Full HD Multi-Streams
Mini Dome IP Camera
User’s Manual
Ver. 1.3
1
Table of Contents
1. Overview ................................................................................................................................ 2
1.1 Features ...................................................................................................................... 2
1.2 Package Contents ....................................................................................................... 3
1.3 Dimensions .................................................................................................................. 5
1.4 Connectors (Indoor Only)............................................................................................. 6
1.5 Function Cable Definition (Outdoor Only) .................................................................... 7
2. Camera Cabling ..................................................................................................................... 8
2.1 Connect Power ............................................................................................................ 8
2.2 Connect Ethernet Cable............................................................................................... 8
2.3 Connect Alarm I/O ....................................................................................................... 9
2.4 Waterproof Cable Connector ....................................................................................... 9
3. System Requirements ........................................................................................................ 11
4. Access Camera ................................................................................................................... 12
5. Setup Video Resolution ...................................................................................................... 17
6. Configuration Files Export / Import ................................................................................... 18
Appendix A: Technical Specifications ................................................................ ...................... 19
Appendix B: Delete the Existing DC Viewer .............................................................................. 25
Appendix C: Setup Internet Security ......................................................................................... 26
2
1. Overview
The Full HD Multi-Streams Mini Dome IP Camera is an easy setup camera with
PoE supported to reduce complicate cabling. Up to 5 Megapixel Resolution is
offered for providing high definition images. Quad Streams Compression (H.264
Baseline / Main / High Profile + MJPEG) are supported for efficient bandwidth
and storage management. For dark environments, the camera has incorporated
WDR, 3DNR and Day/Night ICR technologies to capture clear images in
lowlight conditions.
1.1 Features
Progressive Scan CMOS Sensor
2M / 3M / 5M Resolution*
Dual Streaming- Full HD 1080P Real Time + D1 Real Time
Quad Streams Compression- H.264 Baseline / Main / High Profile + MJPEG
Multi-language Support
Tampering Alarm
Wide Dynamic Range
Motion Detection
Privacy Masks
Smart Picture Quality / 3D Noise Reduction
Vertical View Mode (image rotation by 90 degrees)
Smart IR Mode
Network Failure Detection
True Day/Night (ICR)
IR LED Module (working distance up to 25m)*
microSD Support
BNC Analog Output*
Weatherproof (IP66 International)*
ONVIF Support
(*) Optional
3
1.2 Package Contents
Please check the package contains the following items listed below.
Indoor Camera Package Contents
Full HD Multi-Streams
Mini Dome IP Camera
Self Tapping Screws (x3)
Plastic Screw Anchors (x3)
Quick Guide
CD
(bundled software and documentation)
4
Outdoor Camera Package Contents
Full HD Multi-Streams
Mini Dome IP Camera
Rubber Washers (x2)
Security Torx
Self Tapping Screws (x3)
Plastic Screw Anchors (x3)
Quick Guide
CD
(bundled software and documentation)
5
1.3 Dimensions
The dimensions of the IP Camera are shown below.
Indoor
Outdoor
6
1.4 Connectors (Indoor Only)
The diagram below shows the default button, microSD card slot and various
connectors of the IP Camera. Definition for each connector will be given as
follows.
No.
Connector
Pin
Definition
Remarks
1
RJ-45
-
10/100 Mbps Ethernet / PoE
2
Power
(AC 24V / DC 12V)
1
AC 24V Power-1
DC 12V Power
Power
connection
2
AC 24V GND
DC 12V Reserved
3
AC 24V Power-2
DC 12V GND
3
microSD Card Slot
-
For video recordings storage
4
Video
(BNC Connector)*
-
For analog videos output
5
Alarm & Audio I/O
1
Alarm In –
Alarm
connection
2
Alarm In +
3
Alarm Out –
4
Alarm Out +
5
Audio Out L
Line Out
6
Audio Out R
7
GND
8
Audio In
Line In
6
Default Button
-
Press the button with a proper tool for at least 20
seconds to restore the system.
(*) Optional
NOTE: Insert the microSD card into the microSD card slot before
powering on the camera. If the camera is already powered on, reboot
the camera after the microSD card is inserted.
7
1.5 Function Cables Definition (Outdoor Only)
No.
Connector
Pin
Definition
Remarks
1
RJ-45
-
10/100 Mbps Ethernet / PoE
2
Power (AC 24V / DC 12V)
1
AC 24V 1 / DC 12V –
Power
connection
2
GND
3
AC 24V 2 / DC 12V +
3
Alarm I/O
(4-Pin Terminal Block)
1
Alarm In –
Blue
2
Alarm In +
Green
3
Alarm Out –
Yellow
4
Alarm Out +
Orange
4
Audio I/O
Green
Line Out
Two-way audio
transmission
Pink
Line In
5
BNC
-
For analog videos output
-
Default Button
-
For the position of the default button,
please refer to the diagram shown in
section Connectors (Indoor Only).
8
2. Camera Cabling
Before users connect cables, make sure that all cables and the power adaptor
are placed in dry and well-waterproofed environments, e.g. waterproof boxes.
The purpose is to prevent moisture accumulation inside the camera and
moisture penetration into cables, which might lead to camera breakdown.
Please follow the instructions below to complete IP Camera connection.
2.1 Connect Power
For power connection, please refer to section Connectors (Indoor Only) for the
Indoor models, and see section Function Cables Definition (Outdoor Only) for
the Outdoor models. Alternatively, users can power the camera by PoE if a PSE
switch is available. Please refer to the section below for Ethernet cable
connection.
NOTE: If PoE is used, make sure Power Sourcing Equipment (PSE) is
in used in the network.
2.2 Connect Ethernet Cable
For best transmission quality, cable length shall not exceed 100 meters.
Connect one end of the Ethernet cable to the RJ-45 connector of the camera,
and plug the other end of the Ethernet cable to the network switch or PC.
NOTE: In some cases, Ethernet Crossover cable might be needed when
connecting the IP Camera directly to the PC.
Check the status of the link indicator and activity indicator LEDs. If the LEDs are
unlit, please check the LAN connection.
Green Link Light indicates good network connection.
Orange Activity Light flashes for network activity indication.
