Candy CM2 146-47 User Manual

W.MACHINE/WASHER-DRYER
31000854 CM2 146-47
Service Manual
31000854 CM2 146-47 0512 (18/03/2005)
Ricambio Part No. Piece
Ref. Descrizione - Description - Beschreibung - Descripcion
2 Programs disc 41013997 0521 (16/05/2005) 2 Programs disc 41015951 0521 (16/05/2005)
15 Cam disc 41000265 0521 (16/05/2005)
19a Button 0/1 41013656
31 Control panel 40002339
32 Dispenser drawer front 41013998
47 Table top front frame 91602091
48 R/H side frame 91601685
48a L/H side frame 91601686
49 Top rear frame 91601680
51 Work top 91500655
55 Insulating side 91624924
59a Latch guide fix.screw 91402201
E-Teil Pieza
Inizio Beginning Debut Begin Inicio
Fine Ending Fin End Fin
60 Hinge 91700102
62 Door surround 41013807
63 Door glass 91600903
65a Door catch with spring service pack 49005361
67 Glass door with frame 41014003
67d Counter ring 41013808
76 Cabinet assy 04230672
77 Rear panel 97911044
78 Socle 41006148
79 Rear foot 92606474
80 Front foot 92692300
94c Filter knob with gasket 06015493
96 Gasket 92606391
97c Stopper x drain/recycle pump 97918437
97d Filt hous w/filter cartridge 91941772
101 Dispenser drawer 92953249 0521 (16/05/2005) 101 Dispenser drawer 41013614 0521 (16/05/2005)
103 Rack 91601905
109 Dispenser bottom section assy 92967918 0521 (16/05/2005)
Copyright 2007 Gias S.r.L.
