Candy CIS633DTT User Manual

Instruction Manual For Induction Hob
ENGLISH
Instruction Manual / Mode demploi
MODEL: CIS633DTT
Thank you for purchasing the CANDY induction hob. Please read this instruction
manual carefully before using the hob and keep it in a safe place for future reference.
EN-1
By placing the mark on this product, we are confirming compliance to all relevant European safety, health and environmental requirements which are applicable in legislation for this product.
Safety Warnings
Your safety is important to us. Please read this information before using your cooktop.
Installation Electrical Shock Hazard
Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance on it.
Connection to a good earth wiring system is essential and mandatory.
Alterations to the domestic wiring system must only be made by a qualified electrician.
Failure to follow this advice may result in
electrical shock or death.
Cut Hazard
Take care - panel edges are sharp.
Failure to use caution could result in injury or
cuts.
Important safety instructions
Read these instructions carefully before installing or using this appliance.
No combustible material or products should be
placed on this appliance at any time.
Please make this information available to the person responsible for installing the appliance as it could reduce your installation costs.
In order to avoid a hazard, this appliance must be installed according to these instructions for installation.
This appliance is to be properly installed and earthed only by a suitably qualified person.
This appliance should be connected to a circuit which incorporates an isolating switch providing full disconnection from the power supply.
Failure to install the appliance correctly could invalidate any warranty or liability claims.
Operation and maintenance Electrical Shock Hazard
Do not cook on a broken or cracked cooktop. If
the cooktop surface should break or crack, switch the appliance off immediately at the mains power supply (wall switch) and contact a qualified technician.
Switch the cooktop off at the wall before
cleaning or maintenance.
Failure to follow this advice may result in
electrical shock or death.
Health Hazard
This appliance complies with electromagnetic
EN-2
safety standards.
However, persons with cardiac pacemakers or other electrical implants (such as insulin pumps) must consult with their doctor or implant manufacturer before using this appliance to make sure that their implants will not be affected by the electromagnetic field.
Failure to follow this advice may result in death.
Hot Surface Hazard
During use, accessible parts of this appliance will become hot enough to cause burns.
Do not let your body, clothing or any item other than suitable cookware contact the Induction glass until the surface is cool.
• Metallic objects such as knives, forks, spoons
and lids should not be placed on the hob surface since they can get hot
• Keep children away.
Handles of saucepans may be hot to touch.
Check saucepan handles do not overhang other cooking zones that are on. Keep handles out of reach of children.
Failure to follow this advice could result in
burns and scalds.
Cut Hazard
The razor-sharp blade of a cooktop scraper is
exposed when the safety cover is retracted. Use with extreme care and always store safely and out of reach of children.
Failure to use caution could result in injury or
cuts.
EN-3
Important safety instructions
Never leave the appliance unattended when in
use. Boilover causes smoking and greasy spillovers that may ignite.
Never use your appliance as a work or storage
surface.
Never leave any objects or utensils on the
appliance.
Do not place or leave any magnetisable objects
(e.g. credit cards, memory cards)or electronic devices (e.g. computers, MP3 players) near the appliance, as they may be affected by its electromagnetic field.
Never use your appliance for warming or
heating the room.
After use, always turn off the cooking zones
and the cooktop as described in this manual (i.e. by using the touch controls). Do not rely on the pan detection feature to turn off the cooking zones when you remove the pans.
• Do not allow children to play with the appliance
or sit, stand, or climb on it.
• Do not store items of interest to children in
cabinets above the appliance. Children climbing on the cooktop could be seriously injured.
• Do not leave children alone or unattended in
the area where the appliance is in use.
• Children or persons with a disability which
limits their ability to use the appliance should
EN-4
have a responsible and competent person to instruct them in its use. The instructor should be satisfied that they can use the appliance without danger to themselves or their surroundings.
• Do not repair or replace any part of the
appliance unless specifically recommended in the manual. All other servicing should be done by a qualified technician.
• Do not use a steam cleaner to clean your
cooktop.
• Do not place or drop heavy objects on your
cooktop.
• Do not stand on your cooktop.
• Do not use pans with jagged edges or drag pans
across the Induction glass surface as this can scratch the glass.
• Do not use scourers or any other harsh
abrasive cleaning agents to clean your cooktop, as these can scratch the Induction glass.
• If the supply cord is damaged, it must be
replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
This appliance is intended to be used in household and similar applications such as:
-staff kitchen areas in shops, offices and other working environments; -farm houses; -by clients in hotels, motels and other residential type environments; -bed and breakfast type environments.
WARNING: The appliance and its accessible
parts become hot during use.
EN-5
Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised.
This appliance can be used by children aged
from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
WARNING: Unattended cooking on a hob with
fat or oil can be dangerous and may result in fire. NEVER try to extinguish a fire with water, but switch off the appliance and then cover flame e.g. with a lid or a fire blanket.
WARNING: Danger of fire: do not store items on
the cooking surfaces.
• Warning: If the surface is cracked, switch off
the appliance to avoid the possibility of electric shock, for hob surfaces of glass-ceramic or similar material which protect live parts
A steam cleaner is not to be used.
The appliance is not intended to be operated by
means of an external timer or separate remote-control system.
EN-6
CAUTION: The cooking process has to be supervised. A short term cooking process has to be supervised continuously. WARNING: In order to prevent tipping of the appliance, this stabilizing means must be installed. Refer to the instructions for installation. WARNING: Use only hob guards designed by the manufactuer of the cooking appliance or indicated by the manufacture of the appliance in the instruction for use as suitable or hob guards incorporated in the appliance. The use of inappropriate guards can cause accidents.
This appliance incorporates an earth connection for functional purposes only.
Congratulations on the purchase of your new Induction Hob.
We recommend that you spend some time to read this Instruction / Installation Manual in order to fully understand how to install correctly and operate it. For installation, please read the installation section. Read all the safety instructions carefully before use and keep this Instruction / Installation Manual for future reference.
EN-7
Product Overview
1.2000 W zone, boost to 2600W
2.1500 W zone, boost to 2000W
3.2300 W zone, boost to 3000W
4. Glass plate
5. Control panel
1. Heating zone selection indicator
2. Timer indicator
3. Power/timer regulating key
4. keylock control
5. ON/OFF control
6. Boost function control
7. Stop+Go control
8. Keep warm function control
Top View
Control Panel
EN-8
A Word on Induction Cooking
iron pot
magnetic circuit ceramic glass plate induction coil induced currents
Induction cooking is a safe, advanced, efficient, and economical cooking technology. It works by electromagnetic vibrations generating heat directly in the pan, rather than indirectly through heating the glass surface. The glass becomes hot only because the pan eventually warms it up.
Before using your New Induction Hob
• Read this guide, taking special note of the ‘Safety Warnings’ section.
Remove any protective film that may still be on your Induction hob.
Using the Touch Controls
• The controls respond to touch, so you don’t need to apply any pressure.
Use the ball of your finger, not its tip.
You will hear a beep each time a touch is registered.
Make sure the controls are always clean, dry, and that there is no object (e.g. a
utensil or a cloth) covering them. Even a thin film of water may make the controls difficult to operate.
EN-9
Choosing the right Cookware
Only use cookware with a base suitable for induction
cooking. Look for the induction symbol on the
You can check whether your cookware is suitable by carrying out
a magnet test. Move a magnet towards the base of the pan. If it is attracted, the pan is suitable for induction.
If you do not have a magnet:
1. Put some water in the pan you want to check.
2. If does not flash in the display and the water is heating, the pan is suitable.
Cookware made from the following materials is not suitable: pure stainless steel, aluminium or
copper without a magnetic base, glass, wood, porcelain, ceramic, and earthenware.
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking zone. Use pans whose diameter is as large as the graphic of the zone selected. Using a pot a slightly wider energy will be used at its maximum efficiency. If you use smaller pot efficiency could be less than expected. Always centre your pan on the cooking zone.
packaging or on the bottom of the pan.
Always lift pans off the Induction hob – do not slide, or they may scratch the glass.
Pan dimensions
The cooking zones are up to a limit, automatically adapted to the diameter of the pan. However the bottom of this pan must have a minimum of diameter according to the corresponding cooking zone. To obtain the best efficiency of your hob, please place the pan in the centre of the cooking zone.
EN-10
The base diameter of induction cookware
Cooking zone
Minimum (mm)
1,2(180mm)
120
3 (280mm)
180
The above may vary according to the quality of the pan used.
Using your Induction Hob
To start cooking
1. Touch the ON/OFF control.
After power on, the buzzer beeps once, all displays show
“ – “ or “ –“, indicating that the induction hob has entered
the state of standby mode.
2. Place a suitable pan on the cooking zone that
you wish to use.
Make sure the bottom of the pan and the surface of the cooking zone are clean and dry.
3.Select one heating zone and set a power level by touching the - or + control.
a. If you don’t set the power within 1 minute, the induction hob will
automatically switch off. You will need to start again at step 1.
b. You can modify the heat setting at any time during cooking.
If the display flashes alternately with the heat setting
This means that:
you have not placed a pan on the correct cooking zone or,
EN-11
• the pan you’re using is not suitable for induction cooking or,
the pan is too small or not properly centred on the cooking zone.
No heating takes place unless there is a suitable pan on the cooking zone. The display will automatically turn off after 1 minutes if no suitable pan is placed on it.
When you have finished cooking
1. Turn the cooking zone off by touching the - control that you
wish to switch off.
Make sure the power display shows 0, then shows H.
and then
2. Turn the whole cooktop off by touching the ON/OFF control.
3. Beware of hot surfaces
Hwill show which cooking zone is hot to touch. It will disappear when the
surface has cooled down to a safe temperature. It can also be used as an energy saving function if you want to heat further pans, use the hotplate that is still hot.
Using the Power Management
Using power management you can set the total power to 2.5kW/ 3.0kW/ 4.5kW/
5.5kW and 6.9kW. The default total power setting is the maximum power level.
Setting the total power level to fit your requirement
1. Make sure the cooktop is turned off.
Note: you can only set power management when the cooktop is turned off.
2.Touch the button Stop + Go and hold for 5 seconds. You can hear
EN-12
the buzzer beeps one time.
3. After you hear the beep, touch “+” and “-” button at the same time and hold for
3 second, the timer indicator will show flashing previous total power level, e.g. 2.5. Touch and hold ” +” and ”- for 1 second again to switch to other power level, for example 3.0. When the power that you want is flashing, touch the button Stop+Go and hold for 5 seconds. The buzzer will beep 10 times. It means you have finished the setting.
Note:
1. After step 2, you must touch the + and - within 3 seconds after you hear
the beep. Otherwise you will need to start again from step 2.
2. Once finish setting, wait till the end of 10 beeps. Do not touch any button during
this period. Otherwise the setting will be invalid.
Power management Rules
If total power exceeds the limitation of 2.5kw, 3.0kw, 4.5kw, 5.5kw (depending
on which level you’ve set), you are not able to increase power stage of any zone. If you increase it by touching ‘+’, the cooktop will beep 3 times and indicator will show a flashing ‘Pn. Thus you need to decrease power stage of other zones before
increasing the power of objective zone.
Using the Boost
Boost is the function that one zone rising to a larger power in one second and lasting for 5 minutes. Thus you can get a more powerful and faster cooking.
Using the Boost to get larger power
1. Touch the “-“ or “+” to activate the zone that you wish to boost,
an indicator next to the key will flash.
2. Touch the Boost button, the heating zone will begin to work at
EN-13
Boost mode. The power display will show P to indicate that the zone is boosting.
3. The Boost power will last for 5 minutes and then the zone will go back to the
9power stage.
4. If you want to cancel Boost, touch - or +” to activate the zone first, an
indicator next to the key will flash. And then touch the Boost button, the heating zone will go back to the power stage 9.
Restrictions when using
The three zones were divided into two groups. In one group, if use boost on one zone, first make sure that the other zone is working on/below power level 5.
EN-14
Using the Keep warm
Keep warm is the function that one zone keep a lower power to make the temperature stable.
Using the Keep warm to get stable temperature
1. Touch the - or +” to activate the zone that you wish to use keep warm, an
indicator next to the key will flash.
2. Touch the button , the cooking zone indicator will display A”.
3. If you want to cancel the keep warm, touch - or +” to activate the zone first,
an indicator next to the key will flash. And then touch the keep warm button, the heating zone will go back to 0 power stage.
Using the Pause function- Stop+Go
Pause function can be used at any time during cooking. It allows to stop the induction cooktop and come back to it.
1. Make sure the cook zone is working.
2. Touch the button STOP+GO, the cooking zone indicator will show ll.
And then the operation of the induction cooktop will be deactivate within the scope of all cooking zones, except the STOP+GO, on/off and lock keys.
EN-15
3. To cancel the pause status, touch the Stop+Go function, then the cooking zone
will go back to the power stage which you set before.
Locking the Controls
You can lock the controls to prevent unintended use (for example children
accidentally turning the cooking zones on).
When the controls are locked, all the controls except the ON/OFF control are
disabled.
To lock the controls
Touch the keylock control. The timer indicator will show “ Lo .
To unlock the controls
1. Make sure the Induction hob is turned on.
2. Touch and hold the keylock control for a while
3. You can now start using your Induction hob.
When the hob is in the lock mode, all the controls are disable except the ON/OFF, you can always turn the induction hob off with the ON/OFF control in an emergency, but you shall unlock the hob first in the next operation.
Over-Temperature Protection
A temperature sensor equipped can monitor the temperature inside the Induction hob. When an excessive temperature is monitored, the Induction hob will stop operation automatically.
Over-spillage Protection
Over-spillage protection is a safety protection function. It switch off the hob automatically within 10s if the water flow to the control panel, while buzzer will beep 1 second.
EN-16
Detection of Small Articles
Power level
1 2 3 4 5 6 7 8 9 A II
Default working timer (hour)
8 8 8 4 4 4 2 2 2 2 2
When an unsuitable size or non-magnetic pan (e.g. aluminium), or some other small item (e.g. knife, fork, key) has been left on the hob, the hob automatically go on to standby in 1 minute. The fan will keep cooking down the induction hob for a further 1 minute.
Auto Shutdown Protection
Auto shut down is a safety protection function for your induction hob. It shut down automatically if ever you forget to turn off your cooking. The default working times for various power levels are shown in the below table:
When the pot is removed, the induction hob can stop heating immediately and the hob automatically switch off after 2 minutes.
People with a heart pace maker should consult with their doctor before using this unit.
Using the Timer
You can use the timer in two different ways:
You can use it as a minute minder. In this case, the timer will not turn any
cooking zone off when the set time is up.
You can set it to turn one cooking zone off after the set time is up.
You can set the timer up to 99 minutes
Using the Timer as a Minute Minder
If you are not selecting any cooking zone
1. Make sure the cooktop is turned on.
Note: you can use the minute minder even if you’re not selecting any cooking zone.
2. Touch - or + of the timer control , the minder indicator will
start flashing and 99 or 01 will show in the timer display.
EN-17
Loading...
+ 42 hidden pages
