BA-ORTHO_EN V2.0 Seite: 1 von 19
Operating manual
treadmill
CALLIS - ORTHO
BA-ORTHO_EN V2.0 Seite: 2 von 19
Your treadmill has the above-mentioned serial number and the following options:
Touch Terminal
Serial interface RS232 (only in conjunction with Touch Terminal)
Remote controller/ Handrail controller(only in conjunction with Touch Terminal)
Adjustable Speed 0 km/h – 20 km/h
Inclination smoothly adjustable electronically from 0% to 15%
Inclination smoothly adjustable electronically from 0% to 20%
Running surface 155cm x 60cm
Video-handrail left / right / both sides
Walk-through-handrail
individual safety holder (HzP)
Additional emergency-stop at the handrail
Increased user weight up to 250 kg (without Inclination, without HzP)
Other colour: RAL______________________________________________________________________
Custom design: _______________________________________________________________________
The treadmill specified above is classified as a Class IIa medical device according to the German Medical
Device Law and Directive 93/42 EEC.
It is intended for physical training, physical therapy, diagnostics and rehabilitation.
Hersteller: Sprintex Trainingsgeräte GmbH, Bei der Säge 23 a, 79692 Kleines Wiesental
Treadmill CALLIS – ORTHO Serial number:
• Running surface 155cm x 50cm
• s²ap Sprintex – shock absorbing profile
• Speed 0 km/h - 17 km/h
• Indication of speed, time, distance and pulse
• Adjustable to extremely low velocities
• Handrails on both sides for safe mounting
• Emergency stop control cable with magnet
• Pulse measurement with POLAR chest belt
• Colour: Black (RAL 9005)
BA-ORTHO_EN V2.0 Seite: 3 von 19
Index
1 General Instructions ........................................................................................................................................ 4
2 Treadmill description ....................................................................................................................................... 5
2.1 Classification ............................................................................................................................................ 5
3 Technical data ................................................................................................................................................ 6
4 Safety Instructions .......................................................................................................................................... 7
4.1 General Safety Instructions ...................................................................................................................... 7
4.2 Safe training ............................................................................................................................................. 8
4.3 Indications and contraindications ............................................................................................................. 9
4.4 Polar-Pulse systems ................................................................................................................................ 9
5 Placement ..................................................................................................................................................... 10
6 Commissioning ............................................................................................................................................. 11
6.1 Initial Commissioning ............................................................................................................................. 11
6.2 Power supply .......................................................................................................................................... 11
6.3 Warning notices ..................................................................................................................................... 11
6.4 Operation ............................................................................................................................................... 12
6.5 Reverse Mode ........................................................................................................................................ 13
6.7 Program 8 (One-step-program) ............................................................................................................. 16
6.8 Programming the Programs ................................................................................................................... 16
7 Maintenance ................................................................................................................................................. 18
7.1 Performing safety-controls (STK) according to MPBetriebV ................................................................. 18
7.2 Solving breakdowns ............................................................................................................................... 18
8 Care .............................................................................................................................................................. 18
9. Attachments ................................................................................................................................................. 19
BA-ORTHO_EN V2.0 Seite: 4 von 19
1 General Instructions
Congratulations on the purchase of your CALLIS slatted-belt treadmill.
We have done everything we can to ensure maximum reliability of your treadmill.
CALLIS of SPRINTEX means safe, healthy and uncomplicated running training.
Your SPRINTEX treadmill has the following characteristics:
the toothed belt drive of aluminium slats with rubber lining prevents slipping and heating up through
low power consumption
the slat technology ensures joint-friendly running by means of an optimal rubber lining and impactabsorbing free-running slats
the slip-free action of the toothed belt drive ensures an accurate, error free measurement of speed
and distance
no re-tightening or greasing of the running surface
the bearing friction is distributed evenly over 120 ball bearings resulting in extremely quiet energy-
saving operation
in an emergency, the two hand rails attached to each side ensure a safe stable and skid-free stop
the reflection-free LED indicators and lights offer easily readable values of the current speed, distance,
inclination, time and pulse.
a pulse meter in the chest belt
To allow you to enjoy your treadmill as long as possible, it is important that you carefully read the operating
instructions before the first start-up, particularly the safety advice (chapter 4.2).
BA-ORTHO_EN V2.0 Seite: 5 von 19
2 Treadmill description
The CALLIS treadmill is the basic model for all treadmill models currently produced by Sprintex
Trainingsgeräte GmbH. The model variants differ from one another only by special additions required for
individual areas of application e.g. variants with rails. The basic structure along with all safety-related and
ergonomic specifications remains unchanged.
The CALLIS treadmill is intended for physical training. It is used predominantly in clinics, rehabilitation, gyms
and by individuals. It consists of an electrically driven device that is adapted to suit local power supplies and
which can be installed and started-up without specialist knowledge.
The treadmill is not intended for a specific user group; it can be used for walking and running by both
younger and older people, the handicapped and children. In this connection, the treadmill may be provided
with different ranges of speed and inclination angle. The required adjustment for this is effected manually or
through a program via the associated terminal. The Polar chest belt allows additional monitoring of the speed
through the pulse rate. In the event of the pulse rate exceeding a level pre-set by the user/operator, then the
speed is reduced. When used by children or handicapped persons, the assistance of another person is
required to ensure the correct use of the product.
In the selection of materials, special attention has been given to durability, ease of cleaning and skin
tolerance. Likewise the choice of materials was made according to disposal criteria.
The treadmill has a further application in the measurement of distance covered. It indicates the distances
covered in kilometres to an accuracy of 1 meter.
Conclusions may be drawn by the user/operator (e.g. physical condition) from the indicated values on the
terminal (speed, time, distance and pulse rate). The treadmill is not intended to control other devices or
medicine or be used reciprocally in connection with them. It is very probable that the reciprocal effects will be
affected due to the physical training.
In normal use, the treadmill is unaffected by environmental influences in the areas of operation, transport
and storage. Routine maintenance and/or calibration are not necessary
2.1 Classification
The CALLIS Treadmills match to the DIN EN 957 standard, application class S (Studio: professional and/or
commercial use) precision class A (high precision) and are designed for the exercise, sport and therapy
segment.
Note: All CALLIS devices are medical devices matching to the 93/42 EWG policy.
According to DIN EN 20957 our devices are designed for observed environments by the devices owner.
The user’s weight must not exceed 160 kg. Only 1 person can practice on the device. Devices without
inclination and HzP (individual safety holder) with an extended maximum weight may be used by a user
weight up to 250 kg. Device label provides further information.
BA-ORTHO_EN V2.0 Seite: 6 von 19
3 Technical data
Principle: Toothed belt drive of aluminium slats with rubber lining. Non-slip, no heating
up of the belt, low permanent power consumption.
Dimensions: LxWxH 173cm x 76cm x 130cm
Entry height: 28 cm
Running surface: Slat system with optimal suspension effect
L x W 155cm x 50cm;
Weight: 160 kg; 180 kg with option inclination
Drive: Servo controller with Brushless DC motor
Voltage: 230V 50/60Hz
Current: 5 Ampere
Fuses: 2x 6.3 A slow-acting, with Inclination + 2x 10A slow acting
Humidity: < 80%
Noise: < 75 dBa
Temperature range: 0/ 45 ° C.
Storage temperature: 0 - 45° C.
Leakage current: < 0,5 mA
Degree of protection: IP X0
Speed: 0-13 km/h smoothly adjustable
Indication: Distance covered 0.000km to 9.999km,
Time 00:00 min:sec, to 99:59 min:sec,
Speed 00.0km/h, to 29.9km/h
Pulse 40 beats/min, to 220 beats/min
Pulse measuring system: Chest belt with radio transmission
Guarantee: 24 months starting from purchase date
