Campomatic KOR65S User Manual

Before operating this oven, please read these instructions completely.

OWNER'S
MANUAL

MICROWAVE OVEN

KOR65S

1

PRECAUTIONS TO AVOID POSSIBLE

EXPOSURE TO EXCESSIVE

MICROWAVE ENERGY

(a) Do not attempt to operate this oven with the door

open since open-door operation can result in harmful
exposure to microwave energy. It is important not to defeat
or tamper with the safety interlocks.

(b) Do not place any object between the oven front face and

the door or allow soil or cleaner residue to accumulate on
sealing surfaces.

(c) WARNING : If the door or door seals are damaged, the

oven must not be operated until it has been repaired by a
competent person : (1) door (bent), (2) hinges and
latches(broken or loosened), (3) door seals and sealing
surfaces.

(d) WARNING : It is hazardous for anyone other than a

competent person to carry out any service or repair
operation that involves the removal of a cover which gives
protection against exposure to microwave energy.

(e) WARNING : Liquids and other foods must not be heated

in sealed containers since they are liable to explode.

(f) WARNING : This appliance can be used by children aged

from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children unless
they are aged from 8 years and above and supervised.

2

• PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE

ENERGY .....................................................................................................................1

• IMPORTANT SAFETY INSTRUCTIONS ....................................................................3

• EARTHING INSTRUCTIONS .....................................................................................5

• INSTALLATION ...........................................................................................................5

• FEATURES DIAGRAM ...............................................................................................6

• OPERATION PROCEDURE .......................................................................................8

• CONTROLS .................................................................................................................9

SETTING THE CLOCK ...............................................................................................9

KITCHEN TIMER MODE .............................................................................................9

WEIGHT DEFROSTING ............................................................................................11

TIME DEFROSTING .................................................................................................12

COOKING IN ONE STAGE .......................................................................................13

COOKING IN TWO STAGES ....................................................................................13

+30 SEC ....................................................................................................................14

ONE TOUCH COOKING ...........................................................................................14

SENSOR OPERATIONS ...........................................................................................15

SENSOR REHEAT ....................................................................................................15

SENSOR COOK ........................................................................................................16

CHILD SAFETY LOCK ..............................................................................................17

TO STOP THE OVEN WHILE THE OVEN IS OPERATING .....................................17

• CARE OF YOUR MICROWAVE OVEN ....................................................................18

• QUESTIONS AND ANSWERS .................................................................................19

• BEFORE YOU CALL FOR SERVICE .......................................................................20

• CARE AND CLEANING ............................................................................................20

• DISPOSAL OF USED ELECTRICAL & ELECTRONIC EQUIPMENT ......................20

• SPECIFICATIONS ....................................................................................................21

• COOKING INSTRUCTIONS .....................................................................................22

• USE YOUR MICROWAVE OVEN SAFELY ..............................................................23

• ARCING ....................................................................................................................23

• MICROWAVING PRINCIPLES .................................................................................24

• HOW MICROWAVES COOK FOOD .........................................................................24

• CONVERSION CHARTS ..........................................................................................24

• COOKING TECHNIQUES ........................................................................................25

• DEFROSTING GUIDE ..............................................................................................26

• COOKING & REHEATING CHART ...........................................................................27

• VEGETABLE CHART ................................................................................................29

• RECIPES ..................................................................................................................30

TABLE OF CONTENTS

3

IMPORTANT SAFETY INSTRUCTIONS

READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

WARNING : To prevent fire, burns, electric shock and other
warnings:

Listed below are, as with all appliances, certain rules to follow
and safeguards to assure high performance from this oven:

1. Do not use the oven for any reason
other than food preparation, such as
for drying clothes, paper, or any other
nonfood items or for sterilizing
purposes.

2. Do not use the oven when empty, this
could damage the oven.

3. Do not use the oven cavity for any type
of storage, such as papers, cookbook,
cookware, etc.

4. Do not operate the oven without the
glass tray in place. Be sure it is
properly sitting on the rotating base.

5. Make sure you remove caps or lids
prior to cooking when you cook food
sealed in bottles.

6. Do not put foreign material between
the oven surface and door. It could
result in excessive leakage of
microwave energy.

7. Do not use recycled paper products for
cooking. They may contain impurities
which could cause sparks and/or fires
when used during cooking.

8. Do not pop popcorn unless popped in
a microwave approved popcorn
popper or unless it's commercially

packaged and recommended
especially for microwave ovens.
Microwave popped corn produces a
lower yield than conventional popping;
there will be a number of unpopped
kernels. Do not use oil unless specified
by the manufacturer.

9. Do not cook any food surrounded by a
membrane, such as egg yolks,
potatoes, chicken livers, etc., without
first piercing them several times with a
fork.

10. Do not pop popcorn longer than the
manufacturer's directions. (popping
time is generally below 3 minutes).
Longer cooking does not yield more
popped corn, it can cause scorchings
and fire.

Also, the cooking tray can become too
hot to handle or may break.

11. If smoke is emitted, switch off or unplug
the appliance and keep the door
closed in order to stifle any flames.

12. When heating food in plastic or paper
containers, keep an eye on the oven
due to the possibility of ignition.

4

SAVE THESE INSTRUCTIONS

13. The contents of feeding bottles and
baby food jars shall be stirred or
shaken and the temperature
checked before consumption, in
order to avoid burns.

14. Always test the temperature of food
or drink which has been heated in a
microwave oven before you give it to
somebody, especially to children or
elderly people. This is important
because things which have been
heated in a microwave oven carry on
getting hotter even though the
microwave oven cooking has
stopped.

15. Eggs in their shell and whole hard­boiled eggs should not be heated in
microwave ovens since they may
explode, even after microwave
heating has ended;

16. Keep the waveguide cover clean at
all times. Wipe the oven interior with
a soft damp cloth after each use. If
you leave grease or fat anywhere in
the cavity it may overheat, smoke or
even catch fire when next using the
oven.

17. Never heat oil or fat for deep frying
as you cannot control the
temperature and doing so may lead
to overheating and fire.

18. Liquids, such as water, coffee, or tea
are able to be overheated beyond
the boiling point without appearing to

be boiling due to surface tension of
the liquid. Visible bubbling or boiling
when the container is removed from
the microwave oven is not always
present. THIS COULD RESULT IN
VERY HOT LIQUIDS SUDDENLY
BOILING OVER WHEN A SPOON
OR OTHER UTENSIL IS
INSERTED INTO THE LIQUID.
To reduce the risk of injury to
persons:
a) Do not overheat the liquid.
b) Stir the liquid both before and

halfway through heating it

c) Do not use straight-sided

containers with narrow necks.

d) After heating, allow the container

to stand in the microwave oven for
a short time before removing the
container.

e) Use extreme care when inserting

a spoon or other utensil into the
container.

19. Children should be supervised to
ensure that they do not play with the
appliance.

20. Only use utensils that are suitable for
use in microwave ovens.

21. Microwave heating of beverages can
result in delayed eruptive boiling,
therefore care must be taken when
handling the container.

5

EARTHING INSTRUCTIONS

This appliance must be earthed. In the event of an
electrical short circuit, earthing reduces the risk of
electric shock by providing an escape wire for the
electric current. This appliance is equipped with a
cord having a earthing wire with a earthing plug.
The plug must be plugged into an outlet that is
properly installed and earthed.

WARNING : Improper use of the earthing plug can
result in a risk of electric shock. Consult a qualified
electrician or serviceman if the earthing instructions
are not completely understood, or if doubt exists as
to whether the appliance is properly earthed.
If it is necessary to use an extension cord, use only a
3-wire extension cord that has a 3-blade earthing
plug, and a 3-slot receptacle that will accept the plug
on the appliance. The marked rating of the extension
cord should be equal to or greater than the electrical
rating of the appliance.

IMPORTANT

The wires in this mains lead fitted to this appliance
are colored in accordance with the following code.
Green-and-yellow : Earth
Blue : Neutral
Brown : Live
As the colors of the wires in the mains lead of this
appliance may not correspond with the colored
markings identifying the terminals in your plug,
proceed as follows : the wire which is colored green­and-yellow must be connected to the terminal in the
plug which is marked with the letter ‘E’ or by the
earth symbol or green-and-yellow. The wire which is
colored blue must be connected to the terminal
which is marked with the letter ‘N’ or colored black.
The wire which is colored brown must be connected
to the terminal which is marked with the letter ‘L’ or
colored red.

WARNING : The appliance must be earthed.

INSTALLATION

1. Ventilation

Do not block air vents. If they are blocked during
operation, the oven may overheat and eventually
cause a failure. For proper ventilation, allow above
76mm of space between oven sides, rear and the
minimum height of free space necessary above
the top surface of the oven is 100mm.

2. Steady, flat location

This oven should be set on a steady, flat surface.
This oven is designed for counter top use only.
The microwave oven shall not be placed in a
cabinet unless it has been tested in a cabinet.

3. Leave space behind and side

All air vents should be kept a clearance.
If all vents are covered during operation, the oven
may overheat and, eventually, oven failure.

4. Away from radio and TV sets

Poor television reception and radio interference
may result if the oven is located close to a TV,
Radio antenna, feeder and so on. Position the
oven as far from them as possible.

5. Away from heating appliance and water taps

Keep the oven away from hot air, steam or Splash
when choosing a place to position it, or the
insulation might be adversely affected and
breakdowns occur.

6. Power supply

• Check your local power source. This oven
requires a current of approximately 6.5 amperes,
220~240V 50Hz.

• Power supply cord is about 0.8 meters long.

• The voltage used must be the same as specified
on this oven. Using a higher voltage may result in
a fire or other accident causing oven damage.
Using low voltage will cause slow cooking. We
are not responsible for damage resulting from
use of this oven with a voltage of ampere fuse
other than those specified.

• If the supply cord is damaged, it must be
replaced by the manufacturer or its service agent
or a similarly qualified person in order to avoid a
hazard.

7. Examine the oven after unpacking for any
damage such as:

A misaligned door, Broken door, A dent in cavity.
If any of the above are visible, DO NOT INSTALL,
and notify dealer immediately.

8. Do not operate the oven if it is colder than
room temperature.

(This may occur during delivery in cold weather.)
Allow the oven to become room temperature
before operating.

6

11

DOOR SEAL

Door seal maintains the microwave within the
oven cavity and prevents microwave leakage.

22

DOOR HOOK

When the door is closed, it will automatically
lock shut. If door is opened while oven is
operating, magnetron tube will immediately
stop operating.

33

DOOR SCREEN

Allows viewing of food. Microwave cannot
pass through perforations in screen.

44

SPATTER SHIELD

Protects the microwave outlet from splashes
of cooking foods.

55

OVEN LAMP

Automatically turns on during oven operating.

66

SAFETY INTERLOCK SYSTEM

77

CONTROL PANEL

88

GLASS COOKING TRAY

Made of special heat resistant glass. The tray
must always be in proper position before
operating. Do not cook food directly on the
tray.

99

OVEN FRONT PLATE

00

DOOR OPENING BUTTON

To open the door push the door opening
button. When door is closed, it will
automatically lock shut. If door is opened
while oven is operating, magnetron tube will
immediately stop operating.

qq

ROLLER GUIDE

Supports the glass cooking tray.

FEATURES DIAGRAM

156

2

7

0

93

4

8

q

7

FEATURES DIAGRAM (continued)

1 DISPLAY - Cooking time, power level,

indicators and current time are displayed.

22

SENSOR COOK - Used to cook many of
favorite food.

33

SENSOR REHEAT - Used to reheat food.

44

ONE TOUCH COOK - Used to cook or reheat
specific quantites of food.

55

POWER - Used to set power level.

66

TIME DEFROST - Used to defrost foods for
time.

77

KEEP WARM - Used to keep the food warm.

88

WEIGHT DEFROST PAD - Press to select
DEFROST feature by weight.

99

SOFTEN - Used to soften food.

00

TIME SET PAD - Used to set the cooking time
and the current time.

qq

KITCHEN TIMER - Used as a minute timer,
delay cooking, hold setting after cooking.

ww

CLOCK - Used to set clock.

ee

STOP / CLEAR - Used to stop the oven
operation or to delete the cooking data.

rr

START / +30 SEC - Used to start the oven
and also used to set a reheat time.

3

1

2
4

5
6

8
9

0

e

7

q

w

r

8

Plug power supply cord into 220~240V AC
50Hz power outlet.

After placing the food in a suitable container,
open the oven door and put it on the glass
tray. The glass tray and roller guide must
always be in place during cooking.

Close the door. Make sure that it is firmly
closed. When the oven door is closed, the
light turns off.

The oven door can be opened at any time
during operation by pulling the door handle.
The oven will automatically shut off. To restart
the oven, close the door and then touch the
START pad.

The oven automatically cooks on full power
unless set to a lower power level.

The display will show “ : 0” when the oven is
plugged in.

Time clock returns to the present time when
the cooking time ends.

When the START/PAUSE pad is touched
during the oven operation, the oven stops
cooking and all information retained. To erase
all information(except the present time), touch
the CLEAR/OFF pad once more.
If the oven door is opened during the oven
operation, all information is retained.

If the START pad is touched and the oven
does not operate, check the area between the
door and door seal for obstructions and make
sure the door is closed securely. The oven will
not start cooking until the door is completely
closed or the program has been reset.

OPERATION PROCEDURE

This section includes useful information about oven operation.

1

2

3

4

5

6

7

8

9

WATTAGE OUTPUT CHART

•

The power-level is set by touch the POWERLEVEL pad. The chart shows the display, the power level
and the percentage of power.

Make sure the oven is properly installed
and plugged into the electrical outlet.

once P-HI 100%

twice P-90 90%

3 times P-80 80%

4 times P-70 70%

5 times P-60 60%

6 times P-50 50%

7 times P-40 40%

8 times P-30 30%

9 times P-20 20%

10 times P-10 10%

11 times P-00 0%

TOUCH THE POWER PAD POWER LEVEL (DISPLAY)

APPROXIMATE PERCENTAGE

OF POWER

9

The display stops blinking, and the colon start
blinking. If you selected 12 hour clock
system, this digital clock allows you to set
from 1:00 to 12:59. If you selected 24 hour
clock system, this digital clock allows you to
set from 0:00 to 23:59.

NOTE: If you attempt to enter an incorrect time, the time will not be set and a error signal tone will

sound. Touch the CLOCK pad and re-enter the time.

CONTROLS

NOTE: This oven has multiple clock

system. If you want 12 hour clock
system, omit this step.

1. Touch CLOCK pad.
This is a 12 hour clock system.

2. Touch CLOCK pad once more.
This is a 24 hour clock system.

3. Enter the correct time of day by
touching the numbers in
sequence.

4. Touch CLOCK pad.

SETTING THE CLOCK

When the oven is first plugged in, the display will flash “ :0” and a tone will sound. If the AC power
ever turns off, the display shows “ :0” when the power comes back on.

The TIMER indicator lights and “ : 0” is
displayed.

The display will show what you touched.

1. Touch KITCHEN TIMER pad.

2. Press the amount of time you

want to count down.

3. Touch START pad.

HOW TO USE AS A MINUTE TIMER

KITCHEN TIMER MODE

Timer operates as a minute timer, can be set to delay cooking and used to set a holding time after
cooking. However delay cooking can not be programmed for defrost. Timer operates without
microwave energy.

The TIMER indicator starts blinking and the display counts down the time remaining in KITCHEN TIMER
mode. When KITCHEN TIMER mode ends, you will hear 3 beeps.

10

NOTE : Your oven can be programmed for 59 minutes 99 seconds. (59:99)

The TIMER indicator lights and “ : 0” is
displayed.

The display will show what you touched.

The M/W indicator lights and the selected
power level & cooking time are displayed.

1. Touch KITCHEN TIMER pad.

2. Press the amount of time you
want to delay.

3. Program the desired power
level and cooking time for food
to be cooked.

4. Touch START pad.

HOW TO USE TO DELAY THE START OF COOKING

KITCHEN TIMER MODE (CONTINUED)

When you touch START pad, the TIMER indicator starts blinking and the display counts down the time
remaining in KITCHEN TIMER mode. When KITCHEN TIMER mode ends, the oven will beep. The TIMER
indicator goes off and M/W indicator starts blinking. The display counts down the time remaining in M/W
mode. When M/W cook ends, you will hear 3 beeps.

The M/W indicator lights and the selected
time is displayed.

The TIMER indicator lights and “ : 0” is
displayed.

The display will show what you touched.

1. Program the desired cooking
time.

2. Touch KITCHEN TIMER pad.

3. Press the amount of time you
want the oven to hold.

4. Touch START pad.

HOW TO USE TO SET A HOLDING TIME

The M/W indicator starts blinking and the display counts down the time remaining in M/W mode. When the
M/W cook ends, the oven will beep. The M/W indicator goes off and TIMER indicator starts blinking. The
display counts down the time remaining in KITCHEN TIMER mode. When the KITCHEN TIMER mode
ends, you will hear 3 beeps.

11

once 500 g 800 g 300 g

twice 800 g 1000 g 500 g

3 times 1000 g 1200 g 800 g

4 times 1200 g 1500 g 1000 g

* WEIGHT DEFROST CHART

WEIGHT DEFROSTING

WEIGHT DEFROSTING lets you easily defrost food by eliminating guesswork in determining
defrosting time. Follow the steps below for easy defrosting.

The DEFROST & g indicator light and "500"
is displayed.

The display will show what you touched.

MEAT DEFROSTING begins.

1. Touch MEAT pad.

2. Select desired defrosting
weight.

3. Touch START pad.

The DEFROST & g indicator light and "800"
is displayed.

The display will show what you touched.

POULTRY DEFROSTING begins.

1. Touch POULTRY pad.

2. Select desired defrosting
weight.

3. Touch START pad.

The DEFROST & g indicator light and "300"
is displayed.

The display will show what you touched.

FISH DEFROSTING begins.

1. Touch FISH pad.

2. Select desired defrosting
weight.

3. Touch START pad.

The defrosting time is automatically determined by the weight selected.
The g indicator goes off and the DEFROST indicator blinks and the defrosting time counts down in the
display window. The oven beeps during the defrosting cycle to signal that the food needs to be turned or
rearranged. When the defrosting time ends, you will hear 3 beeps.

Touch pad MEAT POULTRY FISH

12

NOTE:

Your oven can be programmed for

59 minutes 99 seconds.(59:99)

The DEFROST indicator lights and " : 0" is
displayed.

The display will show the numbers you
pressed in the order you touched.

1. Touch DEFROST pad.

2. Touch number pads for the
desired defrosting time.

3. Touch START pad.

TIME DEFROSTING

When TIME DEFROST is selected, the automatic cycle divides the defrosting time into periods of
alternating defrost and stand times by cycling on and off.

When you touch START pad, the DEFROST indicator starts blinking to show the oven is in the DEFROST
mode. The display counts down the time to show you how much defrosting time is left in the DEFROST
mode. The oven beeps during the defrosting cycle to signal that the food needs to be turned or rearranged.
When the defrosting time ends, you will hear 3 beeps.

When pressing KEEP WARM pad, the
display shows 30:00 and the oven starts
automatically.

1. Press KEEP WARM pad.

KEEP WARM

KEEP WARM feature maintains food at a warm temperature for 30 minutes.

When finished, you will hear a series of beeps.

The display will show what you touched.1. Touch SOFTEN pad once for
butter, twice for chocolate, three
times for ice cream, four times
for cream cheese.

2. Touch START pad.

SOFTEN

The soften feature can be used to soften butter, chocolate, ice cream and cream cheese.
See the chart for specific settings to use.

once S--1 Butter 1/2 cup

twice S--2 Chocolate 8 oz.

Three Times S--3 Ice Cream 1/2 gallon

Four Times S--4 Cream Cheese 8 oz.

SOFTEN ITEM CHART

TOUCH PAD DISPLAY SOFTEN ITEM 3WEIGHT

13

COOKING IN TWO STAGES

All recipes require frozen foods to be defrosted fully before cooking.
This oven can be programmed to automatically defrost foods before cooking.

The DEFROST indicator lights and “ : 0” is
displayed and the lb indicator starts blinking.

The display will show the numbers you
pressed in the order you touched.

The M/W indicator lights and “ P-HI” is The
display will show what you touched.
This example shows power level 5.

The display will show the number you
pressed in the order you touched.

1. Touch DEFROST pad.

2. Touch number pads for the
defrosting time you want.

3.Touch POWER pad.

(Select desired power level.)

4. Touch number pads for desired
cooking time.

5. Touch START pad.

COOKING IN ONE STAGE

The M/W indicator lights.
The display will show what you touched.

This example shows power level 5.
The display will show the numbers you
pressed in the order you touched.

1. Touch POWER pad.

(Select desired power level.)

2. Touch the number pads for the

cooking time.

3. Touch START pad.

When you touch START pad, the DEFROST and M/W indicators come on to confirm the power levels
selected. The DEFROST indicator starts blinking to show you that the oven is in DEFROST mode.
The display counts down the time remaining in DEFROST mode.
When the oven beeps, turn over, break apart and/or redistribute the food. At the end of DEFROST mode, the
oven will beep and start M/W cook. The DEFROST indicator goes off and the M/W indicator starts blinking.
The display counts down the time remaining in M/W cook. When M/W cook ends, you will hear 3 beeps.

When you touch START pad, the M/W indicator starts blinking to show the oven is cooking.
The display counts down the time to show how much cooking time is left. When the cooking time ends, you
will hear 3 beeps.

NOTE: If steps 1nd 2 are omitted, the

oven will cook at full power.

NOTE: Your oven can be programmed

for 59 minutes 99 seconds.
(59:99)

NOTE: Using lower power levels increases the cooking time which is recommended for foods such as

cheese, milk and slow cooking of meats.

x6

x6

14

NOTE : 1. Use prepackaged room-temperature microwave popcorn.

2. Place bag in oven according to manufacturer’s directions.

3. Pop only one bag at a time.

4. After popping, open bag carefully: popcorn and steam are extremely hot.

5. Do not reheat unpopped kernels or reuse bag.

6. Do not leave oven unattended while popping popcorn.

CAUTION : If prepackaged popcorn is of a different weight than the recommended weight, do not use

the popcorn pad. Follow the manufacturer instruction.

* BEVERAGE * (200 ml/cup)

• 1 cup (mug) : Touch BEVERAGE once.

• 2 cups (mugs) : Touch BEVERAGE twice within 1.5 seconds.

• 3 cups (mugs) : Touch BEVERAGE three times within 1.5 seconds.

+30 SEC

+30 sec allows you to reheat for 30 seconds at 100% (full power) by simply touching the +30 sec
pad.
By repeatedly touching the +30 sec pad, you can also extend reheating time to 5 minutes by 30
second increments.

When you touch the +30 sec pad, “ :30” is
displayed, and the oven starts reheating

1. Touch the +30 sec pad.

When you touch BEVERAGE pad once, “ 1 “
is displayed.
After 1.5 seconds, the display is changed into
cooking time and the oven starts cooking.

1. Touch BEVERAGE pad once
for 1 cup, twice for 2 cups or
three times for 3 cups.

ONE TOUCH COOKING

One touch cooking allows you to cook or reheat many of your favorite foods by touching just one
pad. To increase quantity, touch the chosen pad until the number in the display is same as desired
quantity to cook. (except for POPCORN)

When you touch POPCORN pad once, “3.5”
is displayed.
After 1.5 seconds, the display is changed into
cooking time and the oven starts cooking.

1. Touch POPCORN pad once
for 1.75 oz bag, twice for 3.0 oz
bag or three times for 3.5 oz
bag.

15

SENSOR OPERATIONS

The Sensor Cook categories are designed to detect the increasing humidity released by the food during the
cooking process. The microwave oven sensor will automatically adjust the cooking time to the type and amount of
food.

using sensor settings

1. After the oven is plugged in, wait 2 minutes before
using Sensor Cook.

2. Be sure the exterior of the cooking container and the
interior of the oven are dry. Wipe off any moisture with
a dry cloth or paper towel.

3. The oven works with foods at normal storage
temperature.

4. More or less food than the quantity listed in the chart
should be cooked following the guidelines in any
microwave cookbook.

5. Do not open the oven door or touch STOP/CLEAR
pad until cooking time appears on the display window.
The measurement of vapor will be interrupted. If this
occurs, an error message will appear. To continue
cooking, touch the STOP/CLEAR pad and cook
manually.

When the sensor detects the vapor emitted from the
food, the remainder of cooking time will appear.

The door may be opened when remaining cooking
time appears on the display. At this time, you may stir
or season food, as desired.

6. Always use microwave-safe containers and cover
them with loose fitting lids or vented plastic wrap.

Never use tight sealing plastic containers. They will
prevent steam from escaping and this will mislead the
sensor, usually causing the food to overcook.

7. Check food for temperature or doneness after
cooking. If food is not completely cooked, enter
additional cooking time manually. Do not use one of
the Sensor Cook categories twice in succession on
the same food portion. This may result in severely
overcooked or burnt food.

covering foods

Some foods work best when covered. Use the cover
recommended in the Sensor Cook Chart for these foods.

1. Casserole lid.

2. Plastic wrap : Use plastic wrap recommended for
microwave cooking. Cover dish loosely; allow
approximately 1/2 inch to remain uncovered to allow
steam to escape. Plastic wrap should not touch food.

3. Wax paper : Cover dish completely; fold excess wrap
under dish to secure. If dish is wider than paper,
overlap two pieces at least one inch to cover.

Be careful when removing any covering to allow
steam to escape away from you.

SENSOR REHEAT

Sensor is semi-conductor device that detects the vapor emitted from the food as it heats. The sensor
adjusts the cooking time and power level for various food and quantities and you don't need to enter
the weight or quantity of the food.

When the sensor detects the vapor emitted
from the food, the remainder of cooking time
will appear.

1. Touch SENSOR REHEAT
pad.

16

SENSOR COOK CHART

Place in dish or casserole slightly larger than amount to be
reheated. Flatten, if possible. Cover with lid, plastic wrap or wax
paper. Use covers such as plastic wrap or lids with larger quantities
of more dense foods such as stews. After reheating, stir well, if
possible. Re-cover and allow to stand 2 to 3 minutes. Foods
should be very hot. if not, continue to heat with variable power and
time.

Use this pad for frozen, convenience foods. It will give satisfactory
results for most brands. You may wish to try several and choose
your favorite. Remove package from outer wrapping and follow
package directions for covering. After cooking, let stand, covered
for 1 to 3 minutes.

Pierce. Place on paper-towel-lined turntable. After cooking, remove
from oven, wrap in aluminum foil and let stand 5 to 10 minutes.

Arrange in ring around shallow glass dish (roll fillet with edges
underneath). Cover with plastic wrap. After cooking, let stand,
covered, 3 minutes.

Wash and place in casserole. Add no water if vegetables have just
been washed. Cover with lid for tender vegetables. Use plastic
wrap for tender-crisp vegetables. After cooking, stir, if possible. Let
stand, covered, for 2 to 5 minutes.

Do not add water. Cover with lid or plastic wrap. After cooking, stir
and let stand, covered, for 3 minutes.

FOOD AMOUNT PROCEDURE

4 ~ 36 oz.

8 ~ 32 oz.

8 ~ 32 oz.
(1 ~ 4 ea)

0.4 ~ 1.0 lbs.

4 ~ 16 oz.

6 ~16 oz.

SENSOR
REHEAT

FROZEN
ENTREE

BAKED
POTATO

FISH/SEAFOOD
FRESH

VEGETABLES
FROZEN

VEGETABLES

SENSOR COOK

SENSOR COOK allows you to cook or reheat many of your favorite foods by repeatedly touching
the SENSOR COOK pad. When you touch the SENSOR COOK pad once, “SC-1” will be displayed.
By repeatedly touching this pad, you can select other food category as shown in below.

"SC-1" will be displayed.

"SC-2" will be displayed.

"SC-3" will be displayed.

"SC-4" will be displayed.

"SC-5" will be displayed.

When the sensor detects the vapor emitted
from the food, the remainder of cooking time
will appear.

1. Touch SENSOR COOK pad
once for FROZEN ENTREE.
Touch SENSOR COOK pad
twice for BAKED POTATO.
Touch SENSOR COOK pad
three times for
FISH/SEAFOOD.
Touch SENSOR COOK pad
four times for FRESH
VEGETABLES.
Touch SENSOR COOK pad
five times for FROZEN
VEGETABLES.

2. Touch START pad.

17

TO STOP THE OVEN WHILE THE OVEN IS OPERATING

1. Press CLEAR/OFF pad.

• You can restart the oven by touching START pad.

• Touch CLEAR/OFF once more to erase all instructions.

• You must enter in new instructions.

2. Open the door.

• You can restart the oven by closing the door and touching START pad.

NOTE: Oven stops operating when door is opened.

CHILD SAFETY LOCK

Child safety lock feature may lock the control panel to prevent the oven from being accidentally
started or used by children. To lock, press and hold STOP/CLEAR pad for 3 seconds. Lock indicator
will be displayed.
To unlock, press and hold STOP/CLEAR pad for 3 seconds. Lock indicator will be turned off.

18

CARE OF YOUR MICROWAVE OVEN

Turn the oven off before cleaning.

Keep the inside of the oven clean. When food
spatters or spilled liquids adhere to oven walls,
wipe with a damp cloth. Mild detergent may be
used if the oven gets very dirty.
The use of harsh detergent or abrasives is not
recommended.

The outside oven surface should be cleaned
with soap and water, rinsed and dried with a
soft cloth. To prevent damage to the operating
parts inside the oven, water should not be
allowed to seep into the ventilation openings.

If the Control Panel becomes wet, clean with a
soft, dry cloth. Do not use harsh detergents or
abrasives on Control Panel.

If steam accumulates inside or around the
outside of the oven door, wipe with a soft cloth.
This may occur when the microwave oven is
operated under high humidity conditions and in
no way indicates malfunction of the unit.

It is occasionally necessary to remove the glass
tray for cleaning. Wash the tray in warm sudsy
water or in a dishwasher.

The roller guide and oven cavity floor should be
cleaned regularly to avoid excessive noise.
Simply wipe the bottom surface of the oven with
mild detergent water or window cleaner and dry.
The roller guide may be washed in mild sudsy
water.

1
2

3

4

5

6

7

The oven should be cleaned regularly and any food deposits removed.
Failure to maintain the oven in a clean condition could lead to
deterioration of the surface that could adversely affect the life of the
appliance and possibly result in a hazardous situation.

ROLLER GUIDE

Glass Tray Roller Guide

The ROLLER GUIDE and oven floor should be
cleaned frequently to prevent excessive noise.

The ROLLER GUIDE MUST ALWAYS be used
for cooking together with the Glass Tray.

1

2

GLASS TRAY

DO NOT operate the oven without the Glass Tray
in place.

DO NOT use any other Glass Tray with this oven.

If Glass Tray is hot, ALLOW TO COOL before
cleaning or placing it in water.

DO NOT cook directly on the Glass Tray.
(Except for popcorn)

1

2
3

4

19

QUESTIONS AND ANSWERS

* Q : I accidentally ran my microwave oven

without any food in it. Is it damaged?

* A : Running the oven empty for a short time will

not damage the oven. However, it is not
recommended.

* Q : Can the oven be used with the glass tray

or roller guide removed?

* A : No. Both the glass tray and roller guide must

always be used in the oven before cooking.

* Q : Can I open the door when the oven is

operating?

* A : The door can be opened anytime during the

cooking operation. Then microwave energy
will be instantly switched off and the time
setting will maintain until the door is closed.

* Q : Why do I have moisture in my microwave

oven after cooking?

* A : The moisture on the side of your microwave

oven is normal. It is caused by steam from
cooking food hitting the cool oven surface.

* Q : Does microwave energy pass through the

viewing screen in the door?

* A : No. The metal screen bounces back the

energy to the oven cavity. The holes are
made to allow light to pass through. They do
not let microwave energy pass through.

* Q : Why do eggs sometimes pop?

* A : When baking or poaching eggs, the yolk may

pop due to steam build-up inside the yolk
membrane. To prevent this, simply pierce the
yolk with a toothpick before cooking. Never
cook eggs without piercing their shells.

* Q : Why is standing time recommended after

the cooking operation has been
completed?

* A : Standing time is very important.

With microwave cooking, the heat is in the
food, not in the oven. Many foods build up
enough internal heat to allow the cooking
process to continue, even after the food is
removed from the oven. Standing time for
joints of meat, large vegetables and cakes is
to allow the inside to cook completely,
without overcooking the outside.

* Q : What does “standing time” mean?

* A : “Standing time” means that food should be

removed from the oven and covered for
additional time to allow it to finish cooking.
This frees the oven for other cooking.

* Q : Why does my oven not always cook as

fast as the microwave cooking guide
says?

* A : Check your cooking guide again, to make

sure you’ve followed directions exactly ; and
to see what might cause variations in cooking
time. Cooking guide times and heat settings
are suggestions, to help prevent over­cooking... the most common problem in
getting used to a microwave oven.
Variations in the size, shape and weights and
dimensions could require longer cooking
time. Use your own judgement along with the
cooking guide suggestions to check whether
the food has been properly cooked just as
you would do with a conventional cooker.

* Q : Will the microwave oven be damaged if it

operates while empty?

* A : Yes. Never run it empty.

* Q : Can I operate my microwave oven

without the turntable or turn the turntable
over to hold a large dish?

* A : No. If you remove or turn over the turntable,

you will get poor cooking results. Dishes
used in your oven must fit on the turntable.

* Q : Is it normal for the turntable to turn in

either direction?

* A : Yes. The turntable rotates clockwise or

counterclockwise, depending on the rotation
of the motor when the cooking cycle begins.

* Q : Can I pop popcorn in my microwave

oven? How do I get the best results?

* A : Yes. Pop packaged microwave popcorn

following manufacture’s guidelines. Do not
use regular paper bags. Use the “listening
test” by stopping the oven as soon as the
popping slows to a “pop” every 1 or 2
seconds. Do not repop unpopped kernels. Do
not pop popcorn in glass cookware.

20

CARE AND CLEANING

Although your oven is provided with safety features, it is important to observe the following:

1. It is important not to defeat or tamper with safety
interlocks.

2. Do not place any object between the oven front
face and the door or allow residue to accumulate on
sealing surfaces. Wipe the sealing area frequently
with a mild detergent, rinse and dry. Never use
abrasive powders or buttons.

3. When opened, the door must not be subjected to
strain, for example, a child hanging on an opened
door or any load could cause the oven to fall
forward to cause injury and also damage to the
door. Do not operate the oven if it is damaged, until
it has been repaired by a competent service
technician. It is particularly important that the oven
closes properly and that there is no damage to the:
i) Door(bent)
ii) Hinges and Hookes(broken or loosened)
iii) Door seals and sealing surfaces.

4. The oven should not be adjusted or repaired by
anyone except a properly competent service
technician.

5. The oven should be cleaned regularly and any food
deposits removed;

6. Failure to maintain the oven in a clean condition
could lead to deterioration of the surface that could
adversely affect the life of the appliance and
possibly result in a hazardous situation.

7. Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they
can scratch the surface, which may result in
shattering of the glass.

8. A steam cleaner is not to be used.

BEFORE YOU CALL FOR SERVICE

Refer to following checklist, you may prevent an unnecessary service call.

* The oven doesn’t work :

1. Check that the power cord is securely plugged
in.

2. Check that the door is firmly closed.

3. Check that the cooking time is set.

4. Check for a blown circuit fuse or tripped main
circuit breaker in your house.

* Sparking in the cavity;

1. Check utensils. Metal containers or dishes with
metal trim should not be used.

2. Check that metal skewers or foil does not press
the interior walls.

If there is still a problem, contact the service agent.
A list of these agent is included in the oven.

DISPOSAL OF USED ELECTRICAL &
ELECTRONIC EQUIPMENT

The meaning of the symbol on the product, its accessory or packaging indicates that this
product shall not be treated as household waste. Please, dispose of this equipment at your
applicable collection point for the recycling of electrical & electronic equipment waste. In the
European Union and Other European countries there are separate collection systems for used
electrical and electronic product. By ensuring the correct disposal of this product, you will help
prevent potential hazardous to the environment and to human health, which could otherwise be
caused by unsuitable waste handling of this product. The recycling of materials will help
conserve natural resources. Please do not therefore dispose of your old electrical and
electronic equipment with your household waste. For more detailed information about recycling
of this product, please contact your local city office, your household waste disposal service or
the shop where you purchased the product.

21

SPECIFICATIONS

POWER SUPPLY AC 220~240V 50Hz, SINGLE PHASE WITH EARTHING

MICROWAVE POWER CONSUMPTION 1450 W

MICROWAVE ENERGY OUTPUT 1000 W

MICROWAVE FREQUENCY 2450MHz

OUTSIDE DIMENSIONS (WXHXD) 612X350X493mm(24.1X13.8X19.4 in)

CAVITY DIMENSIONS (WXHXD) 434X292X481mm(17.1X11.5X18.9 in)

NET WEIGHT APPROX. 21Kg (46.3 lbs)

TIMER 59 min. 99 sec.

POWER SELECTIONS 10 LEVELS

* Specifications are subject to change without notice.

612 493

350

22

COOKING INSTRUCTIONS

Utensil Guide

Only use utensils that are suitable for use in microwave ovens.
To cook food in the microwave oven, the microwaves must be able to penetrate the food, without
being reflected or absorbed by the dish used. Care must therefore be taken choosing the utensil. If the
utensil is marked microwave-safe, you do not need to worry. The following table lists various of utensil
and indicates whether and how they should be used in a microwave oven.

● : Recommended use
▲ : Limited Use
✕ : Not Recommended

Aluminium foil

Crust plate

China and earthenware

Disposable polyester
cardboard dishes

Fast-food packaging

• Polystyrene cups containers

• Paper bags or newspaper

• Recycled paper or metal trims

Glassware

• Oven-to-table ware

• Fine glassware

• Glass jars

Metal

• Dishes

• Freezer bag twist ties

Paper

• Plates, cups, napkins and
Kitchen paper

• Recycled paper

Plastic

• Containers

• Cling film

• Freezer bags

Wax or grease-proof paper

Utensil Safe Comments

Can be used in small quantities to protect areas against
overcooking. Arcing can occur if the foil is too close to
the oven wall or if too much foil is used.

Do not preheat for more than 8minutes.

Porcelain, pottery, glazed earthenware and bone china
are usually suitable, unless deco-rated with a metal trim.

Some frozen foods are packaged in these dishes.

Can be used to warm food. Overheating may cause the
polystyrene to melt.
May catch fire.
May cause arcing.

Can be used, unless decorated with a metal trim.
Can be used to warm foods or liquids.
Delicate glass may break or crack if heated suddenly.
Must remove the lid. Suitable for warming only.

May cause arcing or fire.

For short cooking times and warming. Also to absorb
excess moisture.
May cause arcing.

Particularly if heat-resistant thermoplastic. Some other
plastics may warp or discolour at high temperatures. Do
not use Melamine plastic.
Can be used to retain moisture. Should not touch the
food.
Take care when removing the film as hot steam will
escape.
Only if boilable or oven-proof. Should not be airtight.
Prick with a fork, if necessary.

Can be used to retain moisture and prevent spattering.

▲

●

●

●

●

✕
✕

●

●

●

✕
✕

●

✕

●

●

▲

●

23

USE YOUR MICROWAVE OVEN SAFELY

General Use

Do not attempt to defeat or tamper with safety
interlocks.
Do not place any object between the oven front
frame and the door or allow residue to build up on
sealing surfaces. Wipe with a mild detergent, rinse
and dry. Never use abrasive powders or buttons.
Do not subject the oven door to strain or weight such
as a child hanging on an open door.
This could cause the oven to fall forward resulting in
injury to you and damage to the oven.

Do not operate the oven if door seals or sealing
surfaces are damaged; or if door is bent; or if hinges
are loose or broken.
Do not operate the oven empty. This will damage the
oven.
Do not attempt to dry clothes, newspapers or other
materials in the oven. They may catch on fire.
Do not use recycled paper products as they may
contain impurities which may cause sparks or fires.
Do not hit or strike the control panel with hard
objects. This can damage the oven.

Food

Never use your microwave oven for home canning.
The oven is not designed for proper home canning.
Improperly canned food may spoil and be dangerous
to consume.
Always use the minimum recipe cooking time. It is
better to undercook rather than overcook foods.
Undercooked foods can be returned to the oven for
more cooking. If food is overcooked, nothing can be
done.
Heat small quantities of food or foods with low
moisture carefully. These can quickly dry out, burn or
catch on fire.
Do not heat eggs in the shell. Pressure may build up
and eggs can explode.
Potatoes, apples, egg yolks and sausages are
examples of food with non-porous skins.
These must be pierced before cooking to prevent
bursting.
Do not attempt to deep fat fry in your microwave
oven.
Always allow a standing time of at least 20 seconds
after the oven has been switched off to allow the

temperature to even out, stir during heating, if
necessary, and ALWAYS stir after heating. To
prevent eruptive boiling and possible scalding, you
should put a spoon or glass stick into the beverages
and stir before, during and after heating.
Do not leave the oven unattended while popping
corn.
Do not pop corn in a paper bag unless it is the
commercially prepared Microwave Popcorn product.
The kernels can overheat and ignite a brown paper
bag.
Do not put packaged Microwave Popcorn bags
directly on the oven tray. Place the package on a
microwave safe glass or ceramic plate to avoid
overheating and cracking the oven tray.
Do not exceed the Microwave Popcorn
manufacturers suggested popping time.
Longer popping does not yield more popcorn but it
can result in scorch, burn of fire. Remember, the
Popcorn bag and tray can be too hot to handle.
Remove with caution and use pot holders.

ARCING

If you see arcing, touch the CLEAR/OFF pad and correct the problem.

Arcing is the microwave term for sparks in the oven.

Arcing is caused by:

• Metal or foil pressing the side of the oven.

• Foil not molded to food (upturned edges act like
antennas).

• Metal, such as twist-ties, poultry pins, or gold
rimmed dishes, in the microwave.

• Recycled paper towels containing small metal
pieces being used in the microwave.

24

MICROWAVING PRINCIPLES

Microwave energy has been used in this country to cook and reheat food since early experiments with
RADAR in World War ll. Microwaves are present in the atmosphere all the time, both naturally and manmade
sources. Manmade sources include radar, radio, television, telecommunication links and car phones.

CONVERSION CHARTS

WEIGHT MEASURES

15 g

1

/2 oz.
25 g 1 oz.
50 g 2 oz.

100 g 4 oz.
175 g 6 oz.
225 g 8 oz.
450 g 1 lb.

HOW MICROWAVES COOK FOOD

Microwave oven is a Group 2 ISM equipment in which radio frequency energy is intentionally generated and
used in the form of electromagnetic radiation for the treatment of material. This oven is a Class B equipment
suitable for use in domestic establishments and in establishments directly connected to a low voltage power
supply network which supplies buildings used for domestic purposes.

VOLUME MEASURES

30 ml 1 fl.oz.
100 ml 3 fl.oz.
150 ml 5 fl.oz. (1/4 pt)
300 ml 10 fl.oz. (1/2 pt)
600 ml 20 fl.oz. (1pt)

SPOON MEASURES

1.25 ml

1

/4 tsp

2.5 ml

1

/2 tsp

5 ml 1 tsp

15 ml 1 tbsp

FLUID MEASUREMENTS

1 Cup = 8 fl.oz. = 240 ml
1 Pint = 16 fl.oz. (UK 20 fl.oz.) = 480 ml (UK 560 ml)
1 Quart = 32 fl.oz. (UK 40 fl.oz.) = 960 ml (UK 1120 ml)
1 Gallon = 128 fl.oz. (UK 160 fl.oz.) = 3840 ml (UK 4500 ml)

Then they pass through the
cooking containers to be
absorbed by the water
molecules in the food, all
foods contain water to a
more or lesser extent.

The microwaves cause the water molecules to
vibrate which causes FRICTION, i.e. HEAT. This
heat then cooks the food. Microwaves are also
attracted to fat and sugar particles, and foods high in
these will cook more quickly. Microwaves can only
penetrate to a depth of 4-5cm and as heat spreads
through the food by conduction, just as in a traditional
oven, the food cooks from the outside inwards.

In a microwave oven,
electricity is converted
into microwave by the
MAGNETRON.

The microwaves
bounce off the metal
walls and the metal
door screen.

Oven Cavity

Magnetron

Waveguide

Turntable

REFLECTION

TRANSMISSION

ABSORPTION

Microwave Water Molecule Absorption Vibration

25

STANDING TIME

Dense foods e.g. meat, jacket potatoes and
cakes, require standing time(inside or outside of
the oven) after cooking, to allow heat to finish
conducting to cook the center completely. Wrap
meat joints and jacket potatoes in aluminium foil
while standing. Meat joints need approx. 10-15
minutes, jacket potatoes 5 minutes. Other foods
such as plated meal, vegetables, fish etc require
2-5 minutes standing. After defrosting food,
standing time should also be allowed. If food is not
cooked after standing time, return to the oven and
cook for additional time.

MOISTURE CONTENT

Many fresh foods e.g. vegetables and fruit, vary in
their moisture content throughout the season,
particularly jacket potatoes. For this reason
cooking times may have to be adjusted. Dry
ingredients e.g. rice, pasta, can dry out during
storage so cooking times may differ.

DENSITY

Porous airy foods heat more quickly than dense
heavy foods.

CLING FILM

Cling film helps keep the food moist and the
trapped steam assists in speeding up cooking
times. Pierce before cooking to allow excess
steam to escape. Always take care when
removing cling film from a dish as the build-up of
steam will be very hot.

SHAPE

Even shapes cook evenly. Food cooks better by
microwave when in a round container rather than
square.

SPACING

Foods cook more quickly and evenly if spaced
apart. NEVER pile foods on top of each other.

STARTING TEMPERATURE

The colder the food, the longer it takes to heat up.
Food from a fridge takes longer to reheat than
food at room temperature.

LIQUIDS

All liquids must be stirred before and during
heating. Water especially must be stirred before
and during heating, to avoid eruption. Do not heat
liquids that have previously been boiled. DO NOT
OVERHEAT.

TURNING & STIRRING

Some foods require stirring during cooking. Meat
and poultry should be turned after half the cooking
time.

ARRANGING

Individual foods e.g. chicken portions or chops,
should be placed on a dish so that the thicker
parts are towards the outside.

QUANTITY

Small quantities cook faster than large quantities,
also small meals will reheat more quickly than
large portions.

PIERCING

The skin or membrane on some foods will cause
steam to build up during cooking. These foods
must be pierced or a strip of skin should be peeled
off before cooking to allow the steam to escape.
Eggs, potatoes, apples, sausages etc, will all need
to be pierced before cooking. DO NOT ATTEMPT
TO BOIL EGGS IN THEIR SHELLS.

COVERING

Cover foods with microwave cling film or a lid.
Cover fish, vegetables, casseroles, soups. Do not
cover cakes, sauces, jacket potatoes or pastry
items.

COOKING TECHNIQUES

26

ᶀ Do not defrost covered meat. Covering might allow cooking to take place. Always remove outer wrap and tray. Use

only containers that are microwave-safe.

ᶀ Begin defrosting whole poultry breast-side-down. Begin defrosting roasts fat-side-down.

ᶀ The shape of the package alters the defrosting time. Shallow rectangular shapes defrost more quickly than a deep

block.

ᶀ

After 1/3 of the defrost time has elapsed, check the food.

You may wish to turn over, break apart, rearrange or remove

thawed portions of the food.

ᶀ During defrost, the oven will prompt you to turn the over. At this point, open oven door and check the food. Follow

the techniques listed below for optimum defrost results.

Then, close oven door, press the START button to complete defrosting.

ᶀ When defrosted, food should be cool, but softened in all areas. If still slightly icy, return to microwave oven very

briefly, or let stand a few minutes. After defrosting, allow food to stand 5-60 minutes if there are any icy areas.

Poultry and fish may be placed under running cool water until defrosted

➪ Turn over : Roast, ribs, whole poultry, turkey breasts, hot dogs, sausages, steaks, or chops.

➪ Rearrange : Break apart or separate steaks, chops, hamburger patties, ground meat, chicken or seafood pieces,

chunks of meat such as stew beef.

➪ Shield : Use small strips of aluminum foil to protect thin areas or edges of unevenly shaped foods such as chicken

wings. To prevent arcing, do not allow foil to come within 1-inch of oven walls or door.

➪ Remove : To prevent cooking, thawed portions should be removed from the oven at this point. This may shorten

defrost time for food weighing less than 3 lbs.(1350g).

DEFROSTING GUIDE

27

COOKING & REHEATING CHART

Cooking chart

MEAT

Beef joint -Rare P-80 6-8 min.

-Medium P-80 7-9 min.

-well done P-80 9-11 min.

Lamb Joint P-HI 10-13 min.

Bacon joint P-HI 8-10 min.

POULTRY

Whole chicken P-HI 4-9 min.

Portions chicken P-80 5-7 min.

Breast (boned) P-80 6-8 min.

FISH

Fish Fillets P-HI 3-5 min.

Whole Mackerel, P-HI 3-5 min.

Cleaned and prepared

Whole Trout, Cleaned P-HI 4-6 min.

& Prepared

Salmon steaks P-HI 4-6 min.

NOTE : The above times should be regarded only as a guide. Allow for difference in individual tastes and

preferences. The times may vary due to the shape, cut, and composition of the food.

Frozen meat, poultry and fish must be thoroughly thawed before cooking.

Item

Power Cooking Time

Special Instruction

Level Per lb./450g

- Chilled meat and poultry should be removed from
the refrigerator at least 30 minutes before
cooking.

- Always let the meat and poultry stand, covered
after cooking.

- Brush a little oil or melted butter over the fish, or
add 15~30ml(1-2 tbsp) lemon juice, wine, stock,
milk or water.

- Always let the fish stand, covered, after cooking

28

Reheating chart

• Baby food particularly needs to be checked carefully before serving to prevent burns.

• When heating pre-packaged ready-cooked foods, always follow the pack instructions carefully.

• If you freeze foods which were bought from the fresh or chilled counters, remember that they should
be thoroughly thawed before following the heating instructions on the packed. It’s worth putting a
note on them so that other members of the household will remember too.

• Remember metal ties and transfer food from foil containers before reheating.

• Chilled(refrigerated) food takes longer to reheat than food at room temperature (such as just-cooled
food or food from the store cupboard).

• All foods should be reheated using full microwave power.

Baby food 20 sec.

128g jar

Baby milk

100ml / 4fl.oz. 20-30 sec.
225ml / 8fl.oz. 40-50 sec.

Sandwich roll or bun

1 roll 20-30 sec.

Lasagna

1 serving 4-6 min.
(10 1/2 oz./300g)

Casserole

1 cup 1

1

/2-3 min.

4 cups 5-7 min.

Mashed potatoes

1 cup 2-3 min.
4 cups 6-8 min.

Baked beans

1 cup 2-3 min.

Ravioli or pasta in sauce

1 cup 2-3 min.
4 cups 6-9 min.

Item Cooking time Special Instructions

Empty into a small serving bowl.
Stir well once or twice during heating.
Before serving, check the temperature carefully.

Stir or shake well and pour into a sterilized bottle.
Before serving, shake well and check the temperature carefully.

Wrap in paper towel and place on glass microwaveable rack.

*Note : Do not use recycled paper towels.

Place lasagna on microwaveable plate.
Cover with plastic wrap and vent.

Cook covered, in a microwaveable dish(casserole).
Stir once halfway through cooking.

Cook covered, in a microwaveable dish(casserole).
Stir once halfway through cooking.

Cook covered, in a microwaveable dish(casserole).
Stir once halfway through cooking.

Cook covered, in a microwaveable dish(casserole).
Stir once halfway through cooking.

29

VEGETABLE CHART

Use a suitable glass pyrex bowl with lid. Add 30-45ml cold water(2-3 tbsp.) for every 250g unless
another water quantity is recommended - see table. Cook covered for the minimum time - see table.
Continue cooking to get the result you prefer. Stir once during and once after cooking. Add salt, herbs
or butter after cooking. Cover during a standing time of 3 minutes.
Hint : cut the fresh vegetables into even sized pieces. The smaller they are cut, the quicker they will
cook.
All vegetables should be cooked using full microwave power.

Cooking Guide for frozen vegetables

Cooking Guide for fresh vegetables

Broccoli

1

/2 lb./250g

1 lb./500g

Brussels sprouts

1

/2

lb./250g

Carrots

1

/2 lb./250g

Cauliflower

1

/2 lb./250g

1 lb./500g

Courgettes

1

/2

lb./250g

Aubergine

1

/2 lb./250g

(Eggplant)

Leeks

1

/2 lb./250g

Mushrooms 0.3 lb./125g

1

/2 lb./250g

Onions

1

/2

lb./250g

Pepper

1

/2 lb./250g

Potatoes

1

/2 lb./250g

1 lb./500g

Turnip cabbage

1

/2 lb./250g

Vegetables Weight Time Comments

Prepare even sized florets.
Arrange the stems to the centre.

Add 60-75ml(5-6tbsp.) water.

Cut carrots into even sized slices.

Prepare even sized florets. Cut big florets into halves.
Arrange stems to the centre.

Cut courgettes into slices. Add 30ml(2tbsp.) water or a
knob of butter. Cook until just tender.

Cut aubergine into small slices and sprinkle with 1
tablespoon lemon juice.

Cut leeks into thick slices.

Prepare small whole or sliced mushrooms. Do not add
any water. Sprinkle with lemon juice. Spice with salt and
pepper. Drain before serving.

Cut onions into slices or halves. Add only 15ml(1tbsp.)
water.

Cut pepper into small slices.

Weigh the peeled potatoes and cut them into similar
sized halves or quarters.

Cut turnip cabbage into small cubes.

4-5 min
6-8 min

3

1

/2-5 min

4-5 min

4-5 min
6-8 min

4-5 min

4-5 min

4-5 min

1-2 min
2-4 min

2-3 min

2-4 min

4-6 min
6-8 min

4-6 min

spinach 0.3 lb./125g

broccoli

1

/2 lb./250g

Peas

1

/2 lb./250g

Green beans

1

/2 lb./250g

Mixed vegetables

1

/2 lb./250g

(carrots/peas/corn)

Mixed vegetables

1

/2 lb./250g

(Chinese style)

Vegetables Weight Time Instructions

Add 15ml(1tbsp.) cold water.

Add 30ml(2 tbsp.) cold water.

Add 15ml(1 tbsp.) cold water.

Add 30ml(2t tbsp.) cold water.

Add 15ml(1ttbsp.) cold water.

Add 15ml(1 tbsp.) cold water.

2-3 min

4-6 min

3-5 min

4-6 min

3-5 min

4-6 min

30

TOMATO & ORANGE SOUP

1 oz.(25g) butter
1 medium onion, chopped
1 large carrot & 1 large potato, chopped
1

3

/4lb(800g) canned, chopped tomatoes
juice and grated rind of 1 small orange
1

1

/2pints(900ml) hot vegetable stock
salt and pepper to taste

1. Melt the in a large bowl on P-10 for 1 minute.

2. Add the onion, carrot and potato and cook on P-10
for 4 minutes. stir halfway through cooking.

3. Add the tomatoes, orange juice, orange rind and
stock. Mix thoroughly. Season with salt and pepper
to taste. Cover the bowl and cook on P-10 for 15
minutes. stir 2-3 times during cooking, until the
vegetables are tender.

4. Blend and serve immediately.

FRENCH ONION SOUP

1 large onions, sliced
1 tbsp (15ml) corn oil
2 oz.(50g) plain flour
2 pints(1.2 liters) hot meat

or vegetable stock
salt and pepper to taste
2 tbsp (30ml) parsley, chopped
4 thick slices French bread
2 oz.(50g) cheese, grated

1. Place the onion and oil a bowl, mix well and cook on
P-10 for 1 minutes.

2. Stir in the flour to make a paste and gradually add
stock. Season and add the parsley.

3. Cover the bowl and cook on P-70 for 16 minutes.

4. Pour the soup into serving bowls, submerge bread
and sprinkle generously with cheese.

5. Cook on P-70 for 2 minutes, until the cheese has
melted.

STIR FRIED VEGETABLES

1 tbsp(15ml) sunflower oil
2 tbsp (30ml) soy sauce
1 tbsp (15ml) sherry
1"(2.5cm) root ginger,

peeled and finely grated
2 medium carrots, cut into fine strips
4 oz.(100g) button mushrooms,

chopped
2 oz.(50g) beansprouts
4 oz.(100g) mange-tout
1 red pepper, seeded and thinly sliced
4 spring onions, chopped
4 oz.(100g) canned water chestnuts,

sliced

1

/4 head of chinese leaves, thinly sliced

1. Place the oil, soy sauce, sherry, ginger, garlic and
carrots in a large bowl, mix thoroughly

2. Cover and cook on P-10 for 3-5 minutes, stirring
once.

3. Add the button mushrooms, beansprouts, mange­tout, red pepper, spring onions, water chestnuts and
chinese leaves. Mix thoroughly.

4. Cook on P-10 for 3-4 minutes, until the vegetables
are tender. Stir 2-3 times during cooking.

Stir fried vegetables are ideally served with meat or
fish.

HONEYED CHICKEN

4 boneless chicken breasts
2 tbsp(30ml) clear honey
1 tbsp(15ml) whole grain mustard

1

/2 tsp(2.5ml) dried tarragon

1 tbsp(15ml) tomato puree

1

/4 pint(150ml) chicken stock

1. Place the chicken breasts in a casserole dish.

2. Mix all remaining ingredients together and pour over
the chicken. Salt and pepper to taste.

3. Cook on P-10 for 10-12 minutes. Rearrange and
coat the chicken with the sauce twice during
cooking.

RECIPES

31

BLUE CHEESE & CHIVE JACKETS

2 baking potatoes,

(approx.9 oz.(250g) each)
2 oz.(50g) butter
4 oz.(100g) blue cheese, chopped
1 tbsp(15ml) fresh chives, chopped
2 oz.(50g) mushrooms, sliced
salt and pepper to taste

1. Prick each potato in several places. Cook on P-10
for 7-9 minutes. Halve and scoop the flesh into a
bowl, add the butter, cheese, chives, mushrooms,
salt and pepper, mix thoroughly.

2. Pile mixture into the potato skins and place in a flan
dish.

3. Cook on P-50 for 10 minutes.

WHITE SAUCE

1 oz.(25g) butter
1 oz.(25g) plain flour

1

/2 pint(300ml) milk

salt and pepper to taste

1. Place the butter in a bowl and cook on P-10 for 1
minute, until melted.

2. Stir in the flour and whisk in the milk. Cook on P-10
for 4-5 minutes, stirring every 2 minutes until thick
and smooth. Season with salt and pepper to taste.

STRAWBERRY JAM

11/2

lb.(675g) strawberries, hulled
3 tbsp(45ml) lemon juice
1

1

/2

lb.(675g) caster sugar

1. Place strawberries and lemon juice in a very large
bowl, heat on P-10 for 4 minutes, or until the fruit
has softened. Add sugar, mix well.

2. Cook on P-70 for 20-25 minutes, until setting point*is
reached, stir every 4-5 minutes.

3. Pour into hot, clean jars. Cover, seal and label.

* setting point : To determine setting point, place 1

tsp(5ml)jam onto chilled saucer. Allow to stand for 1
minute. Move surface of jam gently with your finger, if
the surface wrinkles setting point has been reached.

PLAIN MICROWAVE CAKE

4 oz.(100g) margarine
4 oz.(100g) sugar
1 eggs
4 oz.(100g) self raising flour, sifted
2-3 tbsp(30-45ml) milk

1. line the base of 8" (20.4cm) cake dish with grease­proof paper.

2. Cream the margarine and sugar together until light
and fluffy. Beat in the eggs and fold in the sifted flour
alternately with the milk.

3. Pour into prepared container. Cook on P-10 for 4-5
minutes, until a skewer comes out cleanly.

4. Leave the cake to stand for 5 minutes before turning
out.

OMELETTS

1

/2 oz.(15g) butter
4 eggs
6 tbsp(90ml) milk
salt & pepper

1. Whisk together eggs and milk.

2. Place butter in 10"(26cm) flan dish. Cook on P-10 for
1 minute, until melted. Coat the dish with the melted
butter.

3. Pour omelette mixture into flan dish. Cook on P-10
for 3 minutes. whisk mixture and cook again on P-10
for 1 minutes.

32

SCRAMBLED EGG

1

/2 oz.(15g) butter
2 eggs
2 tbsp(30ml) milk
salt & pepper

1. Melt the butter in a bowl on P-10 for 1 minute.

2. Add the eggs, milk and seasoning and mix well.

3. Cook on P-10 for 3 minutes, stirring every 30
seconds.

SAVORY MINCE

1 small onion, diced
1 clove garlic, crushed
1 tsp(5ml) oil
7 oz.(200g) can chopped tomatoes
1 tbsp(15ml) tomato puree
1 tsp(5ml) mixed herbs
8 oz.(225g) minced beef
salt and pepper

1. Place onion, garlic and oil in casserole, and cook on
P-10 for 2 minutes or until soft.

2. Place all other ingredients in casserole. Stir well.

3. Cover and cook on P-10 for 5 minutes then P-50 for

8-12 minutes or until the meat is cooked.
