Cambridge SoundWorks MC630HD User Manual

Newton Series HD

High Performance

Loudspeaker

Contents

Introduction ................................................................... 4

Product Contents .......................................................... 4

Inspecting for Damage .................................................. 4

System Conguration .................................................... 5

Speaker Placement ....................................................... 5

Wiring ............................................................................ 6

Speaker Mounting ......................................................... 7

Horizontal Use ............................................................... 8

Bass Contour Switch .................................................... 9

Enclosure Cleaning ...................................................... 9

In Case of Difculty .................................................... 9

Specications ............................................................ 10

Dimensions

................................................................. 10

- 3 -

Introduction

Thank you for choosing a Newton HD Series speaker. The MC630HD features the nest drivers, precision internal crossover circuitry, and an

elegant enclosure design.

The design team at Cambridge SoundWorks believes there is no better combination of audiophile-level attention to detail and reasonable

cost.

Contents

1. One Speaker

2. Two stick-on rubber feet

3. Four clear round stick-on rubber feet

4. Center Channel rear support

5. ¼-20 machine screw for rear support

6. Two screws and wall anchors

After Unpacking

Save the shipping carton and packing material for future use and transport.

Inspecting For Damage

Examine each part carefully for shipping damage. If there is any, do not install or use the speaker. Return the speaker to the merchant where
you made the purchase or call Cambridge SoundWorks at 1-800 FOR-HIFI (1-800-367-4434) for assistance.

- 4 -
