Candy AB CDC 668 - SY User Manual
Instruction Book
CDC668
Condenser Tumble Dryer
®
English
Dansk
Svenska
Norsk
Suomi
40004258Eng.qxd 05/12/2005 14:55 Page 1
English. . . . . . . . . . . . . . . . . . 2
Dansk. . . . . . . . . . . . . . . . . . 20
Svenska . . . . . . . . . . . . . . . . 38
Norsk . . . . . . . . . . . . . . . . . . 56
Suomi. . . . . . . . . . . . . . . . . . 74
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Delivery information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Unpacking the Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety reminders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
The Laundry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Environmental Issues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
GIAS Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Electrical requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Adjusting the feet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Ventilation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Preparing the load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Clothes preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Sorting the load. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Drying advice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Do not tumble dry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Energy saving. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Drying guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Door and Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Opening the door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Filter care indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Water container . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
To remove the container . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Condenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
To remove the condenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Selecting the Programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Cancelling and resetting the programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Start Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Cleaning and Routine Maintenance. . . . . . . . . . . . . . . . . . . . 17
Cleaning the dryer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Customer Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Spares. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
GIAS Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2
40004258Eng.qxd 05/12/2005 14:55 Page 2
Introduction
Please read and follow these instructions
carefully and operate the machine accordingly.
This booklet provides important guidelines for
safe use, installation, maintenance and some
useful advice for best results when using your
machine.
Keep all documentation in a safe place for future
reference or for any future owners
Delivery information
Please check that the following items are
delivered with the appliance:
● Instruction manual
● Guarantee card
● Energy label
Remove the machine from its packaging close to
the final location of the machine.
1. Cut carefully around the base of the
packaging and up one corner.
2. Remove the polythene sleeve and lift the
dryer off the polystyrene base.
3
Check that no
damage has
occurred to the
machine during
transit. If it has,
call for service by
GIAS.
Failure to comply
with the above
can compromise
the safety of the
appliance. You
may be charged
for a service call
if a problem with
your machine is
caused by
misuse.
Unpacking the product
Dispose of the packaging safely. Make
sure it is out of the reach of children,
it is a potential source of danger.
40004258Eng.qxd 05/12/2005 14:55 Page 3
Safety reminders
Installation
● Check that the product has no visible signs of damage before use. If
damaged do not use and please call GIAS Service.
● Do not use adapters, multiple connectors and/or extensions.
● This machine should not be installed in a bathroom or shower room.
● Never install the dryer against curtains and be sure to prevent items from
falling or collecting behind the dryer.
Use
● WARNING Misuse of a tumble dryer may create a fire hazard.
● This machine is solely for domestic use, i.e. to dry household textiles and
garments.
● This machine should only be used for its intended purpose as described in
this manual. Ensure that the instructions for installation and use are fully
understood before operating the appliance.
● Do not touch the appliance when hands or feet are damp or wet.
● Do not lean on the door when loading the machine or use the door to
lift or move the machine.
● Do not allow children to play with the machine or its controls.
● WARNING Do not use the product if the fluff filter is not in position or is
damaged; fluff could be ignited.
● WARNING Where the hot surface symbol is located the temperature
rise during operation of the tumble dryer may be in excess of 60 degrees C.
● Remove the plug from the electricity supply. Always remove the plug
before cleaning the appliance.
● Do not continue to use this machine if it appears to be faulty.
● Lint and fluff must not be allowed to collect on the floor around the
outside of the machine.
● The drum inside may be very hot. Always allow the dryer to complete the
cool down period before removing the laundry.
The Laundry
● WARNING Do not tumble dry fabrics treated with dry cleaning fluids.
● WARNING Foam rubber materials can, under certain circumstances, when
heated become ignited by spontaneous combustion. Foam plastic, foam
rubber and rubber-like material are not suitable for tumble drying.
Articles made from these materials MUST NOT be placed in the dryer.
● Always refer to the laundry care labels for directions on suitability for
drying.
● Clothes should be spin dried or thoroughly wrung before they are put
into the tumble dryer. Clothes that are dripping wet should NOT be put
into the dryer.
4
40004258Eng.qxd 05/12/2005 14:55 Page 4
● Lighters and matches must not be left in pockets and NEVER use
flammable liquids near the machine.
● Glass fibre curtains should NEVER be put in this machine. Skin irritation
may occur if other garments are contaminated with the glass fibres.
● Garments treated or contaminated with flammable cleaning sprays or
liquids such as petrol, cooking oil or aerosol sprays MUST NOT be put in
this machine.
Environmental Issues
● All packaging materials used are environmentally-friendly and recyclable.
Please help dispose of the packaging via environmentally-friendly means.
Your local council will be able to give you details of current means of
disposal.
● To ensure safety when disposing of an old tumble dryer disconnect the
mains plug from the socket, cut the mains power cable and destroy this
together with the plug. To prevent children shutting themselves in the
machine break the door hinges or the door lock.
GIAS Service
● To ensure the continued safe and efficient operation of this appliance we
recommend that any servicing or repairs are only carried out by an
authorised GIAS Service engineer.
European directive 2002/96/EC
This appliance is marked according to the European directive 2002/96/EC on
Waste Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you
will help prevent potential negative consequences for
the environment and human health, which could
otherwise be caused by inappropriate waste handling
of this product.
The symbol on the product indicates that this product
may not be treated as household waste. Instead it shall
be handed over to the applicable collection point for
the recycling of electrical and electronic equipment
Disposal must be carried out in accordance with local
environmental regulations for waste disposal.
For more detailed information about treatment,
recovery and recycling of this product, please contact
your local city office, your household waste disposal
service or the shop where you purchased the product.
5
If the appliance is not running properly or breaks down,
switch it off and disconnect the plug from the socket.
Consult GIAS Service for possible repair.
40004258Eng.qxd 05/12/2005 14:56 Page 5
Electrical requirements
Tumble dryers are supplied to operate at a
voltage of 230V, 50 Hz single phase. Check that
the supply circuit is rated to at least 16A.
Electricity can be extremely dangerous.
This appliance must be earthed.
The socket outlet and the plug on the appliance
must be of the same type.
Do not use multiple adapters and/or extension
leads.
The plug should be accessible for disconnection
after the appliance has been installed.
The wires in the mains lead are coloured in
accordance with the following codes:
Blue NEUTRAL
Brown LIVE
Green and Yellow EARTH
CE Appliance complies with European Directive
89/336/EEC, 73/23/EEC and subsequent
amendments.
Adjusting the feet
Once the machine is in place the feet should be
adjusted to ensure that the machine is level.
Adjust the four feet to ensure the machine is firm
and level.
6
You may be
charged for a
service call if a
problem with
your machine is
caused by
incorrect
installation.
If the mains cord
on this appliance
is damaged, it
must be replaced
by a special cord
which is ONLY
obtainable from
the spares
service. It must
be installed by a
competent
person.
Installation
Do not plug the machine in and
switch it on at the mains until the
installation is completed.
For your safety, this dryer must be
correctly installed.
If there is any doubt about
installation, call GIAS Service for
advice.
40004258Eng.qxd 05/12/2005 14:56 Page 6
Adequate ventilation must be provided in the
room where the tumble dryer is located to
prevent gases from appliances burning other
fuels, including open fires, being drawn into the
room during operation of the tumble dryer.
● Exhaust air must not be discharged into a
flue which is used for exhausting fumes
from appliances burning gas or other fuels.
● Check regularly that the air flowing through
the dryer is not restricted.
● Check the fluff filter after use, and clean, if
necessary.
● The inlet and outlets should be kept free
from obstructions. To ensure adequate
ventilation the space between the bottom
of the machine and the floor must not be
obstructed. There should be a gap of at
least 12mm between the machine and any
obstructions.
● Prevent items from falling or collecting
behind the dryer as these may obstruct the
air inlet and outlet.
● NEVER install the dryer up against curtains.
7
Ventilation
AIR OUTLETS
AIR OUTLETS IN THE BASE
AIR INLET VENTS
40004258Eng.qxd 05/12/2005 14:56 Page 7
Before using the tumble dryer for the first time:
● Please read this instruction book thoroughly.
● Remove all items packed inside drum.
● Wipe the inside of the drum and door with
a damp cloth to remove any dust which may
have settled in transit.
Clothes preparation
Make sure that the laundry you are going to dry
is suitable for drying in a tumble dryer, as shown
by the care symbols on each item.
Check that all fastenings are closed and that
pockets are empty. Turn the articles inside out.
Place clothes loosely in the drum to make sure
that they don't get tangled.
Maximum drying weight
● Cottons Max. 6 kg
● Synthetics Max. 3 kg
8
Preparing the load
Do not overload
the drum, large
items when wet
can exceed the
maximum
admissible
clothes load
(for example:
sleeping bags,
duvets).
40004258Eng.qxd 05/12/2005 14:56 Page 8
Sort the load as follows:
● By care symbols
These can be found on the collar or inside
seam:
Suitable for tumble drying.
Tumble drying at high temperature.
Tumble drying at low temperature only.
Do not tumble dry.
If the item does not have a care label it
must be assumed that it is not suitable
for tumble drying.
● By amount and thickness
Whenever the load is bigger than the dryer
capacity, separate clothes according to
thickness (e.g. towels from thin underwear).
● By type of fabric
Cottons/linen: Towels, cotton jersey, bed and
table linen.
Synthetics: Blouses, shirts, overalls, etc.
made of polyester or polyamid, as well as
for cotton/synthetic mixes.
● By drying level
Sort into: iron dry, cupboard dry, etc. For
delicate articles press the button to
select low drying temperature.
9
40004258Eng.qxd 05/12/2005 14:56 Page 9
Do not tumble dry:
Woollens, silk, delicate fabrics, nylon stockings,
delicate embroidery, fabrics with metallic
decorations, garments with PVC or leather
trimmings, training shoes, bulky items such as
sleeping bags, etc.
Energy saving
Only put into the tumble dryer laundry which has
been thoroughly wrung or spin-dried. The drier
the laundry the shorter the drying time thus
saving electricity.
ALWAYS
● Try to dry the maximum weight of laundry,
this will save time and electricity.
● Check that the filter is clean before every
drying cycle.
NEVER
● Exceed the maximum weight, this will waste
time and electricity.
● Put dripping wet items into the tumble
dryer, this may damage the appliance.
Drying guide
The table shows approximate drying times,
depending on the type of fabric and dampness of
the clothes.
10
Drying advice
IMPORTANT: Do
not dry articles
which have been
treated with a
dry cleaning fluid
or rubber clothes
(danger of fire or
explosion).
During the last
15 minutes the
load is always
tumbled in cool
air.
Fabric
COTTON
SYNTHETICS
ACRYLIC
HEAT
SETTING
HIGH
LOW
LOW
INDICATOR
LIGHT
OFF
ON
ON
HEAVY
LOAD
120-140 min
–
–
MEDIUM
LOAD
100-120 min
50-70 min
40-50 min
LIGHT
LOAD
30-50 min
30-40 min
20-30 min
40004258Eng.qxd 05/12/2005 14:56 Page 10
Control panel and indicator lights
Programme Selector – Select the required programme
On/Off button and indicator – Press to switch on, the indicator will light
START – Press START to commence the selected drying programme. Press for 5 seconds to
cancel/reset the programme
Acrylics/Synthetics button – Press to reduce the heat level for delicate items, the
indicator above the button will light up. To change the heat setting the programme
must be reset
Low Heat – Indicator light ON High Heat – Indicator light OFF
Empty Water indicator – lights when the water container is full
Filter Care indicator – lights when the filter needs cleaning
Start Delay button – Allows the user to delay the start of the drying cycle (see
details of operation page 16)
Display
START – When the dryer is switched On the START indicator will flash, when the
programme starts the START indicator will light up
60' – Indicator lights when there is less than 60 minutes left until completion of the
programme
15' - Indicator lights when there is less than 15 minutes left until completion of the
programme. At this stage of the drying cycle the machine enters the Cool Down phase
STOP - Indicator lights when the programme is finished.
6h - 6 hour start delay (light flashes when in operation)
9h - 9 hour start delay (light flashes when in operation)
11
Controls and indicators
ACRYLICS/
SYNTHETICS
BUTTON
ON/OFF
BUTTON
FILTER CARE
INDICATOR
EMPTY
WATER
INDICATOR
PROGRAMME
SELECTOR
START
BUTTON
START
DELAY
BUTTON
COUNTDOWN
DISPLAY
40004258Eng.qxd 05/12/2005 14:56 Page 11
Opening the door
Pull on handle to open the door.
To restart the dryer, close the door and press
START.
Filter
IMPORTANT: To maintain the efficiency of the
dryer check that the fluff filter is clean before
each drying cycle.
1. Pull the filter upwards.
2. Open filter as shown.
3. Gently remove lint using a soft brush or
your fingertips.
4. Snap the filter together and push back into
place.
Filter Care Indicator
lights when the filter needs cleaning.
If the laundry is not drying check that the filter is
not clogged.
12
Door and Filter
WARNING!
When the tumble dryer is in use the
drum and door may be VERY HOT.
40004258Eng.qxd 05/12/2005 14:56 Page 12
The water removed from the laundry during the
drying cycle is collected in a container at the
bottom of the dryer.
When the container is full the indicator on
the control panel will light, and the container
MUST be emptied. However, we recommend that
the container is emptied after each drying cycle.
NOTE: Very little water will collect during the
first few cycles of a new machine as an internal
reservoir is filled first.
To remove the container
1. Gently pull the bottom of the kickplate so
that it unclips from the dryer. The top
section can then be unhinged allowing the
kickplate to be completely removed.
2. Pull firmly on the handgrip and slide the
water container out of the dryer.
Support the container with both hands. When
full, the water container will weigh about 4kg.
3. Open the lid located on the top of the
container and empty the water.
4. Refit the lid and slide the water container
back into position. PUSH FIRMLY INTO
PLACE.
5. Refit the kickplate by engaging the hinges
at the top and 'snapping' the lower clips
into place.
13
Water Container
40004258Eng.qxd 05/12/2005 14:56 Page 13
Important: Always switch off and remove the
plug from the electricity supply before cleaning
the condenser.
To maintain the efficiency of the dryer regularly
check that the condenser is clean.
To remove the
condenser
1. Remove the kickplate (see page 13).
2. Turn the two locking levers anti-clockwise
and pull out the condenser.
3. Pull out the condenser unit.
4. Gently remove any dust or fluff with a cloth,
then wash the unit by holding it under a
running tap turning it so that water flows
between the plates, to remove any dust or
fluff.
5. Refit the condenser ensuring it is in the
correct way (as indicated by the arrow) and
pushed firmly into place. Lock the two levers
by turning them clockwise.
6. Refit the kickplate.
14
Condenser
40004258Eng.qxd 05/12/2005 14:56 Page 14
Note: The sensor may not detect a small load of
small articles. For small loads and separate items
or pre-dried fabrics with low moisture content,
use the timed programmes. Set the programme
between 30 and 75 minutes depending on the
load size and dryness required, and select high or
low heat depending upon the fabric type.
If the sensor does not detect the item the dryer
will only operate for 10 minutes before going
into cooldown.
If the load is too large or too wet to tumble dry
the dryer will automatically go into cooldown
after 180 minutes.
15
Selecting the Programme
Programme
Bone Dry
Extra Dry
Cupboard Dry
Iron Dry
Medium Dry
Damp Dry
Fast Iron
75'
60'
45'
30'
Refresh
Description
Select the degree of dryness that you require.
This ranges from Bone Dry for bath towels and
bathrobes, through Cupboard Dry for items that
will be put away without ironing, to the
programmes that leave the laundry suitable for
ironing.
The Fast Iron programme provides a conditioning
and anticrease function. The dryer will heat the
load for 9 minutes followed by a 3 minute cool
down period and is especially good for garments
which may have been left for some time prior to
ironing, in a linen basket for example. Garments
may also become stiffened when dried outside on a
washing line or inside on radiators. The Fast Iron
process relaxes the creases in the fabric making
ironing quicker and easier.
75 minutes of drying
60 minutes of drying
45 minutes of drying
30 minutes of drying
Tumbling of laundry in cool air
The Sensor Dry machine gives many options for drying the laundry to suit all
circumstances.
The table below lists the programmes and the function of each programme.
40004258Eng.qxd 05/12/2005 14:56 Page 15
1. Open the door and load the drum with laundry. Ensure that garments do
not hinder closure of the door.
2. Gently close the door pushing it slowly until you hear the door 'click'
shut.
3. Press the button to switch on the dryer. The indicator will light up
and the START indicator will flash.
4. Turn the Programme Selector dial to select the required drying program
(see Programme Guide).
5. If drying synthetics, acrylics or delicate items, press the button to
reduce the heat level.
The light above the push button will light up when the machine is in low
heat setting. To deselect this status when the drying cycle has started it is
necessary to reset the machine.
6. Press the START button. The dryer will start automatically and the START
indicator will be continuously lit.
7. The display will show the drying progress in terms of time
remaining.
8. If the door is opened during the programme to check the laundry, it is
necessary to press START to recommence drying after the door has been
closed.
9. When the 15' indicator is lit the machine will enter the cool down phase,
the clothes will be tumbled in cool air allowing the load to cool down.
10. When the programme is complete the STOP indicator will light.
Cancelling and resetting the
programme
To cancel a programme press the START button for 5 seconds. The machine will
indicate that it has been reset by the START indicator flashing. It is possible to
change the programme within the first 10 minutes without using the cancel
and reset function.
Start Delay
The Delay Start Function allows the user to delay the start of the drying
cycle by 6 or 9 hours.
When the function is first selected the display will show a delay of 6 hours, a
subsequent press of the button will increase the delay to 9 hours.
16
Operation
40004258Eng.qxd 05/12/2005 14:56 Page 16
To commence the programme press START and
the appliance will complete the drying cycle at
the end of this time. The 6 or 9 hour indicator
light will flash to indicate that the start delay is in
progress.
Cleaning the dryer
● Clean the filter and empty the water
container after every drying cycle.
● Regularly clean the condenser.
● After each period of use, wipe the inside of
the drum and leave the door open for a
while to allow circulation of air to dry it.
● Wipe the outside of the machine and the
door with a soft cloth.
● DO NOT use abrasive pads or cleaning
agents.
● To prevent the door sticking or the build up
of fluff periodically clean the inner door and
gasket with a damp cloth.
Technical specifications
Drum capacity 115 litres
Maximum load 6 kg
Height 85cm
Width 60cm
Depth 60cm
Energy Label Band C
17
IMPORTANT
Always switch
off and remove
the plug from
the electricity
supply before
cleaning this
appliance.
For electrical data
refer to the
rating label on
the front of the
dryer cabinet
(with the door
open).
Cleaning and Routine
Maintenance
WARNING!
The drum, door
and load may be
very hot.
40004258Eng.qxd 05/12/2005 14:56 Page 17
What might be the cause of...
Defects you can remedy yourself
Before calling GIAS Service for technical advice please run through the
following checklist. A charge will be made if the machine is found to be
working or has been installed incorrectly or used incorrectly. If the problem
persists after completing the recommended checks, please call GIAS Service,
they may be able to assist you over the telephone.
Drying time is too long/clothes are not dry enough…
● Have you selected the correct drying time/programme?
● Were the clothes too wet? Were the clothes thoroughly wrung or spin-
dried?
● Does the filter need cleaning?
● Does the condenser need cleaning?
● Is the dryer overloaded?
● Are the inlets, outlets and base of the dryer free from obstructions?
● Has the option been selected from a previous cycle?
The dryer does not operate…
● Is there a working electricity supply to the dryer? Check using another
appliance such as a table lamp.
● Is the plug properly connected to the mains supply?
● Is there a power failure?
● Has the fuse blown?
● Is the door fully closed?
● Is the dryer switched on, both at the mains supply and at the machine?
● Has the drying time or the programme been selected?
● Has the machine been switched on again after opening the door?
● Has the dryer stopped operating because the water tray is full and needs
emptying?
The dryer is noisy…
● Switch off the dryer and contact GIAS Service for advice.
The Filter Care Indicator is on…
● Does the filter need cleaning?
● Does the condenser need cleaning?
Empty Water Indicator is on…
● Does the water container need emptying?
18
Troubleshooting
40004258Eng.qxd 05/12/2005 14:56 Page 18
Should there still be a problem with your dryer
after completing all the recommended checks,
please call GIAS Service for advice. They may be
able to assist you over the telephone or arrange
for a suitable appointment for an engineer to call
under the terms of your guarantee. However, a
charge may be made if any of the following
applies to your machine:
● Is found to be in working order.
● Has not been installed in accordance with
the installation instructions.
● Has been used incorrectly.
Spares
Always use genuine spares, available direct from
GIAS Service.
GIAS Service
For service and repairs call your local GIAS
Service engineer.
The manufacturer declines all responsibility in the
event of any printing mistakes in this booklet.
The manufacturer also reserves the right to make
appropriate modifications to its products without
changing the essential characteristics.
19
Customer Service
40004258Eng.qxd 05/12/2005 14:56 Page 19
Introduktion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Leveringsoplysninger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Udpakning af produktet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Sikkerhedspåmindelser. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Anvendelse. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Vasketøjet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Miljøhensyn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
GIAS Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Elektriske krav . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Justering af fødder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Ventilation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Forberedelse af ilægning af tøj. . . . . . . . . . . . . . . . . . . . . . . . . 26
Klargøring af tøj . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Sortering af vasketøj . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Gode råd om tørring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Må ikke tørres i tørretumbler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Energibesparelse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Tørrevejledning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Knapper og indikatorer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Låge og filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Åbning af lågen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Indikator för fnugfilter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Vandbeholder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Sådan aftages beholderen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Kondensator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Sådan udtages kondensatoren . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Valg af program. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Betjening. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Annullering og genindstilling af program. . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Rengøring og løbende vedligeholdelse. . . . . . . . . . . . . . . . 35
Rengøring af tørretumbleren . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Tekniske specifikationer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Fejlfinding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Reservedele . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
GIAS Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
20
40004258DAN.qxd 05/12/2005 15:47 Page 20
Introduktion
Læs venligst denne instruktionsbog grundigt
igennem og følg anvisningerne. Denne
instruktionsbog giver dig nogle vigtige
retningslinjer angående sikker anvendelse,
installation, vedligehold samt gode råd om
hvordan, du opnår de bedste resultater med din
maskine.
Opbevar alle papirer et sikkert sted, så du har
dem når du skal bruge dem igen, eller hvis du
sælger maskinen.
Leveringsoplysninger
Kontrollér at følgende ting fulgte med maskinen:
● Instruktionsbog
● Garantibevis
● Energietiket
Tag maskinen ud af emballagen, så tæt som
muligt på der, hvor den skal stå.
1. Skær forsigtigt rundt om den underste kant
af emballagen og op langs et af hjørnerne.
2. Tag polythenbeklædningen af og løft
tørretumbleren af polystyrenfoden.
21
Kontrollér at
maskinen ikke er
beskadiget, når
du modtager
den. Hvis den er,
skal du ringe til
GIAS.
Følges
ovenstående ikke
kan maskinen
tage skade. Du
kan komme til at
betale for
reparation, hvis
der opstår
problemer med
din maskine, og
dette skyldes
misbrug.
Udpakning af produktet
Bortskaf emballagen på sikker vis.
Opbevares utilgængeligt for børn.
40004258DAN.qxd 05/12/2005 15:47 Page 21
Sikkerhedspåmindelser
Installation
● Kontroller at produktet ikke viser tegn på beskadigelse – før det tages i
brug. Er det beskadiget må det ikke bruges og GIAS Service skal
kontaktes.
● Der må ikke anvendes adaptere, flere stikdåser og/eller
forlængerledninger.
● Denne maskine må ikke installeres i et bade- eller bruserum.
● Tørretumbleren må aldrig installeres opad gardiner, og genstande skal
forhindres i at falde ned bag ved eller samles bag tørretumbleren.
Anvendelse
● ADVARSEL Misbrug af tørretumbleren kan medføre brandfare.
● Maskinen er kun til husholdningsbrug, dvs. til at tørring af tekstilvarer og
tøj i en husholdning.
● Denne maskine må kun anvendes til det tilsigtede formål som beskrevet i
denne håndbog. Husk at alle instruktioner vedr. installation og
anvendelse skal både læses og forstås før maskinen tages i brug.
● Undgå at røre ved maskinen med fugtige eller våde hænder og fødder.
● Man må ikke læne sig op af lågen, når der lægges tøj i maskinen, eller
bruge lågen til at løfte eller flytte maskinen.
● Børn må ikke lege med maskinen og dens knapper.
● ADVARSEL Produktet må ikke bruges hvis fnugfilteret sidder forkert eller
er beskadiget; fnug kan antændes.
● ADVARSEL Der hvor symbolet for varm overflade er placeret , kan
temperaturen, under tumbling, overstige 60 grader C.
● Tag stikket ud at kontakten. Tag altid stikket ud før apparatet rengøres.
● Maskinen må ikke anvendes, hvis den virker defekt.
● Bomuldsfibre og fnug må ikke ophobes på gulvet omkring maskinen.
● Tromlens inderside kan være meget varm. Lad altid tørretumbleren
fuldføre afkølingsperioden før tøjet tages ud.
Vasketøjet
● ADVARSEL Man må ikke tørretumble tørt stof behandlet med kemiske
rensevæsker.
● ADVARSEL Skumgummimateriale kan, under visse omstændigheder,
selvantænde, hvis det bliver for varmt. Skumplastic, skumgummi og
gummilignende materiale er ikke egnet til tumblertørring. Genstande
fremstillet af disse materialer MÅ IKKE anbringes i tørretumbleren.
● Kontroller altid vaskemærkerne, om tøjet tåler tørretumbling.
● Tøjet skal centrifugeres eller vrides omhyggeligt, før det lægges i
tørretumbleren. Tøj, der er drivvådt, må IKKE lægges i tørretumbleren.
22
40004258DAN.qxd 05/12/2005 15:47 Page 22
● Lightere og tændstikker må ikke efterlades i lommer, og der må ALDRIG
anvendes brandfarlige væsker i nærheden af maskinen.
● Glasfibergardiner MÅ IKKE lægges i maskinen. Der kan opstå
hudirritation, hvis andre beklædningsgenstande kontamineres med
glasfibre.
● Beklædningsgenstande behandlet med brandfarlige rensesprays eller
væsker såsom benzin, madolie eller aerosolspray MÅ IKKE lægges i
denne maskine.
Miljøhensyn
● Den anvendte emballage er miljøvenlig og genanvendelig. Bortskaf
emballagen med tanke for miljøet. Hent vejledning til bortskaffelse af
emballagen hos din lokale kommune.
● For at sikre sikker bortskaffelse af en gammel tørretumbler, skal du tage
stikket ud af væggen, skære ledningen og stik af og smide dem ud. Bræk
hængslerne af lågen eller ødelæg låsen, så det undgås at børn kommer
til at lukke sig selv inde i maskinen.
GIAS Service
● For at sikre apparatets fortsatte sikre og effektive drift anbefaler vi, at
eventuel service eller reparation kun udføres af en autoriseret GIAS
servicetekniker.
Europæisk direktiv 2002/96/EC
Denne maskine er markeret i overensstemmelse med det europæiske direktiv
2002/96/EC vedrørende elektrisk affald og elektronisk udstyr (WEEE).
Ved at sikre, at dette produkt bortskaffes korrekt, bidrager du til at forhindre
eventuelle skadelige konsekvenser for miljøet og helbredet, som ellers kan
forårsages af uhensigtsmæssig bortskaffelse af dette
produkt.
Symbolet på produktet angiver, at dette produkt ikke
må bortskaffes som husholdningsaffald. I stedet bør
det overdrages til en genbrugsstation med henblik på
genanvendelse af elektrisk og elektronisk udstyr.
Bortskaffelse bør ske i henhold til de lokale
miljømæssige regler.
Du kan få yderligere oplysninger om håndtering,
genskabelse og genanvendelse af dette produkt ved at
kontakte dit lokale rådhus, genbrugsstationen eller
den forhandler, du købte produktet af.
23
Hvis maskinen ikke kører ordentligt eller går i stykker, så
sluk for den og tag stikket ud af stikkontakten. Kontakt
GIAS Service mht. eventuel reparation.
40004258DAN.qxd 05/12/2005 15:48 Page 23
Elektriske krav
Tørretumblere kan køre på 230V, 50 Hz enfaset.
Kontrollér at strømkredsen er klassificeret til
mindst 16A.
Elektricitet kan være meget farligt.
Dette apparat skal være jordforbundet.
Stikkontakten og maskinens stik skal passe
sammen.
Der må ikke anvendes flere adaptere og/eller
forlængerledninger.
Stikket skal være tilgængeligt til afbrydelse efter,
at apparatet er blevet installeret.
Ledningerne i netledningen er farvede i
overensstemmelse med følgende koder:
Blå NUL
Brun STRØMFØRENDE
Grøn og gul JORDFORBINDELSE
Dette apparat opfylder kravene i EU direktiverne
89/336/EØF, 73/23/EØF og efterfølgende ændringer.
Justering af fødder
Når maskinen er på plads, skal fødderne justeres,
så maskinen står vandret.
Justér de fire fødder for at sikre, at maskinen står
fast og er plan.
24
Du kan komme
til at betale for
reparation, hvis
der opstår
problemer med
din maskine, der
skyldes ukorrekt
installation.
Hvis
hovedledningen
til denne maskine
er beskadiget,
skal den
udskiftes med en
særlig ledning,
som KUN fås hos
reservedels-
forhandleren.
Den skal
installeres af en
kvalificeret
person.
Installation
Du må ikke sætte stikket i og tænde
for maskinen, før installationen er
fuldført.
Af hensyn til din egen sikkerhed
skal denne tørretumbler være
installeret korrekt.
Hvis der er nogen tvivl om
installation, skal du ringe til GIAS
Service for rådgivning.
40004258DAN.qxd 05/12/2005 15:48 Page 24
Der skal være tilstrækkelig ventilation i det rum,
hvor tørretumbleren placeres, så det undgås at
gasser fra andre apparater, eller åben ild, trækkes
ind i rummet under tørretumbling.
● Udsugningsluft må ikke afledes i en
trækkanal, der er beregnet til aftræk af
røggasser fra apparater, der kører på gas
eller anden brændsel.
● Kontrollér regelmæssigt at luften, der
strømmer gennem tørretumbleren, ikke
hæmmes.
● Kontrollér fnugfiltret efter brug og rengør
det om nødvendigt.
● Indløb og udløb skal holdes fri for
tilstopninger. For at sikre tilstrækkelig
ventilation må mellemrummet mellem
maskinens bund og gulvet ikke tilstoppes.
Der skal være mindst 12 mm fri luft mellem
maskinen og ting, der kan blokere.
● Genstande skal forhindres i at falde ned og
samles mellem tørretumblerens sider og
bagside, da disse kan tilstoppe
luftindsugning og -udsugning.
● Tørretumbleren må ALDRIG installeres op
mod gardiner.
25
Ventilation
LUFTUDSUGNINGSKANALER
LUFTUDSUGNINGSKANALER I
BUNDEN
LUFTINDSUGNINGSKANALER
40004258DAN.qxd 05/12/2005 15:48 Page 25
Før tørretumbleren anvendes første gang:
● Læs venligst denne instruktionsbog
grundigt.
● Fjern alle genstande som er lagt ind i
tromlen.
● Aftør tromlens inderside og låge med en
fugtig klud for at fjerne eventuelt støv, som
har sat sig under transporten.
Klargøring af tøj
Du skal sikre, at det vasketøj, du skal til at tørre,
egner sig til tørring i en tørretumbler, som vist på
vaskemærker på hver genstand.
Kontroller at alle lukninger er lukkede, og at
lommerne er tomme. Vend vrangen ud på
genstandene. Læg tøjet løst i tromlen for at sikre,
at det ikke filtrer sig sammen.
Maksimal tørrevægt
● Bomuld, maks. 6 kg
● Syntetiske stoffer, maks. 3 kg
26
Forberedelse af ilægning
af tøj
Tromlen må ikke
overfyldes,
større, våde ting,
kan overstige
den maksimalt
tilladte vægt
(f.eks.: soveposer
og dyner).
40004258DAN.qxd 05/12/2005 15:48 Page 26
Sorter tøjet, der skal
lægges i, som følger:
● Efter vaskemærker
De findes i kraven eller på en indvendig
søm:
Egnet til tørring i tumbler.
Tørring i tumbler ved høj temperatur.
Kun tørring i tumbler ved lav
temperatur.
Må ikke tørres i tørretumbler.
Hvis der ikke findes noget vaskemærke,
må det betragtes som uegnet til
tørretumbling.
● Efter antal og tykkelse
Når det tøj, der skal lægges i, overstiger
tørretumblerens kapacitet, skal tøjet
adskilles i overensstemmelse med tykkelse
(f.eks. håndklæder fra tyndt undertøj).
● Efter stoftype
Bomuld/linned: Håndklæder, bomuldsjersey,
sengelinned og duge.
Syntetiske stof: Skjortebluser, skjorter,
overalls, osv., fremstillet af polyester eller
polyamid samt efter bomulds/syntetiske
blandinger.
● Efter tørringsniveau
Sorter tøjet i: Strygetørt, Skabstørt, osv. For
sarte genstande tryk på knappen for at
vælge lav tørretemperatur.
27
40004258DAN.qxd 05/12/2005 15:48 Page 27
Må ikke tørres i
tørretumbler:
Uld, silke, sarte stoffer, nylonstrømper, sart
broderi, stof med metaldekoration,
beklædningsgenstande med PVC eller
læderkanter, gummisko, pladskrævende
genstande, som f.eks. soveposer, osv.
Energibesparelse
Læg kun vasketøj i tørretumbleren som er blevet
grundigt vredet eller centrifugeret. Jo mere tørt
vasketøj er, jo kortere vil tørretiden være og
derved spare elektricitet.
ALTID
● Prøv altid at tørre vasketøj så meget
vasketøj som maskinen tillader, dette sparer
både tid og elektricitet.
● Det skal altid kontrolleres, at filtret er rent
før hver tørrecyklus.
ALDRIG
● Den maksimale vægt må aldrig overskrides,
dette vil spilde tid og elektricitet.
● Læg aldrig drivvåde genstande i tørretumbleren, dette kan beskadige apparatet.
Tørrevejledning
Tabellen viser omtrentlige tørretider afhængig af
stoftype og tøjets fugtighed.
28
Gode råd om tørring
VIGTIGT: Tør ikke
genstande som
er behandlet med
kemisk
rensevæske eller
gummitøj (fare
for brand eller
eksplosion).
I de sidste
15 minutter
tørres tøjet altid i
kold luft.
Stof
BOMULD
SYNTETISKE
STOFFER
AKRYL
VARME-
INDSTILLING
HØJ
LAV
LAV
INDIKATOR
LY S
SLUKKET
TÆNDT
TÆNDT
STOR
MÆNGDE
120-140 min
–
–
MEDIUM
MÆNGDE
100-120 min
50-70 min
40-50 min
LILLE
MÆNGDE
30-50 min
30-40 min
20-30 min
40004258DAN.qxd 05/12/2005 15:48 Page 28
Loading...
