1. Introduction
The A829US is a multi protocol fully integrated UHF low power short range reader
designed specifically to be used in desktop or embedded RFID application.
The A829US is fully compliant to the US telecommunication regulation FCC part 15
(902-928 MHz) and it is the reader solution to solve the problem of proximity
reading/writing of tags and labels, where transponders are up to 1 metre distance from
the reader.
Currently the A829US Module supports the ISO18000-6 B, the Philips UCODE EPC 1.19
and EPC Class1 Gen2 protocols. Other future UHF protocols will be available by
firmware upgrade. The A829US houses an integrated antenna, and an USB interface for
PC connection. It is a bus powered USB device designed to operate as a stand alone PC
peripheral communicating via an USB serial port.
Fig. 1.1: Mod. A829US Fully integrated UHF compact reader
NPO: Filename: Number of pages: Page:
00107/05:829US.MUTx/02 A829US_REV1.DOC 5 3
Document type: Title: Revision date: Revision:
User's Manual (MUT) A829US Fully integrated UHF compact reade (FCC part15) 23/01/2007 2
2. Mod. A829US Technical Specifications
2.1. Mod. A829US Technical Specifications Table
Table 2.1: Mod. A829US Technical Specifications
Frequency
RF Power
Antenna
Frequency Tolerance
Number of Channel
Standard compliance
Digital I/O
USB Port
912.500÷917.400 MHz (FCC part 15)
60 mW ERP @ 5V
Integrated Linear polarized Antenna (3.0 dBi @ 915MHz)
±10 ppm over the entire temperature range
50 hopping channels (compliant to FCC part 15)
ISO 18000-6B
Philips UCODE EPC 1.19
EPC C1G2
EPC C1G1 (via firmware upgrade)
Six I/O lines 3.3 V out, 5 V tolerant
USB B female connector
Bus powered USB 2.0 device
Must be connected to High-power Port (> 500 mA @ VBUS)
It appears as USB serial port
Virtual Com Port (VCP) drivers for - Windows 98/2000/ME/XP
Windows CE 4.2, Linux 2.40 and greater
LED display
Dimensions
Electrical Power
Operating Temperature
RED: Power GREEN: Identify TAG YELLOW: USB communication
180 x 130 x 97 mm3 (7.1 x 5.1 x 3.8 inches3)
5 V DC bus powered (USB) Max 250 mA
-20 °C to 60 °C
2.2. External connections
The location of the connectors is on the A829US back side. Their mechanical
specifications are listed here below:
USB Port: USB B female connector, Bus powered USB 2.0 device; it must be connected
to High-power Port (> 500 mA @ VBUS)
GPIO Connector: 3M-7610-5002-5+5 type; Function: general purpose Input/Output, see
figure for pin assignment
NPO: Filename: Number of pages: Page:
00107/05:829US.MUTx/02 A829US_REV1.DOC 5 4
Document type: Title: Revision date: Revision:
User's Manual (MUT) A829US Fully integrated UHF compact reade (FCC part15) 23/01/2007 2
GND
RESET
GPIO4/
ID TAG
GPIO3
EXT
POWER
9
1078
GND
Fig. 2.1: GPIO Connector pin assignment
2.3. Front panel Leds
The A829US front panel houses the following Leds (from left to right):
Function: Type:
ID Tag Led Red Led
Power ON Led Green Led
USB Communication Led Yellow Led
2.4. Regulatory Compliance
GPIO2
5
6
GPIO1
3
4
GPIO0
1
2
EXT
POWER
This equipment has been tested and found to comply with Part 15 of the FCC Rules.
NOTE:
(a) Any changes or modification not approved by CAEN RFID could void the user’s
authority to operate the equipment.
(b) Persons must respect a separation distance of at least 20 cm from the reader. This
device may not be co-located with any other transmitter or transmitter antenna.
