Café™ ENERGY STAR® 22.3 Cu. Ft. Smart Counter-Depth
4-Door French-Door Refrigerator in Platinum Glass
CXE22DM5PS5
FEATURES
Configuration French-door & Double drawer
WiFi connect Built-in
Connected capabilities
Temperature management features Multiflow air system
Temperature management system TwinChill™ evaporators
Defrost type Frost Guard
Control type Electronic temperature controls
Dispenser
Dispenser features
Icemaker Space saving ice
Water filtration
Filter location Left wall
Fresh food cabinet drawers 2 total; 2 adjustable humidity drawers
Fresh food cabinet shelves 4 glass split; 1 Quick Space shelf
Fresh food door bins 6 total; 2 with gallon storage; 2 adjustable
Fresh food door features Dairy compartment
Freezer door bins 1 tilt out
Freezer storage baskets
CXE22DM5PS5
Platnum
FEATURES & BENEFITS
Enjoy the flexibility of a Convertible Drawer with Soft Freeze with settings as
low as 23 degrees or as high as 42 degrees, and keep items organized with
sliding glass dividers
Relish the bright, uniform light of an LED light wall that spans the back wall of
the refrigerator, illuminating the fresh food section so every item is easy to find
Eortlessly fill containers with filtered water by simply pressing the AutoFill
button which uses sensors to dispense the perfect amount every time
A Humidity Control System provides an environment for leafy green
vegetables to last 2-1/2 times longer than standard vegetables drawers.
(*Based on internal testing vs. similar size vegetable drawers with humidity
controls from a leading competitor.)
Easily pull out a slim, full-width tray to accommodate gourmet pizzas and other
frozen, uniquely shaped items
Receive alerts on your smart device whenever your refrigerator’s internal
temperature dips below normal, thanks to built-in WiFi connectivity that helps
you keep foods party-platter ready
From produce to packaged goods, keep any food fresh with TwinChill™
evaporators that create separate climates in the fresh food and freezer sections
Spend more time filling and less time fumbling thanks to the Integrated
Dispenser Design, which senses your proximity and automatically illuminates,
so you never have to compromise on function and fashion
Make a statement with Modern Glass. This sleek refrigerator will speak to
your sensibilities thanks to an unrivaled glass finish, paired with modern lines,
attention to detail and unexpected accents
Freezer features
Exterior style Counter-depth
Leveling system 2 point front adjustable
Performance features
Center drawer features
CAPACITY
Total capacity (cubic feet) 22.3 cu. ft.
Fresh food capacity 12.68 cu. ft.
Freezer capacity 6.73 cu. ft.
Convertible drawer capacity 2.92 cu. ft.
WEIGHTS & DIMENSIONS
Overall depth 28-7/8 in.
Overall height 69-7/8 in.
Overall width 35-5/8 in.
Case depth without door 24 in.
Depth with door open 90° 43 in.
Depth without handle 28-7/8 in.
Height to top of hinge 69-3/4 in.
Height to top of case 68-5/8 in.
Width w/door open 90 degrees
incl. handle 44-7/8 in.
Back air clearances 2 in.
Side air clearances 1/8 in.
Top air clearances 1 in.
Approximate shipping weight 410 lb.
Net weight 375 lb.
Amazon Alexa; The Google Assistant; IFTTT; DSM
Capable; Sonos
Large stainless steel; Cubes, crushed ice and
chilled water
Hands-free AutoFill; Door alarm; Proximity activated
LED dispenser light; Water filter indicator light
GE water filtration 6 month; XWFE; Water filter
indicator light
1 deep bulk storage; 1 flat bread; 1 quick reach;
3 total full-width
Interior lighting - LED; Freezer drawer
with full-extension slides
Easily removable door gaskets; Sabbath Mode
capable; Deluxe quiet design; Dual evaporator
cooling
Convertible drawer; 5 temperature settings
(Soft Freeze, Meats, Beverages, Snacks, Wine
& control lock); 2 Tuck Away glass dividers;
Full-extension slides
APPEARANCE
Exterior design Flat Glass Doors
Handle Integrated pocket
Handle design Café Minimal
Hidden door hinge(s) Ye s
Café™ ENERGY STAR® 22.3 Cu. Ft. Smart Counter-Depth
H
F
G
I
L
J
K
E
4-Door French-Door Refrigerator in Platinum Glass
CXE22DM5PS5
WARRANTY
Parts warranty
Labor warranty
Warranty notes See written warranty for full details
Limited 1-year entire appliance; Limited 5-year sealed
refrigerating system
Limited 1-year entire appliance; Limited 5-year sealed
refrigerating system
DIMENSIONS
BIC
A
L
K
J
H
E
F
G
A - Overall Height to top of door (in)
B - Height to top of hinge cover (in)
C - Height to top of case (in)
D - Hinge Cover Depth from Case Flange (in)
E - Case Depth without door (in)
F - Case Depth without Door Handle (in)
G - Depth with Door open 90 deg (in)
Overall
Dimensions
H - Case Width (in)
I - Width with door open 90 deg including handle (in)
J - Top endcap of FZ drawer to floor (in)
K - Top endcap of Middle drawer to floor (in)
L - End cap to End cap height of middle drawer (in)
69 7/8
69 3/4
68 5/8
6
24
28 7/8
43
35 5/8
44 7/8
24 1/2
33 1/2
8 5/8
For answers to your Café™ product questions, visit our website at cafeappliances.com.
© 2021 GE Ap pliances PC95837 4/2 1
