INSTRUCTION MANUAL
SM4M/SM16M Storage Module
Revision: 3/01
Copyright (c) 2000-2001
Campbell Scientific, Inc.
Warranty and Assistance
The SM4M/SM16M STORAGE MODULE is warranted by CAMPBELL
SCIENTIFIC, INC. to be free from defects in materials and workmanship under
normal use and ser vice for twelve (1 2) months from date of shipment unless
specified otherwise. Batteries have no warranty. CAMPBELL SCIENTIFIC,
INC.'s obligation under this warranty is limited to repairing or replacing (at
CAMPBELL SCIENTIFIC, INC.'s option) defective products. The customer
shall assume all costs of removing, reinstalling, and shipping defective products
to CAMPBELL SCIENTIFIC, INC. CAMPBELL SCIENTIFIC, INC. will
return such products by surface carrier prepaid. This warranty shall not apply
to any CAMPBELL SCIENTIFIC, INC. products which have been subjected to
modification, misuse, neglect, accidents of nature, or shipping damage. This
warranty is in lieu of all other warranties, expressed or implied, including
warranties of merchantability or fitness for a particular purpose. CAMPBELL
SCIENTIFIC, INC. is not liable for special, indirect, incidental, or
consequential damages.
Products may not be returned without prior authorization. The following
contact information is for US and International customers residing in countries
served by Campbell Scientific, Inc. directly. Affiliate companies handle repairs
for customers within their territories. Please visit www.ca mpbellsci.co m to
determine which Campbell Scientific company serves your country. To obtain
a Returned Materials Authorization (RMA), contact CAMPBELL
SCIENTIFIC, INC., phone (435) 753-2342. After an applications engineer
determines the nature of the problem, an RMA number will be issued. Please
write this number clearly on the outside of the shipping container.
CAMPBELL SCIENTIFIC's shipping address is:
CAMPBELL SCIENTIFIC, INC.
RMA#_____
815 West 1800 North
Logan, Utah 84321-1784
CAMPBELL SCIENTIFIC, INC. does not accept collect calls.
SM4M/16M Storage Module
Table of Contents
PDF viewers note: These page numbers refer to the printed version of this document. Use
the Adobe Acrobat® bookmarks tab for links to specific sections.
Section 1. SM4M/SM16M Storage Module Overview.1-1
1.1 Specifications........................................................................................ 1-1
1.2 Physical Description.............................................................................1-2
1.3 Power.................................................................................................... 1-3
1.3.1 Primary Power............................................................................. 1-3
1.3.2 Backup Power and Data Retention.............................................. 1-3
1.4 Function................................................................................................ 1-3
1.4.1 Operation with Current Dataloggers ........................................... 1-3
1.4.2 Operation with Dataloggers with Older Operating Systems........ 1-4
1.4.3 Data Retrieval/Telecommunication Command State...................1-4
1.4.4 Memory Configuration................................................................ 1-5
1.4.5 Baud Rates..................................................................................1-5
1.4.6 File Marks................................................................................... 1-5
1.4.7 Power-up Status Indication......................................................... 1-6
1.5 Quick Start-Up Procedure..................................................................... 1-7
1.5.1 Preparation.................................................................................. 1-7
1.5.2 Programming the Datalogger to Send Data to the
Storage Module ..................................................................... 1-7
1.5.3 Manual Dump..............................................................................1-7
1.5.4 Data Retrieval ............................................................................. 1-7
Section 2. Storing Data from Curre nt Datal ogger s ...2-1
2.1 Instruction 96—Output Data Under Program Control.......................... 2-1
2.1.1 Multiple Storage Modules with the CR500/510, CR10/10X,
or CR23X.................................................................................. 2-2
2.1.2 Use of Two Storage Modules with the 21X or CR7.................... 2-3
2.2 *8 and *9 Mode—Keyboard-Initiated Data Transfer ........................... 2-3
2.2.1 *8 Mode—CR500/510, CR23X, CR10/10X............................... 2-3
2.2.2 *9 Mode—21X or CR7............................................................... 2-3
2.3 Storing Burst Measurement Data from the CR10/10X, CR23X,
or 21X.................................................................................................. 2-4
2.3.1 Burst Data with CR10/10X, CR23X Dataloggers....................... 2-4
2.3.2 Burst Data with 21X Dataloggers ............................................... 2-4
Section 3. The Printer Enable Method of
Data Storage............................................................3-1
3.1 Baud Rates............................................................................................ 3-1
3.2 Storing Data from the 21X and CR7..................................................... 3-1
3.2.1 Instruction 96—Output Under Program Control......................... 3-1
3.2.2 *4 Mode—Output Device Enable............................................... 3-2
3.2.3 *9 Mode—Keyboard-Initiated Data Transfer............................. 3-2
i
SM4M/16M Flash Storage Module Table of Contents
3.3 Special Data Storage Operations........................................................... 3-2
3.3.1 DSP4 Heads Up Display ............................................................. 3-2
3.3.2 Storing Burst Measurement Data from the 21X..........................3-2
Section 4. Storage Module Memory:
Details of Data Storage.......................................... 4-1
4.1 File Marks.............................................................................................4-1
4.2 Pointers .................................................................................................4-1
4.3 Data Formats — Space Requirements................................................... 4-2
4.4 Available Storage..................................................................................4-2
4.5 Bad Data................................................................................................4-3
Section 5. Data Retrieval............................................ 5-1
5.1 Hardware............................................................................................... 5-1
5.1.1 SC532(A) Interface.....................................................................5-1
5.1.2 Via Datalogger ............................................................................ 5-2
5.1.3 Via Remote Datalogger and Modem...........................................5-3
5.2 SMS.......................................................................................................5-3
5.3 Data Retrieval .......................................................................................5-3
5.3.1 Direct Connection........................................................................5-3
5.3.2 Connection Via CR500/510, CR10/10X or CR23X....................5-4
Section 6. Storing and Retrieving
Datalogger Programs............................................. 6-1
6.1 SMS Storage Module Support Software...............................................6-1
6.2 *D Mode—with Datalogger..................................................................6-1
6.3 Using DSP4 Heads Up Display to Store and
Retrieve Datalogger Programs............................................................. 6-2
Appendix A. *9 Mode—Storage Module
Commands .............................................................A-1
Appendix B. Telecommunications Commands ........B-1
Appendix C. Storage Module 9-Pin Connector.........C-1
Appendix D. Upgrading the Operating System.........D-1
Appendix E. SC532A...................................................E-1
ii
Figures
Tables
SM4M/16M Flash Storage Module Instruction Manual
1-1 Storage Module and SC12 Cable.......................................................... 1-2
1-2 Operation with Current Dataloggers ..................................................... 1-4
1-3 Pin-Enable Operations.......................................................................... 1-4
1-4 Telecommunications Command State................................................... 1-5
5-1 Storage Module Connected to a Portable PC via
SC532(A) Interface....................................................................... 5-1
5-2 Communication Via the CR500/510, CR10/10X or CR23X................ 5-2
5-3 Communication Via the CR23X........................................................... 5-2
5-4 Typical Setup for Remote Collection of Data Via
Datalogger and Modem................................................................ 5-3
4-1 Ring-Memory Effective Memory Capacity .......................................... 4-3
6-1 *D Mode Keyboard Commands........................................................... 6-1
A-1 *9 Mode Commands for Storage Module............................................A-2
iii
SM4M/16M Flash Storage Module Table of Contents
This is a bla nk page.
iv
Section 1. SM4M / SM16M Storage Module Overview
Campbell Scientific’s SM4M and SM16M Storage Modules expand on-site data storage
for users of Campbell Scientific dataloggers. They also provide the user with a convenient
method of transporting data from the field back to the office. The SM4M and SM16M are
compatible with the CR500/510, CR10/10X, 21X, CR23X and CR7 dataloggers as well as
the DSP4 Heads Up Display.
This manual contains two broad divisions. The Overview surveys the Storage Modules
and their function. It also explains how to quickly begin using a Storage Module for
straightforward data storage operations. The remainder of the manual is a technical
reference which describes in detail such operations as: storing data from current
dataloggers, storing data from older dataloggers, data retrieval, and datalogger program
storage and retrieval.
The Overview should be read by all users, as should Section 5 (Data Retrieval). Users
with the CR500/510, CR10/10X, CR23X or with the 21X or CR7 with recent operating
systems (i.e., current dataloggers) should read Section 2, while users of Campbell
Scientific’s older dataloggers should read Section 3. Section 6 (Storing and Retrieving
Datalogger Programs) and Appendix B (Telecommunication Commands) may be used as
needed.
SMS (Storage Module Software) simplifies communication procedures between
dataloggers and Storage Modules. SMS is part of Campbell Scientific’s PC208W
Windows-based datalogger support software. Contact Campbell Scientific for further
information.
1.1 Specifications
Storage Capacity:
SM4M: 2 Million low-resolution data values
SM16M: 8 Million low-resolution data values
Program storage: stores up to eight programs with a total
capacity of 128 kbytes (including labels)
Dimensions: 135 x 75 x 20 mm
Weight: 200 g
Canister: Sealed
Processor: Hitachi H8S
Operating system: 64 kbytes, flash memory based, user
downloadable.
Operating Temp. Range: -35°C to +65°C (-55°C to +85°C optional)
1-1
Section 1. SM4M/SM16M Storage Module Overview
Baud Rates for data storage: 9600, 76800 baud
Baud Rates for
telecommunications: 300, 1200, 2400, 4800, 9600, 19200, 38400,
Memory Configuration: User selectable for either ring style (default) or
Power Requirements: 5 ±0.3V DC @ 100mA (max.)
Current drains:
Active, processing,
(e.g., memory test): 30–40 mA (avg.)
Active, but waiting,
(e.g., communications mode): 10mA (avg.)
Typical current during
data storage from a datalogger: 15 mA (avg.)
Low Power Standby State: Less than 200µA.
Peak current (flash erase): 60 mA
Maintenance: There are no user-serviceable parts inside the
57600, 76800, 115200.
fill and stop.
Storage Module.
FIGURE 1-1. Storage Module and SC12 Cable
1.2 Physical Description
The Storage Module is housed in a sealed canister with a single, 9-pin Dconnector. The Storage Module is connected to a datalogger via the SC12 9conductor ribbon cable.
There are two LEDs (light emitting diodes) adjacent to the connector. A red,
status LED indicates the operational status of the module at power-up (see
section 1.4.7) and a green LED lights when data is being stored in the module.
SN:
SM4M
Logan, UT
SOLID STATE STORAGE MODULE
STATUS
WRITE
MADE IN USA
1-2
1.3 Power
1.3.1 Primary Power
1.3.2 Backup Power and Data Retention
Section 1. SM4M/SM16M Storage Module Overview
The SM4M and SM16M are identical except for the amount of memory they
contain. The internal memory is split into 64 kb blocks. There are 64 blocks
of memory in an SM4M and 256 blocks in an SM16M. This equates to a
capacity of more than 2 millio n low-resolution storage valu es f or the SM4M
and more than 8 million low-resolution values for th e SM16M (see Section
4.4).
The Storage Module is powered by 5 VDC received from the datalogger or
from data retrieval interfaces such as the SC532(A) 9-pin Peripheral to RS232.
Pin 1 of the 9-pin D-connector supplies the 5 VDC. Pin 2 is both the power
ground and signal ground.
The modules use non-volatile flash EEPROM memory which does not require
power to retain data. There is no internal b a tter y .
1.4 Function
1.4.1 Operation with Current Datal ogger s
The flash memory will retain stored d ata f or approximately 10 years.
Typically, the flash memory can be erased and rewritten a minimum of
100,000 times.
The SM4M and SM16M Storage Modules supplement the storage capacity in a
datalogger. The Storage Modules can store data from Campbell Scientific
dataloggers and from other devices which properly enable them.
All Storage Module operations occur in one of three basic operational modes:
1. Interactive communication with the datalogger for data and program
storage and retrieval.
2. The Printer-Enable Method for data storage with the 21X and CR7, with
older operating systems, and also with the DSP4.
3. The Telecommunications Command State for data retrieval and other
miscellaneous operations.
The Storage Module uses an interactive command structure with handshaking
when connected to the CR500/510, the CR10/10X, CR23X, or to the 21X or
CR7 fitted with recent software (see Figure 1-2). If the Storage Module is not
connected the datalogger does not send data. The datalogger detects when the
Storage Module is connected and sends the backlogged data the next time it
executes Instruction 96.
1-3
Section 1. SM4M/SM16M Storage Module Overview
STORE DATA W/ INSTRUCTION 96
STORE DATA W/ *8 MODE CR500/CR510/CR10/CR10X/CR23X
Datalogger
STORE DATA W/ *9 MODE 21X, CR7
UPLOAD AND DOWNLOAD PROGRAMS W/ *D MODE
*9 MODE COMMANDS CR500/CR510/CR10/CR10X/CR23X
FIGURE 1-2. Operation with Current Dataloggers
The Storage Module can store data either under program control (Instruction
96) or under user control (*8 Mode with CR500/510/10/10X/23X, *9 Mode
with 21X and CR7). Datalogger programs can be stored in and retrieved from
the Storage Module using the *D Mode. The CR500/510/10/10X/23X *9
Mode enables the user to directly execute commands such as: change address,
view data, etc. (see your datalogger manual for full details).
1.4.2 Operation with Dataloggers with Ol der Operating
SM4M/
16M
21X
CR7X
CR7
DSP4
Systems (Printer-Enable Method)
In the Printer-Enable Method (see Figure 1-3), the Storage Module stores all
data received (on pin 9) while the printer enable line (pin 6) is high. The
Storage Module automatically detects the baud rate from the sending device
(9600 or 76800 only). The datalogger cannot detect whether the Storage
Module is connected. Data is sent whether or not the Storage Module is
connected.
SM4M/
16M
FIGURE 1-3. Pin-Enable Operations
Data can be stored in the Storage Module under program control (Instruction
96 or *4 Mode) or under user control (*9 Mode). Operations with the DSP4
Heads Up Displays also use the Printer-Enable Method (see Section 3).
1-4
1.4.3 Data Retrieval / Telecommunication Command State
Data retrieval and other interactive operations with a computer take place in
the Telecommunications command state (see Figure 1-4). PC208W uses the
Telecommunications Commands for data r e tr iev a l. Dir ect teleco mmunication
commands can also be sent from SMS (part of PC208W) in the Terminal
Section 1. SM4M/SM16M Storage Module Overview
Emulator mode. A list of direct telecommunication commands is shown in
Appendix B.
Computer/
Terminal
FIGURE 1-4. Telecommunications Command State
1.4.4 Memory Configuration
The Storage Module’s memory can be configured as either Fill and Stop or
Ring memory. In the Fill and Stop configuration, the Storage Module stops
accepting data when its memory is full. No data write-over occurs with this
configuration. In the Ring Memory configuration (the default setting), new
data continues to be stored even after th e memory is full. Once full, new data
is written over the oldest data. The Storage Module’s memory configuration
can be changed using SMS or with command 4 of the CR500/510, CR10/10X,
CR23X *9 Mode.
1.4.5 Baud Rates
The Storage Module automatically detects the baud rate of data sent to it.
SM4M/
16M
1.4.6 File Marks
CAUTION
When using the telecommunications commands, sending several carriage
returns will cause the Storage Module to match the computer’s baud rate (see
specifications above).
File Marks are used to separate data in the Storage Module. A File Mark is
automatically placed in the Storage Module’s memory when the Storage
Module is connected to a power source (datalogger or retrieval interface), or
when the datalogger compiles a program containing Instruction 96. For
example, if the user has retrieved data from one datalogger, disconnects the
Storage Module and then connects it to a second datalogger, a File Mark is
placed in the data when the second datalogger is connected. This mark follows
the data from the first datalogger and precedes the data from the second. A
File Mark can also be inserted under program control.
The Storage Module must be disconnected from power for
10 seconds or more to be certain it places a File Mark in
the Storage Module when reconnected.
A File Mark can be placed in the data by using SMS or the
CR500/510/10/10X/23X *9 Mode command 3. The Storage Module will not
1-5
Section 1. SM4M/SM16M Storage Module Overview
store contiguous File Marks; if a File Mark is the last thing stored in memory, a
second file mark will not be stored.
1.4.7 Power-up Status Indication
When power is applied to the Storage Module by plugging it into a datalogger
or SC532(A), the red “Status” LED will flash to indicate the status of the
module.
CAUTION
The Storage Module must be disconnected from power for
a minimum of 10 seconds to ensure it powers down and
performs the status check when reconnected.
After connection there will be a short d elay when neither LED is illuminated.
The length of the delay is variable and is partly determined by the address of
the module. This delay avoids excessive power consumption during power-up,
when several modules are connected to the datalogger. For a module at
address 1 the initial delay will be up to 2 seconds. The delay increases by
approximately one second for each increase in the address number.
The first flash after the delay will last from 1 to 2 seconds, depending on the
last use of the module. Further flashes follow with a 0.5 second OFF and 0.5
second ON spacing.
The total number of flashes indicates the status of the module, as follows:
Module OK 1 flash
Module operating system corrupted 2 flashes
OK and Program area full 3 flashes
Flash memory corrupted 4 flashes
1-6
OK and data has rung around at least once 5 flashes
Storage Module full 7 flashes
Previous operating system load failed 10 flashes
If the module is connected to a datalogger which has data to send, the green
“Write” LED may start to flash shortly after the end of the Status flash, as the
module becomes available to receive data and store it.
The module will only receive data if the status is OK, OK and program area
full, or OK and data has rung around at least once. For any of the other status
conditions the module will not accept any further data until the fault has been
corrected.
Section 1. SM4M/SM16M Storage Module Overview
1.5 Quick Start-Up Procedure
This Section describes the basics of storing and retrieving datalogger data.
These operations are discussed in detail in Sections 3, 4 and 5 of this manual.
1.5.1 Preparation
Before putting the Storage Module into service, connect it to a computer and
use SMS to reset the Storage Module and test the memory.
If it is not possible to use a PC and SMS, you must establish communication
between the Storage Module and the available computer or terminal (see
Section 5), and reset the Storage Module using telecommunications commands
(see Appendix B) or use the *9 Mode in the CR500/510, CR10/10X or
CR23X.
There are two possible reset mechanisms: a full reset and test (command
1248k), which erases the memory and then carries out a thorough test of the
storage memory; and a quick reset (command 1249k). While the 1248k
command thoroughly checks the module, it can take some time to perform this
test (over 20 minutes for larger modules). A quick reset, resets all the memory
pointers and erases the flash chips. It does a less rigorous test of the flash
memory adequate for most purposes. An SM16M will take around 3 minutes
to perform the quick reset.
1.5.2 Programming the Datalogger to Send Data to the Stor age Module
Instruction 96 is used in the datalogger program to send data to the Storage
Module. The Storage Module is connected to the datalogger with the SC12
cable. Each time Instruction 96 is executed, Final Storage data accumulated
since the last transfer is sent to the Storage Module.
For the CR7 and 21X
data to a Storage Module. The Output Enable code should be set to X1, Printer
Enabled ASCII.
The DSP4 outputs data to a Storage Module when the Storage Module function
(or, for older versions of software, the printer function) is enabled.
Instruction 96, the *4 Mode can be used to send
without
1.5.3 Manual Dump
The *8 Mode for the CR500/510, CR10/CR10X, CR23X or the *9 Mode for
the 21X and CR7 can be used to transfer data to the Storage Module under
keyboard control (see Section 4).
1.5.4 Data Retrieval
The simplest method of retrieving data from the Storage Module is to use SMS
which is part of the PC208W support package. If you have a computer which
cannot run this software, the Storage Module telecommunications commands
can be used to retrieve the data. Data retrieval (including interface devices) is
discussed in Section 5.
1-7
Section 1. SM4M/SM16M Storage Module Overview
This is a blank page.
1-8
Section 2. Storing Data from Current Dataloggers
This section covers data storage from the CR500/510, CR10/10X, CR23X and from the
21X and CR7 with current software. See Section 3 for the 21X and CR7 with early
operating systems.
2.1 Instruction 96 — Output Data Under Program Control
Instruction 96 is used to send Final Storage data to a Storage Module under
program control. Instruction 96 should be entered into the program table
following the Output Processing Instructions. Instruction 96 should be
executed each time the table is executed (i.e., the program should not branch
around or skip over Instruction 96). Instruction 96 can also be used to insert a
file mark into the data under program control. To do this, the option code
entered for parameter 1 is 7X (where X equals the Storage Module address)
and the parameter is indexed.
Instruction: 96
Parameter: 01:
7X — CR500/510, CR10/10X, CR23X uses option 7X to send the data to the
Storage Module with address ‘X’. X = 1 – 8
30 — 21X and CR7 use option code 30 to send data to the Storage Module.
When output to the Storage Module is enabled with Instruction 96, the Storage
Module(s) may either be left on-site and periodically exchanged, or brought to
the site to extract the data from the datalogger.
The datalogger is capable of recognizing whether or not the Storage Module is
connected. Each time Instruction 96 is executed and there is data to output, the
datalogger checks for the presence of the Storage Module. If one is not
present, no data is sent; the datalogger continues its other operations without
advancing its Storage Module Pointer.
When you finally connect the Storage Module to the datalogger, two things
happen:
1. Immediately on connection, a File Mark is placed in the Storage Module
memory at the position of the Module’s Storage Reference Pointer (SRP).
The File Mark allows the operator to distinguish blocks of data from
different dataloggers or from different visits to the field.
2. During the next execution of Instruction 96, the datalogger recognizes
that the Storage Module is present, outputs all of the data stored since the
2-1
Section 2. Storing Data from Current Dataloggers
previous output, and updates the Storage Module Pointer to the DSP
location. This transfer occurs in binary at 9600 baud.
Under optimum conditions, the datalogger outputs 480 low resolution data
points per second. For example, a full 128K CR10X takes over two minutes to
complete the data transfer. If the execution interval is less than two minutes,
the data transfer will be interrupted and will take longer to complete.
CAUTION
Be sure to complete the data transfer before making any
changes in the datalogger program. Changing a program
and then compiling it will advance the datalogger’s Storage
Module Pointer to the position of the DSP. If this is done
before connecting the Storage Module to allow the
datalogger to transfer the data, the old data will not be
automatically transferred to the Storage Module. Also, the
Instruction 96 data transfer will not take place while the
datalogger is in communication with another dev ice (e.g., a
computer or an active CR10KD).
To be certain that the Storage Module has been connected during an execution
of Instruction 96, you can observe the green “WRITE” LED of the SM which
indicates when data is being stored into the module. The user should connect
the SM to the datalogger and wait for the green LED to light.
goes off
To avoid data loss, data must be retrieved before the datalogger’s ring memory
wraps around and begins to write over the oldest data.
, data transfer is complete and the SM can be disconnected.
When the LED
2.1.1 Multiple Storage Modules wi th the CR500/ 510, CR10/10X, or CR23X
2-2
CAUTION
These dataloggers use synchronous addressing to communicate with multiple
peripherals. The CR23X must have OS1.7 or later to work with mu ltiple
modules. Up to four SM4M/SM16M Storage Modules can reliably be
connected to a single datalogger. Each is assigned an address, 1 to 8.
Addresses are assigned in the *9 Mode (command 10), using SMS or in the
Telecommunications Command State (the L command). These are discussed
in the datalogger manuals and Appendix B respectively. The default Storage
Module address after Reset (as shipped from the factory) is #1. This will be
sufficient for most users.
While up to eight Storage Modules can be addressed,
communication may be unreliable if more than four SM4M
or SM16M modules are connected to a datalogger at a
time. Contact Campbell Scientific if you need to connect
more than four modules.
At a given time, only one Storage Module will accept commands directed to
SM #1. If there is no Storage Module with address #1, the Storage Module
with the lowest numbered address will accept the co mmands sent to SM #1.
Section 2. Storing Data from Current Dataloggers
Commands directed to addresses other than #1 can be accepted
with the correct address. Do
address to a datalogger at the same time.
If only one Storage Module is used with the datalogger, its address should be
#1. When multiple Storage Modules are used in a datalogger system, each
should be assigned its own address and set to Fill and Stop. Instruction 96 is
configured in the datalogger program to send data to Storage Module address
#1. The lowest numbered Storage Module will fill up first, followed by the
next lowest address, and so on. Alternatively, data can be sent by the
datalogger to specific Storage Modules via direct addressing by the datalogger
(using a separate Instruction 96 for each SM).
Instruction 96 can be entered m ultiple times in a program to sort data to
specific Storage Modules. Three important considerations are:
1. All Storage Modules to be used must be connected to the datalogger with
SC12 cables.
2. Time must be allowed between the execution of multiple instan ces of
Instruction 96 to Storage Modules. Add 5ms to the time it takes to store
the number of bytes to be transmitted (1ms per byte) before executing the
next Instruction 96 which addresses a different Storage Module.
3. Use of the keyboard or telecommunications during the execution of the
Instruction 96 may backlog the data to be sent to the Storage Modules. In
this event, during the next execution of Instruction 96 all backlogged data
will be sent to the Storage Module addressed in that instruction.
connect Storage Modules with the same
not
by the SM
only
2.1.2 Use of Two Storage Modules with the 21X or CR7
For large volumes of data, two Storage Modules can be connected to the 21X
or CR7. Use SMS to set one SM as Fill and Stop, an d the other as Ring
Memory.
2.2 *8 and *9 Mode — Keyboard-Initiated Data Transfer
2.2.1 *8 Mode — CR500/510, CR23X, CR10/10X
The *8 Mode is used to manually initiate a Fin al Storage data transfer from the
datalogger to an external peripheral. Data transfer rate is 9600 baud. Refer to
the discussion of the *8 Mode in the datalogger Operator’s Manual for full
details.
2.2.2 *9 Mode — 21X or CR7
The *9 Mode in the 21X and CR7 dataloggers is used to transfer a specified
block of data from Final Storage to the Storage Module. Consult the
appropriate datalogger manual for details.
2-3
Section 2. Storing Data from Current Dataloggers
NOTE
This function is different from the *9 Mode in the CR500/510,
CR10/10X or CR23X.
2.3 Storing Burst Measurement Data from the CR10/10X, CR23X or 21X
Burst Measurement (Instruction 23) is a special datalogger instruction used to
make fast analog voltage measurements. Two options are available for data
retrieval with this instruction:
1. Data is stored in the datalogger Input Storage Locations
or
2. Raw data is output from the datalogger serial port.
In option 2, the Storage Module can capture the data at 76,800 baud. Burst
data is output by the datalogger in a unique format which includes calibration
measurements at the beginning and end of the series of measurements. Split
(part of the PC208/PC208W software packages) will translate this Burst data.
2.3.1 Burst Data with CR10/10X, CR23X Dataloggers
Entering a ‘3’ for the third digit in parameter 4 of Instruction 23 selects the
Storage Module as the destination of the Burst data. All Storage Modules
connected should be set to Fill and Stop and have consecutive addresses. The
Burst data will be sent to the first available (lowest addressed) Storage Module,
followed by the next lowest addressed, and so on.
2.3.2 Burst Data with 21X Dataloggers
To send Burst Measurement (Instruction 23) data to the Storage Module from
the 21X, set the Destination option (parameter 4) to 2 for serial port output at
76,800 baud.
2-4
Section 3. The Printer Enable Method of Data Storage
Data from the 21X and CR7 with PROMs older than the OSX and OX7 series PROMs (and
from the CR21 and DSP4) are stored in the Storage Module via the Printer Enable
Method; i.e., data on the TD line (pin 9) are stored while the PE line (pin 6) is high. The
Storage Module defaults to the Printer Enable Method each time it is powered up by 5V
DC applied to pin 1 of its 9-pin ‘D’ connector. Up to two Storage Modules can be
connected to the 21X or CR7 dataloggers at one time. If two are connected, one should be
set to Fill and Stop and the other configured as Ring Memory. Storage Module-to-Storage
Module dumps are not possible with the Printer Enable Method.
CAUTION
If the PE line is high when power is applied, the Storage
Module will not store data until the next time PE goes high.
Also, if power to the Storage Module is interrupted during
transmission, data stored since the last time PE went high
will be lost.
3.1 Baud Rates
In the Printer Enable Method, you must ensure that the baud rates of the
Storage Module and the datalogger are matched. The SM4M/SM16M will
only accept data at 9600 or 76800 baud. There is no user configuration for this
setting in the module as it automatically detects the speed of the data sent to it.
Baud rate errors (i.e., baud rate mismatches between the datalogger and the
Storage Module) cause the Storage Module to increment its error counter and
enter a low power standby state.
3.2 Storing Data from the 21X and CR7 (All Versions
Prior to OSX and OS7 Release)
Instruction 96 is the recommended method for the CR7 and the 21X with
Extended Software. The *4 Mode could also be used to transmit data in ASCII
format but Instruction 9 6 is more efficient as data is transferred in the most
compact binary format – therefore it is not recommended.
For large volumes of data two Storage Modules can be connected to the
datalogger. Use SMS to set one as Fill and Stop, and the other as Ring
Memory.
3.2.1 Instruction 96 — Output Under Program Control
Instruction 96, available in the CR7X and in the Extended Software PROMs
for the earlier versions of the 21X, is used to send Final Storage data to the
Storage Module under program control. Instruction 96 should follow the
3-1
Section 3. The Printer Enable Method of Data Storage
Output Processing Instructions in the program table. Consult the datalogger
manual for details about using Instruction 96. Do
and Instruction 96 to activate a device in a datalogger program.
Instruction: 96
Parameter: 01:22
Explanation: Option 22 selects binary printer output at 9600 baud. The
left digit specifies the device option and the right, the baud
rate. Refer to the datalogger manual for further details.
3.2.2 *4 Mode — Output Device Enable
The *4 Mode is used to enable the output of Final Storage data to a printer.
The Storage Module will capture this printer output.
Select option ‘X1’ in window 1, and set the baud rate at 9600 (option 02) in
window 2 (to match the Storage Module’s default setting). Data is written to
the Storage Module each time data is sent to Final Storage.
use both the *4 Mode
not
CAUTION
While the module will work with *4, data will be stored in the
module in ASCII format which requires up to 5 times more
memory space than binary format. Consider buying an
operating system upgrade for dataloggers that do not allow
binary data storage with P96.
3.2.3 *9 Mode — Keyboard-Initiated Data Transfer
The *9 Mode in the 21X and CR7 dataloggers is used to transfer a specified
block of data from Final Storage to the Storage Module. Consult the
appropriate datalogger manual for details. This function is different from the
*9 Mode in the CR10/10X and CR23X.
3.3 Special Data Storage Operations
3.3.1 DSP4 Heads Up Display
In addition to real-time monitoring of datalogger measurements, the DSP4
Heads Up Display can be used with the CR10/10X, CR23X, 21X and CR7
dataloggers to store and retrieve data and programs. With the DSP4 Storage
Module function enabled, datalogger Final Storage data can be sent to the
Storage Module. Refer to the DSP4 Instruction Manual for more details
regarding use with Storage Modules.
3-2
3.3.2 Storing Burst Measurement Data from the 21X
Burst Measurement (Instruction 23) is a special datalogger instruction available
for the 21X which makes fast analog voltage measurements. Two options are
available for data retrieval with this in struction:
Section 3. The Printer Enable Method of Data Storage
1. Data is stored in datalogger Input Storage locations
or
2. Raw data is sent out the datalogger serial port. In the second case, the
Storage Module can capture data at 76,800 baud.
When the Burst Measurement (Instruction 23) is used with the 21X, select the
destination (parameter 4) option as 2 for serial port output at 76,800 baud to
send data to the Storage Module. Burst data is output by the datalogger in a
unique format which includes calibration measurements at the beginning and
end of the series of measurements. Split (part of PC208/PC208W) will
translate Burst data.
3-3
Section 3. The Printer Enable Method of Data Storage
This is a blank page.
3-4
Section 4. Storage Module Memory: Details of Data Storage
Detailed knowledge of the way data is stored in the Storage Module is not normally
necessary for day-to-day use. However, if you ever need to work the exact memory
available or try to extract corrupted data it may be helpful to know these details.
4.1 File Marks
File Marks are used to separate data in the Storage Module. A File Mark is
automatically placed in the Storage Module’s memory when the module is
connected to a power source (datalogger or retrieval interface), when the
datalogger compiles a program containing Instruction 96, or under program
control. For example, if the user has retrieved data from one datalogger,
disconnects the Storage Module and then connects it to a second datalogger, a
File Mark is placed in the data when the second datalogger is connected. This
mark follows the data from the first datalogger and precedes the data from the
second.
CAUTION
4.2 Pointers
The Storage Module must be disconnected from power for
10 seconds or more to be certain it places a File Mark in
the Storage Module when reconnected.
A File Mark can be placed in the data by using SMS, the *9 Mode command 3
(not in 21X or CR7) or from a special P96 command in the datalogger
program.
The Storage Module will not store contiguous file marks. If a File Mark is the
last thing stored in memory, a second File Mark will not be stored.
The Storage Module has several internal pointers which are used to keep track
of data for both storage and retrieval operations.
The Display Location Pointer (DLP) is used to display Storage Module data.
Ordinarily, when the Storage Module is connected to a datalogger, the DLP
will be at the beginning of the curren t file. The DLP can be positioned
anywhere within the data, using the nnnnnnG command (see Appendix B).
Data can then be ‘dumped’ to the user device using one of the appropriate
commands (nnnnC, nnnnD or nnnnF). The dump will begin at the DLP and
continue until it reaches the Storage Reference Pointer (SRP) or until the
next File Mark.
The Storage Reference Pointer (SRP), indicates the next location to be
written to in the Storage Module. It will always be at the end of data in the
Storage Module.
4-1
Section 4. Storage Module Memory: Details of Data Storage
The Dump Pointer is an internal Storage Module pointer used for keeping
track of the current start-of-dump for Storage Module-to Storage Module data
dumps and for the data retrieval options of the SMS program. The user can
move the Dump Pointer with the 4H command (see Appendix B). The Dump
Pointer marks the end point of the previous data dump and thus the start-ofdump location for the next dump. Moving this pointer ‘loses’ this reference
point, which can cause problems with subsequent dumps.
4.3 Data Formats – Space Requirements
The modules store data in the format in which it is sent to them. There is no
conversion or encoding of the data received before it is stored.
Data can be sent to the module in either the Campbell Scientific Final Storage
Format (binary) or in th e Pr intable ASCII format. One low resolutio n data
point requires two bytes in binary format. Storing ASCII data requires 10
bytes per data point, therefore the binary option should be used whenever
possible.
Bytes from the Storage Module input buffer are permanently stored in bytepairs. The Campbell Scientific datalogger’s Final Storage Format data is
always grouped in pairs. Printable ASCII may have a single byte left in the
input buffer when the PE line drops. In this case, the byte will be stored with a
null character (ASCII code 0) as the second byte.
If a single byte remains in the input buffer when power is disconnected from
the Storage Module, it will be stored with a null character (ASCII Code 0) as
the second byte the next time external power is applied. A File Mark is stored
at power-up. If there is an added null character, it will be placed before a File
Mark.
4.4 Available Storage
The flash memory used within the modules is divided into 64 Kbytes blocks,
within the memory chips themselves. Flash memory must first be erased
before it is possible to overwrite oldest data. It is only possible to erase entire
blocks of memory, in this case, 64 Kbytes at a time.
If the memory is being used as Fill and Stop, this is of no consequence as the
memory will have been entirely erased before storing data. The module will
store data until every memory block has been filled.
However, when configured as Ring Memory, once the module has filled it
must erase the next block of memory before it can continue writing data
“around the ring.” Erasing a block takes approximately one second, requiring
the module to erase the 64 Kbyte block well in advance. The module initiates
the erase process 24,000 bytes before the end of the current block.
In the worst case the size of the erased section of the module will be 64 Kbytes
plus 24,000 bytes. Table 4-1 lists effective capacity for the SM4M and
SM16M configured as ring memory. The effective size of the memory can be
4-2
Section 4. Storage Module Memory: Details of Data Storage
calculated by taking the Storage Module size minus 4 bytes per block (used for
internal marking purposes), MINUS the worst case erased data size.
Table 4-1. Ring-Memory Effective Memory Capacity
Module Bytes Low-Res Data Values
SM4M 4104516 2052258
SM16M 16686660 8343330
The amount of storage available for fill and stop memory is 89524 bytes or
44762 low-resolution data values greater than the above (the last eight bytes of
memory cannot be written to).
The module will only store data up to the end of the last complete block of data
transmitted before the module becomes full. This means that if data is sent in
large blocks and the module becomes full just before receipt of the end of the
last block, then the effective capacity will be the above figures minus almost
the block size.
4.5 Bad Data
The Storage Module has mechanisms that detect corrupted data being received
from the datalogger. When bad data is received the module will immediately
stop storing the data. The datalogger will detect this and retransmit the entire
data from the last point that the Storage Module had confirmed receiving the
data.
This process does have some consequence for memory use. Data is stored as
received. With flash memory it is not possible to overwrite the previously
received data transmission without erasing a complete block of memory.
Instead a marker system is used which mar ks the previously written data as
bad. When the data is collected, the “bad” data is skipped so a continuous
stream of good data is output. However, the amount of good data that can be
stored in the module is reduced by the size of the bad data areas.
“Bad” data can also be stored if the module is unplugged while receiving data
from the datalogger or if the module resets due to an electrical transient
occurring while data is being stored.
In most cases “bad” data will be rare and the reduction in storage small. The
likelihood of significant loss of available storage increases if the length of data
transmissions to the module are long, and/or the module is unplugged
frequently without taking care to wait until the end of transmission.
The areas with “b ad” data are freed for normal storage again either when the
module is erased or when the area is erased prior to writing new data.
The only other instances when you might encounter “bad” data is:
• The start of dump pointer is manually positioned in the module, prior to
requesting data and that position is in the middle of an area of “bad” data.
4-3
Section 4. Storage Module Memory: Details of Data Storage
• A Storage Module in ring-mode has filled the memory, wrapped around
and erased the block containing the start of bad data marker or an area of
bad data which straddles flash blocks. The next block containing the
remainder of the bad data has not been erased.
In both cases the “bad” data will be collected as normal data and written to a
file. However, when the end of bad data marker is encountered it will be
treated as if it were a file mark and the data that f o llows will be written into a
new file. In such a case, you will find a small file usually containing some data
that is also written to the following file.
4-4
Section 5. Data Retrieval
Data retrieval is accomplished on PCs using SMS (part of the PC208W package). Other
computers require a software program which makes use of the Storage Module
telecommunications commands (Appendix B). This process requires both a hardware
interface and a software program.
5.1 Hardware
There are two interfaces which enable communication between a computer and
the Storage Module:
1. The SC532(A) Peripheral to RS232 Interface
2. The CR500/510, CR10/10X or CR23X with a suitable cable and interface
(not possible with other dataloggers)
The SC532(A) can function with any computer that has an RS232 port. A
software program is required to raise the DTR and RTS (pins 20 and 4,
respectively) to activate the Storage Module (Section 5.2). SMS performs this
function automatically.
9227
SN:
Logan, UT
SM4M
SOLID STATE STORAGE MODULE
MADE IN USA
a a
H
5
FIGURE 5-1. Storage Module Connected to a Portable PC via an SC532(A) Interface
5.1.1 SC532(A) Interface
A standard 25-pin ribbon cable (e.g., Campbell Scientific SC25) links the
SC532(A) to the computer’s 25-pin serial port. If the computer has a 9-pin
serial port, a 9-pin to 25-pin adaptor cable is required. For the SC532A you
will need a standard 9-pin (or 25-pin, depending on your PC) to 9-pin data
cable for linking PC to interface. The SC12 9-pin ribbon cable links the
Storage Module to the SC532(A) (see Figure 5-1).
The SC532(A) requires 12 VDC (nominal) which is usually provided by
plugging the AC adapter into a standard 120 VAC outlet. The use of battery
power is possible and is described in the SC532(A) manual. The SC532A also
5-1
Section 5. Data Retrieval
5.1.2 Via Datalogger
ships with AC adapter but, in addition, offers the option of a remote power /
field cable (item number 14020) to facilitate connection to datalogger power
for the SC532A and the Storage Module where 120 VAC is not available.
The Storage Module is linked to the CR500/510, CR10/10X or CR23X by the
SC12 cable. The computer connection is via an SC32A (Figure 5-2), SC929 or
SC532(A)/RAD modem interface. For this configuration with the CR23X,
connect all devices to the 9 pin CS I/O port. Select the “Via Datalogger”
option in SMS and select the appropriate datalogger and baud rate.
Please note that communication in th is mode is limited to a maximum speed of
9600 baud (19200 on the CR23X), which can make the transfer of large
volumes of data a lengthy process, compared to direct connection to a PC
where baud rates up to 115200 are supported.
The SC32A internal SDM blocking jumper should be in place. Without the
jumper in place (and sometimes with the SC929/RAD), Windows may report a
“framing error” after corr ectly collecting data with SMS.
PC
Data-
logger
SM4M/16M
FIGURE 5-2. Communication Via the CR500/510, CR10/10X or CR23X
Communication between a PC and Storage Module can also take place via the
CR23X when the computer RS232 is connected to the CR23X RS232 and the
Storage Module is connected to the CS I/O port (Figure 5-3). This
configuration allows baud rates of 19200 and 38400.
CR23X
PC
9-Pin
RS232
Cable
SM4M/16M
SC12
CS I/O
9-Pin
Cable
5-2
FIGURE 5-3. Communication Via the CR23X
5.1.3 Via Remote Datalogger and Modem
The data can be collected from a module, connected to one of the above
dataloggers, via other telecommunication interfaces (e.g., phone lines). Please
refer to the PC208W manual for further details.
Standard Phone
Modem
Cable
Lines
Section 5. Data Retrieval
SC12
9-pin Cable
Computer
Running PC208W
FIGURE 5-4. Typical Setup for Remote Collection of Data Via Datalogger and Modem
5.2 SMS
Hayes Compatible
Modem
COM200E
Modem
Surge
Protector
SM4M/
16M
CR10X
Datalogger
SMS (part of the PC208W software package) is a Windows-based program
which provides a simple and efficient way of communicating with the
SM4M/SM16M, as well as Campbell Scientific’s Card Storage Module
(CSM1), Card Reader (MCR1) and PC (PCMCIA) Cards. SMS normally
requires the SC532(A) interface as shown in Figure 5-1 for direct connection.
For communication via the CR500/510, CR10/10X or CR23X the setup shown
in Figure 5-2 is required. The CR23X can also be used without an SC32A
(Figure 5-3). SMS also has a terminal emulator for manual execution of
telecommunication commands. Refer to the PC208W manual for more details.
For the most rapid data transfer, use a PC capable of supporting data transfer at
115,200 baud in a Windows environment. This will normally require that the
serial ports of the PC are fitted with bu f f e r ed UARTs, which is the case for
most modern machines. Within SMS you should set the baud rate at 115,200.
5.3 Data Retrieval
5.3.1 Direct Connection
Connect the Storage Module to the PC via SC532(A) as in Figure 5-1. Run
SMS and select the Data tab to collect data. Alternately use a terminal
emulator (the program or terminal emulator must raise DTR and RTS). Send
carriage returns until CR, LF, % is return ed. Once the % is returned the
Storage Module is ready to accept telecommunications commands (see
Appendix B).
5-3
Section 5. Data Retrieval
5.3.2 Connection Via CR500/510, CR10/10X or CR23X
Make the connections (see Figure 5-2 or 5-3) and establish communications
with the datalogger. Send the command ‘xM,CR’ to the datalogger (where x is
the Storage Module address 1...8). If the connections are correctly made and
the Storage Module is properly addressed, it will send back ‘CR, LF, %.’ If the
attempt to establish communications fails, the datalogger will return ‘*’.
Once the ‘%’ is received, the Storage Module telecommunications commands
(see Appendix B) may be used. SMS can be used when the connection to the
datalogger is through the SC32A Optically Isolated RS232 Interface as shown
in Figure 5-3.
5-4
Section 6. Storing and Retrieving Datalogger Programs
CR500/510, CR10/10X, CR23X, 21X and CR7 programs can be uploaded and downloaded
between the datalogger and the Storage Module in the *D Mode. (OSX and OS7 series
PROMs required for 21X and CR7.) Campbell Scientific’s SMS software allows programs
to be transferred between the computer and the Storage Module. Using these capabilities,
a program can be developed in the computer, stored in the Storage Module, then carried
to the field and downloaded to the datalogger.
The Storage Module can store up to eight programs, numbered 1 to 8. These are stored in
an area of memory separate from that used for data storage.
With the release of the OS series PROMs (OS10, OSX, OS7), the dataloggers were given
the capability of automatically loading program 8 when the Storage Module is connected
to the datalogger at power-up. This feature is standard in the CR500/510, CR10/10X and
CR23X dataloggers. The program should be stored in program number eight in the
module with address one.
21X and CR7 PROMs before the current OSX and OS7 versions do not have the capability
to store and directly load programs from the Storage Module. Programs can be
transferred via the DSP4 Heads Up Display (see Section 6.3).
6.1 SMS Storage Module Support Software
Select the Program tab in SMS. See the PC208W manual for more
information.
6.2 *D Mode — With Datalogger
The *D Mode is used to transfer programs between the datalogger and Storage
Module. The general commands in Table 6-1 are used to save, retrieve or clear
programs from the Storage Module. See the appropriate datalogger manual for
instructions on using the *D Mode.
TABLE 6-1. *D Mode Keyboard Commands
Key Display Description
*D 13:00 Enter *D Mode
7XA 7X:00 Address Storage Module X
1YA Store Program in Storage Module as Y (Y=1..8)
2YA Load Program Y from Storage Module
3YA Erase Program Y from Storage Module
13:0000 command completed
6-1
Section 6. Storing and Retrieving Datalogger Programs
The program is stored, retrieved, or erased by referring to a program number
(1...8) in the Storage Module. If the program to be retrieved does not exist in
the Storage Module, the error message ‘E99’ will be displayed.
There are 128 kbytes of memory available for program storage. For example,
you can store one 128 kbyte DLD file or eight 16kbyte files. Flash memory
technology affects the use of memory when storing and erasing programs.
When a program is “erased” , the space it occupied is not freed until the entire
program storage area is erased. Thus when you erase a program the amount of
free space in the Storage Module program area does not increase. However,
you can reuse the program number to store another program.
The program storage area can be erased either by issuing one of the module
erase/reformat/test commands or by manually deleting each of the programs in
the module. In the latter case, after the last program is erased the module will
proceed to erase and “tidy-up” the program storage area.
NOTE
The 21X or CR7 must have only one Storage Module connected
when storing and retrieving programs.
6.3 Using DSP4 Heads Up Display to Store and Retrieve Datalogger Programs
In addition to real-time monitoring of datalogger measurements, the DSP4
Heads Up Display can be used with the CR10/10X, CR23X, 21X (including
pre-OSX versions with Extended Software) and the CR7 dataloggers to store
and retrieve data and programs. The DSP4 Load and Save program commands
allow loading and saving CR10/10X, CR23X, 21X, and CR7 datalogger
programs from/to the Storage Module.
The DSP4 Flag buttons 1...8 execute the Load or Save command using the
Storage Module as the medium. Up to eight datalogger programs can be saved
in the Storage Module. The program to be saved or loaded is selected by
pressing the appropriate push button switch. Refer to the DSP4 Instruction
Manual for more details.
6-2
Appendix A. *9 Mode — Storage
Module Commands
The *9 Mode is used to issue commands to the storage module using the
Keyboard/Display or a terminal/computer with all dataloggers except the 21X
and CR7. These ‘commands’ are analogous in many respects to the datalogger
functional (*) Modes.
The key sequences for the *9 Mode commands have a generalized format.
Using command 1 as an example:
Key Display Explanation
*9 09:01 Enter *9 Mode
X 09:X Key in the address (x=1 to 8) of the SM to be given the
command.
A 9X:00 Enter the SM address, x; ready to accept a command.
1 9X:1 Key in command 1. Reset SM.
A 01:0000 Enter command 1. Ready for instruction to effect
command 1.
248 01:248 Key in 248 to effect command 1.
A 01: Execute SM Reset.
The module then executes the equivalent of the 1249K telecommunications
command (Appendix B, note this is not a full 1248K reset as some older
modules perform in response to this command which would take too long for
field use). After about one minute with the SM4M, or three minutes with the
SM16M, the number of megabytes of available data storage is displayed:
01:04 4 for an SM4M
01:16 16 for an SM16M
Most commands have at least one response. Advance through the responses
and return to 9X:00 (ready to accept another *9 command) by keying ‘A’.
Exit the *9 Mode by keying ‘*’ and the character of the mode you want to
switch to (e.g., ‘*0’ to go to the log mode).
A-1
Appendix A. *9 Mode—Storage Module Commands
TABLE A-1. *9 Mode Commands for Storage Module
Command Display Description
1 01:0000 RESET: enter 248 to erase all data and
01:XX The number of megabytes of data storage
3 03:01 INSERT FILE MARK at the position of
4 04:XX DISPLAY/SET MEMORY
5 DISPLAY STATUS (A to advance to each window):
01:ABCD Window 1:
AB Not used
CD Total number of megabytes
02:ABCD Window 2:
ABC Not used
D No. of Programs stored (Max=8)
03:ABCD Window 3:
A Errors logged (up to 9)
B Not Used
C Memory Config. (0=ring, 1=f ill & stop)
D Memory Status (0=not full, 1=full)
04:XXXXX OS signature (0 if bad OS)
6 06:00 Not used
7 07:00 Not used
8 08:00 Not used
9 DISPLAY ADDRESSES OF CONNECTED STORAGE
MODULES:
XXXXXXXX 1 = occupied, 0 = unoccupied
87654321 (Addresses 8-1 from left to right)
10 CHANGE ADDRESS
10:0X X is current address, enter yA to change
programs and reset pointers. While
erasing, the SM does a simple check of the
memory. The time required to reset an
SM4M is approximately 1 minute;
SM16M takes nearly 3 minutes.
(4 for SM4M, 16 for SM16M).
the SRP if a file mark wasn’t the last thing
placed in the data. 1 indicates that the
mark was inserted, 0 indicates that it was
not.
CONFIGURATION: enter the appropriate
code to change configuration 0=ring,
1=fill and stop.
and then display address where y=1...8.
A-2
Appendix B. Telecommunications Commands
The Storage Module telecommunications commands can be issued to an
Storage Module either via a direct SC532(A) connection to the Storage Module
or via a remote connection where the Storage Module is connected to a
datalogger.
Establishing communication between the Storage Module and a
computer/terminal is discussed in Section 5. The commands permit data
storage and retrieval, switch setting, status checks and other functions.
If you are making connections through a datalogger, make the connections
(Figure 5-4) and establish communications with the datalogger. Send the
command ‘XM,CR’ to the datalogger (where X is the Storage Module address
1...8). If the connections are correctly made and the Storage Module is
properly addressed, it will send back ‘CR, LF, %.’ If the attempt to establish
communications fails, the datalogger will return ‘*’.
The Storage Module is ready for a command when it sends its prompt,
‘<CR><LF> %’. The successful execution of a command is also indicated by
the Storage Module returning a ‘<CR><LF> %’. If just a ‘%’ is returned, the
command was in error. ‘
responses to commands. ‘
’ (XOFF) temporarily halts Storage Module
CTRL-S
’ aborts the response.
CTRL-C
A
Status
The descriptions of some commands refer to the Storage Module pointers (see
Section 4). The Display Location Pointer (DLP) is used to display Storage
Module data. The Storage Reference Pointer (SRP) indicates the next
location to be written to in the Storage Module. The Dump Pointer is an
internal Storage Module pointer used for keeping track of the current start-ofdump for Storage Module-to-Storage Module data dumps and for the data
retrieval options of the SMS program.
Storage Module telecommunications commands are similar to datalogger
telecommunications commands and consist of numbers and CAPITAL letters.
In the following list telecommunication s co m m a n ds are on the left and their
descriptions on the right.
Returns Version number, Switch settings, number of Programs stored, number
of good Data Memory blocks, number of Errors logged (max. = 255), number
of Available storage locations, number of locations Full, Storage Reference
Pointer, Display Location Pointer , Dump Pointer and Checksum (sum of all
transmitted ASCII characters since last %; wraps around at 8192 bytes).
The number of Errors logged is a count of bad characters received from the
datalogger and/or the number of times the module has reset itself as a result of
some unknown cause. Contact Campbell Scientific for advice if this counter
increments regularly. Unlike previous modules this counter does not increment
if corrupted characters are received in telecommunications mode.
Example: V1 S1400 P0 M64 E0 A2052258 F1 R2 L2 D2 C2226 is the
expected response to the A command after an SM4M has been reset.
B-1
Appendix B. Telecommunications Commands
NOTE: In Ring mode, when data storage has gone around the memory more
than once the Number of Locations Full will fluctu ate. This is because memory
is erased in 64 Kbyte blocks but filled an arr ay at a time (see Section 4).
AA
Advanced Status
nnnnB
nnnnC
Comma Delineated
ASCII Dump
NOTE
Refer to the L command for a discussion of the switch settings.
Example: B65536 T4194304 U131068 P131072 A00000000 F2097019 W00
C3060 is the expected response to the AA command after a SM4M has been
reset.
Data Flash Block size in bytes, Total Data Flash in bytes, Largest Unused
program space in bytes, Total Program storage area in bytes, Active programs
stored (A10005008 means programs 1,5 and 8 are stored), F Number of
locations left until oldest data will be ov erwritten, Wrap status flag (00 = not
wrapped around, 01 = block of oldest data has been erased (see Section 4.4), 11
= data wrapped around ring memory, and Checksum (sum of all transmitted
ASCII characters since last %; wraps around at 8192 bytes).
Example: B65536 T4194304 U131068 P131072 A00000000 F2097019 W00
C2379 is the expected response to the AA command after an SM4M has been
reset.
Move the DLP back nnnn output arrays from its current position. If it is fewer
arrays to the beginning of the file (File Mark), the DLP will be p laced at the
beginning of the file. B gives the same result as 1B. Status is displayed
following execution of command. This command may take some time to
complete.
Dump nnnn output arrays from the location of the DLP. The dump stops if the
next file mark or the Storage Reference Pointer is reached. ‘C’ gives the same
result as ‘1C’. ‘0C’ means dump continuously. Status is displayed following
execution of command.
nnnnF
Binary Dump
nnnnnnG
Go To Location nnnnnn
OD
Go To the Oldest Data
01G
Go To Last File
08G
Go To Dump Pointer
B-2
Dump nnnn locations (two bytes each) until the next File Mark from the
location of the DLP. The dump stops if the Storage Reference Pointer is
reached, followed by two bytes displaying the signature of the transmitted data.
No data conversion is made. ‘F’ gives the same result as ‘1F’. ‘0F’ means
dump continuously. The status is not displayed following command execution.
Use this command to position th e Display Location Pointer to any location in
the Storage Module. The Status is then displayed.
The Display Location Pointer (DLP) is moved to the start of the oldest data in
the module. (Note: Command is ‘letter O’, NOT ‘zero’ D).
This command causes the Display Location Pointer (DLP) to move to the
beginning of the current file. The status is then displayed.
The Display Location Pointer (DLP) is advanced to the Dump Pointer position.
The Dump Pointer is set to the beginning of memory when the Storage Module
is reset. It is advanced only by the CR10/10X (*9) Storage Module-to-Storage
Module Dump command, the ‘4H’ command, and by SMS.
Appendix B. Telecommunications Commands
09G
Go To Next File
09GG
Go To Next File with
Progress Indicator
0H
Store
4H
Move Dump Pointer To
Display Location
Pointer
9H
Store File Mark in Data
The Display Location Pointer (DLP) is advanced to the beginning of the next
file. The DLP is advanced as the Storage Module reads through the data until a
File Mark or the Storage Reference Pointer is encountered. For long files, the
delay involved could be noticeable. The status is displayed following
command execution. This command can be used to locate every file in the
Storage Module.
Like 09G but this command outputs the value of the DLP every second as it
moves through memory, as the module searches for the next file mark.
The Storage Module will store all data received on the Transmit Data (TD) line
until the Storage Module is deactivated when the PE (Pin 6) and CLK/HS (Pin
7) lines go low. External power must remain applied for at least 5 ms
following deactivating PE and CLK/HS for ‘housekeeping.’ The Storage
Module stores two bytes at a time. If the total number of bytes transmitted is
an odd number, a NULL character will be added at the end of the transmission.
This command is not available in telecommu nications via CR500/CR510,
CR10/10X or CR23X.
The Dump Pointer is moved to the current position of the Display Location
Pointer. Refer to command ‘08G’ regarding the Dump Pointer . Th is command
is not intended for general use.
Used to designate a new area of memory in the Storage Module. File Marks
are automatically placed in data at power-up (upon connection to datalogger or
retrieval interface), or when a CR500/510, CR10/10X, or CR23X compiles a
program containing Instruction 96. A File Mark can also be inserted under
program control. Status is displayed following command execution.
nl
Dump Program n
(n = 1…8)
nJ
Store Program n
(n = 1…8)
nJJ
Store Program n, with
Checksum Signature
n0nJ
Clear Program n
(n = 1…8)
If program ‘n’ is found, the Storage Module dumps it to the user device,
otherwise it sends a null program (30 05 05 HEX) followed by a prompt
without a carriage return and line feed.
The Storage Module responds with ‘<’ after which the Storage Module stores
program data received on its TD line, recordin g its start position in the program
directory. Subsequent data does not write over stored datalogger programs
unless the directory entry is cleared or modified. Programs must start with the
(05 05 HEX)
Start ASCII character (7D HEX) and end with two
CTRL-E
characters. Status is displayed following command execution. This command
is not available when communicating with the Storage Module using an RF
Modem.
Like the nJ command, but the module outputs a 2 byte CSI checksum signature
in response to the 05 05 HEX termination characters, which allows easy
validation that the program has been received correctly.
Clears directory entry for program ‘n’ and frees the memory space for data
storage – this only becomes available for further program storage if all
programs are deleted.
Example: To clear program 7, the command is 707J. Status is displayed
following command execution.
B-3
Appendix B. Telecommunications Commands
1243K
Reset Error Counter
1248K
Reset Storage Module
CAUTION
1249K
Quick Reset
This command resets the communications error counter (the number beginning
with ‘E’) to zero, then displays the status lin e. Neith er the programs nor the
data stored in the module are affected by this command.
Erases all data and programs, resets all pointers, fully tests memory and places
a File Mark at the beginning of memory. If a bad flash memory block is
encountered, the Storage Module will use only the good memory up to the bad
block. The number of good flash memory blocks is indicated in the Status.
During Reset, a plus (+) for each block written to, and a minus (-) for each
block successfully read is output by the Storage Module. An ‘X’ is output for
each RAM which cannot be read successfully. The status is displayed
following command execution. If the Storage Module returns a ‘%’ without a
‘<cr><lf>,’ the memory test failed.
ALL DATA IS LOST WHEN THE STORAG E MODULE IS
RESET. Be sure to collect data before resetting the
Storage Module.
This command is similar to the 1248K command — it also erases all data and
programs. However, it does not do a complete memory test, it simply resets the
memory pointers and instructs the flash memory to erase itself. This is much
faster than the 1248K command and is designed for routine erasure of the
module. If the module has been corrupted, use the 1248K command instead.
A module with damaged memory requires a full memory test to determine how
much usable memory remains. The switches are not changed to their default
settings.
abfeL
Switch Settings
M or *
Disconnect
N
OS Signature
‘a’ is the Storage Module Address Switch. When used with a CR500/510,
CR10/10X or CR23X, this switch can be set to 1...8. The address has no effect
when used with other Campbell Scientific dataloggers. Following reset, the
Storage Module address defaults to 1.
‘b’ is the Baud Rate Switch – this is not currently used in the flash modules.
This switch always defaults to a value of 4, fo r compatibility with older
modules.
‘f’ is the Fill and Stop/Ring Memor y Status Switch. If set to ‘0,’ the memory
is ring type. If ‘1,’ the memory is set to Fill and Stop and once memory is full,
further efforts to write to the Storage Module are aborted. The memory status
switch defaults to ‘0’ (ring memory) following Storage Module Reset.
‘e’ is the Encode ASCII Switch. This switch is not currently supported in the
flash module, it defaults to a value of zero indicating data is stored without any
encoding.
Entering 9 for switch settings leaves the switch setting unchanged. Example:
9990L would only disable the Encode ASCII function. Since position is
important, the 9’s are used to fill the first 3 spaces without changing the
settings.
The Storage Module is deactivated to a low power standby mode. If the
communications interface is (via) the CR500/510, CR10/10X, CR23X the
datalogger “*” prompt will be returned.
Returns the Storage Module operating system signature. If this command
returns ‘0,’ the operating system is bad.
B-4
Appendix C. Storage Module 9-Pin Connector
The pins on the 9-pin sub-miniature D connector on the Storage Module are
numbered 1 to 9. A general description of the function of each pin follows:
Pin 1 (Input) 5 VDC Supply provides power to the Storage Module.
5± 0.3 VDC @ 100mA. Processor held in reset when external power
falls below 4 VDC. Damage to Storage Module hardware can occur if
input on Pin 1 exceeds 5.5 VDC. Low power standby mode current
drain is less than 200µA.
Pin 2 (Input) Power and signal GROUND.
Pin 3 RING LINE. Not used.
Pin 4 (Output) RECEIVE DATA (RD) line. The Storage Module transmits
its responses to Telecommunications commands asynchronously (0 to 5
VDC) on this line. Data format is 8-bit, 1 start bit and 1 stop bit. Refer
to Section 3.1 for baud rate options. This line is held high while the
Storage Module is active in the Printer Enable Method (data storage).
Pin 5 MODEM ENABLE line. Not used.
Pin 6 (Input) PRINTER ENABLE (PE) in Printer Enable Method or
SYNCHRONOUS DEVICE ENABLE (SDE) line in SDC Method. If
the Storage Module is externally powered, the PE line is high (5 VDC)
and Pin 7 (CLK/HS) is low (0 VDC), the processor is set to receive data
asynchronously on Pin 9 (TD). When the PE line is dropped, data
remaining in the input buffer are stored and the location pointers are
saved. The processor then enters an inactive, low power, standby state.
If the processor is still active from a previous transmission of data and
the PE line is raised again, the data from the current transmission will
be ignored. Normal operation will return with the next low to high PE
transition. Switch bounce on the PE line can cause the processor to go
inactive after the PE line stabilizes in its high state.
Pin 7 (Input) CLOCK/HANDSHAKE (CLK/HS) line. For data storage,
CLK/HS must be low. For data retrieval using Telecommunications
Commands (see Appendix B) CLK/HS must be high when the
processor is activated by the PE line going high. CLK/HS must remain
high during Telecommunications. To exit the Telecommunications
Command State, lower both the PE and CLK/HS lines.
Pin 8 TAPE ENABLE / 12V power line. Not used.
Pin 9 (Input) TRANSMIT DATA (TD) Data is received by the Storage
Module on this line. Data is received asynchronously ( 0 to 5 VDC) 8-
bit, 1 start and 1 stop bit. The idle state ( sto p bits) on this line is 0
VDC. The first byte transmitted to the Storage Module should be more
than 200µs after the PE line has activated the processor.
C-1
This is a blank page.
Appendix D. Upgrading the Operating System
The Storage Module operating system is stored in flash memory. (It is NOT
deleted when the Storage Module is reset.) The operating system can be
upgraded using Campbell Scientific’s CSOS download utility. If you need to
upgrade the module operating system, please contact Campbell Scientific for a
copy of this utility compatible with the SM4M and SM16M.
CAUTION
NOTE
Collect any data stored in the module before upgrading the
operating system. Any data held in memory is irreversibly
erased during the upgrade process.
To load the operating system you will need to connect the module to a PC
running Windows, via an SC532(A) interface. Please follow the instructions
supplied with CSOS.
Do not attempt to load any operating system other than that designed for these
Storage Modules. Do not disconnect the power supply to the module during
the upgrade process, otherwise the module memory may be corrupted
requiring a factory repair.
When CSOS indicates that the download is complete, wait un til
the green Write LED on the Storage Module goes out before
disconnecting power or using the Storage Module. The green
LED remains on until the Storage Module completes the OS
upgrade.
D-1
This is a blank page.
Appendix E. SC532A
The SC532A differs from the SC532 in three ways:
1. Provides 12 V on PERIPHERAL Port pin 8
2. “PROGRAM” mode
3. Jack on SC532A POWER input
The SC532A supplies 12 VDC via PERIPHERAL connector pin 8 for the
purpose of powering 12 V peripherals.
The SC532A’s internal jumper selects “SC532” or “PROG” mode. For the
SM4M/SM16M leave the jumper in the factory default position of “SC532.”
“PROG” is a special mode for satellite transmitters only.
The SC532A has a POWER jack allowing convenient replacement in the event
of AC adapter failure (see CAUTION below). The jack also facilitates
operating the SC532A from datalogger power at remote sites by using optional
field cable (item number 14020) in place of the AC adapter. Simply plug the
cable’s DB9 connector into the datalogger’s CS I/O port for 12 V power. If
you have an earlier datalogger lacking 12 V on CS I/O port pin 8 (DVM test
between paper-clip inserted in pin 8 and GND) the field cable can be modified
to connect to the datalogger’s power terminals as f ollows:
1. Unplug field cable from datalogger and SC532A.
2. Cut off DB9 connector.
3. Remove cable sheath exposing positive (RED) wire and negative
(BLACK) wire 2 inches back.
4. Strip ¼ inch of insulation from each wire and tin ends.
5. Connect RED wire to datalogger “12 V” and BLACK wire to datalogger
power ground terminal. The correct barrel connector polarity is (+) on the
inner bore and (−) on the outer sleeve.
CAUTION
The SM4M/SM16M requires that a minimum of 6 VDC @ 100 mA be
supplied to the SC532A POWER jack from AC adapter or field cable. The
maximum voltage that can be safely applied to the SC532A POWER jack is 17
VDC.
Before plugging the power connector into the SC532A, if
you have 1) cut off op tional field cable’s DB9, 2) r eplaced
the factory AC adapter, or 3) built your own dc power
cable, make sure th at the voltage polar ity is correct on the
barrel connector. Application of REVERSED POLARITY
power to the SC532A can damage the SC532A,
datalogger, and peripheral (not covered under warranty)!
Barrel connector inner bore (+)
Barrel connector outer sleeve (−)
The maximum POWER input voltage is 17 VDC!
E-1
This is a blank page.
This is a bla nk page.
Campbell Scientific Companies
Campbell Scientific, Inc. (CSI)
815 West 1800 North
Logan, Utah 84321
UNITED STATES
www.campbellsci.com
info@campbellsci.com
Campbell Scientific Africa Pty. Ltd. (CSAf)
PO Box 2450
Somerset West 7129
SOUTH AFRICA
www.csafrica.co.za
sales@csafrica.co.za
Campbell Scientific Australia Pty. Ltd. (CSA)
PO Box 444
Thuringo wa Cent ra l
QLD 4812 AUSTRALIA
www.campbellsci.com.au
info@campbellsci.com.au
Campbell Scientific do Brazil Ltda . (CSB)
Rua Luisa Crapsi Orsi, 15 Butantã
CEP: 005543-000 São Paulo SP BRAZIL
www.campbellsci.com.br
suporte@campbellsci.com.br
Campbell Scientific Canada Corp. (CSC)
11564 - 149th Street NW
Edmonton, Alberta T5M 1W7
CANADA
www.campbellsci.ca
dataloggers@campbellsci.ca
Campbell Scientific Ltd. (CSL)
Campbell Park
80 Hathern Road
Shepshed, Loughborough LE12 9GX
UNITED KINGDOM
www.campbellsci.co.uk
sales@campbellsci.co.uk
Campbell Scientific Ltd. (France)
Miniparc du Verger - Bat. H
1, rue de Terre Neuve - Les Ulis
91967 COURTABOEUF CEDEX
FRANCE
www.campbellsci.fr
campbell.scientific@wanadoo.fr
Campbell Scientific Spain, S. L.
Psg. Font 14, local 8
08013 Barcelona
SPAIN
www.campbellsci.es
info@campbellsci.es
Please visit www.campbellsci.com to obtain contact information for your local US or International representative.
Loading...
