It is necessary to pay attention to these warnings in order to avoid the risk of personal injury and damage to the
appliance.
Do not use the appliance if it is damaged in any way. At the rst sign of defects or unusual noises or smells, turn o
the appliance and unplug it. In such cases contact an Authorized Service Center.
Only use the appliance if the power cord is intact. If the cord is damaged, it should be replaced: contact an
Authorized Service Center. Danger of electric shocks.
Do not leave the power cord near hot surfaces, sharp edges or other sharp objects. When disconnecting the
appliance, pull on the plug, not the cord; otherwise it may be damaged.
Only connect the appliance to power outlets complying with the requirements of law. Make sure that the power
supply voltage matches the rating shown on the data plate on the bottom of the appliance.
To avoid the risk of re, set the appliance on a at, heat-resistant surface. Only use and store the appliance indoors.
Do not let the power cord dangle! Position the cord so there is no risk of tripping.
Do not allow the appliance to be used by children or persons with impaired mental, physical or sensory faculties
or insu cient experience and/or skills, unless they are under the careful supervision and guidance of a person
responsible for their safety. Children must be kept under supervision to prevent them from playing with the
appliance.
Always close the lever. Never open the lever while the appliance is operating. Always use the appliance with the
drip tray and grill in place.
The quantity of co ee dispensed can be programmed up to a maximum of 250 ml.
Please keep these instructions safe.
Safety warnings
5
Never place your hands inside the capsule compartment. Danger of injury! Never remove parts of the appliance.
Do not insert objects into the openings. This could cause electric shocks! Any operation that is not described in this
instruction manual should only be performed by an Authorized Service Center!
Clean the appliance carefully and regularly. If it is not cleaned, the build-up that forms may be hazardous to your
health. Unplug the appliance and allow it to cool before cleaning.
Descale the appliance regularly, following the instructions provided. If you do not, the appliance may be damaged
and may become harmful to your health.
Make sure the electrical elements, plug and cord are dry.
Never submerge the appliance in water. Protect the appliance from sprays and drips. Water and electricity together
constitute a risk of electrocution.
If you do not expect to use the appliance for a long period of time (leaving on vacation, etc.), unplug it.
Safety warnings
6
Your Ca taly System contact
Instructions for use and disposal
info@mapco ee.com.au
The appliance has been manufactured using high quality materials that can be reused or recycled. Dispose of the
appliance in a suitable waste collection center.
When you decide to dispose of the appliance, unplug it from the power outlet. Then cut o the power cord as close
to the body of the appliance as possible.
Directions for correct disposal of the product according to European Directive 2002/96/EC and Italian Legislative
Decree no. 151 of 25 July 2005. At the end of its useful life, the product should not be disposed of with unsorted
household waste. It should be taken to a suitable selective waste collection center set up by the local authorities
or returned to a retailer who provides this service. Separate collection of an electric household appliance avoids a
possible negative impact on the environment and health arising from improper disposal and enables the materials
it is made of to be recovered so as to achieve signi cant savings of energy and resources. The crossed-out wheelie
bin symbol applied on the product highlights the need to dispose of electric appliances separately. Improper
disposal of the product by the user shall be subject to speci c administrative sanctions as provided for under
current regulations. The packaging is made from recyclable materials. Contact the competent authorities for
information regarding local legislation.
Free call: 1800 239 438
7
Intended use
F
o
llow the instructions (symbols)
The appliance is made to brew co ee and dispense hot water. It is intended for domestic use and must be used in
accordance with these instructions. Use only Map Co ee capsules. Any other use is to be considered improper.
Use of the appliance in any manner other than as directed herein could cause harm to persons and void the guarantee.
The manufacturer will not be responsible for injury or damage resulting from improper use of the appliance.
CAUTION
This is the safety warning symbol.
It is used to call your attention to possible risks of personal injury. Abide by the safety messages provided in order
to avoid possible injury or death.
NOTE
This is the symbol used to highlight some actions that will optimize use of the appliance.
Dishwasher safe.
Not dishwasher safe.
This symbol is used to highlight a WHITE light indication.
This symbol is used to highlight a RED light indication.
This symbol is used to highlight an ORANGE light indication.
8
Description
Dispensing spout
Alarm indicator light
Descaling indicator light
Electric cord
Water tank
Water tank door
Power on/o switch
Vasca raccogligocce
Capsule compartment
Used capsule drawer
Espresso button
Filter beverage button
(
chocolate, tea flavoured beverages)
Co ee button
Lever for opening capsule compartment
9
1
1
3
5
2
4
6
Priming your machine
Fill the water tank with fresh, still water.
The buttons and alarm indicator light will blink simultaneously.
Plug in the appliance and turn it on.
Place an ample container under the dispensing spout.
At the end of this operation, empty out the water from
the used capsule drawer.
Press one of the co ee buttons. Wait for the machine to
complete the priming cycle and ll with water.
10
2
3
1
21
When the indicator lights blink alternately and the appliance emits
3 beeps, it is necessary to carry out a descaling cycle.
Turning on the appliance
Fill the water tank with fresh, still water.
Turn the appliance on.
The buttons will blink simultaneously to indicate that the machine
is warming up. When the buttons remain steadily lit, the appliance
is ready for operation.
General operating indications
1ST DESCALING SIGNAL 2
ND
DESCALING SIGNAL - DISABLING
When the indicator light blinks and the appliance emits 3 beeps, it
is advisable to carry out a descaling cycle.
2
11
1
32
Continued
WARMING UP WHEN THE WATER RUNS OUT DURING OPERATION
The buttons ash simultaneously.
The indicator light will blink RED and the appliance will emit
3 beeps: the water tank is empty or water flow has been
interuppted.
Fill the tank with fresh, still water.
Raise lever to eject capsule, lower lever. Press the
same button as before; the appliance will resume
dispensing.
12
21
43
5
IF THE LEVER IS RAISED
If the lever is raised while a beverage is being dispensed.
T
he indicator light will blink RED and an intermittent beep will be
emitted. The appliance will immediately stop dispensing.
Close the lever
Press a button to reset the alarm.
Press the button corresponding to the desired type of co ee to
brew a new cup.
Espresso
Filter co ee
Long co ee
13
4
1
5
3
4
2
In order to use espresso cups, you must lift and turn the grill on top
of the drip tray.
The grill must be positioned over the drip tray turned.
Adjusting the cup/mug height
The appliance can be adjusted for the use of mugs or espresso
cups.
The appliance is initially set for the use of large cups or mugs.
In this way you can obtain the best results when using small
espresso cups.
14
5
5 6
3 4
1 2
Warning! Before you start
brewing, make sure the capsule
container is not full.
Brewing co ee
Raise the lever to open the capsule compartment. Insert the capsule, pressing it gently into place.
Close the lever rmly.
Place a cup or mug under the co ee dispensing spout
(see chapter 4).
Press the desired co ee button only once. The selected co ee button will blink. The appliance will stop
dispensing on reaching the programmed quantity and the emit
a beep.
Espresso
Filter beverage
Long co ee
15
6
87
Preparing other beverages
Capsules may be available for preparing beverages such as tea, chamomile tea, fi lter beverages,
etc. For their use, proceed as directed in the previous chapter; on reaching step 5, press “Filter coff
ee”.
In order to prepare beverages using barley capsules, cocoa drinks, etc.. proceed as directed in the previous chapter; on reaching step
5, press “Espresso or Long Co ee” depending on the desired quantities.
NOTE:
Traces of the product just dispensed may remain inside the machine.
When switching from one product to another, in order to fully enjoy the avor of the beverage we suggest rinsing
the machine by pressing the co ee button as if to dispense a co ee without inserting a capsule.
NOTE:
The quantities of co ee dispensed can be reprogrammed according to personal taste and the size of the
cups/mugs used. Please refer to chapter 7 for reprogramming instructions.
Raise the lever to eject the used capsule into the drawer. Close the lever.
16
7
5 6
3 4
1 2
Warning! Before you start
brewing, make sure the capsule
container is not full.
Programming the quantity of co ee in a cup
Place a cup or mug under the co ee dispensing spout depending
on the type of co ee you wish to program (see chapter 4).
Press the desired co ee button and keep it pressed down.
On reaching the desired amount of co ee in a cup, release the
button. Now the button is programmed. To reprogram the button
or program another button repeat the above steps.
Raise the lever to open the capsule compartment.
Insert the capsule, pressing it gently into place.
Close the lever rmly.
Espresso
Filter beverage
Long co ee
17
8
2 3
Saving energy
1
Keep the buttons pressed down and at the same time turn on the
machine by pressing the power on/o switch.
The indicator light will ash three times and three beeps will be
emitted to con rm deactivation of the “Energy Saving” function.
When the function is reactivated, the indicator light will ash
twice and two beeps will be emitted.
The machine features a function (normally activated) which
automatically reduces energy consumption by around 98% after
one hour has elapsed since it was last used. To deactivate (or
reactivate) this function, proceed as follows:
Once the “Energy Saving” function has been programmed, the
machine will automatically reduce consumption one hour after
the last use. The buttons will cyclically and slowly blink with a
WHITE light.
To restore normal operating conditions, press any button or
raise the lever. The appliance will start warming up. When the
appliance is ready for use the buttons will be steadily lit WHITE.
Make sure the lever is lowered.
18
1
3
2
4
9
Remove the drip tray and used capsule drawer.
Remove the grill. Empty the drip tray and rinse it out with
fresh water.
Lift the capsule drawer; empty and rinse it out.
Remove the water tank. Empty and rinse out the tank. The water
tank is NOT dishwasher safe.
Use a soft, dampened cloth and a neutral detergent to clean the surfaces of the appliance.
The plastic parts of the machine are not dishwasher safe.
Daily maintenance
19
10
1
3
2
4
Descaling the machine
The machine features an advanced program that monitors how much water is used to dispense beverages. This
measurement provides the user with indications as to when the machine needs to be descaled. Speci c indications are
given in chapter 3.
Carefully read the directions for use on the package of the descaling agent. Avoid contact with eyes, skin and machine
surfaces. Do not use vinegar: it could damage your appliance! During descaling, do not turn the machine o .
Turn the machine o .
Remove and empty the water tank.
Empty and rinse out the used capsule drawer and drip tray.
Prepare the descaling solution following the manufacturer’s
directions and pour a liter of solution into the tank.
20
5 6
10
7 8
The machine delivers descaling solution at intervals. During
this phase the LEDs blink alternately.
During this process do not press any buttons or
interrupt machine as this will inactivate auto descaling.
(Refer to page 22 should descaling be interrupted)
Place a container (at least 250 ml) under the co ee dispensing
spout.
Keep the buttons pressed down and simultaneously turn on the
machine by pressing the power on/o switch.
Make sure the lever is lowered.
The blue button and the LEDs blink alternately. Press the button to
start the descaling cycle.
If the container lls up, empty it out.
9
21
16
13
14
11 12
Rinse water will be run through the machine. During this phase
the LEDs blink alternately (2 blinks at a time).
Empty and rinse out the used capsule drawer and drip tray. The blue button and the LEDs blink alternately.
Press the button to start the rinse cycle.
When the cycle is over, the blue button and the LEDs blink
alternately.
Carefully rinse out the water tank and ll it with fresh drinking
water.
If the container lls up, empty it out.
15
22
17 18
19
20
Carefully rinse out the water tank and ll it with fresh drinking
water.
Empty and rinse out the used capsule drawer and drip tray.
Press the button to quit the cycle.
When the rinse cycle is over, the blue button and the LEDs blink
alternately. The machine will emit a beep.
Use a soft, dampened cloth and a neutral detergent to
clean the surfaces of the appliance.
i. Lower lever and ensure water tank is refilled with freshwater.
ii. Ensure machine is powered ON.
iii. Press and hold small and large coffee buttons for 10 seconds until 3 beeps are emitted then release.
iv. Turn off your machine and then turn back on.
NOTE
Should descaling be interuppted please follow steps below to restart machine:
23
11
6
3 4
5
1 2
Draining the appliance
CAUTION - When the appliance is not used for a long time, it is necessary to drain the water lines. Liquids may freeze and
damage the appliance.
Make sure the lever is lowered.Turn the machine o .
Turn the machine o . The next time you turn it on you will have to
carry out a new start-up procedure.
Remove and empty out the water tank. Keep the buttons pressed down and at the same time turn on the
machine by pressing the power on/o switch.
The indicator light will blink and the machine will carry out a
drainage cycle. At the end the machine will emit a beep.
24
12
13
See the data plate on the bottom of the machine
Máx. 15 bar
approx. 4 kg
1.2 liters
5 °C - 15 °C
170 mm 296 mm 260 mm
Troubleshooting
Technical data
Problem Cause Solution
No co ee is brewed. The water tank is empty, the alarm
indicator light is on and red.
Fill the tank with fresh water.
Press the desired co ee button.
The appliance will resume brewing.
The co ee is not hot enough. Cold cups / mugs
Scale build-up in machine.
Preheat the cup.
Descale the machine.
The lever cannot be lowered. The used capsule drawer is full.
Capsule stuck inside the machine.
Empty out the used capsule drawer.
Remove the used capsule.
The materials and objects in contact
with food products comply with the
requirements of European Regulation
1935/2004.
25
26
27
Imported
for
Map
Coffee
By
Earth
Rules
Pty.
Ltd.
2-4
Buckhurst
StreetSouth
Melbourne
VIC
3205
Phone
1800
239
438
-
www.mapcoffee.com.au
Loading...
