CR1000 Overview
The CR1000 provides precision measurement capabilities in a rugged, battery-operated
package. The CR1000 includes CPU and analog and digital inputs and outputs. The onboard, BASIC-like programming language includes data processing and analysis routines.
PC200, PC400, or LoggerNet software provides program generation and editing, data
retrieval, and real-time monitoring.
SE
12
DIFF
DIFF
SE
3
1
H
2
L
H
109
11
56
H
L
POWER OUT
G
5V
4
56
7
14
7
HL
12V
12V
HL
15 16
COM1
Tx
G
8
4
8
H
L
Rx Tx Rx
C1
C2
COM2
C3
EX1
P1
P2
EX2
EX3
COM3
COM4
Tx
Rx
C4
Tx
G
C5
C6
C7
POWER IN
CAUTION
DC ONLY
12VG
GROUND
LUG
CR1000
WIRING PANEL
RS-232 (Not Isolated)
Rx
C8
G
CS I/O
PERIPHERAL PORT
3
L
HL
12
13
H
L
G
SW-12
G
SDM
FIGURE OV1-1. CR1000 Measurement and Control System
OV1. Physical Description
Figure OV1-2 shows the CR1000 panel and the associated program
instructions. The details of the measurement instructions can be found in
Section 7.
OV1.1 Measurement Inputs
OV1.1.1 Analog Inputs (SE 1-16, DIFF 1-8)
There are 8 differential or 16 single-ended inputs for measuring voltages up to
±5 V. A thermistor installed in the wiring panel can be used to measure the
reference temperature for thermocouple measurements, and a heavy copper
grounding bar and connectors combine with the case design to reduce
temperature gradients for accurate thermocouple measurements. Resolution on
the most sensitive range is 0.67 µV
SN:
MADE IN USA
OV-1
CR1000 Overview
Analog Inputs
Voltage
VoltDiff
VoltSE
Thermocouple
TCDiff
TCSE
Bridge measurements
(use VX)
BrFull
BrFull6W
BrHalf
BrHalf3W
BrHalf4W
Others
PanelTemp
PeriodAvg
AM25T
Switched Voltage
Excitation (EX)
Excite
BrFull
BrFull6w
BrHalf
BrHalf3W
BrHalf4W
Pulse Inputs
PulseCount
PulseCountReset
Signal Ground ( ),
for
Analog
Pulse
Excitation
Ground Lug
Power In
RS-232
CS I/O
DSP4 (Data Tables
and Output)
SE
DIFF
SE
DIFF
5 V
Switched
12 Volts SW-12
PortSet
SW12
12 34 56 78
1234
H
H
L
11
109
5678
L
H
H
POWER OUT
SW-12
G
G
G
5V
12V
HLHLL
1412
15 1613
HLHLL
COM1
COM2 COM3 COM4
Tx
Rx Tx Rx Tx Rx Tx Rx
GC1C2
12V
C3
SDM
12 V SDM Connections
CS7500
CSAT3
SDMINT8
SDMSpeed
SDMTrigger
FIGURE OV1-2. CR1000 Wiring Panel and Associated Instructions
POWER IN
G 12V
EX1
P2
P1
GROUND
LUG
CAUTION
DC ONLY
12VG
CR1000
EX3
EX2
C5
C4
G
C6C7C8
G
Control I/O
PortGet
PortSet
PulseCount
PulseCountReset
ReadIO
TimerIO
WriteIO
WIRING PANEL
RS-232 (Not Isolated)
CS I/O
SN:
Power Ground (G), for
5V
SW-12
12V
SDM
Control I/O
PERIPHERAL PORT
MADE IN USA
Peripheral Port
CardOut (Data
Tables and Output)
OV-2
OV1.1.2 Signal Grounds ( )
Signal Grounds ( ) should be used as the reference for Single-ended Analog
inputs, Pulse inputs, Excitation returns, and sensor shield wires. Signal returns
for the Pulse inputs should use the
inputs.
OV1.1.3 Power Grounds (G)
Power Grounds (G) should be used as the returns for the 5V, SW12, 12V, and
C1-C8 outputs. Use of the G grounds for these outputs with potentially large
currents will minimize current flow through the analog section, which can
cause Single-ended voltage measurement errors.
OV1.1.4 Ground Lug ( )
The large ground lug is used to connect a heavy gage wire to earth ground. A
good earth connection is necessary fix the ground potential of the datalogger
and to send to earth transients that come in on either the G or
are shunted to ground via the spark gaps protecting other inputs.
OV1.1.5 Power In (G and 12V)
The G and 12V terminals on the Power In connector plug are for connecting
power from an external battery to the CR1000. These are the only terminals
that can be used to input battery power; the other 12V and SW-12V terminals
are output only.
CR1000 Overview
terminals located next to the Pulse
terminals or
OV1.1.6 Switched 12 Volts (SW-12)
The SW-12 terminal provide an unregulated 12 volts that can be switched on
and off under program control.
OV1.1.7 Switched Voltage Excitation (EX E1-3)
Three switched excitation channels provide precision programmable voltages
within the ±2.5 Volt range for bridge measurements. Each channel will source
up to 2.5 mA at voltages up to ±2.5 Vdc.
OV1.1.8 Digital I/O (C1-8)
There are 8 digital Input/Output channels (0 V low, 5 V high) for frequency
measurement, pulse counting, digital control, and triggering. In addition to the
individual channel digital I/O functions, there are several groups of channels
that can be used for other functions.
The Synchronous Device for Measurement (SDM) connections C1, C2, and C3
along with the 12 volt and ground terminals are used to connect SDM sensors
and peripherals.
The COM groupings can be used for serial I/O communication and Intelligent
Sensor input.
OV1.1.9 Pulse Inputs (P1-2)
Two Pulse input channels can count pulses from high-level (5 V square wave),
switch closure, or low-level A/C signals.
OV-3
CR1000 Overview
OV1.2 Communication and Data Storage
OV1.2.1 Peripheral Port
The peripheral port is for attaching data storage or communication peripherals.
Both the CFM100 and NL115 modules plug onto the peripheral port and have
a slot for a Type I or Type II CompactFlash
also supports Ethernet communications.
®
card (Section 2.1.2). The NL115
CAUTION
OV1.2.2 CS I/O
Removing a card from the CFM100 or NL115 while the
card is active can cause garbled data and can actually
damage the card. Always press the button to disable the
card for removal before switching off the CR1000 power.
All Campbell Scientific communication peripherals connect to the CR1000
through the 9-pin subminiature D-type socket connector located on the front of
the Wiring Panel labeled “CS I/O” (Figure OV1-3). Table OV1-1 gives a brief
description of each pin.
TABLE OV1-1. Pin Description
ABR = Abbreviation for the function name.
PIN = Pin number.
O = Signal Out of the CR1000 to a peripheral.
I = Signal Into the CR1000 from a peripheral.
PIN ABR I/O Description
1 5 V O 5V: Sources 5 VDC, used to power peripherals.
2 SG Signal Ground: Provides a power return for pin 1
(5V), and is used as a reference for voltage levels.
3 RING I Ring: Raised by a peripheral to put the CR1000 in
the telecommunications mode.
4 RXD I Receive Data: Serial data transmitted by a peripheral
are received on pin 4.
5 ME O Modem Enable: Raised when the CR1000
determines that a modem raised the ring line.
6 SDE O Synchronous Device Enable: Used to address
Synchronous Devices (SDs), and can be used as an
enable line for printers.
7 CLK/HS I/O Clock/Handshake: Used with the SDE and TXD
lines to address and transfer data to SDs. When not
used as a clock, pin 7 can be used as a handshake
line (during printer output, high enables, low
disables).
8 +12 VDC
9 TXD O Transmit Data: Serial data are transmitted from the
CR10X to peripherals on pin 9; logic low marking
(0V) logic high spacing (5V) standard asynchronous
ASCII, 8 data bits, no parity, 1 start bit, 1 stop bit,
300, 1200, 2400, 4800, 9600, 19,200, 38,400,
115,200 baud (user selectable).
OV-4
CR1000 Overview
OV1.2.3 Computer RS-232
The CR1000 RS-232 port is not isolated.
Direct connection of the CR1000 to a PC is most conveniently done through
the "Computer RS-232" port (Figure OV1-3). Table OV1-2 gives a brief
description of each "Computer RS-232" pin.
The Computer RS-232 port is a DCE device when connected to a PC with a
serial cable. It also doubles as a DTE device when connected to a modem
device through a null-modem cable. (DTR function is on pin I, Ring is an
input).
Maximum input = ± 25V
Minimum Output = ± 5V
Typical Output = ± 7V
CS IO)
Pin 5
Pin 9
COMPUTER
RS232
Pin 1
Pin 6
FIGURE OV1-3. Serial Communication Interfaces
NOTE
Serial communications is not reliable over cable greater than 50
feet in length.
TABLE OV1-2. Computer RS-232 Pin-Out
ABR = Abbreviation for the function name
PIN = Pin number
O = Signal Out of the CR1000 to a RS-232 device
I = Signal Into the CR1000 from a RS-232
device
PIN ABR I/O Description
1 DTR O data terminal ready
2 TX O asynchronous transmit
3 RX I asynchronous receive
4 not connected
5 GND ground
6 O connected to pin
7 CTS I clear to send
8 RTS O request to send
9 RING I ring
The CR1000 is supplied with a six foot 9-pin to 9-pin serial cable and a 9- to
25-pin adapter to facilitate connection to a PC RS-232 port.
OV-5
CR1000 Overview
OV1.3 Power Supply and AC Adapter
The CR1000 requires a separate 12 V power supply. The PS100 power supply
has a 7 amp hour battery with built-in charging regulator. Optional adapters
for AC power are available. Charging power can also come from a 17-28
VDC input such as a solar panel.
OV2. Memory and Operating Concepts
OV2.1 Memory
The CR1000 has two MB Flash EEPROM that is used to store the Operating
System. Another 128 K of Flash is used to store configuration settings. A
minimum of 2 MB SRAM (4 MB optional) is available for program storage
(16K), operating system use, and data storage. The size of available memory
may be seen in the status file. Additional data storage is available by using a
compact flash card in the optional CFM100 Compact Flash Module or NL115
Ethernet Interface and Compact Flash Module.
OV2.2 Programming
The CR1000 program directs how and when the sensors are measured and data
are stored. The program is created on a computer and sent to the CR1000.
The CR1000 can store a number of programs in memory. Campbell Scientific
has two software applications that create CR1000 programs: ShortCut and the
CRBasic Editor.
For many applications ShortCut is a good place to start. With ShortCut you
select the sensors to measure, the units to report the measurements in, and the
data to output. ShortCut supports most of the sensors sold by Campbell
Scientific as well as generic measurements. The CR1000 programs created by
ShortCut are generally clear and provide a good example of CRBasic code for
those who wish to write CR1000 programs themselves.
For those that have the need or inclination to tackle more complex programs,
the CRBasic Editor is used to create and edit the CRBasic programs that the
CR1000 runs. Section 4 provides an introduction to CRBasic Programming.
The CRBasic Editor has syntax highlighting and online help for the CR1000
instruction set described in Sections 5-12.
ShortCut is included with PC200, PC400 and LoggerNet and is available for
free from the Campbell Scientific web site. The CRBasic Editor is included in
PC400 and LoggerNet.
OV2.3 Instruction Execution within the Datalogger
OV-6
The execution of instructions within the datalogger is accomplished using three
separate task types: measurement, SDM, and processing. As it is named, the
measurement task handles measuring the signals received on the datalogger’s
wiring panel, as well as outputting signals for control of other devices. The
measurement and control hardware is manipulated on a rigidly timed sequence.
The SDM task handles the measurement and control of most SDM devices.
CR1000 Overview
The processing task converts the raw signals read by the datalogger into
numbers representing engineering units, performs calculations, stores data,
makes the decisions to actuate controls, and performs serial I/O
communication.
Measurement Task
• Analog Measurements
• Excitation
• Read Pulse Counters
• Read Control Ports
(GetPort)
• Set Control Ports
(SetPort
• VibratingWire
• PeriodAvg
• CS616
• Calibrate
SDM Task
• All SDM instructions,
except SMDSIO4 and
SCMIO16
Processing Task
• Processing
• Output
• Serial I/O
• SDMSIO4
• SDMIO16
• ReadIO
• WriteIO
• Expression evaluation
and variable setting in
measurement and SDM
instructions
The datalogger can execute these tasks in either pipeline or sequential mode.
When a program is compiled the datalogger evaluates the program and
determines which mode to use. This information is included in a message
returned by the datalogger and is displayed by the support software.
CRBasic’s precompiler returns a similar message. A program can be forced to
run in sequential mode by placing the SequentialMode instruction in the
declarations section of the program.
OV2.3.1 Pipeline Mode
In pipeline mode, the measurement task, SDM task, and processing task are
three separate functions. In this mode the three tasks may operate
simultaneously. The measurement tasks are scheduled to take place at exact
times and with the highest priority when the datalogger starts each scan. This
results in a more precise timing of measurements, and may be more efficient
with processing and power consumption. However, this prescheduling of
measurements means measurement instructions must be executed every scan,
and because multiple tasks are taking place at the same time, the sequence in
which the instructions are executed may not be in the exact order in which they
appear in the program. For these reasons, conditional measurements are not
allowed in pipeline mode. Also note that because of the precise execution of
measurement instructions, processing for the measurements in the current scan
(including update of public variables and output to data tables) is delayed until
all measurements are completed.
OV2.3.2 Sequential Mode
In sequential mode the instructions are executed in the sequence they appear in
the program. Sequential mode can be slower than pipeline mode since it does
only one step of the program at a time. After a measurement is made the result
is converted to a value determined by the processing included in the
instruction, and then the datalogger proceeds to the next instruction. Because
of this step-by-step instruction execution, conditional measurements are
allowed in sequential mode. The exact time at which measurements are made
may vary if other measurements or processing are made conditionally, if there
is heavy communications activity or other interrupts (e.g., inserting a CF card).
OV-7
CR1000 Overview
OV2.3.3 Slow Sequence Scans
OV2.3.4 Task Priority
The datalogger allows for one or more scans that are run outside of the
instructions placed between the Scan/NextScan instructions in the main
program. These scans, referred to as slow sequence scans, typically run at a
slower rate than the main scan. Up to four slow sequences can be defined in a
program (slow sequences are declared with the SlowSequence instruction).
Instructions in a slow sequence scan are executed whenever the main scan is
not active. When running in pipeline mode, slow sequence measurements will
be spliced in after measurements in the main program, as time allows. Because
of this splicing, the measurements in a slow sequence may actually span across
multiple main program scan intervals. In sequential mode, all instructions in
the slow sequences are executed as they occur in the program (see Task
Priority, below).
When considering the information above regarding pipeline and sequential
mode, you must also consider that some sequences in the program may have
higher priorities than other sequences in the program, and that measurement
tasks generally take precedence over all others. In addition, the priority of
sequences is different for pipeline mode and sequential mode.
When running in pipeline mode, measurement tasks have priority over all other
tasks. Measurements in the main program have the highest priority, then
background calibration, followed by any measurements in slow sequences that
may be defined. The execution of processing tasks are handled by a task
sequencer, and all tasks are given the same priority. When a condition is true
for a task to start running it is put in a queue (this true condition can be based
on time, the triggering of WaitDigTrig, the expiration of a Delay instruction, or
a ring on a COM port triggering communication). Because all tasks are given
the same priority, the task is put at the back of the queue. Every 10 msec (or
faster if a new task is triggered) the task currently running is paused and put at
the back of the queue, and the next task in the queue begins running. In this
way, all tasks are given equal processing time by the datalogger. The only
exception to this task switching queue is when a measurement task is triggered.
In most instances the processing task and the measurement task should be able
to run in parallel. However, if the datalogger is unable to complete a
measurement when the task sequencer is executing, the task will be interrupted
until the measurement is made.
When running in sequential mode, the datalogger uses a queuing system for
processing tasks similar to the one used in the pipeline mode. The main
difference when running a program in sequential mode is that there is no
prescheduled timing of measurements; instead, all of the instructions are run in
the order they occur in the program. A priority scheme is used to avoid
conflicting use of measurement hardware. In this scheme the main scan has
the highest priority and prevents other sequences from using measurement
hardware until the main scan is completed (including processing). Other tasks,
such as processing from other sequences and communications, can occur while
the main sequence is running. Once the main scan has finished other
sequences have access to measurement hardware with the order of priority
being the background calibration sequence followed by the slow sequences in
the order they are declared in the program. Note that Measurement tasks have
OV-8
CR1000 Overview
priority over other tasks such as processing and communication to allow
accurate timing needed within most measurement instructions, e.g.
integrations.
OV2.4 Data Tables
The CR1000 can store individual measurements or it may use its extensive
processing capabilities to calculate averages, maxima, minima, histograms,
FFTs, etc., on periodic or conditional intervals. Data are stored in tables such
as listed in Table OV2-1. The values to output are selected when running
ShortCut or when writing a datalogger program directly.
Table OV2-1. Typical Data Table
TOA5 Fritz CR1000 1079 CR1000.Std.1.0 CPU:TCTemp.CR1 51399 Temp
TIMESTAMP RECORD RefT_Avg TC_Avg(1) TC_Avg(2) TC_Avg(3) TC_Avg(4) TC_Avg(5) TC_Avg(6)
TS RN degC DegC DegC DegC DegC DegC DegC
Avg Avg Avg Avg Avg Avg Avg
10/28/2004 12:10 119 23.52 23.49 23.49 23.5 23.49 23.5 23.5
10/28/2004 12:20 120 23.55 23.51 23.51 23.51 23.51 23.51 23.52
10/28/2004 12:30 121 23.58 23.52 23.53 23.53 23.53 23.53 23.53
10/28/2004 12:40 122 23.58 23.53 23.54 23.54 23.54 23.54 23.54
OV2.5 PakBus® Communication with the CR1000
The CR1000 uses the PakBus network communications protocol. PakBus
increases the number of communications and networking options available to
the datalogger. In addition to communicating via its RS-232 and/or CS I/O
ports, the CR1000 can also communicate via the digital I/O COM ports.
Some of the advantages of PakBus are:
• Routing – the CR1000 can act as a router, passing on messages intended
for another logger. PakBus supports automatic route detection and
selection.
• Short distance networks with no extra hardware – A CR1000 can talk to
another CR1000 over distances up to 30 feet by connecting 3 wires
between the dataloggers: transmit, receive, and ground. A PC
communicating with one of these loggers (e.g. via a phone modem or RF
to the CS I/O port) can be routed through that datalogger to the other
datalogger.
• Datalogger to datalogger communications – Special PakBus instructions
simplify transferring data between dataloggers for distributed decision
making or control.
All devices that send or receive messages in a PakBus network must have a
unique PakBus Address. The CR1000 default PakBus address is 1. In a
PakBus Network each datalogger must be set to a unique address before it is
installed in the network. To communicate with the CR1000, the PC software
(e.g., LoggerNet) must know the CR1000’s PakBus address.
OV-9
CR1000 Overview
OV2.6 Set up: Device Configuration Utility or Keyboard Display
When you receive a new CR1000 from Campbell Scientific it should be set to
the default PakBus address, 1. If you only have one PakBus datalogger, or will
only communicate with the CR1000 with a direct RS-232 or telephone modem
connection, there may be no need to change the address.
However, if a CR1000 has been in use or someone has borrowed it, you may
need to check what the address is or to set it or some other setting. While there
are a number of ways to do this, the two most basic are to use the Device
Configuration Utility or the Keyboard display.
OV3. Device Configurator
The Device Configuration Utility (DevConfig) sets up dataloggers and
intelligent peripherals before those devices are deployed in the field and before
these devices are added to networks in Campbell Scientific datalogger support
software such as LoggerNet or PC400. Some key features of DevConfig
include:
• DevConfig only supports direct serial connections between the PC and
devices.
• DevConfig can send operating systems to supported device types.
• DevConfig can set datalogger clocks and send program files to
dataloggers.
• DevConfig allows you to determine operating system types and versions
• DevConfig provides a reporting facility where a summary of the current
configuration of a device can be shown on the screen and printed. This
configuration can also be saved to a file and used to restore the settings in
the same or a replacement device.
• Some devices may not support the configuration protocol in DevConfig,
but do allow configurations to be edited through the terminal emulation
screen.
• Help for DevConfig is shown as prompts and explanations on its main
screen. Help for the appropriate settings for a particular device can also be
found in the user’s manual for that device.
• Updates to DevConfig are available from Campbell Scientific's web site.
These may be installed over top of older versions.
OV3.1 Main DevConfig Screen
OV-10
The DevConfig window is divided into two main sections: the device selection
panel on the left side and tabs on the right side. After choosing a device on the
left, you will then have a list of the serial ports (COM1, COM2, etc.) installed
on your PC. You’ll be offered a choice of baud rates only if the device
supports more than one baud rate in its configuration protocol. The page for
CR1000 Overview
each device presents instructions about how to set up the device to
communicate with DevConfig. Different device types will offer one or more
tabs on the right.
When the user presses the Connect button, the device type, serial port, and
baud rate selector controls become disabled and, if DevConfig is able to
connect to the CR1000, the button will change from "Connect" to
"Disconnect". The Display will change to:
OV-11
CR1000 Overview
OV3.2 Deployment Tab
OV3.2.1 Datalogger
The Deployment Tab allows the user to configure the datalogger prior to
deploying it.
Serial Number displays the CR1000 serial number. This setting is set at the
factory and cannot be edited.
OS Version displays the operating system version that is in the CR1000.
Station Name displays the name that is set for this station.
PakBus Address allows you to set the PakBus address of the datalogger. The
allowable range is between 1 and 4094. Each PakBus device should have a
unique PakBus address. Addresses >3999 force other PakBus devices to
respond regardless of their respective PakBus settings. See the PakBus
Networking Guide for more information.
Security:
Up to three levels of security can be set in the datalogger. Level 1 must be set
before Level 2 can be set, and Level 2 must be set before Level 3 can be set. If
a level is set to 0, any level greater than it will also be set to 0 (e.g., if Level 2
is 0, Level 3 is 0). Valid security codes are 1 through 65535 (0 is no security).
Each level must have a unique code. Functions affected by each level of
security are:
Security Password 1 When this level is set, collecting data, setting the
clock, and setting variables in the Public table are unrestricted, requiring no
security code. If the user enters the Security1 code, the datalogger program
can be changed or retrieved or variables can be set in the Status table.
Security Password 2 When this level is set, data collection is
unrestricted, requiring no security code. If the user enters the Security2 code,
the datalogger clock can be changed and variables in the public table can be
changed. If the user enters the Security1 code, non-read-only values in the
status table can be changed and the datalogger program can be changed or
retrieved.
Security Password 3 When this level is set, all communication with the
datalogger is prohibited if no security code is entered. If the user enters the
Security3 code, data can be collected from the datalogger. If the user enters
the Security2 code, data can be collected, public variables can be set, and the
clock can be set. If the user enters the Security 1 code, all functions are
unrestricted.
OV-12
OV3.2.2 Ports Settings
CR1000 Overview
Selected Port specifies the datalogger serial port to which the beacon interval
and hello setting values will be applied.
Beacon Interval sets the interval (in seconds) on which the datalogger will
broadcast beacon messages on the port specified by Selected Port.
Verify Interval specifies the interval (in seconds) at which the datalogger will
expect to have received packets from neighbors on the port specified by
Selected Port. A value of zero (default) indicates that the datalogger has no
neighbor list for this port.
Neighbors List, or perhaps more appropriately thought of as the “expected
neighbors list”, displays the list of addresses that this datalogger expects to find
as neighbors on the port specified by Selected Port. As you select items in this
list, the values of the Begin and End range controls will change to reflect the
selected range. You can add multiple lists of neighbors on the same port.
Begin and End Range are used to enter a range of addresses that can either be
added to or removed from the neighbors list for the port specified by Selected
Port. As you manipulate these controls, the Add range and Remove Range
buttons will be enabled or disabled depending on the relative values in the
controls and whether the range is present in or overlaps with the list of address
ranges already set up. These controls will be disabled if the Verify Interval
value is set to zero.
Add Range will cause the range specified in the Begin and End range to be
added to the list of neighbors to the datalogger on the port specified by
Selected Port. This control will be disabled if the value of the Verify Interval
is zero or if the end range value is less than the begin range value.
OV-13
CR1000 Overview
OV3.2.3 Advanced
Remove Range will remove the range specified by the values of the Begin and
End controls from the list of neighbors to the datalogger on the port specified
by Selected Port. This control will be disabled if the range specified is not
present in the list or if the value of Verify Interval is set to zero.
Help is displayed at the bottom of the Deployment tab. When you’re finished,
you must Apply to send the settings to the datalogger. The Summary window
will appear and you can Save or Print the settings for your records or to use
them as a template for another datalogger.
Cancel causes the datalogger to ignore the changes. Read File gives you the
opportunity to load settings saved previously from this or another similar
datalogger. If you load settings from a file, the changes will not actually be
written to the datalogger until you click Apply.
OV-14
Is Router allows you to control whether the datalogger will act as a PakBus
router.
PakBus Nodes Allocation Specifies the amount of memory that the CR1000
Allocates for maintaining PakBus Routing information. This value represents
roughly the maximum number of PakBus Nodes that the CR1000 will be able
to track in its routing tables.
OV3.3 Logger Control Tab
CR1000 Overview
The clock in the PC and the datalogger will be checked every second and the
difference displayed. The System Clock Setting allows you to configure what
offset, if any, should be used with respect to standard time (Local Daylight
Time or UTC, Greenwich mean time). The value selected for this control will
be remembered between sessions. Clicking the Set Clock Button will
synchronize the station clock to the current computer system time.
Current Program displays the current program known to be running in the
datalogger. This value will be empty if there is no current program.
The Last Compiled field displays the time when the currently running
program was last compiled by the datalogger. As with the Current Program
field, this value will be read from the datalogger if it is available.
Last Compile Results shows the compile results string as reported by the
datalogger.
The Send Program button presents an open file dialogue from which you can
select a program file to be sent to the datalogger. The field above the button
will be updated as the send operation progresses. When the program has been
sent the Current Program, Last Compiled, and Last Compile Results fields will
be filled in.
OV-15
CR1000 Overview
OV3.4 Send OS Tab - Downloading an Operating System
DevConfig can send operating systems to all Campbell Scientific devices with
flash replaceable operating systems. An example for the CR1000 is shown
below:
The text at right gives the instructions for downloading the OS. Follow these
instructions.
When you click the Start button, DevConfig offers a file open dialog box to
prompt you for the operating system file (*.obj file). When the CR1000 is then
powered-up, DevConfig starts to send the operating system:
When the operating system has been sent, a message dialog will appear similar
to the one shown below:
The information in the dialog helps to corroborate the signature of the
operating system sent. For devices such as the CR10X (especially those with
extended memory) that can take a long time to reset following an OS
download, text warns you against interrupting the memory test.
OV-16
OV3.5 Settings Editor Tab
The CR1000 has a number of properties, referred to as “settings”, some of
which are specific to the PakBus protocol. PakBus is discussed in more detail
in the PakBus Networking Guide
website (www.campbellsci.com).
The Settings Editor tab provides access to most of the PakBus settings,
however, the Deployment tab makes configuring some of these settings a bit
easier.
CR1000 Overview
available from the Campbell Scientific
The top of the Settings Editor is a grid that allows the user to view and edit the
settings for the device. The grid is divided into two columns with the setting
name appearing in the left hand column and the setting value appearing in the
right hand column. You can change the currently selected cell with the mouse
or by using the up arrow and down arrow keys as well as the Page Up and
Page Down keys. If you click in the setting names column, the value cell
associated with that name will automatically be made active. You can edit a
setting by selecting the value, pressing the F2 key or by double clicking on a
value cell with the mouse. The grid will not allow read-only settings to be
edited.
The bottom of the Settings Editor displays help for the setting that has focus on
the top of the screen.
Once you have changed a setting, you can Apply them to the device or
Cancel. These buttons will only become enabled after a setting has been
changed. If the device accepts the settings, a configuration summary dialogue
will be shown that will give the user a chance to save and/or print the settings
for the device:
OV-17
CR1000 Overview
Clicking the Revert to Defaults button on the Settings Editor will send a
command to the device to revert to its factory default settings. The reverted
values will not take effect until the final changes have been applied. This
button will remain disabled if the device does not support the DevConfig
protocol messages.
If, after changing a setting or clicking the Summary button, you clicked Save
on the summary screen to save the configuration, you can use the Read File
button to load those settings. The settings from the saved file are immediately
sent to the device and, if they’re accepted, you can then Apply them.
OV3.6 Terminal Tab
The Terminal tab offers a terminal emulator that can be used to access the
CR1000 Terminal Mode. Press “Enter” several times until the CR1000
terminal mode prompt: “CR1000>“ is returned. Terminal mode commands
consist of a single character and “Enter”. For example, sending an “H” and
“Enter” will return a list of the terminal commands.
OV-18
CR1000 Overview
OV4. Quick Start Tutorial
OV4.1 Software Products for the CR1000
PC200W Starter Software supports a direct connection between the PC and the
CR1000, and includes Short Cut for Windows (Short Cut) for creating CR1000
programs. PC200W provides basic tools for setting the datalogger’s clock,
sending a program, monitoring sensors, and manually collecting and viewing
data. CR1000 support was added to PC200W in Version 3.0. PC200W is
available at no charge from the Campbell Scientific website.
PC400 Datalogger Support Software (mid-level software) supports a variety of
telecommunication options, manual data collection, and data display. PC400
includes Short Cut and the CRBasic Program Editor for creating CR1000
programs. PC400 does not support combined communication options (e.g.,
phone-to-RF), PakBus® routing, or scheduled data collection.
LoggerNet Datalogger Support Software (full-featured software) supports
combined telecommunication options, data display, and scheduled data
collection. The software includes Short Cut and CRBasic for creating CR1000
programs, and tools for configuring, trouble-shooting, and managing
datalogger networks.
OV4.1.1 Options for Creating CR1000 Programs
1. Short Cut is a program generator that creates a datalogger program in four
easy steps, and a wiring diagram for the sensors. Short Cut supports the
majority of sensors sold by Campbell Scientific, and is recommended for
creating straightforward programs that measure the sensors and store data.
OV-19
CR1000 Overview
OV4.2 Connections to the CR1000
2. The CRBasic Editor is a program editor used to create more complex
CR1000 programs. Short Cut generated programs can be imported into
the CRBasic Editor for adding instructions, or for functionality not
supported by Short Cut.
For those users of CR10X dataloggers who are switching to CR1000
dataloggers, the Transformer Utility can be used to convert a CR10X program
to a CR1000 program, which can be imported into the CRBasic Editor.
Because of differences in program code, not all CR10X programs can be fully
converted by the Transformer. The Transformer Utility is included with
PC400 and LoggerNet software.
Campbell Scientific Power Supplies are described in Section 1.3. When
connecting power to the CR1000, first remove the green power connector from
the CR1000 front panel. Insert the positive 12V lead into the terminal labeled
“12V”, and the ground lead into the terminal labeled “G”. Double-check the
polarity before plugging the green connector into the panel.
Connect the white serial cable (PN 10873, provided) between the port labeled
“RS-232” on the CR1000 and the serial port on the computer. For computers
that have only a USB port, a USB Serial Adaptor (PN 17394 or equivalent) is
required.
OV-20
FIGURE OV4-1. Power and RS-232 Connections
OV4.3 Setting the CR1000 PakBus Address
The CR1000 default PakBus address is 1 (Section OV2.5). Unless the
CR1000 is used in a network, there is no need to change the Pakbus address, or
any of the other default settings. To change settings, the Device Configuration
Utility (DevConfig) is used, as described in Section 0V3.
OV4.4 PC200W Software
This Quick-Start tutorial prompts the user through the process of programming
the CR1000, monitoring sensor measurements, collecting data, and viewing
data using the PC200W software.
When PC200W is first started, the EZSetup Wizard is launched. Click the
Next button and follow the prompts to select the CR1000, the COM port on
the computer that will be used for communications, 115200 baud, and Pakbus
Address 1. When prompted with the option to Test Communications click
the Finish button.
To change a setting in the datalogger setup, select that datalogger from the
main window, and click the Edit button. If a datalogger was not added with
the Wizard, click the Add button to invoke the Wizard.
CR1000 Overview
After exiting the EZSetup wizard, the Setup/Connect window appears, as
shown below. The Current Datalogger Profile, Datalogger Clock, and
Datalogger Program features of PC200W are integrated into this window.
Tabs to the right are used to select the Monitor Values and Collect Data
windows. Buttons to the right of the tabs are used to run the Split, View, and
Short Cut applications.
Short Cut
OV-21
CR1000 Overview
OV4.4.1 Creating a CR1000 Program using Short Cut
Objective: Every one second, measure air temperature in degrees C with a
Type T thermocouple, and store one-minute average Battery Voltage, Panel
Temperature, and Thermocouple temperature.
NOTE
A Type T Thermocouple is included with CR1000, packaged
with the screwdriver. The thermocouple consists of a pair of
5-inch wires with blue/red insulation, soldered together at one
end.
Click on the Short Cut button to display the Home screen, as shown below.
OV-22
Each of the four steps has a button with a ? for accessing Help. Use the Help
in conjunction with the steps outlined below:
Step 1: Create a New File
Step 1 is to open a new or existing file. From the Home page, click the New
button. Use the drop-down list box to select the CR1000. Enter a 1 second
Scan Interval and click OK to complete Step 1.
Step 2: Select the Sensors
A Type T thermocouple consists of two wires of dissimilar metals (copper and
constantan) soldered together at one end. The soldered end is the measurement
junction; the junction that is created when the thermocouple is wired to the
CR1000 is the reference junction.
When the two junctions are at different temperatures, a voltage proportional to
the temperature difference is induced into the wires. The thermocouple
measurement requires the reference junction temperature to calculate the
measurement junction temperature.
CR1000 Overview
Step 2 is to select the sensors to be measured. From the Home page, click the
Sensors button. The Sensors worksheet is divided into two sections: the
Available sensors tree and the Selected sensors table, as shown below. The
sensors you want to measure are chosen from the Available sensors tree.
Double click on the Temperature application group to display the available
sensors. Double click on the Wiring Panel Temperature sensor to add it the
selected sensors table. Click OK on the next screen to accept the PTemp_C
label.
Double click on the Type T thermocouple, change the number to 1 and click
OK. On the next screen, make sure Ptemp_C is selected for the Reference
Temperature Measurement, and click OK to accept the Temp_C label.
OV-23
CR1000 Overview
Click on the Wiring Diagram tab to view the sensor wiring diagram, as shown
below. Wire the Type T Thermocouple (provided) to the CR1000 as shown on
the diagram. Click the Sensors tab and the Home button to return to the Home
page to continue with Step 3.
Step 3: Output Processing
Step 3 is to define the output processing for the sensor measurements. From
the Home page, click the Output button.
The Output screen has a list of Selected Sensors on the left, and Output Tables
on the right. The default is for two Tables, Table1 and Table2. Both Tables
have a Store Every field and the drop-down list box that are used to set the
interval at which data will be stored.
The objective for this exercise calls for a one-minute output processing. To
remove Table2, Click on the Table2 tab to activate it, and click the Delete
Table button.
The Table Name field is the name that will be used for the Table in which the
output will be stored. Change the default Name of Table1 to OneMin, and
change the interval to 1 minute.
The Selected Sensors list is provided on the left side of the screen. To add a
sensor measurement to the Output Table, highlight a measurement and click
one of the output buttons; e.g., Average. Select the Default, Panel Temp, and
Type T TC sensors and click the Average button to add them to the OneMin
Table.
OV-24
CR1000 Overview
Click the Home button to continue with Step 4 to complete the program.
Step 4: Finish
Step 4 is to finish the program. From the Home page, click the Finish button.
Type in QuickStart for the file name. Any errors the compiler may have
detected are displayed, along with the names of the files that were created.
The file QuickStart.CR1 is the program file that will be sent to the CR1000,
QuickStart.def is a summary of the sensor wiring and measurement labels
(click the Summary or Print buttons to view or print the file). Click the OK
button and close Short Cut.
OV-25
CR1000 Overview
OV4.4.2 Configuring the Setup Tab
Connect Button
From the Setup/Connect screen, click on the Connect button to establish
communications with the CR1000. When communications have been
established, the text on the button will change to Disconnect.
OV4.4.3 Synchronize the Clocks
Click the Set Clock button to synchronize the datalogger’s clock with the
computer’s clock.
OV4.4.4 Send the Program
Click the Select and Send Program button. Navigate to the
C:\CampbellSci\SCWin folder and select the file QuickStart.CR1 and click the
Open button. A progress bar is displayed, followed by a message that the
program was successfully sent.
OV4.4.5 Monitor Data Tables
The Monitor Values window is used to display the current sensor measurement
values from the Public Table, and the most recent data from the OneMin Table.
Click on the Monitor Values tab. The Public Table is automatically selected
and displayed. To view the OneMin Table, click the Add button, select the
OneMin Table, and click the Paste button.
OV-26
CR1000 Overview
OV4.4.6 Collect Data
Click on the Collect Data tab. From the Collect Data window you can choose
what data to collect, and where to store the retrieved data.
Click on the OneMin Table, with the Option New data from datalogger
selected. Click the Collect button and a dialog box appears, prompting for a
file name. Click the Save button to use the default file name
CR1000_OneMin.dat. A progress bar, followed by the message Collection
Complete is displayed.
OV-27
CR1000 Overview
OV4.4.7 View Data
To view the collected data, click on the View button (located in the upper right
hand corner of the main screen). Options are accessed by using the menus or
by selecting the toolbar icons. If you move and hold the mouse over a toolbar
icon for a few seconds, a brief description of that icon's function will appear.
To open a data file, click the Open file icon, and double click on the file
CR1000_OneMin.dat in the PC200W folder. Click the Expand Tabs icon to
display the data in columns with column headings. To graph thermocouple
temperature, click on the data column with the heading Temp_C, then click the
Show Graph, 1 Y axis icon on the toolbar.
Open file Expand tabs
Show graph
OV-28
Close the graph and view screens, and close PC200W.
CR1000 Overview
OV4.5 Programming using the CRBasic Program Editor
Those users who are moving from the Edlog Program Editor to the CRBasic
Program Editor may find Short Cut to be an excellent way to learn CRBasic.
First create a program using Short Cut, then open the file with CRBasic to see
how Short Cut created the program. The program file listed below is the Short
Cut file QuickStart.CR1 from the tutorial after being imported into the
CRBasic editor.
See Section 4 for information on the CRBasic programming.
'CR1000
'Declare Variables and Units
Public Batt_Volt
Public PTemp_C
Public Temp_C
Units Batt_Volt=Volts
Units PTemp_C=Deg C
Units Temp_C=Deg C
'Define Data Tables
DataTable(OneMin,True,-1)
DataInterval(0,1,Min,0)
Average(1,Batt_Volt,FP2,False)
Average(1,PTemp_C,FP2,False)
Average(1,Temp_C,FP2,False)
EndTable
DataTable(Table1,True,-1)
DataInterval(0,1440,Min,0)
Minimum(1,Batt_Volt,FP2,False,False)
EndTable
'Main Program
BeginProg
Scan(5,Sec,1,0)
'Default Datalogger Battery Voltage measurement Batt_Volt:
Battery(Batt_Volt)
'Wiring Panel Temperature measurement PTemp_C:
PanelTemp(PTemp_C,_60Hz)
'Type T (copper-constantan) Thermocouple measurements Temp_C:
TCDiff(Temp_C,1,mV2_5C,1,TypeT,PTemp_C,True,0,_60Hz,1,0)
'Call Data Tables and Store Data
CallTable(OneMin)
CallTable(Table1)
NextScan
EndProg
OV-29
CR1000 Overview
OV5. Keyboard Display
The CR1000 has an optional keyboard display. This section illustrates the use
of the CR1000KD.
The CR1000KD has a few keys that have special functions which are listed
below.
Key Usage
[2] and [8] To navigate up and down through the menu list one line at a time
[Enter] Selects the line or toggles the option of the line the cursor is on
[Esc] Backs up one level in the menu
[Home] Moves cursor to top of the list
[End] Moves cursor to bottom of the list
[Pg Up] Moves cursor up one screen
[Pg Dn] Moves cursor down one screen
[BkSpc] Delete character to the left
[Shift] Change alpha character selected
[Num Lock] Change to numeric entry
[Del] Delete
[Ins] Insert/change graph setup
[Graph] Graph
OV-30
CR1000 Overview
Power Up Screen
Press any key
CAMPBELL
SCIENTIFIC
CR1000 Datalogger
06/18/2000, 18:24:35
CPU: TRIG.CR1
Running.
for Main Menu
(except <, >, ^.
or [Esc])
Data
Run/Stop Program
File
PCCard
Ports and Status
Configure, Settings
CR1000 Display
Toggle backlight with ^
Adjust contrast with < >
< lighter darker >
Real Time Tables
Real Time Custom
Final Storage Data
Reset Data Tables
Graph Setup
Options depend on
program state
New
Edit
Copy
Delete
Run Options
Directory
Format
Active Tables
Format Card
PCCard is only in the menu if a
CFM100 is attached, and it has a
card in it.
OSVersion : xxxx
OSDate : xxxx
OSSignature : xxxx
SerialNumber : xxxx
RevBoard : xxxx
StationName : xxxx
PakBusAddress : xxxx
ProgName : xxxx
PakBus
Configure Display
Set Time
OV-31
CR1000 Overview
OV5.1 Data Display
Data
Run/Stop Program
File
PCCard
Ports and Status
Configure, Settings
Move the cursor
to Data and
press Enter
Real Time Tables
Real Time Custom
Final Storage Data
Reset Data Tables
Graph Setup
List of Data Tables created by
active program
List of Data Tables created by
active program
List of Data Tables created by
active program
All Tables
List of Data Tables created by
active program
OV-32
Graph Type Roll
Scaler Manual
Upper: 0.000000
Lower: 0.000000
Display Val On
Display Max On
Display Min On
Scope requires manual scalar
}
Roll/Scope
Manual/Auto
Not shown if “Auto”
On/Off
On/Off
On/Off
OV5.1.1 Real Time Tables
List of Data Tables created by
active program. For Example,
Public
Table1
Temps
Move the cursor to
desired table and
press Enter
Tref : 23.0234
TCTemp(1) : 19.6243
TCTemp(2) : 19.3429
TCTemp(3) : 21.2003
TCTemp(3) :
Flag(1) : -1.0000
Flag(2) : 0.00000
Flag(3) : 0.00000
Flag(4) : 0.00000
Public Table values
can be changed.
Move the cursor to
value and press
Enter to edit value.
CR1000 Overview
Edit field: Num
TCTemp(3)
Current Value:
21.2003
New Value:
Press Graph for
graph of selected
field
30.0 22.35
_____
___ ____
__
20.00
New values are displayed as they
are stored.
Move the cursor to setting
and press Enter to change
Press Ins for
Graph Setup
Scaler Manual
Upper: 30.000000
Lower: 20.000000
Display Val On
Display Max On
Display Min On
Graph Type Roll
Auto/Manual
On/Off
On/Off
On/Off
Roll/Scope
OV-33
CR1000 Overview
OV5.1.2 Real Time Custom
List of Data Tables created by
active program. For Example,
Move the cursor to
desired table and
press Enter
The first time you navigate to Real Time Custom you will need to set up the
display. The CR1000 will keep the setup as long as the same program is
running.
Public
Table1
Temps
Tref
TCTemp(1)
TCTemp(2)
TCTemp(3)
TCTemp(3)
Flag(1)
Flag(2)
Flag(3)
Flag(4)
Move the cursor to
desired field and
press Enter
TCTemp(3) : 24.9496
:
:
:
:
:
:
:
To add value, move the cursor to
position for the value and press
Enter
OV-34
New values are displayed as they
are stored.
To delete a field, move the cursor to
that field and press Del
CR1000 Overview
∧
OV5.1.3 Final Storage Tables
List of Data Tables created by
active program. For Example:
Move the cursor to
desired Table and
press Enter
TimeStamp Record Tref TC(1) TC(2) TC(3)
"2000-01-03 00:12:38" 0 21.934 22.8419
"2000-01-03 00:12:39" 1 24.1242 21.8619 21.9173 22.8364
"2000-01-03 00:12:40" 2 24.1242 21.8786 21.9229 22.8364
"2000-01-03 00:12:41" 3
"2000-01-03 00:12:42" 4
"2000-01-03 00:12:43" 5
"2000-01-03 00:12:44" 6
"2000-01-03 00:12:45" 7
"2000-01-03 00:12:46" 8
"2000-01-03 00:12:47" 9 24.1242 21.8176 21.9118 22.8308
"2000-01-03 00:12:48" 10 24.1242 21.8342 21.945 22.8364
"2000-01-03 00:12:49" 11 24.1242 21.8453 21.9506 22.8364
Press Graph for graph of
selected field or for full
screen display of string
←, →
data. Use
, PgUp,
PgDn to move cursor
and window of data
graphed.
Table1
Temps
Use Home (oldest), End (newest),
PgUp (older), PgDn (newer),
←, →, ↑
data table.
5 :2000-01-03 00:12:43
Tref TC(1)
24.1242 : 21.8786
24.1242 : 21.8786
24.1242 : 21.8675
24.1242 : 21.8675
24.1242 : 21.8675
24.1242 : 21.8398
, and ↓ to move around in
21.8675
21.9173 22.8419
21.9173 22.8253
21.9118 22.8364
21.9173 22.8087
21.9173 22.8142
21.9395 22.8253
Press Ins for Jump To screen.
Go to Record:
5
∨
press Ins to edit
Table Size:
1000
Current Record:
759
Use arrow up
or down to
scroll to the
record number
wanted, or
press Ins and
manually type
in the record
number.
30.0 21.87
_______
______ _______
____ ___ ____
__
20.00
Press Ins for
Graph Setup
Scaler Manual
Upper: 30.000000
Lower: 20.000000
Display Val On
Display Max On
Display Min On
Graph Type Roll
OV-35
CR1000 Overview
r
r
OV5.2 Run/Stop Program
Data
Run/Stop Program
File
PCCard
Ports and Status
Configure, Settings
Move the curso
to run/stop program
and press Ente
.
If program
is running
CPU: ProgramName.CR1
Is Running
>* Run on Power Up
Stop, Retain Data
Stop, Delete Data
Restart, Retain Data
Restart, Delete Data
Execute
}
Select 1 (press Enter)
and move the cursor
to Execute. Press
Enter to execute.
If program
is stopped
No program
running or
stopped
Press escape to cancel or get list of
available programs.
CPU: ProgramName.CR1
Is Stopped
>* Run on Power Up
Stop, Delete Data
Restart, Retain Data
Restart, Delete Data
Execute
Press escape to cancel or get list of
available programs.
CPU:
CRD:
or list of program
files on CPU if no
card is present
Press escape to cancel.
}
Select 1 (press Enter)
and move the cursor
to Execute. Press
Enter to execute.
Select location of
program file.
OV-36
OV5.3 File Display
Data
Run/Stop Program
File
PCCard
Ports and Status
Configure, Settings
Move the cursor
to File and
press Enter
New
Edit
Copy
Delete
Run Options
Directory
Format
CR1000 Overview
New File Name:
CPU: .CR1
CRD: .CR1
CPU:
CRD:
Copy
From
To
Execute
List of files on
CPU or Card.
OV-37
CR1000 Overview
OV5.3.1 File: Edit
The CRBasic Program Editor is recommended for writing and editing
datalogger programs. Changes in the field can be made with the keyboard
display.
List of Program files on CPU: or
CRD: For Example:
CPU:
TCTEMP.CR1 0
RACE.CR1 0
Move the cursor to desired
Program and press Enter
CR1000
' TCTemp.CR1
Public TREF,TC(3),FLAG(8)
D ataTable (Temps,1,1000)
D
Sample (1,TREF,IEEE4)
Sample (3,TC(),IEEE4)
Edit Directly or move cursor
to first character of line and
press Enter
ENTER
Edit Instruction
Blank Line
Create Block
ESC
Press Ins
Save Changes?
Yes
No
INSERT
Instruction
Function
Blank Line
Block
Insert Off
Edit Instruction parameters with
parameter names and some pick lists:
DataTable
TableName
> Temps
TrigVar
1
Size
1000
OV-38
DataTable (Temps,1,1000)
DataTable (Temps,1,1000)
Sample (1,TREF,IEEE4)
Sample (3,TC(),IEEE4)
EndTable
BeginProg
Scan(1,sec,3,0)
Move the cursor
to highlight
desired block and
press Enter
Insert blank line
Block Commands
Copy
Cut
Delete
To insert a block created by this
operation, move the cursor to
desired place in program and press
Ins.
OV5.4 PCCard Display
Data
Run/Stop Program
File
PCCard
Ports and Status
Configure, Settings
Move the cursor
to PCCard and
press Enter
CR1000 Overview
PCCard is only in menu if
CFM100 is attached and a
CF card is inserted.
List of Data Tables on card
used by active program
Active Tables
Format Card
All Card Data
Will be Lost!
Proceed?
Yes
No
OV-39
CR1000 Overview
OV5.5 Ports and Status
Ports
Status Table
PortStatus (1): OFF
PortStatus (2): OFF
PortStatus (3): OFF
PortStatus (4): OFF
PortStatus (5): OFF
PortStatus (6): OFF
PortStatus (7): OFF
PortStatus (8): OFF
Move the cursor to the desired port
and press Enter to toggle OFF/ON.
The port must be configured as an
output to be toggled.
List of Status Variables
(see Appendix A)
OV-40
OV5.6 Settings
CR1000 Overview
Set Time/Date
Settings
Display
05/24/2000, 15:10:40
Year 2000
Month 5
Day 24
Hour 15
Minute 10
Set
Cancel
Routes : xxxx
StationName : xxxx
PakBusAddress : xxxx
Security(1) : xxxx
Security(2) : xxxx
Security(3) : xxxx
IsRouter : xxxx
PakBusNodes : xxxx
Turn Off Display
Back Light
Contrast Adjust
Display Timeout: Yes
Timeout (min): 4
OV5.6.1 Set Time/Date
Move the cursor to time element and press Enter to change it. Then move the
cursor to Set and press Enter to apply the change.
OV5.6.2 PakBus Settings
In the Settings menu, move the cursor to the PakBus element and press Enter
to change it. After modifying, press Enter to apply the change.
Move the cursor to time element
and press Enter to change
OV-41
CR1000 Overview
OV5.6.3 Configure Display
Set Time/Date
Settings
Display
Move the cursor to
Configure Display
and press Enter
Press Enter to turn off Display
On/Off
Turn Off Display
Backlight
Contrast Adjust
Display Timeout: Yes
Timeout (min): 4
Light Dark
<- * ->
Yes/No
Enter display timeout in minutes (max = 60)
OV-42
CR1000 Overview
OV6. Specifications
Electrical specifications are valid over a -25° to +50°C range unless otherwise specified; non-condensing environment
required. To maintain electrical specifications, Campbell Scientific recommends recalibrating dataloggers every two years.
PROGRAM EXECUTION RATE
10 ms to 30 min. @ 10 ms increments
ANALOG INPUTS
8 differential (DF) or 16 single-ended (SE) individually
configured. Channel expansion provided by AM16/32
and AM25T multiplexers.
RANGES and RESOLUTION: Basic resolution
(Basic Res) is the A/D resolution of a single
conversion. Resolution of DF measurements
with input reversal is half the Basic Res.
Input DF Basic
Range (mV)
±5000 667 1333
±2500 333 667
±250 33.3 66.7
±25 3.33 6.7
±7.5 1.0 2.0
±2.5 0.33 0.67
1
Range overhead of ~9% exists on all ranges to guarantee
that full-scale values will not cause over-range.
2
Resolution of DF measurements with input reversal.
ACCURACY3:
±(0.06% of reading + offset), 0° to 40°C
±(0.12% of reading + offset), -25° to 50°C
±(0.18% of reading + offset), -55° to 85°C
3
The sensor and measurement noise are not included and
the offsets are the following:
Offset for DF w/input reversal = 1.5·Basic Res + 1.0 µV
Offset for DF w/o input reversal = 3·Basic Res + 2.0 µV
Offset for SE = 3·Basic Res + 3.0 µV
INPUT NOISE VOLTAGE: For DF measurements
with input reversal on ±2.5 mV input range; digital
resolution dominates for higher ranges.
250 µs Integration: 0.34 µV RMS
50/60 Hz Integration: 0.19 µV RMS
MINIMUM TIME BETWEEN VOLTAGE
MEASUREMENTS: Includes the measurement time
and conversion to engineering units. For voltage
measurements, the CR1000 integrates the input
signal for 0.25 ms or a full 16.66 ms or 20 ms line
cycle for 50/60 Hz noise rejection. DF measure-
s with input reversal incorporate two integra-
ment
tions with reversed input polarities to reduce thermal
offset and common mode errors and therefore take
twice as long.
250 µs Analog Integration: ~1 ms SE
1/60 Hz Analog Integration: ~20 ms SE
1/50 Hz Analog Integration: ~25 ms SE
COMMON MODE RANGE: ±5 V
DC COMMON MODE REJECTION: >100 dB
NORMAL MODE REJECTION: 70 dB @ 60 Hz
when using 60 Hz rejection
SUSTAINED INPUT VOLTAGE W/O DAMAGE:
±16 Vdc max.
INPUT CURRENT: ±1 nA typical, ±6 nA max.
@ 50°C; ±90 nA @ 85°C
INPUT RESISTANCE: 20 Gohms
ACCURACY OF BUILT-IN REFERENCE JUNCTION
THERMISTOR (for thermocouple measurements):
±0.3°C, -25° to 50°C
±0.8°C, -55° to 85°C (-XT only)
ANALOG OUTPUTS
3 switched voltage, active only during measurement,
one at a time.
RANGE AND RESOLUTION: Voltage outputs programmable between ±2.5 V with 0.67 mV resolution.
ACCURACY: ±(0.06% of setting + 0.8 mV), 0° to 40°C
±(0.12% of setting + 0.8 mV), -25° to 50°C
±(0.18% of setting + 0.8 mV), -55° to 85°C (-XT only)
Input Referred Noise Voltage
1
Res (µV)2 Res (µV)
typical
CURRENT SOURCING/SINKING: ±25 mA
RESISTANCE MEASUREMENTS
MEASUREMENT TYPES: The CR1000 provides
ratiometric measurements of 4- and 6-wire full
bridges, and 2-, 3-, and 4-wire half bridges.
Precise, dual polarity excitation using any of the
3 switched voltage excitations eliminates dc errors.
RATIO ACCURACY
at least 1000 mV, not including bridge resistor error.
±(0.04% of voltage reading + offset)/V
3
The sensor and measurement noise are not included and
the offsets are the following:
Offset for DF w/input reversal = 1.5·Basic Res + 1.0 µV
Offset for DF w/o input reversal = 3·Basic Res + 2.0 µV
Offset for SE = 3·Basic Res + 3.0 µV
Offset values are reduced by a factor of 2 when
excitation reversal is used.
PERIOD AVERAGING MEASUREMENTS
The average period for a single cycle is determined by
measuring the average duration of a specified number
of cycles. The period resolution is 192 ns divided by
the specified number of cycles to be measured; the
period accuracy is ±(0.01% of reading + resolution).
Any of the 16 SE analog inputs can be used for period
averaging. Signal limiting a
SE analog channel.
INPUT FREQUENCY RANGE:
Input Signal (peak to peak)4Min. Max
Range Min Max Pulse W. Freq.
±2500 mV 500 mV 10 V 2.5 µs 200 kHz
±250 mV 10 mV 2 V 10 µs 50 kHz
±25 mV 5 mV 2 V 62 µs 8 kHz
±2.5 mV 2 mV 2 V 100 µs 5 kHz
4
The signal is centered at the datalogger ground.
5
The maximum frequency = 1/(Twice Minimum Pulse Width)
for 50% of duty cycle signals.
PULSE COUNTERS
Two 24-bit inputs selectable for switch closure, high
frequency pulse, or low-level ac.
MAXIMUM COUNTS PER SCAN: 16.7x10
SWITCH CLOSURE MODE:
Minimum Switch Closed Time: 5 ms
Minimum Switch Open Time: 6 ms
Max. Bounce Time: 1 ms open w/o being counted
HIGH FREQUENCY PULSE MODE:
Maximum Input Frequency: 250 kHz
Maximum Input Voltage: ±20 V
Voltage Thresholds: Count upon transition from
below 0.9 V to above 2.2 V after input filter with
1.2 µs time constant.
LOW LEVEL AC MODE: Internal ac coupling removes
dc offsets up to ±0.5 V.
t Hysteresis: 16 mV @ 1 Hz
Inpu
Maximum ac Input Voltage: ±20 V
Minimum ac Input Voltage:
Sine wave (mV RMS) Range (Hz)
20 1.0 to 20
200 0.5 to 200
2000 0.3 to 10,000
5000 0.3 to 20,000
DIGITAL I/O PORTS
8 ports software selectable, as binar y inputs or control
outputs. C1-C8 also provide edge timing, subroutine
interrupts/wake up, switch closure pulse counting, high
frequency pulse counting, asynchronous communications (UART), SDI-12 communications, and SDM
communications.
HIGH FREQUENCY MAX: 400 kHz
3
: Assuming excitation voltage of
x
re typically required for the
6
SWITCH CLOS
OUTPUT VOLTAGES (no load): high 5.0 V ±0.1 V;
low <0.1
OUTPUT RESISTANCE: 330 ohms
INPUT STATE: high 3.8 to 5.3 V; low -0.3 to 1.2 V
INPUT HYSTERISIS: 1.4 V
INPUT RESISTANCE: 100 kohms
SWITCHED 12 V
One independent 12 V unregulated sources switched
on and off under program control. Thermal fuse hold
current = 900 mA @ 20°C, 650 mA @ 50°C, 360 mA
@ 85°C.
SDI-12 INTERFACE SUPPORT
Control ports 1, 3, 5, and 7 may be configured for
SDI-12 asynchronous communications. Up to ten
SDI-12 sensors are suppor ted per port. It meets
SDI-12 Standard version 1.3 for datalogger mode.
CE COMPLIANCE
STANDARD(S) TO WHICH CONFORMITY IS
DECLARED: IEC61326:2002
URE FREQUENCY MAX: 150 Hz
CPU AND INTERFACE
PROCESSOR: Hitachi H8S 2322 (16-bit CPU with
32-bit internal core)
MEMORY: 2 Mbytes of Flash for operating system;
2 Mbytes of battery-backed SRAM for CPU usage,
5
program storage and data storage; 4 Mbytes optional
SERIAL INTERFACES: CS I/O port is used to
interface with Campbell Scientific peripherals;
RS-232 por t is for computer or non-CSI modem
connection.
PARALLEL INTERFACE: 40-pin interface for attaching
data storage or communication peripherals such as
the CFM100 module
BAUD RATES: Selectable from 300 bps to 115.2 kbps.
ASCII protocol is one start bit, one stop bit, eight
data bits, and no parity.
CLOCK ACCURACY: ±3 min. per year
SYSTEM POWER REQUIREMENTS
VOLTAGE: 9.6 to 16 Vdc
TYPICAL CURRENT DRAIN:
Sleep Mode: ~0.6 mA
1 Hz Scan
w/RS-232 communication: 19 mA
w/o RS-232 communication: 4.2 mA
1 Hz Scan
w/RS-232 communication: 16.7 mA
w/o RS-232 communication: 1 mA
100 Hz Scan
w/RS-232 communication: 27.6 mA
w/o RS-232 communication: 16.2 mA
CR1000KD CURRENT DRAIN:
Inactive: negligible
Active w/o backlight: 7 mA
Active w/backlight: 100 mA
EXTERNAL BATTERIES: 12 Vdc nominal; reverse
polarity protected.
(8 diff. meas., 60 Hz rej., 2 pulse meas.)
(8 diff. meas., 250 µs integ., 2 pulse meas.)
(4 diff. meas., 250 µs integ.)
PHYSICAL SPECIFICATIONS
MEASUREMENT & CONTROL MODULE SIZE:
8.5" x 3.9" x 0.85" (21.6 x 9.9 x 2.2 cm)
CR1000WP WIRING PANEL SIZE: 9.4" x 4" x 2.4"
(23.9 x 10.2 x 6.1 cm); additional clearance required
for serial cable and sensor leads.
WEIGHT: 2.1 lbs (1 kg)
WARRANTY
Three years against defects in materials and workmanship.
OV-43
CR1000 Overview
This is a blank page.
OV-44
This is a blank page.
Campbell Scientific Companies
Campbell Scientific, Inc. (CSI)
815 West 1800 North
Logan, Utah 84321
UNITED STATES
www.campbellsci.com
info@campbellsci.com
Campbell Scientific Africa Pty. Ltd. (CSAf)
PO Box 2450
Somerset West 7129
SOUTH AFRICA
www.csafrica.co.za
cleroux@csafrica.co.za
Campbell Scientific Australia Pty. Ltd. (CSA)
PO Box 444
Thuringowa Central
QLD 4812 AUSTRALIA
www.campbellsci.com.au
info@campbellsci.com.au
Campbell Scientific do Brazil Ltda. (CSB)
Rua Luisa Crapsi Orsi, 15 Butantã
CEP: 005543-000 São Paulo SP BRAZIL
www.campbellsci.com.br
suporte@campbellsci.com.br
Campbell Scientific Canada Corp. (CSC)
11564 - 149th Street NW
Edmonton, Alberta T5M 1W7
CANADA
www.campbellsci.ca
dataloggers@campbellsci.ca
Campbell Scientific Ltd. (CSL)
Campbell Park
80 Hathern Road
Shepshed, Loughborough LE12 9GX
UNITED KINGDOM
www.campbellsci.co.uk
sales@campbellsci.co.uk
Campbell Scientific Ltd. (France)
Miniparc du Verger - Bat. H
1, rue de Terre Neuve - Les Ulis
91967 COURTABOEUF CEDEX
FRANCE
www.campbellsci.fr
campbell.scientific@wanadoo.fr
Campbell Scientific Spain, S. L.
Psg. Font 14, local 8
08013 Barcelona
SPAIN
www.campbellsci.es
info@campbellsci.es
Please visit www.campbellsci.com to obtain contact information for your local US or International representative.
Loading...
