parameters from Hexadecimal / Decimal table
(D) Scan “OK“ barcode
(E) Scan “End” barcode

6-1-10 Date & Time Transmission

6-1-11 Date & Time Delimiter

Enter 82 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-12 Delimiter Content

If user want to delimit datetime & barcode. Please scan below barcode to
setting.

*C0BE2*

6-1-13 Transmission Length

If user needs to know the length of the barcode data, this configuration enables
to indicate the barcode length in front of barcode data.

*C0061*

Enable

*C0060*

Disable

Procedure

(A) Scan “Enter” barcode
(B) Scan “Delimiter Content” barcode
(C) Scan parameters from Hexadecimal / Decimal table
(D) Scan “OK“ barcode
(E) Scan “End” barcode

6-1-13 Transmission Length

6-1-12 Delimiter Content

Enter 83 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-14 Reject Same

In Memory mode, the user scan the appropriate barcode to enable or disable

Reject Same. This function is for prevent from same barcode scanning
repeatedly.

*C0200*

Disable

*C0201*

Enable

6-1-15 Good Read Beep

Scan the appropriate barcode to enable or disable Good Read Buzzer when a
barcode is successfully decoded.

*BE500*

Disable

*BE501*

Enable

6-1-14 Reject Same

6-1-15 Good Read Beep

Enter 84 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-17 Warning Beep

Scan the appropriate barcode to enable or disable Warning Buzzer when an
error occurs

.

*BE510*

Disable

*BE511*

Enable

6-1-17 Normal Beep

Normal Event Buzzer is used to give an acoustic signal whenever certain
operations, Scan the appropriate barcode to enable or disable Normal Event
Buzzer.

*BE520*

Disable

*BE521*

Enable

6-1-16 Warning Beep

6-1-17 Normal Beep

Enter 85 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-18 Good Read Vibrator

Scan the appropriate barcode to enable or disable Good Read Vibrator when a
barcode is successfully decoded.

*BE600*

Disable

*BE601*

Enable

6-1-19 Warning Vibrator

Scan the appropriate barcode to enable or disable Warning Vibrator when an
error occurs.

*BE610*

Disable

*BE611*

Enable

6-1-18 Good Read Vibrator

6-1-19 Warning Vibrator

Enter 86 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-20 Normal Vibrator

Normal Event Vibrator is used to give a vibration signal whenever certain
operations, Scan the appropriate barcode to enable or disable Normal Event
Vibrator.

*BE620*

Disable

*BE621*

Enable

6-1-21 Viberator Time

Please follow the below steps to specify the length of time the device stays in a
state of vibration when a barcode is decoded successfully

*BFAE0*

Configuration Range Unit Default Setting

0.02 Secs ~ 2.55 Secs 0.01 Sec 0.05 Secs

Procedure

(A) Scan “Enter” barcode
(B) Scan “Viberator Time” barcode
(C) Scan parameters from Hexadecimal / Decimal table
(D) Scan “OK“ barcode
(E) Scan “End” barcode

6-1-20 Normal Vibrator

6-1-21 Viberator Time

Enter 87 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-22 Force Case

This configuration enables to convert all output digits to be same printing-case;
even one barcode may have two kinds of case

*C0380*

None

*C0382*

Lower

*C0381*

Inverse

*C0383*

Upper

6-1-23 Transmission Code ID

When scanning the barcode, User might want to know the symbology of the
barcode ID, This configuration enables to display the Code ID or Sub Code ID.

*C0040*

Disable

*C0041*

Enable

6-1-22 Force Case

6-1-23 Transmission Code ID

Enter 88 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-24 Code ID Position

When “Transmission Code ID” is “Enable”, user can configure the output
position of Code ID or Sub Code ID (Before Barcode/ After Barcode).

*C0050*

Before Barcode

*C0051*

After Barcode

6-1-25 Transmission Code Name

This configuration enables to show the barcode symbology name. Symbology
name will be showing in front of barcode data.

*C0070*

Disable

*C0071*

Enable

6-1-24 Code ID Position

6-1-25 Transmission Code Name

Enter 89 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-26 Good Read Volume

Scan the appropriate barcode to specify the volume of Good Read Buzzer
when a barcode is decoded successfully. The higher level indicates the louder
sound.

*BE480*

Level1

*BE481*

Level2

*BE482*

Level3

*BE483*

Level4

6-1-27 Warning Beep Volume

Scan the appropriate barcode to specify the volume of Warning Buzzer when
an error occurs. The higher level indicates the louder sound.

*BE490*

Level1

*BE491*

Level2

*BE492*

Level3

*BE493*

Level4

6-1-26 Good Read Volume

6-1-27 Warning Beep Volume

Enter 90 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-28 Normal Volume

Scan the appropriate barcode to specify the volume of Normal Event Buzzer
when certain operations, such as switching operation modes, entering data
transmission mode, and deleting all saved barcodes, are initiated by using
Scan Button or Small Trigger so that LED indicator accordingly changes its
blinking frequency or color. The higher level indicates the louder sound.

*BE4A0*

Level1

*BE4A1*

Level2

*BE4A2*

Level3

*BE4A3*

Level4

6-1-29 Double Confirm

This option enables the scanner to double confirm the barcode data, if this
option is enabled, the scanner will require more times to verify the barcode
data. This setting will related to the double confirm count configuration, the
more confirm counts will inhibit miss-reading barcodes.

*C0210*

Disable

*C0211*

Enable

6-1-29 Double Confirm

6-1-28 Normal Volume

Enter 91 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-30 Date/Time Position

If you want to display data from Memory, you can use this function to set
Date/Time position. Date and Time Transmission must be enabled and
configure the following formats: (chapter: 6-1-10)

*C0120*

Before Barcode

*C0121*

After Barcode

6-1-31 Preamble code

Preamble Code refers to a sequence of characters which precedes both Prefix
Code and barcode data during data transmission. Scan the appropriate
barcode to enable or disable Preamble Code.

*C0000*

Disable

*C0001*

Enable

6-1-30 Date/Time Position

6-1-31 Preamble code

Enter 92 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-32 Preamble Content

Setting Preamble code content

*C0CE3*

6-1-33 Postamble code

Postamble Code refers to a sequence of characters which appends to both
barcode data and Suffix Code during data transmission. Scan the appropriate
barcode to enable or disable Postamble Code.

*C0010*

Disable

*C0011*

Enable

Procedure

(A) Scan “Enter” barcode
(B) Scan “Preamble Content” barcode
(C) Scan parameters from Hexadecimal / Decimal table
(D) Scan “OK“ barcode
(E) Scan “End” barcode

6-1-33 Postamble Code

6-1-32 Preamble Content

Enter 93 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-34 Postamble Content

Setting Postamble code content

*C0EE3*

6-1-35 Prefix code

Prefix Code is a sequence of characters interposed between Preamble Code
and barcode data during data transmission. Scan the appropriate barcode to
enable or disable Prefix Code

*C0020*

Disable

*C0021*

Enable

Procedure

(A) Scan “Enter” barcode
(B) Scan “Postamble Content” barcode
(C) Scan parameters from Hexadecimal / Decimal table
(D) Scan “OK“ barcode
(E) Scan “End” barcode

6-1-35 Prefix Code

6-1-34 Postamble Content

Enter 94 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-36 Prefix Content

Setting Prefix code content

*C10E5*

6-1-37 Suffix code

Suffix Code is a sequence of characters interposed between barcode data and
Postamble Code during data transmission. Scan the appropriate barcode to
enable or disable Suffix Code.

*C0030*

Disable

*C0031*

Enable

Procedure

(A) Scan “Enter” barcode
(B) Scan “Prefix Content” barcode
(C) Scan parameters from Hexadecimal / Decimal table
(D) Scan “OK“ barcode
(E) Scan “End” barcode

6-1-37 Suffix Code

6-1-36 Prefix Content

Enter 95 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-38 Prefix Content

Setting Suffix code content

*C18E5*

6-1-39 Control Characters

Scan the appropriate barcode to determine whether or not to transmit control
code info along with the decoded message if the scanned barcode contains
the special ASCII code.

*C0100*

Disable

*C0101*

Enable

Procedure

(A) Scan “Enter” barcode
(B) Scan “Suffix Content” barcode
(C) Scan parameters from Hexadecimal / Decimal table
(D) Scan “OK“ barcode
(E) Scan “End” barcode

6-1-39 Contorl Characters

6-1-38 Suffix Content

Enter 96 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-40

Delimiter code

Scan the appropriate barcode to determine whether or not to interpose the
delimiter parameter between the decoded message and timestamps.

*C0110*

Disable

*C0111*

Enable

6-1-41

Transmission Unit

Set the transmission mode to the batch transfer or single

*BE7C0*

Normal

*BE7C1*

1 By 1

6-1-40 Delimiter code

6-1-41 Transmission Unit

Enter 97 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-1-41

Transmission Data All Delete

Memory after sending the data, whether to remove all data in Memory

*BE7A0*

None

*BE7A1*

DelAll

6-1-42 Transmission Data All Delete

Enter 98 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-2 General Bluetooth Mode Setting – By User Manual

6-2-1 BT Mode

This function to set operation Mode:
(1) Good Read Off: When pressing “Scan” key, turning on scanning light,

scanning barcode correctly or over loading time to make barcode
scanning incorrectly, the light will be turned off.

(2) Momentary: When pressing “Scan” key, turning on scanning light,

scanning barcode correctly or release “Scan” key, the light will be turned

off.
(3) Continue: When pressing “Scan” key, turning on scanning light, No need to

press the trigger then the scanner can read barcode when the LED light

source is on.
(4) Toggle: Scan Toggle label if you intend to gain more flexibility in when to

read a barcode. A press on Scan Button will lead in switching on the light

whereas either a successful decoding of a barcode or giving it another

press correspondingly switches off the light. Please scan the appropriate

label to determine your preferred scan mode.

*C4080*

Good Read Off

*C4081*

Momentary

*C4082*

Continue

*C4083*

Toggle

6-2 General Bluetooth Mode Setting

6-2-1 BT Mode

Enter 99 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-2-2 OutputInterface

Please scan the appropriate barcode to specify the output interface

*C41D1*

Spp-Slave

*C41D2*

Spp-Master

*C41D3*

Hid

*C41D4*

Hid-iOS

*C41D5*

Hid-A303

*C41D6*

Hid-A302

*C41D7*

Spp-A303PT

6-2-2 Output Interface

Enter 100 End

*/$%ENTR* *ZEND*

6. Memory / Bluetooth General Setting

6-2-3 Scan Activation Time

In general, after Scan Button is pressed down, LED light will emit a stream of
light for a scan attempt. This parameter is thus used to specify activation
duration which indicates the amount of time LED light will stays on after Scan
button is held.

*C5DE0*

Configuration Range Unit Default Setting

5 Secs ~ 4 Min 15 Secs 1 Secs 10 Secs

6-2-4 Composite Triggers Functionality

ctionality

Some supplementary functions are necessarily executed by using composite
triggers though Scan Button primarily serves to scan barcodes, and Small
Trigger to initiate data transmission. In Bluetooth mode, Bluetooth paring is an
extra function which can be initiated by pressing Small Trigger and Scan
Button in a specified sequence described below: while holding Small Trigger till
the blue LED light starts flashing rapidly, press down Scan Button at the same
time and then release both buttons. Scan the appropriate label to Pair or
disable pairing functionality.

*C4280*

Disable

*C4281*

Pair

Procedure

(A) Scan “Enter” barcode
(B) Scan “Scan Activation Time” barcode
(C) Scan parameters from Hexadecimal / Decimal table
(D) Scan “OK“ barcode
(E) Scan “End” barcode

6-2-4 Composite Triggers Functionality

6-2-3 Scan Activation Time
