Canary CFT-206X, CFT-20W-XX, CFT-2067X Product Specifications

Fast Ethernet Copper-to-Fiber
Converters

CFT-206X

Standard UTP to Multi-

mode & Single-mode

series 100BASE-TX/FX

CFT-2067X

UTP to Single-Fiber,

Bi-Directional

Single-mode

CFT-20W-XX

UTP to Single-mode

with ITU specified

CWDM wavelengths

Illustrated: Standard and Single-Fiber Fast Ethernet Media Converters

Canary’s Fast Ethernet converters connect twisted-pair and fiber optic segments to extend

Fast Ethernet links. They are ideal for connecting user desktops with low-cost work-group

switches and servers – or for switch-to-switch links. Canary’s UTP-to-Fiber converters are

used to economically distribute Fast Ethernet capacity to user desktops throughout the

network. CFT-206X converters are the first in the industry to speedup Spanning Tree link

recovery by employing Link Fault Signaling (LFS) technology while supporting Far-End

Fault-Indication and Parallel Detection capabilities. Specially modified unidirectional (one-

way fiber transmission) versions are available on special request for security applications

– contact Canary directly for more information.

Economic distribution

of Fast Ethernet

capacity to user

desktops throughout

the network

Installed success … deployed worldwide.

Product Specifications Fast Ethernet Copper-to-Fiber Converters

Power Supply:

External switching

•

100/240 VAC, 1.2/0.6 Amp

•

50/60 Hz

•

Environmental:

Operating Temp.: 0 to 49ºC

•

Storage Temp.: -10 to 66ºC

•

Relative Humidity: 5% to 95% non-

•

condensing

Mechanical:

Height: 1.00” (2.54 cm)

•

Length: 5.75” (14.61 cm)

•

Width: 2.85” (7.24 cm)

•

Ship Weight: 2.0 lb (0.9 Kg)

•

Single Unit: 0.4 lb (0.2 Kg)

•

Regulatory:

Designed in compliance with CE, UL, CSA

•

& TUV standards
IEEE 802.3u, 100BASE-TX/FX

•

Class 1 lasers conform to US 21CFR(J), EN

•

60825-1, UL 1950 and I EC-825

Warranty

Five (5) Years, parts and labor

•

The pages that follow provide ordering
information for Canary’s Fast Ethernet Copper­to-Fiber Converter products:

Standard UTP to Multi-mode &

•

Single-mode series 100BASE-TX/FX

CFT-206X, CFT-206-5M

UTP to Single-Fiber, Bi-Directional

•

Single-mode

CFT-2067X

UTP to Single-mode with ITU

•

specified CWDM wavelengths

CFT-20W-XX

All information contained within this document is subject

to change without notice at Canary Communications’

sole and absolute discretion. Customer agrees that

Canary Communications is not liable for any actual,

consequential, exemplary or other damages arising from

any use of the information contained herein.

Canary warrants the performance of its products only in

accordance with its stated Five-year or Three-year

standard warranties. Canary Communications disclaims

any and all other warranties including express, implied,

statutory; and including warranties of merchantability

or fitness for a particular purpose – except where

prohibited by law. Canary Communications does not

transfer rights to any copyrighted software code

contained within or used by Canary Products.

Canary Communications, Inc.

18655 Madrone Pkwy, #100

Morgan Hill, CA 95037

Tel: [phone]

Fax: [phone]

Web: www.canarycom.com

ISO 9001 : 2000

Canary Communications is an
ISO 9001 : 2000 registered company.

© 2004 Canary Communications. Canary is

a trademark of Canary Communications, Inc. All

trademarks and registered trademarks are the

properties of their respective companies.

Fast Ethernet Copper-to-Fiber Converters

CFT-206X – Standard multi-mode & single-mode series: 100BASE-TX to 100BASE-FX

• Switch for Hard-Setting Full-Duplex or 100BASE-TX

Autonegotiation for 100 Mbs, Full and Half-duplex operation

• Internal Auto-sensing, MDI / MDI-X crossover switch for

proper Network Interface Card or Switch connections

• Switch enabled Link Fault Signaling (LFS) – Forwards lost

link awareness to each connected host

• A full array of diagnostic LEDs

• Auto-sensing, 100 / 240 VAC Power Supply

Illustrated: Standard Fast Ethernet Copper-to-Fiber Converter

Standard CFT-206X multi-mode converters provide transmission
distances of 2000 meters over 62.5/125 µm fiber.

Standard CFT-206X-SM single-mode models provide transmission
distances ranging from 30 to 80 kilometers over 9.0 µm single­mode fiber.

• Optional: UK, Continental European power

• Unidirectional fiber transmission versions available for

sensitive security applications.

• Additional models include: Single-Fiber Bi-Directional single-

mode and versions launching ITU specified CWDM transmitter
wavelengths

Ordering Information

Fast Ethernet Media Min. Tx Max. Tx Rx Min. PWR Max.PWR Max. Input Connector Wavelengths Transmit
Model Numbers Types PWR PWR Sensitivity Budget Budget PWR Type (ηm) Distance

CFT-2061 UTP / MM -20.0 dBm -14.0 dBm -31.0 dBm 11.0 dB 17.0 dB -8.0 dBm SC 1310 ηm 2000 m

CFT-2062 UTP / MM -20.0 dBm -14.0 dBm -31.0 dBm 11.0 dB 17.0 dB -8.0 dBm ST 1310 ηm 2000 m

Specifications above in blue are for multi-mode, fiber connectors. Specifications below for single-mode, fiber connectors.

CFT-2081-SM UTP / SM -16.0 dBm -9.0 dBm -34.0 dBm 18.0 dB 25.0 dB -7.0 dBm SC 1310 ηm18 Km

CFT-2061-SM UTP / SM -15.0 dBm -8.0 dBm -34.0 dBm 19.0 dB 26.0 dB -7.0 dBm SC 1310 ηm 30 Km

CFT-2062-SM UTP / SM -15.0 dBm -8.0 dBm -34.0 dBm 19.0 dB 26.0 dB -7.0 dBm ST 1310 ηm 30 Km

CFT-2061-LSM UTP / SM -5.0 dBm 0.0 dBm -35.0 dBm 30.0 dB 35.0 dB 0.0 dBm SC 1310 ηm 50 Km

CFT-2061-XL UTP / SM -5.0 dBm 0.0 dBm -35.0 dBm 30.0 dB 35.0 dB 0.0 dBm SC 1550 ηm 80 Km

CFT-2061-E85 UTP / SM -5.0 dBm 0.0 dBm -35.0 dBm 30.0 dB 35.0 dB 0.0 dBm SC 1550 ηm 80 Km

*NOTE 1: All CFT models are available as uni-Directional (D) versions, that allow one-way traffic e.g. CFT-2061D. For special order, contact Canary for information.
* NOTE 2: Most versions of CFT-20XX standalone converters are available as card modules for Canary’s CCM-1600 and CCN-2000 / CCN-0400 Chassis models.

Please refer to the CCM-1600 and CCN-2000 / CCN-0400 Data Sheets s for more information.

More versions of the CFT-206X series may be found on the Canary web site as they become available.

Fast Ethernet Copper-to-Fiber Converters

CFT-2067A and CFT-2067B – UTP to Single-Fiber, Bi-Directional Single-Mode

Canary’s Single­Fiber Bi-Directional
Single-mode
converters deliver
long-range data
access over single­mode segments
while using a single
strand of Fiber
cable. CFT-2067A/B
converters are
designed to free-

Illustrated: Single Fiber Fast Ethernet Single-Fiber,
Bi-Directional converter.

up fiber capacity by using dual wavelengths over a single strand of
a duplex fiber pair. They are ideal for data intensive backbones in
the enterprise or across the campus where extra fiber capacity is
lacking but redundancy or additional access is needed to add
channels or alternate protocols.

CFT-2067X converters are the first in the industry to speedup
Spanning Tree link recovery by employing Link Fault Signaling (LFS)
technology while supporting Far-End Fault-Indication and Parallel
Detection capabilities.

Canary’s Single-Fiber, Bi-Directional converters are functionally
identical to standard units with the exception that units designated
with an A (CFT-2067A) transmit at 1550 ηm and receive on

• Switch for Hard-Setting Full-Duplex or 100BASE-T

Autonegotiation for 100 Mbs, Full and Half-duplex operation

• Internal Auto-sensing, MDI / MDI-X crossover switch for

proper Network Interface Card or Switch connections

• Switch enabled Link Fault Signaling (LFS) – Forwards lost

link awareness to each connected host

• Optional: UK, Continental European power

• Auto-sensing, 100 / 240 VAC Power Supply

• A full array of diagnostic LEDs

1310 ηm, while B (CFT-2067B) units transmit at 1310 ηm and receive
on 1550 ηm. Single-Fiber converters must be connected as
complementary A & B pairs. (A and B units must be ordered in
pairs because every A unit must be connected to a B unit.) Similarly,
standalone A & B units can be connected to complementary A & B
modules used in the CCN-2000/0400 or CCM-1600 Chassis
families. Canary Single-Fiber converters are available with 20
kilometer, 40 kilometer or 60 kilometer transmission ranges.

Ordering Information

Fast Ethernet Media Min. Tx Max. Tx Rx Min. PWR Max.PWR Max. Input Connector Wavelengths Transmit
Model Numbers Types PWR PWR Sensitivity Budget Budget PWR Type (ηm) Distance

CFT-2067SA UTP / SM -14.0 dBm -8.0 dBm -33.0 dBm 19.0 dB 25.0 dB -3.0 dBm SC 1550/1310 ηm 20 Km

CFT-2067SB UTP / SM -14.0 dBm -8.0 dBm -33.0 dBm 19.0 dB 25.0 dB -3.0 dBm SC 1310/1550 ηm 20 Km

CFT-2067E4A UTP / SM -8.0 dBm -3.0 dBm -33.0 dBm 25.0 dB 30.0 dB -3.0 dBm SC 1550/1310 ηm 40 Km

CFT-2067E4B UTP / SM -8.0 dBm -3.0 dBm -33.0 dBm 25.0 dB 30.0 dB -3.0 dBm SC 1310/1550 ηm 40 Km

CFT-2067E6A UTP / SM -5.0 dBm 0.0 dBm -33.0 dBm 28.0 dB 33.0 dB -3.0 dBm SC 1550/1310 ηm 60 Km

CFT-2067E6B UTP / SM -5.0 dBm 0.0 dBm -33.0 dBm 28.0 dB 33.0 dB -3.0 dBm SC 1310/1550 ηm 60 Km

* NOTE: CFT-2067SA/B and CFT-2067EXA/B standalone converters are available as card modules for Canary’s CCM-1600 and CCN-2000 / CC N-0400 Chassis models. Please refer
to the CCM-1600 and CCN-2000 / CCN-0400 Data Sheets for more information.

More versions of the CFT-2067A/B series may be found on the Canary web site as they become available.

Optical Specifications

Fast Ethernet Copper-to-Fiber Converters

CFT-20W-XX – UTP to Single-mode with ITU-specified CWDM wavelengths

Canary’s CFT-20W-XX series of Coarse Wavelength Division
Multiplexing (CWDM) converters provide an efficient way to launch
multiple Fast Ethernet channels for transport through CWDM
Multiplexers and provide access to high capacity CWDM based
networks.

Coarse Wavelength Division Multiplexing reduces network
congestion with a minimum infrastructure investment. Using discrete
wavelengths (one per channel), multiple data channels can be
transported in parallel over a single-mode fiber cable.

• Switch for Hard-Setting Full-Duplex or 100BASE-T

Autonegotiation for 100 Mbs, Full and Half-duplex operation

• Internal Auto-sensing, MDI / MDI-X crossover switch for

proper Network Interface Card or Switch connections

• Switch enabled Link Fault Signaling (LFS) – Forwards lost

link awareness to each connected host

• Optional: UK, Continental European power

CFT-20W-XX converters are the first in the industry to speedup

• Auto-sensing, 100 / 240 VAC Power Supply

Spanning Tree link recovery by employing Link Fault Signaling (LFS)
technology while supporting Far-End Fault-Indication and Parallel

• A full array of diagnostic LEDs

Detection capabilities.

Canary’s CFT-20W-XX Coarse Wavelength Division Multiplexing
converters are designed to meet industry needs for an economical
way to access CWDM point-to-point campus and metro-ring
networks. They are used with Main Distribution Frame (central
office) Multiplexers and with remote site Optical Add/Drop
Multiplexers (OADMs) to insert and/or recover optical traffic from
single-mode fiber segments. Specific models provide transmission
on one of eight λs, each an ITU specified, CWDM wavelength.

CWDM converters are functionally identical to standard units with
the exception that units at opposite ends of a fiber link must be
models with identical wavelengths in order to maintain a common
channel link e.g. if one device is operating at 1470 ηm, the second
must transmit and receive on the same CWDM wavelength.
Similarly, a standalone 1470 ηm unit can be connected to a
CCM-1600 or CCN-2000 / CCN-0400 chassis module with the
same wavelength.

Standard versions support 80 Kilometer transmission distances.

Ordering Information

Fast Ethernet Media Min. Tx Max. Tx Rx Min. PWR Max.PWR Max. Input Connector Wavelengths Transmit
Model Numbers Types PWR PWR Sensitivity Budget Budget PWR Type (ηm) Distance

CFT-20W-XXE8 UTP / SM -5.0 dBm 0.0 dBm -34.0 dBm 29.0 dB 34.0 dB -3.0 dBm SC CWDM 80 Km

CFT-20W-XXE9 UTP / SM -3.0 dBm 2.0 dBm -34.0 dBm 31.0 dB 36.0 dB -3.0 dBm SC CWDM 100 Km

* NOTE 1: W-XX designates one of eight CWDM optical transmission wavelengths (λ) e.g. CFT-20W-47=1470ηm or CFT-20W-61=1610ηm transmission.
Please refer to other CWDM (Coarse Wavelength Division Multiplexing Data Sheets for additional information.

* NOTE 2: Canary CWDM standalone converters are available as card modules for the CCM-1600 and SNMP manageable CCN-2000 / CCN-0400 Chassis models.
Please refer to the CCM-1600 and CCN-2000 / CCN-0400 Data Sheets for more information.
Please refer to the Standalone / Rackable CWDM data pages for information on Passive Optical Multiplexer / De-Multiplexers and OADMs.

There are eighteen CWDM wavelengths (λs) specified. Eight standard wavelengths plus four O-band λs are usable over most standard single-mode fiber.
Canary offers products for the standard eight wavelengths plus four O-band λs: 1470, 1490, 1510, 1530, 1550, 1570, 1590, 1610 ηm + 1290, 1310, 1330, 1350 ηm

More versions of the CFT-20W-XX series may be found on the Canary web site as they become available.

Optical Specifications
