fixed socket CCB series

CCB2S1/04
4 pole

• Premium range of circular connectors

• IP68 sealed using vacuum technology
(when connected and using
environmental cable clamp)

• Tough, high performance interconnection
solution

• Compact panel mounting design

• Ideal for harsh and extreme environments

• Suitable for broadcasting, autosport,
military, rail, marine, security, industrial
and agricultural applications

• Key coded to prevent misconnection

• Will not disconnect when the cable is
under load or stress

• Tested to IEC 60512-3-5a

CCB2S1/04

PART NO. DESCRIPTION POLES SERIES

CCB2S1/04

M12*1.0

Female fixed
socket

23

0 min - 8 max

CCB

04

series

1.5

14

Ø14

SPECIFICATION

Shell style/model

Codes Code 1

Contact type Solder type

Contact diameter 0.9mm

Max. stranded conductor AWG 21-22

Max diameter 1.18mm

Vtest (contact-shell)

Vtest (contact-contact)

Rated current 7.0A

Rated voltage ≤250V

Mechanical operation 5000 mating cycles

Housing material

Insulator PPS

Contacts Brass (gold plated)

Humidity (max) <=95% [at 60°C /140°F]

Vibration 15g [10 Hz - 2000 Hz]

Shock resistance 100g [6 ms]

Salt spray corrosion >72 hr

Climatical category 50/175/21

Shielding (min) 75 dB (10 MHz)

Shielding (min) 40 dB (1 GHz)

IP rating

D type fixed socket, female
contact

1100V(AC)
1900V(DC)

1400V(AC)
2200V(DC)

Brass (natural chrome
plated) shell and collet nut,
nickel plated brass latch
sleeve and mid pieces

IP68 (when connected
and using
environmental cable clamp)

KEY FEATURES

Key coded | Panel mounting socket | Flat face | Low profile

ACCESSORIES

Metal and rubber caps for sockets

PART NO. DESCRIPTION

CCT21 Camcirc metal cap for sockets A2

PART NO. DESCRIPTION

CCT22 Camcirc rubber cap for sockets A2

ASSOCIATED PRODUCTS

CCA2P1/A04 - CCA Series A2 size plug page 108
