CS300 Pyranometer

1. Introduction

The CS300, manufactured by Apogee Instruments, measures total sun and sky
solar radiation for solar, agricultural, meteorological, and hydrological
applications. Its spectral range of 360 to 1120 nanometers encompasses most
of the shortwave radiation that reaches the Earth’s surface. This pyranometer
connects directly to our dataloggers. Its output can be measured by all of our
dataloggers.

2. Cautionary Statements

• READ AND UNDERSTAND the Precautions section at the front of this

manual.

• Care should be taken when opening the shipping package to not damage or

cut the cable jacket. If damage to the cable is suspected, consult with a
Campbell Scientific applications engineer.

• Remove the green cap after installing the sensor. Save this cap for

shipping or storing the sensor.

• Handle the sensor carefully when cleaning. Be careful not to scratch the

surface of the sensor.

3. Initial Inspection

• Upon receipt of the CS300, inspect the packaging and contents for

damage. File damage claims with the shipping company.

4. Quickstart

Short Cut is an easy way to program your datalogger to measure the CS106 and
assign datalogger wiring terminals. Use the following procedure to get started.

1. Install Short Cut by clicking on the install file icon. Get the install file

from either www.campbellsci.com, the ResourceDVD, or find it in
installations of LoggerNet, PC200W, PC400, or RTDAQ software.

1

CS300 Pyranometer

2. The Short Cut installation should place a Short Cut icon on the desktop of

your computer. To open Short Cut, click on this icon.

3. When Short Cut opens, select New Program.

4. Select Datalogger Model and Scan Interval (default of 5 seconds is OK

for most applications). Click Next.

2

CS300 Pyranometer

5. Under the Available Sensors and Devices list, select Sensors |

Meteorological | Solar Radiation folder. Select CS300 Pyranometer.

Click to move the selection to the Selected device window. Default
units are kW/m

2

for flux density units and mJ/ m2 for total flux. These can
be changed by clicking the Flux Density and Total Flux boxes and
selecting different values.

6. After selecting the sensor, click at the left of the screen on Wiring

Diagram to see how the sensor is to be wired to the datalogger. The
wiring diagram can be printed out now or after more sensors are added.

3

CS300 Pyranometer

5. Overview

7. Select any other sensors you have, then finish the remaining Short Cut

steps to complete the program. The remaining steps are outlined in Short

Cut Help, which is accessed by clicking on Help | Contents |
Programming Steps.

8. If LoggerNet, PC400, RTDAQ, or PC200W is running on your PC, and the

PC to datalogger connection is active, you can click Finish in Short Cut
and you will be prompted to send the program just created to the
datalogger.

9. If the sensor is connected to the datalogger, as shown in the wiring

diagram in step 6, check the output of the sensor in the datalogger support
software data display to make sure it is making reasonable measurements.

The CS300 measures incoming solar radiation with a silicon photovoltaic
detector mounted in a cosine-corrected head. Output from the detector is a
current, which is converted to voltage by a potentiometer potted in the sensor
head. The resistance of the potentiometer is adjusted when the sensor is
calibrated so that all sensors have the same output sensitivity.

The CS300 is calibrated against a Kipp and Zonen CM21 under natural
sunlight to accurately measure sun plus sky radiation (360 to 1120 nm). The
CS300 should not be used under vegetation or artificial lights.

During the night, the CS300 may read slightly negative incoming solar
radiation. This negative signal is caused by RF noise passing through the
photo-diode. Negative values may be set to zero in the datalogger program.

For more theoretical information on the silicon photovoltaic detector see Kerr,
J. P., G. W. Thurtell, and C. B. Tanner: An integrating pyranometer for
climatological observer stations and mesoscale networks. J. Appl. Meteor., 6,
688-694.

6. Specifications

Features:

• Designed for continuous, long term, unattended operation in adverse

conditions

• Dome-shaped head prevents water from accumulating on the sensor

head

• Compatible with the CWS900-series interfaces, allowing it to be used

in a wireless sensor network

• Compatible with Campbell Scientific CRBasic dataloggers:

CR200(X) series, CR800 series, CR1000, CR3000, CR5000, and
CR9000(X). Also compatible with Edlog dataloggers: CR500,
CR510, CR10(X), CR23X, CR7, and 21X

4

Power requirements: none, self-powered

–2

Sensitivity: 5 W m

Absolute accuracy: ±5% for daily total radiation

mV–1 (0.2 mV W–1 m–2)

CS300 Pyranometer

NOTE

Cosine response: ±5% at 75° zenith angle. ±2% at 45° zenith

angle

Response time: <1 ms

Temperature response: <1% at 5 to 40 °C

Long-term stability: <2% per year

Operating temperature: –40 to +70 °C

Relative humidity: 0 to 100%

7. Installation

Output: 0.2 mV per W m

Diameter: 2.4 cm (0.9 in)

Height: 2.5 cm (1.0 in)

Weight: 65 g (2.3 oz) with 2 m lead wire

Measurement range: 0 to 1750 W m

Light spectrum
waveband: 360 to 1120 nm (wavelengths where response

is 10% of maximum)

The black outer jacket of the cable is Santoprene® rubber. This
compound was chosen for its resistance to temperature extremes,
moisture, and UV degradation. However, this jacket will support
combustion in air. It is rated as slow burning when tested
according to U.L. 94 H.B. and will pass FMVSS302. Local fire
codes may preclude its use inside buildings.

If you are programming your datalogger with Short Cut, skip Section 7.3,
Wiring to the Datalogger, and Section 7.4, Programming. Short Cut does this
work for you. See Section 4, Quickstart, for a Short Cut tutorial.

–2

–2

(full sunlight ≈ 1000 W m–2)

7.1 Siting

The CS300 should be mounted such that it is never shaded by the tripod/tower
or other sensors. The sensor should be mounted with the cable pointing
towards the nearest magnetic pole. For example, in the Northern Hemisphere,
point the cable toward the North Pole.

Mounting height is not critical for the accuracy of the measurement. However,
pyranometers mounted at heights of 3 m or less are easier to level and clean.

5

CS300 Pyranometer

CM225 Stand

U-bolt Nuts

CM225 Stand

CM200-Series Crossarm

U-bolt Nuts

7.2 Mounting to an Instrument Mount

7.2.1 Required Tools

7.2.2 Mounting Procedure

7.2.2.1 CM225 Solar Sensor Mounting Stand

Tools required for installation on a tripod or tower:

Small and medium Phillips screwdrivers
1/2 in open end wrench for CM225 or 015ARM
Tape measure
UV-resistant cable ties
Side-cut pliers
Compass
Step ladder

1. If mounting the CM225 directly to a mast, place the CM225’s U-bolt in
the side holes and secure the CM225 to the mast by tightening the U-bolt
nuts.

2. If mounting a CM225 on a CM200-series crossarm, mount the crossarm to
the tripod or tower. Then place the CM225’s U-bolt in the bottom holes
and secure the CM225 to the crossarm by tightening the U-bolt nuts.

6

CS300 Pyranometer

Leveling Screws

Holes for
Mounting Screws

18356 Base

Leveling Screw

Mounting Screw

Bubble Level

Holes for
Mounting Screws

3. Place the CS300 in the center of the 18356 base/leveling fixture.

4. Loosely mount the 18356 base/leveling fixture on the CM225. Do not
fully tighten the three mounting screws.

5. Turn the leveling screws as required to bring the bubble of the bubble level
within the ring.

6. Tighten the mounting screws to secure the assembly in its final position.
Check that the pyranometer is still correctly leveled and adjust as
necessary.

7

CS300 Pyranometer

Cable Tie

U-bolt Nuts

015ARM

Leveling Screws

Holes for
Mounting Screws

18356 Base

7. Route the sensor cable along the underside of the crossarm to the
tripod/tower, and to the instrument enclosure.

8. Secure the cable to the crossarm and mast using cable ties.

9. Remove the green cap after installing the sensor. Save this cap for
shipping or storing the sensor.

7.2.2.2 015ARM

1. Secure the 015ARM to the mast by tightening the U-bolt nuts.

2. Place the CS300 in the center of the 18356 base/leveling fixture.

8

CS300 Pyranometer

RED

BLACK

CLEAR

500 to 600 Ω
typical

Single-Ended

Analog Input

Ground/AG

Ground/G

Cable Tie

CS300 Pyranometer

Mounting Screw

Leveling Screw

Bubble Level

3. Loosely mount the 18356 base/leveling fixture on the 015ARM. Do not
fully tighten the three mounting screws.

4. Turn the leveling screws as required to bring the bubble of the bubble level
within the ring.

5. Tighten the mounting screws to secure the assembly in its final position.
Check that the pyranometer is still correctly leveled and adjust as
necessary.

6. Route the sensor cable along the underside of the 015ARM’s arm to the
tripod/tower, and to the instrument enclosure.

7. Secure the cable to the mounting arm and mast using cable ties.

8. Remove the green cap after installing the sensor. Save this cap for
shipping or storing the sensor.

7.3 Wiring to the Datalogger

A schematic diagram of the CS300 is shown in FIGURE 7-1.

FIGURE 7-1. CS300 schematic

Connections to Campbell Scientific dataloggers are given in TABLE 7-1.
When Short Cut is used to create the datalogger program, the sensor should be
wired to the channels shown in the wiring diagram created by Short Cut.

9

CS300 Pyranometer

TABLE 7-1. Connections to Campbell Scientific Dataloggers

NOTE

Color

Red Signal SE Analog SE Analog SE Analog SE Analog

Black Signal

Clear Shield

7.4 Programming

Short Cut is the best source for up-to-date datalogger programming code.
Programming code is needed,

If your data acquisition requirements are simple, you can probably create and
maintain a datalogger program exclusively with Short Cut. If your data
acquisition needs are more complex, the files that Short Cut creates are a great
source for programming code to start a new program or add to an existing
custom program.

Wire Label

CR9000(X)
CR5000
CR3000
CR1000
CR800
CR850

CR510
CR500
CR10(X)

AG

21X
CR7
CR23X

Reference

G

• when creating a program for a new datalogger installation

• when adding sensors to an existing datalogger program

CR200(X)

Short Cut cannot edit programs after they are imported and edited
in CRBasic Editor.

A Short Cut tutorial is available in Section 4, Quickstart. If you wish to import
Short Cut code into either Edlog or CRBasic Editor to create or add to a
customized program, follow the procedure in Appendix A, Importing Short Cut
Code Into CRBasic or Edlog Editor. Programming basics for CRBasic and
Edlog dataloggers are provided below. Complete program examples for select
dataloggers can be found in Appendix B, Example Programs.

–2

The output from the CS300 is 0.2 mV per Wm

. The voltage signal from the
CS300 is measured using the single-ended voltage instruction (VoltSE in
CRBasic or Volt (SE) (P1) in Edlog). Dataloggers that use CRBasic include
the CR200(X), CR800, CR850, CR1000, CR3000, CR5000, and CR9000(X).
Dataloggers that use Edlog include CR7, CR10(X), CR510, and CR23X.

–2

Solar radiation can be recorded as an average flux density (W m

–2

total flux (MJ m

). The appropriate multipliers are listed in TABLE 7-2.

) or daily

Negative values should be set to zero before being processed.

10

TABLE 7-2. Multipliers Required for Average Flux

and Total Flux Density in SI and English Units

( )( )

3 9

6999

0 5 3600

2

2 1 1

..

hr

kJ m

kJ m s s hr

=

−

− − −

UNITS MULTIPLIER PROCESS

W m-2 5.0 Average

MJ m-2 t • 0.000005 Total

kJ m-2 t • 0.005 Total

cal cm–2 min–1 0.005 • (1.434) Average

cal cm–2 t • 0.005 • (0.0239) Total

t = datalogger execution interval in seconds

Nearby AC power lines, electric pumps, or motors can be a source of electrical
noise. If the sensor or datalogger is located in an electrically noisy
environment, the measurement should be made with the 60 or 50 Hz rejection
integration option as shown in the example programs.

7.4.1 Total Solar Radiation

If solar radiation is totalized in units of kJ m–2, there is a possibility of
overranging the output limits. For CRBasic dataloggers, you can avoid this by
using the IEEE4 or long data format. With the Edlog dataloggers the largest
number that the datalogger can output to final storage is 6999 in low resolution
(default), and 99999 in high resolution.

CS300 Pyranometer

For Edlog dataloggers, if you assume that the daily total flux is desired in kJ m

2

and assume an irradiance of 0.5 kW m–2, the maximum low resolution output
limit will be exceeded in just under four hours. This value was found by taking
the maximum flux the datalogger can record in low resolution and dividing by
the total hourly flux.

(1)

To circumvent this limitation for Edlog dataloggers, record an average flux.
Then, during post processing, multiply the average flux by the number of
seconds in the output interval to arrive at an output interval flux. Sum the
output interval totals over a day to find a daily total flux.

Another alternative for Edlog dataloggers is to record total flux using the high
resolution format. Instruction 78 is used to switch to the high resolution. The
disadvantage of the high resolution format is that it takes more memory per
data point.

–

11

CS300 Pyranometer

CAUTION

NOTE

8. Maintenance and Calibration

On a monthly basis the level of the pyranometer should be checked. Any dust
or debris on the sensor head should be removed. The debris can be removed
with a blast of compressed air or with a soft bristle, camel hair brush.

Handle the sensor carefully when cleaning. Be careful not
to scratch the surface of the sensor.

Recalibrate the CS300 every three years. Obtain an RMA number before
returning the CS300 to Campbell Scientific, Inc. for recalibration.

9. Troubleshooting

Symptom: –9999 or radiation values around 0

1. Check that the sensor is wired to the single-ended channel specified by the
measurement instruction.

2. Verify that the range code is correct for the datalogger type.

3. Disconnect the sensor leads from the datalogger and use a DVM to check
the voltage between the red (+) and the black (–) wires. The voltage
should be 0 to 200 mV for 0 to 1000 Wm
indicates a problem with either the photodiode or the shunt resistor, both
of which are potted in the sensor head and cannot be serviced.

Symptom: Incorrect solar radiation

1. Make sure the top surface of the sensor head is clean, and that the sensor
is properly leveled.

2. Verify that the range code, multiplier and offset parameters are correct for
the desired engineering units and datalogger type.

Jumps of 3 to 6 Wm–2 are typical of CR200(X) measurements, due
to the 0.6 mV CR200(X) resolution and the 0.2 mV/Wm–2 CS300
sensitivity.

–2

radiation. No voltage

12

Appendix A. Importing Short Cut Code Into CRBasic or Edlog Editor

This tutorial shows:

• How to import a Short Cut program into a program editor for

additional refinement

• How to import a wiring diagram from Short Cut into the comments of

a custom program

A.1 Importing Short Cut Code into a Program Editor

Short Cut creates files that can be imported into either CRBasic Editor or
Edlog program editor. These files normally reside in the

C:\campbellsci\SCWin folder and have the following extensions:

• .DEF (wiring and memory usage information)

• .CR2 (CR200(X) datalogger code)

• .CR1 (CR1000 datalogger code)

• .CR8 (CR800 datalogger code)

• .CR3 (CR3000 datalogger code)

• .CR5 (CR5000 datalogger code)

• .CR9 (CR9000(X) datalogger code)

• .DLD (contain code for CR10(X), CR23X, CR500, CR510, 21X, or

CR7(X) dataloggers)

The following procedures show how to import these files for editing.

A.1.1 CRBasic Datalogger

Use the following procedure to import Short Cut code into CRBasic Editor
(CR200(X), CR1000, CR800, CR3000, CR5000 dataloggers).

1. Create the Short Cut program following the procedure in Section 4,
Quickstart. Finish the program and exit Short Cut. Make note of the file
name used when saving the Short Cut program.

2. Open CRBasic Editor.

3. Click File | Open. Assuming the default paths were used when Short Cut
was installed, navigate to C:\CampbellSci\SCWin folder. The file of
interest has a “.CR2”, “.CR1”, “.CR8”, “.CR3”, “.CR5”, or “.CR9”
extension, for CR200(X), CR1000, CR800, CR3000, CR5000, or
CR9000(X) dataloggers, respectively. Select the file and click Open.

4. Immediately save the file in a folder different from \Campbellsci\SCWin,
or save the file with a different file name.

A-1

Appendix A. Importing Short Cut Code Into CRBasic or Edlog Editor

NOTE
NOTE

Once the file is edited with CRBasic Editor, Short Cut can no
longer be used to edit the datalogger program. Change the name
of the program file or move it, or Short Cut may overwrite it next
time it is used.

5. The program can now be edited, saved, and sent to the datalogger.

6. Import wiring information to the program by opening the associated .DEF
file. Copy and paste the section beginning with heading “-Wiring for
CRXXX–” into the CRBasic program, usually at the head of the file.
After pasting, edit the information such that a ' character (single quotation
mark) begins each line. This character instructs the datalogger compiler to
ignore the line when compiling the datalogger code.

A.1.2 Edlog

Use the following procedure to import Short Cut code into the Edlog program
editor (CR10(X), CR500, CR510, CR23X, CR7, or 21X dataloggers).

1. Create the Short Cut program following the procedure in Section 4,
Quickstart. Finish the program and exit Short Cut. Make note of the file
name used when saving the Short Cut program.

2. Open Edlog.

3. Click File | Document DLD File. Assuming the default paths were used
when Short Cut was installed, navigate to C:\CampbellSci\SCWin folder.
The file of interest has a “.DLD” extension. Select the file and click
Open. The .dld file, which is a type of ASCII machine code, is imported,
documented, and, when saved, given a “.CSI” extension.

4. Immediately save the file in a folder different from \Campbellsci\SCWin,
or save the file with a different file name.

Once the file is edited with Edlog, Short Cut can no longer be used
to edit the program. Change the name of the program file or move
it, or Short Cut may overwrite it.

5. The program can now be edited, saved, and sent to the datalogger.

6. Import wiring information to the program by opening the associated .DEF
file. Copy and paste the section beginning with heading “-Wiring for
CRXXX–” into the Edlog program, usually at the head of the file. After
pasting, edit the information such that a ; (semicolon) begins each line,
which instructs the datalogger compiler to ignore the line when compiling
the datalogger code.

A-2

TABLE B-1. Wiring for Example Programs

Appendix B. Example Programs

The following programs measure the CS300 every 10 s and convert the
millivolt output to Wm
flux (Wm
zero before being processed. Wiring for the examples is given in TABLE B-1.

Color Description CR1000 CR10X

Red Signal SE 1 SE 1

Black Signal Ground

Clear Shield

B.1 CR1000 Program

'CR1000

'Declare Variables and Units
Public SlrW
Public SlrMJ

Units SlrW=W/m²
Units SlrMJ=MJ/m²

'Define Data Tables
DataTable(Table1,True,-1)
DataInterval(0,60,Min,10)
Average(1,SlrW,FP2,False)
EndTable

DataTable(Table2,True,-1)
DataInterval(0,1440,Min,10)
Totalize(1,SlrMJ,IEEE4,False)
EndTable

'Main Program
BeginProg
Scan(10,Sec,1,0)

'Measure CS300 Pyranometer
VoltSe (SlrW,1,mV250,1,1,0,_60Hz,1.0,0) use 1000 mV range for the CR5000, CR9000
For the CR1000, use the Auto Range or
'Set negative values to zero mV 2500 range for > 1200 w/m2 intensities.
If SlrW<0 Then SlrW=0

'Convert mV to MJ/m² for a 10 second scan rate
SlrMJ=SlrW*0.00005

'Convert mV to W/m²
SlrW=SlrW*5.0

'Call Data Tables and Store Data
CallTable(Table1)
CallTable(Table2)
NextScan
EndProg

–2

–2

), and a daily total flux density (MJm–2). Negative values are set to

and MJm–2. Both programs output an hourly average

AG

G

B-1

Appendix B. Example Programs

B.2 CR10X Example Program

;{CR10X}
*Table 1 Program
01: 10.0000 Execution Interval (seconds)

; Measure CS300 pyranometer

1: Volt (SE) (P1)
1: 1 Reps
2: 24 250 mV 60 Hz Rejection Range ; use 500 mV range for the CR7 and
21X,
1000 mV range for the CR23X. For the
3: 1 SE Channel CR10X, use range code 0 or 25 for
4: 1 Loc [ SlrW ] > 1200 w/m2 intensities.
5: 1.0 Multiplier
6: 0.0 Offset

; Set negative values to zero

2: If (X<=>F) (P89)
1: 1 X Loc [ SlrW ]
2: 4 <
3: 0 F
4: 30 Then Do

3: Z=F x 10^n (P30)
1: 0 F
2: 0 n, Exponent of 10
3: 1 Z Loc [ SlrW ]

4: End (P95)

; Convert mV to MJ/m2 for 10 second execution interval

5: Z=X*F (P37)
1: 1 X Loc [ SlrW ]
2: .00005 F
3: 2 Z Loc [ SlrMJ ]

; Convert mV to W/m2

6: Z=X*F (P37)
1: 1 X Loc [ SlrW ]
2: 5 F
3: 1 Z Loc [ SlrW ]

7: If time is (P92)
1: 0 Minutes (Seconds --) into a
2: 60 Interval (same units as above)
3: 10 Set Output Flag High (Flag 0)

8: Set Active Storage Area (P80)
1: 1 Final Storage Area 1
2: 101 Array ID

9: Real Time (P77)
1: 1220 Year,Day,Hour/Minute (midnight = 2400)

10: Average (P71)
1: 1 Reps
2: 1 Loc [ SlrW ]

11: If time is (P92)
1: 0 Minutes (Seconds --) into a
2: 1440 Interval (same units as above)
3: 10 Set Output Flag High (Flag 0)

B-2

12: Set Active Storage Area (P80)
1: 1 Final Storage Area 1
2: 102 Array ID

13: Real Time (P77)
1: 1220 Year,Day,Hour/Minute (midnight = 2400)

14: Resolution (P78)
1: 1 High Resolution

15: Totalize (P72)
1: 1 Reps
2: 2 Loc [ SlrMJ ]

16: Resolution (P78)
1: 0 Low Resolution

Appendix B. Example Programs

B-3

Appendix B. Example Programs

B-4
