INSTRUCTION MANUAL
CSI Model 10164-L Sampler
Control Cable for use with Isco
and Sigma Autosamplers
1/99
Copyright (c) 1998-1999
Campbell Scientific, Inc.
Page 2
The CSI MODEL 10164-L SAMPLER CONTROL CABLE is warranted by CAMPBELL SCIENTIFIC, INC. to be free from defects in materials and workmanship under normal use and service for twelve (12) months from date of shipment unless specified otherwise. Batteries have no warranty. CAMPBELL SCIENTIFIC, INC.'s obligation under this warranty is limited to repairing or replacing (at CAMPBELL SCIENTIFIC, INC.'s option) defective products. The customer shall assume all costs of removing, reinstalling, and shipping defective products to CAMPBELL SCIENTIFIC, INC. CAMPBELL SCIENTIFIC, INC. will return such products by surface carrier prepaid. This warranty shall not apply to any CAMPBELL SCIENTIFIC, INC. products which have been subjected to modification, misuse, neglect, accidents of nature, or shipping damage. This warranty is in lieu of all other warranties, expressed or implied, including warranties of merchantability or fitness for a particular purpose. CAMPBELL SCIENTIFIC, INC. is not liable for special, indirect, incidental, or consequential damages.
Products may not be returned without prior authorization. The following contact information is for US and International customers residing in countries served by Campbell Scientific, Inc. directly. Affiliate companies handle repairs for customers within their territories. Please visit www.campbellsci.com to determine which Campbell Scientific company serves your country. To obtain a Returned Materials Authorization (RMA), contact CAMPBELL SCIENTIFIC, INC., phone (435) 753-2342. After an applications engineer determines the nature of the problem, an RMA number will be issued. Please write this number clearly on the outside of the shipping container. CAMPBELL SCIENTIFIC's shipping address is:
CAMPBELL SCIENTIFIC, INC.
RMA#_____ 815 West 1800 North Logan, Utah 84321-1784
CAMPBELL SCIENTIFIC, INC. does not accept collect calls.
Page 3
CSI MODEL 10164-L SAMPLER CONTROL CABLE
FOR USE WITH ISCO AND SIGMA AUTOSAMPLERS
The 10164-L sampler control cable enables a datalogger to trigger an Isco, American Sigma, or connector-compatible autosampler. Through this cable, the datalogger can inhibit the sampler from running its programmed sampling routine and sense and record when the sampler indicates that it has taken a sample. The following examples illustrate its use. Each of these functions are independent of the others and you may combine functions as desired. You should insulate and tuck out of the way any unused wires.
Trigger Sampler
Wire color CR10 21X BDR320
purple G Ground GND yellow C2 Control 2 C2 red 12V +12 12V clear G Ground GND
To trigger the sampler, pulse port 2 using a set of instructions such as follows:
Do (P86)
1: 42 Set Port 2 High
; Note: The 50 in the third parameter keeps the ; port high for 0.5 seconds. Some users have ; reported using a delay of 1 sec (100 in ; parameter 3) to ensure reliable triggering of ; the sampler.
Excitation with Delay (P22)
1: 1 Ex Channel 2: 0 Delay W/Ex (units = 0.01 sec) 3: 50 Delay After Ex (units = 0.01
sec)
4: 0 mV Excitation
Sense Sampler Event Markers
Pulse port method:
Wire color CR10 21X BDR320
purple G Ground GND orange P1 Pulse 1 P1 clear G Ground GND
To sense sampler events, use Instruction 3 with a configuration code of 0 (no configuration code or Reps are required for the BDR320):
Pulse (P3)
1: 1 Reps 2: 1 Pulse Input Chan 3: 0 High frequency
(configuration code) 4: 2 Loc [:EVENTS] 5: 1 Mult 6: 0 Offset
To record the events in the datalogger's final storage area, remember to totalize the events temporarily stored in Input Location 2 in this example.
Do (P86)
1: 52 Set Port 2 Low
For the CR10 and the 21X, you can also supply the trigger signal from switched excitation if no control ports are available. In this case, connect the yellow cable to the desired excitation channel (say E3) and pulse the channel using Instruction 22 as follows:
Excitation with Delay (P22)
1: 3 EX Chan (or the channel
you select) 2: 50 Delay w/EX (units=0.01sec) 3: 0 Delay after EX (units=0.01sec) 4: 2500 mV Excitation
CR10 control port interrupt method:
For the CR10, there is another useful method for sensing and recording sampler events. This method uses the control port 8/subroutine 98 interrupt feature of the CR10. Each time the sampler reports an event, the CR10 records the sample number with a time stamp in final storage. In this example, sampler events will show up as output arrays with an array ID of 400.
Wire color CR10
purple G orange C8 clear G
1
Page 4
CSI MODEL 10164-L SAMPLER CONTROL CABLE FOR USE WITH ISCO AND SIGMA AUTOSAMPLERS
CR10 Program (Subroutine 98 in Program Table 3)
* 3 Table 3 Subroutines
1: Beginning of Subroutine (P85)
1: 98 Subroutine Number
2: Z=Z+1 (P32)
1: 10 Z Loc [ Sample_No ]
3: Do (P86)
1: 10 Set high Flag 0 (output
flag)
4: Set Active Storage Area (P80)
1: 1 Final Storage Area 1 2: 400 Array ID or location
5: Real Time (P77)
1: 1110 Year,Day,Hour-Minute
6: Sample (P70)
1: 1 Reps 2: 10 Loc [ Sample_No ]
7: End (P95) ;of Subroutine Number 98
Technical details of cable design:
Wire color Via
brown direct D
green direct F
purple direct B
yellow solid state none (controls C)
relay circuit
red solid state C
relay circuit
orange 20Kohm E
resistor
clear cable shield no connection
Connector pin
End Table 3
Inhibit Sampler’s Program
Wire color CR10 21X BDR320
purple G Ground GND (Isco) green C1 Control 1 C1 (Sigma) brown C1 Control 1 C1 clear G Ground GND
To inhibit an Isco sampler from running its own program, set control port 1 low using a program control instruction such as Instruction 86. To allow the sampler to run its program, set it high.
NOTE: The logic for Sigma samplers is just the opposite. A high signal inhibits the sampler.
Example for inhibiting an Isco sampler's program:
Do (P86)
1: 51 Set Port 1 low ;(41 would
set it high)
2
