CalAmp INTEGRA-TR User Manual
INTEGRA-TR™
WIRELESS MODEM FOR LICENSED SPECTRUM
USER MANUAL
PN 001-4008-000 REV 16
Revised December 2010
REV
DATE
DESCRIPTION
REV 0
Feb 2000
Initial Release as 001-4008-000.
REV 1
Mar 2000
Updated manual format.
REV 2
Jul 2000
Corrected FCC/IC numbers and added FM approval information.
REV 3
Sep 2000
Updated Channel information in General Specifications - Section 1.
REV 4
Nov 2000
Updated Typical Deviation in Section 4.
REV 5
Jan 2001
Added CE information to Section 1.
REV 6
Mar 2001
Updated Duty Cycle information in General Specifications - Section 1.
REV 7
Jul 2001
Updated manual to reflect Windows-based Field Programming Software to Section 2.
Added Part Number breakdown to Section 1.
REV 8
Oct 2001
Added CSMA and CWID information to Section 2. Moved CD certificates to Appendix A.
REV 9
Nov 2001
Added Extended ID information to Section 2.
REV 10
Nov 2002
Added Splinter Channel, Digital I/O and note to LED table (1) to Section 2.
REV 11
Sep 2003
Added Packet Test and Array Test information to Section 2. Added product warranty
statements in Appendix B. Updated General Specifications.
REV 12
Apr 2004
Removed references to Sleep and Suspend Mode in Section 1, 2 & 3. Removed
International Warranty from Appendix B-replaced with revised warranty.
REV 13
Mar 2005
Added multi-channel information, replaced references to Sleep and Suspend Mode.
Updated Accessories table.
REV 14
Jul 2006
Moved Revision level to 15 to sync with all formats.
REV 15
Jul 2006
Added pdf and hard copy part numbers for customer reference. Revised references to Band
1 UHF versions, frequencies were listed as 380-403 MHz.
REV 16
Dec 2010
REVISION HISTORY
The Integra-TR radio is intended for use in the Industrial Monitoring and Control and SCADA markets.
The Integra-TR unit must be professionally installed and must ensure a minimum separation distance
listed in the table below between the radiating structure and any person. An antenna mounted on a
pole or tower is the typical installation and in rare instances, a 1/2-wave whip antenna is used.
Antenna Gain
Min Safety Distance (cm @max power)
5 dBi
10 dBi
15 dBi
VHF
79.3 cm
141.0 cm
250.8 cm
UHF
68.2 cm
121.4 cm
215.8 cm
900 MHz
45.0 cm
80.1 cm
142.5 cm
Important Notice
Because of the nature of wireless communication, transmission and reception of data can never be guaranteed. Data may
be delayed, corrupted (i.e., have errors), or be totally lost. Significant delays or losses of data are rare when wireless devices
such as the Integra-TR are used in a normal manner with a well-constructed network. Integra-TR should not be used in
situations where failure to transmit or receive data could result in damage of any kind to the user or any other party,
including but not limited to personal injury, death, or loss of property. CalAmp accepts no responsibility for damages of any
kind resulting from delays or errors in data transmitted or received using Integra-TR, or for the failure of Integra-TR to
transmit or receive such data.
Copyright Notice
© 2010 CalAmp. All rights reserved.
Products offered may contain software proprietary to CalAmp. The offer of supply of these products and services does not
include or infer any transfer of ownership. No part of the documentation or information supplied may be divulged to any
third party without the express written consent of CalAmp. CalAmp reserves the right to update its products, software, or
documentation without obligation to notify any individual or entity. Product updates may result in differences between the
information provided in this manual and the product shipped.
RF Exposure Compliance Requirements
It is the responsibility of the user to guarantee compliance with the FCC MPE regulations when operating this device in a way
other than described above.
Integra-TR uses a low power radio frequency transmitter. The concentrated energy from an antenna may pose a health
hazard. People should not be in front of the antenna when the transmitter is operating.
The installer of this equipment must ensure the antenna is located or pointed such that it does not emit an RF field in
excess of Health Canada limits for the general population. Recommended safety guidelines for the human exposure to radio
frequency electromagnetic energy are contained in the Canadian Safety Code 6 (available from Health Canada) and the
Federal Communications Commission (FCC) Bulletin 65.
Any changes or modifications not expressly approved by the party responsible for compliance (in the country where used)
could void the user's authority to operate the equipment.
1 TABLE OF CONTENTS
1.1 Figures ........................................................................................................................................................................ 6
1.2 Tables ................................................................................................................................ ................................ .......... 7
2 PRODUCT OVERVIEW .................................................................................................................................................... 8
2.1 Scope of Manual ......................................................................................................................................................... 8
2.2 General Description ................................................................................................................................................... 8
2.2.1 Characteristics ...................................................................................................................................................... 8
2.3 Part Number Breakdown .......................................................................................................................................... 9
2.3.1 Transceiver Identification .................................................................................................................................... 9
2.3.2 Accessories and Options ...................................................................................................................................... 9
2.3.3 Factory Mutual NI Kit ....................................................................................................................................... 10
2.3.4 Configuration ..................................................................................................................................................... 12
2.4 Factory Repair ......................................................................................................................................................... 12
2.5 Physical Description................................................................................................................................................. 12
2.6 Diagnostics ................................................................................................................................................................ 12
2.7 Firmware Updates ................................................................................................................................................... 13
2.8 Network Application ................................................................................................................................................ 13
2.8.1 RF Path and Communications Range ................................................................................................................ 13
2.8.2 Basic Connections .............................................................................................................................................. 13
2.8.3 Common Characteristics .................................................................................................................................... 14
2.8.4 Point-to-Point System ........................................................................................................................................ 14
2.8.5 Point-to-Multipoint System................................................................................................................................ 14
2.8.6 Extending a Landline (Tail Circuit) ................................................................................................................... 15
2.9 Specifications ............................................................................................................................................................ 17
3 FEATURES AND OPERATION ..................................................................................................................................... 20
3.1 Overview ................................................................................................................................................................... 20
3.2 Front Panel ............................................................................................................................................................... 20
3.2.1 Antenna Connector ............................................................................................................................................ 20
3.2.2 Connection to DTE ............................................................................................................................................ 20
3.2.3 LED Indicators ................................................................................................................................................... 20
3.2.4 COM Port ........................................................................................................................................................... 21
3.2.5 Setup Port ........................................................................................................................................................... 22
3.3 Rear Panel ................................................................................................................................................................ 23
3.3.1 Heat Sink............................................................................................................................................................ 23
3.3.2 Power ................................................................................................................................................................. 23
3.3.3 Power – I/O Connector ...................................................................................................................................... 23
3.4 Integra-TR Field Programming Software ............................................................................................................. 24
3.4.1 Introduction ........................................................................................................................................................ 24
3.4.2 Setup Modem/Radio Parameters ........................................................................................................................ 25
3.4.3 Version Request ................................................................................................................................................. 38
3.4.4 List Information ................................................................................................................................................. 39
3.4.5 Apply Integra Reset ........................................................................................................................................... 39
3.4.6 Program Comment/ID ........................................................................................................................................ 39
3.4.7 Program Parameters ................................................................ ................................ ................................ ........... 40
3.4.8 Read Parameters................................................................................................................................................. 41
3.4.9 Copy Parameters ................................................................................................................................................ 41
3.4.10 COM Port Settings ............................................................................................................................................. 41
3.4.11 Swap COM Ports ............................................................................................................................................... 44
3.4.12 Port Statistics ..................................................................................................................................................... 45
3.4.13 Offline Link Test................................................................................................................................................ 46
3.4.14 Offline Diagnostics ............................................................................................................................................ 48
3.4.15 Online Diagnostics ............................................................................................................................................. 50
3.4.16 Diagnostic IDs and Alarms ................................................................................................................................ 52
3.4.17 User Test ............................................................................................................................................................ 54
3.4.18 Packet Test ......................................................................................................................................................... 56
3.4.19 Array Test .......................................................................................................................................................... 58
3.4.20 Ping Test ............................................................................................................................................................ 60
3.4.21 ASCII / Hex Terminal ........................................................................................................................................ 63
3.4.22 Program Code Menu .......................................................................................................................................... 64
3.5 Integra-TR Help Files .............................................................................................................................................. 65
3.6 Optimizing Your System ......................................................................................................................................... 65
4 CONFIGURABLE PARAMETERS ................................................................................................................................ 67
4.1 Parameter Overview ................................................................................................................................................ 67
5 DEFINITIONS ................................................................................................................................................................. 69
1.1 FIGURES
Figure 1- FM Approved External Connections ......................................................................................................................... 10
Figure 2- Installation Dimensions ............................................................................................................................................. 11
Figure 3 - Basic Required Connections .................................................................................................................................... 13
Figure 4 - Point-to-Point System .............................................................................................................................................. 14
Figure 5 - Point-to-Multipoint System (simplex or half-duplex) .............................................................................................. 14
Figure 6 - Point-to-Multipoint System (full-duplex)................................................................................................................. 15
Figure 7 - Point-to-Multipoint System (full-duplex repeater) ................................................................................................... 15
Figure 8 - Landline (Tail Circuit) ............................................................................................................................................. 15
Figure 9 - DCE Crossover Cable for RTS-CTS Mode .............................................................................................................. 16
Figure 10 - DCE Crossover Cable for DOX Mode ................................................................................................................... 16
Figure 11 - COM and Setup Port Connectors Pin Locations .................................................................................................... 22
Figure 12 - 3-wire Interface ...................................................................................................................................................... 22
Figure 13 - Integra-TR Rear Panel ............................................................................................................................................ 23
Figure 14 - I/O Connector ......................................................................................................................................................... 23
Figure 15 - Integra-TR Field Programming Software Startup Screen ...................................................................................... 24
Figure 16 - Setup Modem/Radio Parameters Screen ................................................................................................................ 25
Figure 17 - Suspend Mode Timing ........................................................................................................................................... 29
Figure 18 - COM/Analog Setup Parameters Screen ................................................................................................................. 29
Figure 19 - Integra-TR Control Signal Timing ......................................................................................................................... 30
Figure 20 - Digital I/O Circuit Diagram ................................................................................................................................... 32
Figure 21 - Integra Power I/O Cable ......................................................................................................................................... 32
Figure 22 - Integra Field Programming Software Digital I/O Screens ..................................................................................... 34
Figure 23 - Radio Setup Parameters Screen .............................................................................................................................. 35
Figure 24 - Frequencies Tab ..................................................................................................................................................... 37
Figure 25 - Version Request Screen ......................................................................................................................................... 39
Figure 26 - List Request Screen ................................................................................................................................................ 39
Figure 27 - Reset Screen ........................................................................................................................................................... 39
Figure 28 - Program Comment/ID Screen ................................................................................................................................ 40
Figure 29 - Program Parameters ............................................................................................................................................... 40
Figure 30 - Port Settings Screen ............................................................................................................................................... 41
Figure 31 - Port Statistics Screen .............................................................................................................................................. 45
Figure 32 - Offline Link Test Screen ........................................................................................................................................ 46
Figure 33 - Offline Diagnostics Screen ..................................................................................................................................... 48
Figure 34 - Online Diagnostics ................................................................................................................................................. 51
Figure 35 - Diagnostic IDs and Alarms Screen......................................................................................................................... 52
Figure 36 - User Test Screen .................................................................................................................................................... 54
Figure 37 - Packet Test Screen ................................................................................................................................................. 56
Figure 38 - Array Test Screen ................................................................................................................................................... 58
Figure 39 - Ping Test Screen ..................................................................................................................................................... 60
Figure 40 - ASCII Terminal Screen .......................................................................................................................................... 63
Figure 41 - Select Firmware File Window (for reference only) ................................................................................................ 64
Figure 42 - Integra-TR Online Help Introductory Screen ......................................................................................................... 65
1.2 TABLES
Table 1- Integra-TR Part Number Breakdown ............................................................................................................................ 9
Table 2 - Accessories .................................................................................................................................................................. 9
Table 3 - LEDs Color Functions*** ......................................................................................................................................... 21
Table 4 - COM Port Signals ...................................................................................................................................................... 21
Table 5 - Setup Port Signals ...................................................................................................................................................... 22
Table 6 - Diagnostics Information ............................................................................................................................................ 27
Table 7 - 4 Channel Select Mode .............................................................................................................................................. 35
Table 8 - Communications Mode .............................................................................................................................................. 43
Table 9 - Y-Cable Connections ................................................................ ................................ ................................................. 57
Table 10 - SWR / Rev Pwr Interpretation ................................................................................................................................. 66
Table 11 - Normal Factory Settings (Units) .............................................................................................................................. 67
Table 12 - Normal Factory Settings (Bases) ............................................................................................................................. 68
2 PRODUCT OVERVIEW
2.1 SCOPE OF MANUAL
This document provides the information required for the operation and preventive maintenance of the Integra-TR
integrated wireless modem. This manual is intended for system designers, installers and maintenance technicians.
2.2 GENERAL DESCRIPTION
Integra-TR is a high-speed transparent integrated wireless modem. It is FCC refarming compliant and designed specifically
to fit the needs of SCADA, telemetry and control applications. Integra-TR provides the communication links to data
equipment for installations where wired communication is impractical.
Integra-TR works with most makes and models of remote terminal units (RTU) and programmable logic controllers (PLC)
and their protocols. Configuration settings allow tailoring for a variety of applications. Integra-TR supports:
1. Point to point Master-Remote or Peer-to-Peer configurations in simplex or half-duplex modes.
2. Point to multipoint Master-Remote configuration in simplex or half-duplex modes and offers full-duplex in dual-
unit configuration. These configurations are available as I-Base products. Contact your CalAmp Representative for
details.
2.2.1 CHARACTERISTICS
Integra-TR has the following characteristics:
Selectable network speeds of 2400 and 4800 b/s for quarter channel units, 4800 and 9600 b/s for half channel
units as well as 4800, 9600 and 19200 b/s for full channel units
Backward compatible with the Integra-T for bit rate of 4800 and 9600 b/s (full channel units only)
One COM port for connection to DTE. Speed of 1200 - 19200 baud
One Setup port for configuration and diagnostics (speed fixed to 9600 baud, 8 bit, no parity, 1 stop bit)
Built-in 5-watt transceiver (adjustable 1-5 watts), operating in the VHF, UHF or 900 MHz communications bands.
Half-duplex or simplex operation
Fully transparent operation with error-free data delivery
Allows transmission of “break” characters
DOX (Data Operated Transmit) or RTS mode
Stations may be set as “master” or “remote” to prevent remote stations from hearing each other in a simplex RF
configuration
Full local and remote diagnostics
Two configurable I/O lines programmable as either 8-bit analog inputs or digital outputs
“12 VDC, negative ground” device
CWID provides the ability to program the unit to periodically identify itself on the air by sending the FCC Station ID
in Morse code
Disable Tx w/Carrier Present configures the unit to prevent transmission when the radio channel is busy
Low power consumption modes: “sleep” and “suspend” modes (< 20 mA)
Multi-channel capability under system PLC control provides advanced network monitoring
Integra-TR User Manual Page | 8
242-40W8-XYZ*
W X Y
Z (UHF Units)
1 VHF
0 406.1-422 MHz
0 6.25 kHz
0 406.1-422 MHz,
or Dual Band
4 UHF
1 380-400 MHz
1 12.5 kHz
1 414-430 MHz
9 900 MHz
2 403-419 MHz
3 25 kHz
3 419-435 MHz (UHF), 406.1-440 MHz (UHF Dual Band)
5 Dual Band
12.5 & 25 kHz
4 132-150 MHz (VHF), 435-451 MHz (UHF)
5 450-470 MHz (UHF), 440-476 MHz (UHF Dual Band),
928-960 MHz (900 MHz)
6 150-174 MHz (VHF), 464-480 MHz (UHF)
7 480-496 MHz
8 496-512 MHz
Accessory
DRL Part Number
Integra-TR Field Programming Kit includes software, technical manual on CD ROM with
programming cable (DRL part number 697-4008-408)
250-4008-001
SMA to Type N-Male Adapter Cable
697-5000-101
Integra-TR Start-Up Disc includes Field Programming Software, Manual and Quick Start
Guide
002-4008-100
*Cooling fan - factory option (For extended duty-cycle transmit applications)
Catalog number plus “F” suffix.
Power cable
697-4008-001
Factory Mutual NI Kit
023-1000-200
Switching Power Converter (SPC)
250-0300-133
Demo Power Kit
250-0300-175
Data Interface Kit
250-0045-103
Data Diagnostic Kit
250-0005-105
2.3 PART NUMBER BREAKDOW N
The following table provides a breakdown of the Integra-TR part number.
Table 1- Integra-TR Part Number Breakdown
*An F should follow any part number to designate an Integra-TR with the cooling fan option.
2.3.1 TRANSCEIVER IDENTIFI CATION
The transceiver identification is a random, unique serial number (SN) printed on the box label and model label
on the side of the Integra-TR unit.
2.3.2 ACCESSORIES AND OPTI ONS
Table 2 - Accessories
Integra-TR User Manual Page | 9
Integra-TR DIN-rail Mounting Kit
250-5800-408
*Full-duplex base station
Contact Technical Service
VHF Antenna Kit
Contact Sales Representative
*For extended-transmit applications, the “TX Time out” timer must be turned off (set to “disable”) via the Field Programming Software.
For information on accessories and options, contact your sales representative. In the United States phone 1-800-9927774
or 1-507-833-8819, for International inquiries phone 507-833-8819.
2.3.3 FACTORY MUTUAL NI KI T
The Integra-TR with the Factory Mutual NI Kit (DRL part number 023-1000-200) is approved as non-incendive for Class I,
Groups ABCD, Division 2, hazardous locations by Factory Mutual Research Corporation. This option includes approval for
International Electrotechnical Commission (IEC) Class I, Zone 2.
Approved models are labeled with this rating. Only units with the Factory Mutual approved label carry the nonincendive
rating. Installation, service, and repair of the FM approved units must be in accordance with the instructions found in this
manual and the National Electrical Code (ANSI-NFPA 70) Division 2: Hazardous (classified) Location Incendive Wiring
Techniques. Mount the unit in an enclosure or assembly. Route all interconnecting cables (DC power and coaxial) through
conduit as specified in the National Electrical Code document referenced above. For further guidance on installation, see
ANSI\ISA-RPI2.6: Installation of Intrinsically Safe Systems for Hazardous (Classified) locations.
Figure 1- FM Approved External Connections
Integra-TR User Manual Page | 10
Figure 2- Installation Dimensions
Integra-TR User Manual Page | 11
2.3.4 CONFIGURATION
Operating characteristics of the Integra-TR are configured by means of Integra-TR's Field Programming Software. The Field
Programming Software is Windows based and requires a Windows® 98 or later operating system running the Integra-TR
Field Programming Software for both configuration and adjustment.
2.4 FACTORY REPAIR
CalAmp guarantees that every Integra-TR module will be free from physical defects in material and workmanship for two (2)
years from the date of purchase when used within the limits set forth in the Specifications section of this manual. The
manufacturer's warranty statement for this product is available in Appendix 1. If the product proves defective during this
warranty period, call CalAmp Customer Service to obtain a Return Material Authorization (RMA). BE SURE TO HAVE THE
EQUIPMENT MODEL AND SERIAL NUMBER, AND BILLING AND SHIPPING ADDRESSES ON HAND WHEN CALLING. You may
also request an RMA online at www.calamp.com.
When returning a product, mark the RMA clearly on the outside of the package. Include a complete description of the
problem and the name and telephone number of a contact person. RETURN REQUESTS WILL NOT BE PROCESSED WITHOUT
THIS INFORMATION.
For units in warranty, customers are responsible for shipping charges to CalAmp. For units returned out of warranty,
customers are responsible for all shipping charges. Return shipping instructions are the responsibility of the customer.
CalAmp reserves the right to update its products, software, or documentation without obligation to notify any individual or
entity. Please direct all inquiries to:
CalAmp, 299 Johnson Ave., Ste 110, Waseca, MN 56093 Telephone 507.833.8819 or Toll Free 800.992.7774
2.5 PHYSICAL DESCRIPTIO N
Integra-TR consists of a logic PCB (which includes modem circuitry) and a radio module. Each logic PCB and radio module
are matched together and characterized in the factory to optimize performance as an intelligent unit. The two boards then
slide into the rails of an extruded aluminum case.
DTE connection is made via a front panel connector. Power is applied through a rear panel 4-pin connector which includes
two programmable analog connections usable as inputs or outputs.
The unit is not hermetically sealed and should be mounted in a suitable enclosure when dust and/or a corrosive
atmosphere are anticipated. Physically, there are no external switches or adjustments. All operating parameters are set
using the Field Programming Software.
2.6 DIAGNOSTICS
Integra-TR has sophisticated built-in diagnostics that may be transmitted automatically without interfering with normal
network operation. In addition, commands to generate test transmissions, etc., may be issued either locally or remotely.
Diagnostic information takes one of two forms:
Online Diagnostics - Information is automatically sent by each unit at the beginning of every data transmission.
Integra-TR User Manual Page | 12
Offline Diagnostics - Information is sent by a specific unit in response to an inquiry made locally or from another station.
2.7 FIRMWARE UPDATES
The Integra-TR firmware resides in flash EPROM and is designed to allow field updates.
Updates are done using a PC connected to the Integra-TR but do not require opening the unit. Updates will be coordinated
by DRL’s Technical Service.
2.8 NETWORK APPLICATION
Integra-TR is suited to a variety of network applications. Its primary design goal was to satisfy the needs of SCADA systems
using RTUs or PLCs in either point-to-point or point-to-multipoint service.
This section gives an overview of some common configurations. Selection of “master” or “remote” as well as data delivery
conditions is done using the Integra-TR Field Programming Software.
2.8.1 RF PATH AND COMMUNICATIONS RANGE
Integra-TR is designed for use over distances up to 30 miles + (50 km) depending on terrain and antenna system. To assure
reliable communications, the RF (radio frequency) path between stations should be studied by a competent professional
who can determine what antennas are required and whether or not a repeater is needed. Your CalAmp Sales
Representative can assist you.
2.8.2 BASIC CONNECTIONS
The connections required are shown in Figure 3.
While an RTU or PLC is shown in the diagram, master stations often use a PC running an application designed to
communicate with remote RTUs or PLCs. The Setup PC is used for both configuration and local and remote diagnostics. It
may be left connected at all times but is not required for normal operation once the unit has been configured.
Figure 3 - Basic Required Connections
Integra-TR User Manual Page | 13
2.8.3 COMMON CHARACTERISTICS
The networks described in this section share common characteristics:
1. The DTE (data terminal equipment) network speed (1200, 2400, 4800, 9600 and 19,200 b/s) must be the same for all
stations in a network.
2. Transmission of online diagnostics may be enabled or disabled at any station or stations without affecting their ability
to communicate with other stations.
2.8.4 POINT-TO-POINT SYSTEM
Simple point-to-point connection is shown in Figure 4.
Figure 4 - Point-to-Point System
In this system, the user's equipment (DTE) may be set up in either a peer-to-peer or a Master-Remote configuration.
2.8.5 POINT-TO-MULTIPOINT SYSTEM
Basic point-to-multipoint systems are shown in Figure 5.
Figure 5 - Point-to-Multipoint System (simplex or half-duplex)
If a half-duplex radio network is used (i.e. two frequencies with the master station transmitting and receiving on the reverse
pair from the remotes), the master station can be either full duplex or half-duplex.
If a simplex radio network is used (i.e. a single frequency for all stations), we recommend that the master Integra-TR be set
to “master”, the remotes to “remote” and all units to “selective” data delivery. This will prevent remote stations from
hearing each other's responses. For full duplex configuration, set the receiving unit Rx/Tx Mode to Rx Only (using the Field
Programming Software). Set the transmitting unit mode to Tx Only.
Integra-TR User Manual Page | 14
Figure 6 - Point-to-Multipoint System (full-duplex)
Figure 7 - Point-to-Multipoint System (full-duplex repeater)
2.8.6 EXTENDING A LANDLINE (TAIL CIRCUIT)
Integra-TR may be used to extend a landline circuit (giving access to difficult locations, etc.). This type of connection is
called a “tail circuit” and is shown in Figure 8. The tail circuit assembly may be used in any of the network types described in
the preceding sections.
Figure 8 - Landline (Tail Circuit)
Note: The line modems should be full-duplex units.
Integra-TR User Manual Page | 15
Figure 9 - DCE Crossover Cable for RTS-CTS Mode
Some point-to-point FDX landline modems or line drivers may require the use of DOX mode and an alternate pinout for
DTR, DCD, CTS and RTS as shown in Figure 10.
Figure 10 - DCE Crossover Cable for DOX Mode
Integra-TR User Manual Page | 16
General
VHF
UHF
900 MHz
Frequency
132-174 MHz
380-400 MHz*, 403-512 MHz,
406.1-476 MHz Dual Band
928-960 MHz
Channels
Multi-channel capability under system PLC control
Channel Bandwidth
6.25, 12.5 or 25 kHz models
Operating Temperature
-30° to + 60° C
Supply Voltage
10 - 16 VDC maximum (nominal 13.3) Fuse protected against reverse voltage
(internal surface mount 3A fuse: not field replaceable)
RX Current Drain at 13.3 VDC
<220 mA (with a terminal connected to Integra-TR COM port)
TX Current Drain at 13.3 VDC
<2.6 A
Power Saving Mode Current Drain
<20 mA
Cold Start1
4 sec (typical)
Warm Start Rx2
45 to 60 ms (depending on radio model and temperature)
Warm Start Tx3
55 to 70 ms (depending on radio model and temperature)
Tx Turn On Time4
15 ms (typical)
RX/TX Bandwidth (without tuning)
18 MHz (132-150)
24 MHz (150-174)
16 MHz except
20 MHz (380-400, 450-470)
34 MHz (406.1-440 Dual)
36 MHz (440-476 Dual)
32 MHz
Receiver
VHF
UHF
900 MHz
Sensitivity
0.35 µV for 12 dB SINAD
Selectivity (25 kHz)
>70 dB minimum
>65 dB Minimum UHF Dual Band
> 65 dB minimum
Selectivity (12.5 kHz)
>60 dB minimum
>55 dB Minimum UHF Dual Band
>60 dB minimum
Intermodulation
>70 dB minimum
> 70 dB minimum
Spurious Rejection
>70 dB minimum
>70 dB minimum
FM Hum and Noise
<-45 dB max (25 kHz)
<-40 dB max (25 kHz)
Conducted Spurious
< -57 dBm
2.9 SPECIFICATIONS
These specifications are subject to change without notice. RF specifications are measured per TIA/EIA-603 with a
psophometric baseband filter.
*380 to 400 MHz frequency band is not FCC or IC type approved
+
Includes 102 cm power cable
Integra-TR User Manual Page | 17
Transmitter
VHF
UHF
900 MHz
RF Power Output
1 to 5 Watts, software adjustable
Spurious and Harmonics
<-57 dBc (-20 dBm)
Frequency Tolerance
1.5 PPM
FM Hum and Noise
<-45 dB (25 kHz)
<-40 dB (25 kHz)
Tx Duty Cycle
50%, max. Tx time 30 seconds, extended Tx time with the cooling fan option
Modem / Logic
Operation
Simplex / half duplex
Data Bit Rates
25 kHz channel: 4800 b/s, 9600 b/s, 19200 b/s
12.5 kHz channel: 4800 b/s, 9600 b/s
6.25 kHz channel: 2400 b/s, 4800 b/s
Modulation Type
DRCMSK (Differential Raise-Cosine Minimum Shift Keying)
RTS/CTS Delay (RTS mode)
4 ms
Addressing
10 bit station address, 1 bit station type (master / remote)
Bit Error Rate (BER)
12.5 kHz @ 9.6 kbps: -104 dBm, 1x10-6 @ 1.4 µV
25 kHz @ 4.8 or 9.6 kbps: -107 dBm, 1x10-6 @ 1.0 µV
25 kHz @ 19.2 kbps: -100 dBm, 1x10-6 @ 2.3 µV
COM Port
Interface
EIA RS-232C
Data Rate
1200 - 19200 b/s
Protocol
Transparent, 7 or 8 data bits, 1 or 2 stop bits, even, odd or no parity
Transmit Control
RTS or DOX (data operated transmit)
Setup / Diag Port
Data Format
Proprietary binary for setup, ASCII for diagnostics
Data Rate
9600 b/s, 8 bit, no parity, 1 stop bit
Analog Inputs
Interface
Two inputs, 0-10 VDC, 8 bits. May be read only via Offline Diagnostics. Absolute
maximum input voltage < 20 Vdc. Inputs are reverse-voltage protected.
Digital Outputs
1
Cold Start: Time from DC power applied until unit is fully ready to receive or transmit data
2
Warm Start Rx: In power saving modes (sleep or suspend), wake-up time for full receiver recovery
3
Warm Start Tx: In power saving modes (sleep or suspend), wake-up time for full transceiver operation
4
Tx Turn On Time: Typical Rx to Tx switching time for stable transmission
Integra-TR User Manual Page | 18
Interface
Two outputs, requires external pull-up to 2 to 10 Vdc. Set via Offline Diagnostics
Display
4 Bi-color status LEDs
RUN/PWR/ CS/SYN, RX/TX, RD/TD
Connectors
RF
SMA Female
COM
DE-9F
SETUP/DIAG
DE-9F
Power - I/O
Snap & Lock 4-Pin DC Power Jack
Diagnostics
Online
Short ID, temperature, B+ voltage, local RSSI, remote RSSI, fwd and rev power, Rx
Quality
Offline
As for Online plus: Demodulated Signal Voltage, Analog Input Levels, Digital
Outputs
Certifications
FCC (6.25 kHz)
FCC (12.5 & 25 kHz)
IC (DOC)
VHF
NP4MCUA5Q
6K00F1D
EOTMCUA5R
9K30F1D, 15K3F1D
773195562A
9K30F1D, 15K3F1D
UHF
NP4MCUB5Q
6K00F1D
EOTMCUB5R
9K30F1D, 15K3F1D
773195561A
9K30F1D, 15K3F1D
UHF Dual Band
NP44048350
9K30F1D, 15K3F1D
773B-4048350
9K30F1D, 15K3F1D
900 MHz
NA
EOTMCUC5R
9K30F1D, 15K3F1D
7731955611A
9K30F1D, 15K3F1D
Integra-TR User Manual Page | 19
3 FEATURES AND OPERATION
3.1 OVERVIEW
This chapter describes the connections, indicators, and operating characteristics of the Integra-TR. This chapter is intended
for system application and installation personnel.
3.2 FRONT PANEL
The various front panel elements are described in the following sections.
3.2.1 ANTENNA CONNECTOR
Antenna connector is a female 50-ohm SMA- type. Units operated with a “rubber duck” antenna connected directly to the
antenna connector may exhibit unusual operating characteristics and high levels of reverse power.
3.2.2 CONNECTION TO DTE
Integra-TR is configured as DCE. Most DTE devices should be connected using a nine-conductor pin-to-pin “straight” cable
(CalAmp part number 697-4008-408). Some RTUs or PLCs may require a special cable to route the signals correctly. See the
documentation for your data equipment for further information. Contact CalAmp for DTE interface information or review
CalAmp’s Technical Services Application Notes available on our website at www.calamp.com.
3.2.3 LED INDICATORS
Integra-TR has four two-color LED indicators. Their functions are shown in Table 3.
Integra-TR User Manual Page | 20
RUN/PWR
Green
Normal operation
Flash Yellow and Green
Setup mode or loading new application or
new bootloader
Flash Red
Firmware error*
Red
CPU or PROM failure*
CS/SYN
Off
No RF RX carrier
Green
Receive carrier present
Red
(Reserved)
RX/TX
Off
No RF RX carrier
Green
Receiving network data
Yellow
Synthesizer unlocked
Red
Transmitter is on
RD/TD
Off
Idle Green
RX data outgoing from RS-232 port
Red
TX data incoming at RS-232 port**
Pin
Name
Function
1
DCD
Output: Always asserted or asserted when receive RF carrier present (selectable via Field
Programming Software)
2
RXD
Output: Data from Integra-TR to DTE
3
TXD
Input: Data from DTE to Integra-TR
4
DTR
Input: Ignored
5
GND
Signal and chassis ground
6
DSR
Output: always positive
7
RTS
Input: Used as a “begin transmission” signal in RTS mode
8
CTS
Output: Used for handshaking in RTS mode and used for flow control in DOX mode RTS mode: RTS
Table 3 - LEDs Color Functions***
* Contact Technical Support
**or buffered in CSMA mode
***LED indicators may be different during startup
3.2.4 COM PORT
DTE baud rates from 1200 to 19200 are supported. Integra-TR's are factory set (default) for 2400 b/s (6.25 kHz) or 9600 b/s
(12.5 & 25 kHz), 8 bits, no parity, and 1 stop bit. Unless required by your operating protocol, we advise restricting port
speed to be equal to or less than the RF network speed.
Table 4 - COM Port Signals
Integra-TR User Manual Page | 21
to CTS delay in 4 ms DOX mode: CTS always asserted except when data overflow is detected
9
RI
Not internally connected, reserved
Pin
Name
Function
1
DCD
Tied directly to DTR
2
RXD
Data from Integra-TR to setup PC
3
TXD
Data from setup PC to Integra-TR
4
DTR
Tied directly to DCD
5
GND
Signal and chassis ground
6
DSR
Output: always positive (asserted)
7
RTS
Tied to CTS
8
CTS
Tied to RTS
9
RI
Not internally connected, reserved
5 4 3 2 1
9 8 7 6
3.2.4.1 CONNECTOR PIN OUT
The DE-9F pin out is shown in Figure 11 for reference.
Figure 11 - COM and Setup Port Connectors Pin Locations
3.2.4.2 WIRE CONNECTION (DOX)
For DTE that lack RTS control, Integra-TR can operate in DOX mode (Data Operated Transmit) with only Transmit Data,
Receive Data and Ground (“3-wire interface”).
Figure 12 - 3-wire Interface
3.2.5 SETUP PORT
The Setup port uses a DE-9 female connector configured as DCE. Signals are described in Table 5.
Table 5 - Setup Port Signals
Integra-TR User Manual Page | 22
