CS210 Enclosure
Relative Humidity Sensor
Revision: 10/07
Copyright © 1996-2007
Campbell Scientific, Inc.
Warranty and Assistance
The CS210 ENCLOSURE RELATIVE HUMIDITY SENSOR is warranted
by CAMPBELL SCIENTIFIC, INC. to be free from defects in materials and
workmanship under normal use and service for twelve (12) months from date
of shipment unless specified otherwise. Batteries have no warranty.
CAMPBELL SCIENTIFIC, INC.'s obligation under this warranty is limited to
repairing or replacing (at CAMPBELL SCIENTIFIC, INC.'s option) defective
products. The customer shall assume all costs of removing, reinstalling, and
shipping defective products to CAMPBELL SCIENTIFIC, INC. CAMPBELL
SCIENTIFIC, INC. will return such products by surface carrier prepaid. This
warranty shall not apply to any CAMPBELL SCIENTIFIC, INC. products
which have been subjected to modification, misuse, neglect, accidents of
nature, or shipping damage. This warranty is in lieu of all other warranties,
expressed or implied, including warranties of merchantability or fitness for a
particular purpose. CAMPBELL SCIENTIFIC, INC. is not liable for special,
indirect, incidental, or consequential damages.
Products may not be returned without prior authorization. The following
act information is for US and International customers residing in countries
cont
served by Campbell Scientific, Inc. directly. Affiliate companies handle
repairs for customers within their territories. Please visit
www.campbellsci.com to determine which Campbell Scientific company
serves your country. To obtain a Returned Materials Authorization (RMA),
contact CAMPBELL SCIENTIFIC, INC., phone (435) 753-2342. After an
applications engineer determines the nature of the problem, an RMA number
will be issued. Please write this number clearly on the outside of the shipping
container. CAMPBELL SCIENTIFIC's shipping address is:
CAMPBELL SCIENTIFIC, INC.
RMA#_____
815 W
Logan, Ut
CAMPBELL SCIENTIFIC, INC. does not accept collect calls.
est 1800 North
ah 84321-1784
CS210 Table of Contents
PDF viewers note: These page numbers refer to the printed version of this document. Use
the Adobe Acrobat® bookmarks tab for links to specific sections.
1. General .........................................................................1
2. Specifications ..............................................................1
3. Installation....................................................................1
4. Wiring............................................................................2
5. Programming ...............................................................3
5.1 CRBasic Examples ...................................................................................3
5.2 Edlog Examples........................................................................................5
6. Enclosure Humidity.....................................................7
7. Maintenance.................................................................7
Figures
1. CS210 Installed on a CR1000.....................................................................2
2. CS210 Wiring.............................................................................................2
Tables
1. Datalogger Connections..............................................................................2
2. Calibration for Relative Humidity..............................................................3
3. Wiring for Examples 3 and 4......................................................................5
i
This is a blank page.
CS210 Enclosure Humidity Sensor
1. General
The CS210 Enclosure Humidity sensor contains an Elan HM2000 series precision
bulk-polymer relative humidity sensor. It is used to monitor the relative humidity
inside an equipment enclosure deployed in the field.
NOTE
The CS210 was once known as the 10162.
2. Specifications
Sensor: Elan HM2000 series precision bulk-polymer
Relative Humidity Measurement Range: 0 to 100% non-condensing
RH Output Signal Range: 0 to 1.0 VDC
Accuracy at 25°C
Typical Long Term Stability: Better than 3% RH per year
Response Time (at 25°C, 90% response): 10 seconds for a 30% to 90% RH
Operating Temperature: 0°C to +50°C
Storage Temperature: -40°C to +80°C
Probe Length: 2.6 cm (1.02 in.)
Probe Cross Section Area: 0.6 cm x 1.1 cm (0.23 in. x 0.43 in.)
Current Consumption: <0.5 mA
unspecified (0 to 10% Relative Humidity)
±3% RH (10 to 90% Relative Humidity)
unspecified (90 to 100% Relative Humidity)
step change
3. Installation
NOTE
Supply Voltage: 5 ± 0.25 VDC
Settling Time: 10 seconds
Mount the CS210 inside the environmental enclosure or onto a datalogger
using the mounting block and the wire tie included with the sensor (Figure 1).
®
The black outer jacket of the cable is Santoprene
compound was chosen for its resistance to temperature extremes,
moisture, and UV degradation. However, this jacket will
support combustion in air. It is rated as slow burning when
tested according to U.L. 94 H.B. and will pass FMVSS302.
Local fire codes may preclude its use inside buildings.
rubber. This
1
