Cal Spas PATIO, ESCAPE, ESCAPE PLUS, SPECIAL EDITION Owner's Manual

LTR20171001, Rev. B
4/18/17

Table of Contents

Preparing for Your New Portable Spa

Pre-Delivery Checklist. . . . . . . . . . . . . . . . . . 3

Planning the Best Location . . . . . . . . . . . . . . 3

Preparing a Good Foundation . . . . . . . . . . . . 4

230V / 50 Hz Electrical Installation . . . . . . . 5

Filling and Powering Up Your Portable Spa 12

Priming the Pump . . . . . . . . . . . . . . . . . . . . 15

Operating Your Spa

TP400 and TP600 Control Panel Operation 17

TP800 Control Panel Operation . . . . . . . . . 26

Cal Spas Hot Tub Wi-Fi App . . . . . . . . . . . . 31

Cloud Service . . . . . . . . . . . . . . . . . . . . . . . . 33

Electrical Power Efciency . . . . . . . . . . . . . 34

Adjustable Jets . . . . . . . . . . . . . . . . . . . . . . 34

LED Lighting. . . . . . . . . . . . . . . . . . . . . . . . . 34

Diverter Knobs. . . . . . . . . . . . . . . . . . . . . . . 35

Waterfalls . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Air Venturis . . . . . . . . . . . . . . . . . . . . . . . . . 35

Hydro Streamer Waterfall. . . . . . . . . . . . . . 35

Adjustable Therapy System . . . . . . . . . . . . 36

Microsilk Therapy System . . . . . . . . . . . . . . 36

Pure Cure™ Water Sanitizer . . . . . . . . . . . . 37

Ozonator . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Bromine Generator . . . . . . . . . . . . . . . . . . . 38

Intelligent Controller Codes for the Bromine

Generator. . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Troubleshooting Water Clarity Problems . . 40

Cleaning and Maintenance

Removing and Reseating

the Pillows . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Jet Removal and Replacement . . . . . . . . . . 41

Draining Your Portable Spa . . . . . . . . . . . . 42

Winterizing (Cold Climate Draining) . . . . . 43

Vacation Care. . . . . . . . . . . . . . . . . . . . . . . . 43

Spa Cover. . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Filter Cleaning . . . . . . . . . . . . . . . . . . . . . . . 44

Cleaning Your Spa . . . . . . . . . . . . . . . . . . . . 45

Changing the UV Lamp . . . . . . . . . . . . . . . . 46

Maintenance Schedule . . . . . . . . . . . . . . . . 47

Using the Entertainment System

Aquatic AV AQ-DM-5UBT. . . . . . . . . . . . . . . 48

Using the Freedom Sound System . . . . . . . 51

Keeping Fit With Your Swim Spa

Jetstream Propulsion System . . . . . . . . . . . 52

Assembling the Swim Tether . . . . . . . . . . . 52

Using the Exercise Equipment . . . . . . . . . . 52

Appendix

Replacement Parts . . . . . . . . . . . . . . . . . . . 54

Basic Troubleshooting. . . . . . . . . . . . . . . . . 63

Copyright 2017 Lloyd’s Material Supply, Inc. All rights reserved. Duplication without written
consent is strictly prohibited.

Cal Spas™, Adjustable Therapy System™, ATS™, Cal Premium™, Cal Select™, Cal Stone™,
Ultimate Fitness Spa Series™, and XL Heat Exchanger™ are registered trademarks.

Due to continuous improvement programs, all models, operation, and/or specications are

subject to change without prior notice.

LTR20171001, Rev. B
4/18/17

CONTACT INFORMATION

For customer service, please contact
your authorized dealer immediately. If
you need additional information and/
or assistance, please contact:

LMS Customer Service Department
1462 East Ninth Street
Pomona, CA 91766.

Phone: [phone]
Fax: [phone]

Important Safety Instructions

READ AND FOLLOW ALL INSTRUCTIONS.

1

Read This First!

DANGER -- Risk of accidental drowning:

Do not allow children to be in or around a spa
unless a responsible adult supervises them. Keep
the spa cover on and locked when not in use. See
instructions enclosed with your cover for locking
procedures.

DANGER -- Risk of injury:

The suction ttings in this spa are sized to match
the specic water ow created by the pump. Should
the need arise to replace the suction ttings, or the
pump, be sure the ow rates are compatible.

Never operate the spa if the suction tting or lter

baskets are broken or missing. Never replace a

suction tting with one that is rated less than the
ow rate marked on the original suction tting.

WARNING -- To reduce the risk of injury:

The spa water should never exceed 40°C (104°F).
Water temperatures between 38°C and 40°C (100°F
and 104°F) are considered safe for a healthy adult.
Lower water temperatures are recommended for
young children and when spa use exceeds 10 minutes.

High water temperatures have a high potential for
causing fetal damage during pregnancy. Women who
are pregnant, or who think they are pregnant, should
always check with their physician prior to spa usage.

DANGER -- Risk of electric shock:

Install the spa at least 1.5 meters from all metal
surfaces. As an alternative, a spa may be installed
within 5 feet of metal surfaces if each metal surface
is permanently bonded by a minimum #8 AWG solid
copper conductor to the outside of the spa’s control
box.

Do not permit any external electrical appliances,
such as lights, telephones, radios, televisions, and

etc., within ve feet of the spa. Never attempt to

operate any electrical device from inside the spa.

Replace a damaged power cord immediately.

Do not bury the power cord.

Connect to a grounded, grounding-type receptacle
only.

The use of alcohol, drugs or medication before or
during spa use may lead to unconsciousness, with
the possibility of drowning.

Persons suffering from obesity, a medical history of
heart disease, low or high blood pressure, circulatory
system problems or diabetes should consult a
physician before using the spa.

Persons using medications should consult a physician
before using the spa since some medications may
induce drowsiness while others may affect heart rate,
blood pressure and circulation.

HYPERTHERMIA DANGER:

Prolonged exposure to hot air or water can induce
hyperthermia. Hyperthermia occurs when the internal
temperature of the body reaches a level 2°C to 4°C
(1°C to 2°C) above the normal body temperature of
37°C (98.6°F). While hyperthermia has many health

benets, it is important not to allow your body’s core

temperature to rise above 39.5°C (103°F).

Symptoms of excessive hyperthermia include
dizziness, lethargy, drowsiness and fainting. The
effects of excessive hyperthermia may include:

2017 Portable Spa

LTR20171001, Rev. B

• Failure to perceive heat

• Failure to recognize the need to exit spa or hot

tub

• Unawareness of impending hazard

• Fetal damage in pregnant women

• Physical inability to exit the spa

• Unconsciousness

WARNING: The use of alcohol, drugs, or medication
can greatly increase the risk of fatal hyperthermia.

www.calspas.com

2

WARNING: People with infectious diseases should not use a spa or hot tub.

WARNING: To avoid injury, exercise care when entering or exiting the spa or hot tub.

WARNING: Do not use drugs or alcohol before or during the use of a spa or hot tub to avoid unconsciousness

and possible drowning.

Read This First!

WARNING: Do not use a spa or hot tub immediately following strenuous exercise.

WARNING: Prolonged immersion in a spa or hot tub may be injurious to your health.

CAUTION: Maintain water chemistry in accordance with manufacturer’s instructions.

SAVE THESE INSTRUCTIONS.

www.calspas.com

2017 Portable Spa

LTR20171001, Rev. B

Preparing for Your New Portable Spa

Pre-Delivery Checklist

3

Preparing for Your New Portable Spa

Most cities and counties require permits for exterior
construction and electrical circuits. In addition, some
communities have codes requiring residential barriers
such as fencing and/or self-closing gates on property
to prevent unsupervised access to the property by
children under the age of 5. Your dealer can provide
information on which permits may be required and
how to obtain them prior to the delivery of your spa.

Planning the Best Location

Safety First

Do not place your spa within 10 feet (3 m) of
overhead power lines.

Consider How You Will Use Your Spa

How you intend to use your spa will help you
determine where you should position it. For example,
will you use your spa for recreational or therapeutic
purposes? If your spa is mainly used for family
recreation, be sure to leave plenty of room around
it for activity. If you will use it for relaxation and

therapy, you will probably want to create a specic

mood around it.

Plan for Your Environment

If you live in a region where it snows in the winter
or rains frequently, place the spa near a house
entry. By doing this, you will have a place to change
clothes and not be uncomfortable.

For additional operating and installation information,
please see your selling dealer.

Before Delivery

Plan your delivery route

Choose a suitable location for the spa

Lay a 5 - 8 cm concrete slab

Install dedicated electrical supply

After Delivery

Place spa on slab

Connect electrical components

Provide a View with Your Spa

Think about the direction you will be facing when
sitting in your spa. Do you have a special landscaped

area in your yard that you nd enjoyable? Perhaps

there is an area that catches a soothing breeze
during the day or a lovely sunset in the evening.

Keep Your Spa Clean

In planning your spa’s location, consider a location
where the path to and from the house can be kept
clean and free of debris.

Prevent dirt and contaminants from being tracked
into your spa by placing a foot mat at the spa’s
entrance where the bathers can clean their feet
before entering your spa.

Allow for Service Access

Consider Your Privacy

In a cold-weather climate, bare trees won’t provide
much privacy. Think of your spa’s surroundings
during all seasons to determine your best privacy
options. Consider the view of your neighbors as well
when you plan the location of your spa.

2017 Portable Spa

LTR20171001, Rev. B

Many people choose to install a decorative structure
around their spa. If you are installing your spa with
any type of structure on the outside, such as a
gazebo, remember to allow access for service. It is
always best to design special installations so that
the spa can still be moved, or lifted off the ground.

www.calspas.com

4

Preparing a Good Foundation

Preparing for Your New Portable Spa

Your spa needs a solid and level foundation. The area
that it sits on must be able to support the weight
of the spa and the occupants who use it. If the
foundation is inadequate, it may shift or settle after
the spa is in place, causing stress that could damage

your spa shell or nish.

Damage caused by inadequate or improper
foundation support is not covered by the
warranty. It is the responsibility of the
spa owner to provide a proper foundation
for the spa.

Place the spa on an elevated 10 cm concrete slab.
Pavers, gravel, brick, sand, timbers or dirt foundations
are not adequate to support the spa.

We strongly recommended that you have a qualied,

licensed contractor prepare the foundation for your
spa.

If you are installing the spa indoors, pay close

attention to the ooring beneath it. Choose ooring

that will not be damaged or stained.

If you are installing your spa on an elevated wood
deck or other structure, it is highly recommended
that you consult a structural engineer or contractor
to ensure the structure will support the weight of 732
kg / m2 (150 lbs / ft2).

To properly identify the weight of your new spa
when full, remember water weighs 1 kg per liter. For
example, an average 2.4 meter (8 foot) spa holds
approximately 1892 liters of water. Using this formula,

you will nd that the weight of the water alone is

1892 kg. Combined with the dry weight of the spa
you will note that this spa will weigh approximately
2267 kg when full of water.

www.calspas.com

2017 Portable Spa

LTR20171001, Rev. B

230V / 50 Hz Electrical Installation

5

Preparing for Your New Portable Spa

All 230V spas must be permanently connected
(hard wired) to the power supply. These instructions
describe the only acceptable electrical wiring
procedure. Spas wired in any other way will void your
warranty and may result in serious injury.

This is the only acceptable electrical wiring procedure.
Spas wired in any other way will void your warranty.
See the wiring requirements below and wiring
diagrams on page 6 through page 11.

The electrical wiring of this spa must meet the
requirements of any applicable local, state, and
federal codes. The electrical circuit must be installed
by an electrical contractor and approved by a local
building / electrical inspector.

The power supplied to the spa must be on a dedicated

RCD and Wiring Requirements

Note: SINGLE PHASE ONLY!

Three phase power requires 400V.
Only use 230V.

START

HERE

RCD protected circuit with no other appliances or
lights sharing the power.

Use copper wire with THHN insulation. Do not use
aluminum wire.

Use the tables below to determine your RCD and
wiring requirements.

When wires larger than #6 AWG are required, install
a junction box near the spa and use #6 AWG wire
between the junction box and the spa.

Wires that run over 25 meters must increase wire
gauge to the next lower number. For example: A
normal 50 amp RCD with three #8 AWG copper wires
that run over 25 meters would require you to go to
three #6 AWG copper wires.

Use this table to determine your

wiring conguration.

See diagram 1

on page 6.

See diagram 2

on page 7.

601

2100

Which control

system does it

use?

No

Is this for a

fitness spa?

Yes

Is this for a

F1770E?

No

Does it have

the optional

5.5 kW heater?

No

Yes

Yes

Which control

system does it

use?

See diagrams 5
and 6 on pages

10 and 11.

Which control

system does it

use?

601

2100

601

2100

See diagram 1

on page 6.

See diagram 2

on page 7.

See diagram 3

on page 8.

See diagram 4

on page 9.

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

6

F3 10A 250V

J100

J40

J41

J53

J37 J48

J34 J36

J55

J43

K5

3

2

1

BLOWER

24090_B

HEATER

J13

Diagram 1

Preparing for Your New Portable Spa

BROWN (Hot)

BLUE

(Neutral)

GREEN / YELLOW

(Ground)

One 16A RCD

Three wires:
1 brown (HOT)
1 blue (NEUTRAL)
1 yellow (GROUND)

BROWN

(Hot)

BROWN

(Hot)

BLUE
(Neutral)

BLUE
(Neutral)

GREEN / YELLOW

(Ground)

601 control system

www.calspas.com

GREEN / YELLOW (Ground)

BLUE (Neutral)

BROWN (Hot)

J109

J57

2

(UNFUSED)

K1

K12

J56

F6 0.125A 250V

F5 30A

TB1

1

2

3

K3

J101

J12

J54

J42

J39

J38

J35

J46

2017 Portable Spa

LTR20171001, Rev. B

F3 10A 250V

J101

J100

J42

J39

J54

J56

J57

J40

J41

J53

J12

J38

J37 J48

J35

J34 J36

J55

J43

F5 30A

K3

TB1

K5

K1

3

3

2

2

(UNFUSED)

2

1

1

K12

J109

BLOWER

24090_B

J46

HEATER

J13

F3 0.125A SLO-BLOW

K5

K1

J33

3

2

1

J42

J3

J4

J1

J61J47

J38

J39

J111

J53 J58

J11

J12

J88

J62

F8 30A

J55

J59

J52

J98

J10

A/V CHAUD

K9

J109

GREEN / YELLOW (Ground)

BROWN (Hot)

BLUE (Neutral)

Diagram 2

7

Preparing for Your New Portable Spa

BROWN (Hot)

BLUE

(Neutral)

GREEN / YELLOW

(Ground)

One 32A RCD

Three wires:
1 brown (HOT)
1 blue (NEUTRAL)
1 yellow (GROUND)

BROWN

(Hot)

BROWN

(Hot)

BLUE
(Neutral)

BLUE
(Neutral)

GREEN / YELLOW

(Ground)

2100 control system

F6 30A

J9

K4

J46

PUMP 1

K2

J56

J57

J60

J41

2017 Portable Spa

LTR20171001, Rev. B

GREEN / YELLOW (Ground)

BLUE (Neutral)

BROWN (Hot)

J110

1

2

3

4

J45

J79

J51

J72

J37

J36

J54

J77

J75

J78

4

www.calspas.com

F3 10A 250V

J100

J40

J41

J53

J37 J48

J34 J36

J55

J43

K5

3

2

1

BLOWER

24090_B

HEATER

J13

F3 0.125A SLO-BLOW

K5

K1

K2

K4

J33

J9

1

2

3

4

4

3

2

1

J45

J110

J79

J54

J72

J42

J3

J37

J4

J1

J61J47

J77

J75

J78

J36

J60

J46

J38

J39

J111

J53 J58

J11

J41

J12

J88

J62

F6 30A

F8 30A

J56

J57

J55

J59

J51

J52

J98

J10

A/V CHAUD

PUMP 1

K9

J109

F3 0.125A SLO-BLOW

K5

K1

3

2

J39

J10

J43

K9

J109

F3 10A 250V

J100

J40

J41

J53

J37 J48

J34 J36

J55

J43

K5

3

2

1

BLOWER

24090_B

HEATER

12VAC-B 12VAC-A

J13

GREEN / YELLOW (Ground)

BROWN (Hot)

BLUE (Neutral)

8

Diagram 3

Preparing for Your New Portable Spa

BROWN (Hot)

BLUE

(Neutral)

GREEN / YELLOW

(Ground)

Two 16A RCDs

Six wires:
2 brown (HOT)
2 blue (NEUTRAL)
2 yellow (GROUND)

BROWN

(Hot)

BROWN

(Hot)

BLUE
(Neutral)

BLUE
(Neutral)

BROWN

(Hot)

BROWN

(Hot)

BLUE
(Neutral)

BLUE
(Neutral)

GREEN / YELLOW (Ground)

601 control system

J57

J56

2

(UNFUSED)

BLUE (Neutral)

BROWN (Hot)

K1

J109

TB1

F6 0.125A 250V

F5 30A

1

2

3

K3

J12

J54

J42

J39

J38

J35

www.calspas.com

GREEN / YELLOW (Ground)

GREEN / YELLOW (Ground)

J101

K12

BLUE (Neutral)

BROWN (Hot)

5.5 kW heater box

J46

2017 Portable Spa

LTR20171001, Rev. B

F3 10A 250V

J100

J40

J41

J53

J37 J48

J34 J36

J55

J43

K5

3

2

1

BLOWER

24090_B

HEATER

J13

F3 0.125A SLO-BLOW

K5

K1

K4

J33

3

2

1

J42

J3

J4

J1

J61J47

J38

J39

J111

J53 J58

J11

J12

J88

J62

F8 30A

J55

J59

J52

J98

J10

A/V CHAUD

K9

J109

F3 0.125A SLO-BLOW

K5

K1

J33

3

2

1

J42

J3

J4

J1

J61J47

J38

J39

J111

J53 J58

J11

J12

J88

J62

F8 30A

J59

J52

J98

J10

A/V CHAUD

K9

F3 0.125A SLO-BLOW

K5

K1

3

2

J39

J10

K9

F3 0.125A SLO-BLOW

K5

K1

3

2

J39

J111

J11

J10

J43

K9

J109

F3 10A 250V

J100

J40

J41

J53

J37 J48

J34 J36

J55

J43

K5

3

2

1

BLOWER

24090_B

HEATER

12VAC-B 12VAC-A

J13

GREEN / YELLOW (Ground)

5.5 kW heater box

5.5 kW heater box

BROWN (Hot)

BLUE (Neutral)

GREEN / YELLOW (Ground)

Diagram 4

BROWN (Hot)

BLUE

(Neutral)

GREEN / YELLOW

(Ground)

BROWN

(Hot)

BROWN

(Hot)

BLUE
(Neutral)

BLUE
(Neutral)

BROWN

(Hot)

BROWN

(Hot)

GREEN / YELLOW (Ground)

9

Preparing for Your New Portable Spa

BLUE
(Neutral)

BLUE
(Neutral)

One 32A RCD
(connect to 2100 control system)

One 16A RCD
(connect to 5.5 kW heater box)

Six wires:
2 brown (HOT)
2 blue (NEUTRAL)
2 yellow (GROUND)

2017 Portable Spa

LTR20171001, Rev. B

GREEN / YELLOW (Ground)

2100 control system

F6 30A

BLUE (Neutral)

BROWN (Hot)

GREEN / YELLOW (Ground)

BLUE (Neutral)

BROWN (Hot)

J9

K4

J46

PUMP 1

K2

J56

J57

J55

J60

J41

J51

1

J72

2

J37

3

J36

4

J45

J79

J54

J77

J75

J110

J78

4

www.calspas.com

10

F4 3A SLO-BLOW

J25 J31

J26 J30

115V 115V

230V

F3 0.125A SLO-BLOW

F7 10A 250VAC

F2 10A 250VAC

J44

3

J15

ON

10

S1

K5

K1

K3

T1

K8

LIGHT

GND

J33

J21

J32

2

K6

3

2

1

J42

J3

J4

J1

J61J47

J38

J39

J111

J58

J11

J48

J6

J7

J49

J19

J50

J13

J12

J88

J62

F8 30A

J59

J52

J98

J10

J81

J20

J18

J43

CIRC PUMP

OZONE

A/V CHAUD

J14

K9

J5
AUX

J8
AUX

J40

REMOTE

J35
MAIN

J34
MAIN

J109

J27

J91

J22

J23

SERIAL

J29
VAC

J28

AUX
FRZ

J17 J16

24082_E

J101

J108

J24

J107

K12

K7

AUX**

F3 10A 250V

F2 3A 250V

J100

J40

J32

J51

J41

J53

J37 J48

J50

J56

J52

J19 J18

J34 J36

J55

J43

J24 J14

K5

K6

K2

K4

OZONE

J47

A/V

J8 J21

PUMP 1

CIRC

3

2

1

F4 3A 250V

K7

J15

J33

J45

J22

TEMP SENSORS

J16

J28 AUX FRZ

BLOWER

LIGHT

ON

24090_B

1

GND

HEATER

120V 120V

240V

12VAC-B 12VAC-A

J44

J13

J20

P2/BLWR

J23

SERIAL

J108

EXPANDER

J25=HTR1 J26=HTR2
J27=HTR3 J30=TEST
J31=CE HTR SEL

T1

HTR
DISBL

J29
VAC

F3 10A 250V

F2 3A 250V

J100

J40

J51

J41

J53

J37 J48

J50

J52

J19 J18

J34 J36

J55

J43

K5

K6

K2

K4

J8 J21

PUMP 1

CIRC

3

2

1

F4 3A 250V

K7

J15

J45

J28 AUX FRZ

BLOWER

LIGHT

24090_B

GND

HEATER

120V 120V

240V

12VAC-B 12VAC-A

J44

J13

J23

SERIAL

J108

EXPANDER

T1

F4 3A SLO-BLOW

J25 J31

J26 J30

115V 115V

230V

F3 0.125A SLO-BLOW

F7 10A 250VAC

F2 10A 250VAC

J44

3

J15

ON

10

S1

K5

K1

K3

T1

K4

K8

LIGHT

GND

J33

J21

J32

2

3

2

1

J42

J3

J4

J1

J61J47

J38

J39

J111

J53 J58

J11

J48

J6

J7

J49

J19

J50

J13

J12

J88

J62

F8 30A

J55

J59

J52

J98

J10

J81

J20

J18

J43

CIRC PUMP

OZONE

A/V CHAUD

J14

K9

J5
AUX

J8
AUX

J40

REMOTE

J35
MAIN

J34
MAIN

J109

J27

J91

J22

J23

SERIAL

J29
VAC

J28

AUX
FRZ

J17 J16

24082_E

J101

J108

J24

J107

K12

K7

AUX**

F4 3A SLO-BLOW

J25 J31

J26 J30

115V 115V

230V

F3 0.125A SLO-BLOW

F7 10A 250VAC

F2 10A 250VAC

J44

3

J15

ON

10

S1

K5

K1

K3

T1

K8

LIGHT

GND

J21

J32

2

K6

3

2

J39

J111

J11

J48

J6

J7

J49

J19

J50

J13

J10

J81

J20

J18

J43

CIRC PUMP

OZONE

J14

K9

J5
AUX

J8
AUX

J40

REMOTE

J35
MAIN

J34
MAIN

J109

J27

J91

J22

J23

SERIAL

J29
VAC

J28

AUX
FRZ

J17 J16

24082_E

J101

J108

J24

J107

K12

K7

AUX**

GREEN / YELLOW

(Ground)

BLUE

(Neutral)

BROWN (Hot)

With 3.0 kW heater and 5.5 kW heater

SPA SIDE

SWIM SIDE

Diagram 5

With 3.0 kW heater only

One 32A RCD
(connect to 2100 control system)

Preparing for Your New Portable Spa

BROWN (Hot)

BLUE

(Neutral)

GREEN / YELLOW

(Ground)

SWIM SIDE

BROWN

(Hot)

BROWN

(Hot)

BLUE
(Neutral)

BLUE
(Neutral)

BROWN

BROWN

(Hot)

(Hot)

BLUE
(Neutral)

BLUE
(Neutral)

GREEN / YELLOW (Ground)

One 16A RCD
(connect to 601 control system)

Six wires:
2 brown (HOT)
2 blue (NEUTRAL)
2 yellow (GROUND)

2100 control system

J9

K4

J46

PUMP 1

K2

J56

J57

F6 30A

BLUE (Neutral)

BROWN (Hot)

J55

J60

J41

J51

1

J72

2

J37

3

J36

4

J53

J45

J79

J54

J77

J75

J78

J110

4

www.calspas.com

SPA SIDE

GREEN / YELLOW (Ground)

GREEN / YELLOW (Ground)

601 control system

J57

J56

2

(UNFUSED)

TB1

BLUE (Neutral)

BROWN (Hot)

K1

J109

K12

F6 0.125A 250V

F5 30A

1

2

3

K3

J101

J12

J54

J42

J39

J38

J35

J46

2017 Portable Spa

LTR20171001, Rev. B

Diagram 6

F3 10A 250V

F2 3A 250V

J100

J40

J51

J41

J53

J37 J48

J50

J52

J19 J18

J34 J36

J55

J43

K5

K6

K2

K4

J8 J21

PUMP 1

CIRC

3

2

1

F4 3A 250V

K7

J15

J45

J28 AUX FRZ

BLOWER

LIGHT

24090_B

GND

HEATER

120V 120V

240V

12VAC-B 12VAC-A

J44

J13

J23

SERIAL

J108

EXPANDER

T1

F4 3A SLO-BLOW

J25 J31

J26 J30

115V 115V

230V

F3 0.125A SLO-BLOW

F7 10A 250VAC

F2 10A 250VAC

J44

3

J15

ON

10

S1

K5

K1

K3

T1

K8

LIGHT

GND

J33

J21

J32

2

3

2

1

J42

J3

J4

J1

J61J47

J38

J39

J111

J58

J11

J48

J6

J7

J49

J19

J50

J13

J12

J88

J62

F8 30A

J59

J52

J98

J10

J81

J20

J18

J43

CIRC PUMP

OZONE

A/V CHAUD

J14

K9

J5
AUX

J8
AUX

J40

REMOTE

J35
MAIN

J34
MAIN

J109

J27

J91

J22

J23

SERIAL

J29
VAC

J28

AUX
FRZ

J17 J16

24082_E

J101

J108

J24

J107

K12

K7

AUX**

F4 3A SLO-BLOW

J25 J31

J26 J30

115V 115V

230V

F3 0.125A SLO-BLOW

F7 10A 250VAC

F2 10A 250VAC

J44

3

J15

ON

10

S1

K5

K1

K3

T1

K8

LIGHT

GND

J21

J32

2

K6

3

2

J39

J111

J11

J48

J6

J7

J49

J19

J50

J13

J10

J81

J20

J18

J43

CIRC PUMP

OZONE

J14

K9

J5
AUX

J8
AUX

J40

REMOTE

J35
MAIN

J34
MAIN

J109

J27

J91

J22

J23

SERIAL

J29
VAC

J28

AUX
FRZ

J17 J16

24082_E

J101

J108

J24

J107

K12

K7

AUX**

With 3.0 kW heater and 5.5 kW heater

11

Preparing for Your New Portable Spa

One 32A RCD
(connect to 2100 control system)

BROWN

(Hot)

BLUE
(Neutral)

BROWN

BROWN (Hot)

BLUE

(Neutral)

GREEN / YELLOW

(Ground)

BROWN

(Hot)

BLUE
(Neutral)

BROWN

GREEN / YELLOW (Ground)

SWIM SIDE

(Hot)

(Hot)

BLUE
(Neutral)

BLUE
(Neutral)

BROWN

(Hot)

BROWN

(Hot)

BLUE
(Neutral)

BLUE
(Neutral)

2100 control system

J9

J46

PUMP 1

K2

J56

F6 30A

J60

J41

BLUE (Neutral)

BROWN (Hot)

1

2

3

4

J45

J79

J54

J77

J75

J78

J110

4

Two16A RCDs

(connect to 601 control system
and 5.5 kW heater)

Nine wires:
3 brown (HOT)
3 blue (NEUTRAL)
3 yellow (GROUND)

K4

J57

J55

J51

J72

J37

J36

J53

SPA SIDE

2017 Portable Spa

LTR20171001, Rev. B

GREEN / YELLOW (Ground)

GREEN / YELLOW (Ground)

GREEN / YELLOW (Ground)

BLUE (Neutral)

BROWN (Hot)

5.5 kW heater box

601 control system

F6 0.125A 250V

J57

J56

F5 30A

2

(UNFUSED)

TB1

BLUE (Neutral)

BROWN (Hot)

1

2

3

K1

K3

J109

J101

K12

J12

J54

J42

J39

J38

J35

J46

www.calspas.com

12

Filling and Powering Up Your Portable Spa

1. Inspect the spa equipment.

Preparing for Your New Portable Spa

Inspect all plumbing connections in the
equipment area of your spa.

2. Remove the cartridge from lter canister.

If you have a skimmer like this:

Grip the lter by the handle and unscrew it from

the canister.

• Make sure unions in the equipment pack are tight. (Be
careful not to over-tighten the plumbing ttings.)

• If your spa has

gate valves, make
sure they are all
in the UP or OPEN
position.

• Make sure the drain
valve is closed and
capped. (See page
42 for a description
of drain valves.)

Never run the spa with the gate valves closed or
without water circulating for long periods of time.

If you have a skimmer like this:

Rotate and remove the black locking ring. Remove

the black skimmer cap and barrel, grip the lter

by the handle and unscrew it from the canister.
Replace and lock the locking ring and slide the
skimmer cap and barrel back in the canister.

If you have a skimmer like this:

Remove the black skimmer cap and barrel, grip

the lter by the handle and unscrew it from the

canister.

Teleweir Mega

lter skimmer

• 75 square
feet ltration

• Smooth cap

Note: The skimmer cap and barrel were locked
in place at the factory to prevent damage during
shipment. It must be unlocked and replaced in

the lter canister so that it can oat when the spa
is lled. If you do not remove the cap and barrel,
your spa’s ltration system will not perform as it was

designed to.

Teleweir lter

skimmer

• 50 square feet
ltration

• Spoked cap

After you remove the lter, remove the plastic

wrapper and soak it in water for 30 minutes

before you replace it. A dry lter can allow air
into the ltration system which can cause the

pump to fail to prime.

www.calspas.com

2017 Portable Spa

LTR20171001, Rev. B

3. Fill the spa.

13

Preparing for Your New Portable Spa

Place a garden hose in the lter canister and ll your

spa.

Always ll the spa through the lter canister.

Fill the spa until water level is about six inches from the top.

If the water level is too low or too high, your spa will not operate properly.

Never ll your spa with soft water.

Soft water makes it impossible to maintain the proper water chemistry and may cause the water to

foam, which will ultimately harm the nish of the spa and void your warranty.

Failure to do so may cause air to be trapped in the

ltration system and prevent the pumps from operating

properly.

4. Turn on power to the spa.

When the spa is lled to the correct level, turn on the

power at the GFCI breaker. (Ensure that the 120V spas are
connected to the proper electrical outlet.)

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

14

5. Prime the pump.

Your spa will perform a self-diagnostic check and go into
Priming Mode. The control panel will display either RUN
PUMPS PURG AIR --- or Priming Mode, depending on
which control panel you have.

Do the following:

Press the JETS or JETS 1 button once to start the pump in
low speed.

a. Press it again to switch the pump to high speed.

b. If you have other pumps, press JETS 2 or JETS 3

to turn them on also. Running the pumps helps the
pumps prime.

After two minutes, the pump should prime. If it does not, follow the priming instructions on the next page. If it
does, continue with the next step.

Preparing for Your New Portable Spa

6. Install the lter into the lter canister.

Make sure the lter has soaked at least 30

minutes before you install it.

7. Adjust water chemistry.

Test and adjust the water chemistry. See the section
on page 40. for instructions on keeping your water
clear.

Spa owners with the bromine generator need to
follow the instructions on page 38.

8. Let the spa heat up.

When the spa has nished priming, the heater will

activate. Put the cover on and let the spa heat to the
set temperature.

www.calspas.com

2017 Portable Spa

LTR20171001, Rev. B

Priming the Pump

15

Preparing for Your New Portable Spa

New spa owners often have difculty the rst time they

start their spa and the pump fails to prime. This can be
frustrating, but these simple instructions can help you.

Sometimes air can become trapped in the pump while

lling the spa. You will know this has happened when after you have lled and started the spa, the pump does

not seem to function. You will hear the pump operating, but no water will be moving.

The pump will not work properly while
air is trapped in it. Continuing to operate
the pump in this way will cause damage.

Starting Up: Priming Mode

After the initial start-up
sequence, the spa will enter
Priming Mode, which lasts 4
to 5 minutes. Depending on
your control panel, one of the messages shown at right will
appear.

As soon as the Priming Mode screen appears on the panel,
press the Jets or Jets 1 button once to start Pump 1 in low
speed and then again to switch to high speed. Also, select
the other pumps, to turn them on. The pumps should be
running in high speed to facilitate priming.

Exit Jets 1 Jets 2 Jets 3 Circ

If the pumps have not primed after two minutes, and water

is not owing from the jets in the spa, do not allow the

pumps to continue to run. Turn off the pumps and repeat
the process. Note: Turning the power off and back on again
will initiate a new pump priming session.

Sometimes momentarily turning the pump off and on will

help it to prime. Do not do this more than ve times. If the pumps will not prime, shut off the power to the

spa and call for service.

Important: A pump should not be allowed to run without priming for more than two minutes. Under NO
circumstances should a pump be allowed to run without priming beyond the end of the 4 to 5 minute priming
mode. Doing so may cause damage to the pump and cause the system to energize the heater and go into
an overheat condition.

Priming Mode

Exiting Priming Mode

You can manually exit Priming Mode by pressing an Up or Down button. Note that if you do not manually
exit the priming mode as described above, the priming mode will be automatically terminated after 4 to 5
minutes. Be sure that the pumps have been primed by this time.

Once the system has exited Priming Mode, the top-side panel will momentarily display the set temperature
but the display will not show the temperature yet. This is because the system requires approximately one

minute of water owing through the heater to determine the water temperature and display it.

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

16

Bleeding Air from the Pump

If you have tried priming the pump several
times unsuccessfully using the control panel,
you can bleed the air from the pump manually.

1. Shut off the power to the spa.

2. Using a Phillips screwdriver, remove the
front panel from the spa and locate the
pump.

3. Close the gate valve on the discharge side
of the pump (if your spa is installed with
one.)

4. Turn the bleeder valve counter clockwise
with a small pair of pliers until the air has
been released from the pump.

5. If this is unsuccessful, loosen the union nut
on side of the pump with channel locks.
When air is bled out, tighten the nut.

Preparing for Your New Portable Spa

6. Turn on power to the spa and press the
JETS button. If there is still air trapped in
the pump, repeat steps 2 through 5 until
the pump primes.

www.calspas.com

2017 Portable Spa

LTR20171001, Rev. B

Operating Your Spa

SET

RANGE

SET

SET

RANGE

READY

RANGE

FLTR1

SET

1

READY

SET

2

Adjust the set
temperature

Set temperature
ranges

Select heat mode

Set time of day

Flip (invert display)

Lock the display
(restrict operation)

Hold mode (standby)

Adjust ltration cycle 1

Adjust ltration cycle 2

Set personal
preferences

System utilities
(for diagnostics only)

Main screen

Press

2X

3X

4X

5X

6X

7X

8X

9X

10X

1X

1X

To go through all menus:

(1) Press the

Temperature button

1

2

(2) Then press the
Light button.

Each time you
press the Light
button, it will
take you to the
next menu item.

TP400 and TP600 Control Panel Operation

Primary Navigation and Functions

Navigating and programming the entire menu
structure is done with 2 or 3 buttons on the control
panel.

During normal operation, the control panel will show
the actual temperature of the water, as the control
panels above show.

There are eleven settings, or menu items, you can
access in the control panel. To access them in order,
start by pressing the Warm or Cool button once.

The Set Temperature will start to ash.

While the set temperature is still ashing, press the

Light button. This will take you to the next menu
item. Each time you press the Light button, it will
take you to the next screen.

17

Operating Your Spa

The gures below show the order the menu items

appear. Tap each menu item to go to the section that
explains its function.

TP400 Control Panels

Warm Cool Light Jets Aux

For one pump systems

For two pump systems

TP600 Control Panel

TEMP JETS AUX

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

18

Jets and Pumps

Jet Operation

One Pump Systems
Uses the TP400 control panel

Single pump systems are all two-speed pumps.

To operate the jets, press the JETS button:

• Once to turn on low speed.

Operating Your Spa

• Twice to turn on high speed.

• Three times to turn off the pump.

Two pump systems
Uses either the TP400 or TP600 control

panel

Press the Jets or Jets 1 button:

Press the Aux or Jets 2 button:

• Once to turn on low speed.

• Twice to turn on high speed.

• Three times to turn off the pump.

What is the difference between a 24-hour
circulation pump and a two-speed pump?

Circulation Pump - A 24-hour circulation pump

is an optional, dedicated low power pump just

for ltration. A circulation pump will reduce wear

and tear on main pump and can cost less to run

than using pump 1 for ltration. When a spa has

a circulation pump, pump 1 will have only one
speed.

Although it can be set to run continuously, some

spa owners prefer to reduce their ltration times

in order to lower their energy cost. See “Adjusting
Filtration” on page 22.

Two-Speed Pump - Spas without a circulation
pump use the low speed setting of pump 1 as a
circulation pump. Pump 1 will have two speeds,
low speed and high speed. Low speed is used for

ltration, and high speed is used for operating

the jets.

• Once to turn the pump ON.

• Twice to turn the pump OFF.

Three pump systems
Uses the TP600 control panel

Press the Jets 1 button:

• Once to turn on low speed.

• Twice to turn on high speed.

• Three times to turn off the pump.

Press the Jets 2 button:

• Once to turn the pump ON.

• Twice to turn the pump OFF.

Press Jets 3 button:

• Once to turn the pump ON

• Twice to turn pump OFF.

www.calspas.com

2017 Portable Spa

LTR20171001, Rev. B

Adjusting the Set Temperature

Press the WARM or COOL buttons to adjust the set temperature.

Press Once

When the temperature stops ashing, the spa will heat to the new set temperature

when required. The temperature can be set between 15.5°C and 40°C (60°F and
104°F).

19

Operating Your Spa

RANGE

SET

RANGE

SET

SET

Set Temp
will show
and flash

Press the Temp buttons to
change the temperature.

Setting Dual Temperature Ranges

You can set two temperature range settings with independent set temperatures.

Press Once

Then
Press

SET

RANGE

Once

The High Range is shown in the display by an “up” arrow and the Low Range with
a “down” arrow. The ranges can be used for different reasons, the most common
being a “ready to use” setting versus a “vacation” setting. (See “Vacation Setting”
below.) Each range maintains its own set temperature that you program according
to your needs. This way, when a range is chosen, the spa will heat to the set
temperature programmed to that range.

High Range can be set between 26.5°C and 40°C (80°F and 104°F).

Low Range can be set between 10°C and 37°C (50°F and 99°F).

The example below shows setting the Low Range temperature.

RANGE

SET

RANGE

SET

RANGE

FLTR1

READY

Main Screen

SET

RANGE

RANGE

FLTR1

FLTR1

READY

RANGE

RANGE

SET

FLTR1

FLTR1

Select High Range or Low
Range. Toggle the Range
arrows on the display.

Vacation Setting

Set the spa to operate in the Lower Range temperature choice before you go on vacation.

1. Press the Temp button. The “Set Temp” will show

and ash.

2. Press the Light button. “TEMP” will show on the
display, which give you the choice of High Range
or Low Range.

3. To set the Low Range, press the Light button,

2017 Portable Spa

LTR20171001, Rev. B

Set Temp will
show and flash

Press a Temp Button

Main Screen

repeatedly to change the
temperature.

then press the Temp button. The “Set Temp” will

show and ash.

4. Press the Temp buttons to adjust the temperature.

5. Press the Light button or wait several seconds to
return to the main screen.

www.calspas.com

20

Press Jets 1

Main Screen

Main Screen

READY and REST

Operating Your Spa

Setting the Heat Mode

There are two heat modes: READY Mode and REST Mode.

Press Once

Then
Press

READYSET

Toggle between

Ready-in-Rest Mode

READY/REST appears in the display if the spa is in Rest Mode and Jet 1
is pressed. When the spa is being used, it will heat to set temperature.
While Pump 1 High can be turned on and off, Pump 1 Low will run until
set temperature is reached, or 1 hour has passed. After 1 hour, the system
will revert to Rest Mode. This mode can also be reset by entering the Mode
Menu and changing the Mode.

Twice

SET

READY Mode: In order for the spa to heat, a pump needs to circulate water
through the heater. The pump that performs this function is known as the
“heater pump.”

The heater pump can be either a 2-Speed Pump 1 or a circulation pump. If the
heater pump is a 2-Speed Pump 1, READY Mode will circulate water every 1/2
hour, using Pump 1 Low, in order to maintain a constant water temperature,

heat as needed, and refresh the temperature display.
This is known as “polling.”

READY

RANGE

REST

FLTR1

REST Mode: REST Mode will only allow heating

during programmed lter cycles. Since polling does not

occur, the temperature display may not show a current
temperature until the heater pump has been running
for a minute or two.

RANGE

RANGE

REST

READY

/ REST

Setting Time

Press Once

Then
Press

3x

SET

Set hour Set minutes Main Screen

Flip (Invert Display)

Press Once

Then
Press

4x

Setting the time of day is important for determining ltration times and other

background features. 24-hour time display can be set under the PREF menu.

Note: This system does NOT display the time of day. The default
display on the Main Screen is the current water temperature.
Displaying time of day is not a selectable feature.

P

SET

P

SET

P

SET

P

READY

RANGE

FLTR1

Inverting the display allows you to be able to read the control panel while you
are in the spa.

SET

SET

READY R

ANGE

FLTR1

www.calspas.com

Press Temp button to
flip the display

Main Screen

2017 Portable Spa

LTR20171001, Rev. B

Locking the Control

hold

twice

Main screen

Press Once

Then
Press

5x

21

Operating Your Spa

The control can be locked to prevent unwanted use or temperature adjustments.
You can lock the set temperature or the control panel.

Locking the temperature allows Jets and other features to be used, but the Set
Temperature and other programmed settings cannot be adjusted.

Locking the panel prevents the controller from being used, but all automatic
functions are still active.

TO LOCK SET TEMPERATURE

SET

SET

Press Light button to

lock control panel

TO LOCK THE CONTROL PANEL

SET

Unlocking the control

While pressing and holding the
WARM Button, press the LIGHT
button twice.

SET

SET

You can toggle between ON and OFF
using the Warm and Cool buttons

SET

SET

You can toggle between ON and OFF
using the Warm and Cool buttons

FLTR1

ANGE

READY

R

Press and

Press

FLTR1

Main screen

READY

RANGE

The set temperature
has been locked

READY

RANGE

FLTR1

Main screen

The control panel
has been locked

READY

RANGE

FLTR1

Hold Mode

Hold Mode is used to disable the pumps during service functions like cleaning or

Press Once

Then
Press

2017 Portable Spa

LTR20171001, Rev. B

6x

Timer will count down for 60 minutes Main Screen

replacing the lter. (See page 44 for instruction on cleaning the lter.)

Hold Mode will last for 1 hour unless the mode is exited manually.

READY

FLTR1

RANGE

www.calspas.com

22

several seconds,

revert to the previous Filter 2 settings.

Adjusting Filtration

Press Once

Then
Press

7x

Main Filtration

Filter cycles are set using a duration. Each setting can be adjusted in 15-minute
increments. Filter Cycle 1 and Filter Cycle 2 (if enabled) are set to the same
duration.

If Filter Cycle 2 is enabled, Filter 2 will appear in the LCD. If Filter 2 is disabled,
Filter 1 will appear.

Operating Your Spa

1

Press Light button
to select Filter 2

2

SET

FLTR1

SET

Shows start
time

to show RUN HRS

FLTR1

to show F1 ENDS xx:xx

to set

to set

2

FLTR

SET

FLTR1 P

FLTR1

FLTR

2

*****

to set

FLTR1 P

SET

Sets start
hour

FLTR1

SET

Sets Filter 1
length in hours

SET

Sets
minutes

SET

Selects part
of an hour

A

to set

Note: Waiting several seconds will lose any
new Filter 1 Start Time and Run Hours and
revert to the previous Filter 1 settings.

If you wait several seconds, it
will revert to original setting.

FLTR1 P

FLTR1

*****

FLTR1 P

SET

Sets 15- minute
increments

*****

FLTR1

SET

Sets 15-minute
increments

If you wait

it will revert to

original setting.

READY

FLTR1

RANGE

Main Screen

READY

FLTR1

RANGE

Main Screen

2

FLTR

FLTR

www.calspas.com

2 P

FLTR

SET

Shows start
time

to show RUN HRS

2

2

FLTR

to show F2 ENDS xx:xx

to set

SET

Sets start
hour

2

FLTR

SET

Sets Filter 2
length in hours

A

SET

Sets
minutes

SET

Selects part
of an hour

2 P

FLTR

to set

Note: Waiting several seconds will lose any new
Filter 2 On/Off, Start Time and Run Hours and

*****

2 P

2 P

FLTR

FLTR

SET

Sets 15- minute
increments

*****

2

FLTR

SET

2

FLTR

Sets 15-minute
increments

READY

FLTR1

RANGE

Main Screen

2017 Portable Spa

LTR20171001, Rev. B

Setting Preferences

Press Once

23

Operating Your Spa

This allows you to set the following preferences for system operation:

• Change the temperature between Fahrenheit and Celsius

Then
Press

9x

• Change the clock between 12-hour and 24-hour display

• Turn periodic reminders (like “CLEAN FILTER”) on or off

SET

Toggle Fº en Cº

SET

Toggle 12-hour clock
and 24-hour clock

SET

SET

SET

to set

to set

SET

Toggle Yes and No

to set

Utilities

This menu feature is for system information only and is used mainly for repair and troubleshooting.

Other Spa Systems

Several spa functions operate in the background and require no action or maintenance from you. This is for
your information only.

Pumps

Press the “Jets 1” button once to turn pump 1 on
or off, and to shift between low- and high-speeds if
equipped. If left running, the pump will turn off after
a time-out period. The pump 1 low-speed will time
out after 30 minutes. The high-speed will time out
after 15 minutes.

On non-circ systems, the low-speed of pump 1 runs
when the blower or any other pump is on. If the spa
is in Ready Mode, Pump 1 low may also activate for
at least 1 minute every 30 minutes to detect the spa
temperature (polling) and then to heat to the set
temperature if needed. When the low-speed turns
on automatically, it cannot be deactivated from the

panel, however the high speed may be started.

Circulation Pump

The circulation pump will come on when the system

is checking temperature (polling), during lter cycles,

during freeze conditions, or when another pump is
on.

The ozonator will run with the circulation pump

during ltration cycles.

Purge Cycles

In order to maintain sanitary conditions, secondary
Pumps and/or a Blower will purge water from

their respective plumbing by running briey at the
beginning of each lter cycle.

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

24

Operating Your Spa

Diagnostic Messages

Message Meaning Action Required

RUN PMPS PURG AIR Priming Mode

Each time the spa is powered up, it will
enter Priming Mode. The purpose of
Priming Mode is to allow the user to run
each pump and manually verify that the
pumps are primed (air is purged) and

water is owing. This typically requires

observing the output of each pump
separately, and is generally not possible
in normal operation.

---F - ---C Water Temperature Is Unknown

After the pump has been running for
1 minute, the temperature will be
displayed.

42F TOO COLD Too Cold - Freeze Protection

A potential freeze condition has been
detected, or the Aux Freeze Switch has
closed, and all pumps and blower are
activated. All pumps and blower are ON
for at least 4 minutes after the potential
freeze condition has ended, or when
the aux freeze switch opens. In some
cases, pumps may turn on and off and
the heater may operate during Freeze
Protection.

WATR TOO HOT Water is Too Hot

One of the water temp sensors has
detected spa water temp 43.5°C (110°F)
and spa functions are disabled.

SFTY TRIP ---- Safety Trip - Pump Suction

Blockage

The Safety Trip error message indicates
that the vacuum switch has closed. This
occurs when there has been a suction
problem or a possible entrapment
situation avoided. (Note: not all spas
have this feature.)

HTR FLOW LOSS ---- Heater Flow Is Reduced

There may not be enough water ow

through the heater to carry the heat
away from the heating element.

HTR FLOW FAIL ---- Heater Flow is Reduced

There is not enough water ow through

the heater to carry the heat away from
the heating element and the heater has
been disabled.

Priming Mode lasts 4 minutes, but
you can exit it earlier by pressing
any Temp button. The heater is not
allowed to run during Priming Mode.

NOTE: If your spa has a Circ Pump,
it will turn on with Jets 1 in Priming
Mode. The Circ Pump will run by itself
when Priming Mode is exited.

None

None.

None. System will auto reset when
the spa water temp is below 42°C
(108°F ). Check for extended pump
operation or high ambient temp.

Drain or lter may be covered,

creating a blockage. Clear the
blockage and reset by pressing any
button on the topside panel.

Check for low water level, suction ow

restrictions, closed valves, trapped
air, too many closed jets and pump
prime. Heater start up will begin
again after about 1 minute.

Check for low water level, suction ow

restrictions, closed valves, trapped
air, too many closed jets and pump
prime. Heater start up will begin
again after about 1 minute.

www.calspas.com

2017 Portable Spa

LTR20171001, Rev. B

Message Meaning Action Required

HTR MAY BE DRY ---­WAIT ----

HTR DRY ---- Heater Is Dry

Heater May Be Dry

Possible dry heater, or not enough water
in the heater to start it. The spa is shut
down for 15 min.

There is not enough water in the heater
to start it. The spa is shut down.

Check for low water level, suction ow

restrictions, closed valves, trapped
air, too many closed jets and pump
prime. Press any button to reset the
heater start-up.

Check for low water level, suction ow

restrictions, closed valves, trapped
air, too many closed jets and pump
prime. Press any button to reset the
heater start-up.

HTR TOO HOT ---- Heater Is Too Hot

One of the water temp sensors has
detected 48°C (118°F) in the heater and
the spa is shut down.

PRES BTTN TO RSET

----

Spa Needs To Be Reset

This message may appear with other

Check for low water level, suction ow

restrictions, closed valves, trapped
air, too many closed jets and pump
prime. Press any button to reset
when water is below 42°C (108°F).

Press any button on the topside
control to reset.

messages.

102F SNSR BAL- ANCE Sensor Balance Is Poor

Call for service.

25

Operating Your Spa

The temperature sensors MAY be out of
sync by 1°C or 2°C (2°F or 3°F).

SNSR SYNC ---- CALL
FOR SRVC ----

Sensor Balance is Poor

The temperature sensors ARE out of
sync.

SNSR A ---- CALL FOR
SRVC

SNSR B ---- CALLFOR

Sensor Failure

A temperature sensor or sensor circuit
has failed.

SRVC

NO COMM No Communications

The control panel is not receiving
communication from the system.

102°T °F or °C is replaced by °T

The control system is in Test Mode.

STUK PUMP ---- A Pump Appears To Be Stuck ON

Water may be overheated.

HOT FALT ---- CALL FOR
SRVC ----

A Pump Appears To Be Stuck ON

A pump appears to have been stuck ON
when spa was last powered.

Call for service. Note: This message
can be reset from the topside panel
with any button press.

Call for service.

Call for service.

Call for service.

POWER DOWN THE SPA. DO NOT
ENTER THE WATER. Call for service.

POWER DOWN THE SPA. DO NOT
ENTER THE WATER. Call for service.

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

26

Operating Your Spa

TP800 Control Panel Operation

The Main Screen

Spa Status

When the spa has nished priming, you will see

the Main Screen. Important information about spa
operation can be seen quickly from the Main Screen.

The most important features can be accessed from
this screen.

• The actual water temperature can be seen in

large text and the desired, or Set Temperature,
can be selected and adjusted.

• Time-of-day, ozone operation and lter operation

status are shown, along with other messages
and alerts.

• Temperature Range (High or Low) is indicated in

the upper right corner.

• A Lock icon is visible if the panel or settings are

locked.

Water Temperature

Navigation

There are four selections you can

Desired Temperature

make on the Main Screen:

Set temperature - Press the left arrow
button to change the Set Temperature
number to white. The Set Temperature
can then be adjusted with the up and
down buttons. Pressing the Select
button or the Right Arrow button will

Status

102°F

Set: 104°F Spa
8:32 PM
Ozone
Filter 1

Ready in Rest Mode
Heating

save the new set temperature.

Setting Your Language Preference

You can set the TP800 control panel to one of six
languages: English, French, Spanish, German,
Italian, and Czech.

On the main screen, select Settings, then scroll
down to Preferences, and then select Language.

After you have made your selection, return to
Preferences and select Temp Display to change
the temperature display from Fahrenheit to Celsius.

After you have done this, return to the main menu.

The examples shown in this manual assume you
have selected English as your language preference.

Temperature Range

Pump and Heat

High Range

Scenes

Settings

Lock IndicatorMenusMessages

Left, Right, Up, Down,
and Select Buttons

www.calspas.com

2017 Portable Spa

LTR20171001, Rev. B

27

Menu selections - The three menu choices on the
right, Spa, Shortcuts, and Settings, can be selected
and the screen will change to show more detailed
controls or programming functions. They will be

Messages

At the bottom of the screen, messages may appear
at various times. Some of these messages must be
dismissed by the user (see page 30).

discussed further in this section.

Spa Screen

The Spa Screen shows all available equipment to control, as well as other
features, like Invert, in one easy-to-navigate screen. The display shows
icons that are related to the equipment installed on a particular spa model,
so this screen may change depending on the installation.

The navigation buttons are used to select an individual device. The device
that is chosen is highlighted with a white outline and the text under the icon
changes to white. Once a device is selected, it can be controlled using the
center Select Button.

Some devices, like pumps, may have more than one ON state, so the icon

will change to reflect the state that the equipment is in. Below are some

examples of 2-speed Pump indicators.

If the Spa has a Circ Pump, a Circ Pump Icon will appear to indicate its activity, but outside of Priming Mode,
the Circ Pump cannot be controlled directly. NOTE: The icon for the pump that is associated with the heater
(Circ or P1 Low) will have a red glow in the center when the heater is running.

Back Jets 1 Jets 2 Jets 3 Light 1

Invert

Ready in Rest Mode
Heating

Operating Your Spa

Settings Screen

The Settings Screen is where all programming and other spa behaviors
are controlled.

This screen has several features that can be acted on directly. These
features include Temp Range, Heat Mode, and Invert Panel. When one
of these items is highlighted, the Select Button is used to toggle between
two settings. All other menu items (with an arrow pointing to the right) go to
another level in the menu.

Setting Time of Day

Setting the time of day is important for determining ltration times and

other background features. “Set Time” will appear on the Main Screen if
no time of day is set.

Settings

Temp Range

Back

Heat Mode
Time of Day
Filter Cycles
Light Cycle
Invert Panel
Lock

Time of Day

12 : 00 PM 12 HR10:05 PM 12 HR

Save

Back

Cancel

High

Ready

Normal

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

28

Setting Dual Temperature Ranges

This system incorporates two temperature range settings with independent

set temperatures. The specific range can be selected on the Settings screen

and is visible on the Main Screen in the upper right corner of the display.

These ranges can be used for various reasons, with a common use being
a “ready to use” setting vs. a “vacation” setting. Each range maintains its
own set temperature as programmed by the user. This way, when a range is
chosen, the spa will heat to the set temperature associated with that range.

High Range can be set between 26.5°C and 40°C (80°F and 104°F). Low

Operating Your Spa

Range can be set between 10°C and 37°C (50°F and 99°F). More specific Temp Ranges may be determined

by the Manufacturer. Freeze Protection is active in either range.

Selecting Heat Modes – Ready vs. Rest

In order for the spa to heat, a pump needs to circulate water through the
heater. The pump that performs this function is known as the “heater pump.”

The heater pump can be either a 2-speed pump (Pump 1) or a circulation
pump. If the heater pump is a 2-Speed Pump 1, Ready Mode will circulate
water every 1/2 hour, using Pump 1 Low, in order to maintain a constant
water temperature, heat as needed, and refresh the temperature display.
This is known as “polling.”

Rest Mode will only allow heating during programmed filter cycles. Since

polling does not occur, the temperature display may not show a current temperature until the heater pump
has been running for a minute or two. While Pump 1 High can be turned on and off, Pump 1 Low will run until
set temperature is reached, or 1 hour has passed.

Back

Back

Settings

Temp Range

Heat Mode
Time of Day
Filter Cycles
Light Cycle
Invert Panel
Lock

Settings

Temp Range

Heat Mode

Time of Day
Filter Cycles
Light Cycle
Invert Panel
Lock

High

Ready

Normal

High

Ready

Normal

Circulation Mode

If the spa is configured for 24HR

circulation, the heater pump generally runs
continuously. Since the heater pump is
always running, the spa will maintain set
temperature and heat as needed in Ready
Mode, without polling. In Rest Mode, the
spa will only heat to set temperature during

programmed filter times, even though the
water is being filtered constantly when in

Circulation Mode.

Filter Cycles

Filter Cycle 1

Back

Starts at 12:00 AM
Runs 0 HR 0 Min
Ends at 12:00 AM

Filter Cycle 2 NO
Starts at 12:00 AM
Runs 0 HR 0 Min
Ends at 12:00 AM

Ready-in-Rest Mode

READY/REST appears in the display if the spa is in Rest Mode and the Jets
1 Button is pressed. It is assumed that the spa is being used and will heat
to set temperature. While Pump 1 High can be turned on and off, Pump 1
Low will run until set temperature is reached, or 1 hour has passed. After 1
hour, the System will revert to Rest Mode. This mode can also be reset by
entering the Settings Menu and changing the Heat Mode.

www.calspas.com

Filter Cycles

Filter Cycle 1

Save

Back

Starts at 6:15 AM
Runs 3 HR 0 Min
Ends at 9:15 AM

Cancel

Filter Cycle 2 NO
Starts at 12:00 AM
Runs 0 HR 0 Min
Ends at 12:00 AM

39°C

Set: 40°F
8:32 PM
Ozone
Filtre 1

Prêt/Repos
Chauffage

Haute Gamme

Spa

Scènes

Paramètres

2017 Portable Spa

LTR20171001, Rev. B

Setting Filter Cycles

Lock

Back

Settings

Panel

OFF

OFF

Filter cycles are set using a start time and a duration. Each setting can be adjusted in 15-minute increments.
The panel calculates the end time and displays it automatically.

Filter cycle 2 is off by default, but can be selected for use if desired.

Locking and Unlocking the Control Panel

29

Operating Your Spa

The control can be restricted to prevent unwanted use or temperature
adjustments.

Locking the Settings allows jets and other features to be used, but the
set temperature and other programmed settings cannot be adjusted.

When settings are locked, there is a reduced selection of menu items.
These include Set Temperature, Invert, Lock, Utilities, Information
and Fault Log. They can be seen, but not changed or edited.

Locking the Panel prevents the controller from being used, but all
automatic functions are still active.

Locking and Unlocking -- Use the
navigation buttons from the Lock Screen.

Press: Twice

The Lock and Unlock Sequence is the same
for both Panel Lock and Settings Lock.

Then
Press:

Additional Settings

Light Cycle

If Light Cycle does not appear in the Settings
Menu, the light timer feature is not enabled by the
manufacturer. When available, the light timer is OFF
by default. The settings can be edited the same way

as lter cycles.

Invert Panel

Selecting Invert Panel will ip the display and the

buttons so the panel can be easily operated from
inside or outside the hot tub.

Utilities

This menu feature is for system information only and
is used mainly for repair and troubleshooting.

Preferences

This allows you to set the following preferences for
system operation:

• Change the language on the control panel

• Change the temperature between Fahrenheit

and Celsius

Once

Lock

Settings

Back

Panel

40°C

Set: 40°C
8:32 PM
Ozone
Filter 1

Ready in Rest Mode
Heating

OFF

OFF

High Range

Unlock

Hold

Hold Mode is used to disable the pumps during

service functions like cleaning or replacing the lter.
(See page 44 for instruction on cleaning the lter.)

Hold Mode will last for 1 hour unless the mode is
exited manually.

2017 Portable Spa

LTR20171001, Rev. B

• Change the clock between 12-hour and 24-hour
display

• Turn periodic reminded (like “CLEAN FILTER”) on
or off

Information

This menu feature is for system information only and
is used mainly for repair and troubleshooting.

www.calspas.com

30

Operating Your Spa

Diagnostic Messages

Message Meaning

---F - ---C Water temperature is unknown. After the pump has been running for

one minute, the temperature will be displayed.

Possible freezing condition

The water is too hot

Water ow is low

Water ow has failed

The heater may be dry

The heater is dry

The heater is too hot

Sensors are out of sync The temperature sensors MAY be out of sync by 1°C or 2°C (2°F or

Sensors are out of sync -­Call for service

Sensor A Fault, Senor B Fault A temperature sensor or sensor circuit has failed. Call for service.

Communications error The control panel is not receiving communication from the System. Call

°F or °C is replaced by °T The Control System is in Test Mode. Call for service.

A potential freeze condition has been detected, or the Aux Freeze Switch
has closed. All water devices are activated. In some cases, pumps may
turn on and off and the heater may operate during Freeze Protection.
This is an operational message, not an error indication.

The system has detected a spa water temp of 43.5°C (110°F) or more,
and spa functions are disabled. System will auto reset when the spa
water temp is below 42°C (108°F). Check for extended pump operation
or high ambient temp.

There may not be enough water ow through the heater to carry the

heat away from the heating element. Heater start up will begin again
after about 1 min. See “Flow Related Checks” below.

There is not enough water ow through the heater to carry the heat

away from the heating element and the heater has been disabled. See
“Flow Related Checks” below. After the problem has been resolved, you
must press any button to reset and begin heater start up.

Possible dry heater, or not enough water in the heater to start it. The
spa is shut down for 15 min. Press any button to reset the heater start­up. See “Flow Related Checks” below.

There is not enough water in the heater to start it. The spa is shut down.
After the problem has been resolved, you must clear the message to
restart heater start up. See “Flow Related Checks” below.

One of the water temp sensors has detected 48°C (118°F) in the heater
and the spa is shut down. You must clear the message when water is
below 42°C (108°F). See “Flow Related Checks” below.

3°F). Call for service.

The temperature sensors ARE out of sync. The fault above has been
established for at least 1 hour. Call for service.

for service.

Flow-Related Checks

Check for low water level, suction ow restrictions, closed valves, trapped air, too many closed jets and

pump prime. On some systems, even when spa is shut down by an error condition, some equipment may
occasionally turn on to continue monitoring temperature or if freeze protection is needed.

www.calspas.com

2017 Portable Spa

LTR20171001, Rev. B

Cal Spas Hot Tub Wi-Fi App

The Cal Spas Hot Tub Wi-Fi app can provide you with instant access and control of your spa wherever you
connect within the spa’s Wi-Fi range. This optional feature is available for use with any smart device (Android™
or iOS™ systems only). You must have the Wi-Fi module installed in your spa in order to use the app. It is only
available for spas with the BP501 or BP2000 control box.

Spa owners who do not have this feature installed on their spa at the factory can order it as an after-market
item.

Installing the app

Go to the Apple app store or Google Play and search for the free spa app using the key words
“Cal Spas Hot Tub.” Select the app. The icon for the app will appear on your device as shown
at left.

Make sure you enable Wi-Fi on your phone before you run the app.

On the Wi-Fi connections screen on your device, a network will appear called “BWGSpa_
xxxxxx_”. (The x’s represent the Wi-Fi module’s local address and is unique for every spa.) Once you are
connected to the network, start the Cal Spas app and follow the prompts on the screen. (Your start screen
maybe different.)

31

Operating Your Spa

1. Tap the app button on the main screen of your device.

2. Connect to the spa’s Wi-Fi signal.

3. When connected, you will be

taken to the main app screen.

4. You are now directly connected to

your hot tub and can control all
the hot tub functions via the app.

Troubleshooting connection problems

You should have few problems connecting with the Wi-Fi app. However, if you are unable to connect quickly
and easily to the spa’s Wi-Fi source, try doing the following.

• Enable Wi-Fi on your device. This is the most likely reason you may not be able to connect to the app.

Check your devices Wi-Fi settings and try connecting again.

• Power cycle the spa. Shut off power to the spa for 30 second and turn it back on. Wait until the spa has

gone through its complete set-up routine before you try to connect with the Wi-Fi app.

• Wait until the spa has completely primed. When you turn on the spa, it will go through a priming routine,

which is followed by temperature polling, where no temperature is shown on the control panel. As soon
as a temperature appears, you can connect with the Wi-Fi app.

• If you use your home network router, it MUST be close enough to the spa in order for the spa’s Wi-Fi

signal to reach the router. If you have connectivity problems, you may need to relocate your router closer
to your spa or consider adding a wireless signal booster to your router.

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

32

Operating Your Spa

Connecting to a Device or Network

Direct connection

1

Range: About 20 feet
Range limit: Limited to the range

HOW TO CONNECT TO IT:
Install the app on your phone or device -- see the following section “Installing the app”.

Through home network with no internet access

2

Allows one local connection at a time

Range: About 50 feet
Range limit: Limited to the range of your

HOW TO CONNECT TO IT:

1. Install the app on your phone or device.

2. Exit the app and go to wi- settings on your phone or device.

3. Select and enable your local router.

4. Start the app. After you connect, select Settings on the home screen.

5. On the Settings screen, select Advanced, then on the Advanced screen, select Wi- Settings.

6. On the Wi- screen, select WPA. Then select the name of your home router from the drop-down menu.

7. Enter the SSID and Key for your router, the tap Save and select OK twice.

8. Close the app and re-start it to connect to your home network.

of the wi- module

home router’s signal

Through a network with internet access, using
Cloud connection or other hotspot connection

3

Allows unlimited simultaneous connections

Range: Worldwide
Range limit: Limited to 3G / 4G / hotspot

HOW TO CONNECT TO IT:
Follow connection instructions from section (2) above. The Cloud icon appears
automatically when network connection is made. You can then connect to the
spa’s wi- module.

Your

spa

Wi-

signal

availability

Phone or

other

device

Your home

network

router

Internet cloud

connection

Local wi-

connection

Internet

3G or 4G

Wi-

Local hotspot

www.calspas.com

2017 Portable Spa

LTR20171001, Rev. B

Cloud Service

Cal Spas Wi-Fi can be used as a point to point remote control to be added to any home network free of charge.
Those using the Cloud to access spa control from nearly anywhere in the world via the Internet will enjoy one
year Cloud service free of any access charge. After the initial year of Cloud service, the user will receive a notice
from the Cloud provider requiring a small charge for each continuing year of Cloud service. At the time of this
publication, the annual fee for this service is $24. Once your device is paired and connected, all sounds from
your device will be played through the spa’s optional sound system, including system sounds and telephone
messages. The Wi-Fi package contents are pictured below.

33

Operating Your Spa

For More Information

If you have any trouble connecting, you can nd more in-depth instructions at the Balboa Water Group web

site at www.balboawatergroup.com/bwa and download the PDF document “Setting Up Your Wi-Fi”.

There are also installation and setup videos at www.youtube.com/user/balboawatergroup.

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

34

Operating Your Spa

Electrical Power Efciency Adjustable Jets

Your new spa comes equipped with an electric heater.
Following the directions listed below will ensure the

most efcient operation:

NOTE: This method is only for spa usage under two
hours a week.

• Keep the spa’s operating temperature 3°C (5°F)

below the desired usage temperature when not
in use. One or two hours before use, set the
temperature to the desired temperature.

• If the spa usage exceeds two hours a week, the

set temperature should remain at the desired
usage temperature.

• The air venturis should be used sparingly. When

open, water temperature drops quite rapidly and
can also dissipate chemicals.

Allowing the water temperature to lower more than

5.5°C (10°F) below the desired usage temperature
and reheating it prior to usage will cause the heater
to operate longer than it normally would maintaining
the desired temperature. Doing this will increase your
operating cost and makes your heater work more than
necessary.

Almost all of the jets in your spa are adjustable.
Rotating the face of an adjustable jet to the left
(counter-clockwise) will decrease the amount of

water ow through the jet. Rotating the face of an

adjustable jet to the right (clockwise) will increase

the amount of water ow through the jet. (See

example shown below.)

Neck jets adjust in the opposite directions (counter­clockwise to increase, clockwise to decrease).

LED Lighting

Press the LIGHT button on the topside control panel
to turn the spa light on. If your spa has perimeter LED
lights, they will also light up at the same time as the
spa light.

The LEDs operate in three modes:

1. Cycle: When you continually press the LIGHT
button, the LEDs will cycle through the three main
LED colors (Red, Green, and Blue) or combinations
of the three that produce the following colors:
light green, purple, light blue, yellow, etc.

Each time you press the button, you immediately
advance to the next color in sequence or eventually
a different light pattern.

www.calspas.com

2. Flashing: When you are cycling through all the
colors, the next time you push the LIGHT button,

the LED lights may start ashing. This is another

normal operational pattern option.

3. Fading cycle: The next phase of operation when
you push the LIGHT button is a slow and/or fast
fade random transition from one color to the next.

Spas with exterior corner LED lighting generally work
in the same mode as described above. The variations
in color and patterns provide you with multiple options
to suit almost any lighting preference.

2017 Portable Spa

LTR20171001, Rev. B

Diverter Knobs

Diverter knobs are the larger knobs located around the top of your spa.
They allow you to divert water through jets from one side of the spa to the

other, or in most cases from oor jets to wall jets. This is accomplished by

rotating the diverter knob to the left (counterclockwise), decreasing the

amount of water ow through a section of jets. To increase the amount
of water ow through the other section of jets, rotate the handle to the

right (clockwise).

Waterfalls

Some spa series include optional waterfalls. When
the booster pump is on, rotate the dial on top (for
the cascade waterfall) or turn the knob (for the hydro
streamer -- see below).

35

Operating Your Spa

Air Venturis

Air venturis are the smaller knobs located around the top of your spa.
Each one will let you add a mixture of air with the jet pressure. This
is accomplished by rotating the air venturi knob to the left (counter-

clockwise) to increase the amount of airow through the jets. To
decrease the amount of airow through the jets, rotate the handle to

the right (clockwise).

Hydro Streamer Waterfall

Your spa may include two to eight streamer waterfalls. When the booster pump is on, turn the 1” diverter

knob to adjust the rate of ow to the waterfall jets.

The waterfall jet faces are not adjustable. Do not turn the jet faces because you may accidentally remove them.

Always shut off water to the hydro streamer jets before you place the cover on the spa. Water
from the hydro streamer jets sprays in an arc that
is higher than the top surface of the spa.
When water from the hydro streamer
sprays the bottom of the
cover, it will collect and
run to the edge of the spa
and drip over the top.

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

36

1

Low rolling bursts

2

Medium connuous burst

3

Accelerated connuous bursts

4

Swi rolling bursts

5

3 gentle bursts followed by 1 vigorous burst

6

Quick powerful, connuous bursts

7

Gentle & powerful alternang bursts

Warm Cool Light

Adjustable Therapy System

Pump On / Off Button

Press this button once to turn on the ATS pump. The
POWER ON light on the control panel will appear.
Press this button a second time to turn off the ATS
pump. The ATS pump must be on before you can use
any other features of this system.

Pulse Mode Button

Operating Your Spa

Press this button once to turn on the Pulse Mode.

The rst time it is pressed, the orange LED in position

number 1 will light, indicating the number one pulse
mode. Each press of either the Up or Down button
will move the orange LED up or down to the next
pulse mode. There are seven pulse modes in all. See
the image at right.

Allow one second between each button press. Pressing
the button quickly may cause improper operation. To
turn the Pulse Mode off and return to normal pump
operation, press the Pulse Mode button a second
time.

Up / Down Buttons

As described above, these buttons allow you to cycle
through seven massage modes. Each mode offers a
different pulsating massage. Some modes are faster

than others, so just cycle through them to nd the

massage you like best.

Time Reset

Pulse Mode will normally run for 15 minutes then
automatically shut off. For another 15-minute session,
press the Pump On / Off button and the Pulse
Mode button. A light will blink and the pump will run
on high-speed mode as part of a 15-minute cool down
period. After that, the pump will stop automatically
and the LED light on the panel will continue to blink

Pulse Modes

for one minute then
shut off automatically.
After the second
15-minute session, the
system will run through
a cool down cycle for
up to two hours. In this
cool down mode, the you
will only be able to operate
the pump (by again pressing the
Pump On / Off button). However, the massage mode
will remain off until the cool down mode is completed.

Resetting Pulse Mode

Pulse Mode will shut off for two hours unless reset.
During this time the pump will run at a maximum
speed. To reset Pulse Mode, press the Pump
On / Off to turn off the ATS pump, the press
the Pulse Mode button once. The power light
will ash to indicate Pulse Mode has been reset.

Microsilk Therapy System

The optional Microsilk feature is available with Connect and Escape spas only.

Aux

The Microsilk pump will run for 15 minutes or until you press Aux to turn it off. When the pump cycle nishes,
you can press Aux to start the Microsilk pump again.

www.calspas.com

The Microsilk system generates microbubbles that are 50 to 100 times smaller than ordinary air
bubbles. The microbubbles are oxygen-rich and help hydrate your skin.

Press the Aux button to start the Microsilk pump. When the spa water becomes saturated with the
microbubbles, it will turn white to create an ideal Microsilk environment.

2017 Portable Spa

LTR20171001, Rev. B

Pure Cure™ Water Sanitizer

The Pure Cure™ water sanitizer is an optional water purication system installed at the factory. It eradicates

germs in the water that are resistant to chlorine-based chemicals using high intensity UV light. Although the water
sanitizer works automatically with your spa, you will still need to test for chlorine or bromine and occasionally
replenish it to return the sanitizer level to the baseline.

For spas without a circulation pump, pump 1 will run at low speed and the water sanitizer will run during

ltration.

For spas with a circulation pump, the water sanitizer will run with the circulation pump.

The spa’s control system is factory-programmed with one lter cycle that will run in the evening when energy
rates are often lower. The time and duration of the lter cycle can be set according to your needs. In addition,
a second lter cycle can be enabled. Filtration time may need to be increased with heavy bather load.

See instructions for setting ltration cycles on page 22 or page 29.

The water sanitizer is virtually maintenance-free. Once a year the UV light needs to be replaced. See page
46 for instructions. However, the water sanitizer is not a user-serviceable item and maintenance

must be performed by a spa technician. Have your service technician consult the manufacturer’s
instruction and service manual.

37

Operating Your Spa

Ozonator

The ozone generator releases ozone into the spa water. You will still need to test for chlorine or bromine and
occasionally replenish it to return the sanitizer level to the baseline.

For spas without a circulation pump, pump 1 will run at low speed and the ozonator will run during ltration.

For spas with a circulation pump, the ozonator will run with the circulation pump.

The spa’s control system is factory-programmed with one lter cycle that will run in the evening when energy
rates are often lower. The time and duration of the lter cycle can be set according to your needs. In addition,
a second lter cycle can be enabled. Filtration time may need to be increased with heavy bather load.

See instructions for setting ltration cycles on page 22 or page 29.

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

38

Operating Your Spa

Bromine Generator

The bromine generator automatically generates and
releases free bromine into the spa water. You will still
need to test for bromine and occasionally adjust it to
return the bromine level to the baseline.

Start-up/Operating Instructions

Be certain that you start with a clean spa. It should
be free of contaminants and other residues that can
accumulate on the sides and/or around the jets. It
is also important to only use spa cleaning products
that have no phosphates or phosphonic acids since
phosphates will deplete free bromine and are super­food for algae. Always start your spa with a clean

lter before lling with water.

If the water source is “well water” or a non-municipal
water source, have your water tested for Total Dissolved
Solids (TDS) and metals. Water with high TDS is likely
to have higher metal content and will need a metal
remover to decrease the metals and ensure a successful
start. This test can be done by your local spa dealer. The
ideal range for your start-up TDS is between 50 and
200 ppm - mg/L. If TDS from your source water is above
500 ppm, a metal remover is strongly recommended.

DO NOT FILL THE SPA WITH SOFT WATER.

Use the phosphate test kit included with your system.

Bromide residuals will be signicantly reduced if

phosphate levels are high. If phosphates are detected,
purchase a phosphate remover and follow the
directions accordingly. Any phosphates in your spa
will reduce bromine levels.

3. Determine the level of “NaBr” (Sodium Bromide)
required for your spa size. NaBr should be added at
a rate of 1.2 lbs per 100 gallons or approximately
1300-1500 ppm.

Example: For a 500 gallon spa add
approximately 6 lbs of NaBr. 1.2 lbs x (5) 500
gallons = 6lbs NaBr.

1. Using your PURE FILL Spa Pre-Filter, ll your

spa with water to the recommended level (six
inches below the lip of the spa) and DO NOT FILL
WITH WATER FROM A “RESIDENTIAL WATER
SOFTENER.”

2. Before starting the system, balance your water
chemistry to ensure a successful start up. Ideal
ranges are as follows:

Ideal Range

Minimum Maximum

pH 7.2 7.6

Total alkalinity 80 ppm 120 ppm

Calcium hardness 150 ppm 250 ppm

Phosphates 0 ppb 30 ppb

4. Turn the jets on high speed. Sprinkle the NaBr
across the surface of the water to evenly distribute
the NaBr in the spa and circulate for 30 minutes.

5. Test the Sodium Bromide concentration with the
Tru-Blu NaBr test kit. The correct amount of NaBr
will secure a reading of between 1300-1500 ppm.

6. Adjust the ltration time to circulate for 8 hours
every 24 hours on a 2 speed pump.

7. For a spa between 300-500 gallons, start at a
power level of “6” and then press the “boost”
feature. This will accelerate the production of
bromine for 8 hours. Wait for proper bromine
levels before entering the spa.

8. Always keep your bromine level between 3-5ppm.
Test the bromine level after 24 hours and adjust the
power setting accordingly. An occasional heavier
bather load may require the “boost” feature.
Always keep your spa or hot tub water in balance.

www.calspas.com

2017 Portable Spa

LTR20171001, Rev. B

39

Maintaining the Bromine Level

Maintaining the pH and the alkalinity is part of being
a spa owner. The bromine generator requires you
to determine your power setting based upon your
circulation time and your spa usage. It requires a
minimum of eight hours of circulation per day. If the
spa is not circulating, the bromine generator is not

generating bromine. If you nd that you are having

trouble maintaining the desired level, make sure the
spa is circulating the required amount.

A spa that is frequently used will require a higher
power setting. If you have a bromine reading that is too
high or too low, adjust the DECREASE / INCREASE
control accordingly. Depending on the amount usage,
circulation time, and type of spa, each spa owner’s
setting will be different.

The bromine generator can go up to 12 months before

a drain and ll is required, unlike non-equipped spas

that require it every three months. This is because the
bromine generator does not add unwanted chemical
by-products like traditional chemicals do.

Sodium bromide is not the only contributor to the
TDS count in your water. Over time, the TDS count
in your water will rise (from such things as residuals

from other chemicals and minerals, and unlterable

material). Test the TDS every few months to make
certain it stays within range.

Shower prior to entering any hot tub or spa. This will
help prevent phosphate contamination and reduce the
demand on the bromine.

Shocking your tub is recommended after heavy bather
load.

Intelligent Controller Codes for the Bromine Generator

Operating Your Spa

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

40

Troubleshooting Water Clarity Problems

Problem Probable Causes Possible Solutions

Cloudy Water • Dirty lter

• Clean lter

Operating Your Spa

Water Odor • Excessive organics in water

Chlorine Odor • Chloramine level too high

Musty Odor • Bacteria or algae growth • Shock spa with sanitizer – if problem is

Organic buildup /
scum ring around
spa

Algae Growth • High pH

Eye Irritation • Low pH

• Excessive oils / organic

matter

• Improper sanitization

• Suspended particles /

organic matter

• Overused or old water

• Improper sanitization

• Low pH

• Low pH

• Buildup of oils and dirt • Wipe off scum with clean rag – if severe,

• Low sanitizer level

• Shock spa with sanitizer

• Add sanitizer

• Adjust pH and/or alkalinity to recommended

range

• Run jet pump and clean lter

• Drain and rell the spa

• Shock spa with sanitizer

• Add sanitizer

• Adjust pH to recommended range

• Shock spa with sanitizer

• Adjust pH to recommended range

visible or persistent, drain, clean and rell

the spa

drain the spa, use a spa surface and tile

cleaner to remove the scum and rell the spa

• Shock spa with sanitizer and adjust pH

• Shock spa with sanitizer and maintain

sanitizer level

• Adjust pH

• Low sanitizer level

Skin Irritation / Rash • Unsanitary water

• Free chlorine level above 5

ppm

Stains • Total alkalinity and/or pH

too low

• High iron or copper in

source water

Scale • High calcium content in

water – total alkalinity and
pH too high

www.calspas.com

• Shock spa with sanitizer and maintain

sanitizer level

• Shock spa with sanitizer and maintain

sanitizer level

• Allow free chlorine level to drop below 5 ppm

before spa use

• Adjust total alkalinity and/or pH

• Use a stain and scale inhibitor

• Adjust total alkalinity and pH – if scale

requires removal, drain the spa, scrub off the

scale, rell the spa and balance the water

• Use a stain and scale inhibitor

2017 Portable Spa

LTR20171001, Rev. B

Cleaning and Maintenance

Removing and
Reseating
the Pillows

You can remove the pillows for
cleaning and maintenance quickly and
easily. This method works for all types
of pillows.

Grab the lower edge of the pillow with

both hands rmly and pull up. As you

do this, the pillow inserts will pop out
of the holes.

Reseat the pillows by aligning the pillow
inserts with the holes and striking the
pillow hard enough to insert the pegs
back into the holes.

41

Cleaning and Maintenance

Jet Removal and
Replacement

Jets can be easily removed for cleaning.

Screw-in jet removal

Grasp the outer rim of the jet and turn it
counter-clockwise. The jet will unscrew

from the tting until it is free.

To replace the jet, place it in the tting

and turn it clockwise until it is snug in
place and it can be rotated freely about
half a turn. Do not overtighten the jet.

Snap-in SQR jet removal

Grasp the outer rim of the jet and turn
it counter-clockwise until it completely
stops. You may feel it slightly loosen pop

out a bit from the xture. Pull the jet
out from the jet xture. The jet will be

very snug and may require some force to
remove it. DO NOT PRY OUT JETS.

To replace any jet, place it in the tting

and turn it clockwise until it snaps in and
can be rotated freely about half a turn.
Do not overtighten the jet.

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

42

Draining Your Portable Spa

Your spa should be drained every four to six months for cleaning and maintenance and relled with fresh tap

water. See page 45 for instructions on cleaning the shell, cover, and pillows. See page 12 for instructions on

relling your spa. Before you begin, turn off power to the spa at the breaker and remove all lters.

1. Locate your drain.

For spas with drain inside the spa

Using a Phillips screwdriver, remove the screws to the
access panel and open it. Locate the drain as shown
below.

Cleaning and Maintenance

2. Remove the cap

Make sure the valve is in the closed position, then unscrew and remove the cap.

For spas with drain inside the spa

For spas with cabinet mounted drain

Pull the knob out of the cabinet. The cabinet drain is
screwed into the drain pull knob.

For spas with cabinet mounted drains

3. Connect valve to a garden hose.

Attach a garden hose to the hose-bib xture. Place the other

end of the garden hose where you would like the water to
drain.

4. Drain the spa.

Turn the valve on the hose-bib xture to open the drain.

When the spa has drained completely, turn the valve on the

hose-bib xture, remove garden hose, and replace the cap.

www.calspas.com

For all spas

2017 Portable Spa

LTR20171001, Rev. B

Winterizing (Cold Climate Draining)

In many areas of the country, the temperature drops below 32˚F (0°C). We recommend that you always have
your spa full of water and running at normal spa temperatures (80˚F to 100˚F, 26.7°C to 37.8°C). This will help

reduce the risk of freezing in your spa and your spa’s equipment.

Warning: If you nd the need to drain your spa, be aware of the potential of freezing in your

spas equipment and plumbing. Even if the directions below are followed perfectly, there is no
guarantee that your spa will not suffer freeze damage. Freeze damage is not covered by your
warranty.

1. Remove the lter baskets and lters.

2. Drain your spa completely as described in the instructions above.

3. Vacuum water from the spa’s main drain and from the jets with a wet/dry vacuum.

4. Open the bleeder valves on the pumps.

5. Disconnect the unions from both sides of all pumps.

6. Blow any remaining water out of the jets and equipment area with the wet/dry vacuum.

7. When the spa has completely nished draining, close the bleeder valves and re-connect the unions on all

pumps. Replace the lters and lter baskets.

Cover your spa with a good spa cover and an all-weather tarp to ensure that neither rain nor snow enters the spa.

43

Cleaning and Maintenance

Vacation Care

You can leave your spa unattended for up to two weeks if you follow these instructions.

ALWAYS lock your cover using the cover locks if you plan to be away from home and the spa is

lled with water.

1. Select the Low Range temp choice used for vacation mode. (See instructions on page 19 or page 28 for
vacation setting.)

2. Adjust the pH.

3. Shock the water (add either chlorine or bromine sanitizer).

4. When you return, check and adjust the pH and shock the water.

If you will not be using your spa for longer than 14 days and a spa maintenance service is not available, we
strongly recommend you drain or winterize your spa.

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

44

Spa Cover

Important! Keep the spa covered when not in use!

• Covered spas will use less electricity in maintaining your set temperature.

• Covering your spa will protect your spa’s nish from the sun’s ultraviolet rays.

• You are required to keep the spa covered to maintain warranty coverage.

• Covering your spa helps prevent children from drowning in the spa.

See the manual enclosed with your cover for instructions on mounting the locks and how to lock and unlock
the cover.

In addition, while the spa cover is rigid, it is not designed to support any weight. Therefore, as a safety
precaution and to preserve the life of your cover, you must not sit, stand, or lie on it, nor should you place
objects of any kind on top of it.

Cleaning and Maintenance

Filter Cleaning

The lter is the part of your spa that removes the debris from the water and needs to be cleaned on a regular
basis to maximize your spa’s ltering performance and heating efciency.

In addition to spraying off the lter weekly to remove surface debris, your lter should be deep cleaned
periodically to dissolve scale and particles that get lodged deep within the lter bers and impede the ltration
process. Even if the lter looks clean, scale and particles can clog the bers and prevent water from owing
through the lter resulting in the most common spa problem—no heat, caused by a dirty lter.

We recommend you clean your lter once a month and replace it once a year or as necessary.

It is extremely important that you never run the spa without a lter. There is a possibility that
debris may be sucked into the plumbing through the lter well.

Set the spa in Hold Mode before you remove the lter. Hold Mode pauses all spa operations for
60 minutes for service functions like cleaning or replacing the lter. See page 21 or page 29 for

instructions on using Hold Mode.

Cleaning the lter

1. Remove the lter by unscrewing it and pulling it up and out.

2. Place the dirty lter into a bucket of water deep enough to cover the lter. Add 8 oz of liquid lter cleaner

to the bucket of water.

Note: It is a good idea to keep a spare lter to use in the spa while the dirty lter is being deep cleaned.
This way, you can rotate the lters and both will last longer.

3. Soak the lter for a minimum of 24 hours.

4. Spray the lter with a water hose. Spray each pleat carefully.

5. Reinstall the lter. Do not overtighten.

www.calspas.com

2017 Portable Spa

LTR20171001, Rev. B

Cleaning Your Spa

Spa Cover and Pillows

Due to the constant punishment your spa cover and pillows receive, you should protect them by applying

a vinyl and leather cleaner as part of your monthly maintenance plan. Use a product that is specically

designed to protect spa covers and pillows from chemical and ultraviolet light damage without leaving an
oily residue behind that is normally associated with common automotive vinyl protectants.

Warning: Do not use automotive vinyl protectants on spa covers or pillows. These products are generally

oil-based and will cause severe water clarity issues that are difcult to correct.

Spa Shell

Each time you drain your spa, before you rell it you should clean your spa shell with an all-purpose cleaner

and apply a coat of surface protectant.

Use a low detergent, non-abrasive cleaner specically formulated to clean the spa without damaging its

acrylic nish.

Use a non-oil based surface protectant that is specically formulated to protect the spa’s nish from the

chemicals and minerals associated with normal spa use.

45

Cleaning and Maintenance

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

46

Changing the UV Lamp

CAUTION: Always turn off power to the spa at
the GFCI prior to any maintenance.

Note: Periodically you should the check the light on the transformer for the
UV light system. The transformer is mounted in the spa equipment area
close to the system control box. When it is operating normally, the light will
be green. When it requires maintenance, it will be red. This usually happens
when the UV lamp needs replacing. The UV lamp is a wearable part that
needs replacing about once a year.

1 Water-proof strainer

Cleaning and Maintenance

2 Aluminum nut

3 Lamp socket and lead wire

4 Germicidal UV lamp

5 Rubber O-ring

6 Quartz thimble

7 Chamber

8 Clip

9 Ballast

See page 54 for part numbers for
replacement parts.

To remove the UV lamp

1. Disconnect power.

2. Turn water off and open down stream of system

to relieve pressure.

3. Cut the tie wrap that attaches the UV lamp

chamber to the spa frame.

4. Remove the water-proof strainer (1) and unscrew

the aluminum nut (2).

5. Pull out the lamp (4) approximately 2” from the

chamber (7).

6. While holding the lamp end, remove the lamp

socket (3) from the end now exposed.

7. Remove the lamp from the chamber.

8. Remove the O-ring (5) from the end of the quartz

thimble (6).

9. Remove the quartz thimble.

When replacement UV lamp has been installed,

conduct a nal leak check:

1. Restore power to the spa at the GFCI.

2. Turn on the pump and let water run for ve

To reinstall the replacement UV lamp, follow these
steps in reverse.

www.calspas.com

minutes to check for leaks.

2017 Portable Spa

LTR20171001, Rev. B

Maintenance Schedule

Each time you rell the spa Follow the section “Filling and Powering Up Your Portable Spa” on

page 12.

Prior to each use Test the spa water using either test strips a reagent test kit. Adjust

chemical levels as necessary.

Once a week Test the spa water using either test strips a reagent test kit. Adjust

chemical levels as necessary.

If your water source is high in calcium, add stain and scale preventer.

Once a month Deep clean your spa’s lter. (Follow lter cleaning instruction at

beginning of this section)

Every two to four months Change the spa water. How often you change the water depends

on how much you use the spa. When you change the water, you
will need to:

47

Cleaning and Maintenance

• Clean and polish the acrylic surface (see page 45)

• Clean and treat the spa cover and pillows (see page 45)

• Deep clean the lter (see page 44)

• Rell your spa (see page 12)

Once a year Replace lter cartridges if the pleats appear frayed.

If you use the Cal Pure UV water sanitizer, you will need to replace
the UV lamp (see page 46 for UV lamp maintenance)

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

48

Using the Entertainment System

The digital media locker is fully integrated with your
Cal Spa. It will accommodate any digital device, such
as iPhones, smart phones, and MP3 players, that is
USB or Bluetooth capable.

The docking station comes with its own owner’s
manual. It describes parts included, installation, and
proper use. Owners of this system must read the
manufacturer’s instructions prior to operating this
unit. The instructions are shipped inside the docking
station behind the remote control.

The instructions contained in this manual describe
only basic functions. See the manufacturer’s operating
instructions for other features and functions.

Although the media locker features a locking door with
seals, it is water resistant and NOT waterproof.
You must take every precaution to keep the interior of

Using the Entertainment System

the media locker dry.

• Make sure that hands are dry before coming in

contact with the media locker.

• Always CLOSE AND LOCK the protective door.

Water damage caused by negligence or
improper use is not covered under warranty.

Note: The digital media locker comes with a
remote control and does NOT INCLUDE an MP3
player such as an iPod.

Aquatic AV AQ-DM-5UBT

Synchronizing (Pairing) the Remote
Control with the Media Locker

Before you can use the remote control with the
docking station, they need to be synchronized, or
paired. Follow the simple instructions below.

Before you begin, make sure the docking bay
is OFF. If the red Power light inside the dock-

1

ing bay is on, press it once to turn it off.

2

Press the red Power button on the remote.

Press and hold the Mode button

3

on the remote. The display on the
remote will read PAIR.

While still holding the Mode button, press and hold the Power

4

button inside the docking station for five seconds.

If you have trouble pairing the
devices:

• Re-read the instructions and follow

them carefully. You may have missed an
important detail.

• Make sure the red power light inside the

docking bay is OFF before you begin.

• PRESS and HOLD the Mode button on the

remote until it reads PAIR. Do not release
the Mode button.

• Do not press the Power button inside the

docking station until the remote reads
PAIR.

• Press and hold the Power button for NO
MORE than ve seconds. Otherwise, the

devices will not pair.

www.calspas.com

The display on
the remote will
read WELCOME
or show a mode
position such as
RADIO.

If they do not pair the first time, repeat these four steps
until it is successful.

When the remote
and docking bay
are paired, the
power button
light will turn
blue.

2017 Portable Spa

LTR20171001, Rev. B

49

Listening to Devices

There are three ways to connect your device to the
media locker: With the USB connection, Bluetooth
connection, and the auxiliary input.

1. Connecting via USB

The Aquatic AV digital media locker comes with one
USB connector for Apple devices. If you have another
kind of device, you will need to supply your own USB
connector, such as the type shown below.

Apple USB connector USB micro B connector

1. Attach your device to the USB cable inside the
digital media locker using the appropriate USB
connector.

2. Secure the device with the anchor straps.

3. Close and lock the media locker’s protective door.

4. Press POWER on the remote control or Power
button on the locker to turn it ON.

5. Once you nd the desired media, press PLAY/

Using the Entertainment System

PAUSE to make your selection. If your selection is
a song, it will begin to play. If you select a playlist,
artist, album, genre, composer or audio book, the
songs in the selected folder will be visible. Press
PLAY/PAUSE to play the desired song within the
folder.

Other USB devices

1. Press SEARCH to enter the USB searching mode.

2. Press Volume UP/DOWN to scroll through the
folders on your USB device. To select a folder,
press the PLAY/PAUSE button.

3. Press Volume UP/DOWN to scroll through the
songs in the folder and press PLAY/PAUSE to
play the desired song.

2. Connecting via Bluetooth

1. Switch on your Bluetooth device.

2. Select ‘AQUATIC AV’ from the list of available
devices to pair (no password is needed).

Only one Bluetooth device can be paired with the
Digital Media Locker at any time.

Bluetooth mode will be activated once a Bluetooth
device is linked. Play the song from device and the
sound will play through the Digital Media Locker.

5. Press MODE on the remote control to select USB
mode. Use the buttons as shown in the remote
function chart.

Note: When USB devices are connected to the
USB input, the device’s battery will charge.

Search for Songs and Playlists

Apple devices

1. Press SEARCH to enter iPod searching mode.

2. Once in searching mode, the remote will display
‘Playlist’. Continue to press SEARCH to scroll
through the search modes below:

1) Playlist 2) Artist 3) Album 4) Song 5) Genre

6) Composer 7) Audio Book

3. Press PLAY/PAUSE To select the desired search
mode.

4. Press Volume UP/DOWN to scroll through your
media in the selected search mode.

• Press PLAY/PAUSE to play or pause the

song.

• Press FAST REWIND or FORWARD buttons
to play previous/next song le.

Track and volume can be controlled directly from your
Bluetooth device, remote control or door controls.

3. Connecting via Auxiliary Input

When you connect your device via the auxiliary input,
you play media directly to the audio input of the media
locker. The remote control can not control your device
when it is connected through the auxiliary input. You
will need a 3.5 mm audio connector as shown below.

3.5 mm audio cable

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

50

1. Connect your MP3 device to the 3.5 mm jack
input.

2. Secure the device with the anchor straps.

3. Close and lock the media locker’s protective door.

4. Press POWER on the remote control or the
POWER button on the locker to turn it ON.

5. Press MODE on the remote control to select ‘AUX
IN’ mode.

Only one auxiliary input (3.5 mm jack) can be used at
any one time.

Listening to FM Radio

Press MODE on remote control to switch to FM radio

mode. If this is the rst time you listen to FM radio,

the default frequency will be 87.5MHz, as shown on
the remote LCD.

Closing and Locking the Door

Always CLOSE and
LOCK the media locker
door after you place or
remove a media device
inside it.

Slide the clasp down to
lock the door as shown
at right. Make sure the

door is rmly pressed

into the watertight seal
before you slide the
lock into place.

Water damage
caused by
negligence or
improper use is
not covered under

Using the Entertainment System

REWIND or FAST FORWARD to seek another

To scan or seek FM radio channels, press FAST

warranty.

station. Press and hold either FAST REWIND or
FAST FORWARD for manual tuning back or forward.

To save the current radio station into memory, press
and hold the 1, 2, or 3 button for more than 2 seconds.
The station will be stored to that button. Press the 1,

2, or 3 button to listen to the preset station.

Remote and Keypad Functions

All of the functions on remote control and the keypad
on the media locker’s door are identical.

For a detailed description of all key functions, see the
manual for the Aquatic AV media locker.

Search functions
and audio menu

Volume UP

Fast rewind /

previous track

Volume DOWN

In USB mode:

Folder functions

In FM mode:

radio presets

Mode
(select function)

Play / pause

Fast forward /
next track

Random
playback

Power

www.calspas.com

2017 Portable Spa

LTR20171001, Rev. B

Using the Freedom Sound System

The Freedom Sound System™ entertainment option contains a Bluetooth-enabled speaker system
that is available for certain Cal Spa models. Any Bluetooth-enabled device can be used to play audio
through your spa.

Before you can use the sound system, you need to pair the Bluetooth module with your device. The Bluetooth
module is installed within the spa cabinet. Everything can be done with your device. The example shown below
is from an iPhone device. Your device may appear differently. Before you begin, make sure Bluetooth in enabled
on your device.

1. Select Bluetooth from your device’s option list.

2. Select SWA8-1BT... from the list of available devices to pair.

3. Allow your device to pair with the spa’s Bluetooth module.

4. When the devices have been connected, the device SWA8-1BT... will be highlighted.

Only one Bluetooth device can be paired with the Freedom Sound System™ at any time.

Once your device is paired and connected, all sounds from your device will be played through the sound system,
including system sounds and telephone.

1 2 3 4

51

Using the Entertainment System

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

52

Keeping Fit With Your Swim Spa

Jetstream Propulsion System

Use the control panel to start and stop the Jetstream Propulsion
System. The JETS 1 and JETS 2 buttons control the top and
bottom jets.

Use the air venturi valves to inject air in the water streams.

Assembling the Swim Tether

Keeping Fit With Your Swim Spa

The swim tether pole has three pieces and assembles
easily. Slide the ends of the top and middle sections
into the middle and bottom sections as shown at right.

Insert the tether in the anchor hole when you are
ready to use it.

Buckle the strap around your waist. It is easily
adjustable and can accommodate most sizes.

Using the Exercise Equipment

IMPORTANT: Always consult your physician before starting any exercise activity or program. The Ultimate
Fitness series spas feature rubber exercise bands. When stretched, these bands create a high tension condition.
Improper use or failure to connect the exercise bands properly may cause injury. Always inspect all of the
exercise equipment prior to beginning any exercise. Do not use any damaged equipment.

This equipment attaches to the exercise anchors located on the spa walls.

Connecting the Exercise Equipment

The drawings below show different ways the exercise kit can be connected depending on the exercises you
wish to do.

For 14 foot spas and model F1222

The exercise kit contains:

• Two hand grips

• Two ankle braces

• Two 6” elastic bands

• Two 18” elastic bands

• Two 25” elastic bands

• Two rowing bars

For 16 and 17 foot spas

The exercise kit contains:

• Two hand grips

• Two ankle braces

• Two 18” elastic bands

• Two 25” elastic bands

• Two 56” elastic bands

• Two rowing bars

www.calspas.com

2017 Portable Spa

LTR20171001, Rev. B

When attaching the

6” bands with

hand grips

56” bands

with hand grips

When attaching the
rowing bar, place the
hook into the eye pad
as shown.

6” bands with

hand grips

18” band

25” bands

56” bands

with hand grips

When attaching the
rowing bar, place the
hook into the eye pad
as shown.

Elastic bands attach
to the eye pad as
shown.

All elastic bands can be connected to
the end of the spa and used with
either hand grips or ankle braces.

6” bands with

hand grips

18” band

25” bands

18” band

25” bands

56” bands

with hand grips

Elastic bands

with hand grips

rowing bar, place the
hook into the eye pad
as shown.

Elastic bands attach
to the eye pad as
shown.

53

Typical conguration for F1222 spa

Keeping Fit With Your Swim Spa

18” band

All elastic bands can be connected to
either end of the spa and used with hand
grips or ankle braces.

Typical conguration for 14’ spa

Typical conguration for 16’ and 17’ spa

56” bands

56” bands

with hand grips

2017 Portable Spa

LTR20171001, Rev. B

25” bands

18” band

www.calspas.com

54

Appendix

Note: All Cal Spa models use a combination of screw-in and snap-in jet inserts where removable jets are used.

Appendix

Replacement Parts

Please visit www.quickspaparts.com
to order your replacement parts.

Screw-in Jet Inserts

Description Used by

ELE 2” Euro No Eyeball

PLUCS2295021SL

ED 2” Euro Directional

PLUCS2295051SL

MED 3” XL Cluster Storm
Directional

PLUCS2295031SL

Escape

Escape+

Escape

Escape+

Escape

Escape+

Screw-in Jet Inserts

Description Used by

MM 3” Mini Storm Massage

PLUCS2297061SL-8

MFD 3.5” Maxi Flow
Directional

PLUCS2295091SL

Escape

Escape+

Escape

Escape+

mfd 3” Micro Flow Directional

PLUCS2295061SL

www.calspas.com

Escape

Escape+

PSD 5” Power Storm

PLUCS2295131SL

If you need jet bodies, go to www.quickspaparts.

com or refer to the Cal Spa Replacement Parts
Catalog, which can be downloaded from www.
calspas.com/replacement-parts.

2017 Portable Spa

Escape

Escape+

LTR20171001, Rev. B

Screw-in Jet Inserts

Please visit www.quickspaparts.com
to order your replacement parts.

Screw-in Jet Inserts

55

Appendix

Description Used by

ET 2” Cluster Storm Twin

PLUCS2295161SL

MMP 3” Mini Multi-Massage

PLUCS2295171SL

PSTR 5” Power Storm Twin
Roto

PLUCS2295181SL

Escape

Escape+

Escape

Escape+

Escape

Escape+

Description Used by

PST 5” Power Storm Wagon
Wheel

PLUCS2295191SL

T 5” Tornado Adjustable

PLUCS2295201SL

Escape

Escape+

Escape

Escape+

PSR 5” Power Storm Ried

PLUCS2295141SL

2017 Portable Spa

LTR20171001, Rev. B

Escape

Escape+

If you need jet bodies, go to www.quickspaparts.
com or refer to the Cal Spa Replacement Parts
Catalog, which can be downloaded from www.
calspas.com/replacement-parts.

www.calspas.com

56

Please visit www.quickspaparts.com
to order your replacement parts.

SQN candy cane, 2” neck jet,
100% shut-off

Appendix

Candy cane w/clear center

PLU29923-144-000

SQN halo, 2” neck jet, 100% shut­off

Halo w/ graphite gray center

PLU29520-611-500

Snap-in SQR Jet Inserts

Description Used by

Used by:

Escape

Escape+

Platinum

Fitness

Used by:

Patio

Patio+

Snap-in SQR Jet Inserts

Description Used by

SQ3D, 3” directional mini jet

Halo w/ graphite eyeball

PLU29530-111-500

SQ3M halo, 3” mini massage jet

Halo w/ graphite center

PLU29530-141-500

Used by:

Patio

Patio+

Used by:

Patio

Patio+

SQ2D, 2” euro jet directional

Halo w/ graphite gray eyeball

PLU29520-011-500

SQ2R, 2” rotating jet

Stainless steel w/ black rotors

PLU29523-022-100

Used by:

Patio

Patio+

Used by:

Escape

Escape+

SQ4D, 4” directional maxi ow

jet

Halo w/ graphite gray eyeball

PLU29540-111-500

SQ5R, 5” rotational jet

Halo w/ graphite gray eyeball

PLU29550-081-500

Used by:

Patio

Patio+

Used by:

Patio

Patio+

If you need jet bodies, go to www.quickspaparts.
com or refer to the Cal Spa Replacement Parts
Catalog, which can be downloaded from www.
calspas.com/replacement-parts.

www.calspas.com

2017 Portable Spa

LTR20171001, Rev. B

Please visit www.quickspaparts.com
to order your replacement parts.

57

Snap-in SQR Jet Inserts

Description Used by

MM, 7” ultra blaster

Stainless steel w/ black center

PLU23570-142-400

Used by:

Escape

Escape+

Swim Jet

River Jet Assembly Black with Stainless Steel
Rim 210-5101SCS

PLU210-5101SCS

Jet Insert 3” Pro-Loc
SQ3R Mini Jet Roto

PLU29530-121-500

Appendix

If you need jet bodies, go to www.quickspaparts.
com or refer to the Cal Spa Replacement Parts
Catalog, which can be downloaded from www.
calspas.com/replacement-parts.

Jet Insert 3-5” Pro-Loc
(SQ3.5R) Mini Twin Roto

PLU29530-031-500

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

58

Please visit www.quickspaparts.com
to order your replacement parts.

Rain Jet

PLU23028-292-00

Appendix

SQL, SQR dual hydrostream (#25269-404-

000) - includes jet insert, jet body, gasket
and nut

PLU25269-404-000

Rain Jet

Water Feature

Pillows

Cascade Pillow No
Insert Black

ACC01401031

Innity Pillow

Ribbed Black

ACC01401051

Innity Pillow Plain

Black

ACC01401061

Waterfalls

Waterfall 12-3/8”
W/ Logo, LED
(Round) Textured
(CS675952T8L-1) ‘14

PLU21800828

Waterfall 12­3/8” No Logo, LED
(Round) Textured
(CS675953T8L-1) ‘14

PLU21800829

Waterfall 20” Clear,
LED

LIT25269-009-000

If you need jet bodies, go to www.quickspaparts.
com or refer to the Cal Spa Replacement Parts
Catalog, which can be downloaded from www.
calspas.com/replacement-parts.

Y Pillow recess
(used for C-751L)

ACC01401100

Cup Holder

Cup Holder

LIT25241-314-800

www.calspas.com

2017 Portable Spa

LTR20171001, Rev. B

Water Diverter Valves

Diverter Valve 1½” On/
Off ASSY (600-4601)

PLU21100045

Diverter Valve 2”
Black/Titanium

Please visit www.quickspaparts.com
to order your replacement parts.

Weir Skimmers

Weir Skimmer Gate
Small Black

PLU21600284

Weir Skimmer Gate
Large Black

PLU21600294

59

Appendix

PLU21300465

Diverter Valve 1”
Black/Titanium

PLU21300453

Air Control Valve

Air Control
Black/Titanium

PLU21300504

Drains

Drain Super Hi Flo Suction
2½” Black (640-3581LGV)

PLU21400146

50 sq ft

75 sq ft

Filters

FIL11100208

Filter cartridge
antibacterial

Female threaded

PWW50L-M

FIL11100209

Filter cartridge
antibacterial

Female threaded

PCAL75-M

FIL-PCAL77-P4-M

Filter cartridge
antibacterial

Female threaded

Teleweir mega
skimmer

Low Prole Drain ¾” Black

(640-0511)

PLU21400401

If you need jet bodies, go to www.quickspaparts.
com or refer to the Cal Spa Replacement Parts
Catalog, which can be downloaded from www.
calspas.com/replacement-parts.

2017 Portable Spa

LTR20171001, Rev. B

FIL-PCAL77-P25-M

Filter cartridge
antibacterial

www.calspas.com

60

Please visit www.quickspaparts.com
to order your replacement parts.

Teleweir lter

skimmer 50 sq. ft.

Appendix

(510-4601)

FIL11700006

Teleweir mega

lter skimmer 75

sq. ft. (510-5671)

FIL11700015

Teleweir Skimmers

LED Lights

LED mini DCU
controller
(P1309)

LIT16100626

2-LED light
string

LIT16100620

4-LED light
string

LIT16100621

If you need jet bodies, go to www.quickspaparts.
com or refer to the Cal Spa Replacement Parts
Catalog, which can be downloaded from www.
calspas.com/replacement-parts.

Interior light
with logic

LIT16100625

LED light
string
jumper, 46
inches, daisy
chain

ELE09902531

www.calspas.com

2017 Portable Spa

LTR20171001, Rev. B

Pure Cure™ UV Water Sanitizer

Pure Cure complete
system (Wonder
PP-1)

LIT16000380

Germicidal UV lamp
(T515)

LIT16000381

Rubber O-ring
(D24.5)

LIT16000384

Quartz thimble
(24.5X350)

LIT16000383

Ballast (UV-3)

LIT16000382

Please visit www.quickspaparts.com
to order your replacement parts.

61

Appendix

Clips

LIT16000385

Exercise Equipment

Exercise Kit for 7 Foot and 8
Foot Spas

EXC12000006

Exercise Kit for 11 Foot Spas

EXC12000005

Exercise Kit for 12 Foot and
14 Foot Spas

EXC12000008

Exercise Kit for 16 Foot and
17 Foot SpasEXC12000007

Exercise Kit Attachment
Plate

EXC11000065

Replacement Cabinet Panels

The complete selection of replacement cabinets for
all models is very extensive and too lengthy for this
owner’s manual. To order replacement panels for
your spa, visit www.quickspaparts.com.

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

62

Please visit www.quickspaparts.com
to order your replacement parts.

Covers

All spa covers are designed with a tapered height, angling downward from the center to the sides to drive off

rain and prevent water from pooling. The covers listed below are lled with either 1.5 lb or 2.0 lb foam.

Standard

Appendix

4” - 2.5”

1.5 Lb. foam

54” x 78”

Fits spa models: PZ-517L, PPZ-525L

64” x 84”

Fits spa model: PPZ-537L

72” x 72” triangle

Fits spa models: PZ-617T, PPZ-628T

78” x 84”

Fits spa models: PZ-621L, PPZ-631L

78” round

Fits spa model: P2511R

87” x 87”

Fits spa model: EP-760DL, EC-754DL

Deluxe

5” - 3”

2.0 Lb. foam

Gray

Standard

COV5478S53G-CC COV5478S53S-WN

COV6484S53G-CC COV6484S53S-WN

COV7272TRS53G-CCCOV7272TRS53R-

COV7884S53G-CC COV7884S53S-WN

COV78RDS53G-CC COV78RDS53S-WN

COV8787S53G-CC N/A

Slate

Standard

WW

93” x 130”

Fits spa model: EC-947E

84” x 84” (7 foot spas)

Fits spa models: P2-722L,
P2-722B, PP-732L+, PP­732B+, EC-735L, EC-735B,
EC751L, EC751B, EP-761L,
EP-761B,
PL-760L, PL-760B, PPL7L+

93” x 93” (8 foot spas)

Fits spa models: EC-835L,
EG835B, EC-851L, EC-851B,
EC-852L, EC-864L, EC-864B,
EP-861L, EP-864B, PL-860L,
PL-861B, PL-880L, PL-881B,
PPL-8B+

www.calspas.com

Gray

Standard

N/A

COV8484S53G-CCCOV8484D53G-CCCOV8484S53S-WNCOV8484D53S-

COV9393S53G-CCCOV9393D53G-CCCOV9393D53S-WNCOV9393D53R-

Gray

Deluxe

COV93130D53G-

CC

Slate

Standard

N/A N/A

WN

WW

2017 Portable Spa

LTR20171001, Rev. B

Slate

Deluxe

Please visit www.quickspaparts.com
to order your replacement parts.

Basic Troubleshooting

The troubleshooting guidance provided here is intended to cover the most common problems a spa owner
may encounter. For more in-depth troubleshooting, go to www.calspas.com/troubleshooting.

Symptom Possible Solutions

Problems starting up

Pump won't prime See priming instructions on page 15.

Breaker keeps shutting off Reset the GFCI breaker. If this continues, contact your dealer or a qualied

spa technician.

Power and system problems

63

Appendix

System won’t start up or
breaker keeps shutting off

Control panel doesn’t respond Turn on or reset the GFCI circuit breaker. If this does not solve the problem,

Spa does not turn off Spa may be trying to heat up. Check if spa is in Ready or Rest mode (see

Message on the control panel There may be a problem. See Diagnostic Messages on page 24 or page 30.

Power may be shut off. Turn on GFCI circuit breaker. If this continues, contact

your dealer or a qualied spa technician.

contact your dealer or a qualied spa technician.

If you hear the pump running but the control panel doesn’t respond, contact your
dealer

page 20 or page 28)

In cold climates, if spa is not equipped with full foam or any kind of insulation,
it will try to maintain the set temperature. Set the spa to low temperature
range and set the temperature to 80°F.

Spa may be in lter cycle. If it is, this is normal and no adjustment is

necessary.

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

64

Please visit www.quickspaparts.com
to order your replacement parts.

Heat problems

Appendix

Symptom Possible Solutions

Spa water does not get hot Spa may be in low temperature range. Set the spa to high temperature range.

The lter may be dirty or may need to be replaced. Clean or replace the lter.

The water level may be too low. Fill the spa with water level at 4 to 6 inches
from the top.

The temperature is not turned up high enough. Raise temperature on topside
control.

Cover the spa. The cover will keep heat in the spa and help keep heat from
escaping. Make sure cover is on at all times when spa is not in use.

The heater element may be old, deteriorated, coated with scale, or defective.
Contact your dealer for more assistance.

The gate valves may be partially or completely closed. NEVER OPERATE YOUR
SPA WITH THE GATE VALVES CLOSED!

Spa overheats - temperature
greater than 110°F / 43°C

Overheating can occur during summer months and may not necessarily
indicate a malfunction. When it occurs, a message code may also appear on
the control panel.

Temperature may be set too high. Turn the set temperature down to a lower
temperature.

Filtration time may be too long. Turn the ltration cycles down during the

warm months.

The spa may not be properly ventilated. Make sure the front of the spa is not

blocked to allow air ow.

High speed pumps may have been running too long. Limit pump running time
to no more than 15 to 30 minutes.

Water pressure problems

Low water pressure Jet valves may be partially or fully closed. Open the jet valves.

Filter cartridge may be dirty. Clean or replace the lter.

Pump may have airlock. Remove airlock by priming spa (page 15)

The suction ttings may be blocked. Remove any debris that may be blocking

them.

The lter skimmer may be blocked. Remove the blockage.

Gate valves may be closed. Open gate valves. Note: Never operate your spa
with the gate valves closed!

Spa may be running in ltration mode. Press JETS or JETS 1 button to turn on

high speed pump.

No water pressure (no water
stream from any jets)

Jets surge on and off Water level may be too low. Add water to normal level.

Power may be switched off. Turn the power back on.

The pump may be defective. After you have tried all other troubleshooting,
contact your dealer for assistance.

www.calspas.com

2017 Portable Spa

LTR20171001, Rev. B

Symptom Possible Solutions

Pump problems

Please visit www.quickspaparts.com
to order your replacement parts.

65

Appendix

Pump runs constantly – will
not shut off

Noisy pump The water level may be too low. Fill the spa with water level at 4 to 6 inches

Pump turns off during
operation

Pump has a burning smell
while running

Pump does not run Pump may have over heated. Let it cool for an hour and try operating the spa

There may be a problem with circuit board. Contact your dealer.

from the top.

Filter cartridge may be dirty. Clean or replace the lter.

Pump may have airlock. Remove airlock by priming spa (page 15)

The suction ttings may be blocked. Remove any debris that may be blocking
the suction ttings.

Gate valves may be closed. Open gate valves. Note: Never operate your spa
with the gate valves closed!

Air may be leaking into the suction line. Contact your dealer for assistance.

Debris may be inside the pump. Contact your dealer for assistance.

Noise may be a sign of damage. Contact your dealer for service.

Automatic timer may have completed its cycle. Press JETS or JETS 1 button to
start the cycle again.

Pump may have overheated due to the vents on the equipment door being

blocked. Make sure the front of the spa is not blocked to allow air ow.

The pump motor may be defective. Contact your dealer for assistance.

A burning smell may be a sign of damage. Contact your dealer for service.

for a shorter time.

Power to the spa may be shut off. Turn on or reset the GFCI circuit breaker.

If this does not solve the problem, contact your dealer or a qualied spa

technician.

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

66

This Limited Warranty is extended to the original purchaser of a Cal Spa brand portable spa manufactured after
January 1, 2017 and installed for residential use outside the United States of America and Canada. This warranty
begins on the date of delivery of the spa, but in no event later than one year from the date of manufacture.

Appendix

Shell Structural

Warranted against water loss due to defects in the spa shell.

Shell Finish

Warranted against blistering, cracking, or delaminating of the
interior surface of the spa shell.

Equipment and Controls

Electrical equipment components – specically limited to the

pumps and control system – are warranted against malfunctions
due to defects in workmanship or materials.

Plumbing

Warranted against leaks due to defects in workmanship or
materials.

Cabinet - synthetic, berglass, or wicker

Warranted against defects in workmanship or materials. Normal wear

and weathering of the nish will occur naturally over time and are not

defects.

Warranties for Other Components

The fuses, headrests, cabinet nish, and lters are warranted to be free of defects in workmanship and material
at the time of delivery. The factory installed water purication system is warranted against malfunction due

to defects in workmanship or material for one year from the original date of delivery except the UV bulb and
quartz tube, which are warranted for 90 days from the original date of the spa delivery. All stereo-related
components (receiver, speakers, sub-woofer, stereo media locker, power supply, wireless remote control etc.)
are warranted against malfunction due to defects in workmanship or material for one year from the original date

of delivery. All other factory-installed components not mentioned specically, including, but not limited to the
wood frame, jets, diverter valves, LED lighting systems, lter lids, and mechanical components, are warranted

against malfunction due to defects in workmanship and material for two years from the original date of delivery.
The spa cover delivered with the spa is warranted for one year for Escape, Platinum, and Swim spas, 90 days
for Gen II, Patio, and Connect spas.

This warranty applies only to these spa lines:

Platinum,

Patio,

Patio+

Escape,

Escape+

Platinum+,

Swim

5 years 7 years 10 years

2 years 5 years 7 years

2 years 3 years 5 years

2 years 3 years 5 years

1 year 1 year 5 years

Genuine Cal Spas Parts & Accessories

This Limited Warranty is void if Cal Spas (the “Manufacturer”) or its designated representative determines that
the spa has been subjected to damage or failure due to installation of aftermarket parts that are not genuine

Cal Spas branded parts and accessories. This disclaimer includes, but is not limited to lters, UV bulbs, ozone

systems, salt systems, repair parts and other accessories. Genuine Cal Spas brand parts and accessories are
built to our highest standards of quality, durability and performance, and they are designed to work with your
spa to ensure optimal performance and function.

Performance

This warranty begins on the date of delivery of the spa, but in no event later than one year from the date of
manufacture. To obtain service in the event of a defect covered by this Limited Warranty, notify your Cal Spa
dealer or Cal Spas as soon as possible and use all reasonable means to protect the spa from further damage.
Upon proof of purchase, a designated service representative will correct the defect subject to the terms and
conditions contained in this Limited Warranty. There will be no charge for parts or labor to repair the defect,

www.calspas.com

2017 Portable Spa

LTR20171001, Rev. B

67

although providing access to affect the repair is your responsibility as the spa owner. Freight charges for
replacement parts is the responsibility of the spa owner. You may be assessed reasonable repairman travel
mileage charges. In the event that the spa is removed to a repair facility for repair and reinstalled, the cost
of removal and reinstallation will be your responsibility as the spa owner. If the Manufacturer determines that
repair of the covered defect is not feasible, it reserves the right to provide a replacement spa instead, equal in
value to the purchase price of the original spa. In such an event, reasonable costs for removal of the original
spa, shipping costs from the factory for the replacement spa and delivery and installation of the replacement
will be your responsibility as the spa owner. The replacement spa will carry the balance of the original spa’s

warranty. Spa covers are not included. This warranty ends either by specied time frame, owner-transfer,

relocation, or installation of any component other than by manufacturer.

Warranty Limitations

This Limited Warranty is void if Cal Spas or its designated representative determines that the spa has been
subjected to alteration, neglect, misuse or abuse, or freight damage caused by the common carrier; any repairs
have been attempted by anyone other than a designated representative; or if the failure is caused by accident,
acts of God or other causes beyond the control of the Manufacturer. Neglect, misuse and abuse include any
installation, operation or maintenance of the spa other than in accordance with the instructions contained in the
owner’s manual provided with the spa, including but not limited to the failure to maintain proper water chemistry
and chemical balance and the use of abrasive or improper cleaners or non-genuine parts and accessories. This
Limited Warranty does not provide coverage for any item attached to or installed on the spa after the date of
manufacture or for gaining access to any component for repair or replacement. Spa units in commercial use are
excluded from any coverage whatsoever. The spa owner accepts liability for repair work performed by anyone
other than the Manufacturer or a designated Cal Spa representative.

Appendix

Limitations

The Manufacturer disclaims all warranties, expressed or implied, in fact or in law, to the extent allowed by your

State’s Law, including the warranty of merchantability and tness for use, except as stated specically herein.

All warranty service must be performed by the Manufacturer or its designated representative using authorized
Cal Spa parts. No agent, dealer, distributor, service company or other party is authorized to change, modify or
extend the terms of this limited warranty in any manner whatsoever. The Manufacturer will not be responsible
for any statements or representations made in any form that go beyond, are broader than, or are inconsistent

with any authorized literature or specications furnished by Cal Spas.

Disclaimers

The Manufacturer and its representatives shall not be liable for any injury, loss, cost or other damage, whether
incidental or consequential, arising out of any defect covered by this limited warranty, including without
limitation, loss of use of the spa and cost for removal of defective product even if the Manufacturer was advised
of the possibility of damage. The liability of the Manufacturer under this limited warranty, if any, shall not exceed
the original amount paid for the defective product. Coverage under this limited warranty shall commence as
of the original date of delivery and the duration of such coverage shall not extend for any reason whatsoever
beyond the stated time periods. These disclaimers shall be equally applicable to any service provided by the
Manufacturer and its designated representatives.

Legal Rights

This Limited Warranty gives you specic legal rights. You may also have other rights that vary from state to

state. Some states do not allow limitations on how long an implied warranty lasts, so this limitation may not
apply to you.

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

68

Appendix

www.calspas.com

2017 Portable Spa

LTR20171001, Rev. B

69

Appendix

2017 Portable Spa

LTR20171001, Rev. B

www.calspas.com

Locating the product serial number

The serial number of your Cal Spa is located on a metal plate attached to
the lower right front panel of the spa. You will need this number to properly
register your spa and activate coverage. Write this information in the space
provided below.

Cal Spa Model: _______________________________________________

Cal Spa Serial Number: ________________________________________

Date Purchased: ______________________________________________

Date Installed: _______________________________________________

Cal Spa Dealer’s Phone Number: _________________________________

Cal Spa Dealer’s Address: ______________________________________

CONTACT INFORMATION

For customer service, please contact your authorized
dealer immediately. If you need additional information
and/or assistance, please contact:

LMS Customer Service Department
1462 East Ninth Street
Pomona, CA 91766.

Phone: [phone]
Fax: [phone]

www.calspas.com

Please visit www.quickspaparts.com
to order your replacement parts.

LTR20171001, Rev. B

4/18/17
