CHAIN SLINGS

Cam-Alloy "J" Hooks

■ Forged Alloy Steel

■ Proof Tested to 2 Times the Working Load Limit

■ Self Colored Finish

■ Made in the USA

■ DO NOT EXCEED THE WORKING LOAD LIMIT

Cat. No. UPC No. Style Material Diameter Working Load Limit Weight Each (lbs.)

5616215 020418078484 A 3/4 in 2250 lb 0.85 lb

5616615 020418078491 B 1 in 3600 lb 2.37 lb

5616616 020 41818 97 77 A 1 in 3600 lb 2.38 lb

Cam-Alloy "S" Hooks

■ Made of Heat-Treated Alloy Steel

■ Proof Tested to 2 Times the Working Load Limit

■ Meet Proof Test and Design Factor for Use in Alloy Chain Slings

■ Working Load Limit is Embossed on the S-Hook Body

■ Finish is Self Colored

■ Made in the USA

■ DO NOT EXCEED THE WORKING LOAD LIMIT

Trade Size Cat. No. UPC No. A Dim. B Dim. C Dim. R Dim.

18

MATERIAL HANDLING

9/32 in 5610405 0 20 418078262 2.75 in 0.75 in 0.38 in 0.38 in 250 lb 0.07 lb

3/8 in 5610605 0204180782 79 4.13 in 1.13 in 0.56 in 0.56 in 500 lb 0.34 lb

1/2 in 5 61080 5 020418078286 5.50 in 1.5 0 in 0.75 in 0.75 in 1000 lb 0.59 lb

5/8 in 56 11005 020418 07 82 93 7. 0 0 in 1.8 8 in 0.94 in 0.94 in 150 0 lb 1.24 lb

3/4 in 5 61120 5 020 418078 309 8.25 in 2.25 in 1.13 in 1.13 in 2000 lb 2.31 lb

1 in 5 611605 0 20 418078323 11.0 0 in 3.00 in 1.50 in 1.50 in 3200 lb 4.45 lb

Field I.D. Tags

■ Designed for Field Attachment

■ Pre-Stamped for Easy Addition of Reach, Working Load Limit, Chain Size,
Chain Grade and Serial Number

■ Tag Measures 1 1/2" X 4 1/8" X 5/32" Thick and Has A 1 1/16" Diameter Hole

■ Cut at Top of Tag Allows You to Attach to Sling Link

■ Also Available Solid (Without Split)

■ Box of 50 Tags (Order Unit is "Carton")

Cat. No. UPC No. Type Quantity Per Package Weight Per Carton (Lbs)

7503506 020418135309 Split 50 12.80 lb

7503506C 02 0418217319 Solid 50 12.80 lb

Working L oad

Limit

Weight Each

(lbs.)
