Cadillac CTS-V Wagon 2014, CTS-V Sedan 2014, CTS-V Coupe 2014, CTS Wagon 2014, CTS Sedan 2014 User's Guide
...
2014
ConvenienCe/Personalization Guide
Review this guide for an overview of some important features in your Cadillac CTS. Some optional equipment (denoted by ♦) described
in this guide may not be included in your vehicle. More detailed information can be found in your Owner Manual.
Instrument Panel
Memory
Seat
Buttons
Power
Mirror
Controls
Electric
Parking
Brake
Switch
Cruise Control/
Voice Recognition/
Heated Steering
Wheel♦ Buttons
Turn Signal
Lever/Exterior
Lamps
Control
Head-Up
Display
Controls♦
Instrument
Cluster/Driver
Information
Center
Power Rake/
Telescope
Steering Wheel
Control♦
Manual
Paddles
Windshield
Shift
Audio Steering
Wheel Controls/
5-way Control
Wipers
Lever
2
Hazard Warning
Flashers/Lane
Departure
Warning Buttons
Engine
Start/Stop
Button
CUE
Touch
Screen
Traction Control
and StabiliTrak
Button/Driver
Mode Control
Glove Box/Parking
Assist/Automatic
Parking Assist♦
Buttons
Heated/
Ventilated Seat
Buttons♦
Audio
System
Controls
Climate
Controls
Steering Wheel Controls
Cruise Control
On/Off
On/Off
(Adaptive Cruise Control♦)
SET Set Speed
With Cruise Control on, press
the control bar down fully to set the cruise speed.
RES Resume Speed
With Cruise Control on, press the control bar up fully to resume
the previous set speed.
+ – Adjust Speed
When active, press the control bar up (+) or down (–) lightly to
increase or decrease the set speed by 1-mph increments; press
up or down fully to increase or decrease the set speed to the next
5-mph interval on the speedometer.
Cancel
Press to cancel cruise control without erasing the set speed from
memory.
Follow Distance Gap (Adaptive Cruise Control♦)
Press repeatedly to select a gap setting of Far, Medium, or Near.
See Driving and Operating in your Owner Manual.
Heated Steering Wheel♦
On/Off
See Instruments and Controls in your Owner Manual.
♦ Optional equipment
Voice Recognition
Push to Talk
Press to interact with the OnStar, Bluetooth or CUE system.
End Call/Mute
Press to end/reject a call or mute the audio system.
See your CUE Infotainment System Manual.
5-Way Control
Moves left/right, up/down, and in.
Left/Right
Press to view the left or right
cluster display. Press the left
to exit a display menu.
Up/Down
Press the control bar up or down
to scroll through a menu.
SEL Select
Press to select a highlighted menu item.
See Instruments and Controls in your Owner Manual.
Audio Controls
+ – Volume
Press the + or – to increase or decrease the volume.
Next/Previous
Press or to select the next or previous favorite radio
station, track or le.
See your CUE Infotainment System Manual.
3
Instrument Cluster
Uplevel Performance Cluster♦ shown
Cluster Display Zones
Use the 5-way control on the right
side of the steering wheel to move
between the different display zones
and scroll through the different dis-
plays in each cluster conguration.
Uplevel Cluster Congurations♦
1. With the vehicle in Park, use the 5-way control on the steering
wheel to nd the Settings page in one of the display zones on
the cluster.
2. Press SEL (Select) to enter the Settings menu.
3. Scroll down to highlight Display Layout; press SEL.
4. Scroll up or down to highlight one of four cluster congurations;
press SEL.
5. Press to exit the menu.
See Instruments and Controls in your Owner Manual.
4
Driver Information Center
The Driver Information Center (DIC) on the instrument cluster
displays a variety of vehicle information. The DIC Info Displays
may include a digital speedometer, trip odometers, fuel range,
average fuel economy, instantaneous fuel economy, average
speed, timer, compass, turn arrow, travel time, distance to
destination, speed limit speed warning, cruise control set speed,
follow distance gap/gap setting, battery voltage, oil life, and
odometer.
Info Pages Menu
1. Use the 5-way control on the right side of the steering wheel
to nd the Settings page in one of the display zones on the
cluster. Press SEL to enter the Setting menu.
2. Scroll down to highlight Info Pages; press SEL.
3. Scroll up or down to move through the list of
Info Displays.
4. Press SEL to select or deselect a display item.
Head-Up Display♦
The Head-Up Display (HUD) displays some operating information
onto the windshield. The HUD controls are located on the left side
of the instrument panel.
HUD
Lift up or press down to adjust the position of the image. It cannot
be adjusted side-to-side.
INFO
Press to select from four displays: Speed View; Audio/Phone
View; Navigation View; and Performance View.
+ –
Lift up or press down to brighten or dim the display.
Hold down to turn off the display.
See Instruments and Controls in your Owner Manual.
♦ Optional equipment
See Instruments and Controls in your Owner Manual.
5
Touch Screen and Controls
Applications:
Touch the screen icon
to access the desired
application
VOLUME:
Touch arrows or swipe
nger above chrome bar
Power/Mute:
Press and hold to turn
CUE On/Off; Press to
mute audio
Driver’s Temperature
Control
OFF
Climate Control Power Off
Driver’s Heated/
Ventilated Seat Control♦
AUTO:
Automatic Climate
Control Operation
Windshield Defrost Mode
The controls use capacitive technology – simply touch the icon/text
to access a feature or adjust a function.
6
See your CUE Infotainment System Manual.
Additional Pages:
Touch to view additional
pages of applications
Interaction Selector:
Touch to display the
favorites list.
Home Page
Passenger’s
Temperature Control
Climate Control Fan Speed
Passenger’s Heated/
Ventilated Seat Control♦
Recirculation Mode
Rear Window Defog
Storage Compartment
with USB Port:
Press and hold the bright
bar to open/close
