Black plate (1,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

2015 Cadillac CUE Infotainment System M

Infotainment System .. . . . . 3

Introduction . ... . . . . . . . . . . . . . 3

Infotainment . . . . . . . . . . . . . . . . . . . . 3

Overview . . . . . . . . . . . . . . . . . . . . . . . 3

Steering Wheel Controls . . . . . . . 6

Using the System . . . . . . . . . . . . . . 7

Software Updates . . . . . . . . . . . . . 10

Radio . . . . . . . . . . . . . . . . . . . . . . . 11

AM-FM Radio . . . . . . . . . . . . . . . . . 11

Radio Reception . . . . . . . . . . . . . . 15

Backglass Aerial . . . . . . . . . . . . . . 15

Multi-Band Aerial . . . . . . . . . . . . . . 16

Audio Players . . . . . . . . . . . . . 16

CD Player . . . . . . . . . . . . . . . . . . . . . 16

USB Port . . . . . . . . . . . . . . . . . . . . . . 19

SD Card Reader . . . . . . . . . . . . . . 23

Auxiliary Jack . . . . . . . . . . . . . . . . . 23

Bluetooth Audio . . . . . . . . . . . . . . . 23

Rear Seat Infotainment . . . 24

Rear Seat Entertainment (RSE)

System . . . . . . . . . . . . . . . . . . . . . . 24

Rear Seat Entertainment (RSE)

System (Platinum) . . . . . . . . . . . 43

Navigation . . . . . . . . . . . . . . . . . 56

Using the Navigation

System . . . . . . . . . . . . . . . . . . . . . . 56

Maps . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Navigation Symbols . . . . . . . . . . . 62

Destination . . . . . . . . . . . . . . . . . . . . 65

Settings . . . . . . . . . . . . . . . . . . . . . . . 79

Global Positioning

System (GPS) . . . . . . . . . . . . . . . 80

Vehicle Positioning . . . . . . . . . . . . 81

Problems with Route

Guidance . . . . . . . . . . . . . . . . . . . . 82

If the System Needs

Service . . . . . . . . . . . . . . . . . . . . . . 82

Map Data Updates . . . . . . . . . . . . 82

Database Coverage

Explanations . . . . . . . . . . . . . . . . . 82

Voice Recognition . . . . . . . . 83

Phone . . . . . . . . . . . . . . . . . . . . . . 91

Bluetooth (Overview) . . . . . . . . . . 91

Bluetooth (Infotainment

Controls) . . . . . . . . . . . . . . . . . . . . 92

Bluetooth (Voice

Recognition) . . . . . . . . . . . . . . . . . 96

Text Messaging . . . . . . . . . . . . . . . 97

Settings . . . . . . . . . . . . . . . . . . . . 98

Trademarks and License

Agreements . . . . . . . . . . . . .

101

Index . . . . . . . . . . . . . . . . . . . . . i-1

Page 3

Black plate (2,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Page 4

Black plate (3,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 3

Introduction

Infotainment

The names, logos, emblems, slogans, and vehicle body designs appearing in this manual including, but not limited to, GM, the GM logo, CADILLAC, CADILLAC Emblem and CADILLAC CUE are registered trademarks of General Motors LLC., its subsidiaries, affiliates, or licensors.

This manual describes features that may or may not be on the vehicle because of optional equipment that was not purchased on the vehicle, model variants, country specifications, features/applications

that may not be available in your region, or changes subsequent to the printing of this manual.

Keep this manual with the owner manual in the vehicle, so it will be there if it is needed. If the vehicle is sold, leave this manual in the vehicle.

Overview

Read the following pages to become familiar with the infotainment system features.

{

Warning

Taking your eyes off the road for too long or too often while using any infotainment feature can cause a crash. You or others could be injured or killed. Do not give extended attention to infotainment tasks while driving. Limit your glances at the vehicle

(Continued)

Warning (Continued)

displays and focus your attention on driving. Use voice commands whenever possible.

The infotainment system has built-in features intended to help avoid distraction by disabling some functions when driving. These functions may grey out when they are unavailable. Many infotainment features are also available through the instrument cluster and steering wheel controls.

Before driving:

Become familiar with the operation, faceplate buttons, and screen buttons.

Set up the audio by presetting favourite stations, setting the tone, and adjusting the speakers.

Set up phone numbers in advance so they can be called easily by pressing a single

Page 5

Black plate (4,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

4 Infotainment System

button or by using a single voice command if equipped with Bluetooth phone capability.

See "Defensive Driving" in the owner manual.

To play the infotainment system with the ignition off, see “Retained Accessory Power (RAP)” in the owner manual.

Customer Assistance

Assistance may be available to help with Bluetooth pairing, other mobile device interfaces, and operation support of the CUE infotainment system. See your dealer.

Infotainment System

The infotainment system is controlled by using the touchscreen, the buttons below the touchscreen, steering wheel controls, and voice recognition.

1. O (Power and Mute)

2. Volume

{ (Home Page)

Power (On/Off/Mute)

When off, press O (1) to turn the system on. Press and hold to turn off.

When on, press O to mute the system. Press

O again to

unmute the system.

Retained Accessory Power (RAP)

The vehicle has RAP. When in RAP the audio system can be played even after the ignition is turned off. See “Retained Accessory Power (RAP)” in the owner manual.

Volume

The black area above the chrome bar (2) is used to increase or decrease the volume. There are three ways to adjust the volume:

Slide a finger.

Press.

Press and hold.

Rear Seat Armrest Control Panel

If equipped, there is a control panel in the centre of the rear seat back. See “Armrest Storage” in the owner manual.

Page 6

Black plate (5,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 5

1. O (Power): Press to turn the

power on or off for the sourced audio or media playback and sunshade control button (if equipped).

S VOL T (Volume): Press the

left or right arrow to adjust the volume of current playback.

Q (Sunshade Switch): Press

and release the switch to control the rear window sunshade. See “Rear Window Sunshade” in the owner manual.

4. SRCE (Source): Press to change the source of playback.

S SEEK T: Press the left or

right arrow to go to the previous or next station on the radio or track on a media source.

6. PRESET: Press to go to a saved favourite.

Home Page

The Home Page is where application icons are accessed. Some features are disabled when the vehicle is moving.

The Home Page can be set up to have up to five pages with eight icons per page.

Press the left

u or right v or slide

a finger left/right across the screen to access the pages of icons.

v (Next): Press to go to the next

Home Page.

u (Previous): Press to go to the

previous Home Page.

k (Interaction Selector): Press to

display the favourites list.

Press and hold a location within the favourites area to begin the process of saving a favourite application.

Press the application icon to store as a favourite, and the name of the application will be shown in favourites.

Home: Press to go back to the Home Page to start a different application.

Managing Home Page Icons

1. Press and hold any of the Home Page icons to edit that icon.

Page 7

Black plate (6,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

6 Infotainment System

2. Drag the icon to a new location on the Home Page or to save it to the applications tray.

3. Press

{ to exit edit mode.

Steering Wheel Controls

The infotainment steering wheel controls can be used to control the infotainment features displayed in the instrument cluster.

When in Valet Mode (if equipped), access to the infotainment functions is disabled. See Settings on page 98.

g (Press to Talk): Press to answer

an incoming call or to start a voice recognition. See Bluetooth

(Overview) on page 91 or Bluetooth (Infotainment Controls) on page 92 or Bluetooth (Voice Recognition) on page 96.

c (End Call): Press to decline an

incoming call, or end a current call. Press to mute or unmute the infotainment system when not on a call.

S or T (Previous or Next): Press

the five-way control to the left or right to go to the previous or next area in the display or to the previous or next menu.

y or z (Previous or Next):

Press the five-way control up or down to go up or down in a list or page.

SEL: Press to select a highlighted menu item.

C or B (Next or Previous

Favourite): Press to go to the next or previous favourite when listening

Page 8

Black plate (7,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 7

to the radio. Press to go to the next or previous track when listening to a media source.

x + or x − (Volume): Press to

increase or decrease the volume.

Using the System

Audio

Press the AUDIO icon to display the active audio source page. Available sources are AM, FM, CD (if equipped), My Media, USB, SD, Bluetooth, and AUX Input.

Phone

Press the PHONE icon to display the Phonemain page. See Bluetooth

(Overview) on page 91 or Bluetooth (Infotainment Controls) on page 92 or Bluetooth (Voice Recognition) on page 96.

NAV (Navigation, If equipped)

Press the NAV icon to display the navigation map. See Using the Navigation System on page 56.

Settings

Press the SETTINGS icon to display the Settings menu. See Settings on page 98.

Energy (If Equipped)

Press the ENERGY leaf icon to display energy flow on the hybrid vehicle. See the owner manual.

Climate

Press the CLIMATE icon to display the Climate main page. See “Dual Automatic Climate Control System” in the owner manual.

Rear Climate (If Equipped)

Press the R. CLIMATE icon to display the Rear Climate main page. See “Rear Climate Control System” in the owner manual.

Video (If Equipped)

Press the VIDEO icon to display the video Rear Seat Entertainment main page. See Rear Seat Entertainment

(RSE) System on page 24 or Rear Seat Entertainment (RSE) System (Platinum) on page 43.

Applications Tray

The applications tray is at the top centre of the screen. The applications tray can have three to five applications.

To add an application from the Home Page to the applications tray:

1. Press and hold any icon on the Home Page to enter edit mode.

Page 9

Black plate (8,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

8 Infotainment System

2. Drag the icon to the applications tray.

To remove an item from the applications tray, drag the icon from the applications tray back to the Home Page.

Adding or removing applications from the applications tray will not remove them from the Home Page.

Touchscreen Buttons

Touchscreen buttons show on the screen when available. When a function is unavailable, the button may grey out. When a function is selected, the button may highlight.

Proximity Sensing

The infotainment system uses proximity sensing. When enabled, certain screen buttons and features will become visible when a hand approaches the screen. When the hand is removed, these features fade. Proximity sensing can be disabled in the Settings applications in the Display menu options.

Haptic Feedback

Haptic feedback is a pulse that occurs when a button is pressed on the screen or when buttons below the screen are pressed.

Infotainment Gestures

Use the following finger gestures to control the infotainment system.

Press/Tap

Press/Tap is used to select a button or option, activate an application, or change the location inside a map.

Press and Hold

Press and hold can be used to start another gesture, move, or delete an application.

Page 10

Black plate (9,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 9

Drag

Drag is used to move applications on the Home Page, or to pan the map. To drag the item, it must be held and moved along the screen to the new location. This can be done up, down, right, or left.

Nudge

Nudge is used to move items a short distance on a list or a map. To nudge, hold and move the selected item up or down to a new location.

Fling or Swipe

Fling or swipe is used to scroll through a list, pan the map, or change page views. Do this by placing a finger on the screen then moving it rapidly up and down or right and left.

Page 11

Black plate (10,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

10 Infotainment System

Spread

Spread is used to zoom in on a map, certain images, or web page. Place finger and thumb together on the screen, then move them apart.

Pinch

Pinch is used to zoom out on a map, certain images, or a web page. Place finger and thumb apart on the screen, then move them together.

Cleaning High Gloss Surfaces and Vehicle Information and Radio Displays

For vehicles with high gloss surfaces or vehicle displays, use a microfiber cloth to wipe surfaces. Before wiping the surface with the microfiber cloth, use a soft bristle

brush to remove dirt that could scratch the surface. Then use the microfiber cloth by gently rubbing to clean. Never use window cleaners or solvents. Periodically hand wash the microfiber cloth separately, using mild soap. Do not use bleach or fabric softener. Rinse thoroughly and air dry before next use.

Software Updates

Contact your dealer for website information.

Page 12

Black plate (11,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 11

Radio

AM-FM Radio

Playing the Radio

While on the audio main page the available sources are: AM, FM, DAB, CD (if equipped), My Media, USB, SD, Bluetooth, and AUX Input.

Press the RADIO screen button to scroll through AM, FM, or DAB.

Press the MEDIA screen button to scroll through CD (if equipped), My Media, USB, SD, Bluetooth, and Aux Input.

Infotainment System Settings

Press the RADIO screen button to access broadcast sources.

Press the MENU screen button to display the following menus:

Tone Settings:

Bass, Midrange, Treble – Press + or − to adjust the volume of the seat speakers.

Surround – If equipped, press + or − to adjust.

Balance – Press S or T for

more sound from the left or right speakers. The middle position balances the sound between the left and right speakers.

Fade – Press y or z for more sound from the front or rear speakers. The middle position balances the sound between the front and rear speakers.

DSP Modes:

If equipped with Bose Studio Surround

sound system, it will

have four DSP modes including:

‐ Normal: Adjusts the audio to

provide the best sound for all seating positions.

‐ Driver: Adjusts the audio to

provide the best sound for the driver.

‐ Rear: Adjusts the audio to

provide the best sound for the rear seat occupants.

‐ Centrepoint: Creates the best

surround sound for the whole vehicle.

Auto Volume: If equipped, this feature adjusts the volume based on vehicle speed. The options are Off, Low, Medium - Low, Medium,

Medium - High, or High. Press

[

Back to go back to the previous menu.

Bose AudioPilot Noise Compensation Technology:

If equipped, this feature adjusts the volume based on the noise in the vehicle. When turned on, AudioPilot detects noise and vehicle speed to continuously adjust the audio signal so that music will sound the same at a set volume level. This feature is most effective at lower radio volume settings where background noise can affect how well the music is being played. See www.bose.com/ audiopilot. This feature can be

turned on or off. Press

[ Back to go

back to the previous menu.

Page 13

Black plate (12,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

12 Infotainment System

EQ (Equaliser): If equipped with a

Bose Sound System, the available choices are Manual and Talk.

Update Station List: For AM, FM, and DAB only, press to update the

station list. Press

[ Back to go back

to the previous menu.

Tag Song: Press to bookmark a song on an Apple

device for later

purchase using iTunes

Timeshift: Timeshift is the recording of a radio station for up to 25 minutes. See “Timeshifting” later in this section.

Finding a Station

Seeking a Station

Press t or u to search for the

previous or next strongest station.

Tuning a Station

Press the SEEK screen button to switch to TUNE. Press again to

change back. Press

t or u to

manually search for a station.

Storing Radio Station Presets

Favourites are stored in the area at the bottom of the screen.

Up to 60 preset stations can be stored under the following:

AM, FM, DAB Stations: Press and hold a favourite button to save the current station as a favourite. Press a favourite button to recall a favourite station.

Mixed-Audio Favourites

Favourites that can be stored include radio stations, applications, contacts, tone settings, artists, songs, albums, podcasts, etc

To scroll through the favourites:

Drag up along the top of the favourites. To close the favourites, drag them down.

Slide a finger to the right or left to scroll through each page of

favourites. A

V indicates which

page is being viewed.

Tone Settings: While viewing the tone settings and lifting up the favourite buttons, press and hold to store a tone setting. Press a screen button in the favourite area to recall a favourite tone setting.

The number of favourites displayed is automatically adjusted by default, but can be manually adjusted in the Settings menu under Radio and then Manage Favourites.

Page 14

Black plate (13,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 13

Radio Data System (RDS)

The audio system has an RDS. RDS features are available for use only on FM and DAB stations that broadcast RDS information. With RDS, the radio can:

Seek to stations broadcasting the selected type of programming

Receive announcements concerning local and national emergencies

Display messages from radio stations

This system relies on receiving specific information from these stations and only works when the information is available. In rare cases, a radio station may broadcast incorrect information that causes the radio features to work improperly. If this happens, contact the radio station.

The RDS is always on. When information is broadcast from the current FM station, the station name

or call letters display on the audio screen. RDS may provide a program type (PTY) for current programming and the name of the program being broadcast.

When RDS signal information has been detected, the metadata fields will be updated on the screen display to show the RDS data. The radio text will be updated any time new information is received.

The RDS fields on the screen will show in the order of:

Frequency and /or RDS-PSN.

RDS text line one is the information provided by the broadcast.

RDS text line two and three is RDS text. Line three is used only if necessary, to wrap over from the text on line two.

If the RDS text information overflows from line two and three, the previous information given on line two and three will clear. The overflow of information will finish

starting from the previously used line two and then if necessary, line three.

If an RDS text update occurs during the paging, the display fields are cleared and the new information is displayed, beginning on line two.

Once the entire broadcast text is finished paging, the amount of text that can fit in lines two and three will be displayed and an ellipsis will indicate further text exists.

RDS Traffic Volume Setting

Traffic alert volume can be adjusted by turning the volume up or down while the alert is playing. The system will store this setting for future traffic alerts.

If the current source is playing at a higher volume than the traffic alert volume setting, the traffic alert will play back at the current source volume setting. If the current source is playing at a lower volume than

Page 15

Black plate (14,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

14 Infotainment System

the traffic alert volume setting, the traffic alert will play at the volume set for traffic.

Once an alert is complete, the system volume returns to its previously set level prior to the traffic alert.

If the traffic alert volume is set to zero during an alert, the next traffic alert will play at the minimum connection volume level.

If stations or sources are switched during a traffic alert, the current traffic alert will be cancelled.

If the RDS On/Off option is set to Off, and the Traffic Program (TP) is set to On, a traffic alert will automatically override the Off setting and place the RDS mode to On.

The default station list is sorted by RDS stations first, in order of signal strength, and followed by non-RDS stations grouped at the end of the list.

Stations that support traffic programming are marked TP and show on the right side of the line item.

Timeshifting (If Equipped)

The audio system can record live radio for up to 25 minutes. When tuned to a station, the system automatically begins recording the audio along with the associated metadata. Timeshift must be turned on in the menu before recording can take place.

Press

j to pause playback of the

audio and to initiate timeshift mode. Press

r to resume playback of the

live audio.

When timeshifting begins, a time is indicated on the right of the play/ pause indicator. This time initially indicates the time of day at which playback is paused. This time continues to show as long as the system is in a paused mode and the buffer continues to fill.

Buffer Reset

The buffer will reset anytime the broadcast band or stations/channels are changed. Changing to a media source while in pause mode will not reset the buffer.

Rewinding or Fast Forwarding a Timeshifted Broadcast

Press and hold the t indicator

to reverse playback at a rate of 15 times the rate of normal playback.

Press and hold the u indicator

to advance playback at a rate of 15 times the rate of normal playback. The timeshift buffer

Page 16

Black plate (15,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 15

can be advanced up to the end of the timeshift buffer and return to live mode.

Returning to Live Broadcast

If listening to timeshifted radio, press the LIVE button to return to live radio.

Timeshifting and Station/Channel Lists

If browsing a station/channel list is started while listening to the timeshift content, the list content is shown in live time, not buffered time.

Skipping Back in a Broadcast

For programs with metadata, pressing the previous button less than five seconds into a program will make the system skip to the beginning of the previous program. If more than five seconds into the current song/program, the system starts at the beginning of the current program. If no metadata is available, the system skips back 30 seconds.

Reaching the End of the Buffer

If the audio is paused and the 25 minute buffer is reached, the buffer continues recording the latest content and will erase the oldest content. When playback is started, the content played will be the last 25 minutes in the buffer.

Radio Reception

Unplug electronic devices from the accessory power outlets if there is interference or static in the radio.

FM signals only extend about 16 to 65 km (10 to 40 mi). Although the radio has a built-in electronic circuit that automatically works to reduce interference, some static can occur, especially around tall buildings or hills, causing the sound to fade in and out.

The range for most AM stations is greater than for FM, especially at night. The longer range can cause station frequencies to interfere with each other. Static can also occur when things like storms and power lines interfere with radio reception. When this happens, try reducing the treble on the radio.

Mobile Phone Usage

Mobile phone usage, such as making or receiving phone calls, charging, or just having the phone on may cause static interference in the radio. Unplug the phone or turn it off if this happens.

Backglass Aerial

The AM-FM aerial is integrated with the rear window demister in the rear window. Do not scratch the inside surface or damage the lines in the glass. If the inside surface is damaged, it could interfere with radio reception. For proper radio

Page 17

Black plate (16,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

16 Infotainment System

reception, the aerial connector needs to be properly attached to the post on the glass.

If attaching a mobile phone aerial to the glass, attach it between the grid lines.

{

Caution

Using a razor blade or sharp object to clear the inside rear window can damage the rear window aerial and/or the rear window defogger. Repairs would not be covered by the vehicle warranty. Do not clear the inside rear window with sharp objects.

{

Caution

Do not apply aftermarket glass tinting with metallic film. The metallic film in some tinting materials will interfere with or

(Continued)

Caution (Continue d)

distort the incoming radio reception. Any damage caused to the backglass aerial due to metallic tinting materials will not be covered by the vehicle warranty.

Multi-Band Aerial

The roof aerial is for the GPS (Global Positioning System). Keep clear of obstructions for clear reception. If the vehicle has a sunroof, and it is open, reception can also be affected.

Audio Players

CD Player

If equipped, the player can be used for CD and MP3 audio.

The system is capable of playing:

Most audio CDs

CD-R

CD-RW

MP3 or unprotected WMA formats

When playing any compatible recordable disc, the sound quality can be reduced due to disc quality, the method of recording, the quality of the music that has been recorded, or the way the disc has been handled.

There can be increased skipping, difficulty in finding tracks, and/or difficulty in loading and ejecting. If these problems occur, check the disc for damage or try a known good disc.

Page 18

Black plate (17,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 17

To avoid damage to the CD player:

Do not use scratched or damaged discs.

Do not apply labels to discs. The labels could get caught in the player.

Insert only one disc at a time.

Keep the loading slot free of foreign materials, liquids, and debris.

Use a marking pen to label the top of the disc.

Loading and Ejecting Discs

To load a disc:

1. Turn the vehicle on.

2. Insert a disc into the slot, label side up. The player pulls it in the rest of the way. If the disc is damaged or improperly loaded, there is an error and the disc ejects.

Press

X to eject a disc from the

CD player. If the disc is not removed within a short period of time, it is automatically pulled back into the player.

Playing an Audio MP3 or CD

Press the MEDIA screen button until CD Audio icon Now Playing view is selected.

On the CD main page, a track number displays at the beginning of each track. Song, Artist, and Album information displays when available.

Use the following controls to play the disc:

t (Previous/Fast Reverse):

Press to seek to the beginning of the current or previous track. If the track has been playing for less than five seconds, it seeks to the previous track. If longer than five seconds, the current track starts from the beginning.

Press and hold to fast reverse through a track. Release the button to return to playing speed. Elapsed time displays.

u (Next/Fast Forward):

Press to seek to the next track.

Press and hold to fast forward through a track. Release the button to return to playing speed. Elapsed time displays.

When a Blu-ray

or DVD disc, if equipped, is loaded and the CD button is pressed, a message displays. Go to video application to play DVD/BD.

Page 19

Black plate (18,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

18 Infotainment System

Error Messages

If Disc Error displays and/or the disc comes out, it could be for one of the following reasons:

The disc has an invalid or unknown format.

The road is very rough. Try the disc again when the road is smoother.

The disc is dirty, scratched, wet or upside down.

The air is very humid. Try the disc again later.

There was a problem while burning the disc.

The label is caught in the CD player.

If Disc Player Error displays, it could be for one of the following reasons:

The player temperature is too high.

There are load or eject errors.

If the CD is not playing correctly, for any other reason, try a known good CD.

If any error continues, contact your dealer.

CD Menu

Press the MENU button while that source is active to access the menu.

Press any of the following buttons on the CD Menu:

Shuffle: Press to play the tracks randomly. Press again to stop shuffle.

Auto Volume: If equipped, this feature adjusts the volume based on the speed of the vehicle. See AM-FM Radio on page 11.

Tone Settings: Press + or − to adjust Bass, Midrange, Treble, or Surround. See AM-FM Radio on page 11.

MP3 Guidelines

Sampling rate: 16 kHz, 22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz, and 48 kHz.

Bit rates supported: 8, 16, 24, 32, 40, 48, 56, 64, 80, 96, 112, 128, 144, 160, 192, 224, 256, and 320 kbps.

Recorded on a CD-R or CD-RW.

MP3 Folder Information

Press anywhere between the top applications tray or the bottom menu to display the browse screen.

Root Directory: To access, press the screen anywhere in the central area of the screen. The root directory is treated as a folder. All files contained directly under the root directory are accessed prior to any root directory folders.

No Folder: When the CD only contains compressed audio files without any folders or playlists, all files are under the root folder.

Page 20

Black plate (19,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 19

File System and Naming: The

song titles, artists, albums, and genres are taken from the file's ID3 tag and are only displayed if present in the tag. If a song title is not present in the ID3 tag, the radio displays the file name as the track name.

USB Port

Audio from videos stored on USB devices may be listened to while the vehicle is in a forward gear. Videos can be watched while the vehicle is in P (Park). Use play/pause or next/ previous to control the video or touch in the browse to display a list of the current video filters.

This vehicle may have three USB ports. There may be one USB port in the centre console, one USB port in the storage behind the climate control system, and if equipped with Rear Seat Entertainment (RSE), one USB port in the rear media console storage area.

Playing from a USB

A USB mass storage device can be connected to the USB port.

Audio extensions supported by the USB are:

MP3

WMA

AAC

OGG

AIFF

3GPP

Gracenote

When plugging in a USB device, Gracenote service builds voice tags for music. Voice tags allow artists, albums with hard to pronounce names, and nicknames to be used to play music through voice recognition.

While indexing, infotainment features are available.

My Media Library

The infotainment system allows access to content from all of the connected devices. Press the MEDIA screen button to scroll through the options until My Media is selected. Press anywhere in the central area of the screen to browse the content.

USB MP3 Player and USB Drives

The USB MP3 players and USB drives connected must comply with the USB Mass Storage Class specification (USB MSC).

To play a USB device:

1. Connect the USB.

2. Press MEDIA until the

connected device is shown.

Use the following when playing an active USB source:

r (Play): Press to play the current

media source.

j (Pause): Press to pause play of

the current media source.

Page 21

Black plate (20,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

20 Infotainment System

t (Previous/Reverse):

Press to seek to the beginning of the current or previous track. If the track has been playing for less than five seconds, the previous track plays. If playing longer than five seconds, the current track restarts.

Press and hold to reverse quickly through playback. Release to return to playing speed. Elapsed time displays.

u (Next/Fast Forward):

Press to seek to the next track.

Press and hold to advance quickly through playback. Release to return to playing speed. Elapsed time displays.

USB Menu

Press Menu to display the USB menu. The following may be available:

Shuffle: Press to play the tracks randomly. Press again to stop shuffle.

Bose AudioPilot: If equipped, press to turn Bose AudioPilot on or off. AudioPilot is an On/Off selection on the list entry from the Main menu. See AM-FM Radio on page 11.

Tone Settings: Press + or − to adjust Bass, Midrange, Treble, or Surround. See AM-FM Radio on page 11.

USB Browse Menu

Press the browse screen button to view the browse menu and the following options are displayed along the bottom of the screen:

Playlists:

Supported Playlist extensions are: m3u, pls, wpl, asx, b4s, and xspf.

1. Press to view the playlists stored on the USB.

2. Select a playlist to view the list of all songs in that playlist.

3. Select a song from the list to begin playback.

Artists:

1. Press to view the list of artists stored on the USB.

2. Select an artist name to view a list of all albums by the artist.

3. To select a song, press All Songs or press an album and then select a song from the list.

Albums:

1. Press to view the albums on the USB.

2. Select the album to view a list of all songs on the album.

3. Select a song from the list to begin playback.

Songs:

1. Press to display a list of all songs on the USB.

2. To begin playback, select a song from the list.

Genres:

1. Press to view the genres on the USB.

Page 22

Black plate (21,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 21

2. Select a genre to view a list of artists.

3. Select an artist to view albums by that artist.

4. Select an album to view songs on the album

5. Select a song to start playback.

Podcasts, Composers, Audiobooks, Videos, and Folder View are shown when More is selected from the bottom of the screen.

Podcasts:

1. Press to view the podcasts on the USB.

2. Select podcast to get a list of podcast episodes.

Composers:

1. Press to view the composers on the USB.

2. Select Composer to view a list of albums by that composer. Select an album or all songs to view a list of songs.

3. Select a song from the list to begin playback.

Audiobooks:

1. Press to view the audiobooks stored on the device. Select an audiobook to get a list of chapters.

2. Select the chapter from the list to begin playback.

Folder View:

1. Press to view the directories on the USB/SD card.

2. Select a folder to view a list of all files.

3. Select a file from the list to begin playback.

File System and Naming

File systems supported by the USB are:

FAT32

NTFS

HFS+

The songs, artists, albums, and genres are taken from the file's song information and are only displayed if present. The radio displays the file name as the track name if the song information is not available.

Supported Apple

Devices

The following Apple devices are supported:

iPod touch®(5th generation)

iPod touch (4th generation)

iPod touch (3rd generation)

iPod touch (2nd generation)

iPod touch (1st generation)

iPod nano®(7th generation)

iPod nano (6th generation)

iPod nano (5th generation)

iPod nano (4th generation)

iPod nano (3rd generation)

iPod nano (2nd generation)

iPod nano (1st generation)

iPod classic

Page 23

Black plate (22,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

22 Infotainment System

iPod®with video

iPhone®5

iPhone 4S

iPhone 4G

iPhone 3GS

iPhone 3G

iPhone

iPad

Loss of Audio

Do not play music through Bluetooth of an iPhone that is connected by USB. If an attempt to pair the Bluetooth of the same connected phone is made, the system will automatically mute the iPhone audio.

If there is a loss of audio, playback can be resumed by changing the audio flow from Bluetooth to USB cable.

To change the audio flow:

1. While the iPhone is connected, double tap the phone's home button.

2. Swipe a finger to the left on the phone's screen display. A box with a triangle on the lower line of the box that is highlighted displays. Press this box to display the dock connector option.

3. Select "Dock Connector."

Other phones such as the Android™ phones may have a similar reaction.

Storing and Recalling Media Favourites

To store media favourites, press and hold an open favourite during media playback to display a list of media types. Select from this list.

The media types that may display are:

Genres: Press to store the current genre as a favourite. Press a screen button in the favourite area to recall a favourite genre. The first song of the genre begins to play.

Artists: Press to store the current artist as a favourite. Press a screen button in the favourite area to recall a favourite artist. The first song in the artist list begins to play.

Albums: Press to store the current album as a favourite. Press a screen button in the favourite area to recall a favourite album. The first song in the album list begins to play.

Playlists: Press to store the current playlist as a favourite. Press a screen button in the favourite area to recall a favourite playlist. The first song in the playlist begins to play.

Songs: Press to store the current song as a favourite. Press a screen button in the favourite area to recall a favourite song.

Podcasts or Podcast Episode:

Press and hold a screen button to store the current podcast as a favourite. Press a screen button in the favourite area to recall a favourite podcast or podcast episode. The podcast or podcast episode begins to play.

Page 24

Black plate (23,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 23

Audiobooks: Press and hold a

screen button to save the current audiobook as a favourite. Press a screen button in the favourite area to recall a favourite audiobook; the first chapter in the audiobook begins to play.

Videos: Press and hold a screen button to store the current video as a favourite. Press a screen button in the favourite area to recall a favourite video; the first episode in the video begins to play.

SD Card Reader

This vehicle may have two SD card readers: one in the centre console and one in the rear HVAC area, if equipped with Rear Seat Entertainment (RSE).

The SD card reader is for audio and video playback. Playback from an SD card follows the same file formats and restrictions defined under the USB section. See USB Port on page 19.

Set up the SD card while the vehicle is in P (Park). See “Audio” under Infotainment on page 3.

Place the card into the port.

If an SD card has already been connected, but a different source is currently active, press the MEDIA screen button to scroll through the audio source screens until SD card displays.

Auxiliary Jack

This vehicle has an auxiliary input jack in the centre console under the armrest and in the rear media console if equipped with Rear Seat Entertainment (RSE). Possible auxiliary audio sources include:

Laptop computer

Audio music player

This jack is not an audio output. Do not plug headphones into the auxiliary input jack. Set up an auxiliary device while the vehicle is in P (Park).

Connect a 3.5 mm (1/8 in) cable from the auxiliary device to the auxiliary input jack. When a device is connected, the system can play audio from the device over the vehicle speakers.

If an auxiliary device has already been connected, but a different source is currently active, press the MEDIA screen button to scroll through audio source screens, until AUX Input source screen displays.

Bluetooth Audio

If equipped, music may be played from a paired Bluetooth device. See

Bluetooth (Overview) on page 91 or Bluetooth (Infotainment Controls) on page 92 or Bluetooth (Voice Recognition) on page 96 for help

pairing a device.

The music can be controlled by either the infotainment controls, or the controls on the device.

Music can be launched by pressing the MEDIA screen button on the Home Page.

Page 25

Black plate (24,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

24 Infotainment System

To play music via Bluetooth:

1. Power on the device, and pair to connect the device.

2. Once paired, go into the audio application from the Home Page or via the applications tray. Select MEDIA until Bluetooth displays.

Bluetooth Audio Menu

Press the MENU screen button to display the Bluetooth Audio menu. The following may be available:

Bose AudioPilot: If equipped, press to turn Bose AudioPilot on or off. AudioPilot is an On/Off selection on the list entry from the Main menu. See AM-FM Radio on page 11.

Tone Settings: Press + or − to adjust Bass, Midrange, Treble, or Surround. See AM-FM Radio on page 11.

Press

[ Back to go back to the

previous menu.

Manage Bluetooth Devices: Press to go to the Bluetooth page to add or delete devices or pair.

When selecting Bluetooth audio, the radio may not be able to launch the audio player on the connected device to start playing. When the vehicle is not moving, use the phone to begin playback.

All devices launch audio differently. When selecting Bluetooth audio as a source, the radio may show as paused on the screen. Press play

on the device or press

r on screen

to begin playback.

Some phones support sending Bluetooth music information to display on the radio. When the radio receives this information, it will check to see if any is available and display it. For more information about supported Bluetooth features, see www.gm.com/bluetooth.

Rear Seat Infotainment

Rear Seat Entertainment (RSE) System

The vehicle may have an RSE system. The RSE system includes Blu-ray/DVD/CD player, USB (if equipped), SD card reader (if equipped), audio/video jacks, wired headphone jack, wireless headphones (if equipped), and remote control.

Before Driving

The RSE can only be viewed on the front screen when the vehicle is in P (Park). The driver cannot safely view the video screen while driving.

In severe or extreme weather conditions, the RSE system may not work until the temperature is within the operating range of above −20°C (−4°F) and below 55°C (131°F).

Page 26

Black plate (25,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 25

System Operation

The video screens are on the back of the driver and front passenger seats, or overhead in the second or third row (if equipped).

Rear Seat Screens (as equipped)

1. IR Lens

2. Release Button

To use:

1. Press the release button on the seat back console or in front of the overhead screen. Do not pull on the sides of the screen.

2. Move the screen to the viewing position. The remote must be removed from the storage location to be used.

{

Caution

When storing the remote, place it in the storage area with buttons facing towards you or damage to the screen could occur.

3. Opening a screen will turn the system on. If the screens are open with the system off, press

the power button on the remote to turn the system on. The system can also be turned on from the front infotainment system by pressing the Video icon on the Home Page.

Push the video screen into its locked position when it is not in use. The screen turns off automatically.

The audio may continue with the screens down. This allows listening to music without the screen on. To turn the audio off, press the power button on the remote or on the front infotainment Video page.

{

Caution

Avoid directly touching the video screen, as damage may occur.

Sources

Sources, if equipped, include AM, FM, BD, AUX, Photos, CD/DVD/ Blu-ray, USB, and SD card.

Page 27

Black plate (26,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

26 Infotainment System

Menus and Features

AM/FM Menu

Press the RADIO button on the remote, then select AM or FM.

Access the AM or FM menu by pressing any menu button in any AM or FM screen.

Use this menu to select Strong Stations, All Stations, Favourites, Categories, Headphones, DivX

VOD, or Software Information.

Only one tuner source may be active at any one time.

Disc Menu BD

Press MEDIA on the remote control and then select CD/DVD/BD, USB, SD, AUX, or Photo Viewer.

Press MENU on the remote control once to display menus based on the media.

Choose from POP-UP MENU (BD Only), TOP MENU, COLOUR, KEYPAD, DISC CONTROL, and MORE (SETTINGS, PREVIOUS, NEXT, STILLS OFF).

To close, press the MENU button or

4 (Back) button, or wait for the

time out.

Disc Menu DVD

Press MENU on the remote control once to select from TOP MENU, KEYPAD, STOP DISC, PHOTO, and SETTINGS.

To close, press MENU or

4 (Back),

or wait for the time out.

CD Menu

Select from:

Track List

Shuffle

Disc Information (if available)

Headphones

Brightness

Page 28

Black plate (27,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 27

Player Setup: Audio Compression, Auto Enter (if available)

DivX VOD

Title Search (if available)

Software Information

Pop-Up Menu (BD Only)

Select POP-UP MENU from the menu options to display the disc menu on top of the movie. Make a selection to exit the Pop-up menu. When the Pop-up menu is opened, the overlay/Interaction Selector menu will be closed. The Pop-up menu is disc dependent and may or may not time out on its own.

Top Menu BD/DVD

Select this item to display the menu for the DVD or BD. Make a selection to exit the TOP MENU. TOP MENU is not available for BDAV, DVD-VR, and AVC-REC.

Colour (BD Only)

Select COLOUR to display the four colour button options: blue, yellow, red, and green. Highlight a colour option and press ENTER and the appropriate action will be carried out. Press the Back button or MENU button, or wait for the 15-second time out to close the menu. Press the down arrow on the yellow colour to keep the overlay menu up, but close the colour menu. The colour menu is disc dependent; selecting colours for discs that do not support this feature will have no function.

Keypad BD/DVD

Press KEYPAD to display the single digit entry keypad. To close the keypad, press the Back button or MENU button, wait for the menu to time out, or press the down arrow from the Exit or Done buttons to keep the menu up but close the keypad. The keypad is disc dependent; selecting numbers for discs that do not support this feature will have no function.

The keypad input is limited to four digits. Any digits entered beyond four will be discarded.

Page 29

Black plate (28,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

28 Infotainment System

Press the Clear button to clear one digit at a time. Press and hold the Clear button to clear all entered digits.

Disc Control (BDAV and BDMV Only)

Press DISC CONTROL to display options for subtitles, play, pause, track forward, track previous, and stop the disc. Press the Back button or MENU button, or wait for the time out to close the menu. Press the down arrow from Stop, Play, or Next to keep the overlay menu up, but close the disc control menu. The disc control menu is disc

dependent; selecting controls for discs that do not support this feature will have no function.

Stop Disc (DVD Only)

Select to close the overlay menu. Press Menu on the screen to open the Disc Stopped menu.

Select from:

Resume Playback: Returns to the current position on the disc and resumes play.

Title Search (if available)

Restart Disc

Screen Mode

Headphones

Brightness

Player Setup: Audio Compression, Auto Enter (if available)

DivX VOD

Software Information

Not all options are available while the disc is playing.

Browse Media (AVCREC, BDAV, DVD-A, and DVD-VR only): Allows the media on the disc to be searched in a list format.

More BD/DVD

The MORE sub-menu includes both the SETTINGS item and items related to still pictures.

Prev Still/Next Still/Stills Off

This feature allows for turning still off, going to the previous still, or advancing to the next still picture. PREV STILL will go back to the previous picture. NEXT STILL will advance to the next picture in sequential order. STILLS OFF will return to the designated home still,

Page 30

Black plate (29,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 29

if it is available. Press the Back button or MENU button, or wait for the 15-second time out to close the menu. Press the down arrow on the bottom option to close the next still pop-up. The menu will remain up. This feature is disc dependent.

This feature can also be accessed from the Photo button on the DVD Disc Menu depending on the disc.

Settings BD/DVD

Select to access:

Browse Media (BDAV, AVCREC, DVD-A, DVD-VR Only): Allows browsing by Video List or Playlist.

Title Search (AVCHD, DVD-V, BDMV Only): This allows the titles provided by the disc to be searched. Select this option to bring up a keypad to search for specific titles.

Restart Disc: Restarts the disc from the beginning.

Disc Information (if available)

Audio Tracks

Subtitles

Angle (BDMV, DVD-V, DVD-A Only): Select an angle by using the up and down arrows to highlight the option, and then press ENTER or the right arrow.

Screen Mode: Use Screen Mode to adjust the framing on the RSE display. Select Normal, Wide, or Zoom. Screen Mode only applies to video sources and should be maintained if the disc is ejected.

Headphones: Use Headphones to listen to audio on the wired headphones. The headphone

audio plays depending on which screen is selected. The default is screen 1 audio.

Brightness: Increase the brightness by using the up or right arrow and decrease the brightness by using the down or left arrow. Each screen brightness can be adjusted separately.

Player Setup: See “Player Setup” later in this section.

DivX VOD

Software Information

Player Setup BD/DVD

Page 31

Black plate (30,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

30 Infotainment System

Player Setup may include the following options:

Default Menu Language: With no disc inserted, select from a list of languages or enter a language code.

Default Audio Language: With no disc inserted, select from a list of languages or enter a language code.

Default Subtitle Language: With no disc inserted, select from a list of languages or enter a language code.

Audio Compression: When on, the RSE will attempt to reduce the difference between the audio highs and lows.

Pseudo Resume: When on, the RSE will attempt to resume play of the video where it left off. This can be turned on or off.

Auto Enter: When on, the RSE will attempt to start playing the video when the disc is inserted.

This feature can be turned on or off. Not all discs support this feature.

Audio Channel (AVCREC, DBAV, DVD-VR Only) contains: Stereo, Left Mono, and Right Mono. Audio Channel is available from the Settings menu. Default will be determined by the disc.

Format Internal User Memory: Only shown when no disc is inserted.

Enter Language Code

Enter the desired language code.

Language/Code User

Code

Japanese JPN 7465

English ENG 6978

French FRA 7082

German DEU 6869

Italian ITA 7384

Spanish SPA 6983

Dutch NLD 7876

Russian RUS 8285

Chinese ZHO 9072

Korean KOR 7579

Greek ELL 6976

Afar AAR 6565

Abkhazian ABK 6566

Afrikaans AFR 6570

Amharic AMH 6577

Arabic ARA 6582

Assamase ASM 6583

Aymara AYM 6589

Azerbaijani AZE 6590

Bashkir BAK 6665

Byelorussian BEL 6669

Bulgarian BUL 6671

Bihari BIH 6672

Bislama BIS 6673

Bengali BEN 6678

Page 32

Black plate (31,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 31

Tibetan BOD 6679

Breton BRE 6682

Catalan CAT 6765

Corsican COS 6779

Czech CES 6783

Welsh CYM 6789

Danish DAN 6865

Bhutani DZO 6890

Esperanto EPO 6979

Estonian EST 6984

Basque EUS 6985

Persian FAS 7065

Finnish FIN 7073

Fiji FIJ 7074

Faroese FAO 7079

Friesian FRY 7089

Irish GLE 7165

Scots-Gaelic GLA 7168

Galician GLG 7176

Guarani GRN 7178

Gujarati GUJ 7185

Hausa HAU 7265

Hindi HIN 7273

Croatian HRV 7282

Hungarian HUN 7285

Armenian HYE 7289

Interlingua INA 7365

Interlingue ILE 7369

Inupiak IPK 7375

Indonesian IND 7368

Icelandic ISL 7383

Hebrew HEB 7269

Yiddish YID 8973

Javanese JAV 7487

Georgian KAT 7565

Kazakh KAZ 7575

Greenlandic KAL 7576

Cambodian KHM 7577

Kannada KAN 7578

Kashmiri KAS 7583

Kurdish KUR 7585

Kirghiz KIR 7589

Latin LAT 7665

Lingala LIN 7678

Laothian LAO 7679

Lithuanian LIT 7684

Latvian LAV 7686

Malagasy MLG 7771

Maori MRI 7773

Macedonian MKD 7775

Malayalam MAL 7776

Mongolian MON 7778

Moldavian MOL 7779

Marathi MAR 7782

Malay MSA 7783

Maltese MLT 7784

Burmese MYA 7789

Page 33

Black plate (32,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

32 Infotainment System

Nauru NAU 7865

Nepali NEP 7869

Norwegian NOR 7879

Occtian OCI 7967

Oromo ORM 7977

Oriya ORI 7982

Panjabi PAN 8065

Polish POL 8076

Pashto, Pushto PUS 8083

Portuguese POR 8084

Quechua QUE 8185

Rhaeto-Romance ROH 8277

Kirundi RUN 8278

Romanian RON 8279

Kinyarwanda KIN 8287

SanSkrit SAN 8365

Sindhi SND 8368

Sangho SAG 8371

Serbo-Croatian SCR 8372

Singhalese SIN 8373

Slovak SLK 8375

Uzbek UZB 8590

Vietnamese VIE 8673

Volapuk VOL 8679

Wolof WOL 8779

Xhosa XHO 8872

Yoruba YOR 8979

Zulu ZUL 9085

Slovenian SLV 8376

Samoan SMO 8377

Shona SNA 8378

Somali SOM 8379

Albanian SQI 8381

Serbian SRP 8382

Siswaiti SSW 8383

Sesotho SOT 8384

Sundanese SUN 8385

Swedish SWE 8386

Swahili SWA 8387

Tamil TAM 8465

Telugu TEL 8469

Tajik TGK 8471

Thai THA 8472

Tigrinya TIR 8473

Turkmen TUK 8475

Tagalog TGL 8476

Setswana TSN 8478

Tonga TON 8479

Turkish TUR 8482

Tsonga TSO 8483

Tatar TAT 8484

Twi TWI 8487

Ukrainian UKR 8575

Urdu URD 8582

Page 34

Black plate (33,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 33

Errors

Errors can occur if the local storage area has been broken or if the ignition is turned off during formatting. If the screen is closed during formatting, this will not interrupt the formatting. If the screen is opened again, the current state of format will be displayed. If an error occurs, the Error screen will display when the ignition is turned on.

Wired Headphones

To select the headphone audio for the wired headphone jack based on screen 1 or screen 2, press ENTER or the right arrow on the remote. Press the Back button to exit the menu.

The headphones are linked to screen 1 by default.

Player Setup (CD-DA Only)

This allows access to Audio Compression and Auto Enter.

Title Search (CD-DA Only)

This displays a keypad. Press Stop to close the overlay menu and open the Disc Stopped screen. Press Menu on the screen to open the Disc Stopped menu. Select Title Search.

Disc Information (CD-DA Only)

If the inserted disc is a BDMV, BDAV, AVCHD, AVCREC, DVD-Video, or DVD-VR, the disc title should display. If the inserted disc is DVD-Audio, DTS-CD, CDDA, or Mixed-CD, the track number will display.

DivX

This indicates the vehicle is registered to play DivX media and states how to obtain more information.

Software Information

This allows access to Version Information, Save Vehicle Info to USB, and View Open Source.

Save Vehicle Info to USB allows the current version to be saved to a jump drive, which must be done before an update can be performed.

View Open Source indicates where software information can be found.

Changing Between SCREEN 1 and SCREEN 2

For single overhead screen systems only:

Although two audio sources can be listened to at one time, only one video source can be viewed on the overhead screen at a time.

Press the SCREEN 1 or SCREEN 2 button on the remote control to change between which source will display on the overhead screen.

When SCREEN 1 is being displayed and the SCREEN 2 button on the remote is pressed, the source for SCREEN 2 will be displayed. The audio for SCREEN 1 is available on channel 1 of the headphones and the audio for SCREEN 2 is available on channel 2 of the headphones.

Page 35

Black plate (34,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

34 Infotainment System

Change the channel on the headphones to the desired screen source.

One user can listen to the audio from SCREEN 1 and view the source on the overhead display while another user can listen to a separate audio source by changing the channel on the wireless headphones or setting their wired headphones to SCREEN 2 in the MENU.

RSE Controls Available from the Front Screen

To access the RSE application, select Video from the HOME screen. The Video app may also be selected from the applications tray if it has been stored in one of the five locations.

Sourcing to DVD/BD

After a disc is inserted, it will automatically begin playing on both rear screens. If no video disc is inserted or if the disc is ejected

while it is sourced to DVD/BD, the screen will display “No Video Disc Inserted.”

With the vehicle in P (Park), BD/ DVD can be watched on the front screen. The following icons will appear along the bottom of the front screen when a DVD, VCD, USB, SD, or AUX is inserted:

The following appears when a BD is sourced:

Rear Media

REAR MEDIA will allow transitioning between Disc, USB, SD, and AUX sources for the rear screens. Sources selected using the REAR MEDIA button will automatically be sourced for both rear screens and begin playback from the first available file.

The video will only appear on the front screen with the vehicle in P (Park). When the vehicle is in any other gear, the front screen displays the active media source.

DVD/BD Disc Menu

With the vehicle in P (Park), press to access the DVD/BD disc menu. Make a selection to exit the disc menu.

Next Track/Previous Track

Use

u to skip ahead, or t to skip

back between chapters. Press

less than 10 seconds into the current track to start at the beginning of the previous track.

Page 36

Black plate (35,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 35

Press t more than five seconds

into the current track to start at the beginning of the current track.

Fast Forward/Fast Rewind

With the vehicle in P (Park), hold

or t for approximately one and

one-half seconds to fast forward or fast rewind at a rate of eight times

normal playback speed. If

u or t

are held for approximately six seconds, the rate of fast forward or fast rewind will increase.

Play/Pause

Press

r to play or j to pause,

depending on the current selection.

Keypad for DVD/VCD/SD/USB

With the vehicle in P (Park), press to display the DVD keypad. DVD keypad functionality is disc dependent and may not be available on all DVDs. Up to four digits can be entered. Press Clear to remove

one digit in the entry field. Press and hold Clear to remove all digits in the entry field.

Pop-Up Menu (BD Only)

This displays the pop-up menu contents for the BD. Make a selection to exit the pop-up menu view.

Cursor

The cursor is used to navigate and select items in the disc menu. Press the up, down, right, or left arrows, or the ENTER button. The cursor will close after a selection or time out.

Sourcing USB/SD/VCD/AUX with Video

With the vehicle in P (Park), video can be watched on the front screen from devices plugged into the rear pod. The following icons will be available:

These features will function the same as in DVD/BD sources, with the following exceptions:

KEYPAD is only available for VCD in P (Park).

DISC MENU is only available for disc sources such as VCD. The system displays the menu provided by the disc.

Page 37

Black plate (36,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

36 Infotainment System

Sourcing DVD/BD/USB/SD/VCD

With the vehicle in D (Drive), the following icons display along the bottom of the front screen when one of these sources is active:

DVD/BD/USB/SD/VCD: All five buttons are available.

AUX: Only REAR MEDIA and MENU are available.

Rear Media

Use REAR MEDIA to select AUX, Disc, USB, or SD sources for the Rear Seat Entertainment (RSE). When using the REAR MEDIA button to select a source, both rear screens will be sourced and begin playback of the first available file. The video will only display on the front screen if the vehicle is in

P (Park). When the vehicle is in any other gear, the front screen displays the active media source.

Previous Track/Next Track

Press

t or u to select the

previous or next track on the current media.

Play/Pause

Press

r to play or j to pause,

depending on the current selection. A time bar displays when the pause button is pressed.

Menu (DVD/BD/SD/USB/AUX/VCD)

MENU is only available in D (Drive). Press the MENU button to display these menu options:

Tone Settings

Auto Volume Control

Traffic Announcements

Tone Settings (DVD/BD)

Tone settings for bass, mid, and treble are available in any source mode. Once set, tone settings are set for all sources.

Auto Volume Control (DVD/BD)

Automatic Volume Control (AVC) adjusts the volume of the audio based on the speed or ambient noise of the vehicle. Some vehicles may be equipped with the Bose AudioPilot system. In these cases, the Auto Volume main menu item is replaced with the Bose AudioPilot menu item. AVC or Bose AudioPilot is available to use with any source mode.

Traffic Announcements (DVD/BD)

Traffic program alerts will display in the RSE system. The video will continue to play and the audio will mute, depending on the alert.

Page 38

Black plate (37,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 37

Closing the Menu (DVD/BD)

Press the Back or Exit button to close a menu. This will return to the RSE application on the previously viewed screen.

Power

Press the power button on the screen to turn the rear RSE screens on or off. The front screen will continue to operate when the rear screens are turned off. The rear screens can be turned back on by pressing the power button again or from the rear seat by using the remote. Select SCREEN 1 or 2 and press the power button.

Headphones

1. Power Indicator Light

2. Channel 1 or 2 Switch

3. Volume Control

4. Power Button

5. Battery Cover

RSE includes two or four 2-channel wireless headphones depending on the vehicle model. The headphones are used to listen to various multimedia. The wireless headphones have a power button, Channel 1 or 2 switch, and a volume control.

Press the power button to turn on the headphones. A light on the headphones comes on. If the light

does not come on, check the batteries. Intermittent sound or static can also indicate weak batteries. See “Battery Replacement” later in this section.

Turn the headphones off when not in use.

Press the centre of the right side of the headphone to change the channel. Channel 1 will provide audio associated with screen 1 and channel 2 will provide audio associated with screen 2.

Infrared transmitters are on the top of the left seat back video screen or in front of the second overhead screen. The headphones shut off automatically to save the battery power if the RSE system is off or if the headphones are out of range of the transmitters for more than three minutes. Moving too far forward or stepping out of the vehicle can cause the headphones to lose the signal or have static.

Use the volume control on the headphones to adjust the volume.

Page 39

Black plate (38,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

38 Infotainment System

For best audio performance, wear the headphones as indicated with L (Left) and R (Right) on the ear pads. Do not let anything cover the ear pads.

{

Caution

Do not store the headphones in heat or direct sunlight. This could damage the headphones and repairs will not be covered by the warranty. Storage in extreme cold can weaken the batteries. Keep the headphones stored in a cool, dry place.

If the foam ear pads become worn or damaged, the pads can be replaced separately. To purchase replacement ear pads, contact your dealer.

Battery Replacement

To change the batteries:

1. Loosen the screw to the battery door on the left side of the headphones.

2. Slide the battery door open.

3. Replace the two AAA batteries.

4. Replace the battery door and tighten the screw.

Remove the batteries if the headphones will not be used for a long time.

Auxiliary Inputs

Audio/Video (A/V) Jacks

Rear Media Connections (as

equipped)

1. SD Card Reader

2. USB Port

3. A/V Jacks

4. Wired Headphone Jack

5. Volume Control

If equipped with RSE, an SD card reader (1), a USB port (2), A/V input jacks (3), wired headphone jack (4), and a volume control (5) will be inside the rear storage area of the centre console.

Page 40

Black plate (39,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 39

The A/V jacks allow audio or video cables to be connected from an auxiliary device such as a camcorder or video game system.

The A/V jacks are colour coded:

Yellow for video input

White for left audio input

Red for right audio input

Power for the auxiliary devices is not supplied by the infotainment system.

To use the auxiliary inputs of the RSE system:

1. Connect the auxiliary device cables to the A/V jacks.

2. Power on both the auxiliary device and the RSE video screen.

USB/SD

This allows for video and audio playback of supported media.

To use the USB and SD:

1. Insert the device in the appropriate slot.

2. Select the source via the rear screen menu with the remote control MEDIA button.

3. Select the source via the front by pressing on the Video application on the home screen.

Audio Output

Audio from a Blu-ray/DVD/CD player or auxiliary inputs can be heard through:

Wireless headphones

Vehicle speakers

Vehicle wired headphone jack

The RSE system transmits the audio signal to the wireless headphones if an audio signal is available. See “Headphones” earlier in this section.

Wired Headphone Jack

Audio from the wired headphone jack can be heard from the desired source through the MENU button on the remote and by selecting Settings, then Headphones. The headphone audio is selected based on the audio associated with screen 1 or screen 2.

The front seat passengers are able to listen to playback from the A/V jacks through the vehicle speakers by selecting Rear A/V as the source on the radio.

Remote Control

Remote Control Buttons

Page 41

Black plate (40,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

40 Infotainment System

1. 7 (Previous/Reverse)

Radio: Press to seek the previous radio station.

CD: Press to seek the previous track.

Blu-ray/DVD: Press to seek the previous chapter.

Press and hold for fast reverse.

2. MEDIA

Press to scroll through the menus including: CD, AUX, Blu-ray, /DVDSD, USB.

J (Play/Pause)

Press to start playing. Press to pause. Press again to continue playing.

6 (Next/Fast Forward)

Radio: Press to seek the next radio station.

CD: Press to seek the next track.

Blu-ray/DVD: Press to seek the next chapter.

Press and hold to fast forward.

5. SCREEN 1

For dual seat back screens:

Press to select the left screen. Once pressed, all remote control commands will only pertain to screen 1.

For single overhead screens:

Press to change the source displayed on the overhead screen to SCREEN 1 selected source. Select audio sources. Only one video can be played on the screen at a time. Audio for both sources will continue on the headphones. Once pressed, all remote control commands will correspond to SCREEN 1.

For dual overhead screens:

Press to select the second row overhead screen. Once pressed, all remote control commands will correspond to SCREEN 1.

O (Power)

Press to turn the video screens on and off.

7. SCREEN 2

For dual seat back screens:

Press to select the right screen. Once pressed, all remote control commands will only pertain to SCREEN 2.

For single overhead screens:

Press to change the source displayed on the overhead screen to SCREEN 2 selected source. Only one video can be played on the screen at a time. Audio for both sources will continue

Page 42

Black plate (41,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 41

on the headphones. Once pressed, all remote control commands will correspond to SCREEN 2.

For dual overhead screens:

Press to select the optional third row overhead screen. Once pressed, all remote control commands will correspond to SCREEN 2.

o (Previous/Reverse/Decrease)

Radio and CD: Press to go to the previous station or track.

Press to go to the previous menu.

Press to decrease the brightness of the RSE screen.

w (Up Arrow)

Press to scroll up a list.

10.

r / ENTER

Press to select the highlighted choice in any menu.

Press and hold for quick play.

11.

p (Next/Forward/Increase)

Radio and CD: Press to go to the next station or track.

Press to go to the next menu.

Press to increase the brightness of the RSE screen.

12. RADIO

Press to scroll through the radio sources including AM or FM.

13. MENU

Press to go to the menu of the now playing screen.

14.

4 (Back)

Press to go back to the previous menu.

Press and hold to go back to the now playing screen.

15.

x (Down Arrow)

Press to go down a list.

To use the remote control, aim it at the transmitter window at either seat back console or at the second row overhead screen and press the buttons firmly. Direct sunlight or very bright light could affect the ability of the RSE transmitter to receive signals from the remote control. Check the batteries if the remote control does not seem to be working. See “Battery Replacement” later in this section. Objects blocking the line of sight could also affect the function of the remote control.

Page 43

Black plate (42,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

42 Infotainment System

{

Caution

Storing the remote control in a hot area or in direct sunlight can damage it, and the repairs will not be covered by the warranty. Storage in extreme cold can weaken the batteries. Keep the remote control stored in a cool, dry place.

Battery Replacement

To change the remote control batteries:

1. Insert a coin or key to pull up the rear cover on the remote control.

2. Replace the two AAA batteries in the compartment.

3. Replace the battery cover.

Remove the batteries from the remote control if it will not be used for an extended period of time.

RSE Troubleshooting

No power: The ignition might not

be in ON/RUN or ACC/ ACCESSORY.

The picture does not fill the screen. There are black borders on the top and bottom or on both sides or it looks stretched out:

Press the MENU button on the remote control to change the display mode setting.

In auxiliary mode, the picture moves or scrolls: Check the

auxiliary input connections at both devices.

The remote control does not work: Check to make sure the

remote control is programmed to the correct screen. Make sure there is no obstruction between the remote control and the transmitter window and check the batteries to make sure they are not dead or installed incorrectly.

There is no sound from the headphones with the indicator light on: If the batteries are good,

make sure the headphones are programmed to the correct screen and on the correct channel for the screen being viewed.

The auxiliary source is running but there is no picture or sound:

Check that the RSE video screen is in the auxiliary source mode by pressing the MEDIA button on the remote control. Check the auxiliary input connections at both devices.

Sometimes the wireless headphone audio cuts out or buzzes: Check for obstructions,

low batteries, reception range, and interference from mobile phone towers or from mobile telephone use in the vehicle. Check that the headphones are on correctly using the L (Left) and R (Right) on the headphones. Check that the headphones are positioned properly with the headband across the top of the head.

Page 44

Black plate (43,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 43

I lost the remote and/or the headphones: See your dealer for

assistance.

The Blu-ray/DVD is playing, but there is no picture or sound:

Check that the RSE video screen is sourced to the Blu-ray/DVD player by pressing the MEDIA button on the remote control.

Video Display Error Messages

The video screen may display one of the following:

Disc Error: There are disc load or eject problems, the disc is inserted with the disc label wrong side up, the disc is damaged, or the disc is not from the correct region.

No Disc Inserted: No disc is present.

Disc Player Error: The temperature is outside the operating range of the RSE system. If the temperature is within range, see your dealer.

Video Distortion

Video distortion can occur when operating cellular phones, scanners, CB radios, Global Positioning Systems (GPS), two-way radios, mobile faxes, or walkie talkies.

It might be necessary to turn off the video player when operating one of these devices in or near the vehicle.

Rear Seat Entertainment (RSE) System (Platinum)

Vehicles with an RSE system include two head restraint video display screens with integrated DVD players, auxiliary inputs, two wired headphones, and remote control. This system works independently from the vehicle's Overhead DVD RSE system. See Rear Seat

Entertainment (RSE) System on page 24 or Rear Seat Entertainment (RSE) System (Platinum) on page 43 for information about the

Overhead DVD RSE system.

The vehicle has a feature called Retained Accessory Power (RAP). With RAP, the RSE system can be played even after the ignition is turned off. See “Retained Accessory Accessory Power (RAP)” in the owner manual.

Video Display Screens

The video display screens are located on the back of each head restraint.

Page 45

Black plate (44,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

44 Infotainment System

{

Caution

Avoid directly touching the video screen, as damage can occur. See “Cleaning the Video Screens” later in this section for more information.

RSE Overview System

The loading slot for the DVD player is located at the top of the head restraint. Insert the disc partially into the loading slot with the printed side facing the rear of the vehicle. The DVD player automatically draws the disc in, “Loading” displays on the screen along with a disc indicator, and playback starts. If the disc is inserted incorrectly, the DVD player ejects the disc and “No Disc” displays.

Some DVDs do not allow fast forwarding or skipping of the copyright information or previews.

If the DVD does not begin playing at the main title, refer to the on-screen instructions.

The DVD player can be controlled by using the buttons below the video display screen or by using the buttons on the system's remote control. See “Remote Control” later in this section.

The following discs are compatible with the DVD player:

DVD-Video: A DVD that has video.

CD-DA: A CD that has music or sound content only.

CD-Video: A CD that has a movie.

CD-R/RW: A disc that has audio files such as CD-R with downloaded MP3 files, MPEG, or JPEG files.

The DVD player and discs are coded by global region. The DVD players are set to Region 1. Discs with other region codes will not work in the players.

If an error message displays on the video screen, see “DVD Messages” later in this section.

While the vehicle is moving, passengers should not unfasten their safety belts to make adjustments to the video screen control buttons. See “Safety Belts” in the owner manual. Use the remote control for any necessary adjustments. See “Remote Control” later in this section.

Page 46

Black plate (45,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 45

1. Video Screen

Located behind the front seat headrest.

2. CD/DVD Slot

3. Lever Lock and Release Latch

The viewing angle of the video screen can be adjusted by releasing the latch and gently moving the screen. Then lock it into a secure position.

4. POWER

Press to turn the power on or off. Each video screen can be powered on or off independently.

5. SOURCE

Press to select between Monitor 3, Monitor 4, or the AV INPUT. Each video display screen can be adjusted independently, as well as display information from both DVD players and both A/V inputs.

6. USB Port

Connect the USB drive to listen to music or view pictures. To charge a device, connect it to the USB port. Not all devices are able to be charged. For playback, the formats available are:

‐ JPEG

‐ JPG

‐ M2V

‐ MP3

‐ MPE

‐ MPEG-1

‐ MPEG-2

‐ MPG

‐ OGG

‐ WMA

7. Video Input

The yellow connector is used for video input.

8. Left Audio Input

The white connector is used for the left side audio.

9. Right Audio Input

The red connector is used for the right side audio.

10. 3.5 mm (1/8 in) Output Jack

Wired headphones can be plugged in with a 3.5 mm (1/8 in) jack.

Page 47

Black plate (46,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

46 Infotainment System

11. PLAY r

Press this button located below the video display screen to start playback of a disc. On DVDs and video CDs with playback control (PBC), menu screens can display automatically. It might be necessary to press the play button again to begin play. There is a play position memory feature for DVD and video CD only. If the DVD player is turned off and then turned back on, the DVD player resumes playback where the disc stopped. The play position memory is erased if the disc is removed.

12. STOP

Press once to stop playing a DVD.

There is a pre-stop feature for DVD and video CD only. This feature resumes playback of the disc where it was stopped. Press the stop button once during

disc playback and

displays on the DVD startup screen. This icon disappears after a few seconds. Press the stop button a second time, or eject the disc, to cancel the pre-stop feature and to clear the disc position memory.

13. EJECT

Press to eject a disc from the DVD slot.

If a disc is ejected from the player, but not removed, it will automatically reload into

the player. Another way to reload a disc that has been ejected, but not removed from the DVD player, is to press the eject button or the play button.

Infrared Remote Sensor: Located in the top centre of the video display screen. Do not block the signal from the remote to the sensor.

Infrared Transmitters: Located in the top centre of the video display screen. Do not block the signal from the headphones to the transmitter.

Using the RSE On-Screen Display (OSD) Menus

Use the OSD setup display menus for:

General Setup

Audio Setup

Quality Setup

Preference Setup

Page 48

Black plate (47,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 47

To use the OSD menus while using the DVD player or an auxiliary device:

1. Press the SETUP button on the remote control to display the icons and pages on the display screen.

2. Select the desired page by using the left/right navigation arrows to move the cursor.

3. Press the SETUP button again on the remote control to cancel use of the setup display.

Not all DVDs support all of the feature defaults in the setup menus. If a feature is not supported, the defaults are provided by the DVD media.

General Setup Menu

To set the language for the OSD:

1. Press the SETUP button on the remote control.

2. Use the left/right navigation arrows to navigate the General Setup Page, then use the down navigation arrow to select the OSD language.

3. Press the ENTER button and then use the right or left navigation arrows to select English, Simple/Traditional Chinese, French, German, Italian, Spanish, Portuguese, or Korean. Press the left navigation arrow to go back to the previous menu.

The angle mark allows different viewing angles on the DVD player. To set the angle mark:

1. Press the SETUP button on the remote control.

2. Use the left/right navigation arrows to navigate the General Setup Page, then use the down navigation arrow to select the OSD language.

3. Press the ENTER button and then use the right or left navigation arrows to select On or Off. Press the left navigation arrow to go back to the previous menu.

Audio Setup Menu

The Audio Setup Menu is available when a disc is not loaded.

To set the speaker setup:

1. Press the SETUP button on the remote control.

2. Use the left/right navigation arrows to navigate the Audio Setup Page.

3. Press the down navigation arrow to select the Speaker Setup sub-menu and to adjust the speakers setting. Choose from LT/RT, Stereo, V SURR, and OFF.

4. Press the ENTER button and then use the left or right navigation arrows to select a

Page 49

Black plate (48,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

48 Infotainment System

speaker option. Press the left navigation arrow to go back to the previous menu.

The Dolby Digital Setup Menu speaker options are L-Mono, R-Mono, and Mix-Mono.

Quality Setup Menu

To set up the video quality setup menu:

1. Press the SETUP button on the remote control.

2. Use the left/right and down navigation arrows on the remote control to select the Video Quality Setup sub-menu.

3. Press the ENTER button, and use the left or right navigation arrows to adjust the following:

Sharpness: Adjust to soften or sharpen the picture. Use the right or left navigation arrows to choose from Low, Med, or High.

Brightness: Adjust to brighten or darken the picture. Use the right or left navigation arrows to choose from −20 to +20.

Contrast: Adjust to increase or decrease the picture contrast. Use the right or left navigation arrows to choose from −16 to +16.

Hue: Adjust to increase or decrease the colour hue. Use the right or left navigation arrows to choose from −9 to +9.

Saturation: Adjust to increase or decrease colour intensity. Use the right or left navigation arrows to choose from −9 to +9.

Preference Setup Menu

To set the audio playback language:

1. Press the SETUP button on the remote control.

2. Use the left/right and down navigation arrows on the remote control to select the Audio sub-menu under the Preference Page.

To turn the Subtitles on or off:

1. Press the SETUP button on the remote control.

2. Use the left/right and down navigation arrows on the remote control to select the Subtitle sub-menu under the Preference Page and use the left or right navigation arrows to choose On or Off. Press the left navigation arrow to go back to the previous menu.

To set the disc menu language:

1. Press the SETUP button on the remote control.

2. Use the left/right and down navigation arrows on the remote control to select the Disc sub-menu under the Preference Page and use the left or right navigation arrows to select the language. Press the left navigation arrow to go back to the previous menu.

Page 50

Black plate (49,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 49

To set up the Parental Control:

1. Press the SETUP button on the remote control.

2. Use the left/right and down navigation arrows on the remote control to select the Parental sub-menu under the Preference Page.

3. Press the SETUP button, and use the right and up/down navigation arrows to select any one of the available Rating settings from the display menu.

The Rating settings are:

Kid SAFE (Children)

PG 13

PG R

NC 17

ADULT

4. Press the left navigation arrow to confirm the selection.

If a disc is inserted into the DVD compartment slot and it exceeds the Parental Setting, the following message appears on the display:

The Parental Setting of this player prohibits play. Would you like to allow this disc to play?

If yes if selected, the six digit password must be entered for the disc to play. If the wrong password is entered, the following message appears:

This movie will not play due to the Parental Setting of the player.

To create a six digit password, use the numeric keypad on the remote control. Press the ENTER button to confirm. The default password is

136900.

To change the Parental Control Password:

1. Press the SETUP button on the remote control.

2. Navigate to the Password sub-menu under the Preference Menu and press ENTER.

3. At the Old Password option, enter the old password or the default password (136900).

4. At the New Password option, enter the new password (six digits) using numeric buttons.

5. At the Confirm PWD option, confirm the new password by entering the new password again.

6. Scroll to the OK button and press ENTER. The message “Your password has been changed” displays.

To reset the system back to the factory default settings:

1. Press the SETUP button on the remote control.

2. Use the left/right and down navigation arrows on the remote control to select the Default sub-menu under the Preference Page and press the ENTER

Page 51

Black plate (50,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

50 Infotainment System

button to reset the settings. The parental settings will not be affected.

Vehicle Speakers

Audio from the DVD player or an auxiliary device can be heard through the vehicle speakers or the wireless/wired headphones, while the radio is tuned to one of the many frequencies selected on the Sound Around portion of the system's remote control. See “Remote Control” later in this section.

Only one audio source can be heard through the vehicle's speakers at a time. The audio source being used is specified by the A/V (audio/video) source selected on the driver side head restraint video display screen.

To turn the RSE system audio output to the vehicle's speakers, press Sound Around ON, on the system's remote control. The audio from the RSE system can be heard through the wireless/wired headphones and the vehicle's

speakers at the same time. The volume on the radio can vary when switching between the radio, CD, DVD, MP3, or an auxiliary device.

Wired Headphones

VOL 0 (Volume): Use to adjust

the volume on the headphones.

100 Channel FM-Modulation Control

For Monitor “A” Only:

To activate the FM modulation feature, press the “Sound Around On/Off” button until the text “FM CH XX.XMH2” is displayed on the monitor.

On the remote, press the “Sound Around Select” button to cycle through a pre-established list of 6 channels (88.3MHz, 88.7MHz,

89.1MHz, 89.5MHz, 89.9MHz,

90.3MHz.)

If none of these stations are suitable for FM modulation, use the “Fine Tune” option. To “Fine Tune” the modulator to a specific target station

while the display is active, press the “Up” or “Down” keys on the remote to change the channel by 0.2MHz. Hold down the “Up" or “Down” keys to cycle quickly through the stations. When the end (107.9MHz) or beginning (87.5MHz) of the FM band is reached, the channels will continue from the beginning (87.5MHz) or end (107.9MHz), respectively.

To deactivate the FM modulation feature, press the “Sound Around On/Off” button on the remote until the text “FM OFF” is displayed on the monitor.

{

Caution

Page 52

Black plate (51,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 51

Remote Control

To use the remote control, aim the remote sensor at top centre of the video display screen and press the desired button.

Objects blocking the line of sight can affect the function of the remote control. Direct or very bright light can affect the ability of the transmitter to receive signals from the remote control. If the remote control does not seem to be working, the batteries might need to be replaced. See “Battery Replacement” following this section.

The remote control provided with the Headrest DVD RSE system is not a universal remote control and will not control other equipment.

{

Caution

Storing the remote control in a hot area or in direct sunlight can damage it, and the repairs will not

(Continued)

Caution (Continue d)

be covered by the warranty. Storage in extreme cold can weaken the batteries. Keep the remote control stored in a cool, dry place.

Remote Control Buttons

POWER: Press to turn the

Headrest DVD RSE system on and off.

SOURCE: Press to select between Monitor 3, Monitor 4, or AV INPUT. Any video equipment connected to the AV inputs automatically overrides the source selection.

SETUP: Press to change the default settings. See “Using the RSE On-Screen Display (OSD) Menus” earlier in this manual. There are four main menu screens. Each screen displays a menu to select different setting options. The screens are:

1. General Setup — adjusts screen settings.

2. Audio Setup — sets the language.

3. Preference Screen — sets the subtitles and parental controls.

4. Password Setup — allows a password to be set.

Press SETUP again to exit.

EJECT

X : Press to eject or

reload a disc.

Page 53

Black plate (52,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

52 Infotainment System

DVD-Video Screen 3: Press the

DVD button located under 3 to transmit IR codes for DVD mode on Video Screen 3.

TV-Video Screen 3: This button is not used with the system.

DVD-Video Screen 4: Press the DVD button located under 4 to transmit IR codes for DVD mode on Video Screen 4.

TV-Video Screen 4: This button is not used with the system.

SOUND AROUND ON/OFF: Press to turn the FM Transmitter power on or off.

MUTE

> (For DVD Only): Press to

turn off the headphone sound. Press again to turn the sound on again.

PIX (Picture Selection): Press to adjust the picture's On Screen Display (OSD). Each time this button is pressed, the picture adjustment OSD cycles through bars for BRIGHTNESS, CONTRAST, COLOUR, and TINT. Use the right/left navigation arrows

to adjust the setting. This feature automatically shuts off if another button is pressed or adjustments are not made within six seconds.

SOUND AROUND SELECT: Press to select an FM transmitter channel. The SOUND AROUND SELECT lets the DVD audio play over the vehicle's sound system by tuning the radio to one of the many FM frequencies.

MENU: Press to enter the DVD disc menu while the disc is playing.

Q, R, q, r (Navigation Arrows):

Press to navigate through menus.

CH + (Channel): Press to change the channel to a higher level in sequential order.

CH − (Channel): Press to change the channel to a lower level in sequential order.

VOL +: Press to adjust the sound louder.

VOL −: Press to adjust the sound lower.

ENTER: Press to enter a selected function or to begin playback of the disc.

REPEAT

7 : Press to repeat part

or all of a chapter, title, track, or the entire disc after using the A-B button to setup repeat preset sections.

TITLE: Press to enter the disc title mode. The title feature is disc-specific, and may not be available on all discs.

SUBTITLE: Press to change the subtitle language to another available language or to turn subtitles off.

ANGLE: Press to select a different viewing angle for discs that are recorded with different camera angles.

AUDIO: Press to select a different language for discs that are recorded with different languages.

Page 54

Black plate (53,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 53

0-9 (Numbers): The numbers

located on the lower left side of the remote control can be used to enter numbered menu options, channels, or track numbers.

DISPLAY: Press to scroll through display information on the upper left corner of the screen, such as title, chapter/track, time elapsed, and time remaining, or to turn off the display

RANDOM: Press to play titles randomly.

PLAY /

r : Press to start playback

of the disc.

STOP

c : Press to stop playback

of a disc.

PAUSE

j : Press to pause

playback of a disc.

To resume disc playback, press PLAY.

To start playback from the beginning of the disc, press STOP, STOP, then PLAY.

CLR (Clear): Press to clear the previous menu selection.

INT (Initialize): Press to start the process of programming a selected menu item on the remote control.

r (Fast Reverse): Press to

fast reverse the disc. Press multiple times to choose between 2X, 4X, 8X, 16X, and 32X speeds.

[ (Fast Forward): Press to fast

forward the disc. Press multiple times to choose between 2X, 4X, 8X, 16X, and 32X speeds.

g (Previous): Press to play

the previous chapter or track. To return to previous chapters or tracks one at a time, press and release multiple times until the desired chapter or track is reached.

d : Press to play the next

chapter or track. To go to the next chapter or track one at a time, press and release multiple times until the desired chapter or track is reached.

Battery Replacement

To change batteries in the remote control:

1. Turn the remote control face down.

2. Press down on the ridged area of the battery cover and slide it off.

3. Install two AAA batteries into the battery compartment.

4. Slide the cover back on until it clicks.

If the remote control is to be stored for a long period of time, remove the batteries and keep it in a cool, dry place.

Playing Audio CD

When an audio CD is playing, the display shows the current track and the amount of time that track has been playing, the total amount of time on the disc, and the current time running on the disc.

Page 55

Black plate (54,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

54 Infotainment System

DISPLAY: Press to choose from

the following display options:

1. Press DISPLAY once and Single Elapsed appears along with the current track playing and the length of time for that track.

2. Press DISPLAY twice and Single Remain appears along with the current track playing and the amount of time left on the track.

3. Press DISPLAY three times and Total Elapsed appears along with the current track playing and the total time that has played on the CD.

4. Press DISPLAY four times and Total Remain appears along with the current track playing and the amount of time left on the CD.

REPEAT: Press to toggle between Track and All. The default for repeat is OFF.

Track repeats the track that is playing.

All repeats the disc that is playing.

Playing MP3 CD

MP3 is the format for storing digital audio. An audio CD quality song can be compressed into the MP3 format with very little loss of quality, while taking up much less space. CD-R/RW discs that have been encoded in MP3 format can be played on the DVD player.

Selecting Folders and Songs

When an MP3 disc is inserted in the player, the navigation screen appears. The folders and songs can be changed by navigating through the file system. The DVD player plays the songs in the order they were burned to the disc.

1. Press STOP if a disc is playing. Press the up or down navigation arrows on the remote control to go through the folder list on the left side of the screen.

2. Press ENTER when the desired folder is highlighted.

3. Press the up or down navigation arrows to go through the song list and highlight the desired song. Press ENTER to begin the playback of the selected song.

Skipping a Song

NEXT: Press to go to the

next song.

PREV (Previous): Press to return to the beginning of the song that is currently playing. Press PREV twice to go to the previous song.

Selecting a Play Mode

The order in which the songs are played can be temporarily chosen on a disc. The FOLDER play mode is the default. Press the REPEAT button to access the play mode options.

The play mode options are:

Single — Play a selected song.

Folder — Play the folder in the order the songs were recorded.

Page 56

Black plate (55,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 55

Shuffle — Play the songs in random order, from within the selected folder.

Using the REPEAT Feature

REPEAT: Press to change between

Repeat One and Repeat Folder.

Repeat One — Repeats the song that is playing.

Repeat Folder — Repeats the folder that is playing.

Tips and Troubleshooting

IR Sensor Inoperative: Check that

the batteries are good in the remote control. Check that the remote Control IR Sensor is not blocked. Aim the remote control toward the IR Sensor being controlled. Select the correct screen, 3 or 4.

No picture: Check that the correct video input mode is selected. Check that the video cable is plugged into the jack securely.

No Sound: Check that the correct audio input mode is selected. Check that the audio cable is securely plugged into the jack.

Cleaning the Video Screens

The video display screens are made of a specially coated glass and can be scratched or damaged by abrasive products, solvents, or ammonia-based window cleaners. Clean with a soft, lint-free, cotton cloth that has been slightly dampened with warm water. Dry the screens by wiping with a clean dry cotton cloth.

Cleaning the Components

Use care when touching or cleaning the components such as the DVD player or the discs.

Do not use DVD lens cleaners for DVD players because the lens of the DVD optics can become contaminated by lubricants.

Handle CDs and DVDs carefully. Store them in their original cases or other protective cases and away

from direct sunlight and dust. The DVD player scans the bottom surface of the disc. If the surface of a CD or DVD is damaged, such as cracked, broken, or scratched, the CD or DVD may not play properly or not at all. If the surface of a CD or DVD is soiled, take a soft, lint free cloth or dampen a clean, soft cloth in a mild, neutral detergent solution mixed with water, and clean it. Make sure the wiping process starts from the centre to the edge.

Do not touch the bottom side of a CD or DVD while handling it; this could damage the surface. Pick up CDs or DVDs by grasping the outer edges or the edge of the hole and the outer edge.

Page 57

Black plate (56,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

56 Infotainment System

Navigation

Using the Navigation System

Press the NAV button on the Home Page or the NAV icon in the applications tray to access the navigation application.

Press MENU from the map view to access the Navigation Menu. Features displayed in the Navigation Menu can be selected to adjust navigation preferences.

To exit out of a list, press the EXIT screen button in the top right corner of the map to return to the main map view.

It is advised to set up preferences before setting a destination. To set a destination, see Destination on page 65.

Additional navigation features are:

Cancel/Resume to

Navigation Voice Preferences

Current Location

Display “Points of Interest” Icons

Map View

Routing Preferences

Traffic

Personal Data

Cancel/Resume Route

While under route guidance, this screen button displays Cancel Route. Press Cancel Route to cancel route guidance. No further prompts will be given. The list item then changes to Resume to.

Press the Resume to screen button to resume route guidance to the last entered destination.

The last location that the system has provided guidance to can be resumed by pressing on this list item.

If the route includes waypoints, the entire route can be suspended using the Cancel Route list item. When Resume to is pressed, all waypoints are resumed for guidance.

Page 58

Black plate (57,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 57

Navigation Voice Preferences

Press the Navigation Voice Preferences list item to adjust the voice preferences.

The following options can be adjusted:

Voice Prompts ON/OFF

Voice Volume

Prompts During Phone Calls ON/OFF

Voice Prompts

Press the Voice Prompts list item to toggle voice prompts ON and OFF.

Voice Volume

Adjust the loudness of the audio feedback by pressing the - or + button. If a manoeuvre prompt is being played, and the main volume is adjusted, the prompt volume will update and be saved.

As the volume of the voice guidance is being adjusted, a quick status bar displays, showing the volume setting.

Prompts During Phone Calls

When enabled, the system plays a shorter prompt while on a phone call. This setting can be configured as to whether a prompt would be heard during a phone conversation.

When this setting is OFF, only the short alert tone is played when approaching the manoeuvre.

Current Location

Press the Current Location list item to display a Current Location list.

The following information is displayed on the Current Location list:

Nearest Address

Lat/Long

Nearest Hospital

Nearest Police

Nearest Fuel

Nearest Assistance

Page 59

Black plate (58,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

58 Infotainment System

Pressing on any of the options will display the destination details view for that location to allow you to begin guidance to the selected location.

Press the Nearest Address button and then the Save screen button to store the current location to the Address Book.

Display “Points of Interest” Icons

Places of Interest (POI) icons can be displayed on the map using this view.

The POI icons can be turned ON and OFF. Press the check box next to the POI icon to display the icon.

Press Clear All to reset the icons that are displayed on the map.

A subcategory can be selected instead of the entire category. Press the list item itself rather than the check box. The subcategories will display. Select any of those categories to navigate down the hierarchy.

When a higher-level category has some of its subcategories selected, the checkmark next to it is greyed out. This indicates that only some of the categories below are shown. Press the greyed-out checkmark to turn all of the icons for that category on or off.

Map View

Press to select the desired map view. A checkmark appears to indicate a view has been selected.

3D View

The 3D View is a Heading Up view but it includes perspective. Map items will appear larger as the vehicle comes closer.

Heading Up View

The Heading Up View keeps the vehicle's current heading at the top of the view. The vehicle icon always faces the top of the view as the map rotates.

North Up View

The North Up View keeps north at the top of the view. The vehicle icon is placed in the centre of the view and rotates to indicate the heading for the vehicle.

Page 60

Black plate (59,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 59

Audio Information On/Off

Press to turn the audio information view on or off from the main map view. When ON, the audio information becomes an audio status pane. This allows for two lines of audio information in the status pane and enables the use of some Interaction Selector controls.

The audio status screen contains the following elements:

Station Frequency

Artist Information

Song Information

r / j or t / u Station and

Channel Controls

Press the

t / u Station controls to

go to the next or previous strong signal station or digital channel.

When the audio status pane displays Artist and Song

Information, press the

t / u

controls to go to the next or previous track based on the current media mode.

Day/Night Mode

Press to access the Day/Night Mode menu.

The options are:

Day Mode: Brightens the map background.

Night Mode: Darkens the map background.

Automatic: Adjusts the screen background automatically depending on the exterior lighting conditions.

Routing Preferences

Press the Routing Preferences list item to access the Routing Preferences menu. Options on how the routes are created for route guidance are listed on this menu.

Route Style

Press this list item to change the route type preferences.

The options are:

Fast (default)

Eco Friendly (if equipped)

Short

Edit Eco Profile

The Edit Eco Profile can be used to configure two parameters for the Eco Friendly route. These parameters are roof load and trailer. For each parameter, the options are None, Small, Medium, and Large. Press to scroll through the list. The default for both is None.

These preferences are used for all routes generated.

Page 61

Black plate (60,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

60 Infotainment System

Route segment preferences are other options showing on the Routing Preferences menu.

This includes:

Use Toll Roads ON/OFF

Use toll-free roads ON/OFF

Use Carpool Lanes ON/OFF

Avoid Slow Traffic ON/OFF

Use Tunnels ON/OFF

Use Time Restricted Roads ON/OFF

Personal Data

Data that the system has saved during the course of using the navigation system can be managed through:

Address Book Entries

Recent Destinations

My POIs (if equipped)

Upload Saved Locations

Address Book Entries

Press Address Book to edit.

Recent Destinations

Press Delete Individual Destinations to display a recent destinations list. Select the individual entry to delete.

Press Delete All Destinations to delete the entire recent destination list. A pop-up displays asking to confirm the deletion.

My POIs

Press My POIs to display a menu of other options.

Select Delete Individual Categories. A My POIs category list displays.

Select the individual entry to delete.

Press Delete All My POIs to delete the entire list of categories. A pop-up displays asking to confirm the deletion.

Page 62

Black plate (61,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 61

To exit out of a list, press the EXIT screen button in the top right corner of the map to return to the main map view.

Upload Saved Locations: Press to upload any saved locations such as downloaded POIs and all entries in the vehicle address book to the USB device.

Press Upload Saved Locations to save the Vehicle Contacts list and any MyPOIs that have been saved to the vehicle.

Once saved locations have been uploaded to a USB, they can be transferred to a different vehicle or restored to the current address book.

Map Adjustments

ZOOM −/+ can be used to adjust the scale of view on the map. When the end of the zoom level is reached, ZOOM −/+ will grey out.

Use the pinch/spread hand gesture to zoom the scale of view on the map.

ZOOM − (minus): Pinch fingers together to zoom out.

ZOOM + (plus): Spread fingers apart to zoom in.

The zoom scales can be configured for English or metric units. To change from English to metric, see "Instrument Cluster" in the owner manual.

Scroll Features

To scroll within the map, press anywhere on the map screen.

Nudge or slide a finger on the map; the map moves in the direction of the finger.

Fling a finger on the map; the map will start scrolling in a short continuous scroll.

Press a finger on the location on the map; the map recentres to the location that was pressed on.

Press a finger twice on a location on the map; the map zooms in one level to the location that was pressed twice.

When the map is recentred away from being locked to the vehicle position, the crosshairs will show in the centre of the map. As the map continues to be recentred, the crosshairs will remain on the screen. When the crosshairs are shown on the screen, a callout with more information displays. If the map is moved from the current location, the crosshairs will disappear along with the callout.

Page 63

Black plate (62,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

62 Infotainment System

Press a finger on the callout next to the crosshairs and the destination details view displays. From this view, route guidance can be received or saved to the vehicle's contact list.

When the map is recentred, the straight-line distance from the vehicle to the selected point is displayed in the callout. In addition, a heading direction in the form of an arrow is displayed to indicate the direction. The arrow is shown in relation to the current vehicle heading.

Press a finger on a POI icon shown on the map; the name of the POI is shown in the address callout, along with the city name

and country. If the callout is selected, the destination details view for the POI is shown.

After panning the map away from the vehicle, press RESET to return the map back to the current position.

Press the Overview button to quickly get a view of the entire route. The route Overview button takes the place of the RESET button while under route guidance. Press the RESET button to return the map to the current position.

Maps

The map database is stored in the internal flash memory that is used in the navigation system.

Detailed Areas

Road network attributes are contained in the map database for detailed areas. Attributes include information such as street names, street addresses, and turn

restrictions. A detailed area includes all major motorways, service roads, and residential roads. The detailed areas include Places of Interest (POIs) such as restaurants, airports, banks, hospitals, police stations, petrol stations, tourist attractions, and historical monuments. The map database may not include data for newly constructed areas or map database corrections that are completed after production. The navigation system provides full route guidance in the detailed map areas.

Navigation Symbols

Following are the most common symbols that appear on a map screen.

Page 64

Black plate (63,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 63

The vehicle symbol indicates the current position and heading direction of the vehicle on the map. When under route guidance, a circle with an arrow is added to the vehicle symbol which indicates the direction to the destination.

Vehicle Address Callout

Tap on the vehicle icon; the current address of the vehicle is overlaid on the map next to the vehicle icon in a callout. Another tap hides the information.

Any address information about the vehicle's current location will be shown, including the street, city, and state names.

Tap on this callout to save the current address to the vehicle address book.

The destination symbol marks the final destination after a route has been planned.

The waypoint symbol marks one or more set waypoints.

A waypoint is a stopover destination point added to the planned route.

The estimated time to the destination displays. Press the Arrival button to toggle to duration and to the distance of the destination.

This symbol indicates the recommended manoeuvre that should be performed. Press it to display the turn list or waypoint list.

The No GPS symbol appears when there is no Global Positioning System (GPS) satellite signal. When

Page 65

Black plate (64,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

64 Infotainment System

the GPS is gone, the vehicle position on the map may not be accurate.

Autozoom

As a manoeuvre is being approached, the map automatically zooms in to give greater detail.

If lane guidance is available for the manoeuvre, this is also shown.

When the system begins to autozoom, it zooms in to its minimum level. After the manoeuvre is performed, the system slowly zooms back out.

Driving on a Route

Manoeuvre Road Name

If the road name has multiple names, all names are shown.

Map View with Proximity

Map View without Proximity

If the road that the system has calculated for the next manoeuvre has an icon, it will be shown to the left of the manoeuvre road name.

The distance to the manoeuvre is shown from the current location along the route to the manoeuvre.

Off-Road Indication

When driving in an area with no road showing on the map, the system transitions to off-road mode. The map displays a destination pointer in the Turn List area. The system will attempt to guide by showing a highlighted route starting at the nearest road. This road name is shown in the next manoeuvre name field at the top of the screen.

Page 66

Black plate (65,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 65

Navigation Next Turn Manoeuvre Alert

The navigation system may need to get the attention of the driver in certain situations.

If not in the navigation application when a near manoeuvre prompt is given, it is shown as an alert. The alert contains the turn indicator and button to display the main navigation view, or dismiss the alert.

The alert also contains the name of the street to turn on and a countdown bar.

Destination

If route guidance is not active, press the NAV screen button on the Home Page to access the map view. Press the Destination icon from the map view to enter a destination. Available methods of entering a destination are Voice Recognition, Address, Recent Destination, Contacts, and POIs. Several options can be selected to plan a route. Some destination items may be greyed out if no destination was previously entered or saved.

Press the DESTINATION button to go to the destination entry views.

Available Methods of Search

Voice Recognition

Address

Recent Destinations

Contacts

POIs (Points of Interest)

Press the DESTINATION button and the last used destination view is shown. This mode is retained. The initial default is Address.

Alpha-Numeric Keyboard

The keyboard is used in multiple locations throughout the system and can be used with many features. The navigation system uses the alpha-numeric system keyboard

Page 67

Black plate (66,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

66 Infotainment System

which includes 1 to 0, A to Z in QWERTY layout, hyphen, comma, full stop, Space, and Sym which would show additional characters needed.

The keyboard can also be modified to include characters appropriate for the region configured in the vehicle settings.

@ GO: Press to search for the

destination details of an address or place of interest entered in the text field. Once the GO screen button is pressed, the activity indicator displays in the list of possible matches.

| (Dropdown Arrow): Press to

display a list of matches.

When there are multiple matches, a dropdown arrow is shown after the autocomplete text. This dropdown displays an entire list of matches. Press the appropriate match without having to enter more text.

z (Delete): Press to delete the last

typed character. Press and hold this screen button to clear the entire text field. If the entire text field has been deleted, this screen button becomes an Undo button. Pressing Undo will restore the deleted text.

EXIT: Press to return to the previous Map view.

Sym: Press to show the symbol keyboard.

Space: Press to enter a space between characters or the words of a name.

Q (Up Arrow): Press to display the

Interaction Selector.

Special Characters

As the characters are typed on the keyboard, a pop-up of the letter pressed displays above the key that was pressed.

Continue to press and hold, and any additional special characters associated with that letter are displayed around the current letter.

To select one of the special characters, slide a finger left or right to adjust the highlight of the special character.

Special Character List

The following characters have special characters beneath them:

Page 68

Black plate (67,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 67

Address

A destination can be searched by typing out the address, intersection, highway, or motorway entrance ramps on the keyboard. This information is typed and displayed in the information field. Press the search icon to start the search.

Tips for address entry:

Most of Europe*

* Austria (AUT), Belarus (BLR), Belgium (BEL), Bosnia-Herzegovina (BIH), Bulgaria (BGR), Croatia (HRV), Czech Republic (CZE), Denmark (DNK), Estonia (EST), Finland (FIN), Greece (GRC), Hungary (HUN), Italy (ITA), Liechtenstein (LIE), Lithuania (LTU), Luxembourg (LUX), Macedonia (MKD), Moldova (MDA), Monaco (MCO), Netherlands (NLD), Norway (NOR), Poland (POL),

Portugal (PRT), Romania (ROU), Russia (RUS), San Marino (SMR), Serbia (SRB), Slovakia (SVK), Slovenia (SVN), Spain (ESP), Sweden (SWE), Switzerland (CHE), Turkey (TUR), Vatican City (VAT)

France (FRA)

Germany (DEU)

Albania (ALB), Andorra (AND)

Gibraltar (GIB), Ireland (IRL)

Great Britain (GBR)

[<house number> <street> <city>] [<postal code>] <country>

Latvia (LVA), Ukraine (UKR)

Montenegro (MNE)

Country information does not have to be included in the search field if entering an address that is located in the same country.

Whenever the keyboard view is entered, the last text that was typed, even if it was not searched on, will display.

A partial or complete address can be typed in the search field. If a partial address is typed, the system attempts to use local knowledge to fill in additional information. For example, if no city name or country are given, the system assumes a search for something in the current city or a nearby city in the current country. The system is also

Page 69

Black plate (68,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

68 Infotainment System

capable of recognising address formats according to other regions.

If a destination address or location being entered is outside of the country, the country abbreviation must be added after the address. For example, if the current vehicle location is in Paris FRA, and the destination is in Brussels Belgium, the correct input would be Brussels BEL.

Intersections: If looking for an intersection, type in the two street names and optionally the city and country of the intersection.

On-Ramp: If looking for the closest on-ramp as a destination, enter a highway name. The direction is not required but can be specified. The system will search for the closest on-ramp.

Also available is the Exit-Ramp. For example, N-94 Exit 42.

The keyboard can utilise an autocomplete function. Depending on the application, autocomplete matches entries that have been previously typed or are stored in a Recent Destinations list.

1. After a character has been typed, the system is able to start displaying matches that begin

with that character. The matches continually become more refined as additional characters are entered.

2. If there are multiple matches for what has been entered, the first result alphabetically will be shown.

When there are multiple matches, a dropdown arrow is shown after the autocomplete text. This dropdown displays the entire list of matches. Press the appropriate match without having to enter more text.

3. If autocomplete does not show the results needed, press the delete screen button to clear the autocomplete from the entered field.

If there are no matches, a pop-up displays in response to show how the system understood the entered text and attempts to show how the text could be entered to help find the destination.

Page 70

Black plate (69,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 69

Multiple Matches

If the search results in multiple matches, a list of matches is shown.

Address search results are grouped by result type, in the order of Full Addresses, Countries, Cities, Intersections, and Streets. If no results are found in a particular group, that group is not shown. If only one type of result is found, the single type result screen is shown. Within each group, they are listed in Confidence order. This means that the highest confidence result will be at the top.

Address searches can be sorted by Confidence, Distance, or Alphabetical Order.

Spelling Mistakes

The system is able to offer alternatives if the searched term is not found exactly. The system uses the closest term it finds and provides those results.

The system first searches the entered term exactly. If no matches are found, partial words are used. An example is, when entering in an address, the system attempts to do a full match on the entire string. If it does not find a match, the house number is then considered an optional term and the system attempts to find the street and city name. The prefix and suffix of street names are also treated as optional terms. The search is first done by trying to match the prefix and/or suffix. If there is no match found, these terms are removed from the search to make the search more generic.

Places of Interest (POI)

While at the Home Page, press the Nav screen button to display a view of the map. Press the Destination screen button to go to the destination entry views.

Page 71

Black plate (70,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

70 Infotainment System

1. Press the POIs screen button to display a list of POI categories.

The first list item in every POI list is a search function. For the highest level of categories, press the Spell Name screen button or select a category and search within that selection.

2. Select a POI category to display subcategories.

3. If a selected subcategory has no results in the surrounding area, the search is expanded until a result is found.

4. When a category is selected, the nearest locations are shown on the map and it lists the nearest

20 matches. If the limit is reached and no further matches display, there is a Show Next Results button to expand the search by another 10 results. The currently selected category or search term is shown in the title bar along with the number of matches shown in the list in parentheses.

5. Pan the map using the finger gestures to minimise the POI list and to interact with the map. The icons that were shown before continue to be displayed and updated. The list is also updated based on where the map was panned or zoomed. The search for POIs is constrained to where the map has been moved to. Press the list reveal button which is the arrow pointing right, near the left edge of the screen to display the list again.

6. If the search map is pressed to recenter, the crosshairs are shown to indicate the centre of the new search location. If a POI

icon is pressed on while in the full expanded map, a callout for that location displays. Press the callout to display the destination details view.

7. Press the map reset button to return the map to automatic zooming and searching. It is recentred around the vehicle's position, the route, the destination, or another location that was specified for the search. The map RESET button is only displayed if the map was manually adjusted.

Page 72

Black plate (71,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 71

Press the List All screen button to display all of the matching results in a particular category with its subcategories.

Using the Keyboard

The POI can be searched by entering a POI name, category, name and category, or phone number on the keyboard.

For example, enter the information as:

POI Name: Worldwide Food

POI Category: Restaurants

POI Name and Category:

Worldwide Food Restaurants

POI Phone Number: 0001222555

The POI keyboard search results will display in the order in which they were found. Press the Sort button to change the sorting order by Confidence, Alphabetical, or Distance.

POI Search Location

If browsing for POIs or searching for results on a keyboard in a different location than what was searched previously, press the Search Options button to specify a different location.

If not under route guidance, the search area options are:

Nearby (default)

Another Location

If under route guidance, the search area options are:

Along Route (default)

Nearby

Near My Destination

Page 73

Black plate (72,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

72 Infotainment System

Another Location

Favourite POIs

Locations, categories, or a particular POI chain ID can be saved as Favourites in the POIs view.

Press and drag up on the row of interaction selector buttons to reveal the Favourite buttons.

Press and hold on a favourite location, then press on the category to be saved. Whenever a set of POIs is grouped, as in a category or a set of POIs that all belong to the same chain ID, the whole category or chain ID is saved in the favourites for recall. Whenever a set of POIs that belong to the same chain ID is saved in the favourites, a POI chain saving pop-up message displays asking to save only that location, or to save the entire chain.

POIs are only grouped by chain when the sorting order is Alphabetical.

A POI search can also be saved as a Favourite. While in the POI search keyboard view, press and hold on a favourite location and the text that is currently typed in the keyboard will be saved.

Press the Sort button to change the sorting order.

Recalling a POI Category or Chain

If a POI category or chain favourite is recalled, the system displays a list of matching results defaulting to nearby, but allows a search of other locations. Press the Search Near button to specify a different location.

Creating and Downloading Predefined POIs (My POIs)

In addition to the POIs already stored in the infotainment system, predefined POIs can be created.

While creating a predefined POI, the GPS coordinates for longitude and latitude of the POI's location and a descriptive name will need to be entered.

After creating the predefined POIs, they can be downloaded to the Infotainment system from either a USB stick or SD card.

Once downloaded, the POI data becomes a selectable destination in the My POIs menu.

Creating a Text File with Information

Create a text file by using a simple text editor software. Save this file with a name and extension of .csv, for example, “TomsPOI.csv.”

Enter the POI information into the text file in the following format:

Longitude coordinate, Latitude coordinate, "Name of POI", "Additional information", "Phone number."

Example: 7.0350000,

50.6318040, "Michaels Home", "123 Maple Lane", "02379234567."

Page 74

Black plate (73,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 73

The GPS coordinates must be expressed in decimal degrees and can be taken from a geographical map. The additional information and phone number strings are optional.

The POI name and the additional information string may not exceed 60 characters.

POI information for each destination address must be entered in a single separate line.

Storing the POI on a USB Drive

In the root directory of a USB drive, create a folder name “myPOIs,” for example, “F:\” is the root directory of the USB drive.

In the “myPOIs” folder, store the text file with your POIs, for example, “F: \myPOIs\TomsPOIs.csv.”

Downloading the POI to the Infotainment System

Connect the USB drive or SD card containing the POI information to the USB port or SD card slot of the Infotainment system. A message

displays prompting whether or not to download the POI information from the USB stick. All POIs found are saved even if they are in multiple folders.

Subfolders can also be created to organise the POIs into categories. For example, "F:\myPOIs \Restaurants\TomsPOIs.csv."

If the message is dismissed or ignored, no POI information is downloaded. This prompt will not recur for the current ignition cycle.

When the system is finished downloading, a pop-up displays asking to specify a category for the new POIs, if desired.

Importing and Overwriting Categories

When POIs are found on a media device, the date of the file is examined and compared to the date for the files already in the system. If the file being downloaded is newer than the one on the system, that particular category of POIs is overwritten. Any other POIs that had previously been saved in other categories are not affected.

Page 75

Black plate (74,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

74 Infotainment System

Address Book Download

If an Address Book is found on the connected USB device, the same alert is used to indicate that locations have been found and they can be downloaded. If there is already content in the vehicle Address Book, the system prompts if the stored content should be overwritten. Select Save to overwrite the existing Address Book information. Select Cancel to abort the import of information.

Browsing Downloaded POIs

Access the downloaded POIs by selecting the My POIs list item in the POIs list.

Edit My POIs

Downloaded POIs can be edited at a category level. These POIs can either be deleted as an entire category or reassigned as another category. To edit the categories:

Select the EDIT button at the main category view to edit the POIs. Edit buttons display next to each category name. There is no POI browsing in this mode, only edit functions are available.

Once an action such as deleting or reassigning has been selected, the changes are saved immediately.

Changing POI Categories

POI categories can be assigned to a different category by using the same method as assigning a category for an Address Book entry. When editing, the right side of the screen displays the current category name.

Deleting POI

POI categories can be deleted by selecting Edit and then Delete. A pop-up displays to confirm the deletion.

Saved Destinations

Select a saved destination from the Contacts or Recent Destinations.

Page 76

Black plate (75,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 75

Contacts

Select the Contacts button to view the vehicle's contact list or a connected Bluetooth device. Press the Change Contacts List screen button to switch between the vehicle's contact list and the Bluetooth device's contact list. If a particular contact has a single address associated with it, that contact has a Quick Route list item function button next to it. Contacts without this Quick Route button either have multiple addresses or no address at all. Press the Quick Route button to go to the Destination Details view.

Press on an address, either from the Quick Route on the contact list or a specific address from the contact detail list, to go to the destination view showing that address on the map.

Trips from Contacts can be saved and recalled. The order is based on when the trip was last used. When the trips are saved, they are given a default title of the final destination name. If there are no saved trips, this list item is hidden.

Favourite Destinations

Destinations can be saved as Favourites for recall later. Depending on the favourite,

when an address or POI favourite is recalled, the Destination Details View is shown.

When a favourite address is being routed to, it is shown active. Press on the active favourite to suspend that route.

Save locations as Favourites for recall later in the Destination Details View.

Save trips from the Address Book.

Storing Favourites from the Contact Details List

A contact name or any of the contact's information such as phone number, e-mail address, or address from Contact Details can be stored as a Favourite.

Press and drag up on the row of interaction selector buttons to reveal the Favourite buttons.

Page 77

Black plate (76,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

76 Infotainment System

Press and hold on the favourite location while viewing a contact on the Contact Details List. The contact name and all contact information can be stored.

Press to save as a favourite. The favourite label will be the name of the contact.

Press on the Favourite to display the destination view.

Storing Favourites from Map

Favourite locations can be stored from the Map View.

If not under route guidance, the current vehicle location will be saved as a Favourite. If under route guidance, the final destination will be saved.

Press and drag up on the row of interaction selector buttons to reveal the Favourite buttons. Press and hold on the favourite location from the Map View to save it.

Route Guidance

Press GO to go to the main navigation view and to start route guidance.

If the system has an active route, a pop-up will display, “What would you like to do with

this destination?” The options are: Add as Waypoint, Set New Destination, or Cancel.

If a waypoint is added, it is placed in the location that leads to the most efficient route.

There is a maximum number of waypoints that can be added to the system. When the maximum number of waypoints has been reached, a pop-up displays indicating that a waypoint must first be deleted before a new one can be added. The system will hold this waypoint into a Pending Waypoints list and it will automatically be added to the route once a position is available, either by arriving at a waypoint, or by deleting one.

To save a location, tap on the Q

to display the Favourite buttons. Press and hold on a favourite location to save the shown location as a Favourite.

Page 78

Black plate (77,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 77

Estimated Time of Arrival (ETA) and Distance

When under route guidance, the system shows the ETA or travel time, or the driving distance.

The ETA and travel time are calculated using any available traffic information.

If in a waypoint trip, the ETA, travel time, and driving distance are all shown relative to the final destination.

The final ETA is shown taking into consideration any time zone crossings that the route has travelled through.

Press the ETA information area to switch between the estimated arrival time, total driving time resulting, and driving distance.

Turn List

Press on the next turn indicator shown on the map to display the turn list or waypoint list. The Interaction Selector is minimised

automatically. Press

Q to reveal the

following options:

Destination

Press the Destination screen button to add a waypoint or change the destination while viewing the turn list. When the Destination screen button is pressed, the display shows the Destination screens.

End Guidance

Press the End screen button to suspend the current route in the turn list. When the End screen button is pressed, the turn list is exited and the display returns to the main map view.

Avoid Areas

Press the Avoid Areas screen button to select the highway name that is to be avoided. The system shows a pop-up asking how many miles or if the entire road should be avoided.

Turn List

When under a waypoint trip, press on the Turn List Interaction Selector button to show the turn list. When entering a turn list, the next manoeuvre instruction is spoken.

The turn list title is the name or address of the destination. Press on the information button next to

Page 79

Black plate (78,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

78 Infotainment System

the name of the destination to display the destination information.

The turn list is sorted in order, with the next manoeuvre at the top of the list and the subsequent manoeuvres listed below it. The next manoeuvre is always highlighted upon entry into the Turn List to quickly show what the next manoeuvre is.

Each manoeuvre indicates the distance between it and the previous manoeuvre or the vehicle's current location. The next manoeuvre at the top will count down until the manoeuvre is reached, and then the next manoeuvre will begin to count down.

Each manoeuvre has an estimated time of arrival based on the current driving conditions.

Saved Trips

Waypoint trips can be saved for later recall. Press the Add button in the waypoints list to save the trip to the Saved Trips list in the vehicle's contacts list. When trips are saved, they are given a default title of the final destination. Saved trips can be edited by selecting the Edit list item button to access the edit screen for the saved entry. The only field that can be edited is the name field. Press on the name field to access the keyboard view. Type the name change. This change is automatically saved when executed by the keyboard.

The saved trip can also be deleted from the edit mode. Press the delete button and a delete confirmation pop-up will display.

Waypnts

When under a waypoint trip, press on the next turn indicator to bring up the waypoint list. The last waypoint view is shown, which could be Waypnts, Turn List, or Edit.

The waypoint list is sorted in order with the next waypoint at the top of the list. Each waypoint is indicated with a numbered icon, starting with the next waypoint.

To indicate what segment of the route is for the next waypoint, and what is for the remainder of the route, they appear in different colours.

Page 80

Black plate (79,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 79

Optimised Route

Press the Optimise screen button to optimise the current waypoint trip.

The optimisation is done according to how the preferences are set for new routes, e.g., fastest route, shortest distance, or eco friendly.

While the system is optimising the route, the waypoint trip has the activity indicator displayed over top of it. If the system is calculating the ETA and travel distance for a waypoint, the activity indicator is displayed in the list header.

When either a waypoint trip is first created, or additional waypoints are added to an existing waypoint trip, they are added in the location that would lead to an optimised route.

If a destination is already planned and a waypoint is added, it is either added before

or after the current destination, whichever leads to the most optimal route.

If under an existing waypoint trip consisting of two or more destinations, any additional waypoints are added in the location that would lead to the most optimal route.

Edit Route

Press the Edit screen button to modify the order or remove a waypoint from the route. Press the delete screen button to remove a waypoint from the route.

A pop-up displays asking for confirmation of the waypoint deletion.

Settings

Press Settings on the Home Page to adjust features and preferences, such as Time and Date, Sport Mode, Language, Valet Mode, or Radio. For setting options, see Settings on page 98.

A few of the setting options change the way the navigation system displays or reacts while in use.

1. Press the Settings screen button on the Home Page.

2. Press the scroll bar until the desired option displays. Select the desired settings to change.

Page 81

Black plate (80,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

80 Infotainment System

Voice

Voice recognition allows for hands-free operation within the navigation, audio, and phone applications. See Voice Recognition on page 83.

Press the voice screen button to display the Voice menu.

Prompt Length: Press to change the prompt length to Short or Long.

Audio Feedback Speed: Press to change the audio feedback speed to Slow, Medium, or Fast.

Confidence Threshold: Press to change the sensitivity of speech recognition system.

Display

Mode: Press Mode to change the

screen background. This setting controls map colours.

The Auto setting adjusts the screen background automatically depending on the exterior lighting conditions.

The Day setting brightens the map background.

The Night setting darkens the map background.

Calibrate Touchscreen: Press to display the Touchscreen Calibration Screen.

Turn Display Off: Press to turn the Display option off.

Low Fuel Alert

If the vehicle reaches a low fuel level, the system displays an alert about the low fuel condition. Press the More Info screen button to view nearby gas stations, and start guidance if desired.

If the remaining driving distance is available from the system, this is included in the alert.

Global Positioning System (GPS)

The position of the vehicle is determined by using satellite signals, various vehicle signals, and map data.

At times, other interference such as the satellite condition, road configuration, condition of the vehicle, and/or other circumstances can affect the navigation system's ability to determine the accurate position of the vehicle.

Page 82

Black plate (81,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 81

The GPS shows the current position of the vehicle using signals sent by GPS Satellites. When the vehicle is not receiving signals from the satellites, a symbol appears on the map screen. See Navigation Symbols on page 62.

This system might not be available or interference can occur if any of the following are true:

Signals are obstructed by tall buildings, trees, large trucks, or a tunnel.

Satellites are being repaired or improved.

For more information if the GPS is not functioning properly, see

Problems with Route Guidance on page 82 and If the System Needs Service on page 82.

Vehicle Positioning

At times, the position of the vehicle on the map could be inaccurate due to one or more of the following reasons:

The road system has changed.

The vehicle is driving on slippery road surfaces such as sand, gravel, or snow.

The vehicle is travelling on winding roads or long straight roads.

The vehicle is approaching a tall building or a large vehicle.

The surface streets run parallel to a freeway.

The vehicle has been transferred by a vehicle carrier or a ferry.

The current position calibration is set incorrectly.

The vehicle is travelling at high speed.

The vehicle changes directions more than once, or the vehicle is turning on a turn table in a car park.

The vehicle is entering and/or exiting a car park, garage, or a car park with a roof.

The GPS signal is not received.

A roof carrier is installed on the vehicle.

Tyre chains have been installed.

The tyres are replaced or worn.

The tyre pressure is incorrect.

This is the first navigation use after the map data is updated.

The 12-volt battery is disconnected for several days.

The vehicle is driving in heavy traffic where driving is at low speeds, and the vehicle is stopped and started repeatedly.

Page 83

Black plate (82,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

82 Infotainment System

Problems with Route Guidance

Inappropriate route guidance can occur under one or more of the following conditions:

The turn was not made on the road indicated.

Route guidance might not be available when using automatic rerouting for the next right or left turn.

The route might not be changed when using automatic rerouting.

There is no route guidance when turning at an intersection.

Plural names of places might be announced occasionally.

It could take a long time to operate automatic rerouting during high-speed driving.

Automatic rerouting might display a route returning to the set waypoint if heading for a destination without passing through a set waypoint.

The route prohibits the entry of a vehicle due to a regulation by time or season or any other regulation which may be given.

Some routes might not be searched.

The route to the destination might not be shown if there are new roads, if roads have recently changed, or if certain roads are not listed in the map data. See Maps on page 62.

To recalibrate the vehicle's position on the map, park with the vehicle running for two to five minutes, until the vehicle position updates. Make sure the vehicle is parked in a location that is safe and has a clear view of the sky and away from large obstructions.

If the System Needs Service

If the navigation system needs service and the steps listed here have been followed but there are still problems, see Problems with Route Guidance on page 82.

Map Data Updates

The map data in the vehicle is the most up-to-date information available when the vehicle was produced. The map data is updated periodically, provided that the map information has changed.

For questions about the operation of the navigation system or the update process, contact your dealer.

Database Coverage Explanations

Coverage areas vary with respect to the level of map detail available for any given area. Some areas feature greater levels of detail than others.

Page 84

Black plate (83,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 83

If this happens, it does not mean there is a problem with the system. As the map data is updated, more detail can become available for areas that previously had limited detail. See Map Data Updates on page 82.

Voice Recognition

Voice recognition allows for hands-free operation within the navigation, audio, phone, and weather applications. This feature can be started by pressing either

the

g button on the steering wheel

g on the touchscreen display.

However, not all features within these areas are supported by voice commands. Generally, only complex tasks that require multiple manual interactions to complete are supported by voice commands.

For example, tasks that take more than one or two button presses such as selecting a song or artist to play from a media device would be supported by voice commands. Other tasks, like adjusting the volume or seeking up or down, are audio features that are easily performed by pressing one or two buttons, and are not supported by voice commands.

In general there are flexible ways to speak commands for completing the tasks. Most of them, except destination entry and voice keypad, can be completed in a single command. If the task takes more than one command to complete, the first command would be to indicate the kind of task to be performed, like “Nav Destination Entry.” The system replies with prompts that lead you through a dialogue to enter the necessary information. For example, if a destination for route guidance is needed, say “Nav” or “Nav.”

Voice recognition can be used when the ignition is on or when Retained Accessory Power (RAP) is active. See “Retained Accessory Power (RAP)” in the owner manual.

Page 85

Black plate (84,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

84 Infotainment System

Using Voice Recognition

Voice recognition becomes available once the system has been initialised. This begins when the ignition is turned on. Initialisation may take a few moments.

1. Press

g on the steering wheel

control to activate voice recognition, or press

g on the

infotainment touchscreen on the centre stack.

If voice recognition is started from the steering wheel control, the instrument cluster displays the selections and visual dialogue content.

If voice recognition is started from the infotainment touchscreen on the centre stack, the selections and visual dialogue content are displayed on both the centre stack display and the instrument cluster display.

2. The audio system mutes and the system plays a prompt followed by a beep.

3. Wait until after the beep completes, then clearly speak one of the commands described in this section.

A voice recognition system prompt can be interrupted while

it is playing by pressing

g again.

For example, if the prompt seems to be taking too long to

finish, press

g again and the

beep should happen right away.

There are two voice prompt modes supported:

Long verbal prompts: The longer prompts provide more information regarding the supported actions.

Short prompts: The short prompts provide simple instructions about what can be stated.

If a command is not spoken, the voice recognition system says a help prompt.

Prompts and Screen Displays

While a voice recognition session is active, there will be corresponding buttons on screens displayed. Manual interaction in the voice recognition session is permitted. Interaction during a voice session may be completed entirely using voice commands, or some selections may expedite a session. If a selection is made using a manual control, the dialogue will progress in the same way as if the selection was made through a voice command. Once the system is able to complete the task, or the session is terminated, the voice recognition dialogue stops.

An example of this type of manual intervention is pressing on an entry of a displayed number list instead of speaking the number associated with the entry desired.

Page 86

Black plate (85,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 85

Cancelling Voice Recognition

Press the Home screen button. Pressing this button will terminate the voice recognition session.

Press or say “stop” or “cancel” to terminate the voice recognition session and display the screen from which voice recognition was initiated.

Press i on the steering wheel controls to terminate the voice session and display the screen from which voice recognition was initiated.

Most languages do not support natural language commands in sentence form. For those languages, use direct commands like the examples shown on the display.

Helpful Hints for Speaking Commands

Voice recognition can understand commands that are either naturally stated in sentence form or direct commands that state the application and the task.

For best results:

Listen for the prompt and wait for the beep before saying a command or reply.

Say “I need help” or look at the screen display for example commands.

Voice recognition system prompt can be interrupted while it is

playing by pressing

g again.

For example, if the prompt seems to be taking too long to finish, to speak the command without waiting for the prompt to

complete, press

g again and

wait for the beep.

Speak the command naturally, not too fast, not too slow. Use direct commands without a lot of extra words.

Usually Phone and Audio commands can be spoken in a single command.

For example, “Call Dave Smith at work,” “Play” followed by the artist or song name, or “Tune” followed by the radio station number.

Navigation destinations are too complex for a single command. First, state a command that explains the type of destination needed, such as I want directions to an “address,” “Navigate to an intersection," ”I need to find a destination POI or POI,” or “Directions to a Contact.” The system responds by requesting more details. After saying “destination POI,” only major chains are available by name. Chains are businesses with at least 20 locations. For

Page 87

Black plate (86,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

86 Infotainment System

other POIs, say the name of a category like “Restaurants,” “Shopping Malls,” or “Hospitals.”

Most languages do not support natural language commands in sentence form. For those languages, use direct commands like the examples shown on the display.

There is no need to memorise specific command words. Direct commands might be more clearly understood by the system. An example of a direct command would be “call <Phonenumber>.” Examples of these direct commands are displayed on most of the screens while a voice session is active. If “go to phone” or “go to phone commands Commands,” is stated, the system understands that a phone call is requested and will respond with questions until enough details are gathered.

If the phone number has been saved with a name and a place, the direct command should include both, for example “Call Dave Smith at work.”

Using Voice Recognition for List Options

When a list is displayed, a voice prompt will ask to confirm or select an option from that list. A selection can be made by manually selecting the item, or by speaking the line number for the item to select.

When a screen contains a list, there may be options that are available but not displayed. The list on a voice recognition screen functions the same as a list on other screens. Scrolling or flinging can be used to help display other entries from the list.

Manually scrolling or paging the list on a screen during a voice recognition session suspends the current voice recognition event and plays the prompt “Make your selection from the list using the

manual controls, press

q BACK on

the faceplate, or press the Back screen button to try again.”

If manual selection takes more than 15 seconds, the session terminates and prompts that it has timed out. The screen returns back to the screen where voice recognition was initiated.

The Back Command

Say “back” or press

q BACK on the

faceplate, or press the Back screen button to go to the previous screen.

If in voice recognition, and “back” is stated all the way through to the initial screen, then “go back” is stated one more time, the voice recognition session will cancel.

Help

Say “I need help” on any voice recognition screen and the help prompt for the screen is played. Additionally, a pop-up displays a text version of the help prompt. Depending on how voice recognition

Page 88

Black plate (87,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 87

was initiated, the Help pop-up will either display on the instrument cluster or the infotainment touchscreen. Press the Dismiss button to make the pop-up go away.

Pressing

g while the help prompt is

playing will terminate the prompt and a beep will be heard. Doing this will stop the help prompt so that a voice command can be used.

Voice Recognition for the Radio

All audio screens have a voice recognition button (

g) to launch

audio voice recognition. If the voice button is pressed in a radio screen, the voice commands for radio and media features are available.

“Switch to AM”: Switch bands to AM and tune to the last AM radio station.

“Switch to FM”: Switch bands to FM and tune to the last FM radio station.

“Tune to <AM frequency> AM”:

Tune to the radio station whose frequency is identified in the command (like "nine fifty").

“Tune to <FM frequency> FM”:

Tune to the radio station whose frequency is identified in the command (like “one o one point one”).

Voice Recognition for Audio My Media

If browsing My Media when the voice button is selected, the voice recognition commands for My Media features are available.

“artist”: Begin a dialogue to enter a specific Artist name.

“artist <artist name>”: Begin playback of the media selection identified in the command.

“album”: Begin a dialogue to enter a specific album name.

“album <album name>”: Begin playback of the identified album name in the command.

“go to song”: Begin a dialogue to enter a specific song name.

“go to song <song name>”:

Begin playback of the identified song name in the command.

“genre”: Begin a dialogue to enter a specific genre.

“genre <genre name>”: Begin playback of the media selection identified in the command.

“go to playlist”: Begin a dialogue to enter a specific playlist name.

“go to playlist <playlist name>”:

Begin playback of the identified playlist in the command.

Page 89

Black plate (88,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

88 Infotainment System

“Play <device name>”: Play music from a specific device identified by name. The device name is the name displayed on the screen when the device is first selected as an audio source.

“audiobook chapter”: Begin a dialogue to enter a specific name.

“audiobook chapter <chapter name>”: Begin playback of the

media selection identified in the command.

“audiobook”: Begin a dialogue to enter a specific name.

“audiobook <audiobook name>”: Begin playback of the

media selection identified in the command.

“Play CD Track <track number>”: Begin playback of the

CD at the track identified in the command.

“Play Episode”: Begin a dialogue to enter a specific name.

“Play Episode <episode name>”: Begin playback of the

media selection identified in the command.

“go to podcast”: Begin a dialogue to enter a specific name.

“go to podcast <podcast name>”: Begin playback of the

media selection identified in the command.

“go to video”: Begin a dialogue to enter a specific name.

“go to video <video name>”:

Begin playback of the media selection identified in the command.

“go to mymedia”: Begin a dialogue to enter the desired media content.

Handling Large Amounts of Media Content

It is expected that large amounts of media content will be brought into the vehicle. It may be necessary to handle large amounts of media content in a different way than

smaller amounts of media. The system may limit the options of voice recognition by not allowing selection of song titles by voice at the highest level if the number of songs exceeds the maximum limit.

Voice command option changes through media content limits are:

Song files including other individual files of all media types such as audiobook chapters, podcast episodes, and videos.

Album type folders including types such as albums and audiobooks.

There are no restrictions if the number of song files and albums is less than 4,000. When the number of song files connected to the system is between 4,000 and 8,000, the content cannot be accessed directly with one command like “Play <song name>.”

Page 90

Black plate (89,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 89

The restriction is that the command “go to song” must be spoken first; the system will then ask for the song name. The reply command would be to say the name of the song to play.

Similar limits exist for album content. If there are more than 4,000 albums, but less than 8,000, the content cannot be accessed directly with one command like, “Play <album name>.” The command “album” must first be spoken; the system will then ask for the album name. The reply would be to say the name of the album to play.

Once the number of songs has exceeded approximately 8,000, there is no support for accessing the songs directly through voice commands. There will still be access to the media content by using commands for playlists, artists, and genres.

The access commands for playlists, artists, and genres are prohibited after the number of this type of media exceeds 4,000.

The system will provide feedback the first time voice recognition is initiated if it has become apparent that any of these limits are reached during a device initialising process.

Voice Recognition for Navigation

“Nav”: Begin a dialogue to enter specific destination information.

“Nav Commands”: Begin a dialogue to enter specific destination information.

“address”: Begin a dialogue to enter a specific destination address, which includes the entire address consisting of the house number, street name, and city and state.

“crossroad”: Begin a dialogue to enter a specific destination intersection.

“Destination destination POI”:

Begin a dialogue to enter a destination Place of Interest category or major brand name (if equipped).

Not all brand names of businesses are available for voice entry. Most major chains, such as chains with more than 20 locations, should be available to search for by name, but the name must be precisely spoken. Nicknames or short names for the businesses will not likely be found. Lesser known businesses might have to be located by category, such as fast food, hotels, or banks.

“contact”: Begin a dialogue to enter a specific destination contact name.

“cancel directions”: End route guidance.

Page 91

Black plate (90,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

90 Infotainment System

Voice Recognition for the Phone

“Call <contact name>”: Initiate a call to an entered contact. The command may include location if the contact has location numbers stored.

“Call <contact name> At Home,” “At Work,” “On Mobile,” or “On

Other”: Initiate a call to an entered contact and location at home, at work, on mobile device, or on another phone.

“Call <phone number>”: Initiate a call to a standard phone number seven or 10 digits in length, and also 112.

“Pair go to phone”: Begin the Bluetooth pairing process. Follow instructions on the radio display.

“Redial”: Initiate a call to the last dialled number.

“change phone”: Select a different phone for outgoing calls.

“call international”: Begin a dialogue to enter special numbers like international numbers. The numbers can be entered in groups of digits with each group of digits being repeated back by the system. If the group of digits is not correct, the command “Delete” will remove the last group of digits and allow them to be re-entered. Once the entire number has been entered, the command “Call” will start dialling the number.

“call voice mail”: Initiate a call to voice mail numbers.

Voice Pass-Thru

Voice pass-thru/Siri®Eyes Free allows access to the voice recognition commands on the mobile phone, for example, Siri or Voice Command. See the mobile phone manufacturer's user guide to see whether the mobile phone supports this feature. To activate the phone voice recognition system,

press and hold

g on the steering

wheel for a few seconds.

This enhances the normal use of Siri. Siri allows access to text messages, calendars, and audio sources such as iTunes.

Page 92

Black plate (91,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 91

Phone

Bluetooth (Overview)

The Bluetooth-capable system can interact with many cell phones, allowing:

Placement and receipt of calls in a hands-free mode.

Sharing of the mobile phone's address book or contact list with the vehicle.

To minimise driver distraction, before driving and with the vehicle parked:

Become familiar with the features of the mobile phone. Organise the phone book and contact lists clearly and delete duplicate or rarely used entries. If possible, program speed dial or other shortcuts.

Review the controls and operation of the infotainment system.

Pair mobile phone(s) to the vehicle. The system may not work with all mobile phones. See "Pairing" in this section.

Vehicles with a Bluetooth system can use a Bluetooth-capable mobile phone with a Hands-Free Profile to make and receive phone calls. The infotainment system and voice recognition are used to control the system. The system can be used while in ON/RUN or ACC/ ACCESSORY. The range of the Bluetooth system can be up to

9.1 m (30 ft). Not all phones support all functions and not all phones work with the Bluetooth system. See www.gm.com/bluetooth for more information about compatible phones.

Controls

Use the buttons on the infotainment system and the steering wheel to operate the Bluetooth system.

Steering Wheel Controls

g (Press to Talk): Press to answer

incoming calls and start voice recognition.

i (End Call): Press to end a call,

decline a call, or cancel an operation. Press to mute or unmute the infotainment system when not on a call.

Infotainment System Controls

For information about how to navigate the menu system using the infotainment controls, see Infotainment on page 3.

PHONE: Press this screen button to enter the phone main menu.

Audio System

When using the Bluetooth phone system, sound comes through the vehicle's front audio system speakers and overrides the audio system. Press just above the chrome volume bar during a call to change the volume level. The

Page 93

Black plate (92,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

92 Infotainment System

adjusted volume level remains in memory for later calls. The system maintains a minimum volume level.

Bluetooth (Infotainment Controls)

For information about how to navigate the menu system using the infotainment controls, see Infotainment on page 3.

Pairing

A Bluetooth-enabled mobile phone must be paired to the Bluetooth system and then connected to the vehicle before it can be used. See the mobile phone manufacturer's user guide for Bluetooth functions before pairing the mobile phone.

Pairing Information

A Bluetooth phone with music capability can be paired to the vehicle as a phone and a music player at the same time.

Up to 10 devices can be paired to the Bluetooth system.

The pairing process is disabled when the vehicle is moving.

Pairing only needs to be completed once, unless the pairing information on the mobile phone changes or the mobile phone is deleted from the system.

If multiple paired cell phones are within range of the system, the system connects to the paired cell phone in the order that they were last used in the system. To link to a different paired phone, see "Linking to a Different Phone" later in this section.

Pairing a Phone

1. Press the PHONE screen button.

2. Select PHONES and select Pair Device.

3. A four-digit Personal Identification Number (PIN) appears on the display. The PIN, if required, may be used in Step 5.

4. Start the pairing process on the mobile phone to be paired to the vehicle. See the mobile phone manufacturer's user guide for information on this process.

5. Locate “Cadillac CUE” on the display. Follow the instructions provided in Step 3 on the cell phone to enter the PIN or confirm the six-digit code shown on the display. After the PIN is successfully entered or the code is confirmed, the system responds with “<Device name> has been successfully paired” when the pairing process is complete.

6. If “Cadillac CUE” does not appear, turn the phone off or remove the phone battery and retry.

7. If the phone prompts to accept connection or allow phone book download, select Always Accept and Allow. The phone book may not be available if not accepted.

Page 94

Black plate (93,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 93

8. Repeat Steps 1-7 to pair additional phones.

Listing All Paired and Connected Phones

1. Press the PHONE screen button.

2. Select PHONES.

Disconnecting a Connected Phone

1. Press the PHONE screen button.

2. Select PHONES.

3. Press the

z next to the phone to

disconnect.

Deleting a Paired Phone

Only disconnected phones can be deleted.

1. Press the PHONE screen button.

2. Select PHONES.

3. Press the

M next to the phone

to delete and follow the on screen prompts.

Linking to a Different Phone

To link to a different phone, the new phone must be in the vehicle and paired to the Bluetooth system.

1. Press the PHONE screen button.

2. Select PHONES.

3. Select the new phone to link to from the not connected device list.

Switching to Handset or Handsfree Mode

To switch between handset or handsfree mode, press the PHONE icon on the Home Page to display “Call View.”

While the active call is hands-free, press the Handset screen button to switch to the handset mode. The screen button changes to Handsfree once the Bluetooth device confirms it is operating as handset.

While the active call is on the handset, press the Handsfree screen button to switch to the hands-free mode. The screen button changes to Handset once the Bluetooth device confirms it is operating as handsfree.

Making a Call Using Contacts and Recent Calls

Calls can be made through the Bluetooth system using personal mobile phone contact information for all phones that support the Phone Book feature. Become familiar with the phone settings and operation. Verify the mobile phone supports this feature.

When supported, the Contacts and Recent Calls menus are automatically available.

The Contacts menu accesses the phone book stored in the mobile phone.

The Recent Calls menu accesses the recent call list(s) from your mobile phone.

Page 95

Black plate (94,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

94 Infotainment System

To make a call using the Contacts menu:

1. Press the PHONE screen button.

2. Select CONTACTS.

3. Select the name to call.

4. Select the desired contact number to call.

To make a call using the Recent Calls menu:

1. Press the PHONE screen button.

2. Select RECENT.

3. Select the name or number to call.

4. If necessary, select between Missed, Recent, and Sent calls by selecting the View button in the top right corner of the list.

Making a Call Using the Keypad

To make a call by dialling the numbers:

1. Press the PHONE screen button.

2. Select KEYPAD and enter a phone number.

3. Select Call to start dialling the number.

Accepting or Declining a Call

When an incoming call is received, the infotainment system mutes and a ring tone is heard in the vehicle.

Accepting a Call

There are three ways to accept a call:

Press g on the steering wheel controls.

Press Answer on the centre stack display.

Press Answer on the instrument cluster using the select button.

Declining a Call

There are three ways to decline a call:

Press i on the steering wheel controls.

Press Ignore on the centre stack display.

Press Ignore on the instrument cluster using the select button.

Call Waiting

Call waiting must be supported on the Bluetooth phone and enabled by the wireless service carrier to work.

Accepting a Call

There are three ways to accept a call-waiting call:

Press g on the steering wheel controls.

Press Switch on the centre stack display.

Press Switch on the instrument cluster using the select button.

Page 96

Black plate (95,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 95

Declining a Call

There are three ways to decline a call-waiting call:

Press i on the steering wheel controls.

Press Ignore on the centre stack display.

Press Ignore on the instrument cluster using the select button.

Switching Between Calls (Call Waiting Calls Only)

To switch between calls, press the phone icon on the Home Page to display "Call View."While in Call View, press the call information of the call on hold to change calls.

Three-Way Calling

Three-way calling must be supported on the Bluetooth phone and enabled by the wireless service carrier to work.

To start a three-way call while in a current call:

1. In the Call View, select Add to add another call.

2. Initiate the second call by selecting from RECENT, CONTACTS, or KEYPAD.

3. When the second call is active, press Merge to conference the three-way call together.

4. Once all calls are merged, the Merge button becomes an Unmerge button. Press to unmerge the calls.

Some wireless service carriers may not allow a merged call to become unmerged.

Ending a Call

Press i on the steering wheel controls.

Press End on the centre stack display to end all existing calls, or press End next to a call to end only that call.

Press End on the instrument cluster using the select button.

Dual Tone Multi-Frequency (DTMF) Tones

The in-vehicle Bluetooth system can send numbers during a call. This is used when calling a menu-driven phone system.

1. Press the PHONE screen button.

2. While in the Call View, press the up arrow to raise the Interaction Selector.

3. Select KEYPAD and enter the number.

Voice Mail

The default voice mail number is the phone number of the outgoing phone source. The voice mail number can be changed in Bluetooth settings.

To dial a voice mail number:

1. Press the PHONE screen button.

Page 97

Black plate (96,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

96 Infotainment System

2. Select VOICE MAIL.

3. Select Call.

4. Enter the DTMF tones using the keypad if needed.

Bluetooth (Voice Recognition)

Using Bluetooth Voice Recognition

To use voice recognition, press the

g button on the steering wheel. Use

the commands below for the various voice features. For additional information, say “I need help” while in a voice recognition menu. See Voice Recognition on page 83 for help using voice recognition commands.

Making a Call

Calls can be made using the following commands.

Using the “Dial” or “Call” Command

To call a number:

1. Press

g. The system responds

“Command Please,” followed by a tone.

2. Say “Dial” or “Call” followed by the complete phone number.

Use the “call international” command for international numbers or special numbers which include * or #.

Once connected, the person called will be heard through the audio speakers.

To call using a contact from your phone book:

1. Press

g. The system responds

“Command Please,” followed by a tone.

2. Say “Dial” or “Call” and then say the contact name. For example “Call John at Work.”

Once connected, the person called will be heard through the audio speakers.

Calling 112 Emergency

1. Press

g. The system responds

“Command Please,” followed by a tone.

2. Say “Call 112.”

Once connected, the person called will be heard through the audio speakers.

Using the “change phone” Command

1. Press

g. The system responds

“Command Please,” followed by a tone.

2. After the tone, say “change phone.” The system displays a list of phones to select.

Page 98

Black plate (97,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 97

Using the “call international” Command

1. Press

g. The system responds

“Command Please,” followed by a tone.

2. After the tone, say “call international.The system allows entry of special numbers and characters.

Using the “Voice Mail” Command

1. Press

g. The system responds

“Command Please,” followed by a tone.

2. After the tone, say “call voice mail.The system dials the voice mail number of the connected phone.

Clearing the System

Unless information is deleted out of the vehicle Bluetooth system, it will be retained. This includes phone pairing information. For directions on how to delete this information, see "Deleting a Paired Phone."

Text Messaging

If equipped, the infotainment system may allow text messages to be received and replied to. Received messages can also be read aloud.

Text Menu

Inbox: Press to display incoming

messages. To view a message, press on the name of the sender.

Press

> to listen to the text

message. Press the

[ Back screen

button to go back to the previous menu.

Settings: See "Text Settings" later in this section.

Reply: Press to reply using a predefined text message. See "Text Settings."

Call: Press to place a call to the sender of the text message.

Viewing a Text Message

While viewing a text message:

Press Reply to reply using a predefined text message.

Press Call to place a call to the sender of the text message.

Viewing Sender Information

If equipped, press the name of the sender to view sender information if this information matches contact information already stored.

Select a Predefined Message:

Press to select from a set of quick messages. Press the message to send.

Predefined Messages

These are short text messages that can be used to send so responses will not have to be typed.

The messages can be deleted or a new message can be added.

Page 99

Black plate (98,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

98 Infotainment System

To add a new message:

1. Press Text Settings, then press Manage Predefined Messages.

2. While in the predefined messages list view, select Add New Predefined Message and a keyboard displays.

3. Type a new message and press NEW MSG when done to add

the message. Press the

[ Back

screen button to go back to the predefined messages list. Press

z to delete one character at

a time.

Memory Full

This message may display if there is no more room on the phone to store messages.

Text Settings

Text Alerts: When on, this feature

will display an alert when a new text message has been received. Press to turn on or off.

Manage Predefined Messages:

Press to add, change, or delete predefined messages.

Settings

The Settings Menu allows adjustment of different vehicle and radio features. The menu may contain the following:

Time and Date

See "Clock" in the owner manual.

Language

This will set the display language in the radio, instrument cluster, and voice recognition. Press Language and select the appropriate

language. Press the

[ Back screen

button to go back to the previous menu.

Valet Mode (If Equipped)

This will lock the infotainment system, steering wheel controls, and steering column. It will also limit top speed, power, and access to vehicle storage locations. The storage behind the infotainment system can still be accessed manually.

Page 100

Black plate (99,1)

Cadillac CUE Infotainment System - 2015 - crc - 7/1/14

Infotainment System 99

To access:

1. Enter a four-digit code on the keypad.

2. Press Enter to go to the confirmation screen.

3. Re-enter the four-digit code.

Press LOCK to lock the system. Press

[ Back to go back to the

previous menu.

Radio

Press to display the Radio Menu and the following may display:

Manage Favourites: Press a displayed Favourite to select that favourite to edit. Press Rename to rename the favourite or Delete to delete it. Press and hold the station to drag it to a new location. Press Done to go back to the previous menu.

Number of Favorites Shown: Press to set the number of favourites to display. Select Auto, 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, or 60. Auto will

automatically add or hide additional Favourite pages based on the amount of

Favourites stored. Press the

[

Back screen button to go back to the previous menu.

Tag Song: Press to tag song information, including artist and title, to transfer to an iPod

. See

AM-FM Radio on page 11.

Timeshift: Timeshift is the recording of a radio station for up to 25 minutes. See

“Timeshifting” under AM-FM Radio on page 11.

Tone Settings:

‐ Bass, Midrange, Treble –

Press + or − to adjust.

‐ Surround – If equipped, press

+ or − to adjust.

‐ Balance – Press

S or T for

more sound from the left or right speakers. The middle

position balances the sound between the left and right speakers.

‐ Fade – Press

y or z for

more sound from the front or rear speakers. The middle position balances the sound between the front and rear speakers.

Maximum Start-Up Volume: This feature sets the maximum start-up volume. If the vehicle is started and the volume is greater than this level, the volume is adjusted to this level. To set the maximum startup volume, press + or - to increase

or decrease. Press the

[ Back

screen button to go back to the previous menu.

Audio Cue Volume (If Equipped): This feature adjusts the start-up and shut-down sounds. To adjust the volume, press + or to increase or decrease. This

Cadillac 2015 CUE Infotainment, 2015 CUE Infotainment System System User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
