Caframo BDC250 User Manual [en, de, es, fr]
Return Address
________________________
________________________
________________________
________
Canada
501273 Grey Rd 1
Georgian Bluffs ON N0H 2T0
Attn: Warranty Validation Department
Caframo Warranty Registration
F. Do you use other Caframo Products?
___Yes ____No
G. Do you use similar products from other
manufacturers?
___Yes ___No
If yes, who is the manufacturer?___________
C. Volumes mixed:
___0-1 liter (1)
___1-2 liters (2)
D. Average speed range used:
___1-1000 RPM (1)
___1000-2000 RPM (2)
E. Why did you purchase this product?
I. What do you require in your facility that you
are having a difcult time obtaining? ________
______________________________________
______________________________________
_______________________
___Reputation (1)
___Pricing (2)
___Capabilities (3)
___Other (4)
Company Name________________________________________Contact Name_____________________________________________________
Address___________________________City___________________State/Prov______________Country______Zip/Postal Code______________
Telephone_____________________________Fax____________________________E-mail____________________________________________
Name of Dealer that supplied your Caframo Product__________________________Date of Purchase____________________________________
Model #___________________________Serial #______________________________________________________________________________
Please check the correct response and return to us via mail or fax to 800-209-6786. Or register on line at www.caframo.com/lab/warranty.php .
A. Frequency of use:
___Continuous Duty (1)
___Apporx 8 hrs/day (2)
___Approx. 4 hrs/day (3)
___Approx. 1 hr/day (4)
___Infrequent Use (5)
B. Viscosity of product:
___Low Viscosity
(1CPS - ie. Water) (1)
___Med. Viscosity
(1000CPS - ie. Paint, Oil) (2)
Contents
General Instructions...............................................................................6
Safety Instructions .................................................................................6
Approvals ................................................................................................ 7
Technical Data......................................................................................... 7
Stirrer Description....................................................................................8
Installation.........................................................................................8
Environmental Operating Conditions...................................................9
General Operating Instructions..............................................................9
Cleaning And Service..............................................................................9
Warranty And Product Liability..........................................................10
Packing List
• Petite digital stirrer • Impeller shaft
• Power cord • (2) Impeller blades
• Stand base • (2) Impeller lock screws
• Stand support rod and lock nut • Instruction manual
• Allen key, (2) collet set screws
Optional Universal Adapter
Ordered separately - Caframo Part No. 250EL008
• universal AC input
• regulated output voltage
• interchangeable plugs for:
(a) North America/Mexico/Japan
(b) Europe
(c) Australia/China
(d) UK/Singapore
Measures H 74, W 43.5, D 34 mm
RoHS compliant
CE marked
5
(a)
(b)
(d)
(c)
250MN001
REV03
General Instructions
Read all safety instructions before operating.
Unpack the stirrer carefully. Ensure the stirrer is not damaged and verify the
contents against the packing list. If the stirrer is damaged or the contents do not
correspond with the packing list, notify your supplier immediately.
Read the manual carefully! Make sure that all users read the manual thoroughly
before operating the stirrer. For further questions or inquiries, please contact:
Caframo Limited
501273 Grey Road 1
Georgian Bluffs ON N0H 2T0, Canada
Tel: 519-534-1080
Toll free in USA and Canada: 800-567-3556
Fax: 800-209-6786
Email: labsales@caframo.com
Web site: www.caframo.com
Safety Instructions
Each operator should read all instruction before using this device.
The stirrer must be securely xed to a stable support such as the provided stand.
If other stands are used, the unit must be secured such that it will not fall if tipped.
CAUTION: This is not an explosion-proof stirrer. Do not use in a highly
ammable or explosive environment.
Spinning paddles or impellers can cause severe personal injuries. Operators must
use extreme care and good judgment when mixing at any speed.
All mixing paddles and impellers must be in good condition with straight shafts.
If the stirrer vibrates at high speeds, check the paddle shaft for damage, and repair
or replace if needed.
Extreme care must be taken when mixing chemicals to ensure that no chemicals
are splashed outside the mixing vessel. Care must be taken when changing to
faster mixing speeds.
Ensure that the mixing impeller does not contact the containment vessel.
Do not operate while standing in water. Keep the unit dry and do not immerse any
part, except the mixing paddle into any liquids. Protect unit and operator from
splashing.
Ensure that no loose clothing, jewelry, or hair can become entangled in any
rotating parts. A fast spinning chuck can cause injury to operator.
6
Power can be interrupted to the stirrer by pressing the power button. In an
emergency, disconnect the main power cord.
Approvals
North America
Constructed in accordance with CAN/CSA-C22.2 (1010),
FCC 15/ICES-003/EN 55011
Tested to the same standards as IEC61010.
Europe
Constructed in accordance with EMC/EMI standard EN61326-1:2006
(EN55011, conducted and radiated emissions, EN61000-3-2, EN61000-4-2,
EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6)
RoHS and WEEE compliant.
Technical Data
Model Number BDC250
Speed range 50 - 2500 rpm
Maximum torque 10 Ncm
Mechanical output power 1/100 hp, 7 watts
Input to power supply AC 100 to 240 volts, 50/60 hz (must use
supplied Caframo power cord)
Electrical output from power
supply to stirrer
Weight - stirrer only
Weight - total package
Maximum volume 2 liters, water-like viscosity
Molded housing Chemical-resistant, high-impact nylon.
Keypad Waterproof, chemical-resistant polyester
Power cord length 1.8 m (6 ft)
Stainless Steel Collet Fits 6mm (1/4”) shaft
LED display accuracy ±10 rpm, 4 digit
DC 24 V, 0.5 A
0.46 kgs (1.0 lbs)
1.94 kgs (4.25 lbs)
Recyclable (PA).
Technical specications subject to change without notice.
7
Stirrer Description
1
6
2
3
4
5
1
Four-digit LED display Collet
2
Button - power on/off Housing
3
Button - increase rpm Clamp opening
4
Button - decrease rpm Clamp knob
5
6
7
8
7
8
Installation
Stand Assembly
Remove lock nut. Insert the threaded end of the stand rod into the stand base.
Turn rod clockwise to tighten. Secure with lock nut.
Stirrer Installation
Slide the clamp opening over the top of the stand rod. Lower to desired height.
Turn clamp knob to securely tighten the stirrer onto the stand rod. Connect
supplied power cord to stirrer. Connect power cord to a grounded electrical outlet.
Impeller Assembly
Add impeller blade(s) to impeller shaft. Tighten screw to secure.
Impeller Installation
Insert impeller shaft into collet opening until it stops. Tighten set screw.
8
Environmental Operating Conditions
The BDC250 stirrer must operate in the following conditions:
• Indoors
• Altitudes not exceeding 2000 meters
• Temperature from 5 to 40°C (41 to 104°F)
• Maximum relative humidity 80% for temperatures up to 31°C (87°F)
decreasing linearly to 50% relative humidity at 40°C (104°F)
• Pollution degree 2 in accordance with IEC 664 “Normally only nonconductive pollution occurs. Occasionally, however, temporary conductivity
caused by condensation may be expected.”
General Operating Instructions
The stirrer must be securely mounted as specied in the installation instructions.
Ensure the mixing shaft and blade are securely attached. The stirrer is now ready
for use to mix liquids.
Button Operation Functions:
Power Button - Turns the stirrer motor on and off. When
initially turned on, stirrer will spin at 50 rpm.
Increase Button - Increases the speed.
Decrease Button - Decreases the speed.
OL Indicates an overload condition. The load is too great for the
stirrer and must be reduced. To reset stirrer turn power off
and back on.
Cleaning And Service
Cleaning
Using a mild soap and water solution, wipe the housing and control panel of the
stirrer with a damp cloth. Do not use chlorine bleach, chlorine-based cleanser,
abrasives, ammonia, steel wool, or scouring pads with metal content or similar
harsh solvents or abrasives. These may damage the surface of the stirrer.
Service
Do not attempt to service or repair a Caframo stirrer. If the stirrer housing is
opened, the warranty becomes void. Contact Caframo for return authorization
and return instructions.
9
Clean the stirrer so that it is free from any materials which may be harmful. Provide
an MSDS or other safety data sheets for all chemicals used in conjunction with this
stirrer where appropriate. Place the stirrer and its parts into the original packing to
protect and prevent damage during transport. Follow shipping directions provided
by Caframo when return is authorized and RMA issued.
CAUTION: Failure to clean, service, and handle the stirrer as outlined
above can cause it to fail which could impair the safety of the user.
Warranty And Product Liability
Warranty
Caframo warrants the herein described product of its manufacture for three years
from receipt of the equipment by the purchaser, against defects in material and
workmanship. Warranty registration is available on-line at www.caframo.com/
lab/warranty.php or ll out the supplied warranty registration card.
This limited warranty covers parts and labor. If the stirrer housing is opened,
the warranty becomes void.
This warranty may only be altered by a specically published amendment. No
individual has authorization to alter the provisions of this warranty policy or its
amendments. Expendable items are not covered by this warranty. Damages due to
corrosion or accidental breakage are not covered.
Liability
Under no circumstances shall Caframo be liable for indirect, consequential, or
special damages of any kind.
Caframo reserves the right to make technical changes without prior notice.
10
