CIRCULATION
FANS - 6
NOV/2022
FEATURES
PERFORMANCE SPECIFICATIONS
DIMENSIONS
FANBOS
• Six aluminum airfoils contoured for maximum air movement.
• DC motor for quiet performance and low operating cost.
• 5 speed forward and reverse with remote control (wall mountable).
• Control multiple fans with one remote within 50’.
• 1/4” powder-coated steel and anodized aluminum chassis resists rusting and
corrosion even in cold and damp environments.
• Standard with a 1” diameter 12” downrod mount. Optional 24” and
36” long downrods are available to purchase.
• Easy installation with standard ball hanger design.
• 48” lead wires.
• 120 volt.
• Damp rated.
• Available in grey, white and matte black finishes.
• CP96-LEDBK comes complete with light kit.
• Title-20 certified.
• 5 year warranty.
The FANBOS blankets a very large area by constantly moving air to
create an expansive comfort zone. As a
result, the big ceiling fan can create an
evaporative cooling effect of three to four degrees throughout the
facility. During the heating season, The FANBOS can destratify
uneven temperatures that can be in excess of fifteen degrees from
ceiling to floor. This results in significant energy savings since the
heating system cycles less frequently.
COMPLETE WITH
5 SPEED CONTROL
This economic, high volume low speed fan
design is ideal for circulating air in Workshop
and Warehouse Applications and can help
save energy year round.
CP120
10’ span x 8 1/4” height
(plus downrod height)
CP96
8’ span x 8 1/4” height
(plus downrod height)
CP96PG/CP120PG
CP96-LEDBK
Complete with light kit
CP96BK/CP120BK
LK-CPPG - Grey
LK-CPBK - Matte Black
LK-CPWH - White
NEW NEW
Optional 1000 Lumens Light Kits
CP96WH/CP120WH
CANARM LTD. - Corporate Office
PO Box 367 2157 Parkedale Ave.,
Brockville, ON
Canada K6V 5V6
Tel: (613) 342-5424 Fax: 1-800-263-4598
Arthur Manufacturing Facility
#7686 Concession 16, RR 4
Arthur, ON
Canada N0G 1A0
Tel: (519) 848-3910 Fax: (519) 848-3948
CP120
SPEED RPM CFM CFM/W WATTS AMPS EFFICIENCY
HIGH SPEED 69 20693 335 61.8 0.9
LOW SPEED 32 11087 1827 9.1 0.1
CP96
HIGH SPEED 105 16729 281 61.6 0.9
LOW SPEED 49 10292 1711 6.0 0.1
565 CFM/W
487 CFM/W
