Campbell Scientific SDM-AO4A User Manual

SDM-AO4A Four Channel

Analog Output Module

5/11

Copyright © 1986-2011

Campbell Scientific, Inc.

Warranty and Assistance

PRODUCTS MANUFACTURED BY CAMPBELL SCIENTIFIC, INC. are
warranted by Campbell Scientific, Inc. (“Campbell”) to be free from defects in
materials and workmanship under normal use and service for twelve (12) months

from date of shipment unless otherwise specified on the corresponding Campbell
invoice. Batteries, fine-wire thermocouples, desiccant, and other consumables have
no warranty. Campbell's obligation under this warranty is limited to repairing or
replacing (at Campbell's option) defective products, which shall be the sole and
exclusive remedy under this warranty. The customer shall assume all costs of
removing, reinstalling, and shipping defective products to Campbell. Campbell
will return such products by surface carrier prepaid within the continental United
States of America. To all other locations, Campbell will return such products best
way CIP (Port of Entry) INCOTERM
apply to any Campbell products which have been subjected to modification,
misuse, neglect, improper service, accidents of nature, or shipping damage. This
warranty is in lieu of all other warranties, expressed or implied. The warranty for
installation services performed by Campbell such as programming to customer
specifications, electrical connections to products manufactured by Campbell, and
product specific training, is part of Campbell’s product warranty. CAMPBELL
EXPRESSLY DISCLAIMS AND EXCLUDES ANY IMPLIED WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
Campbell is not liable for any special, indirect, incidental, and/or consequential
damages.

Products may not be returned without prior authorization. The following contact
information is for US and International customers residing in countries served by
Campbell Scientific, Inc. directly. Affiliate companies handle repairs for customers
within their territories. Please visit www.campbellsci.com to determine which
Campbell Scientific company serves your country.

®

2010, prepaid. This warranty shall not

To obtain a Returned Materials Authorization (RMA), contact Campbell Scientific,
Inc., phone [phone]. After an applications engineer determines the nature
of the problem, an RMA number will be issued. Please write this number clearly
on the outside of the shipping container. Campbell Scientific's shipping address is:

CAMPBELL SCIENTIFIC, INC.

RMA#_____
815 West 1800 North
Logan, Utah 84321-1784

For all returns, the customer must fill out a “Declaration of Hazardous Material and
Decontamination” form and comply with the requirements specified in it. The form
is available from our website at
must be either emailed to [e-mail]
Campbell Scientific will not process any returns until we receive this form. If the
form is not received within three days of product receipt or is incomplete, the
product will be returned to the customer at the customer’s expense. Campbell
Scientific reserves the right to refuse service on products that were exposed to
contaminants that may cause health or safety concerns for our employees.

www.campbellsci.com/repair

or faxed to 435-750-9579.

. A completed form

SDM-AO4A Table of Contents

PDF viewers note: These page numbers refer to the printed version of this document. Use
the Adobe Acrobat® bookmarks tab for links to specific sections.

1. Function........................................................................1

2. Specifications ..............................................................1

3. Power Supply ............................................................... 2

4. Physical Connections .................................................2

5. Addressing ...................................................................4

6. Operational Modes ......................................................4

7. Programming ...............................................................6

7.1 CRBasic ....................................................................................................7

7.1.1 SDMAO4A Instruction...................................................................7

7.1.2 SDMSpeed Instruction....................................................................8

7.2 Edlog.........................................................................................................9

7.3 Programming Examples..........................................................................10

7.3.1 CR5000 Program Example ...........................................................10

7.3.2 CR10X Program Example ............................................................11

List of Figures

1. Front Panel of the SDM-AO4A..................................................................3

2. Synchronous Mode.....................................................................................5

3. Sequential Mode .........................................................................................6

List of Tables

1. Description of Terminal Block Connections ..............................................3

2. SDM-AO4A Addressing ............................................................................4

3. Bit Period Values........................................................................................8

4. Description of Instruction 103..................................................................10

i

SDM-AO4A Four Channel Analog Output

1. Function

The SDM-AO4A is designed to output four continuous voltages at levels set
by a Campbell Scientific datalogger.

The SDM-AO4A is a replacement for the SDM-AO4. However, the SDM­AO4A offers several new features including a 0-10 V Mode, a choice of
synchronous or sequential operation, and SDM signature checking. In
addition, the SDM-AO4A has higher resolution, improved accuracy, and high
drive current for sensor excitation.

2. Specifications

Vsupply

Iq (no load, Vout = 0, Vsupply = 12 V)

Iq (no load, Vout = Fullscale, Vsupply = 12 V)

Iq (w/ load, Vsupply = 12 V)

Iq (power down mode, Vsupply = 12 V)

Range

Resolution

Accuracy @ 25°C (20 kOhm load)

Accuracy @ -40° to 60°C (20 kOhm load)

Additional Fullscale Error w/ 50 mA load

Max Iout per Channel

Max Iout Total

Overcurrent shutdown point

± 5 V mode 10 V mode

12 V Nominal (9.6 to 16 V)

11 mA typical 21 mA typical

13 mA typical 28 mA typical

13 mA + load typical 28 mA + 2.4*load typical

1.1 mA typical

± 5 V 0-10 V

167 µV

± (0.05% of |Vout(V)| + 500 µV) max

± (0.1% of |Vout(V)| + 500 µV) max

-1.3 mV typical -1.5 mV typical

50 mA

100 mA

130 ± 15 mA

Size

Weight

Operating Temperature Range

5.3" x 3.35" x 0.95" (13.46 x 8.51 x 2.41 cm)

6.2 oz (175 grams)

-40° to +60°C

1

SDM-AO4A Four Channel Analog Output

3. Power Supply

It is often convenient to power the SDM-AO4A from the datalogger power
supply, but when doing so consideration must be given to the SDM-AO4A's
continuous current drain (the current drain is 11 mA in ±5V mode and 21 mA
in 10V mode). The alkaline supply available with the datalogger has 7.5 Amp­hours and will power one SDM-AO4A for less than one month. This supply is
not recommended for continuous long-term operation. The rechargeable lead
acid option, float charged by an AC supply or solar panel, may be used for
long term operation.

The SDM-AO4A may also be powered from an external 12 Volt supply,
independent from the datalogger supply. The low side of an external 12 Volt
supply should be connected to datalogger ground and not directly earth
grounded.

Slight alterations in ground potential across a 21X terminal strip are created
when the 21X 12 Volt supply is used to power peripherals. Therefore, low
level voltage measurements (e.g., thermocouples, thermopiles, and
radiometers) should be made differentially when powering the SDM-AO4A
with a 21X 12 Volt output.

4. Physical Connections

Figure 1 shows the front panel of the SDM-AO4A. The terminal block on the
left is used for connection to the datalogger and the terminal block on the right
provides the continuous analog output. The two ground ports on the left block
are identical and connected internally.

Table 1 describes the terminal block connections. Multiple SDM-AO4As may
be used by connecting the datalogger side of one SDM-AO4A to the next.

The CABLE5CBL-L or similar cable is used to connect the module to the
datalogger. A 1-ft cable length should be sufficient when both datalogger and
module are housed within an ENC12/14 enclosure; a 2-ft length may be
required if the datalogger and SDM-AO4A are housed at opposite ends of an
ENC16/18 enclosure.

CRBasic dataloggers should use the SDMSpeed instruction if the cable length
is longer than 20 feet (see Section 7.1.2). The maximum recommended cable
length for the CR7 is 600 ft. For other Edlog dataloggers, the maximum
recommended cable length is 20 feet.

CAUTION

Cables connecting the terminals of the datalogger and
SDM device should be as short as possible to minimize the
risk of corruption of the signal and damage from induced
surges.

When first powered up, the device is in low-power mode until the first valid
SDM instruction is received. In this mode, outputs are pulled to GND.

2

CAUTION

The order of connections is critical. ALWAYS CONNECT
GROUND FIRST, followed by 12V and then the Control
Ports.

Shielded twisted pair cabling is recommended for wiring the continuous analog
outputs.
