Campbell Scientific CSBUOY-NS User Manual

CSBUOY-NS

Revision: 11/08

Copyright © 2002-2008

Campbell Scientific, Inc.

Warranty and Assistance

The CSBUOY-NS is warranted by CAMPBELL SCIENTIFIC, INC. to be free
from defects in materials and workmanship under normal use and service for
twelve (12) months from date of shipment unless specified otherwise.
Batteries have no warranty. CAMPBELL SCIENTIFIC, INC.'s obligation
under this warranty is limited to repairing or replacing (at CAMPBELL
SCIENTIFIC, INC.'s option) defective products. The customer shall assume
all costs of removing, reinstalling, and shipping defective products to
CAMPBELL SCIENTIFIC, INC. CAMPBELL SCIENTIFIC, INC. will
return such products by surface carrier prepaid. This warranty shall not apply
to any CAMPBELL SCIENTIFIC, INC. products which have been subjected
to modification, misuse, neglect, accidents of nature, or shipping damage. This
warranty is in lieu of all other warranties, expressed or implied, including
warranties of merchantability or fitness for a particular purpose. CAMPBELL
SCIENTIFIC, INC. is not liable for special, indirect, incidental, or
consequential damages.

Products may not be returned without prior authorization. The following
contact information is for US and International customers residing in countries
served by Campbell Scientific, Inc. directly. Affiliate companies handle
repairs for customers within their territories. Please visit
www.campbellsci.com to determine which Campbell Scientific company
serves your country.

To obtain a Returned Materials Authorization (RMA), contact CAMPBELL
SCIENTIFIC, INC., phone [phone]. After an applications engineer
determines the nature of the problem, an RMA number will be issued. Please
write this number clearly on the outside of the shipping container.
CAMPBELL SCIENTIFIC's shipping address is:

CAMPBELL SCIENTIFIC, INC.

RMA#_____
815 West 1800 North
Logan, Utah 84321-1784

For all returns, the customer must fill out a “Declaration of Hazardous Material
and Decontamination” form and comply with the requirements specified in it.
The form is available from our website at
completed form must be either emailed to [e-mail]
to 435-750-9579. Campbell Scientific will not process any returns until we
receive this form. If the form is not received within three days of product
receipt or is incomplete, the product will be returned to the customer at the
customer’s expense. Campbell Scientific reserves the right to refuse service on
products that were exposed to contaminants that may cause health or safety
concerns for our employees.

www.campbellsci.com/repair

. A

or faxed

CAMPBELL SCIENTIFIC, INC. does not accept collect calls.

CSBUOY-NS Shipping List

Items packaged with the CSBUOY-NS for shipment include:

• CSBUOY-NS (See Figure 2-1)

• Solar panel with mounting brackets and cable

• Lid

• Instrument housing with antenna hole plug

• Float with two (2) eye-bolts

• Float plug unscrewed

• Instrument shroud

• Instrumentation mounting bracket

• CR206

• Antenna with cable

• 7 AH battery with cable

• Two (2) large desiccant packs

• Humidity card

• CSBUOY-NS manual

• CR206 manual/CD-ROM

This is a blank page.

Special Operating Notes

1. Check the shipping list in the front of the manual and make sure that all

the parts checked off the list are with the CSBUOY-NS. If any parts are
missing, please contact Campbell Scientific, Inc. [phone].

2. When connecting the battery avoid shorting the battery to the CR206.

3. Damage to the electronics will occur if moisture builds up inside the

CSBUOY-NS instrument housing.

4. The Heyco pressure fittings seal the cable entry points against water

intrusion. These fittings must be tightened periodically to ensure a tight
fit.

This is a blank page.

CSBUOY-NS Table of Contents

PDF viewers note: These page numbers refer to the printed version of this document. Use
the Adobe Acrobat® bookmarks tab for links to specific sections.

1. Introduction...............................................................1-1

1.1 Specifications........................................................................................ 1-1

2. CSBUOY-NS Description .........................................2-1

2.1 System Components .............................................................................2-1

2.2 Communication Options....................................................................... 2-1

2.2 Power Supply........................................................................................ 2-1

3. CSBUOY Installation ................................................3-1

3.1 Site Selection........................................................................................3-1

3.2 CSBUOY-NS Assembly....................................................................... 3-1

4. Communication.........................................................4-1

4.1 Direct Connection to PC....................................................................... 4-1

4.1.1 Device Configuration Utility Software Installation.................... 4-1

4.1.2 RF401 Connection...................................................................... 4-1

4.2 CSBUOY-NS as a Wireless Sensor...................................................... 4-1

5. Maintenance..............................................................5-1

5.1 Instrumentation Maintenance ............................................................... 5-1

5.1.1 Batteries ...................................................................................... 5-1

5.1.2 Desiccant..................................................................................... 5-1

5.1.3 Sensor Maintenance.................................................................... 5-1

i

This is a blank page.

Section 1. Introduction

The CSBUOY-NS is programmed to communicate directly with a personal
computer operating Device Configuration Utility software and/or as a wireless
sensor providing data for other Campbell Scientific dataloggers. A 5-watt
solar panel is used to trickle charge the battery.

1.1 Specifications

General

CSBUOY-NS Weight: 37 lbs

Environment: Freshwater and brackish ponds and small lakes;

quiet water marine (no wave or tidal activity)

Buoy

Material: Polyethylene

Dimensions: 47” (119 cm) height, 30” (76 cm) float diameter

Instrument Housing: 6.36” (16.15 cm) OD, 6” (15.24 cm) ID

Wireless Transmitter

Storage: 512 Kbytes Flash Final Storage; data format is 4

Radio Type: RF401, 916 MHz Spread Spectrum Transceiver

Average Continuous
Current Drain: 20 mA radio always on, 2.2 mA radio in 1 s duty

Antenna

Frequency: 900 Mhz

Distance: 5000 ft (1524 m) assuming line of sight

Gain: 0 dBd

Length: 3.25” (8.26 cm)

bytes per data point (table-based); 60 Kbytes Flash
(OS/program)

cycle, 0.6 mA radio in 8 s duty cycle

1-1

Section 1. Introduction

Solar Panel

Typical Peak Power: 5 W

Voltage @ Peak Power: 17.1 Vdc

Current @ Peak Power: 300 mA

Dimensions: 9.45” (24 cm) length, 10.4” (26.4 cm) width

1-2

Section 2. CSBUOY-NS Description

The CSBUOY-NS is designed to eliminate the use of hard-wire cable to
connect the water quality sensors with the datalogger (CR510, CR10X,
CR23X, CR800, CR850, CR1000, CR3000). This manual covers installation,
communication, and maintenance.

2.1 System Components

Mooring Eyebolts

5 W Solar Panel

Sensor Shroud

Solar Panel
Mounting
Brackets

5 W Solar Panel

Instrument Housing

Float

Antenna

CR206

FIGURE 2-1. CSBUOY-NS

2.2 Communication Options

• Direct RS-232 Connection to PC

• RF401 Spread Spectrum Radio Connection to PC

• RF401 Spread Spectrum Radio Connection to Datalogger (CR510,

CR10X, CR23X, CR800, CR850, CR1000, CR3000)

2.3 Power Supply

• 7 Amp/hr 12 VDC Rechargeable Battery

• 5 W Solar Panel Trickle Charger

2-1

Section 2. CSBUOY-NS Description

2-2

Section 3. CSBUOY Installation

3.1 Site Selection

The site should represent the general area being measured. Placement should
allow the buoy to float freely without obstruction from the bottom of the water
compound being monitored. The buoy solar panel should not have any
obstruction from full sunlight. Keep away from overhanging trees or other
obstructions. The solar panel should be angled towards the south to maximize
full solar capabilities.

3.2 CSBUOY-NS Assembly

CR206 Solar Panel Batt

Battery- Black
Battery+ Red
Charge- Black
Charge+ Red

Ensure that each wire is in the proper place on the CR206. Connect the battery
cable to the battery. Using a wrench, tighten the Heyco Pressure fitting to
ensure a watertight seal around the sensor cables exiting the instrument

housing. Insert the instrument mounting bracket into the instrument
housing, paying particular attention that the cable are not pinched. Tighten the
instrument housing lid.

With a wrench, tighten the vent plug into the float.

Attach the solar panel to the solar panel brackets. Tighten the connection
with the thumb screws.

Secure the mooring eye-bolts to a mooring line or the anchor eye-bolt to the
anchor line to secure placement of buoy in desired location.

3-1

Section 3. CSBUOY Installation

This is a blank page.

3-2

Section 4. Communication

The CSBUOY-NS can be used as a stand-alone monitoring system that
communicates directly with the PC, or as a wireless sensor that is integrated
with other Campbell Scientific dataloggers (CR510, CR10X, CR23X, CR800,
CR850, CR1000, CR3000) with table-based operating systems using the
Device Configuration Utility communication protocol.

4.1 Direct Connection to PC

In order to communicate with the CSBUOY-NS directly from the PC:

1. Device Configuration Utility software must be installed in the PC.

2. An RF401 Spread Spectrum Radio must be connected via com port to the

PC.

3. The RF401 and CSBUOY-NS Transceiver (CR206) must be configured to

communicate with each other (refer to RF401 and CR206 manuals).

4.1.1 Device Configuration Utility Software Installation

Refer to the Device Configuration Utility Manual for installation an d operation
instructions.

4.1.2 RF401 Connection

Refer to the RF401 Manual for configuration instructions.

4.2 CSBUOY-NS as a Wireless Sensor

A CSBUOY-NS acting as a wireless sensor can communicate with a CR800,
CR850, CR1000, or CR3000 datalogger using the GetVariable instruction.
With a CR10X, CR510, or CR23X, program instruction P193 is used. These
instructions open the communication between CSBUOY-NS and the
datalogger allowing data to be sent and received. In addition to this
instruction:

1. The datalogger requires a RF401 Spread Spectrum Radio configured with

a datalogger CDSC current port configuration.

2. The RF401 connected to the datalogger and the CSBUOY-NS must be

configured with the same radio address, net address and hopping
sequence.

4-1

Section 4. Communication

‘CR1000 Series Datalogger

Public Result, Remotedata (3)

DataTable (Test,1,-1)
DataInterval (0,60,Sec,10)
Sample (3,Remotedata(),FP2)
EndTable

Alias Remotedata(1) = pH
Alias Remotedata(2) = WaterTempC
Alias Remotedata(3) = BatteryVolt

BeginProg
Scan (30,Sec,0,0)
GetVariables (Result,ComSDC7,0,1,0000,0,“Public”,“Buoydata()”,Remotedata(),3)

‘where 1 is the PakBus address of the CSBUOY-NS

CallTable Test
NextScan
EndProg

Programming Examples

The following example allows the CR1000 to communicate with one
CSBUOY-NS, measuring the parameters.

This example allows the CR10X to communicate with one CSBUOY-NS.

;{CR10X-PB}
;
*Table 1 Program
01: 30 Execution Interval (seconds)

1: Batt Voltage (P10)
1: 1 Loc [ Batt ]

2: PakBus - Wireless Network Master (P193)
1: 1 Number of Remotes
2: 10 First Remote Address
3: 0 Time Into Transmit Interval (sec)
4: 300 Transmit Interval (sec, 0 = use execution interval)
5: 0 Transmit Delay Between Remotes (sec)
6: 5 Swath to Receive
7: 7 First Loc for Data Received [ RID_1 ]
8: 0 Swath to Send
9: 18 First Loc to Send [ Scratch ]
10: 2 Result Code Loc [ RCom_1 ]

3: Data Table (P84)
1: 0 Seconds into Interval
2: 300 Seconds Interval
3: 0 (0 = auto allocate, -x = redirect to inloc x)
4: Hist Table Name

4-2

4: Sample (P70)
1: 13 Reps
2: 1 Loc [ Batt ]

For further instruction on programming, please refer to the CR10X manual.

Section 4. Communication

4-3

Section 4. Communication

This is a blank page.

4-4

Section 5. Maintenance

The CSBUOY-NS has been engineered to provide many years of reliable
service. However, periodic maintenance is required to help ensure that the
system performs up to its potential. Equipment must be in good operating
condition, which requires a program of regular inspection and maintenance.
Routine and simple maintenance can be accomplished by the person in charge
of the CSBUOY-NS.

5.1 Instrumentation Maintenance

The instrumentation requires a minimum of routine maintenance. A few
preventative maintenance steps will optimize battery life and decrease the
chances of system failure.

5.1.1 Batteries

The CSBUOY-NS has been programmed to record battery voltage. This will
allow the user to determine how long a fresh battery will last. The
CSBUOY-NS is supplied with a fresh 12 VDC, 7.0 Ahr rechargeable battery.
This battery is continually recharged by the 5-watt solar panel mounted on top
of the instrument housing. Be aware of battery voltage that consistently
decreases over time, which indicates a failure in the charging circuitry.

5.1.2 Desiccant

Damage to the CR206 and wiring panel will occur if high moisture levels
inside the CSBUOY-NS instrument housing are not corrected. Enclosure
humidity is monitored by a humidity indicator card provided with the
CSBUOY-NS. It can also be more accurately monitored using the 10162
Enclosure Humidity Sensor, which is an optional sensor that can be purchased
with the CSBUOY-NS.

Regardless if the humidity sensor or the humidity indicator card is used to
monitor humidity inside the instrument housing, desiccant packs should be
replaced when relative humidity inside the instrument housing exceeds 35%.

5.1.3 Sensor Maintenance

Sensor maintenance should be performed at regular intervals, depending on the
desired accuracy and the conditions of use. A suggested maintenance schedule
is outlined below.

First week

• Check the Heyco pressure seals to ensure a tight fit.

• Check inside of the instrument housing to ensure against water leakage.

Any leakage will also be indicated by increase in humidity inside the
instrument housing.

5-1

Section 5. Maintenance

Each month

• Check humidity indicator card (or humidity readings from sensor).

Replace desiccant pack and tighten Heyco pressure fittings if needed.

Each Year

• Check cable for rodent or environmental damage.

• Replace humidity indicator card if necessary.

Every Three to Five Years

• Replace 10162 Humidity Sensor (if being used).

General Maintenance

• An occasional cleaning of the glass on the solar panel will improve its

efficiency.

• Check sensor leads and cables for cracking, deterioration, and rodent

damage.

• Check the CSBUOY-NS float, instrument housing, instrument shroud, and

cap for structural damage, poor fittings, loose fittings.

5-2

This is a blank page.

Campbell Scientific Companies

Campbell Scientific, Inc. (CSI)

815 West 1800 North

Logan, Utah 84321

UNITED STATES
www.campbellsci.com
[e-mail]

Campbell Scientific Africa Pty. Ltd. (CSAf)

PO Box 2450

Somerset West 7129

SOUTH AFRICA

www.csafrica.co.za

[e-mail]

Campbell Scientific Australi

PO Box 444

Thuringowa Central
QLD 4812 AUSTRALIA
www.campbellsci.com.au

[e-mail]

Campbell Scientific do Brazil Ltda. (CSB)

Rua Luisa Crapsi Orsi, 15 Butantã

CEP: 005543-000 São Paulo SP BRAZIL

www.campbellsci.com.br

[e-mail]

Campbell Scientific Canada Corp. (CSC)

11564 - 149th Street NW

Edmonton, Alberta T5M 1W7

CANADA

www.campbellsci.ca

[e-mail]

Campbell Scientific Ltd. (CSL)

Campbell Park

80 Hathern Road

Shepshed, Loughborough LE12 9GX

UNITED KINGDOM

www.campbellsci.co.uk

[e-mail]

Campbell Scientific Ltd. (France)

Miniparc du Verger - Bat. H

1, rue de Terre Neuve - Les Ulis

91967 COURTABOEUF CEDEX

FRANCE

www.campbellsci.fr

[e-mail]

Campbell Scientific Spain, S. L.

Psg. Font 14, local 8

08013 Barcelona

SPAIN
www.campbellsci.es
[e-mail]

Please visit www.campbellsci.com to obtain contact information for your local US or International representative.

a Pty. Ltd. (CSA)
