NewLife® Family
User Manual (English)
2 - ENG PN MN239 B | User Manual
NewLife Family
User Controls & System Status Indicators
ISO 7000; Graphical symbols for use on
equipment—Index and synopsis
Read user’s manual before operation.
Reg. # 1641
Operating temperature limitation of
these units is 41°F to 104°F (5°C to
40°C). Storage temperature limitation
range is -13°F to +158°F (-25°C to
+70°C). Reg. # 0632
Humidity range is 10 to 95%. Reg.
# 2620
Atmospheric pressure limitation. Reg.
# 2621
Keep away from rain, keep dry. Reg.
# 0626
Name and address of manufacturer.
Reg. # 3082
Caution, consult accompanying documents. Reg. # 0434A
Catalog Number. Reg. # 2493
Serial Number. Reg. # 2498
This way up. Reg. # 0623
Fragile, handle with care. Reg. #
0621
Stacking limit by number. Reg. #
2403
ISO 7010: Graphical symbols—Safety colors
and safety signs—Registered safety signs
The instruction manual must be read.
Reg. # M002
Keep away from open ame, re,
sparks. Open ignition source and
smoking prohibited. Reg. # P003
Do not smoke near unit or while
operating unit. Reg. # P002
Type BF applied part (degree of
protection against electric shock).
Reg. # 5333
Warning. Reg. # W001
Council Directive 93/42/EEC; concerning
medical devices
Authorized representative in the
European Community
This device complies with the
requirements of Directive 93/42/EEC
concerning medical devices. It bears
the CE marking as shown.
Internal Symbols
Keep away from ammable materials,
oil and grease.
Safety agency for CAN/CSA
C22.2 No. 60601-1-14 for medical
electrical equipment. Certied for
both the U.S. and Canadian markets,
to the applicable U.S. and Canadian
standards.
Do not disassemble.
When present on the device alarm
panel indicates external power interruption has been detected.
When present on the device alarm
panel indicates low oxygen concentration in device output.
ON (power switch on)
OFF (power switch off)
Date of Manufacture
Class II equipment
21 CFR 801.15: Code of Federal Regulations
Title 21
Federal law restricts this device to
sale by or on the order of a physician.
IEC 60601-1: Medical electrical equipment Part
1 General requirements for basic safety and
essential performance
Drip Proof Equipment - IP21
Council Directive 2012/19/EU: waste electrical
and electronic equipment (WEEE)
PN MN239 B | User Manual ENG - 3
NewLife Family
NewLife® Oxygen
Concentrator
This User Manual will acquaint you with the
NewLife Oxygen Concentrator (5-liter and 10-liter
models). Make sure you read and understand all the
information contained in this manual before you
operate your unit. Should you have any questions,
your Equipment Provider will be happy to answer
them for you.
What is the Oxygen
Concentrator
The air we breathe contains approximately 21%
oxygen, 78% nitrogen, and 1% other gasses. In the
NewLife oxygen concentrator, room air is drawn
into the machine through the air intakes. It then
passes through an adsorbent material called molecular sieve. This material separates the oxygen from
the nitrogen and allows only the oxygen to pass
through. The result is a ow of high-concentration
oxygen delivered to the user.
Note: There is never a danger of depleting the
oxygen in a room when you use your Oxygen
Concentrator unit.
Why Your Physician
Prescribed Oxygen
Many people suffer from a variety of heart, lung,
and other respiratory diseases. A signicant number
of these people can benet from supplemental
oxygen therapy at home, when traveling, or while
participating in daily activities away from home.
Oxygen is a gas that makes up 21% of the room air
we breathe. Our bodies depend on a steady supply
to function properly. Your physician prescribed a
ow or setting to address your particular respiratory
condition.
Although oxygen is a non-addictive drug, unauthorized oxygen therapy can be dangerous. You must
seek medical advice before you use this oxygen
concentrator. The Equipment Provider who supplies
your oxygen equipment will demonstrate how to set
the prescribed ow rate.
WEEE
This symbol is to remind the equipment owners to return it to a recycling
facility at the end of its life, per Waste
Electrical and Electronic Equipment
(WEEE) Directive.
Our products will comply with the
restriction of Hazardous Substances
(RoHS) directive. They will not contain more than trace amounts of lead
or other hazardous material content.
This product may be covered by one or more patents, US and international. Please visit our website
below for the listing of applicable patents.
Pat.: patents.cairemedical.com.
4 - ENG PN MN239 B | User Manual
NewLife Family
WARNING: “NO SMOKING – OXYGEN
IN USE” SIGNS MUST BE PROMINENTLY DISPLAYED IN THE HOME,
OR WHERE OXYGEN IS IN USE. USERS
AND THEIR CAREGIVERS MUST BE
INFORMED ABOUT THE DANGERS OF
SMOKING IN THE PRESENCE OF, OR
WHILE USING, MEDICAL OXYGEN.
CAUTION: The Manufacturer recommends an alternate source of
supplemental oxygen in the event
of a power outage, alarm condition,
or mechanical failure. Consult your
physician or Equipment Provider for
the type of reserve system required.
It is very important to select only the prescribed level of oxygen. Do not change the
flow selection unless you have been directed
to do so by a licensed clinician.
The Oxygen Concentrator may be used during
sleep under the recommendation of a licensed
clinician.
Operator Profile
Concentrators are intended to supply supplemental
oxygen to users suffering from discomfort due to
ailments which effect the efciency of one’s lungs
to transfer oxygen in the air to their bloodstream.
Stationary oxygen concentrators (SOCs) do not
store or contain oxygen. They do not need to be re-
lled, and can recharge anywhere AC or DC power.
Oxygen concentrator use requires a physician’s
prescription and is not intended for life support use.
Although oxygen therapy can be prescribed for
users of all ages, the typical oxygen therapy user
is older than 65 years of age and suffers from a
variety of respiratory diseases, including Chronic
Obstructive Pulmonary Disorder (COPD). Users
typically have good cognitive abilities and must
be able to communicate discomfort. If the user is
unable to communicate discomfort, or unable to
read and understand the concentrator labeling and
instructions for use, then use is recommended only
under the supervision of one who can. If any discomfort is felt while using the concentrator, users
are advised to contact their healthcare provider.
Users are also advised to have back-up oxygen
available (i.e. cylinder oxygen) in the event of a
power outage or concentrator failure. There are
no other unique skills or user abilities required for
concentrator use.
Unpacking Your NewLife
Verify that all of the components listed and shown
below are included in the package. If any items are
missing, contact your oxygen provider immediately.
• Stationary Oxygen Concentrator
PN MN239 B | User Manual ENG - 5
NewLife Family
Getting to Know Your NewLife Oxygen Concentrator
First, become familiar with the important parts of
your NewLife Oxygen Concentrator (Figures 1a,
1b, and 1c).
A. On/Off (I/0) Power Switch: Starts and stops the
operation of the unit.
B. Circuit Breaker Reset Button: Resets the unit
after electrical overload shutdown
C. Digital Hour Meter: Records the unit’s total
hours of operation.
D. Flowmeter/Adjustment Knob: Controls and
indicates the oxygen ow rate in liters per minute
(lpm).
E. Oxygen Outlet: Provides connections for a
humidier (if required), nasal cannula, face mask,
or catheter.
F. Top and Side Handles: Enables convenience in
carrying the unit.
G. Operating Instructions: Explains procedures to
operate the unit.
H. Air Intake Gross Particle Filter: Prevents dust
and other airborne particles from entering the
unit.
I. Power Cord: Allows connection of unit into
electrical outlet.
WARNING: DO NOT USE EXTENSION
CORDS WITH THIS UNIT OR CONNECT
TOO MANY PLUGS INTO THE SAME
ELECTRICAL OUTLET. THE USE OF
EXTENSION CORDS COULD ADVERSELY AFFECT THE PERFORMANCE
OF THE DEVICE. TOO MANY PLUGS
INTO ONE OUTLET CAN RESULT IN
AN OVERLOAD TO THE ELECTRICAL
PANEL CAUSING THE BREAKER/FUSE
TO ACTIVATE OR FIRE IF THE BREAKER
OR FUSE FAILS TO OPERATE.
C
B
A
D
E
F
G
F
Figure 1c
H
I
Figure 1a
Important!
Safety Instructions are defined as
follows:
WARNING: IMPORTANT SAFETY
INFORMATION FOR HAZARDS THAT
MIGHT CAUSE SERIOUS INJURY.
CAUTION: Important information for
preventing damage to the NewLife
Family.
Note: Information needing special attention.
6 - ENG PN MN239 B | User Manual
NewLife Family
WARNING: IF YOU SMOKE, YOU MUST
ALWAYS FOLLOW THESE THREE (3) IMPORTANT STEPS FIRST: TURN OFF THE
OXYGEN CONCENTRATOR, TAKE OFF
THE CANNULA, AND LEAVE THE ROOM
WHERE THIS DEVICE IS LOCATED.
WARNING: “NO SMOKING – OXYGEN IN USE”
SIGNS MUST BE PROMINENTLY DISPLAYED
IN THE HOME, OR WHERE OXYGEN IS IN USE.
USERS AND THEIR CAREGIVERS MUST BE INFORMED ABOUT THE DANGERS OF SMOKING IN
THE PRESENCE OF, OR WHILE USING, MEDICAL
OXYGEN.
WARNING: FEDERAL (USA) LAW RESTRICTS THIS
DEVICE TO SALE OR RENTAL BY ORDER OF A
PHYSICIAN OR OTHER LICENSED HEALTH CARE
PROVIDER.
WARNING: THIS DEVICE SUPPLIES HIGH-CONCENTRATION OXYGEN THAT PROMOTES RAPID
BURNING. DO NOT ALLOW SMOKING OR OPEN
FLAMES WITHIN THE SAME ROOM OF (1) THIS
DEVICE, OR (2) ANY OXYGEN-CARRYING ACCESSORY. FAILURE TO OBSERVE THIS WARNING CAN
RESULT IN SEVERE FIRE, PROPERTY DAMAGE
AND / OR CAUSE PHYSICAL INJURY OR DEATH.
Indications for Use
WARNING: IT IS VERY IMPORTANT
TO SELECT ONLY THE PRESCRIBED
LEVEL OF OXYGEN. DO NOT CHANGE
THE FLOW SELECTION UNLESS YOU
HAVE BEEN DIRECTED TO DO SO BY A
LICENSED CLINICIAN.
WARNING: FEDERAL (USA) LAW RESTRICTS THIS
DEVICE TO SALE OR RENTAL BY ORDER OF A
PHYSICIAN OR OTHER LICENSED HEALTH CARE
PROVIDER.
WARNING: THIS UNIT IS NOT TO BE USED FOR
LIFE SUPPORT. GERIATRIC, PEDIATRIC, OR
ANY OTHER USER UNABLE TO COMMUNICATE
DISCOMFORT WHILE USING THIS DEVICE MAY
REQUIRE ADDITIONAL MONITORING. USERS
WITH HEARING AND/OR SIGHT IMPAIRMENT(S)
MAY NEED ASSISTANCE WITH MONITORING
ALARMS. IF YOU FEEL DISCOMFORT OR ARE
EXPERIENCING A MEDICAL EMERGENCY, SEEK
MEDICAL ASSISTANCE IMMEDIATELY.
Contraindications for Use
WARNING: IN CERTAIN CIRCUMSTANCES, THE USE OF NON-PRESCRIBED OXYGEN CAN BE HAZARDOUS. THIS DEVICE SHOULD ONLY
BE USED WHEN PRESCRIBED BY A
PHYSICIAN.
WARNING: NOT FOR USE IN THE PRESENCE OF
FLAMMABLE ANESTHETICS.
WARNING: AS WITH ANY ELECTRICALLY
POWERED DEVICE, THE USER MAY EXPERIENCE
PERIODS OF NON-OPERATION AS A RESULT OF
ELECTRICAL POWER INTERRUPTION, OR THE
NEED TO HAVE THE OXYGEN CONCENTRATOR
SERVICED BY A QUALIFIED TECHNICIAN. THE
OXYGEN CONCENTRATOR IS NOT APPROPRIATE
FOR ANY USER WHO WOULD EXPERIENCE ADVERSE HEALTH CONSEQUENCES AS THE RESULT
OF SUCH TEMPORARY INTERRUPTION.
Safety Guidelines
WARNING: CAREFULLY REVIEW AND
FAMILIARIZE YOURSELF WITH THE
FOLLOWING IMPORTANT SAFETY
INFORMATION ABOUT THE NEWLIFE
INTENSITY OXYGEN CONCENTRATOR.
WARNING: DO NOT OPERATE THIS EQUIPMENT
WITHOUT FIRST READING AND UNDERSTANDING THIS MANUAL. IF YOU ARE UNABLE TO UNDERSTAND THE WARNINGS AND INSTRUCTIONS,
CONTACT YOUR EQUIPMENT PROVIDER BEFORE
ATTEMPTING TO USE THIS EQUIPMENT; OTHERWISE INJURY OR DAMAGE COULD OCCUR.
WARNING: SMOKING WHILE USING OXYGEN
IS THE NUMBER ONE CAUSE OF FIRE INJURIES
AND RELATED DEATHS. YOU MUST FOLLOW
THESE SAFETY WARNINGS:
WARNING: DO NOT ALLOW SMOKING, CANDLES,
OR OPEN FLAMES IN THE SAME ROOM WITH
THE DEVICE OR THE OXYGEN-CARRYING ACCESSORIES.
WARNING: SMOKING WHILE WEARING AN OXYGEN CANNULA CAN CAUSE FACIAL BURNS AND
POSSIBLY RESULT IN DEATH.
WARNING: REMOVING THE CANNULA AND
PLACING IT ON CLOTHING, BEDDING, SOFAS,
OR OTHER CUSHION MATERIAL WILL CAUSE A
FLASH FIRE WHEN EXPOSED TO A CIGARETTE,
HEAT SOURCE, SPARK OR OPEN FLAME.
PN MN239 B | User Manual ENG - 7
NewLife Family
WARNING: DO NOT USE YOUR OXYGEN CONCENTRATOR IN THE PRESENCE OF FLAMMABLE
GASES. THIS CAN RESULT IN RAPID BURNING
CAUSING PROPERTY DAMAGE, BODILY INJURIES
OR DEATH.
WARNING: DO NOT LEAVE A NASAL CANNULA
ON CLOTHING, BED COVERINGS OR CHAIR
CUSHIONS. IF THE UNIT IS TURNED ON BUT NOT
IN USE, THE OXYGEN WILL MAKE THE MATERIAL FLAMMABLE. SET THE I/0 POWER SWITCH
TO THE 0 (OFF) POSITION WHEN THE OXYGEN
CONCENTRATOR IS NOT IN USE.
WARNING: USE NO OIL, GREASE, OR PETROLEUM-BASED OR OTHER FLAMMABLE PRODUCTS WITH THE OXYGEN-CARRYING ACCESSORIES OR THE OXYGEN CONCENTRATOR. OXYGEN
ACCELERATES THE COMBUSTION OF FLAMMABLE SUBSTANCES.
WARNING: USE ONLY WATER-BASED LOTIONS
OR SALVES THAT ARE OXYGEN COMPATIBLE
PRIOR TO OR DURING OXYGEN THERAPY. NEVER
USE PETROLEUM OR OIL-BASED LOTIONS OR
SALVES TO AVOID THE RISK OF FIRE OR BURNS.
WARNING: DO NOT LUBRICATE FITTINGS, CONNECTIONS, TUBING, OR OTHER ACCESSORIES OF
THE OXYGEN CONCENTRATOR TO AVOID THE
RISK OF FIRE AND BURNS.
WARNING: ELECTRICAL SHOCK HAZARD. TURN
OFF THE UNIT AND DISCONNECT THE POWER
CORD FROM THE ELECTRIC OUTLET BEFORE
YOU CLEAN THE UNIT TO PREVENT ACCIDENTAL
ELECTRICAL SHOCK AND BURN HAZARD. ONLY
YOUR EQUIPMENT PROVIDER OR A QUALIFIED
SERVICE TECHNICIAN SHOULD REMOVE THE
COVERS OR SERVICE THE UNIT.
WARNING: CARE SHOULD BE TAKEN TO
PREVENT THE OXYGEN CONCENTRATOR FROM
GETTING WET OR ALLOWING FLUIDS TO ENTER
THE UNIT. THIS CAN CAUSE THE UNIT TO MALFUNCTION OR SHUT DOWN, AND CAUSE AN
INCREASED RISK FOR ELECTRICAL SHOCK OR
BURNS.
WARNING: DO NOT USE LIQUID DIRECTLY ON
THE UNIT. A LIST OF UNDESIRABLE CHEMICAL
AGENTS INCLUDES BUT IS NOT LIMITED TO THE
FOLLOWING: ALCOHOL AND ALCOHOL-BASED
PRODUCTS, CONCENTRATED CHLORINE-BASED
PRODUCTS (ETHYLENE CHLORIDE), AND OILBASED PRODUCTS (PINE-SOL
®
, LESTOIL®). THESE
ARE NOT TO BE USED TO CLEAN THE PLASTIC
HOUSING ON THE OXYGEN CONCENTRATOR, AS
THEY CAN DAMAGE THE UNIT’S PLASTIC.
WARNING: CLEAN THE CABINET, CONTROL
PANEL, AND POWER CORD ONLY WITH A MILD
HOUSEHOLD CLEANER APPLIED WITH A DAMP
CLOTH (NOT WET) OR SPONGE, AND THEN WIPE
ALL SURFACES DRY. DO NOT ALLOW ANY LIQUID
TO GET INSIDE THE DEVICE.
WARNING: THE OXYGEN CONCENTRATOR
SHOULD NOT BE USED ADJACENT TO OR
STACKED WITH OTHER EQUIPMENT. IF ADJACENT
OR STACKED USE IS UNAVOIDABLE, THE DEVICE
SHOULD BE OBSERVED TO VERIFY NORMAL
OPERATION.
WARNING: ALWAYS PLACE THE OXYGEN SUPPLY
TUBING AND POWER CORDS IN A MANNER
THAT PREVENTS TRIP HAZARD OR POSSIBLE
ACCIDENTAL STRANGULATION.
WARNING: NO MODIFICATION OF THIS EQUIPMENT IS PERMITTED.
WARNING: USE OF CABLES AND ADAPTERS
OTHER THAN THOSE SPECIFIED, WITH THE
EXCEPTION OF CABLES AND ADAPTERS SOLD
BY THE MANUFACTURER OF THE MEDICAL ELECTRICAL EQUIPMENT AS REPLACEMENT PARTS
FOR INTERNAL COMPONENTS, MAY RESULT IN
INCREASED EMISSIONS OF DECREASED IMMUNITY OF THE OXYGEN CONCENTRATOR.
WARNING: USE ONLY ELECTRICAL
VOLTAGE AS SPECIFIED ON THE
SPECIFICATION LABEL AFFIXED TO THE
DEVICE.
WARNING: DO NOT USE EXTENSION CORDS
WITH THIS UNIT OR CONNECT TOO MANY
PLUGS INTO THE SAME ELECTRICAL OUTLET. THE
USE OF EXTENSION CORDS COULD ADVERSELY
AFFECT THE PERFORMANCE OF THE DEVICE. TOO
MANY PLUGS INTO ONE OUTLET CAN RESULT IN
AN OVERLOAD TO THE ELECTRICAL PANEL CAUSING THE BREAKER/FUSE TO ACTIVATE OR FIRE IF
THE BREAKER OR FUSE FAILS TO OPERATE.
WARNING: ENVIRONMENTAL CONDITIONS CAN
AFFECT PERFORMANCE OF DEVICE. LOCATE IN
CLEAN, PEST-FREE ENVIRONMENT.
WARNING: DEVICE SHOULD ONLY BE OPERATED BY END USERS, TRAINED CAREGIVERS, OR
TRAINED TECHNICIANS. CHILDREN SHOULD NOT
OPERATE THE DEVICE.
8 - ENG PN MN239 B | User Manual
NewLife Family
WARNING: USE OF THIS DEVICE AT AN ALTITUDE
ABOVE 3048 METERS (10,000 FEET) OR OUTSIDE
A TEMPERATURE OF 50°F TO 104°F (10°C TO
40°C) OR A RELATIVE HUMIDITY ABOVE 95% IS
EXPECTED TO ADVERSELY AFFECT THE FLOWRATE AND THE PERCENTAGE OF OXYGEN AND
CONSEQUENTLY THE QUALITY OF THE THERAPY.
WARNING: THE USE OF SOME OXYGEN ADMINISTRATION ACCESSORIES NOT SPECIFIED FOR
USE WITH THIS OXYGEN CONCENTRATOR MAY
IMPAIR ITS PERFORMANCE. RECOMMENDED
ACCESSORIES ARE REFERENCED WITHIN THIS
MANUAL.
WARNING: TO ENSURE RECEIVING THE
THERAPEUTIC AMOUNT OF OXYGEN DELIVERY
ACCORDING TO YOUR MEDICAL CONDITION THE
NEWLIFE UNIT MUST BE USED WITH THE SPECIFIC COMBINATION OF PARTS AND ACCESSORIES
THAT ARE IN LINE WITH THE SPECIFICATION
OF THE CONCENTRATOR MANUFACTURER AND
THAT WERE USED WHILE YOUR SETTINGS WERE
DETERMINED.
CAUTION: Federal (USA) law restricts
this device to sale or rental by order
of a physician or other licensed
health care provider.
CAUTION: Do not position the unit so that it is
difficult to access the power cord.
CAUTION: The concentrator should be located
as to avoid smoke, pollutants or fumes.
CAUTION: Ensure concentrator is operated in an
upright position.
CAUTION: Always place oxygen supply tubing
and power cords in a manner that prevents a
trip hazard.
CAUTION: If the audio alarm is weak or does
not sound at all, consult your Equipment Provider immediately.
CAUTION: The Manufacturer recommends an alternate source of
supplemental oxygen in the event
of a power outage, alarm condition,
or mechanical failure. Consult your
physician or Equipment Provider for
the type of reserve system required.
CAUTION: It is very important to select only the
prescribed level of oxygen. Do not change the
flow selection unless you have been directed to
do so by a licensed clinician.
CAUTION: The Oxygen Concentrator may be
used during sleep under the recommendation
of a licensed clinician. CAUTION: Do not operate
this unit in a restricted or confined space where
ventilation can be limited. This can cause the
device to overheat and affect performance.
CAUTION: Do not allow either the air intake or
the air outlet vents to be blocked. DO NOT drop
or insert any object into any openings on the
device. This can cause the Oxygen Concentrator
to overheat and impair performance.
CAUTION: Operating or storing the Oxygen
Concentrator outside of its normal operating
temperature range can impair the performance
of the unit. Refer to the specification section of
this manual for storage and operating temperature limits.
CAUTION: Position the unit away from curtains
or drapes, hot air registers or heaters. Be
certain to place the unit on a flat surface and
make sure all sides are at least 1 foot (30 cm)
away from a wall or other obstruction. Do not
place the unit in a confined area. Choose a dust
and smoke free-location away from direct sunlight. Do not operate the unit outdoors unless
the unit is plugged into a Ground Fault Circuit
Interrupter (GFCI) protected outlet.
CAUTION: In the event of an alarm or you observe the Oxygen Concentrator is not working
properly; consult the troubleshooting section of
this manual. If you cannot resolve the problem,
consult your Equipment Provider.
CAUTION: If the humidifier bottle tubing is not
properly connected to the humidifier bottle
fitting or to the oxygen outlet, an oxygen leak
can occur.
CAUTION: Normally, you should not need to adjust the flowmeter on your unit. If you turn the
flowmeter adjustment knob clockwise, you will
decrease and can shut off the flow of oxygen
from your unit. For your convenience, the flowmeter is marked in ½ LPM increments. For units
equipped with the 2 LPM flowmeter option, the
flowmeter is marked in 1/8 LPM increments for
flow settings up to 2 LPM.
PN MN239 B | User Manual ENG - 9
NewLife Family
Note: . Ensure the cannula is fully inserted and
secure. You should hear or feel oxygen flow to
the prongs of the nasal cannula. If oxygen does
not seem to flow, first verify that the flow meter
ball is registering a flow. Then, place the tip of the
cannula into a glass of water; if bubbles come out
of the cannula, oxygen is flowing. If bubbles do not
appear, refer to the troubleshooting section of this
manual.
Note: Always follow the cannula manufacturer’s
instructions for proper use. Replace the disposable
cannula as recommended by the cannula manufacturer or your Equipment Provider. Additional supplies are available from your Equipment Provider.
Note: Allow the unit to run for at least 5 minutes at
2 LPM or above before use.
Note: Always follow the cannula manufacturer’s
instructions for proper use. Replace the disposable
cannula as recommended by the cannula manufacturer or your equipment provider. Additional supplies are available from your equipment provider.
Note: The Manufacturer does not recommend the
sterilization of this equipment.
Note: If the unit has not been used for an extended
period of time, it needs to operate for several
minutes before power failure alarm can become
activated.
Note: The concentrator releases warm air out
the bottom of the unit which can permanently
discolor temperature sensitive flooring surfaces
such as vinyl. The concentrator should not be used
over flooring that is sensitive to heat staining. The
Manufacturer is not responsible for flooring that
becomes discolored.
Note: The NewLife Intensity Oxygen Concentrator
must be operated for at least five minutes at 2 LPM
before using the unit.
The NewLife Intensity is appropriate for usage by
two users, provided the combined flow is a minimum of 2 LPM and does not exceed the maximum
capacity of the concentrator.
Note: The standard NewLife Elite Oxygen Concentrator accommodates prescriptions from 1 LPM
minimum to 5 LPM maximum.
Note: The standard NewLife Intensity 10 Oxygen
Concentrator accommodates prescriptions from 2
LPM to 10 LPM maximum.
Note: To prevent a void warranty, follow all manufacturers’ instructions.
Note: Do not attempt any maintenance other than
the possible solutions listed within the manual.
Note: Do not operate the unit without the intake
gross particle filter in place.
Note: Portable and mobile radio frequency (RF)
communications equipment can effect medical
electrical equipment.
Note: There is never a danger of depleting the
oxygen in a room when you use your Oxygen
Concentrator unit.
Note: To Equipment Provider: The following oxygen
administration accessories are recommended for
use with the Oxygen Concentrator:
• Nasal Cannula with 7 feet (2.1 m) of tubing:
CU002-1
• For any additional recommended accessories,
please see the Accessories Catalog (PN MLLOX0010) available on www.CAIREmedical.com.
A firebreak is required for use with any cannula.
• CAIRE offers the OxySafe™. This is intended to be
used in conjunction with the oxygen concentrator.
The OxySafe™ is a thermal fuse to stop the flow of
gas in the event that the downstream cannula or
oxygen tubing is ignited and burns to the OxySafe.
It is placed in-line with the nasal cannula or oxygen
tubing between the patient and the oxygen outlet
of the NewLife.
For proper use of the OxySafe, always refer to the
manufacturer’s instructions (included with each
OxySafe kit).
CAIRE offers an OxySafe™ kit that includes a
cannula headpiece, OxySafe™, and 7’ tubing: PN
20629671.
WARNING: KEEP OUT OF THE REACH
OF CHILDREN UNTIL INSTALLED.
WARNING: THIS PRODUCT CAN EXPOSE YOU
TO CHEMICALS INCLUDING NICKEL, WHICH
IS KNOWN TO THE STATE OF CALIFORNIA TO
CAUSE CANCER. FOR MORE INFORMATION, GO
TO WWW.P65WARNINGS.CA.GOV.
Loading...
